Panasonic SCHC30DB Operating Instructions
RQTX1072-2B
EB
Operating Instructions
Compact Stereo System
Model No.
SC-HC30DB
Dear customer
Thank you for purchasing this product.
Before connecting, operating or adjusting this product, please
read the instructions completely. Please keep this manual for
future reference.
Operations in these instructions are described using remote
control, but you can do the operations with the main unit if the
controls are the same.
Your unit may not look exactly as illustrated.
The included AC mains lead is for use with this unit only. Do
not use it with other equipment.
Do not use an AC mains lead of other equipment.
•
•
Please check and identify the supplied
accessories.
Supplied accessories
Model number suffix “EB” denotes UK model.
Use numbers indicated in parentheses when asking
for replacement parts. (Product numbers correct as of
February 2010. These may be subject to change.)
Supplied accessories Cover page
Caution for AC Mains Lead 2
Connections 4
Attaching the unit to a wall (Optional) 5
Control guide 8
Disc operations 9
Radio operations 10
DAB 11
Timer 14
Sound adjustment 14
External unit 15
Troubleshooting guide 17
Memory reset (Initialization) 18
Maintenance 18
Specifications 19
Safety precautions Back cover
Table of contents
1 AC mains lead
(K2CZ3YY00005)
1 DAB antenna
(N1EADY000001)
1 Remote control
(N2QAYB000521)
2 Batteries
Screw accessories (RFAX1020)
2 Fixing screws
(XYN3+J10FJ)
1 Safety holder
(RMKX1015)
Wall bracket accessories (RFAX1021)
1 Wall bracket
(RGQX1004)
Four-legged cushions
(RKAX0028-K)
B
RQTX1072
2
2
How to replace the fuse
The location of the fuse differ according to the type of AC mains
plug (figures A and B). Confirm the AC mains plug fitted and
follow the instructions below.
Illustrations may differ from actual AC mains plug.
1. Open the fuse cover with a screwdriver.
Figure A Figure B
2. Replace the fuse and close or attach the fuse cover.
Figure A Figure B
Fuse cover
Sales and Support Information
Customer Care Centre
For customers within the UK: 0844 844 3852
For customers within the Republic of Ireland:
01 289 8333
Visit our website for product information
www.panasonic.co.uk
E-mail: customer.care@panasonic.co.uk
Direct Sales at Panasonic UK
For customers: 0844 844 3856
Order accessory and consumable items for your
product with ease and confidence by phoning our
Customer Care Centre
Monday–Thursday 9:00 a.m.–5:30 p.m.,
Friday 9:30 a.m.–5:30 p.m.
(Excluding public holidays)
Or go on line through our Internet Accessory ordering
application at www.pas-europe.com.
Most major credit and debit cards accepted.
All enquiries transactions and distribution facilities are
provided directly by Panasonic UK Ltd.
It couldn’t be simpler!
Also available through our Internet is direct shopping
for a wide range of finished products, take a browse on
our website for further details.
•
•
•
•
•
•
•
•
•
•
•
Fuse
(5 ampere)
Fuse
(5 ampere)
For your safety, please read the following text carefully.
This appliance is supplied with a moulded three pin mains plug
for your safety and convenience.
A 5-ampere fuse is fitted in this plug.
Should the fuse need to be replaced please ensure that
the replacement fuse has a rating of 5-ampere and that it is
approved by ASTA or BSI to BS1362.
Check for the ASTA mark or the BSI mark on the body
of the fuse.
If the plug contains a removable fuse cover you must ensure
that it is refitted when the fuse is replaced.
If you lose the fuse cover the plug must not be used until a
replacement cover is obtained.
A replacement fuse cover can be purchased from your local
dealer.
CAUTION!
IF THE FITTED MOULDED PLUG IS UNSUITABLE FOR
THE SOCKET OUTLET IN YOUR HOME THEN THE FUSE
SHOULD BE REMOVED AND THE PLUG CUT OFF AND
DISPOSED OF SAFELY.
THERE IS A DANGER OF SEVERE ELECTRICAL SHOCK
IF THE CUT OFF PLUG IS INSERTED INTO ANY
13-AMPERE SOCKET.
If a new plug is to be fitted please observe the wiring code as
stated below.
If in any doubt please consult a qualified electrician.
IMPORTANT
The wires in this mains lead are coloured in accordance with
the following code:
Blue: Neutral, Brown: Live.
As these colours may not correspond with the coloured
markings identifying the terminals in your plug, proceed as
follows:
The wire which is coloured Blue must be connected to the
terminal which is marked with the letter N or coloured Black or
Blue.
The wire which is coloured Brown must be connected to the
terminal which is marked with the letter L or coloured Brown or
Red.
WARNING: DO NOT CONNECT EITHER WIRE TO THE
EARTH TERMINAL WHICH IS MARKED WITH THE
LETTER E, BY THE EARTH SYMBOL OR COLOURED
GREEN OR GREEN/YELLOW.
THIS PLUG IS NOT WATERPROOF–KEEP DRY.
Before use
Remove the connector cover.
Caution for AC Mains Lead
RQTX1072
3
CAUTION!
DO NOT INSTALL OR PLACE THIS UNIT IN A
BOOKCASE, BUILT-IN CABINET OR IN ANOTHER
CONFINED SPACE. ENSURE THE UNIT IS WELL
VENTILATED. TO PREVENT RISK OF ELECTRIC SHOCK
OR FIRE HAZARD DUE TO OVERHEATING, ENSURE
THAT CURTAINS AND ANY OTHER MATERIALS DO
NOT OBSTRUCT THE VENTILATION VENTS.
DO NOT OBSTRUCT THE UNIT’S VENTILATION
OPENINGS WITH NEWSPAPERS, TABLECLOTHS,
CURTAINS, AND SIMILAR ITEMS.
DO NOT PLACE SOURCES OF NAKED FLAMES, SUCH
AS LIGHTED CANDLES, ON THE UNIT.
DISPOSE OF BATTERIES IN AN ENVIRONMENTALLY
FRIENDLY MANNER.
•
•
•
•
WARNING:
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR
PRODUCT DAMAGE,
* DO NOT EXPOSE THIS APPARATUS TO RAIN,
MOISTURE, DRIPPING OR SPLASHING AND THAT NO
OBJECTS FILLED WITH LIQUIDS, SUCH AS VASES,
SHALL BE PLACED ON THE APPARATUS.
* USE ONLY THE RECOMMENDED ACCESSORIES.
* DO NOT REMOVE THE COVER (OR BACK); THERE
ARE NO USER SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION!
THIS PRODUCT UTILIZES A LASER.
USE OF CONTROLS OR ADJUSTMENTS OR
PERFORMANCE OF PROCEDURES OTHER THAN THOSE
SPECIFIED HEREIN MAY RESULT IN HAZARDOUS
RADIATION EXPOSURE.
DO NOT OPEN COVERS AND DO NOT REPAIR
YOURSELF. REFER SERVICING TO QUALIFIED
PERSONNEL.
The socket outlet shall be installed near the equipment and
easily accessible.
The mains plug of the power supply cord shall remain readily
operable.
To completely disconnect this apparatus from the AC Mains,
disconnect the power supply cord plug from AC receptacle.
CAUTION
Danger of explosion if battery is incorrectly replaced. Replace
only with the same or equivalent type recommended by the
manufacturer. Dispose of used batteries according to the
manufacturer’s instructions.
This product may receive radio interference caused by mobile
telephones during use. If such interference is apparent,
please increase separation between the product and the
mobile telephone.
THIS UNIT IS INTENDED FOR USE IN MODERATE
CLIMATES.
MPEG Layer-3 audio decoding technology licensed from
Fraunhofer IIS and Thomson.
Inside of product
RQLS0418
AUX
RQT4389ZAA
Back of product
“Made for iPod” means that an electronic accessory has
been designed to connect specifically to iPod and has
been certified by the developer to meet Apple performance
standards.
“Works with iPhone” means that an electronic accessory has
been designed to connect specifically to iPhone and has
been certified by the developer to meet Apple performance
standards.
Apple is not responsible for the operation of this device or its
compliance with safety and regulatory standards.
iPod is a trademark of Apple Inc., registered in the U.S. and
other countries. iPhone is a trademark of Apple Inc.
or
RQTX1072
4
AUX
Connections
Back View
Connect the AC mains lead after all other connections
are complete.
Connect the AC mains lead.
2
Exhaust holes
AUX (➡ page 16)
4 3
2 1
To household mains socket
AC IN
Avoid listening for prolonged periods of time to
prevent hearing damage.
Excessive sound pressure from earphones and
headphones can cause hearing loss.
Listening at full volume for long periods may damage
the user’s ears.
Be sure to use the supplied or recommended
headphones or earphones.
•
•
•
Reduce the volume level and
connect the headphones.
Plug type: 3.5 mm stereo
3
Headphones (not included)
Tape the antenna to a wall or column, in a position
with the least amount of interference.
Please refer to “Checking the DAB signal quality”
(➡ page 13).
•
•
g Notes on speakers
These speakers do not have magnetic shielding. Do not
place them near televisions, personal computers or other
devices easily influenced by magnetism.
The speaker nets cannot be removed.
•
•
DAB outdoor antenna (Optional)
DAB outdoor antenna (not included)
Be sure to fully
tighten the screw.
Use DAB outdoor antenna for better reception.
The antenna should only be installed by a competent
technician.
Never use the outdoor antenna during lightning storm.
Please refer to “DAB” (➡ page 11).
•
•
•
•
Connect the DAB antenna to receive
FM radio and DAB (Digital Audio
Broadcasting).
1
Adhesive tape
Be sure to fully
tighten the screw.
The cross bar of the T should be kept firmly
stretched. Find a good position with good reception.
READ THE CAUTION FOR THE AC MAINS LEAD ON
PAGE 2 BEFORE CONNECTION.
RQTX1072
5
Attaching the unit to a wall (Optional)
Notes on installation
g Before installation, read the “Safety precautions” and “Wall mount instructions” for correct installation.
g For optimal performance and to prevent potential problems, do not install this unit:
at locations other than vertical walls.
near a sprinkler or a sensor.
near high-voltage lines or power sources.
near heating device.
at locations where the unit is subject to vibration or impact.
near sources of magnetism, heat, vapour, airborne grease, etc.
at locations where there may be water droplets (e.g. under an air conditioner).
g Do not install this unit under ceiling lights (e.g. spotlight, halogen light, etc.).
Failure to do so may bend the cabinet or lead to damage caused by high heat.
g Use a proper installation method that suits the structure and material of the wall.
g Use a soft blanket or cloth to prevent damage to the product or floor during installation.
g When tightening screws, make sure the screws are not loosely-tightened or overtightened.
g Secure a safe surrounding area and pay attention to safety during installation.
g Panasonic is not liable for incidental or consequential damages resulting from improper installation or operation.
•
•
•
•
•
•
•
Only a qualified building contractor shall install or
uninstall this unit.
Improper installation may cause the unit to fall, resulting in
injury.
To prevent injury, the unit must be securely attached to
the wall in accordance with the installation instructions.
Do not install the unit where it cannot support the load.
If the mounting parts are not strong enough, this may cause
the unit to fall, resulting in injury.
Do not use installation methods other than instructed.
This may cause the unit to fall and be damaged, resulting in
injury.
Do not install the unit at locations other than vertical
walls.
This may cause the unit to fall and be damaged, resulting in
injury.
Take the safety factor for mounting strength into account
(approx. 10 times the product weight).
Insufficient strength will cause the unit to fall, resulting in
injury.
The wall on which the unit is to be attached to should be
capable of supporting 20 kg per screw.
Insufficient strength of the walls will cause the unit to fall in the
long run.
Do not disassemble or modify the wall-mounting hanger.
This will cause the unit to fall and be damaged, resulting in injury.
Do not install this unit at humid or dusty locations, or
locations where airborne grease or steam may come into
contact with the unit, or under an air conditioner where
water may drip onto the unit.
This may have negative impact on the unit, resulting in fire or
electric shock.
Secure enough space of more than 30 cm above the
main unit and more than 10 cm on the left and right sides
respectively. Keep space between the wall and rear of the
unit clear of obstructions.
Blocking the exhaust holes on the main unit may result in fire.
Use the designated components for installation.
Otherwise, the main unit may fall and be damaged, resulting
in injury.
Prevent the mounting screws or power cord from coming
into contact with metal parts inside the wall during
installation.
Failure to do so may cause electric shock.
When removing the main unit, remove the wall mounting
screws as well.
Otherwise the wall mounting screws may hit a person and
lead to injury.
Install the unit at a height where the operation buttons
can be seen for safe operation.
Operating at improper position may cause the unit to fall and
be damaged, resulting in injury.
CAUTION!
Safety precautions
WARNING!
Installation accessories
g Included accessories
Screw accessories (RFAX1020)
2 Fixing screws (XYN3+J10FJ)
1 Safety holder (RMKX1015)
Wall bracket accessories (RFAX1021)
1 Wall bracket (RGQX1004)
Four-legged cushions (RKAX0028-K)
•
»
»
•
»
»
B
g Commercially available accessories (not included)
2 Wall mounting screws
1 Safety holder screw
Use screws with nominal diameter of 4 mm, which are suitable
to the material of the wall (e.g. wood, steel, concrete, etc.).
•
•
C
C
Keep all the intended accessories out of reach of
children to prevent swallowing.
RQTX1072
6
2. Attach the wall bracket to the back of the unit.
Wall mount instructions
• Before installation, turn the unit off and disconnect the AC mains lead plug from the AC receptacle.
• Tighten screws firmly to prevent slack in each step.
3. Drive the mounting screws into the wall.
Secure the wall bracket with fixing screw (2 pieces).
(Tightening torque: 1.2 Nm to 1.5 Nm)
2
1
Fixing screw
B
Tab
Rear of main unit
Wall bracket (bottom view)
Align both tabs on the wall bracket and the main
unit, then slide it in until it clicks into place.
B
AUX
300 mm
Space required
Rear View
Space required
85.5 mm77.5 mm
500 mm
700 mm
74.8 mm
130 mm
8 mm to 9.5 mm
2.2 mm to 2.8 mm
2.5 mm to 3.5 mm
4 mm
A length which supports the
strength of 20 kg or more must
be kept for each screw.
Wall
Mounting screw
C
163 mm
Measure and mark the position of the mounting screw (2 pieces) and drive them into the wall.
Use figures below for screw positions and measurements.
Please install using both wall mounting screws.
Use a level ruler to ensure both screws are level.
Use a screw which is strong enough to support the weight of at least 20 kg.
•
•
•
•
C
1. Detach the stand from the unit.
Bottom of main unit
Stand
Soft blanket
or cloth
Fixing screw
A
Slide the stand off the unit.
Unscrew the fixing screw (2 pieces) at the bottom of
the unit.
Keep the removed screws in a safe place.
A
Attaching the unit to a wall (Optional) (continued)
Loading...
