Nokia 2366i User Manual

User Guide

Tex t Mes s a gin g Ph o ne

2366i

Nokia 2366i User Guide

LEGAL INFORMATION

PART NO. 9253423, ISSUE NO. 1

Copyright ©2006 Nokia. All rights reserved. Nokia, Nokia Connecting People, Pop-Port, and the Nokia Original Enhancements logos are trademarks or registered trademarks of Nokia Corporation. Other company and product names mentioned herein may be trademarks or trade names of their respective owners.

cdma2000 is a registered certification mark of the Telecommunications Industry Association.

Bluetooth wireless technology is a registered trademark of Bluetooth SIG, Inc.

Includes RSA BSAFE cryptographic or security protocol software from RSA Security.

Java™ is a trademark of Sun Microsystems, Inc.

The information contained in this user guide was written for the Nokia 2366i product. Nokia operates a policy of ongoing development. Nokia reserves the right to make changes to any of the products described in this document without prior notice.

UNDER NO CIRCUMSTANCES SHALL NOKIA BE RESPONSIBLE FOR ANY LOSS OF DATA OR INCOME OR ANY SPECIAL, INCIDENTAL, AND CONSEQUENTIAL OR INDIRECT D AMAGES HOWSOEVER CAUSED. THE CONTENTS OF THIS DOCUMENT ARE PROVIDED “AS IS.” EXCEPT AS REQUI RED BY A PPL ICAB LE LA W, NO WA RRANTI ES OF AN Y KIN D, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY AND RELIABILITY OR CONTENTS OF THIS DOCUMENT. NOKIA RESERVES THE RIGHT TO REVISE THIS DOCUMENT OR WITHDRAW IT AT ANYTIME WITHOUT PRIOR NOTICE.

EXPORT CONTROLS This device may con tain commodities, technology, o r software subject to export laws and regulations from the U.S. and other countries. Diversion contrary to law is prohibited.

Copyright protections may prevent some images, music (including ringing tones), and the content from being copied, modified, transferred, or forwarded.

FCC/INDUSTRY CANADA NOTICE Your device may cause TV or radio interference (for example, when using a telephone in close proximity to receiving equipment). The FCC or Industry Canada can require you to stop using your telephone if such interference cannot be eliminated. If you require assistance, contact your local service facility. This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by Nokia could void the user’s authority to operate this equipment.

Contents

For your safety........................................................ 5

Welcome.................................................................. 8

1. Phone at a glance........................................... 10

2. Set up your phone.......................................... 16

3. Gallery............................................................. 24

4. Recent calls..................................................... 26

5. Media .............................................................. 29

6. Settings........................................................... 31

7. Contacts .......................................................... 56

8. Tools ................................................................ 64

9. Text entry........................................................ 78

10. Messaging....................................................... 81

11. Extras .............................................................. 91

12. Enhancements ................................................ 92

13. Battery information ....................................... 93

Care and maintenance.......................................... 97

Additional safety information ............................. 99

Index .....................................................................106

For your safety

Read these simple guidelines. Not following them may be dangerous or illegal. Read the complete user guide for further information.

SWITCH ON SAFELY

Do not switch the device on when wireless phone use is prohibited or when it may cause interference or danger.

ROAD SAFETY COMES FIRST

Obey all local laws. Always keep your hands free to operate the vehicle while driving. Your first consideration while driving should be road safety.

INTERFERENCE

Do not switch the device on when wireless phone use is prohibited or when it may cause interference or danger.

SWITCH OFF IN HOSPITALS

Follow any restrictions. Switch the device off near medical equipment.

SWITCH OFF IN AIRCRAFT

Follow any restrictions. Wireless devices can cause interference in aircraft.

SWITCH OFF WHEN REFUELING

Do not use the device at a refueling point. Do not use near fuel or chemicals.

SWITCH OFF NEAR BLASTING

Follow any restrictions. Do not use the device where blasting is in progress.

For your safety

USE SENSIBLY

Use only in the normal position as explained in the product documentation. Do not touch the antenna unnecessarily.

QUALIFIED SERVICE

Only qualified personnel may install or repair this product.

ENHANCEMENTS AND BATTERIES

Use only approved enhancements and batteries. Do not connect incompatible products.

WATER-RESISTANCE

Your phone is not water-resistant. Keep it dry.

BACK-UP COPIES

Remember to make back-up copies or keep a written record of all important information.

CONNECTING TO OTHER DEVICES

When connecting to any other device, read its user guide for detailed safety instructions. Do not connect incompatible products.

EMERGENCY CALLS

Ensure the device is switched on and in service. Press the end key as many times as needed to clear the display and return to the main screen. Enter the emergency number, then press the send key. Give your location. Do not end the call until given permission to do so.

■ About your device

The wireless device described in this guide is approved for use on the following Verizon networks: CDMA 800 MHz, CDMA 1900 MHz, and CDMA2000 1xRTT. Contact Verizon for more information about networks.

For your safety

When using the features in this device, obey all laws and respect privacy and the legitimate rights of others.

Warning: To use any features in this device, other than the alarm clock, the device must be switched on. Do not switch the device on when wireless phone use may cause interference or danger.

■ Network services

To use the device you must have service from a network operator. Many of the features in this device depend on features in the wireless network to function. These network services may not be available on all networks or you may have to make specific arrangements with your network operator before you can utilize them. Your network operator may need to give you additional instructions for their use and explain what charges will apply. Some networks may have limitations that affect how you can use network services. For instance, some networks may not support all language-dependent characters and services.

Your network operator may have requested that certain features be disabled or not activated in your device. If so, they will not appear on your device menu. Contact your network operator for more information.

■ Shared memory

The following device features may share memory: tones in the gallery, calendar notes, games, and applications. Use of one or more of these features may reduce the memory available for the remaining features sharing memory. If your phone displays a message that the memory is full when you try to use a shared memory feature, delete some of the information or entries stored in the shared memory features before continuing. Deleting games and applications is not recommended, as these features cannot be recovered.

Welcome

Congratulations on your purchase of the Nokia 2366i mobile device. Your phone provides many functions practical for daily use, such as a hands-free loudspeaker, alarm clock, calculator, calendar, and more. To personalize your phone, you can set your favorite ringing tones.

■ Register your phone

Make sure to register your phone so we can serve your needs better if you need to call a customer care center or to have your phone repaired. Use the warranty card included in the box to register your phone.

■ Getting help

Find your phone label

If you need help, Verizon’s Wireless Customer Service is available. Dial 1-800-256-4646. It is recommended that you write down the following information and have it available:

• Electronic serial number (ESN) or mobile equipment ID (MEID)

• Your zip code

The ESN or MEID is found on the type label, which is located beneath the battery on the back of the phone. See "Insert the battery," p. 16.

Welcome

Verizon wireless customer service

To reach Verizon’s billing and customer service support, get updates on your phone, learn about accessibility solutions, or to get phone support, dial 1-800-256-4646.

Phone at a glance

1. Phone at a glance

• Earpiece (1)

•Main

display screen (2)

•Left soft

key (3)

•Volume

key (4)

• Send key (5)

• Keypad (6)

• Headset

connector (7)

•Four-way

scroll and center soft key; and Navigation keys (8)

• Right soft key (9)

• Power and end key (10)

• Pop-Port™ charger (11)

• Microphone (12)

Phone at a glance

■ Standby mode

The following soft keys appear in the standby mode. The standby mode is home base and indicates your phone is in the idle state.

Signal strength (1)— More bars indicate a stronger network signal.

Menu (2)—Press the center of the scroll key to select this option. Go to (3)—Press the left soft key to select this option. Names (4)—Press the right soft key to select this option.

Battery level (5)—A solid green symbol indicates a fully-charged battery. The green color appears smaller as the battery is used.

■ Navigation key shortcuts

The following Navigation

key shortcuts appear in the

standby mode. In the standby mode, the Navigation key or scroll key instantly takes you to frequently-accessed menus:

Scroll up to view the calculator. Scroll down to view the calendar. Scroll right to view the tools menu. Scroll left to view the settings menu. Press the center of the scroll key to view the main menu

or a selected submenu. To change the shortcuts to different menus, select Menu >

Settings > Phone > Navigation key. See "Navigation key," p. 40.

Phone at a glance

■ Indicators and icons

Some or all of the following indicators and icons may appear in the standby mode.

To view the icons on your phone, select Menu > Settings >

Phone details > Icon glossary.

The alarm clock is set to on. See "Alarm clock," p. 64. Bluetooth connectivity is activated.

See "Bluetooth connectivity," p. 44. Call status indicates an incoming call, a call in

progress, or a missed call. See "View missed calls," p. 26.

The countdown timer is running.

GPS is active and set to Location on. See "Location info sharing," p. 36.

A headset is connected to the phone.

A hearing aid is connected. See "Hearing aid,"p. 48.

Your phone keypad is locked. See "Keyguard," p. 23. You are roaming outside your home network.

See "Roaming options," p. 52. Your phone is set to the silent profile. See "Profiles,"

p. 31. The stopwatch timer is running in the background. Enter text to add contacts, write text messages,

notes, or to-do lists. You have a new text message. See "Text messages,"

p. 82. The vibrating alert is activated.

You have new voice messages. See "Voice messages," p. 88.

Phone at a glance

You are in a 1XRTT network. See "Network services," p. 7.

You are in a digital network. See "Network services," p. 7.

, , or An enhancement is connected to the

phone. See "Enhancement settings," p. 47.

■ Phone menus

Phone features are grouped according to function and are accessed through the main menus. Each main menu contains submenus and lists from which you can select or view items and customize your phone features. To access these menus and submenus, use the scroll method or a shortcut.

To change your menu view from list to grid, select Menu >

Options > Ma in menu view > List or Grid.

Select Menu > Options > Organize to arrange the order of the main menu icons. Use the scroll keys to move up, down, left, or right, and select Move.

Some features may not be available, depending on your network. For more information, contact your network operator.

Scroll method

Use the scroll key to scroll up, down, left, and right through the options.

1. In the standby mode, select Menu, and scroll through the main menus.

Phone at a glance

As you scroll through the menus, the menu number appears in the upper right corner of the display. Below the time indicator is a scroll bar with a tab that moves up or down on the right side of the display screen as you scroll through the menus, providing a visual representation of your current position in the menu structure.

2. When you arrive at a menu, press OK at the center of the scroll key to select submenus.

3. To return to the previous menu, select Back (the right soft key).

To return to the standby mode from any menu or submenu, press the end key.

In-phone help

Many features have brief descriptions (help text) you can view on the display. To view these descriptions, you must first activate help text as follows.

Select Menu > Settings > Phone > Help text activation >

On or Off.

Scroll to a feature, and wait about 14 seconds. Scroll down to view all of the description, or select Back to exit.

■ Lock code

Your device has a security option allowing you to lock your phone with a code. When the code is set and turned on, no outgoing calls are allowed, and the menu cannot be accessed without entering the correct code first. This prevents unauthorized outgoing calls or access to any information stored on your device.

The Security option is in the Settings menu. When you access the Security option, you must enter a lock code. The preset lock code is th e last four digits o f your phone num ber. If this does n ot work, contact Verizon Wireless Customer Service for help.

Phone at a glance

You must enter the lock code to access the following

Security option:

1. In the standby mode, select Menu > Settings > Security.

2. Enter the lock code, and select OK. See "Change lock code," p. 50.

■ Go to functions

The Go to men u enables y ou to chang e the fun ctio n of th e left soft key on your phone. With this function, you can quickly access your most frequently used functions from the Go to menu in the standby mode.

Choose Go to functions

1. In the standby mode, select Go to > Options >

Select options.

2. Scroll up or down to the desired function.

3. Select Mark to add a function or Unmark to remove a function.

4. Select Done when you have added all desired functions, and Yes to save the changes.

Organize functions

1. Select Go to > Options > Organize. Scroll to the function you want to move, and select Move.

2. Use the scroll keys to move the function up or down, and select OK.

3. Select Done when you have moved all desired functions, and Yes to save the changes.

Set up your phone

2. Set up your phone

■ Antenna

Your device has a fixed antenna located at the top of the phone with the fold closed. Hold the phone with the antenna area pointed up and over your shoulder.

In the Nokia 2366i phone, the internal GPS antenna is activated when placing emergency calls or when Locat ion on is selected from the Location info sharing menu (a network-dependent feature). See "Location info sharing," p. 36.

Note: Do not touch the antenna unnecessarily with the device switched on. Contact with the antenna affects call quality and may cause the device to operate at a higher power level than otherwise needed. Not touching the antenna area during a phone call optimizes the antenna performance and battery life.

■ Insert the battery

Note: Always switch off the power, and disconnect

the charger and any other device before removing the cover. Avoid touching electronic components while changing the cover. Always store and use the device with the cover attached.

Slide the back cover off to remove it (1).

Insert the battery so that the goldcolored connectors on the battery align with the connectors on the phone (2).

Replace the back cover: align the catches (3) together, and slide the cover (4) forward.

Set up your phone

Charge the battery

Note: Before you use a charger with this device,

check the charger’s model number. This device is intended for use with the AC-4UZ.

1. Plug the charger transformer into a standard wall outlet.

2. Plug the charger connector into the Pop-Port connector at the bottom end of your phone.

After a few seconds, the battery indicator on the display starts to scroll. If the battery is completely discharged, it may take a few minutes before the charging indicator appears on the display or before any calls can be made.

Warning: Use only batteries, chargers, and enhancements approved by Nokia for use with the Nokia 2366i device. The use of any other types may invalidate any approval or warranty, and may be dangerous.

■ Switch your phone on or off

1. To switch your phone on or off, press and hold the end key for at least 4 seconds.

2. Enter the lock code, if necessary, and select OK. See "Phone lock," p. 49.

Set up your phone

Warning: Do not switch the phone on when wireless

phone use is prohibited or when it may cause interference or danger.

■ Connect the headset

A compatible headset may be purchased sepa rately as an enhancement. See "Enhancement settings," p. 47. The Nokia 2366i is a Bluetooth compatible device. See "Pair a Bluetooth headset to a phone,"p. 46.

1. Plug the headset connector into the phone.

2. Position the headset on your ear.

With the headset connected, you can make, answer, and end calls as usual:

• Use the keypad to enter numbers.

• Press the send key to place a call.

• Press the end key to end a call.

■ Make a call

Keypad

1. Enter the phone number (including the area code), and press the send key. (To delete a character to the left of the cursor, select Clear.)

2. Press the end key to end the call, or select End call to cancel the call attempt.

Set up your phone

Contacts list

1. In the standby mode, scroll down to display your contacts list and highlight your desired entry.

2. Select Details to highlight your desired number; then select Call.

Last dialed number

1. In the standby mode, press the send key to display the last 20 numbers dialed.

2. Scroll to the number (or name) you want to redial, and press the send key.

Conference calling

Conference calling is a network service that allows you to take part in a conference call with two other participants.

1. Make a call to the first participant.

2. With the first participant on the line, select Options >

New call.

3. Enter the phone number of the second participant, or select Find to retrieve a number from the contacts list. Select Call. The first participant is put on hold.

4. When the second participant answers, press the send key to connect the calls.

5. To end the conference call, select Options > End all calls, or press the end key.

■ Answer calls

Incoming call

1. With the fold open, press the send key, or select Answer to answer the call.

Set up your phone

2. Press the end key to reject the call.

Select Silence to mute the ringing tone, then Dismiss, or do nothing. The call is eventually diverted to voicemail.

With your phone set to silent in the profiles menu, select

Dismiss to divert the call to voicemail.

3. With the fold closed, press the volume key to mute the ringing tone.

By default, your phone answers an incoming call when you open the fold. You can change the setting to not answer the call when the fold opens.

Select Menu > Settings > Call > A nswer when fold is opened >

On or Off.

Adjust the earpiece volume

Whether in or out of a call, you can scroll the volume key up or down to adjust the volume of the earpiece. When you adjust the volume, a bar chart indicates the volume level.

Answer a call with the keypad locked

To answer a call with the keypad locked, press the send key with the fold open. During the call, all features function as normal. When you end or reject the call, the keypad automatically relocks. See "Keyguard," p. 23.

When the keypad lock is on, calls still may be possible to the official emergency number programmed into your device. Enter the emergency number, and press the send key.

Loudspeaker

Warning: Do not hold the device near your ear when

the loudspeaker is in use because the volume may be extremely loud.

Set up your phone

• To activate the loudspeaker during a call, select Loudsp. and close the fold.

• To deactivate the loudspeaker during a call, open the fold and select Handset. The loudspeaker is automatically deactivated when the call ends.

The loudspeaker is deactivated when a call (or call attempt) ends or when certain enhancements are connected.

Call options

Many of the options you can use during a call are network services. Check with your network operator for more information.

1. Select Options during a call to display the following options:

Loudspeaker or Handset—Activate or deactivate

the loudspeaker.

New call—Start a conference call. See "Conference

calling," p. 20.

Save—Save a new number to your contacts list. This option

is available only when entering numbers during a call.

Add to contact—Add a phone number to a contact in your

contacts list. This option is available only when entering numbers during a call.

End all calls—Disconnect from all active calls.

Touch tones—Enter the numbers, and select Tones to send

the numbers as tones.

Contacts—View the contacts menu.

Menu—View the phone menu.

2. Select an option to activate the option or enter its submenu.

Set up your phone

■ Keyguard

With the keyguard, you can lock the keypad to prevent keys from accidental presses. The locked keypad unlocks when you receive a call. After the call, the lock automatically reactivates.

With the keyguard on, calls still may be possible to the official emergency number programmed into your phone. Enter the emergency number, and press the send key.

Lock the keypad

Select Menu; then press * within 2 seconds.

Unlock the keypad

Select Unlock; then press * within 2 seconds.

Gallery

3. Gallery

You can save recordings, and ringing tones to folders in the

Gallery and add new folders. You can download tones with

text messages.

Copyright protection may prevent some ringing tones, and other content from being copied, modified, transferred, or forwarded.

Your device has about 1 MB of memory for storing files in the

Gallery. If the device displays a message that the memory is

full, delete some existing files before proceeding.

■ Folders

1. Select Menu > Gallery > Themes, Graphics, Tones,

Recordings, or a folder you created.

2. Select Open to view a list of the files in the folder or

Options to access the following: Delete folder —Delete a folder you have created. You

cannot delete a preset folder.

Move—Move the selected folder into another folder.

After selecting Move, scroll to another folder, and select

Move to. You cannot move a preset folder. Rename folder—Rename a folder you have created. You

cannot rename a preset folder.

Details—Show the name, size, and date of creation of the

selected folder.

Type of view > List with details, List, or Grid—Determine

how to display the folders and files within them.

Sort—Sort the contents of the selected folder by name,

date, format, or size.

Add folder—Create a new folder.

Gallery

Memory status—Check the available memory for the

device handset.

Mark or Unmark—Mark or unmark folders to be deleted

or moved.

Mark all—Mark all folders to be deleted.

Other folder options

Other options are available after opening content specific folders in the gallery.

To choose a theme, select Menu > Gallery > Themes >

Options > Apply theme.

Choose wallpaper and screen savers in the Graphics folder. Select Menu > Gallery > Wallpapers or Sc r. savers > Use image,

Set contrast, Rename, or Open in sequence .

In Tones, select Menu > Gallery > Tones > Ring. tones or

Alert tones > Use tone.

Use recordings as ringing tones, message alert tones, or alarm tones. Select Menu > Gallery > Recordings > Use tone.

Recent calls

4. Recent calls

Recent calls stores information about the last 20 missed,

received, or dialed calls. It also displays the total duration of all calls. When the number of calls exceed the maximum, the most recent call replaces the oldest.

When viewing missed, received, or dialed calls, the menu options are the same:

Time of call—Display the date and time of the call. Send message—Send a message to the number. Use number—Edit the number and associate a name with

the number.

Save—Enter a name for the number and save it to your

contacts list.

Add to contact—Add the number to an existing name in your

contacts list, if the number is not associated with a name.

Delete—Clear the number from memory. Call—Call the number.

■ View missed calls

Missed calls are calls that were never answered. The missed calls feature does not function when your phone is switched off.

1. Select Menu > Recent calls > Missed calls; if a missed call notification appears, select List.

2. Scroll to a name or number, select Options, and an option.

■ View received calls

Received calls are calls that have been answered.

1. Select Menu > Recent calls > Received calls.

2. Scroll to a name or number, select Options, and an option.

Recent calls

■ View dialed numbers

Dialed calls are numbers you have previously dialed from your phone:

1. Press the send key; or select Menu > Recent calls >

Dialed numbers.

2. Scroll to a name or number, and select Options and an option.

■ View message recipients

You can view recipients of messages you have sent. Select

Menu > Recent calls > Message recipients.

■ Time of call

You can make or receive up to five calls to or from the same number and view the time each call occurred. Your clock must be set for this feature to work accurately.

1. While viewing a missed, received, or dialed call, select

Options > Time of call.

2. Scroll down to view the most recent call times from this number.

3. Select Back to return to the options list.

■ Clear calls

You can delete any missed, dialed, or received calls from phone memory.

Select Menu > Recent calls > Clear calls > All call list s, Missed

calls, Received calls, Dialed numbers, or Msg. recipients.

Recent calls

■ Call timers

To view the duration of your calls, select Menu > Recent

calls > Call timers and one of the following options:

Last call duration—Check the time of your last call.

Dialed calls' duration—Check the combined time of calls you

dialed for either Home or Roaming.

Received calls' duration—Check the combined time of calls

you received for either Home or Roaming.

All calls' duration—Check the combined time of all calls.

Life timer—Check the total airtime minutes logged on

your phone.

Clear timers—Enter your lock code, and select OK to clear all

timers on your phone.

Note: Some timers, including the life timer, may be reset during service or software upgrades.

Media

5. Media

■ Voice recorder

You can record pieces of speech or sound with your device and listen to them later. The total available time is 3 minutes with no memos stored. The maximum length of a recording depends on how much memory remains available. Select

Menu > Media > Recorder > Record to start the recording

or Recordings list to manage the folder you have defined for recording storage.

Record speech or sound

1. Select Menu > Media > Recorder.

2. To start the recording, select the record virtual button using the right and left scroll keys; press Select.

3. Hold the phone in the normal position near your ear, and record your message.

4. When you are finished recording, select the stop virtual button.

The recording is given a default name and saved to the

Recordings list. The default location of the Recordings list

is the Recordings folder in the Gallery.

After you have made a recording, select Options > Play last

recorded to replay the recording.

+ 83 hidden pages

Nokia 2366i User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Contents

For your safety

Welcome

1. Phone at a glance

2. Set up your phone

3. Gallery

4. Recent calls

5. Media
