8-Port Gigabit Ethernet Smart Managed Pro Switches with Cloud Management Data Sheet
GS108Tv3, GS110TPv3
As a leading provider of network equipment for SMBs, NETGEAR understands the
importance of providing great choice of port counts, PoE port counts and PoE power budgets that can adapt to the business’s needs, whether in the hospitality, catering, education or retail domains. That is why NETGEAR launched these two new 8-Port Gigabit Smart Managed Pro switches, one with PoE, one without PoE. Also, NETGEAR understands the importance of easy and centralized management for business network-
ing. Therefore, NETGEAR now expands Cloud Management capabilities to select models within its Smart Managed Pro switch line with these new versions of two of our most popular Smart Managed Pro switches.
The GS108Tv3 and GS110TPv3 8-Port Gigabit Smart Managed Pro Switches provides a great value, with configurable L2 network features like VLANs and PoE operation scheduling, allowing SMB customers to deploy PoE-based VoIP phones and IP surveillance. Advanced features such as Layer 3 static routing, IPv6 management, ACL, DiffServ QoS, LACP link aggregation and Spanning Tree will satisfy even the most advanced small business networks.
The GS110TPv3 adds full 8 port PoE support for deployment of modern PoE devices. Cautious spender organizations can now deploy PoE devices connected to a cost effective switch, with a reasonable PoE power budget of 55W. Each port can provide up to 30 watts to power up connected devices. Fanless, the GS110TPv3 supports perfectly silent desktop operation or wall mounting.
Specifically for these 2 new models, additional features were added for full flexibility: Single Sign-On registration for firmware and security updates and warranty entitlement. Remote Cloud Management capability with NETGEAR Insight. By activating the NETGEAR Insight Cloud management, the users will enable fundamental management features allowing businesses simpler configuration and deployment from anywhere using the NETGEAR Insight app from mobile devices or the Insight Cloud Portal from any device with a web browser.
Highlights
Flexible and cost-effective solution for SMB data, voice and video converged network
•Flexible and cost-effective solution for SMB data, voice and video converged network
•8 Gigabit 10/100/1000BASE-T RJ-45 ports
•1 PD port to receive power from another PoE switch or injector (GS108Tv3 only)
•55W PoE budget available across 8 Gigabit PoE+ (802.3at/802.3af) ports (GS110TPv3 only)
•2 dedicated Gigabit SFP fiber ports (GS110TPv3 only)
•Non-blocking switching with 16Gbps and 20Gbps
•Fanless switches for silent operation in noise sensitative enviornment
•Flexible mounting options - desktop and wall-mounting with VESA holes
Powerful Connectivity and Security
Features
•Layer 3 static routing with 32 routes (IPv4) for inter-VLAN local routing
•Advanced VLAN support for better network segmentation
•L2/L3/L4 access control lists (ACLs) for granular network access control including 802.1x port authentication
•Advanced per port PoE controls for remote power management of PoE connected devices including operation scheduling
(GS110TPv3 only)
•Advanced QoS (Quality of Service) for traffic prioritization including port-based, 802.1p and L2/L3/L4 DSCP-based
•Auto “denial-of-service” (DoS) prevention
•IGMP Snooping and Querier for multicast optimization
•Rate limiting and priority queuing for better bandwidth allocation
•Port mirroring for network monitoring
•Energy Efficient Ethernet (IEEE 802.3az) for maximum power savings
•Cable test to troubleshoot connection issues
•SNMP v1, v2c, v3 and RMON remote monitoring
Fully-integrated cloud-manageable devices*
Remote/Cloud Management capability with NETGEAR Insight. Instantly activate NETGEAR Insight Cloud management from the web GUI, given they subscribe to Basic (first 2 devices free), Premium or Insight Pro (Insight Pro is for resellers/MSP only)
Smart IT, not Big IT
•Easy to manage via web-Based
Management GUI or Smart Control Center
(Windows PC required) for multi-switch deployment
•NETGEAR Switch Discovery Tool (NSDT) to discover, register and access to the local browser interface to configure the switches
•Network Management System (NMS300), allowing all NETGEAR business products to be deployed and managed through this single interface
NETGEAR quality and reliability
•Worry-free Limited Lifetime Warranty*, online technical chat support and Next
Business Day (NBD) replacement.
Page 1 of 12
8-Port Gigabit Ethernet Smart Managed Pro Switches with Cloud Management |
|
Data Sheet |
|||||||||||||||||||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
GS108Tv3, GS110TPv3 |
|||||
Hardware at a Glance |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
FRONT |
|
|
|
|
|
|
|
|
|
|
REAR |
|
|
|
SIDE |
||||||
Model Name |
Form-Factor |
|
10/100/1000BASE-T |
|
|
1G SFP Ports |
|
PoE/PoE+ Ports |
|
|
Power Supply |
|
|
|
Fans |
||||||||||||||||||
|
RJ-45 Copper Ports |
|
|
|
|
(Budget) |
|
|
|
|
|
|
|||||||||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||||
GS108Tv3 |
Desktop |
|
|
|
|
8 |
|
|
|
|
- |
|
|
- |
|
|
|
|
|
|
External |
|
|
|
Fanless |
||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
DC 12V 1.0A |
|
|
|
|||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
GS110TPv3 |
Desktop |
|
|
|
|
8 |
|
|
|
|
2 (Dedicated) |
|
|
8 PoE+ (55W) |
|
|
|
|
External |
|
|
|
Fanless |
||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
DC 54V 1.25A |
|
|
|
|||||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Software at a Glance |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
LAYER 2+ / LAYER 3 LITE FEATURES |
|
|
|
|
|
|
|
|
|
|
||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
IEEE |
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
IPv4/IPv6 |
|
|
Static |
|
IPv4/IPv6 |
|
|
Auto-VoIP, |
|
(802.3az) |
|
|
|
|
|
Link |
||||||||||
Management |
|
|
|
|
ACL and QoS |
|
|
Routing |
|
Multicast |
VLANs |
Auto-Video |
|
Energy |
|
Convergence |
|
Aggregation/ |
|||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Filtering |
|
|
|
|
|
|
Efficient |
|
|
|
|
Port Trunking |
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Ethernet |
|
|
|
|
|
|
|||
Web Browser-based GUI (HTTP/ |
|
L2, L3, L4 Ingress |
|
|
IPv4 |
|
|
|
IGMP |
Static, |
|
Yes |
|
|
Yes |
|
LLDP-MED, |
|
|
LACP and |
|||||||||||||
HTTPS); |
|
|
|
|
|
|
|
|
|
32 Routes |
|
Snooping, |
Dynamic, |
|
|
|
|
|
|
|
|
RADIUS, |
|
Manual Static |
|||||||||
|
|
|
|
|
|
|
|
|
|
|
|
Querier, Fast |
Voice, |
|
|
|
|
|
|
|
|
802.1X |
|
|
|
LAGs |
|||||||
NETGEAR Insight mobile app or |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||||||||
|
|
|
|
|
|
|
|
|
Leave, L2 |
Video, |
|
|
|
|
|
|
|
|
|
|
|
|
(up to 8 LAGs |
||||||||||
Insight Cloud Portal for local or |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||||||||
|
|
|
|
|
|
|
|
|
Multicast |
8K Max |
|
|
|
|
|
|
|
|
|
|
|
|
|
with max 8 |
|||||||||
remote management from your |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||||||
|
|
|
|
|
|
|
|
|
|
Router |
MAC (64 |
|
|
|
|
|
|
|
|
|
|
|
|
|
members) |
||||||||
mobile device, |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
VLANs), |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
PC, Mac, or tablet; |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Protocol |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
PC-Based Smart Control Center |
|
|
|
|
|
|
|
|
|
|
|
|
|
based, |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
GARP, |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||
Utility (SCC), |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
GVRP |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
IPv4 and IPv6 management, |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
SNMP, RMON |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
Performance at a Glance |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
Mode Name |
|
Packet |
|
|
|
CPU |
|
ACLs |
|
|
MAC Address Table |
|
Fabric |
|
|
|
|
Latency |
|
|
|
IPv4Static |
|||||||||||
|
Buffer |
|
|
|
|
|
|
|
ARP Table VLANs |
|
|
|
|
(64-Byte Packet) |
|
Routing |
|||||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||||||||
GS108Tv3 |
|
|
|
|
|
500MHz single core |
|
100 shared |
|
|
8K Max MAC |
|
16 Gbps line-rate |
|
|
1G Copper: <3.85µs |
|
|
|||||||||||||||
|
|
512K |
|
|
|
128MB RAM |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
32 |
|||||||||||
GS110TPv3 |
|
|
|
|
|
(ingress) |
|
|
64 VLANs |
|
20 Gbps line-rate |
|
1G Copper: < 3.69 µs; |
||||||||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||||||||||||||
|
|
|
|
|
32MB SPI FLASH |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
1G Fiber: < 3.02 µs |
|
|
|||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
Ordering Information |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||||||||||||
Model Name |
|
|
|
|
Americas |
|
|
Europe |
|
Asia Pacific |
|
|
India |
|
|
|
China |
||||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||||
GS108Tv3 |
|
GS108T-300NAS |
|
GS108T-300PES |
|
GS108T-300AUS- |
|
|
|
- |
|
|
|
GS108T-300PRS |
|||||||||||||||||||
|
|
GS108T-300UKS |
|
GS108T-300JPS |
|
|
|
|
|
|
|||||||||||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||||||
|
|
|
|
|
|
|
|
|
|
|
|||||||||||||||||||||||
GS110TPv3 |
|
GS110TP-300NAS |
|
GS110TP-300EUS |
|
GS110TP-300AJS |
|
|
GS110TP-300INS |
|
GS110TP-300PRS |
||||||||||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Page 2 of 12
8-Port Gigabit Ethernet Smart Managed Pro Switches with Cloud Management Data Sheet
|
|
GS108Tv3, GS110TPv3 |
Features and Benefits |
|
|
|
|
|
|
|
|
Hardware Features |
Benefits |
|
Fully-integrated Cloud-manageable |
Require no additional hardware (cloud keys, network portals, local servers, VPN or proxy appliances etc) |
|
Devices |
to directly connect to the cloud and allow remote management. No additional hardware or software. Just |
|
|
switch to Insight Cloud Management mode through Web browser-based User Interface and go. |
|
|
|
|
1000BASE-T Copper Ethernet |
Support high-density VoIP, Surveillance and Wi-Fi AP deployments, scalable for future growth. Never face |
|
and PoE+ (GS110TPv3 only) |
the risk of running out of PoE ports or PoE power budget. |
|
connections |
|
|
1000BASE-X SFP ports |
Two dedicated Gigabit SFP ports Dedicated SFP ports provide fiber uplinks without sacrificing any downlink |
|
(GS110TPv3 only) |
copper Gigabit Ethernet port, and across long distances. Support for Fiber and Copper modules. |
|
Silent Acoustics |
Fanless design allows for silent operation, great for deployment in noise-sensitive environments. |
|
|
|
|
Energy Efficient Ethernet |
Maximum power reduction for ongoing operation cost savings. |
|
(IEEE 802.3az) |
|
|
Desktop and Wallmount |
Flexible deployment on desktop, wall or other location using 75mm VESA-compliant mounts. |
|
(VESA holes available) |
|
|
Kensington Lock Slot |
Prevent theft, removal, or tampering when used for desktop deployment. |
|
|
|
|
Software Features |
Benefits |
Remote setup, management, and |
Locally or remotely setup, configure, manage, monitor or even troubleshoot your network from anywhere, |
monitoring anywhere, anytime, |
anytime. Check network status, view dashboards for network health and activity, power cycle PoE ports, |
from your mobile device, PC, Mac, |
etc, and update firmware remotely. No need to be on-site, open up ports to your network, or VPN into |
or tablet |
it. |
|
|
Auto-join and Configure |
Additional Insight Managed devices added to the network automatically inherit settings and configuration. |
(Zero-Touch Provisioning) |
|
|
|
Multi-site, Multi-network Single |
View and configure multiple networks across multiple sites, all from one single app; NETGEAR Insight. |
Pane-of-Glass View |
|
|
|
Comprehensive IPv6 Support for |
Build current network with future in mind. Ensure investment protection and a smooth migration to an |
Management, ACLs and QoS |
IPv6-based network without switch replacement. |
|
|
IPv4 |
A simple way to provide segmentation of the network with internal routing through the switch – reserving |
|
the router for external traffic routing only, making the entire network more efficient. |
|
|
Robust security features: |
Build a secured, converged network with all types of traffic by preventing external attacks and blocking |
• 802.1x authentication (EAP) |
malware while allowing secure access for authorized users. |
• Port-based security by locked |
|
MAC |
|
• ACL filtering to permit or deny |
|
traffic based on MAC and IP |
|
addresses |
|
|
|
Comprehensive QoS features: |
Advanced controls for optimized network performance and better delivery of mission-critical traffic such as |
• Port-based or VLAN |
voice and video. |
802.1p-based prioritization |
|
• Layer 3-based (DSCP) |
|
prioritization |
|
• Port-based egress rate limiting |
|
|
|
Page 3 of 12
8-Port Gigabit Ethernet Smart Managed Pro Switches with Cloud Management Data Sheet
GS108Tv3, GS110TPv3
Software Features (con’t) |
Benefits |
|
|
|
|
Auto-VoIP, Auto-Voice VLAN, and |
Automatic Voice over IP prioritization (Auto-VoIP) simplifies most complex multi-vendor IP telephone |
|
Auto-Video VLAN |
deployments either based on protocols (SIP, H.323 and SCCP) or on OUI bytes (default database and |
|
|
user-based OUIs) in the phone source MAC address, providing the best class of service to VoIP streams |
|
|
(both data and signaling) over other ordinary traffic by classifying traffic, and enabling correct egress queue |
|
|
configuration. Similarly, Auto-Video VLAN enables IGMP snooping to minimize broadcast streams. |
|
IGMP Snooping and MLD Snooping |
Facilitate fast receiver joins and leaves for multicast streams. Save cost and improve network efficiency by |
|
|
ensuring multicast traffic only reaches designated receivers without the need of an extra multicast router. |
|
Protected Ports |
Ensure no exchange of unicast, broadcast, or multicast traffic between the protected ports on the switch, |
|
|
thereby improving the security of your converged network. This allows your sensitive phone phone |
|
|
conversations to stay private and your surveillance video clips can be forwarded to their designated |
|
|
storage device without leakage or alteration. |
|
DHCP Snooping |
Ensure IP address allocation integrity by only allowing DHCP messages from trusted DHCP servers and |
|
|
dropping malformed DHCP messages with a port or MAC address mismatch. |
|
Dynamic VLAN Assignment |
IP phones and PCs can authenticate on the same port but under different VLAN assignment policies. Users |
|
(RADIUS) |
are free to move around and enjoy the same level of network access regardless of their physical location on |
|
|
the network. |
|
Port Trunking/Link Aggregation |
Build up bigger bandwidth to support aggregated uplink/downlink traffic or to provide redundant link(s). |
|
(LACP) |
Aggregate up to 8 ports for 8Gbps connections. |
|
|
|
|
Loop Prevention and Auto-DoS |
Detect and prevent (auto port shutdown) accidental network loops and protect against DoS attacks. |
|
Prevention |
||
|
||
PoE Timer and Scheduling |
Allows IT administrators to increase network security, better utilize network resources and conserve energy |
|
(GS110TPv3 only) |
by scheduling or remotely controlling on/off of PoE ports. |
|
Port Mirroring and Cable Test |
Many-to-one port mirroring for better and quicker network diagnostics and troubleshooting. Cable test |
|
|
easily identifies bad Ethernet cables. |
|
Dual Firmware Images |
Dual firmware images for transparent firmware updates with minimum service interruption |
|
|
||
|
|
|
Firmware Updates from Cloud |
Direct cloud-to-device firmware updates, initiated and/or scheduled using the Insight app, all from the |
|
|
palm of your hand, anytime, anywhere! |
Simply Activate NETGEAR Insight Cloud Management to manage your network. Anytime. Anywhere.
By activating the NETGEAR Insight Cloud management, the users will enable fundamental management features allowing businesses simpler configuration and deployment from anywhere using the NETGEAR Insight app from mobile devices or the Insight Cloud Portal from any device with a web browser.
Unique advanced management features of these Insight Managed devices include:
•Remote monitoring and management with performance dashboards and troubleshooting features including remote reboot, port and PoE advanced configuration including remote enable/disable/power-cycle, PoE scheduling, and firmware updates with auto-schedule mode
•Single pane-of-glass multi-device, multi-network, and multi-site remote monitoring and notifications with the NETGEAR Insight app
•Full-fledged local or remote access for configuration, management, and monitoring on a larger display using your tablet, laptop, or desktop computer through the NETGEAR Insight Cloud Portal
•Configurable in-app and email alerts and notifications
•Auto-join and configure (zero-touch provisioning) for additional Insight Managed devices added to the network
•Centralized network configuration (policies) across Insight Managed Switches, Access Points, and ReadyNAS storage for VLANs, ACLs, QoS, LAGs, etc.
•Cloud-based network administration, monitoring, and firmware management
For more information about NETGEAR Insight-manageable device settings, please see at: https://www.netgear.com/support/product/Insight.aspx
Page 4 of 12
