Halo Flash™
User’s
Guide
®
®
Important!
Read this manual carefully, and keep for future reference.
Register online at: www.oreck.com/customer-service/registration
Enjoy
Call
Click
Visit
Thank You for purchasing an Oreck Halo Flash™! This state-of- the-art UV-C handheld will help give you a healthier clean home. Benefits of your new unit include:
•Completely chemical free
•Germicidal ultraviolet light that neutralizes many dust mite eggs, viruses, bacteria, mold, and other germs
•5 year warranty
This combination of technologies provides broad protection against a wide range of contaminants to help give you a healthier clean home.
At Oreck, we understand that our customers are unique and expect superior service. To meet your needs, we offer different customer service options to work with your lifestyle and preferences.
Welcome to our Call. Click. Visit. customer service program.
To speak with an Oreck representative call:
USA: 1•800•989•3535
Canada: 1•888•676•7325
On the web, point and click at: www.oreck.com
or visit www.oreck.com and click (locate a store) on the top right.
Visit any of our nearly 450 Oreck Clean Home Centers. To find the nearest store, please call 888•oreck
(1•888•673•2578).
Contents |
General Warnings |
|
|
. . . . . . . . . . . . |
. . . . . |
. 4 |
|||||
|
|
. |
|||||||||
|
Environment . |
|
. . |
. . . . . . . . . . . |
. . . . . . . . . . |
. . . |
. . . . . . . . . |
. |
. 4 |
||
|
Operation . . |
|
. . . . . . . . . . . . . |
. . . . . |
. 4 |
||||||
|
Ultraviolet Light |
. . . . . . . . . . . |
. . . . . . . . . . |
. . . |
. . . . . . . . . |
. |
. 5 |
||||
|
Parts. . |
. . . . . . . . . . . . . . . . . . . . . . . 7 |
|||||||||
|
Product Components & Accessories . . . . . |
. . . |
. . . . . . . . . |
. |
. 7 |
||||||
|
Features . . |
. . . |
. . . . . . |
. . . . . |
. . . . . . . 8 |
||||||
|
Assembly . . |
. . |
|
. . . . . . . |
. . . . . . . . . . . . 8 |
||||||
|
Use . . |
. . . . . . . . . . . . . . . . . . . . . . . 9 |
|||||||||
|
Operating the Oreck Halo Flash™ Handheld |
. . |
. . . . . |
|
.9 |
||||||
|
Using Ultraviolet (UV-C) Technology . . |
. . |
. . . . |
. |
9 |
||||||
|
Operating a Vacuum with the Oreck Halo Flash |
|
|
|
|||||||
|
Handheld . . |
. . . . . . . . . . . . . . |
. . . . . |
.10 |
|||||||
|
Operating the Oreck Halo Flash Handheld with |
|
|
|
|||||||
|
the Oreck Halo Flash™ Vac . . |
. . . . . . . |
. . . . . 10 |
||||||||
|
Cleaning Tips. |
. |
. . . . . . . . . . . . |
. . . . . 11 |
|||||||
|
Maintenance. |
. . . . . . . . . . . . . . . |
. . . . . |
|
12 |
||||||
|
Replacement and Disposal of the |
|
|
|
|
||||||
|
Ultraviolet Bulb . |
. . . . . . . . . . . . |
. . . . . 12 |
||||||||
|
Ultraviolet Bulb Replacement. |
. . . . . . |
. . . . . |
12 |
|||||||
|
Ultraviolet Bulb Disposal. . . . |
. . . . . . . . . . |
. . . |
. . . . . . . . . |
. |
12 |
|||||
|
Ultraviolet Bulb Cover Cleaning . . . . . . . . |
. . . |
. . . . . . . . . |
. |
12 |
||||||
|
Troubleshooting . . |
|
. . . . . . |
. . . . . |
. . . . . . . 13 |
||||||
|
Accessories . |
. . . . . . . . . . . . . . . |
. . . . . |
|
13 |
||||||
|
Warranty. . |
. . . . . . . . . . . . . . . . |
. . . . |
. |
14 |
||||||
|
|
|
|
|
|
|
|
|
|
|
|
Safety |
General Warnings |
|
! IMPORTANT SAFETY
INSTRUCTIONS
When using an electrical appliance, basic precautions should always be followed, including the following:
Read all instructions before using this unit.
WARNING! To reduce the risk of fire, electric shock, or injury:
•The unit is intended for household use only.
•Use the unit only as described in this manual.
•Use only manufacturer’s recommended attachments.
DO NOT EXPOSE SKIN OR EYES TO THE UV-C LIGHT THROUGH TRANSPARENT OR TRANSLUCENT MATERIALS INCLUDING BUT NOT LIMITED TO CLOTHING, GLASS, MESH, SCREENS, PLASTIC & PLEXIGLASS.
Environment
Use of the unit outdoors or on wet surfaces may result in damage to the appliance and void the warranty. Do not use outdoors or on wet surfaces.
Operation
This appliance has an ultraviolet bulb and powerful suction capability. Do not allow it to be used as a toy and always maintain close attention when used by or near children.
Use of the unit with an opening blocked may reduce air-flow and suction. Keep all openings free of dust, lint, hair etc.
Improper handling of the power cord may result in wiring, connection damage and potential sparking or shock. Always follow these instructions when handling the power cord:
•Do not pull or carry the unit by the cord
•Do not use the cord as a handle
•Do not close a door on the cord
•Do not pull the cord around sharp edges or corners
•Keep the cord away from heated surfaces
•Do not run another appliance over the cord
•Always grasp the plug, not the cord, when unplugging the unit
A damaged cord or plug may cause a spark, shock and fire. Always check the cord and plug before use. If appliance is not working as it should, has been dropped, damaged, left outdoors, or dropped into water, return it to a service center or call customer service at: U.S.: 1-800-989-3535 Canada: 1-888-676-7325.
Using the unit with wet hands and on wet surfaces may result in unexpected shock, slippage and personal injury. Do not handle the plug or appliance with wet hands or on wet surfaces.
Operation of the appliance in a stationary position for any period of time may result in property (e.g.: carpet color loss) or appliance damage. Always keep the unit moving while in operation.
Moving the unit over burning or smoking objects, flammable or combustible liquids and toxic material may result in a fire and personal injury. Do not move the unit over burning or smoking objects, flammable or combustible liquids.
Do not leave appliance unattended when plugged in. Unplug from outlet when not in use and before servicing.
Polarized Plug Notice
This product is equipped with a polarized alternating current line plug (a plug having one blade wider than the other). This plug will fit into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact an electrician to replace the obsolete outlet. Do not defeat the purpose of the polarized plug.
Ultraviolet Light
We learned that ultraviolet light (UV-C) had been used for decades to disinfect hospitals and sterilize drinking water.
This product emits germicidal ultraviolet light. Exposure to
or touching the ultraviolet light during operation may result in burns and skin or vision damage.
Follow these safety guidelines when using the ultraviolet light:
• Never stare directly at the ultraviolet light.
•While the unit is in operation never pick up and turn over the unit.
•Never touch the bottom of the unit or protective lens. Allow the UV-C light and protective lens to cool down before touching the bottom of the unit or storing the unit.
Safety features have been designed into the unit to minimize the risk of personal injury. These include:
•The unit must be on a flat surface to activate the UV-C light.
•The UV-C light will disengage if the product is raised off the flat surface or placed on a non-flat surface.
•Keep the unit moving while in use.
•HEAT PROTECTION SYSTEM:
If the Oreck Halo Flash™ is used without continuous suction for an extended period of time, the heat protection system will shut off the UV-C bulb to avoid overheating and prevent permanent damage to the UV-C bulb and housing.
NOTE: The light around the Oreck Halo® Technology logo will blink when the heat protection system shuts off the UV-C bulb. The unit must remain unplugged for at least 30 minutes for the UV-C bulb to cool and the system to reset.
WARNING: The UV-C bulb cover can become very hot to the touch. Do not place on any surface that can be damaged by temperatures of 120 F or higher.
Any attempt to turn the ultraviolet light ON by defeating the UV-C light switch or other safety features may result in personal injury and is considered an unauthorized use of the appliance.
DO NOT EXPOSE SKIN OR EYES TO THE UV-C LIGHT THROUGH TRANSPARENT OR TRANSLUCENT MATERIALS INCLUDING BUT NOT LIMITED TO CLOTHING, GLASS, MESH, SCREENS, PLASTIC & PLEXIGLASS.
If necessary, call customer service or take the unit into an authorized Oreck service center.
SAVE THESE
INSTRUCTIONS
|
Residential Use Only |
|
Parts |
2 |
||||
|
Product Components & Accessories |
||||
|
1 |
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
4
3
(optional accessory)
6 Halo glow
5 |
|
|
|
|
8 |
|
8 |
|
7 |
|
|
Side, Front, and Bottom View |
|
9 |
|
|
|
||
1. |
Soft grip handle |
5. |
Power cord connection |
2. |
UV-C activation |
6. |
Ultraviolet (UV-C) |
|
switch |
|
light indicator |
3. |
Canister Hose Opening |
7. |
Vacuum suction |
4. |
Power cord |
8. |
Safety Sensors (4 total) |
|
(optional accessory) |
9. |
UV-C Bulb Cover |
|
|
Features
Assembly
Important Features of the Oreck Halo Flash™
Handheld Unit
1. UV-C Activation Switch:
Squeeze and hold to activate UV-C light.
2.UV-C Technology:
Patented UV-C technology safely neutralizes many dust mite eggs, viruses, bacteria, and mold. The light around the Oreck Halo® Technology logo will glow when UV-C is activated.
Halo glow
3.Power Cord: Long power cord provides a wide range of use. (this is an optional accessory and may not be included; power cord included with model no. FLASH100)
The only assembly necessary before using the unit is to attach the power cord.
Note: If you are using the Oreck Halo Flash™ Handheld with the Oreck Halo Flash™ Vac, the power cord is not necessary. The Oreck Flash™ Vac powered suction hose has built-in power.
Use |
Operating the Oreck Halo Flash™ Handheld |
|
1. Place the unit on a non-transparent/non-translucent surface. |
|
Ensure that all four safety sensors are in contact with the surface |
|
or up to 1/2 inch of the surface. |
|
2. Plug in the power cord. (If using the Oreck Halo Flash™ with |
|
the Oreck Halo Flash™ Vac, the power cord is not necessary. |
|
The Oreck Halo Flash™ powered suction hose will provide the |
|
power to the unit.) |
|
3. Squeeze and hold the |
|
UV-C activation |
|
switch. |
|
4. Uses include: |
|
Mattresses, uphol- |
|
stery, tabletops, |
|
countertops, changing |
|
tables, appliances, vir- |
|
tually anything that |
|
has a flat surface. |
Using Ultraviolet (UV-C) Technology
To engage the ultraviolet light and the disinfecting power of the Oreck Halo Flash™ Handheld:
1. Follow the basic operating steps.
2. Squeeze and hold the UV-C activation switch.
Note: The oval light around the Oreck Halo® Technology logo will illuminate indicating power is being supplied to the ultraviolet light. There is a short delay before the ultraviolet light is activated.
Halo glow
Operating a Vacuum with the Oreck Halo Flash™ Handheld Unit
The Oreck Halo Flash Handheld™ will work with the Oreck Halo
Flash™ Vacplus many canisters and vacuums with hose attachment openings.
1.Attach vacuum hose to the opening on the Oreck Halo Flash™ Handheld.
2.Connect the Oreck Halo Flash™ Handheld power cord and plug it and the vacuum/canister power cord into a 120V/60Hz socket.
3.Turn the vacuum/canister on.
4.Follow the basic operating steps on page 9 to operate the UV-C technology.
5.Vacuum at a steady speed. There is no need to exert pressure.
Operating the Oreck Halo Flash™ Handheld with the Oreck Halo Flash™ Vac
1.Insert the Oreck Halo Flash Vac™ powered suction hose (with blue ends) into the Oreck Halo Flash™ Handheld until click is heard.
2.Unwind the necessary length of cord from the Oreck Halo Flash™ Vac and insert the plug into a 120V/60Hz socket. (Note: The Oreck Halo Flash™ Handheld power cord is NOT necessary when using the Oreck Halo Flash™ Vac powered suction hose.)
3.Push on/off switch that is located on the top handle of the Oreck Halo Flash™ Vac to produce suction.
4.Place the Oreck Halo Flash™ Handheld on a flat surface and make sure that all four safety sensors are touching.
5.Follow the basic operating steps on page 9 to operate the UV-C technology.
6.Vacuum at a steady speed. There is no need to exert pressure.
7.To adjust the suction power, slide the suction bar on top of the Oreck Halo Flash™ Vac.
8.If the Oreck Halo Flash™ Handheld is removed to use one of the Oreck Halo Flash™ Vac vacuuming accessories, you must remove the powered suction hose and replace it with the nonpowered suction hose included in the Oreck Halo Flash™ Vac.
9.Shoulder strap and accessory tool caddy are included in the Oreck Halo Flash™ Vac for easier portability.
10
Cleaning
Tips
•Follow all safety warnings.
•Keep the Oreck Halo Flash™ Handheld moving while in use.
•Keep the Oreck Halo Flash™ Handheld close to the surface or unit
will automatically shut off.
•Operate the unit in a slow, back-and-forth motion. See table below for estimated exposure times to neutralize many common microorganisms.
Microorganism |
Seconds for |
|
99.99% Kill |
||
|
||
|
|
|
|
Virus* |
Bacteriophage-E. Coli |
|
0.33 |
|
|
|
Infectious Hepatitis |
|
0.40 |
|
|
|
Influenza |
|
0.33 |
|
|
|
Poliovirus |
|
0.33 |
|
|
|
Bacteria* |
|
|
|
|
|
Bacillus anthracis - Anthrax |
|
0.44 |
|
|
|
E. coli |
|
0.33 |
|
|
|
Mycobacterium tuberculosis |
|
0.50 |
|
|
|
Salmonella enteritidis |
|
0.38 |
|
|
|
Mold* |
|
|
|
|
|
Penicillium expansum |
|
1.10 |
|
|
|
*Estimates only. Results may vary. Extent of killing on surfaces depends on microorganism exposure time. The Oreck Halo Flash™ is not intended for use in the cure, mitigation, treatment, or prevention of any disease or medical condition, including asthma, allergies or the influenza virus.
11
Maintenance
! WARNING!
Performing maintenance on the unit while it is plugged into a wall outlet may result in unexpected unit operation, shock and personal injury. Always unplug before performing inspection and maintenance.
DO NOT EXPOSE SKIN OR EYES TO THE UV-C LIGHT THROUGH TRANSPARENT OR TRANSLUCENT MATERIALS INCLUDING BUT NOT LIMITED TO GLASS, MESH, SCREENS, PLASTIC & PLEXIGLASS.
! CAUTION!
Replacement and Disposal of the Ultraviolet Bulb
Contact with the small amount of mercury in the ultraviolet bulb may cause health problems. Always take proper precautionary measures (e.g.: containment, proper clean up supplies, dress etc.) when exposed to mercury.
Ultraviolet Bulb Replacement
If necessary, replacement of the ultraviolet bulb should only be conducted by qualified service personnel. Should there be any problem with the bulb, please visit oreck.com or call for more information: U.S.: 1-800-989-3535 Canada 1-888-676-7325
Ultraviolet Bulb Disposal
Please manage and make any disposal of the Oreck Halo® ultraviolet bulb in accordance with local disposal laws. For more information, please see www.lamprecycle.org or call:
U.S.: 1-800-989-3535 Canada: 1-888-676-7325
Ultraviolet Bulb Cover Cleaning
Clean the quartz glass with a non-abrasive cleaning solution, such as rubbing alcohol or glass cleaner with a clean soft cloth to prevent scratching the surface.
12
Troubleshooting
Accessories
If the following troubleshooting tips do not resolve the problem please contact Oreck Customer Service. U.S.: 1-800-989-3535 Canada: 1-888-676-7325
Important! Always unplug and allow the unit to cool down before conducting any troubleshooting. See safety warnings.
Problem |
Solution |
|
|
|
|
The Oreck |
• Ensure the appliance is plugged into a |
|
Halo Flash™ |
wall outlet |
|
will not |
• Check for damage to the plug or cord |
|
turn ON |
||
|
||
|
• Check for blown fuse or tripped circuit |
|
|
breaker in your home |
|
|
|
|
The UV-C |
• Check to see if all four sensors are |
|
light will |
touching |
|
not turn on |
• If using the Oreck Halo Flash™ with the |
|
|
||
|
Oreck Halo Flash™ Vac, make sure you |
|
|
are using the correct hose with the blue |
|
|
end. This hose provides the power to the |
|
|
Oreck Halo Flash™ when the handheld |
|
|
is not plugged into a socket. |
|
|
|
Part |
Number |
|
|
Flash100 Power Cord |
48002-01-327 |
|
|
13
Warranty
Oreck
Halo Flash™
ORECK MANUFACTURING COMPANY:
(Oreck Manufacturing Company gives you the following limited warranty for this product only if it was originally purchased
for residential use, not resale, from Oreck, an Oreck Franchise or an Oreck Authorized Retail Dealer, it has not been used for commercial use, and it has been used and maintained in accordance with the product’s owner’s manual.)
Oreck will repair or replace, free of charge, to the original purchaser, any part that is found to be defective in material or workmanship within five (5) years immediately following the date of purchase. This limited warranty applies to normal
domestic use. Any commercial use of this product will void this limited warranty.
This limited warranty does not cover the replacement of expendable or consumable parts such as carbon motor brushes, edge brushes, drive belts, brushes, lights and light bulbs (other than the ultraviolet bulb), and other parts subject to normal wear unless they are defective in material or workmanship.
This limited warranty does not apply to any part subjected to accident, abuse, commercial use, alteration, misuse, damage caused by act of God, the use of voltages other than indicated on the serial number displayed on this product or service of this product by other than Oreck or an Oreck Authorized Service Center. Oreck does not authorize any person or representative to assume or grant any other warranty obligation with the sale of this product.
Oreck’s limited warranty is valid only if you retain proof of purchase from Oreck, an Oreck Franchise or an OreckAuthorized Retail Dealer for this product. If you purchase this product
from any other source, your purchase is “AS IS,” which means Oreck grants you no warranty, and that you, not Oreck, assume the entire risk of the quality and performance of this product, including the entire cost of any necessary servicing or repairs of any defects.
Oreck’s liability for damages to you for any costs whatsoever arising out of this statement of limited warranty shall be limited to the amount paid for this product at the time of original
14
purchase, and Oreck shall not be liable for any direct, indirect, consequential or incidental damages arising out of the use or inability to use this product.
Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you.
ALL EXPRESS AND IMPLIED WARRANTIES FOR THIS PRODUCT, INCLUDING IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED IN DURATION TO THE WARRANTY PERIOD, AND NO WARRANTIES, WHETHER EXPRESS OR IMPLIED, WILL APPLY AFTER THIS PERIOD.
Some states do not allow limitations on the duration of implied warranties, so the above limitation may not apply to you.
This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
15
