Nokia Customer Care
RH-37 Series Transceivers
2 - Parts Lists and Component
Layout
Issue 1 07/04 2004 Nokia Corporation Page 1
Company Confidential
RH-37
2 - Parts Lists and Component Layout Nokia Customer Care
[This page left intentionally blank]
Page 2 Nokia Corporation Issue 1 07/04
RH-37
Nokia Customer Care 2 - Parts Lists and Component Layout
Table of Contents
Page No
Exploded View of RH-37 ...................................................................................................................... 5
Assembly parts ......................................................................................................................................6
Variant parts ..........................................................................................................................................8
1cna_50a PWB Module Parts List ................................................................................................... 10
1cna_50a PWB component locator (top) ....................................................................................24
1cna_50a PWB component locator (bot) ....................................................................................24
Issue 1 07/04 Nokia Corporation Page 3
RH-37
2 - Parts Lists and Component Layout Nokia Customer Care
[This page left intentionally blank]
Page 4 Nokia Corporation Issue 1 07/04
RH-37
Nokia Customer Care 2 - Parts Lists and Component Layout
Exploded View of RH-37
Issue 1 07/04 Nokia Corporation Page 5
RH-37
2 - Parts Lists and Component Layout Nokia Customer Care
Assembly parts
Note: Do not use the following lists for spare part ordering. For ordering the spare parts please refer to
the related and updated Technical Bulletins.
ITEM/CIRCUIT
REF.
I001 XXXXXXX A-COVER ASSY
I002 XXXXXXX KEYMAT
I003 6380209 SCREW 1.8X6 RF T6
I004 - UI-SHIELD
I005 - EARPIECE
I006 - LIGHT GUIDE
I007 9795302 DOME SHEET
I008 4850833 LCD MODULE
QTY PART NO PART NAME
9498016 UI-SHIELD ASSY
9795401 LIGHT Guide ASSY
I009 - ENGINE MODULE
I010 9511279 VGA CAMERA SHIELD
I011 4858023 VGA CAMERA MODULE
9491744 B-COVER ASSY
9481182 IHF LID ASSY
I012 - IHF PIN
I013 - IHF GASKET
I014 - IHF-LID
I015 - B-COVER
I016 - ANTENNA RADIATOR + DECO FOIL
I017 - POGO PIN
I018 - IHF-NET
I019 - SIM-GRIP
I020 9453568 GEL GRIP 3 DMD11361 (TOP RIGHT)
I021 9453566 GEL GRIP 1 DMD11359 (BOTTOM RIGHT)
Page 6 Nokia Corporation Issue 1 07/04
RH-37
Nokia Customer Care 2 - Parts Lists and Component Layout
ITEM/CIRCUIT
REF.
I022 9453569 GEL GRIP 4 DMD11362 (TOP LEFT)
I023 9453567 GEL GRIP 2 DMD11360 (BOTTOM LEFT)
I024 6800057 VIBRA MOTOR
I025 5140265 MICROPHONE
I026 5400243 DC-JACK
I027 5149007 SPEAKER IHF
I028 9480890 SPEAKER ADHESIVE
I029 9791212 POWER-KEY
I030 9453671 BLIND PLUG
I031 9381484 TYPE LABEL
I032 XXXXXXX C-COVER ASSY
QTY PART NO PART NAME
Issue 1 07/04 Nokia Corporation Page 7
RH-37
2 - Parts Lists and Component Layout Nokia Customer Care
Variant parts
ITEM/
CIRCUIT
REF.
I001 1 9491739 A-COVER ASSY WHITE/BLUE
I001 1 9491740 A-COVER ASSY WHITE/RED
I001 1 9491741 A-COVER ASSY BLACK/BLUE/SILVER
I001 1 9491742 A-COVER ASSY RED/RED
I001 1 9491743 A-COVER ASSY BLACK/BLUE
I002 1 9791495 KEYPAD ASSY LATIN RED
I002 1 9791496 KEYPAD ASSY LATIN BLUE
I002 1 9791497 KEYPAD ASSY BoPoMoFo RED
QTY PART NO PART NAME
I002 1 9791498 KEYPAD ASSY BoPoMoFo BLUE
I002 1 9791499 KEYPAD ASSY THAI RED
I002 1 9791500 KEYPAD ASSY THAI BLUE
I002 1 9791501 KEYPAD ASSY GREEK RED
I002 1 9791502 KEYPAD ASSY GREEK BLUE
I002 1 9791503 KEYPAD ASSY HEBREW RED
I002 1 9791504 KEYPAD ASSY HEBREW BLUE
I002 1 9791505 KEYPAD ASSY STROKE RED
I002 1 9791506 KEYPAD ASSY STROKE BLUE
I002 1 9791507 KEYPAD ASSY ARABIC RED
I002 1 9791508 KEYPAD ASSY ARABIC BLUE
I002 1 9791509 KEYPAD ASSY HINDI RED
I002 1 9791510 KEYPAD ASSY HINDI BLUE
I002 1 9791511 KEYPAD ASSY RUSSIAN RED
I002 1 9791512 KEYPAD ASSY RUSSIAN BLUE
I002 1 9791513 KEYPAD ASSY URDU RED
I002 1 9791514 KEYPAD ASSY URDU BLUE
I002 1 9797201 KEYPAD ASSY FARSI RED
I002 1 9797201 KEYPAD ASSY FARSI BLUE
I009 1 0510756 BASIC TRANSCEIVER (RH-37/BOM1)
I009 1 0516128 BASIC TRANSCEIVER (RH-37/BOM2)
I032 1 9491746 C-COVER ASSY WHITE/BLUE
