RH-37 Product Selection
The RH-37 is a triple band monoblock transceiver unit, designed for EGSM900,
GSM1800 and GSM1900 EDGE networks. It is a GSM900 phase 2, power class 4 (2W)
transceiver and a GSM1800/1900 power class 1 (1W) transceiver. It is also an EDGE900
power class E2 (0.5W/27dBm) and an EDGE1800/1900 power class E2 (0.4W/26dBm)
transceiver.
RH-37 product and modules
Name Type Code Material Code
Basic transceiver RH-37 0516128
Printed Wiring Board (PWB) module 1CN 0202178
Mechanics module 0263468
Software module 8457773
Figure 1: RH-37 Transceiver
Issue 1 07/04 2004 Nokia Corporation. Page 5
RH-37 Company Confidential
1 - General Information Nokia Customer Care
Supported accessories
Product Type Description Comment
AC-1E Retractable charger
ACP-7 E&A, APAC = Standard Charger,
Americas = Standard Travel Charger
ACP-8 E&A = Travel Charger,
APAC = Fast & Light Charger
ACP-12 Travel Charger
AD-5B Wireless Voice Adaptor
BHF-1 Headrest Handsfree
BHF-3 Headrest Handsfree
BL-5B Battery Eur/Afr & Apac
Battery France
Battery Americas
Battery China
Battery Brazil
DKU-5 Connectivity Adapter Cable
DT-6 Call forwarding deskstand
HDB-4 Boom Headset
HF-2 Activity Handsfree
HF-3 Plug-in Handsfree
HS-2R Radio Headset
HS-3W Wireless Headset
HS-5 Headset
HS-10 Retractable Headset
LCH-9 E&A, APAC = Mobile Charger
LCH-12 E&A, APAC = Mobile Charger
LPS-4 Inductive Loopset
HDA-10
PT-5W Digital Camera
SU-5 TV image viewer
Pop-port
FunctionlaCover “0b” colour 2
FunctionlaCover “0b” colour 3
Cut-out Cover Emo-Dance
Cut-out Cover Blue Sq.
Cut-out Cover Red Flwr
Nokia Observation Camera
TM
to tty adapter
English type label
French type label
English type label
Chinese type label
Portuguese type label
Note: No car kit support.
Page 6 2004 Nokia Corporation. Issue 1 07/04
Company Confidential RH-37
Nokia Customer Care 1 - General Information
Environmental conditions
Environmental Condition Ambient Temperature Notes
Normal operation -10°C…+55°C Specifications fulfilled
Reduced performance +55°C…+70°C Operational only for short periods
No operation or storage <-30°C…>+80°C No storage outside these tempera-
tures. An operation attempt may
cause permanent damage
Charging allowed -5°C…+55°C
Transceiver features
Transceiver main HW parts/features include:
• GPRS (Class 10) 3+2, 4+1
• EGPRS (Class 6) 3+1, 2+2
• HSCSD/CSD
• Integrated VGA camera
• Colour display (size: 27.5mmx27.5mm. 64K colours, high resolution (128x128)
active matrix.
• Internal Triple band antenna (no connection for external antenna)
• User changeable Xpress on grips with configurable light effects
• User changeable front and back covers
• 5-way navigation key
• Integrated Hands Free (IHF) speaker
• DCT charger plug
• Pop-portTM connector
