User Guide
Nokia Asha 502 Dual SIM
Issue 1.0 EN
User Guide
Nokia Asha 502 Dual SIM
Safety |
4 |
Add social info to contacts |
21 |
|
Get started |
5 |
Update your status |
21 |
|
Keys and parts |
5 |
Send a message |
21 |
|
Insert the SIM card and battery |
5 |
Mail for Exchange |
22 |
|
Insert a second SIM card |
6 |
Set up your mail account |
23 |
|
Insert a memory card |
7 |
Send a mail |
23 |
|
Charge the battery |
8 |
Chat with your friends |
24 |
|
Set which SIM card to use |
9 |
Check your voice mail |
25 |
|
Copy contacts from your old phone |
9 |
Camera |
26 |
|
Basics |
11 |
Take a photo |
26 |
|
Display indicators |
11 |
Record a video |
26 |
|
Touch screen actions |
11 |
Share your photo or video |
27 |
|
Switch between views |
13 |
Maps & navigation |
28 |
|
Check your activity |
13 |
Find nearby places |
28 |
|
Change settings quickly |
14 |
Internet |
29 |
|
Prolong battery life |
14 |
Browse the web |
29 |
|
Reorganise the apps menu |
15 |
Add a website to your favourites |
29 |
|
Personalise the lock screen |
15 |
Entertainment |
31 |
|
Change your ringtone |
16 |
Play a song |
31 |
|
Add a full keyboard or phone keypad |
16 |
Listen to the radio |
31 |
|
Add a writing language |
16 |
Office |
32 |
|
Keys on the keyboard |
16 |
Change the time and date |
32 |
|
Write using the keyboard |
17 |
Set an alarm |
32 |
|
Keys on the keypad |
17 |
Add a calendar entry |
32 |
|
Write using the keypad |
18 |
Phone management & connectivity |
34 |
|
Use predictive text |
18 |
Share your content using Slam |
34 |
|
Nokia Store |
18 |
Connect to a Wi-Fi network |
34 |
|
People & messaging |
20 |
Copy content between your phone and |
|
|
Make a call |
20 |
computer |
35 |
|
Update your phone software |
35 |
|||
Save a name and phone number |
20 |
|||
|
|
© 2013 Nokia. All rights reserved. |
2 |
|
Use your phone in flight mode |
36 |
Access codes |
36 |
Product and safety information |
38 |
© 2013 Nokia. All rights reserved. |
3 |
|
Read these simple guidelines. Not following them may be dangerous or illegal. For further info, read the complete user guide.
SWITCH OFF IN RESTRICTED AREAS
Switch the device off when mobile phone use is not allowed or when it may cause interference or danger, for example, in aircraft, in hospitals or near medical equipment, fuel, chemicals, or
blasting areas. Obey all instructions in restricted areas.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free to operate the vehicle while driving. Your first consideration while driving should be road safety.
INTERFERENCE
All wireless devices may be susceptible to interference, which could affect performance.
QUALIFIED SERVICE
Only qualified personnel may install or repair this product.
BATTERIES, CHARGERS, AND OTHER ACCESSORIES
Use only batteries, chargers, and other accessories approved by Nokia for use with this device. Do not connect incompatible products.
KEEP YOUR DEVICE DRY
Your device is not water-resistant. Keep it dry.
PROTECT YOUR HEARING
To prevent possible hearing damage, do not listen at high volume levels for long periods. Exercise caution when holding your device near your ear while the loudspeaker is in use.
SAR
This device meets RF exposure guidelines when used either in the normal use position against the ear or when positioned at least 1.5 centimetres (5/8 inch) away from the body. The specific maximum SAR values can be found in the Certification Information (SAR) section
of this user guide. For more info, go to www.sar-tick.com.
When a carry case, belt clip or other form of device holder is used for body-worn operation, it should not contain metal and should provide at least the above-stated separation distance from the body. Note that mobile devices may be transmitting even if you are not making a voice call.
© 2013 Nokia. All rights reserved. |
4 |
|
Get to grips with the basics, and have your phone up and running in no time.
Explore the keys and parts of your new phone.
1 Micro-USB connector
2 Audio connector (3.5 mm AHJ) 3 Volume/Zoom keys
4 Lock/Power key
5 Microphone
6 Back key
7 Touch screen
8 Camera lens
9 Loudspeaker
10 Antenna area
Avoid touching the antenna area while the antenna is in use. Contact with antennas affects
the communication quality and may reduce battery life due to higher power level during operation.
Do not connect products that create an output signal, as this may damage the device. Do not connect any voltage source to the audio connector. If you connect an external device or headset, other than those approved for use with this device, to the audio connector, pay special attention to volume levels.
The images in this guide may differ from your device screen.
Learn how to insert a SIM card and the battery.
1. Press on the camera bezel of the back cover with your thumb, and pull the edge of the back cover until it comes off.
Note: Switch the device off and disconnect the charger and any other device before removing any covers. Avoid touching electronic components while changing any covers. Always store and use the device with any covers attached.
2. If the battery is in the phone, lift it out.
© 2013 Nokia. All rights reserved. |
5 |
|
3. Push the SIM in with the contact area face down until it locks into place.
Important: This device is designed to be used with a mini-UICC SIM card, also known as a microSIM card only. A micro-SIM card is smaller than the standard SIM card. Use of incompatible SIM cards, or use of SIM card adapters, may damage the card or the device, and may corrupt data stored on the card.
4.Line up the battery contacts, and put the battery in.
5.Replace the back cover.
6.To switch on, press and hold the power key until the phone vibrates.
You can easily add a second SIM card (SIM2) without removing the battery.
© 2013 Nokia. All rights reserved. |
6 |
|
1. Press on the camera bezel of the back cover with your thumb, and pull the edge of the back cover until it comes off.
Note: Switch the device off and disconnect the charger and any other device before removing any covers. Avoid touching electronic components while changing any covers. Always store and use the device with any covers attached.
Both SIM cards are available at the same time when the device is not being used, but while one SIM card is active, for example, making a call, the other is unavailable.
2.Push the SIM in with the contact area face down until it locks into place.
3.To remove the SIM, push the card in until it's released, then pull it out.
Learn how to insert a memory card into your phone.
Use only compatible memory cards approved for use with this device. Incompatible cards may damage the card and the device and corrupt data stored on the card.
1. Remove the back cover.
Note: Switch the device off and disconnect the charger and any other device before removing any covers. Avoid touching electronic components while changing any covers. Always store and use the device with any covers attached.
© 2013 Nokia. All rights reserved. |
7 |
|
2.Push the card in with the contact area face down until it locks into place.
3.To remove the card, push the card in until it's released.
Important: Do not remove the memory card when an app is using it. Doing so may damage the memory card and the device and corrupt data stored on the card.
Your battery has been partially charged at the factory, but you may need to recharge it before you can use your phone.
1.Plug the charger into a wall outlet.
2.Connect the charger to the phone. When done, unplug the charger from the phone, then from the wall outlet.
© 2013 Nokia. All rights reserved. |
8 |
|
If the battery is completely discharged, it may take several minutes before the charging indicator is displayed or before any calls can be made.
Tip: You can use USB charging when a wall outlet is not available. Data can be transferred while charging the device. The efficiency of USB charging power varies significantly, and it may take a long time for charging to start and the device to start functioning.
By default, your phone asks you which SIM to use for the connection. You can also set the default SIM for calls or messaging. If you name your SIMs, you can see at a glance which is, for example, for work or personal use.
Tap Settings > Dual SIM.
1.Switch Always ask toOff.
2.Select which SIM to use for which connection.
Availability of SIMs
•If you only have one SIM, put it into the SIM1 holder. Some features may only be available with the SIM in the SIM1 holder.
•When you set one SIM to be used for outgoing calls or messages, or for data connections, the other SIM can still receive calls or messages.
•When one SIM is having an active connection, the other SIM is not available.
Rename SIM
Tap SIM settings, and type in the new name under the card you want to name.
Get all your contacts to your new phone in one go.
Your old phone must have Bluetooth, and the contacts must be stored in the phone memory, not on the SIM.
1.On both your new and old phone, switch Bluetooth on, and make sure both phones are visible to others.
2.On your new phone, tap Contacts > Import contacts > Another device.
Tip: If you already have contacts on your phone, swipe up from the bottom of the screen, and tap Import contacts > Another device.
3. Move the phones close to each other. When the phones are connected using Bluetooth, the contacts transfer starts.
© 2013 Nokia. All rights reserved. |
9 |
|
If your contacts are written in a language that is not supported by your new phone, the contact info may not show correctly.
© 2013 Nokia. All rights reserved. |
10 |
|
Learn how to get the most out of your new phone.
The display indicators on your phone tell you the current time, battery and signal strength, and much more.
An alarm is set.
The silent profile is on.
Battery power level
You have new notifications. Swipe down from the top of the screen to see the details.
Wi-Fi is on.
Signal strength
Flight mode is on.
Bluetooth is on.
The type of mobile network you're currently connected to may be shown with a single letter, a combination of letters, or a combination of letters and numbers. For example, , depending on your network service provider.
The icons may vary depending on your region or network service provider.
Explore your phone with a tap or swipe.
1.To open an app or other item, tap the app or item.
2.To switch a setting on or off, tap the switch.
© 2013 Nokia. All rights reserved. |
11 |
|
3.To see more options, tap and hold an item.
4.To swipe, for example, to another home screen, steadily slide your finger left or right.
5.To see more options, swipe up from the bottom of the screen if you can see three lines there.
6.To close an app and go back to the home screen, swipe in from the left or right of the screen.
7.To see notifications and change settings, swipe down from the top of the screen. To close the menu, swipe up, or tap an empty area outside the menu.
8.To scroll through a long list or menu, slide your finger quickly up or down, and lift your finger.
© 2013 Nokia. All rights reserved. |
12 |
|
9. To zoom, slide two fingers apart or together on an item.
Tip: For more info on touch screen actions, tap Care > Nokia Care > Tutorial.
Your phone has 2 home screens: one for keeping up with your activities, and another one for apps. Swipe left or right to switch between home screens.
Choose your view according to your needs:
•Easily see what you've been doing lately, and check what's happening next in your calendar.
•In the apps menu you can open apps and shortcuts, and rearrange them as you like.
Your phone makes it easy for you to always keep up with what's happening.
In the apps menu, swipe left or right to view your activities. Here, you can see the following:
•Apps you've opened recently, grouped by date
•Your upcoming calendar events. Swipe down at the top of the activity list to see what you've got planned next.
•Your social networking activities, like status updates and comments
•Your latest messages, missed calls, downloads, recent music, alarms, and more
Tip: You can easily pause or resume the currently-playing song directly from the list.
© 2013 Nokia. All rights reserved. |
13 |
|
