Nokia 3220 User Guide

User Guide

Nokia 3220 phone at a glance

Display screen

Power key

Earpiece

Left selection key

Call key

Keyp ad

Back of phoneBottom of phone

Pop-Port

Charger port

Microphone

connector

Right

selection key

End key

Scroll key

Camera lens

•QUICK GUIDE

Action Description

Make a call Enter a phone number, and press the Call key.

Answer a call Press the Call

Answer call during call Press the Call

End a call Press the End key.

Decline a call Press the End key to send the call to voice mail.

Mute a call Select Mute during a call.

Redial Press the Talk

Adjust call volume Press the Scroll left and Scroll right

Use in-call menu Select Options

Save name and number Enter a number. Select Options > Save

Use 1-touch dialing Press and hold a key (2–8). You must assign a key to a number in

Look up a name Select Contacts > Find.

Check voice mail Press and hold the 1

Write text messages Select Menu > Messages > Text Messages > Create message.

Send text messages In the message entry screen, select Options > Send. Enter the

Read new message If n message(s) received appears on the display, select Show,

Reply to a message Select Options > Reply. Write a reply. Select Options > Send.

Press Press a key briefly and release it.

Press and hold Press a key, hold it for 2 to 3 seconds, and release it.

the phone book.

Write the message.

recipient’s phone number or search for it in contacts, and select OK. The message service is dependent on the service provider.

then the message you want to read.

key, or select Answer.

key.

key twice.

keys during a call.

during a call.

. Enter a name. Select OK.

key (contact your service provider for details).

DECLARATION OF CONFORMITY

We, NOKIA CORPORATION declare under our sole responsibility that the products RH-37 and RH-49 are in conformity with the provisions of the following Council Directive:1999/5/EC.

A copy of the Declaration of Conformity can be found at

www.nokia.com/phones/declaration_of_conformity/.

http://

LEGAL INFORMATION

Part No. 9232826, Issue No. 1 Copyright © 2004 Nokia. All rights reserved. Nokia, Nokia Connecting People, the Nokia Original Enhancements logos, Nokia 3220, Xpress-on, and Pop-Port are trademarks or registered trademarks of Nokia Corporation. All other product and company names mentioned herein may be trademarks or tradenames of their respective owners. Printed in Canada, September 2004

Includes RSA BSAFE cryptographic or security protocol software from RSA Security.

Java is a trademark of Sun Microsystems, Inc.

The information in this user guide was written for the Nokia 3220 phone. Nokia operates a policy of ongoing development. Nokia reserves the right to make changes and improvements to any of the products described in this document without prior notice.

UNDER NO CIRCUMSTANCES SHALL NOKIA BE RESPONSIBLE FOR ANY LOSS OF DATA OR INCOME OR ANY SPECIAL, INCIDENTAL, AND CONSEQUENTIAL OR INDIRECT DAMAGES HOWSOEVER CAUSED.

THE CONTENTS OF THIS DOCUMENT ARE PROVIDED “AS IS.” EXCEPT AS REQUIRED BY APPLICABLE LAW, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY AND RELIABILITY OR CONTENTS OF THIS DOCUMENT. NOKIA RESERVES THE RIGHT TO REVISE THIS DOCUMENT OR WITHDRAW IT AT ANY TIME WITHOUT PRIOR NOTICE.

EXPORT CONTROLS

This device may contain commodities, technology, or software subject to export laws and regulations from the U.S. and other countries. Diversion contrary to law is prohibited.

FCC/INDUSTRY CANADA NOTICE

Your device may cause TV or radio interference (for example, when using a telephone in close proximity to rec eiving equipment). The FCC or Industry Canada can require you to stop using your telephone if such interference cannot be eliminated. If you require assistance, contact your local service facility. This device complies with part 15 of the FCC rules. Operation is subject to the condition that this device does not cause harmful interference.

Manufactured or sold under one or more following US Patents. Asterisk (*) indicates design patents pending.

RE 32,580 4558302 4868846 4945633 4969192 5001372

5101175 5151946 5173927 5212834 5230091 5241583

5 3111 51 5317283 5331638 5335362 5353328 5371481

5378935 5384782 5396657 5400949 5416435 5442521

5446364 5479476 5526366 5553125 5557639 5565821

5570369 5581244 5600708 5625274 5677620 5692032

5729541 5760568 5794142 5802465 5809413 5818437

5827082 5839101 5844884 5845219 5870683 5884103

5889770 5907823 5912570 5914690 5914796 5917868

5920826 5953541 5956332 5956625 5956633 5966378

5977887 5987137 5991857 6006114 6011554 6011853

6014551 6014573 6026161 6035189 6038238 6043760

6047196 6049796 6050415 6055439 6060193 6069923

6072787 6081732 6084920 6084962 6094587 6097964

6105784 6112099 6115617 6119180 6121846 6128509

6138091 6140966 6144243 6144676 6148209 6151485

6151507 6163609 6164547 6167248 6185295 6188909

6249584 6259312 6266330 6272361 6282436 6292668

6295286 6311054 6314166 6324389 6324412 6347218

6363259 6370362 6370389 6377820 6381468 6392660

6400958 6453179 6463278 6470470 6487397 6522670

6198928 4969192 5266782 5390223 5444816 5487084

5640395 5664053 5699482 5701392 5722074 5754976

5805301 5835889 5857151 5859843 5862178 5898925

5930233 5946651 5960354 5960389 5963901 6005857

6011971 6031827 6118775 6128322 6137789 6167248

6170073 6178535 6195338 6199035 6240076 6266321

6285888 6356759 6377803 6430163 6438370 6456237

Quick guide . . . . . . . . . . . . . . . . . . ii

1. For your safety. . . . . . . . . . . . . 1

About your device . . . . . . . . . . . . . 2

Network Services. . . . . . . . . . . . . . 3

Shared memory . . . . . . . . . . . . . . . 3

2. Welcome . . . . . . . . . . . . . . . . . 4

Access alternate formats . . . . . . . 4

Contact Nokia . . . . . . . . . . . . . . . . 5

3. SIM card and battery . . . . . . . . 7

Remove the back

cover and battery . . . . . . . . . . . . . 7

Insert the SIM card . . . . . . . . . . . . 7

Replace the battery. . . . . . . . . . . . 8

Replace the back cover. . . . . . . . . 8

Charge the battery . . . . . . . . . . . . 8

4. About your phone. . . . . . . . . . . 9

In-phone help . . . . . . . . . . . . . . . . 9

Start screen (standby mode) . . . . 9

Antenna . . . . . . . . . . . . . . . . . . . . 10

Indicators and icons . . . . . . . . . . 10

Change the grips. . . . . . . . . . . . . 11

Change the phone covers. . . . . . 12

Create custom back cover . . . . . 12

Change cut-out cover. . . . . . . . . 13

Attach the wrist strap. . . . . . . . . 13

5. Basic operations . . . . . . . . . . . 14

Switch the phone on or off . . . . 14

Set the time. . . . . . . . . . . . . . . . . 14

Make and answer calls . . . . . . . . 14

Adjust the earpiece volume . . . . 15

Loudspeaker. . . . . . . . . . . . . . . . . 15

6. Write text . . . . . . . . . . . . . . . 16

Standard mode . . . . . . . . . . . . . . 16

Predictive text. . . . . . . . . . . . . . . 16

Enter punctuation and special

characters . . . . . . . . . . . . . . . . . . 17

7. Phone security . . . . . . . . . . . .18

Lock the keypad (Keyguard) . . . . 18

Automatic Keyguard . . . . . . . . . . 18

Access codes . . . . . . . . . . . . . . . . 18

8. Phone menu . . . . . . . . . . . . . .19

Messages . . . . . . . . . . . . . . . . . . . 19

Instant messaging . . . . . . . . . . . . 26

Call log . . . . . . . . . . . . . . . . . . . . . 30

Contacts . . . . . . . . . . . . . . . . . . . . 30

Settings . . . . . . . . . . . . . . . . . . . . 34

Operator menu. . . . . . . . . . . . . . . 39

Gallery . . . . . . . . . . . . . . . . . . . . . 40

Media . . . . . . . . . . . . . . . . . . . . . . 40

Organizer . . . . . . . . . . . . . . . . . . . 42

Applications . . . . . . . . . . . . . . . . . 44

Services . . . . . . . . . . . . . . . . . . . . 48

SIM services. . . . . . . . . . . . . . . . . 53

9. PC connectivity. . . . . . . . . . . .54

PC Suite . . . . . . . . . . . . . . . . . . . . 54

GPRS, EGPRS, HSCSD,

and CSD . . . . . . . . . . . . . . . . . . . . 54

Data communication

applications . . . . . . . . . . . . . . . . . 54

10. Reference information . . . . . .56

Battery information. . . . . . . . . . . 56

Enhancements . . . . . . . . . . . . . . . 56

Care and maintenance . . . . . . . . 57

Additional safety information . . 58

Technical information . . . . . . . . . 62

Appendix A. . . . . . . . . . . . . . .67

Appendix B . . . . . . . . . . . . . . . 71

Index . . . . . . . . . . . . . . . . 79

NOTES

For your safety

1 For your safety

Read these simple guidelines. Not following them may be dangerous or illegal. Read the complete user guide for further information.

SWITCH ON SAFELY

Do not switch the phone on when wireless phone use is prohibited or when it may cause interference or danger.

ROAD SAFETY COMES FIRST

Obey all local laws. Always keep your hands free to operate the vehicle while driving. Your first consideration while driving should be road safety.

INTERFERENCE

All wireless phones may be susceptible to interference, which could affect performance.

SWITCH OFF IN HOSPITALS

Follow any restrictions. Switch the phone off near medical equipment.

SWITCH OFF IN AIRCRAFT

Follow any restrictions. Wireless devices can cause interference in aircraft.

SWITCH OFF WHEN REFUELING

Don't use the phone at a refueling point. Don't use near fuel or chemicals.

SWITCH OFF NEAR BLASTING

Follow any restrictions. Don't use the phone where blasting is in progress.

USE SENSIBLY

Use only in the normal position as explained in the product documentation. Don't touch the antenna unnecessarily.

QUALIFIED SERVICE

Only qualified personnel may install or repair this product.

ENHANCEMENTS AND BATTERIES

Use only approved enhancements and batteries. Do not connect incompatible products.

WATER-RESISTANCE

Your phone is not water-resistant. Keep it dry.

BACKUP COPIES

Remember to make back-up copies or keep a written record of all important information stored in your phone.

CONNECTING TO OTHER DEVICES

When connecting to any other device, read its user guide for detailed safety instructions. Do not connect incompatible products.

EMERGENCY CALLS

Ensure the phone is switched on and in service. Press End as many times as needed to clear the display and return to the main screen. Enter the emergency number, then press Call. Give your location. Do not end the call until given permission to do so.

• About your device

The wireless device described in this guide comes in two models. The Nokia 3220 phone is approved for use on the EGSM 900 and GSM 1800 and 1900 networks. The Nokia 3220b phone is approved for use on the GSM 850, 1800 and 1900 networks. See “Find information about your phone” on page 5 to identify your specific phone model. Contact your service provider for more information about networks.

When using the features in this device, obey all laws and respect privacy and legitimate rights of others.

Warning: To use any features in this device, other than the alarm clock, the phone must be switched on. Do not switch the device on when wireless phone use may cause interference or danger.

Note: Your device and its enhancements may contain small parts. Keep them out of the reach of small children.

For your safety

• Network Services

To use the phone you must have service from a wireless service provider. Many of the features in this device depend on features in the wireless network to function. These Network Services may not be available on all networks or you may have to make specific arrangements with your service provider before you can utilize Network Services. Your service provider may need to give you additional instructions for their use and explain what charges will apply. Some networks may have limitations that affect how you can use Network Services. For instance, some networks may not support all language-dependent characters and services.

Your service provider may have requested that certain features be disabled or not activated in your device. If so, they will not appear on your device menu. Contact your service provider for more information.

• Shared memory

The phone has three different memories. The following features in this device may share the first memory: contacts, text messages, SMS e-mail, voice tags, calendar, and notes. The second shared memory is used by multimedia messages, files stored in Gallery, and configuration settings. The third shared memory is used by Java games and applications. Using one or more of these features may reduce the memory available for the remaining features sharing the same memory. For example, saving many Gallery items may use all of the available memory in the second memory. Your device may display a message that the memory is full when you try to use a shared memory feature. In this case, delete some of the information or entries stored in the corresponding shared memory before continuing.

2Welcome

Congratulations on your purchase of the Nokia 3220 mobile phone. Your phone provides many functions that are practical for daily use, such as a calendar, a clock, an alarm clock, and a built-in camera. The camera can be used for recording video clips and taking pictures that you can, for example, attach as wallpaper in the standby mode or as thumbnail pictures in Contacts. See “Camera” on page 40.

You can personalize your phone with cut-out covers and with themes. See “Create custom back cover” on page 12 and “Themes” on page 34. Also, a range of Nokia Xpress-on™ covers and Nokia Xpress-on grips are available for your phone. To change the covers and grips, see “Change the phone covers” on page 12 and “Change the grips” on page 11.

Other features on your phone are:

• Mu ltimedia messaging. See “Multimedia messages (MMS) (network service)” on page 22.

• Instant messages, see “Instant messaging” on page 26.

• EDGE (enhanced data rates for GSM evolution), see “GPRS and EGPRS” on page 37.

• Java 2 Platform Micro Edition, J2ME

• XHTML browser, see “Settings” on page 34.

• Access alternate formats

This user guide is available in alternate formats, contact Nokia at

www.nokiaaccessibility.com

or call 1-888-665-4228 for more information.

• Register your phone

Make sure to register your phone at www.warranty.nokiausa.com or 1-888-NOKIA-2U (1-888-665-4228) so that we can serve your needs better if you should need to call the center or have your phone repaired.

™

, see “Applications” on page 44.

• Copyright protection

Copyright protections may prevent some images, ringing tones, and other content from being copied, modified, transferred, or forwarded.

• Contact Nokia

If you ever need to call Nokia Customer Care or your service provider, you will need to provide specific information about your phone (see “Find information about your phone” on page 5).

Whether you are calling about your phone or an enhancement, have the equipment with you when you call. If a Nokia representative asks a specific question about the enhancement, you will have it available for quick reference.

Nokia Customer Care Center, USA Customer Care, Canada

Welcome

Nokia Mobile Phones 7725 Woodland Center Boulevard, Suite #150 Tampa, Florida 33614

Tel:1-888-NOKIA-2U (1-888-665-4228)

Fax: 1-813-249-9619 For TTY users: 1-800-24-NOKIA (1-800-246-6542)

Nokia Products Ltd. 601 Westney Rd. South Ajax, Ontario L1S 4N7

Tel:1-905-427-1373 1-888-22-NOKIA (1-888-226-6542)

Fax:1-905-619-4360 Web site: www.nokia.ca

Find information about your phone

Information about your phone is provided on the phone label (1), which is on the back of the phone under the battery (see “Remove the back cover and battery” on page 7). The label contains the model and serial numbers, as well as the following:

• Phone type (such as RH-37 or RH-49)

• Phone model (such as Nokia 3220 or Nokia 3220b)

• International Mobile Equipment Identity (IMEI)

• FCC ID number

Contact your service provider

In many cases, the service provider will make available descriptions of its services and instructions for using features, such as:

• Voice mail and voice privacy

• Call waiting, call forwarding, and caller ID

• Messaging

• News and information services

• Selected Internet services Service providers may differ in their support of features. Before you sign up

with a service provider, make sure that the service provider supports the features that you need.

SIM card and battery

3 SIM card and battery

The SIM card and its contacts can easily be damaged by scratches or bending, so be careful when handling, inserting, or removing the card.

Keep all SIM cards out of the reach of small children. For availability and information on using SIM card services, contact your SIM card vendor. This may be the service provider or another vendor.

Always switch the device off and disconnect the charger before removing the battery.

• Remove the back cover and battery

1 Push the back cover release button

at the bottom of the phone (1) and gently pull the back cover away from the phone beginning at the bottom of the phone (2).

2 Remove the battery by lifting it

as shown.

• Insert the SIM card

Insert the SIM card into the SIM card holder until it snaps into position. Make sure that the SIM card is properly inserted and that the gold-colored contact area on the card is facing downward.

If you need to remove the SIM card, press the card release (1), and slide the SIM card toward the top of the phone (2).

• Replace the battery

The SIM card must be installed before installing the battery.

Insert the battery so that the gold-colored contacts match up with those on the phone.

• Replace the back cover

Align the top of the back cover with the top of the phone (1), and press the bottom of the back cover to lock it (2).

• Charge the battery

Warning: Use only batteries, chargers, and enhancements approved by

Nokia for use with this particular model. The use of any other types may invalidate any approval or warranty, and may be dangerous.

Your phone is powered by a rechargeable battery. To charge the battery, do the following:

1 Plug the charger transformer

into a standard ac outlet.

2 Insert the charger output plug

into the charger port at the bottom end of the phone.

After a few seconds, the battery indicator in the display starts to scroll from bottom to top. If the battery is completely discharged, it may take a few minutes before the charging indicator appears on the display or any

calls can be made. You can use the phone while the charger is connected. The BL-5B battery provides up to 3.5 hours of talk time and up to 14 days of

standby time. Operation times are estimates and may vary depending on network conditions, charging, and phone use. Charging the battery with the ACP-12 charger takes approximately 1 hour and 20 minutes while the phone is in standby mode.

About your phone

4 About your phone

• In-phone help

Many features have brief descriptions (help text) that can be viewed on the di spl ay. T o vi ew t he h elp tex t, s cro ll t o a f eat ure , an d wa it f or abo ut 1 5 seconds. Select More to view all of the description (if necessary) or Back to exit. For instructions on how to turn the help text feature on and off, see “Phone settings” on page 36.

• Start screen (standby mode)

The start screen is home base and indicates that the phone is in the standby mode.

HOME

Signal strength

Battery level

Left selection

Middle selection (Menu)

HOME—The name of your service provider may appear here. Signal strength—A higher bar indicates a stronger network signal. Battery level—A higher bar indicates more power in the battery. Left selection—The Left selection key in the standby mode opens the Go to

menu. See “Go to options” on page 35. Middle selection—Press the middle of the scroll key to select the item displayed

in the bottom center (middle selection area) of the display screen. For example, in the standby mode, pressing the middle of the scroll key opens the Menu. See “Phone menu” on page 19.

Right selection—The Right selection key in the standby mode opens either the Contacts menu (default), a service provider’s home page, or a user-specified

function. See “Personal shortcuts” on page 35.

Right selection

• Antenna

Your device has an internal antenna.

Note: As with any other radio transmitting device, do not touch the antenna unnecessarily when the device is switched on. Contact with the antenna affects call quality and may cause the phone to operate at a higher power level than otherwise needed. Avoiding contact with the antenna area when operating the phone optimizes the antenna performance and the battery life.

• Indicators and icons

The following icons may be displayed in the standby mode:

Icon Indicates...

You have one or more text or picture messages. See “Text messages (SMS) (network service)” on page 20.

The phone has logged a missed call. See “Call log” on page 30.

Your phone is connected to the instant messaging service, and the

availability status is online or offline, respectively. See “Instant messaging” on page 26.

You have received one or several instant messages, and you are connected to the instant messages service. See “Instant messaging” on page 26.

You have one or more multimedia messages. See “Multimedia messages (MMS) (network service)” on page 22.

You have one or more voice messages. See “Voice messages” on page 24.

Your phone keypad is locked. See “Lock the keypad (Keyguard)” on page 18.

Your phone is set to the Silent profile. See “Profiles” on page 34.

The alarm clock is set to On. See “Alarm clock” on page 42.

Icon Indicates...

The GPRS connection mode Always online is selected, and the GPRS service is available, or there is an active GPRS connection.

You have an incoming or outgoing call during a GPRS dial-up connection. GPRS is suspended.

Forward all voice calls. All calls are forwarded to another number. If you have two phone lines, the indicator for line 1 is and for line 2 .

If you have two phone lines, this indicates that you are on the second phone line. See “Call settings” on page 36.

Calls are limited to a closed user group. See “Security settings” on page 39.

The timed profile is selected. See “Profiles” on page 34.

Integrated handsfree is active. See “Loudspeaker” on page 15.

orA headset, handsfree, or Nokia Loopset enhancement is connected

to the phone.

• Change the grips

1 Remove the covers from the

phone as described in “Change the phone covers” on page 12.

2 To remove the grips, slide them

to the top of the phone (1), then remove the grip (2).

3 Replace the grips as shown. 4 Replace the covers of the phone

as described in “Change the phone covers” on page 12.

About your phone

• Change the phone covers

Note: Before removing the

cover, always switch off the power and disconnect the charger and any other device. Avoid touching electronic components while changing the covers. Always store and use the device with the covers attached.

1 Remove the back cover from the

phone as described in “Remove the

back cover and battery” on page 7. 2 Beginning at the top of the phone (1),

gently pull the front cover away from

the phone and detach it (2). 3 To remove the key mat from the front

cover, take it out gently. 4 Place the key mat in the new front

cover (3). 5 To replace the front cover, press it

gently onto the phone until it snaps

into position (4). 6 Align the top of the back cover with

the top of the phone (5), and press

the bottom of the back cover to lock it (6).

• Create custom back cover

Note: Use normal, plain paper as found in standard printers or use a

photo print that is not thicker than 0.3 mm. To avoid affecting the antenna performance the material must not contain metal particles.

Use the plastic stencil to create a cut-out cover using your own design.

1 Place the stencil in

the correct position

and draw the

outline (1). 2 Carefully cut out your

new cover (2).

• Change cut-out cover

1 Remove the back cover from the

phone as described in “Remove the back cover and battery” on page 7.

2 Remove the cut-out cover from

the back cover.

3 To place the new cut-out cover

into the back cover, slide the cut-out cover under the two guides at the bottom (1), then under the guide at the top (2).

4 Replace the back cover.

• Attach the wrist strap

Remove the back cover as described in “Remove the back cover and battery” on page 7 and thread the strap as shown in the picture. Tighten the strap, and replace the back cover.

About your phone

5 Basic operations

• Switch the phone on or off

1 To turn your phone on or off, press and hold the Power

key as shown.

If the phone displays Insert SIM card even though the

SIM card is properly inserted, or SIM card not supported,

contact your service provider. 2 If the phone asks for a PIN code, enter the PIN code

(displayed as ****), and select OK. 3 If the phone asks for a security code, enter the security

code, and select OK. See “Access codes” on page 18 for more information.

• Set the time

Select Menu > Settings > Time and date settings > Clock > Set the time. Enter the time (in hh:mm format), and select OK > am or pm.

• Make and answer calls

Use the keypad—Enter the phone number (including the area code), and press

the Call key. To delete a character to the left of the cursor, select Clear. To end the call or to cancel the call attempt, press the End key.

Use contacts—At the start screen, press the Scroll down key to view your contacts, scroll to the entry you want to call, and press the Call key to make the call.

Redial the last number—At the start screen, press the Call key twice. Make an international call—Press * twice to enter the international prefix [a plus

(+) sign] in place of the international access code. Then enter the c ountry code, the area code without a leading zero (if necessary), and the phone number.

Answer or reject a call—Press the Call key to answer the call or the End key to reject the call. If Forward if busy is activated to your voice mailbox, the call is forwarded to your voice mail. If not, the call is rejected.

If you select Silence, only the ringing tone is muted. You can then answer or reject the incoming call.

Answer a call with the keypad locked—See “Lock the keypad (Keyguard)” on page 18.

1-touch dialing—See “1-touch dialing” on page 32. Call waiting—See “Call settings” on page 36.

Basic operations

• Adjust the earpiece volume

To increase the volume of a call, press the Right scroll key. To decrease the volume of a call, press the Left scroll key. When adjusting the volume, a bar chart appears in the display indicating the volume level. See also Automatic volume control in “Call settings” on page 36.

You can only adjust the earpiece volume during an active call.

• Loudspeaker

You can use your phone as a loudspeaker during a call. Do not hold the phone to your ear during the loudspeaker operation as the volume may be very high.

To activate the loudspeaker, select Options > Loudspeaker. To deactivate the loudspeaker during a call, select Options > Handset.

6 Write text

You can use two methods for entering text and numbers:

• Standard mode ( ) is the only way to enter names into Contacts and

to rename caller groups.

• Predictive text input ( ) is a quick and easy method for writing messages. Press # to switch predictive text on or off and to use predictive text in

various modes.

• Standard mode

Press a key once to insert the first letter on the key, twice for the second letter, etc. If you pause briefly, the last letter in the display is accepted and your phone awaits the next entry.

Select Clear to backspace the cursor and delete a character. Select and hold Clear to backspace continuously and delete characters. Press 0 to enter a space and accept a completed word. Press 1 to enter a period (.). Press * to display special characters. See “Enter punctuation and special characters”

on page 17. Press and hold # to switch between text and numeric entry. The icon is

displayed at the top of the screen when the phone is in numeric entry mode. Depending on which capitalization mode you have selected, , , or

is displayed when the phone is in text entry mode.

•Predictive text

Predictive text input allows you to write messages quickly using your keypad and the built-in phone dictionary. It is faster than using the standard multi-tap method. You can use predictive text to write a message and create a calendar note.

To activate predictive text at any text entry screen, select Options > Predictive

text and a language.

How to use predictive text

• For each letter of the word that you want to spell, press the corresponding

key on your keypad only once, even if the letter you want is not the first

letter on the key. The phone “guesses” the word you are trying to spell.

• If a displayed word is not correct, press * to see other matches. To move

forward through a list of matches, keep pressing *. To return to the previous

word in the list of matches, select Previous.

Write text

• Press 0 to accept the word, enter a space, and begin writing the next word.

•If ? appears after a word, select Spell to add the word to the dictionary.

See “Add words to the dictionary” on page 17.

• Press 1 to insert a period into your message.

• Press and hold * to display special characters. See “Enter punctuation and

special characters” on page 17.

Compound words

Enter the first part of the word; to confirm it, press the Scroll right key. Enter the last part of the word; to confirm it, press 0.

Add words to the dictionary

If you encounter a word that predictive text does not recognize, a question mark (?) follows the word, and Spell appears in the lower left of the display.

Select Spell, enter your new word using the keypad, and select Save. The word is added to the dictionary and to the message that you are writing.

Keep these factors in mind when adding words:

• To accept and save new words to the dictionary, select Save, or press O, or

delete the space between two words.

• Depending on the language and the length of the words, you may be able to add hundreds of words to the dictionary.

• When the dictionary is full, the most recent addition replaces the first.

• Enter punctuation and special characters

While at any text entry screen, press * to display special characters (press and hold * if predictive text is on) or press * twice to display the Smiley menu.

To navigate through the list of special characters, use the Four-way scroll key like a joystick. Once a character is highlighted, select Insert to insert the character into your message.

7 Phone security

• Lock the keypad (Keyguard)

You can lock the keypad to prevent accidental key presses. To answer a call with keyguard on, press the Call key. During the call, all features function as normal. When you end or reject a call, the keypad automatically relocks.

• To lock the keypad, select Menu > *.

• To unlock the keypad, select Unlock > *. When the keypad is locked, calls may be possible to the official emergency

number programmed into your phone. Enter the emergency number, and press the Call key.

• Automatic Keyguard

You can set your phone to lock the keys automatically after a time you specify. See “Phone settings” on page 36 to activate this feature.

• Access codes

The following access codes allow you to secure your phone from unauthorized use. To change access codes, see “Security settings” on page 39. Keep the new codes secret and in a safe place, separate from your phone.

Security code—This code, supplied with the phone, protects your phone against unauthorized use. The preset code is 12345.

PIN code—This code, supplied with the SIM card, protects the card against unauthorized use. Turn the PIN code request on so th at the code is requested ea ch time the phone is switched on. If you enter an incorrect PIN code three times in succession, the SIM card is blocked. You must enter the PUK code to unblock the SIM card and set a new PIN code.

PIN2 code—This code is supplied with some SIM cards and is required to access certain services, such as charging unit counters. If you enter an incorrect PIN2 code three times in succession, PIN2 code blocked appears in the display and you will be asked for the PUK2 code.

PUK and PUK2 codes—These unblocking codes may be supplied with the SIM card. For more information, contact your service provider.

Call restriction password (4 digits)—This password is needed when using Call restrictions. You can obtain the password from your service provider.

Phone menu

8 Phone menu

Phone features are accessed through the main menu of your phone. Use the menus and submenus to select or view items and customize phone features.

Note: Some service providers order the phones specially programmed for their network. This may mean that some features are not shown on the menu.

In the standby mode, press the middle of the scroll key to select Menu. The first menu item is displayed.

You can view the menu as a list or as a grid: List view—List view is the default view for the

main menu. Scroll up and down to view main menu selections one at a time.

Grid view—To switch between List and Grid view, see “Display settings” on page 35. In Grid view, scroll up, down, right, and left to navigate through the main menu icons.

In the Grid view, the icon for the selected menu is outlined, and the name of the menu appears at the top of the display.

As you scroll through the menus, the menu number appears in the upper right corner of the display. Below the menu number is a scroll bar with a tab. The tab moves up or down as you scroll through the menus, providing a visual representation of your current position in the menu structure.

Open a menu item—Scroll to it, and press the Left selection key. Open a submenu—If the menu contains submenus, scroll to highlight the

desired menu; then press the Left selection key. Return to the previous menu—Select Back (press the Right selection key) to

return to the previous menu or submenu.

Return to the start screen—Press the End key from any menu screen.

• Messages

The message services can only be used if they are supported by your network or your service provider.

To select the font size for reading and writing messages, select Menu > Messages > Message settings > Other settings > Font size.

Note: When sending messages, your phone may display the words Message sent. This is an indication that the message has been sent by

your device to the message center number programmed into your device. This is not an indication that the message has been received at the intended destination. For more details about messaging services, check with your service provider.

Text messages (SMS) (network service)

Using the SMS (short message service), your phone can send and receive multipart messages, which consist of several ordinary text messages. Invoicing may be based on the number of ordinary messages that are required for a multipart message.

Before you can send a message, you need to save some message settings. See “text and SMS e-mail messages” on page 24.

You can also send and receive text messages that contain pictures. A picture message can be a multipart message.

Note: Only devices that offer picture message features can receive and display picture messages.

WRITE AND SEND MESSAGES

Your device supports the sending of text messages beyond the normal 160-character limit. If your message exceeds 160 characters, it will be sent as a series of two or more messages. The number of available characters and the current part number of a multipart message are shown on the top right of the display, for example 120/2. Note that using special (Unicode) characters such as ë, â, á, ì take up more space.

1 Select Menu > Messages > Create message > Text message. 2 Enter a message. See “Write text” on page 16. To insert text templates or

a picture into the message, see “Templates” on page 21.

3 Select Send, or press the Call key to send the message.

The messages that you have sent will be saved in the Sent items folder if the setting Save sent messages is set to Yes. See “text and SMS e-mail messages” on page 24. Text messages are indicated with .

4 Enter the recipient’s phone number, or search for the phone number

in Contacts.

5 Select OK to send the message.

OPTIONS FOR SENDING A MESSAGE

After you have written a message, select Options > Sending options and one of the following:

Send to many—Send the message to several recipients. Send as e-mail—Send a message as an SMS e-mail (network service). Sending profile—Use a predefined message profile to send the message. To define

a message profile, see “text and SMS e-mail messages” on page 24.

+ 62 hidden pages

Nokia 3220 User Guide

Specifications and Main Features

Frequently Asked Questions

User Manual

Contents

1 For your safety

2Welcome

3 SIM card and battery

4 About your phone

5 Basic operations

6 Write text

7 Phone security

8 Phone menu
