NAD T 533 User Manual

®

T 533

DVD / CD / MP3 Player

ENGLISH

Owner’s Manual

Introduction

SAFETY PRECAUTIONS

ENGLISH FRANÇAIS

DEUTSCH

NEDERLANDS

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR
MOISTURE

CAUTION

THIS DVD PLAYER EMPLOYS A LASER SYSTEM. TO ENSURE PROPER USE
OF THIS PRODUCT, PLEASE READ THIS OWNER’S MANUAL CAREFULLY
AND RETAIN FOR FUTURE REFERENCE. SHOULD THE UNIT REQUIRE
MAINTENANCE, CONTACT AN AUTHORIZED SERVICE LOCATION.

USE OF CONTROLS, ADJUSTMENTS TO MODIFY PERFORMANCE OF
PROCEDURES OTHER THAN THOSE SPECIFIED MAY RESULT IN
HAZARDOUS RADIATION EXPOSURE.

TO PREVENT DIRECT EXPOSURE TO LASER BEAM, DO NOT TRY TO
OPEN THE ENCLOSURE. VISIBLE LASER RADIATION EXISTS WHEN THE
ENCLOSURE IS OPENED. DO NOT STARE INTO BEAM.

THE APPARATUS SHOULD NOT BE EXPOSED TO DRIPPING OR
SPLASHING, AND OBJECTS FILLED WITH LIQUIDS, SUCH AS VASES,
SHOULD NEVER BE PLACED ON THE APPARATUS.

WARNING: CHANGES OR MODIFICATIONS NOT
EXPRESSLY APPROVED BY THE PARTY RESPONSIBLE FOR
COMPLIANCE COULD VOID THE USER’S AUTHORITY TO
OPERATE THE EQUIPMENT.

NOTES ON COPYRIGHT

It is forbidden by law to copy, broadcast, show, broadcast via cable, play
in public, or rent copyright material without permission. This product is
equipped with copy protection measures developed by Macrovision.
Copy protection signals are recorded on some discs. When recording
these discs on a VCR, picture noise will appear during playback. This
product incorporates copyright protection technology that is protected
by certain U.S. patent claims and other intellectual property rights
owned by Macrovision Corporation and other rights owners. Use of this
copyright protection technology must be authorized by Macrovision
Corporation, and is intended for home and other limited viewing uses
only unless otherwise authorized by Macrovision Corporation. Reverse
engineering or disassembly is prohibited.

RECORD YOUR MODEL NUMBER (NOW, WHILE YOU CAN
SEE IT)

The model and serial number of your new DVD player are located on
the back of the DVD player cabinet. For your future convenience, we
suggest that you record these numbers here:

MODEL NO.____________________________
SERIAL NO.____________________________

ESPAÑOL

ITALIANO

PORTUGUÊS

SVENSKA

This product is manufactured to comply with the radio interference
requirements of EEC DIRECTIVE 89/336/EEC, 93/68/EEC and 73/23/EEC.

NAD is a trademark of NAD Electronics International, a division of Lenbrook Industries Limited

Copyright 2003, NAD Electronics International, a division of Lenbrook Industries Limited

2

Introduction

TABLE OF CONTENTS

INTRODUCTION

Safety precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Before Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Playable Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Disc-related terms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Types of video CDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Precautions for handling the unit . . . . . . . . . . . . . . . . . . . . . . . . 5

Notes on Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

About Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Rear Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Front Panel and Display Window . . . . . . . . . . . . . . . . . . . . . . . .7

Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

PREPARATION

Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Connecting to a TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Connecting to Optional Equipment . . . . . . . . . . . . . . . . . . . . . 10

Before Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

General Explanation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

On-Screen Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Initial Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Sound . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Speaker selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Others . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Parental Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

OPERATION

Operation with DVD and Video CD . . . . . . . . . . . . . . . . . . . . .17

Playing a DVD and Video CD . . . . . . . . . . . . . . . . . . . . . . . . . 17

General Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Special DVD Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

DVD Audio Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Operation with Audio CD and MP3 / WMA Disc . . . . . . . . . . .21

Playing an Audio CD and MP3 / WMA Disc . . . . . . . . . . . . . . . 21

Notes on MP3/WMA Recordings . . . . . . . . . . . . . . . . . . . . . . . 21

Operation with JPEG Disc . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

Viewing a JPEG disc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Programmed Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

Additional Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

REFERENCE

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26

Table of Languages and Their Abbreviations . . . . . . . . . . . . . .27

Country Code List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

ENGLISH

FRANÇAISDEUTSCHNEDERLANDSESPAÑOL

ITALIANO

PORTUGUÊS

SVENSKA

3

Introduction

1

BEFORE USE

ENGLISH FRANÇAIS

DEUTSCH

NEDERLANDS

ESPAÑOL

PLAYABLE DISCS

DVD video discs
(8 cm / 12 cm disc)

DVD audio discs
(8 cm / 12 cm disc)

Video CD (VCD)
(8 cm / 12 cm disc)

Audio CD
(8 cm / 12 cm disc)

In addition, this unit can play a DVD-R, DVD±RW, Kodak PICTURE CD,
SVCD, and CD-R or CD-RW that contains audio titles, MP3, WMA or
JPEG files.

NOTES

• Depending on the conditions of the recording equipment or the CD­R/RW (or DVD-R/±RW) disc itself, some CD-R/RW (or DVD-R/±RW)
discs cannot be played on the unit.

• Do not attach any seal or label to either side (the labeled side or the
recorded side) of a disc.

• Do not use irregularly shaped CDs (e.g., heart-shaped or octagonal).
It may result in malfunctions.

NOTES ON DVDS AND VIDEO CDS

Some playback operations of DVDs and Video CDs may be intentionally
fixed by software manufacturers.
As this unit plays DVDs and Video CDs according to disc content
designed by the software manufacturer, some playback features of the
unit may not be available or other functions may be added.
Refer also to the instructions supplied with the DVDs and Video CDs.
Some DVDs made for business purposes may not be played on the unit.

TRACK (DVD AUDIO, VIDEO CD AND AUDIO CD ONLY)

Sections of a picture or a musical piece on a video CD or an audio CD.
Each track is assigned a track number, enabling you to locate the track
you want.

SCENE

On a video CD with PBC (Playback control) functions, moving pictures
and still pictures are divided into sections called “Scenes”. Each scene is
displayed in the menu screen and assigned a scene number, enabling
you to locate the scene you want. A scene is composed of one or several
tracks.

TYPES OF VIDEO CDS

There are two types of video CDs:

Video CDs equipped with PBC (Version 2.0)

PBC (Playback control) functions allow you to interact with the system
via menus, search functions, or other typical computer-like operations.
Moreover, still pictures of high resolution can be played if they are
included in the disc.

Video CDs not equipped with PBC (Version 1.1)

Operated in the same way as audio CDs, these discs allow playback of
video pictures as well as sound, but they are not equipped with PBC.

ITALIANO

PORTUGUÊS

SVENSKA

REGIONAL CODE OF THE DVD PLAYER AND DVDS

This DVD player is designed and manufactured for playback of
region “1” encoded DVD software.

The region code on the labels of some DVD discs indicates
which type of player can play those discs. This unit can play only DVD
discs labeled “1” or “ALL”. If you try to play any other discs, the
message “Check Regional Code” will appear on the TV screen. Some
DVD discs may not have a region code label even though their playback
is prohibited by area limits.

DISC-RELATED TERMS
TITLE (DVD VIDEO DISCS ONLY)

The main film content, accompanying feature content, additional
feature content, or music album. Each title is assigned a title reference
number enabling you to locate it easily.

CHAPTER (DVD VIDEO DISCS ONLY)

Sections of a picture or a musical piece that are smaller than titles. A title
is composed of one or several chapters. Each chapter is assigned a
chapter number, enabling you to locate the chapter you want.
Depending on the disc, chapters may not be recorded.

GROUP (DVD AUDIO DISCS ONLY)

The main audio content or accompanying feature content or additional
feature content, or music album. Each group is assigned a group
reference number enabling you to locate it easily.

4

Introduction

BEFORE USE

PRECAUTIONS FOR HANDLING THE UNIT
WHEN SHIPPING THE UNIT

The original shipping carton and packing materials come in handy. For
maximum protection, re-pack the unit as it was originally packed at the
factory.

WHEN SETTING UP THE UNIT

The picture and sound of a nearby TV, VCR, or radio may be distorted
during playback. In this case, position the unit away from the TV, VCR,
or radio, or turn off the unit after removing the disc.

TO KEEP THE EXTERIOR SURFACES CLEAN

Do not use volatile liquids, such as insecticide spray, near the unit. Do
not leave rubber or plastic products in contact with the unit for a long
period of time. They will leave marks on the surface.

TO CLEAN THE CABINET

Use a soft, dry cloth. If the surfaces are extremely dirty, use a soft cloth
lightly moistened with a mild detergent solution. Do not use strong
solvents such as alcohol, benzine, or thinner, as these might damage the
surface of the unit.

TO OBTAIN A CLEAR PICTURE

The DVD player is a high-tech, precision device. If the optical pick-up
lens and disc drive parts are dirty or worn, the picture quality will be
poor. Regular inspection and maintenance are recommended after every
1,000 hours of use. (This depends on the operating environment.) For
details, please contact your nearest dealer.

ABOUT SYMBOLS
ABOUT THE SYMBOL DISPLAY

“” may appear on the TV screen during operation. This icon means
the function explained in this owner’s manual is not available on that
specific DVD video disc.

ABOUT THE DISC SYMBOLS FOR INSTRUCTIONS

A section whose title has one of the following symbol is applicable only
to the disc represented by the symbol.

DVD-V

DVD Video discs

DVD-A

DVD Audio discs

VCD 2.0

Video CDs with the PBC (playback control) function

VCD 1.0

Video CDs without the PBC (playback control) function

CD

Audio CDs

MP3

MP3 disc

WMA

WMA disc

JPEG

JPEG disc

ENGLISH

FRANÇAISDEUTSCHNEDERLANDSESPAÑOL

NOTES ON DISCS
HANDLING DISCS

Do not touch the playback side of the disc. Hold the disc by the edges
so that fingerprints will not get on the surface. Do not stick paper or
tape on the disc.

STORING DISCS

After playing, store the disc in its case.
Do not expose the disc to direct sunlight or sources of heat, or leave it
in a parked car exposed to direct sunlight, as there may be a
considerable temperature increase inside the car.

CLEANING DISCS

Fingerprints and dust on the disc can cause poor picture quality and
sound distortion. Before playing, clean the disc with a clean cloth. Wipe
the disc from the center out.
Do not use strong solvents such as alcohol, benzine, thinner,
commercially available cleaners, or anti-static spray intended for older
vinyl records.

ITALIANO

PORTUGUÊS

SVENSKA

5

ENGLISH FRANÇAIS

DEUTSCH

Introduction

REAR PANEL

COAXIAL (Digital audio out jack)

Connect to digital (coaxial) audio equipment.

AUDIO OUT (Left/Right)

Connect to an amplifier, receiver, or stereo system.

VIDEO OUT

Connect to a TV with video inputs.

12V TRIGGER IN

By connecting this DVD player to another NAD audio component or system controller equipped with a 12V
trigger output, you can remotely operate the T533 power ON/OFF.

NEDERLANDS

ESPAÑOL

ITALIANO

PORTUGUÊS

COMPONENT/PROGRESSIVE SCAN VIDEO OUT (Y Pb Pr)

Connect to a TV with Y Pb Pr inputs.

S-VIDEO OUT

Connect to a TV with S-Video inputs.

OPTICAL (Digital audio out jack)

Connect to digital (optical) audio equipment.

5.1 CHANNEL AUDIO OUT

Connect to a 5.1 channel receiver

- center channel connection

- subwoofer connection

- front channel connections

- rear (surround) channel connections

AC Power Cord

Plug into the power source.

SVENSKA

DO NOT TOUCH THE INNER PINS OF THE CONNECTORS ON THE REAR PANEL.
ELECTROSTATIC DISCHARGE MAY CAUSE PERMANENT DAMAGE TO THE UNIT.

6

Introduction

ADVD

DVD

FRONT PANEL AND DISPLAY WINDOW

Shows the current status of

Power button

Switches the player on and to
standby.

Power Indicator

Lights green when the DVD player is turned
on. Lights amber when the DVD player is in
standby.

Moves to previous or next chapter/track.

Pause playback temporarily or press repeatedly for frame-by-frame playback.

the player

Disc Tray

Starts Playback of media.

AUDIO/VIDEO

Point the DVD player’s remote

Remote Sensor

control here.

Opens or closes the disc tray.

Press for fast reverse or forward search.

OPEN/CLOSE

Insert playable media here.

Display window

Accesses menu on a DVD disc.

SKIP

PAUSE

PLAY

STOP

Stops playback.

SCAN

MENU

ENGLISH

FRANÇAISDEUTSCHNEDERLANDSESPAÑOL

DVD video disc inserted

DVD audio disc inserted

CD Audio CD inserted

VCD Video CD inserted

MP3 MP3 or WMA disc inserted

Indicates current player function:
Playback, Pause, etc.

Angle active

Selects an item in the OSD menu and Acknowledges menu selection

TITLE Indicates current title number

CHP/TRK Indicates current chapter or track number

Indicates total play time or elapsed time

PROG. Programmed playback active

ADVD

TITLEMP3 VCD CD

CHP/TRK

PROG.

Left / right / up / down / SELECT

Random playback active

Indicates repeat mode

RANDOM ALL

AB

ITALIANO

PORTUGUÊS

SVENSKA

7

Introduction

REMOTE CONTROL

ENGLISH FRANÇAIS

DEUTSCH

NEDERLANDS

Switches DVD Player ON

Selects an audio language (DVD) or

an audio channel (CD)

Selects a subtitle language

Selects a DVD camera angle if available

Repeat chapter, track, title, and all

Repeat sequence

Plays tracks in random order

Marks any point during playback

Displays MARKER SEARCH menu

Reverse / Forward slow playback

Accesses or removes setup menu

Displays the discs Title menu, if available

Selects items in the on screen display menus

Acknowledges menu selection

Accesses On-Screen Display (OSD)

ON

AUDIO

SUBTITLE

ANGLE

REPEAT

RPT A-B

RANDOM

MARKER

SEARCH

SLOW

SETUP

TITLE

CURSOR

ENTER

DISP

ON OFF

AUDIO

SUBTITLE

REPEAT

RPT A-B

PROGRAM

CLEAR

SEARCH

MARKER

2

1

5

4

7

8

0

SLOW

SETUP

TITLE

ENTER

DISP

STOP

OPEN/CLOSE

PLAY

SKIP

ANGLE

RANDOM

ZOOM

NEXT DISC

3

6

9

SCAN

MENU

RTN

PAUSE/STEP

SKIP

OFF

Switches DVD Player to standby

PROGRAM

Enters to the program edit mode or exits from that

CLEAR

Removes a track number on the program list or a mark on
the MARKER SEARCH menu

ZOOM

Enlarges video image

0-9 number buttons
Selects numbered items in a menu

SCAN

Press for fast reverse search or forward search

MENU

Accesses menu on a DVD disc

RTN

Removes the setup menu
Displays the menu of a video CD with PBC

OPEN/CLOSE

Opens and closes the disc tray

STOP

Stops playback

PAUSE/STEP

Pauses playback temporarily/ press repeatedly for frame-by­frame playback

Reverse SKIP

Go to beginning of current chapter or track or go to previous
chapter or track

PLAY

Starts playback

Forward SKIP

Go to next chapter or track

ESPAÑOL

ITALIANO

PORTUGUÊS

SVENSKA

PRESS IN AND LIFT TAB TO REMOVE
BATTERY COVER OUT OF RECESS

DVD 5

PLACE BATTERIES INTO OPENING. ENSURE
THE CORRECT FITTING IS OBSERVED

REPLACE BATTERY COVER BY ALIGNING AND
INSERTING THE TWO TABS INTO THE HOLES.

PRESS BATTERY COVER INTO PLACE UNTIL IT
'CLICKS' CLOSED

REMOTE CONTROL OPERATION RANGE

Point the remote control at the remote sensor and press the buttons.

Distance: About 23 ft (7 m) from the front of the remote sensor.
Angle: About 30° in each direction of the front of the remote sensor.

8

CAUTION

Do not mix old and new batteries. Never mix different types of batteries
(standard, alkaline, etc.).

Introduction

CONNECTIONS

• Depending on your TV and other equipment you wish to connect,
there are various ways you could connect the player. Use only one of
the connections described below.

•Please refer to the manuals of your TV, VCR, Stereo System or other
devices as necessary to make the best connections.

• For better sound reproduction, connect the player’s AUDIO OUT
connectors to the audio in connectors of your amplifier, receiver,
stereo or audio/video equipment. See “Connecting to Optional
Equipment” on page 10.

CAUTION

• Make sure the DVD Player is connected directly to the TV. Tune the
TV to the correct video input channel.

• Do not connect the DVD Player’s AUDIO OUT jack to the phono in
jack (record deck) of your audio system.

• Do not connect your DVD Player via your VCR. The DVD image could
be distorted by the copy protection system.

CONNECTING TO A TV

• Make one of the following connections, depending on the
capabilities of your existing equipment.

VIDEO CONNECTION

1 Connect the VIDEO OUT jack on the DVD Player to the video in jack

on the TV using the video cable (V).

2 Connect the Left and Right AUDIO OUT connectors of the DVD

Player to the audio left/right in connectors on the TV using the audio
cables (A).

PROGRESSIVE SCAN CONNECTION

• If your television is a high-definition or “digital ready” television, you
may take advantage of the DVD Player’s progressive scan output for
the highest video resolution possible.

• If your TV does not accept the Progressive Scan format, the picture
will appear scrambled if you try Progressive Scan on the DVD Player.

1 Connect the COMPONENT VIDEO OUT/ PROGRESSIVE SCAN

connectors on the DVD Player to the corresponding in connectors on
the TV using an optional Y Pb Pr cable (C).

2 Connect the Left and Right AUDIO OUT connectors of the DVD Player

to the audio left/right in connectors on the TV using the supplied
audio cables (A).

NOTES

• Set the Progressive to “On” on the setup menu for progressive
signal, see page 13.

•Progressive scan does not work with the analog video connections
(yellow VIDEO OUT jack).

Rear of TV

ENGLISH

FRANÇAISDEUTSCHNEDERLANDSESPAÑOL

S-VIDEO CONNECTION

1 Connect the S-VIDEO OUT jack on the DVD Player to the S-Video in

jack on the TV using the S-Video cable (S).

2 Connect the Left and Right AUDIO OUT connectors of the DVD

Player to the audio left/right in connectors on the TV using the audio
cables (A).

COMPONENT VIDEO (COLOR STREAM®) CONNECTION

1 Connect the COMPONENT VIDEO OUT/ PROGRESSIVE SCAN

connectors on the DVD Player to the corresponding in connectors on
the TV using an Y / Pb / Pr cable (C).

2 Connect the Left and Right AUDIO OUT connectors of the DVD

Player to the audio left/right in connectors on the TV using the audio
cables (A).

ITALIANO

Rear of DVD player

PORTUGUÊS

SVENSKA

9

Preparation

CONNECTIONS

ENGLISH FRANÇAIS

DEUTSCH

NEDERLANDS

CONNECTING TO OPTIONAL EQUIPMENT

Connecting to an amplifier equipped with two channel analog
stereo or Dolby Pro Logic ll / Pro Logic

Connect the Left and Right AUDIO OUT connectors on the DVD Player
to the audio left and right in connectors on your amplifier, receiver, or
stereo system, using the audio cables (A).

Connecting to an amplifier equipped with two channel digital
stereo (PCM) or to an Audio / Video receiver equipped with a
multi-channel decoder (Dolby Digital™, MPEG 2, or DTS)
1 Connect one of the DVD Player’s DIGITAL AUDIO OUT connectors

(OPTICAL (O) or COAXIAL (X)) to the corresponding in jack on your
amplifier. Use an optional digital (optical (O) or coaxial (X)) audio
cable.

2 You will need to activate the player’s digital output. (See “Digital

Audio Output” on page 14).

DIGITAL MULTI-CHANNEL SOUND

A digital multi-channel connection provides the best sound quality. For
this you need a multi-channel Audio/Video receiver that supports one or
more of the audio formats supported by your DVD Player (MPEG 2,
Dolby Digital and DTS). Check the receiver manual and the logos on the
front of the receiver.

CAUTION

Due to the DTS Licensing agreement, the digital output will be in DTS
digital out when DTS audio stream is selected.

Analog connection to a multi-channel A/V receiver with 6
Channel connectors (Dolby Digital)

This DVD Player contains a multi-channel decoder. This enables playback
of DVDs recorded in Multi-channel Surround without the need for an
optional decoder.

1 Connect the CENTER and WOOFER connectors for the Center

speaker and the Subwoofer (C) to the corresponding in connectors
on your receiver.

2 Connect the Left and Right FRONT speaker connectors (F) to the

corresponding in connectors on your receiver.

3 Connect the Left and Right REAR speaker connectors (R) to the

corresponding in connectors on your receiver.

4 Make the appropriate Sound settings for Analog Output and

Speaker Settings in the setup menu. See page 14.

Rear of DVD player

ESPAÑOL

ITALIANO

PORTUGUÊS

SVENSKA

Rear of DVD player

Amplifier (Receiver)

Amplifier (Receiver)

NOTES

• If the audio format of the digital output does not match the
capabilities of your receiver, the receiver will produce a strong,
distorted sound or no sound at all.

• Six Channel Digital Surround Sound via digital connection can only
be obtained if your receiver is equipped with a Digital Multi-channel
decoder.

•To see the audio format of the current DVD in the onscreen display,
press AUDIO.

10

OFF

A B

ALL

TRACK

GROUP

CHAPT

TITLE

Preparation

OFF

ABC

1 /1

NORM.

BEFORE OPERATION

GENERAL EXPLANATION

This manual gives basic instructions for operating the DVD Player. Some
DVDs require specific operation or allow only limited operation during
playback. When this occurs, the symbol appears on the TV screen,
indicating that the operation is not permitted by the DVD Player or is not
available on the disc.

ON-SCREEN DISPLAY

General playback status can be displayed on the TV screen. Some items
can be changed on the menu.

ON-SCREEN DISPLAY OPERATION

1 Press DISP during playback.
2 Press to select an item. The selected item will be highlighted.
3 Press to change the setting of an item. The number buttons

can be also be used for setting numbers (e.g., title number). For
some functions, press ENTER to execute the setting.

TEMPORARY FEEDBACK FIELD ICONS

Repeat Title

Repeat Chapter

Repeat Group (DVD audio discs only)

Repeat Track
(non-PBC Video CDs and DVD audio discs only)

Repeat All Tracks (non-PBC Video CDs only)

Repeat A-B

Repeat Off

Resume play from this point

Action prohibited or not available

NOTES

• Some discs may not provide all of the features on the on-screen
display example shown below.

• If no button is pressed for 10 seconds, the on-screen display
disappears.

ENGLISH

FRANÇAISDEUTSCHNEDERLANDSESPAÑOL

DVD-V

Items

Title Number

Chapter Number

Time search

Audio language and

1 /3

1 /12

0:20:09

1 ENG

Digital Audio Output
mode

5.1 CH

Subtitle language Shows the current subtitles language, and changes the setting.

Angle

Sound

Function (Press to select desired item)

Shows the current title number and total number of titles, and
skips to the desired title number.

Shows the current chapter number and total number of
chapters, and skips to the desired chapter number.

Shows the elapsed playing time, and searches the point by the
elapsed time directly.

Shows the current audio soundtrack language, encoding

D

method, and channel number, and changes the setting.

Shows the current angle number and total number of angles,
and changes the angle number.

Shows the current sound mode, and changes the setting.

Selection Method

, or Numbers, ENTER

, or Numbers, ENTER

Numbers, ENTER

, or AUDIO

ITALIANO

, or SUBTITLE

, or ANGLE

PORTUGUÊS

SVENSKA

11

Preparation

BEFORE OPERATION

DVD-A

ENGLISH FRANÇAIS

DEUTSCH

NEDERLANDS

Items

Group Number

Track Number

Time search Shows the elapsed playing time.(Display only)

DVD Audio Output
mode

Subtitle language Shows the current subtitles language, and changes the setting.

Page (or Angle)

ABC

2 /6

1 /12

0:10:15

1

PPCM

5 CH

OFF

1 /12

or

Function (Press to select desired item)

Shows the current group number and total number of groups,
and skips to the desired group number.

Shows the current track number and total number of tracks,
and skips to the desired track number.

Shows the current encoding method, and channel number,
and changes the setting.

Shows the current angle number and total number of angles,
and changes the angle number.

1 /1

VCD 2.0 VCD 1.1

Selection Method

, or Numbers, ENTER

, or Numbers, ENTER

- - -

, or AUDIO

, or SUBTITLE

, or ANGLE

ESPAÑOL

ITALIANO

PORTUGUÊS

SVENSKA

Items

Track Number

Time Shows the elapsed playing time (Display only)

Audio Channel Shows the audio channel, and changes the audio channel.

1 /3

1 /12

0:20:09

Function (Press to select desired item)

Shows the current track number, total number of tracks and
PBC On mode, and skip to the desired track number.

1 ENG

Sound

Shows the current sound mode, and changes the setting.

D

5.1 CH

Selection Method

, or Numbers, ENTER

- - -

, or AUDIO

12

Preparation

BEFORE OPERATION

INITIAL SETTINGS

You can set your own Personal Preferences on the player.

Initial Settings General Operation
1 Press SETUP. The setup menu appears.

Disc Audio

Disc Subtitle

Disc Menu

Rating

Country Code

TV Aspect

Menu Language

Progressive Scan

Digital Audio Output

5.1 Speaker Setup

Others

Original

English

French

German

Spanish

Italian

Chinese

Polish

Hungarian

Other – – – –

2 Press to select the desired item. The screen will show the

current setting for the selected item, as well as alternate setting(s).

3 While the desired item is selected, press , then to select the

desired setting.

4 Press ENTER to confirm your selection. Some items require additional

steps.

5 Press SETUP, RTN, or PLAY to exit the setup menu.

LANGUAGE
DISC LANGUAGE

DVD-ADVD-V

Select a language for the disc’s Menu, Audio, and Subtitle.

Original: The original language set for the disc is selected.
Other: To select another language, press number buttons to enter the

corresponding 4-digit number according to the language code list on
page 27. If you enter the wrong language code, press CLEAR.

Disc Audio

Disc Subtitle

Disc Menu

Rating

Country Code

TV Aspect

Menu Language

Progressive Scan

Digital Audio Output

5.1 Speaker Setup

Others

Original

English

French

German

Spanish

Italian

Chinese

Polish

Hungarian

Other – – – –

MENU LANGUAGE

Select a language for the setup menu. This is the menu you see when
you press SETUP.

Disc Audio

Disc Subtitle

Disc Menu

Rating

Country Code

TV Aspect

Menu Language

English

Spanish

French

TV ASPECT

DVD-ADVD-V

4:3 Letterbox: Select when a standard 4:3 TV is connected. Displays

theatrical images with masking bars above and below the picture.
4:3 Panscan: Select when a conventional TV set is connected. The video
material formatted in the Pan & Scan style is played back in that style
(Both sides of the picture are cut off).
16:9 Wide: Select when a 16:9 wide TV is connected.

Letterbox

Disc Audio

Disc Subtitle

Disc Menu

Rating

Country Code

TV Aspect
Menu Language

Progressive Scan

Digital Audio Output

5.1 Speaker Setup

Others

PROGRESSIVE SCAN

4:3

Panscan

4:3

Wide

16:9

DVD-ADVD-V

Progressive Scan Video provides the highest quality pictures with less
flickering. If you are using the COMPONENT VIDEO OUT/ PROGRESSIVE
SCAN connectors, but are connecting the DVD Player to a standard
(analog) television, set Progressive Scan to Off. If you are using the
Component Video connectors for connection to a TV or monitor that is
compatible with a progressive scan signal, set Progressive Scan to On.

Disc Audio

Disc Subtitle

Disc Menu

Rating

Country Code

TV Aspect
Menu Language

Progressive Scan

Digital Audio Output

5.1 Speaker Setup

Others

Off

On

CAUTION

Once the setting for progressive scan output is entered, an image will
only be visible on a progressive scan compatible TV or monitor. If you set
Progressive Scan to On in error, you must reset the unit. Press STOP to
stop any disc that is playing. Next, press STOP again and hold it for five
seconds before releasing it. The video output will be restored to the
standard setting, and a picture will once again be visible on a
conventional analog TV or monitor.

ENGLISH

FRANÇAISDEUTSCHNEDERLANDSESPAÑOL

ITALIANO

PORTUGUÊS

13

SVENSKA

Preparation

BEFORE OPERATION

ENGLISH FRANÇAIS

DEUTSCH

NEDERLANDS

ESPAÑOL

ITALIANO

PORTUGUÊS

SOUND
DIGITAL AUDIO OUTPUT

Each DVD disc has a variety of audio output options. Set the player’s
Digital Audio Output according to the type of audio system you use.
DOLBY DIGITAL/PCM: Select “DOLBY DIGITAL/PCM” if you connected
the DVD Player’s DIGITAL OUT jack to a Dolby Digital decoder (or an
amplifier or other equipment with a Dolby Digital decoder).
Stream/PCM: Select “Stream/PCM” if you connected the DVD Player’s
DIGITAL OUT jack to an amplifier or other equipment with a DTS
decoder, Dolby Digital decoder or MPEG decoder.
PCM: Select when connected to a 2-channel digital stereo amplifier. The
DVD player outputs sounds in the PCM 2channel format when you play
a DVD video disc recorded on the Dolby Digital, MPEG1, or MPEG2
recording system.

Disc Audio

Disc Subtitle

Disc Menu

Rating

Country Code

TV Aspect
Menu Language

Progressive Scan

Digital Audio Output

5.1 Speaker Setup

Others

DOLBY

/PCM

DIGITAL

Stream/PCM

PCM

Sample Freq.

48 KHz

96KHz

SAMPLE FREQUENCY

To change the Sample Frequency setting, first select the desired Digital
Audio Output as indicated as above.
If your receiver or amplifier is NOT capable of handling 96 KHz signals,
select 48 KHz. When this choice is made, this unit will automatically
convert any 96 KHz signals to 48 KHz so your system can decode them.
If your receiver or amplifier is capable of handling 96 KHz signals, select
96 KHz. When this choice is made, this unit will pass each type of signal
through without any further processing.

5.1 SPEAKER SETTINGS

DVD-ADVD-V

Select speaker settings, including volume balance and delay time, or test
the speaker settings. Speaker settings are only active on the Analog
Multi- Channel Output.

Disc Audio

Disc Subtitle

Disc Menu

Rating

Country Code

TV Aspect
Menu Language

Progressive Scan

Digital Audio Output

5.1 Speaker Setup

Others

R R

Front L

Volume 0 dB

Size Large

Distance 1 ft

Test

Return

SPEAKER SELECTION

Select a speaker that you want to adjust. (Front speakers (Left), Front
speakers (Right), Center Speaker, Rear speakers (Left), Rear speakers
(Right), or Subwoofer)

NOTE

Certain speaker settings are prohibited by the Dolby Digital licensing
agreement.

VOLUME

Press to adjust the output level of the selected speaker (from 0dB
to -10dB).

SIZE

•Press to set a mode (Large, Small or None).

• If you have connected your system to a speaker with a low
frequency roll-off of below 100 Hz, select “Large.”

• If you have connected your system to a speaker with a low
frequency roll-off above 100 Hz, select “Small.”

NOTE

If you have not connected a subwoofer, always select “Large” for
Front speaker (L/R).

• When you do not have a speaker connected, select “None.”

•Front L/R speaker’s size may be set to “Large” or “Small.”

• If Front L/R speaker’s size is set to “Small,” Rear and Center
speaker’s size may be set to “Small” or “None.”

• Subwoofer’s size may only be set to “Large” or “None”

DISTANCE

If you connected speakers to your DVD Player, setting the Distance lets
the speakers know how far the sound has to travel to reach your set
listening point. This allows the sound from each speaker to reach the
listener at the same time. (1 ft = 30.48 cm)

TEST

Press ENTER to test the levels of each speaker. Adjust the volume of each
speaker so that the volume levels are the same, relative to your viewing
position. The speakers are selected in turn as follows:
Front Left (L) ➜ Center ➜ Front Right (R) ➜ Rear Right (R)
➜ Rear Left (L) ➜ Subwoofer

RETURN

Press ENTER to return to the previous menu.

SVENSKA

Make the following settings for the built-in 5.1 channel surround
decoder.
1 Select “5.1 Speaker Setup” using the buttons on the setup

menu.

2 While “5.1 Speaker Setup” is selected, press > button.
3 Press buttons to select the desired speaker.
4 Adjust options by using buttons.

14

Preparation

BEFORE OPERATION

OTHERS

The DRC, PBC and Auto Play settings can be changed.

•Press to select the desired item and press ENTER. The setting
of the selected item is changed between On and Off.

Disc Audio

Disc Subtitle

Disc Menu

Rating

Country Code

TV Aspect
Menu Language

Progressive Scan

Digital Audio Output

5.1 Speaker Setup

Others

DRC

PBC

Auto Play

On

On

Off

DYNAMIC RANGE COMPRESSION (DRC)

With the DVD format, you can hear a program’s soundtrack in the most
accurate and realistic presentation possible, thanks to digital audio
technology. However, you may wish to compress the dynamic range of
the audio output (the difference between the loudest sounds and the
quietest ones). Then, you may listen to a movie at a lower volume
without losing clarity of sound. Set DRC to On for this effect.

PBC

Set Playback Control (PBC) to On or Off.

On: Video CDs with PBC are played according to the PBC.
Off: Video CDs with PBC are played the same way as Audio CDs.

AUTO PLAY

DVD-V

You can set up the DVD Player so a DVD disc automatically starts playing
whenever the DVD is inserted. If Auto Play mode is set to On, the T 533
DVD player will search for the longest title playback time and then play
back the title automatically.

On: Auto Play function is activated.
Off: Auto Play function is not activated.

NOTE

The Auto Play function may not work for some DVDs.

PARENTAL CONTROL
RATING

DVD-V

Movies on DVDs may contain scenes not suitable for children. Therefore,
discs may contain Parental Control information that applies to the
complete disc or to certain scenes on the disc. These scenes are rated
from 1 to 8, and alternatively, more suitable scenes are available for
selection on some discs. Ratings are country-dependent. The Parental
Control feature allows you to prevent discs from being played by your
children or to have certain discs played with alternative scenes.

Disc Audio

Disc Subtitle

Disc Menu

Rating

Country Code

TV Aspect
Menu Language

Progressive Scan

Digital Audio Output

5.1 Speaker Setup

Others

8

7

6

5

4

3

2

1

Unlock

Change

1 Select “Rating” on the Setup menu using the buttons.
2 While “Rating” is selected, press .
3 When you have not yet entered a password;

Enter a 4-digit password using the numbered buttons to create a
personal 4-digit security password, and then press ENTER. Enter the
4-digit password again and press ENTER to verify.

When you have already entered a password;

Enter a 4-digit password using the numbered buttons to confirm the
personal 4-digit security password, and then press ENTER. If you
make a mistake before pressing ENTER, press CLEAR and enter 4­digit security password again.

4 Select a rating from 1 to 8 using the buttons. Eight (8)

has the least playback restrictions. One (1) has the most
playback restrictions.
Unlock: If you select Unlock, Parental Control is not active. The disc

will play in full.
Ratings 1 to 8. Some discs contain scenes not suitable for children.
If you set a rating for the player, all disc scenes with the same rating
or lower will be played. Higher rated scenes will not be played unless
an alternative scene is available on the disc.
The alternative must have the same rating or a lower one. If no
suitable alternative is found, playback will stop. You must enter the
4-digit password or change the rating level in order to play the disc.

5Press ENTER to confirm your rating selection, and then press

SETUP to exit the menu.

ENGLISH

FRANÇAISDEUTSCHNEDERLANDSESPAÑOL

ITALIANO

15

PORTUGUÊS

SVENSKA

Preparation

BEFORE OPERATION

ENGLISH FRANÇAIS

DEUTSCH

NEDERLANDS

COUNTRY CODE

DVD-V

Enter the code of a country/area whose standards were used to rate the
DVD video disc, referring to the list (See “Country Code List”, page 28.)

Disc Audio

Disc Subtitle

Disc Menu

Rating

Country Code

TV Aspect

Menu Language

Progressive Scan

Digital Audio Output

5.1 Speaker Setup

Others

Code Set

U S

1 Select Country Code using the buttons on the setup menu.
2 While Country Code is selected, press .
3 Follow step number “3” of “Rating” on left side of this page.
4 Select the first character using the buttons.
5 Shift the cursor using button and select the second character

using buttons.

6 Press ENTER to confirm your country code selection, then press

SETUP to exit the menu.

NOTE

Confirmation of the 4-digit password is necessary when the code is
changed (see “Changing the 4-digit code” below).

CHANGING THE 4-DIGIT CODE

1 Follow Steps 1-2 as shown above to the left (Rating).
2 Enter the old code, and then press ENTER.
3 Select Change using buttons then press ENTER.
4 Enter the new 4-digit code, and then press ENTER.
5 Enter exactly the same code a second time and verify by pressing

ENTER.

6 Press SETUP to exit the menu.

IF YOU FORGET YOUR 4-DIGIT CODE

If you forget your password, to clear the current password, follow the
procedure below:

1 Press SETUP to display the setup menu.
2 Use the Number buttons to enter the 6-digit number “210499”. The

4-digit password is cleared. “P CLr” appears on the T 533’s front
display for a moment.

3 Enter a new code as shown under “Rating”

ESPAÑOL

ITALIANO

PORTUGUÊS

SVENSKA

16

Operation

OPERATION WITH DVD AND VIDEO CD

PLAYING A DVD AND VIDEO CD
PLAYBACK SETUP

VCD 1.1VCD 2.0DVD-ADVD-V

•Turn on the TV and select the video input source connected to the
DVD player.

• Audio system: Turn on the audio system and select the input source
connected to the DVD player.

1Press OPEN/CLOSE to open the disc tray.
2 Load your chosen disc in the tray, with the playback side down.
3Press OPEN/CLOSE to close the tray. READING appears on the TV

screen, and playback starts automatically. If playback does not start,
press PLAY. In some cases, the disc menu might appear instead.

IF A MENU SCREEN IS DISPLAYED

The menu screen may be displayed first after loading a DVD or Video
CD which offer a menu.

DVD-V

Use the buttons to select the title/chapter you want to view,
then press ENTER to start playback. Press TITLE or MENU to return to the
menu screen.

DVD-A

Use the buttons to select an option you want, then press
ENTER to view the option.

VCD 2.0

• Use the number buttons to select the track you want to view. Press
RTN to return to the menu screen.

• Menu setting and the exact operating procedures for using the
menu may differ depending on the disc. Follow the instructions on
the each menu screen. You also may set PBC to Off under setup. See
page 15.

NOTES

• If Parental Control is set and the disc is not within the Rating settings
(not authorized), the 4-digit code must be entered and/or the disc
must be authorized (see “Parental Control).

• DVDs may have a region code. Your player will not play discs that
have a region code different from your player. The region code for
this player is 1 (one).

MOVING TO ANOTHER CHAPTER / TRACK

VCD 1.1DVD-ADVD-V

When a title on a disc has more than one chapter or a disc has more
than one track, you can move to another chapter/track as follows:

•Press SKIP or briefly during playback to select the next
chapter/track or to return to the beginning of the current
chapter/track.

•Press twice briefly to step back to the previous chapter/track.

•To go directly to any chapter during DVD playback, press DISP. Then,
press to select the chapter/track icon. Then, enter the
chapter/track number using the numbered buttons (0-9).

1 /12

1 /3

1 /12

NOTE

For two-digit numbers, press the numbered buttons (0-9) in rapid
succession.

SEARCH

VCD 1.1VCD 2.0DVD-ADVD-V

1 Press and hold SCAN or for about two seconds during

playback. The player will now go into SEARCH mode.

2 Press and hold SCAN or repeatedly to select the required

speed: X2, X4, X16, X100 (backward) or

X2, X4, X16, X100 (forward). With a Video CD,

the Search speed changes: X2, X4, X8, (backward) or

X2, X4, X8, (forward).

3 To exit SEARCH mode, press PLAY.

NOTE

When using a DVD audio disc that includes pictures, this operation
may be permitted in some picture segments.

PAUSE

VCD 1.1VCD 2.0DVD-ADVD-V

1 Press PAUSE/STEP during playback.
2 To r eturn to playback, press PLAY.

STILL PICTURE AND FRAME-BY-FRAME PLAYBACK

VCD 1.1VCD 2.0DVD-ADVD-V

1 Press PAUSE/STEP during playback. The player will now go into

PAUSE mode.

2 You can advance the picture frame-by-frame by pressing

PAUSE/STEP repeatedly on the remote control.

ENGLISH

FRANÇAISDEUTSCHNEDERLANDSESPAÑOL

ITALIANO

GENERAL FEATURES

NOTE

Unless stated otherwise, all operations described use the remote
control. Some features may also be available on the Setup menu.

MOVING TO ANOTHER TITLE / GROUP

DVD-ADVD-V

When a disc has more than one title/group, you can move to another
title/group as follows:

•Press DISP, then press the appropriate numbered button (0-9) to
select a title/group number.

1 /3

1/6

NOTE

When using a DVD audio disc that includes pictures, this operation
may be permitted in some picture segments.

PORTUGUÊS

SVENSKA

17

Operation

OPERATION WITH DVD AND VIDEO CD

ENGLISH FRANÇAIS

DEUTSCH

NEDERLANDS

ESPAÑOL

ITALIANO

PORTUGUÊS

SLOW MOTION

VCD 1.1VCD 2.0DVD-ADVD-V

1 Press SLOW or during playback. The player will enter SLOW

mode.

2 Use the SLOW or to select the required speed: 1/16,

1/8, 1/4 or 1/2 (backward), or 1/16, 1/8,

1/4 or 1/2 (forward).

3 To exit slow motion mode, press PLAY.

NOTE

• Slow motion playback in reverse is not applicable for Video CD.

• When using a DVD audio disc that includes pictures, this operation
may be permitted in some picture segments.

RANDOM

VCD 1.1VCD 2.0

1 Press RANDOM during playback or in stop mode. The unit

automatically begins Random Playback and “RANDOM” appears on
the display window.

2 To return to normal playback, press RANDOM until “RANDOM”

disappears on the display window.

TIPS

By pressing SKIP during Random playback, the unit selects
another title (track) and resumes Random playback.

NOTE

• This function only works with video CD without PBC.

• On a Video CD with PBC, you must set PBC to Off in the setup menu
to use the Random function. See page 15.

REPEAT A-B

VCD 1.1VCD 2.0DVD-ADVD-V

To repeat a sequence in a title or group:
1 Press RPT A-B at your chosen starting point. “A *” appears briefly

on the TV screen.

2 Press RPT A-B again at your chosen end point. “A B” appears briefly

on the TV screen, and the repeat sequence begins (“AB” appears
the display window).

3 To cancel the sequence, press RPT A-B.

A *

A B

OFF

REPEAT

VCD 1.1VCD 2.0DVD-ADVD-V

DVD Video Discs - Repeat Chapter/Title/Off
1 To repeat the currently playing chapter, press REPEAT. The Repeat

Chapter icon appears on the TV screen.

2 To repeat the title currently playing, press REPEAT a second time. The

Repeat Title icon appears on the TV screen.

3 To exit Repeat mode, press REPEAT a third time. The Repeat Off icon

appears on the TV screen.

CHAPT

TITLE

GROUP

TRACK

ALL

OFF

DVD Audio Discs - Repeat Track/Group/Off
1 To repeat the currently playing track, press REPEAT. The Repeat Track

icon appears on the TV screen.

2 To r epeat the group currently playing, press REPEAT a second time.

The Repeat Group icon appears on the TV screen.

3 To exit Repeat mode, press REPEAT a third time. The Repeat Off icon

appears on the TV screen.

Video CDs - Repeat Track/All/Off
1 To repeat the track currently playing, press REPEAT. The Repeat Track

icon appears on the TV screen.

2 To repeat the disc currently playing, press REPEAT a second time. The

Repeat All icon appears on the TV screen.

3 To exit Repeat mode, press REPEAT a third time. The Repeat Off icon

appears on the TV screen.

NOTE

On a Video CD with PBC, you must set PBC to Off on the setup
menu to use the Repeat function. See page 15.

TIME SEARCH

DVD-V

The Time Search function allows you to start playing at any chosen time
on the disc.
1 Press DISP during playback. The on-screen display appears on the

screen. The Time Search box shows the elapsed playing time of the
current disc.

2 Within 10 seconds, press to select the Time Search icon in the

on-screen display. The “-:--:--” appears in the Time Search box.

3 Within 10 seconds, use the number buttons to enter the required

start time. Enter hours, minutes, and seconds from left to right in the
box. If you enter the wrong numbers, press CLEAR to remove the
numbers you entered. Then enter the correct numbers.

4 Within 10 seconds, press ENTER to confirm the start time. Playback

starts from the selected time on the disc. If you enter an invalid time,
playback will continue from the current point.

0:20:09

-:--:--

SVENSKA

18

Operation

OPERATION WITH DVD AND VIDEO CD

3D SURROUND

VCD 1.1VCD 2.0DVD-V

This unit can produce a 3D Surround effect, which simulates multi­channel audio playback from two conventional stereo speakers, instead
of the five or more speakers normally required to listen to multichannel
audio from a home theater system.

1 Press DISP during playback.
2 Use to select the sound option. The sound option will be

highlighted.

3 Use to select “3D SUR”. To turn off the 3D Surround effect,

select “NORM”.

NORM.

ZOOM

3D SUR

VCD 1.1VCD 2.0DVD-V

The Zoom function allows you to enlarge the video image and to move
through the enlarged image.
1 Press ZOOM during playback or still playback to activate the Zoom

function. If you press ZOOM repeatedly, the magnification level
increases up to six steps.

2 Use the buttons to move through the zoomed picture.
3 Press CLEAR to resume normal playback or return to the paused

image.

NOTE

The zoom function may not work for some DVDs.

MARKER SEARCH

VCD 1.1VCD 2.0DVD-V

You can start playback from a memorized point. Up to nine points can
be memorized. To enter a mark, follow these steps.
1 During disc playback, press MARKER when playback reaches the

spot that you want to memorize. The Marker icon will appear on the
TV screen briefly.

2 Repeat step 1 to enter up to nine Marker points on a disc.

1/9

MARKER SEARCH

SPECIAL DVD FEATURES
MENUS

DVD-ADVD-V

DVDs may offer menus that allow you to access special features. To use
the disc menu, press MENU. Then, press the appropriate number button
to select an option. Or, use the buttons to highlight your
selection, then press ENTER.

TITLE MENU

DVD-ADVD-V

1 Press TITLE. If the current title has a menu, the menu will appear on

the screen. Otherwise, the disc menu may appear.

2 The menu can list camera angles, spoken language and subtitle

options, and chapters for the title.

3 To r emove the title menu, press TITLE again.

DISC MENU

DVD-ADVD-V

1 Press MENU. The disc menu is displayed.
2 To r emove the disc menu, press MENU again.

CAMERA ANGLE

DVD-ADVD-V

If the disc contains scenes recorded at different camera angles, you can
change to a different camera angle during playback.

•Press ANGLE repeatedly during playback to select a desired angle.
The number of the current angle appears on the display.

1 /1

CHANGING THE AUDIO LANGUAGE

DVD-ADVD-V

Press AUDIO repeatedly during playback to hear a different audio
language or audio track.

1 ENG

5.1 CH

CHANGING THE AUDIO CHANNEL

1
PPCM

D

5 CH

VCD 1.1VCD 2.0

Press AUDIO repeatedly during playback to hear a different audio
channel (STER., LEFT or RIGHT).

ENGLISH

FRANÇAISDEUTSCHNEDERLANDSESPAÑOL

To Recall a Marked Scene
1 During disc playback, press SEARCH. The MARKER SEARCH menu

will appear on the screen.

2 Within 10 seconds, press to select a Marker number that you

want to recall.

3 Press ENTER. Playback will start from the marked scene.
4 To r emove the MARKER SEARCH menu, press SEARCH.

To clear a Marked Scene
1 During disc playback, press SEARCH. The MARKER SEARCH menu

will appear on the screen.

2 Press to select the Marker number that you want to erase.
3 Press CLEAR. The Marker number will be erased from the list.
4 Repeat steps 2 and 3 to erase additional Marker numbers.
5 To r emove the MARKER SEARCH menu, press SEARCH.

SUBTITLES

DVD-ADVD-V

Press SUBTITLE repeatedly during playback to see the different subtitle
languages.

ABC

1 ENG

NOTE

If “ ” appears, the feature is not available on the disc.

ITALIANO

PORTUGUÊS

SVENSKA

19

Operation

OPERATION WITH DVD AND VIDEO CD

ENGLISH FRANÇAIS

DEUTSCH

NEDERLANDS

ESPAÑOL

DVD AUDIO DISCS

DVD-A

DVD Audio is a new disc format building on the success of DVD to
provide high quality, uncompressed, multichannel audio for a new
experience in audio quality. A DVD Audio disc can be identified by the
DVD audio logo on the disc jacket or on the disc itself. DVD Audio can
provide higher quality stereo than Audio CDs with a sampling rate of up
to 192 kHz (compared to 44.1 kHz for CDs). DVD Audio digital sound
can be delivered with up to 24 bits of data (compared to 16 bits for a
standard CD). A typical DVD Audio disc contains up to seven times the
data capacity of a CD. This additional space is used for music, either
Advanced Resolution multi-channel sound quality that is closer to the
artist’s master recording or for longer recordings. Many DVD Audio discs
contain on-screen text, such as artist biographies, play lists, or lyrics.
Some DVD Audio discs contain photo galleries or video clips.

NOTE

To enjoy maximum sound quality and surround effect of DVD Audio,
you must use 5.1 channel analog audio outputs (5.1CH AUDIO OUT
connectors on the DVD Player). If you use the DIGITAL OUT (OPTICAL
or COAXIAL) for your audio connection, the sound will only be
similar to CD-quality sound even though you’re playing a DVD Audio
disc.

MOVING TO ANOTHER GROUP

DVD-A

Some DVD Audio discs divide content into different groups. Your player
enables you to quickly access different groups during playback via the
on-screen display.

1 Press DISP during playback in stop mode.
2 Press to select Group icon.
3 Press or the numbered buttons (0-9) to select a group number.

1/6

VIEWING ANOTHER PAGE

DVD-A

Since DVD Audio discs can hold a lot of content, there are various ways
to see what’s available on the disc.

1 Press DISP during playback.
2 Press to select Page icon.
3 Press to select a page number. What appears on the screen will

vary from disc to disc because the information available depends
upon the way the disc was created.

1 /12

NOTE

Since the authoring of DVD Audio Discs varies, some of the on­screen display choices might not be available for the disc you’re
playing.

ITALIANO

PORTUGUÊS

SVENSKA

NOTE

Sometimes the author of the disc creates hidden content that can
only be accessed by entering a password. If the lock icon appears on
the TV screen, enter the password (sometimes you’ll find it on the
disc’s jacket cover or on a web site). This password control isn’t
dictated by your DVD Player - it is a function of the disc. Since the
authoring of DVD Audio Discs varies, some of the on-screen display
choices might not be available for the disc you’re playing.

20

Operation

JPEG

MP3 WMA

Folder1

Folder2

Folder3

Folder4

Folder5

Folder6

Folder7

Folder8

MP3 WMA

OFF00:00

Program

Clear All

Program

CD

STER. NORM.

0: 56: 18

TRACK01

TRACK02

TRACK03

TRACK04

TRACK05

TRACK06

TRACK07

TRACK08

Clear All

TRACK 1.mp3

TRACK 2.mp3
TRACK 3.mp3
TRACK 4.mp3
TRACK 5.mp3
TRACK 6.mp3
TRACK 7.mp3
TRACK 8.mp3

Program

MP3 WMA

OFF00:00

1

Clear All

OPERATION WITH AUDIO CD AND MP3 / WMA DISC

PLAYING AN AUDIO CD AND MP3 / WMA DISC

WMAMP3CD

The DVD Player can play MP3/WMA formatted recordings on CD-ROM,
CD-R or CD-RW discs. Before playing MP3/WMA recordings, read the
notes on MP3/WMA Recordings on right.

1 Insert a disc and close the tray.

Audio CD; Audio CD menu appears on the TV screen go to step 4.
MP3 / WMA disc; The MP3/WMA-JPEG choice menu appears on

the TV screen. Go to step 2

2Press to select the MP3/WMA then press ENTER.

The MP3/WMA menu appears on the TV screen. Press RTN to move
to the MP3/WMA-JPEG choice menu.

3Press to select a folder, and ENTER.

A list of files in the folder appears.

4Press to select a track then press PLAY or ENTER.

Playback starts. During playback, the current track’s elapsed playing
time will appear on the display window and menu. Playback will
stop at the end of the disc.
Press TITLE to move to the next page.
Press MENU to move to the previous page.

NOTES ON MP3/WMA RECORDINGS
ABOUT MP3

• An MP3 file is audio data compressed by using the MPEG1 audio
layer-3 file-coding scheme. We call files that have the “.mp3” file
extension “MP3 files”.

• The player can not read an MP3 file that has a file extension other
than “.mp3”.

ABOUT WMA (WINDOW MEDIA AUDIO)

• An WMA file is a Microsoft audio compression technology.

• WMA (Windows Media Audio) offers double the audio compression
of the MP3 format.

MP3 / WMA Disc compatibility with this player is limited as
follows:
1 Sampling Frequency / only at 44.1 kHz (MP3), 22.05 - 44.1 kHz

(WMA)

2 Bit rate / within 32 - 320 kbps (MP3), 32 - 196 kbps (WMA)
3 CD-R physical format should be “ISO 9660”
4 If you record MP3/WMA files using the software which cannot

create a FILE SYSTEM, for example “Direct-CD” etc., it is impossible
to playback MP3/WMA files. We recommend that you use “Easy­CD Creator”, which creates an ISO9660 file system.

5 A single session disc requires MP3/WMA files in the first track. If

there is no MP3/WMA file in the 1st track, it cannot playback
MP3/WMA files. If you wish to playback MP3/WMA files, format all
the data in the disc or use a new one.

6 File names should be named using 8 letters or less and must

incorporate “.mp3” or “.wma” extension e.g. “********.MP3” or
“********.WMA”.

7 Do not use special letters such as / : \ * ? “ < >” etc.
8 Total number of files on the disc should be less than 650. This DVD

player requires discs/recordings to meet certain technical standards
in order to achieve optimal playback quality. Pre-recorded DVDs are
automatically set to these standards. There are many different types
of recordable disc formats (including CD-R containing MP3 or WMA
files) that require certain pre-existing conditions (see above) to insure
compatible playback.

ENGLISH

FRANÇAISDEUTSCHNEDERLANDSESPAÑOL

Audio CD menu MP3/WMA menu

TIP

If you are in a file list and want to return to the Folder list, use the

to highlight and press ENTER to return to the previous

menu screen.

5To stop playback at any other time, press STOP.

Customers should also note that permission is required in order
to download MP3/WMA files and music from the Internet. NAD
Electronics International has no right to grant such permission.
Permission should always be sought from the copyright owner.

PAUSE CD

WMAMP3

1 Press PAUSE/STEP during playback.
2 To r eturn to playback, press PLAY or press PAUSE/STEP again.

MOVING TO ANOTHER TRACK

WMAMP3CD

•Press SKIP or briefly during playback to go to the next track
or to return to the beginning of the current track.

•Press SKIP twice briefly to step back to the previous track.

• In case of audio CD, to go directly to any track, enter the track
number using the numbered buttons (0-9) during playback.

REPEAT TRACK / ALL / OFF

WMAMP3CD

1 To repeat the track currently playing, press REPEAT. The Repeat icon
and “TRACK” appears on the menu screen.
2 To repeat all tracks on a disc, press REPEAT a second time.
The Repeat icon and “ALL” appears on the menu screen.
3 To cancel Repeat mode, press REPEAT a third time. The Repeat icon
and “OFF” appears on the menu screen.

21

ITALIANO

PORTUGUÊS

SVENSKA

Operation

OPERATION WITH AUDIO CD AND MP3 / WMA DISC

ENGLISH FRANÇAIS

DEUTSCH

NEDERLANDS

SEARCH

WMAMP3CD

1 Press and hold SCAN or > > during playback. The player will

now go into SEARCH mode.

2 Press and hold SCAN or repeatedly to select the required

speed: X2, X4, X8 (backward) or X2, X4,

X8 (forward). Search speed and direction are indicated on the

menu screen.

3 To exit SEARCH mode, press PLAY.

RANDOM

WMAMP3CD

1 Press RANDOM during playback or when playback is stopped. The

unit automatically begins Random Playback and RANDOM or
“RAND.” appears on the display window and menu screen.

2 To return to normal playback, press RANDOM repeatedly until

RANDOM or “RAND.” disappears on the display window and menu
screen.

REPEAT A-B

CD

To repeat a sequence:
1 During disc playback, press RPT A-B at your chosen starting point.

The Repeat icon and “A *” appears on the menu screen.

2 Press RPT A-B again at your chosen end point. The Repeat icon and

“A B” appears on the menu screen, and the sequence begins to play
repeatedly.

3 To exit the sequence and return to normal play, press RPT A-B again.

The Repeat icon and “OFF” appears on the menu screen.

ESPAÑOL

ITALIANO

PORTUGUÊS

SVENSKA

3D SURROUND

CD

This unit can produce a 3D Surround effect, which simulates multi­channel audio playback from two conventional stereo speakers, instead
of the five or more speakers normally required to listen to multichannel
audio from a home theater system.

1 Press DISP during playback.
2 Use to select the sound option. The sound option will be

highlighted.

3 Use to select “3D SUR”. To turn off the 3D Surround effect,

select “NORM”.

CHANGING THE AUDIO CHANNEL

CD

Press AUDIO repeatedly during playback to hear a different audio
channel (STER., LEFT, or RIGHT).

22

Operation

MP3 WMA

JPEG

Slide Speed

Off

Folder1

Folder2

Folder3

Folder4

Folder5

Folder6

Folder7

Folder8

JPEG

Slide Speed

5/32 1024X768








JPEG

Off

Folder1

5/32 Picture5.jpg1024X768

OPERATION WITH JPEG DISC

VIEWING A JPEG DISC

JPEG

This DVD Player can play discs with JPEG files and Kodak picture CD.
Before playing JPEG recordings, read the notes on JPEG Recordings on
the right.

1 Insert a disc and close the tray.

The MP3/WMA-JPEG choice menu appears on the TV screen.

2Press to select the JPEG then press ENTER.

The JPEG menu appears on the TV screen.

3Press to select a folder, and ENTER.

A list of files in the folder appears. Press RTN to move to the
MP3/WMA-JPEG choice menu.

TIP

If you are in a file list and want to return to the Folder list, use the

buttons on the remote to highlight “ “ and press ENTER

to return to the previous menu screen.

4 If you want to view a particular file, press to highlight a

file and press ENTER or PLAY.

Viewing of the file starts. During viewing a file, press RTN to move
to the previous menu (JPEG menu).
Press TITLE to move to the next page.
Press MENU to move to the previous page.

MOVING TO ANOTHER FILE

Press SKIP or once during viewing a picture to advance to the
next file or to the previous file.

STILL PICTURE

1 Press PAUSE/STEP during slide show. The player will now go into

PAUSE mode.

2 To r eturn to the slide show, press PLAY or press PAUSE/STEP again.

TO FLIP THE PICTURE

Press during showing a picture to flip the picture horizontally or a
vertically.

TO ROTATE PICTURE

Press during showing a picture to rotate the picture clockwise or
counter clockwise.

NOTES ON JPEG RECORDINGS

• Depending upon the size and number of the JPEG files, it could take
a long time for the DVD player to read the disc’s contents. If you
don’t see an onscreen display after several minutes, some of the files
are too big - reduce the resolution of the JPEG files to less than 2
mega pixels and burn another disc.

•Total number of files and folders on the disc should be less than 650.

• Some disc may be incompatible due to different recording format or
condition of disc.

• When you are using software such as “Easy CD Creator” to burn the
jpeg files into the CD-R, ensure that all the selected files have the
“.jpg” extensions when copying into the CD layout.

• If the files have “.jpe” or “.jpeg” extensions, please rename them as
“.jpg” files.

• File names without “.jpg” extension will not be able to be read by
this DVD player. Even though the files are shown as JPEG image files
in windows explorer.

ENGLISH

FRANÇAISDEUTSCHNEDERLANDSESPAÑOL

TIP

There are three viewing Slide Speed options: Fast, Normal, Slow, and
Off. Press to highlight the Slide Speed then press to select
the option you want to use, and press ENTER.

5To stop viewing at any other time, press STOP.

The JPEG menu appears.

ITALIANO

PORTUGUÊS

SVENSKA

23

Operation

STER. NORM.

E

0: 56: 18

TRACK 1

TRACK 2

TRACK 3

TRACK 4

TRACK 12

TRACK 8

TRACK 10

TRACK 3

TRACK 5

TRACK 6

TRACK 7

TRACK 8

Program

CD

Clear All

E

TRACK 1.mp3
TRACK 2.mp3

TRACK 3.mp3

TRACK 4.mp3

TRACK 8.mp3

TRACK 2.mp3

TRACK 4.mp3

TRACK 3.mp3

TRACK 5.mp3
TRACK 6.mp3
TRACK 7.mp3
TRACK 8.mp3

Program

MP3 WMA

OFF00:00

3

Clear All

E

TRACK 1

TRACK 2

TRACK 3

TRACK 4

TRACK 5

TRACK 6

TRACK 7

TRACK 8

Program

VCD

Clear All

ENGLISH FRANÇAIS

DEUTSCH

NEDERLANDS

PROGRAMMED PLAYBACK

VCD

VCD

2.0

CD

1.1

PROGRAMMED PLAYBACK WITH AUDIO CD AND
MP3/WMA DISC

The Program function enables you to store your favorite tracks from any
disc in the player memory.
Program can contain 30 tracks.

1Press PROGRAM during playback or in the stop mode to enter

the Program Edit mode.

The mark will appear to the right of the word Program on the right
side of the menu screen.

NOTE

Press PROGRAM to exit the Program Edit mode; the mark will

E

disappear.

2 Select a track, and then press ENTER to place the selected

track on the Program list.

3 Repeat step 2 to place additional tracks on the Program list.

WMAMP3

PROGRAMMED PLAYBACK WITH VIDEO CD

NOTE

On a Video CD with PBC, you must set PBC to Off on the setup
menu to use the Program function. See page xx

1 Insert Video CD and close the tray.

2Press PROGRAM while playback is stopped.

The VCD Program menu will appear.

NOTE

Press RTN or PROGRAM to exit the Program menu.

3 Follow steps 2-6 of “Programmed Playback with Audio CD

and MP3/WMA disc” on left.

4To resume normal playback from programmed playback,

press PROGRAM.

“PROG.” indicator disappears in the display window.

ESPAÑOL

ITALIANO

PORTUGUÊS

SVENSKA

Audio CD menu MP3/WMA menu

4Press

The programmed track you selected last is highlighted on the
program list.

5Press to select the track you want to start playing.

Press TITLE to move to the next page.
Press MENU to move to the previous page.

6Press PLAY to start.

Playback begins in the order in which you programmed the tracks
and “PROG.” appears on the menu screen.
Playback stops after all of the tracks on the Program list have played
once.

7To resume normal playback from programmed playback,

select a track of CD (or MP3/WMA) list and then press ENTER.

“PROG.” indicator disappears on the menu screen.

REPEAT PROGRAMMED TRACKS

•To repeat the track currently playing, press REPEAT. The Repeat icon
and “TRACK” appears on the menu screen.

•To repeat all tracks on the program list, press REPEAT a second time.
The Repeat icon and “ALL” appears on the menu screen.

•To cancel Repeat mode, press REPEAT a third time. The Repeat icon
and “OFF” appears on the menu screen.

ERASING A TRACK FROM PROGRAM LIST

1 Press PROGRAM during playback (Audio CD and MP3/WMA disc

only) or in the stop mode to enter the Program Edit mode. The

E

mark will appear.

2 Press to move to the Program list.
3 Use to select the track that you wish to erase from the

Program list.

4 Press CLEAR. The track will be erased from the Program list.

ERASING THE COMPLETE PROGRAM LIST

1 Follow steps 1-2 of “Erasing a Track from Program List” as above.
2 Use to select “Clear All”, and then press ENTER. The complete

Program for the disc will be erased. The programs are also cleared
when the disc is removed.

24

LAST CONDITION MEMORY

VCD

DVD-ADVD-V

1.1

2.0

VCD

This player memorizes the user settings for the last disc that you have
viewed. Settings remain in memory even if you remove the disc from the
player or switch off the player. If you load a disc that has its settings
memorized, the latest stop position is automatically recalled.

SCREEN SAVER

The screen saver picture appears when you leave the DVD Player in stop
mode for about five minutes. After the Screen Saver has been engaged
for about five minutes, the DVD Player will automatically turn itself off.

VCD

VIDEO MODE SETTING

VCD

DVD-ADVD-V

1.1

2.0

•With certain discs, the playback picture may be flickering or Dot
Crawl is shown on straight lines. That means Vertical interpolation or
De-interlace is not perfectly matched with the disc. In this case, the
picture quality may be improved by changing the video mode.

•To change the video mode, press and hold DISP about 3 seconds
during disc playback. The new video mode number selected is
displayed on the TV screen. Check whether the video quality has
improved. If not, repeat the above procedure until picture quality is
improved.

•Video mode change sequence: MODE1 ➜ MODE2 ➜ MODE3 ➜
MODE1

• If you turn off the power, the video mode will be back to initial state
(MODE1).

Operation

ADDITIONAL INFORMATION

ENGLISH

FRANÇAISDEUTSCHNEDERLANDSESPAÑOL

DETAILED DESCRIPTIONS FOR VIDEO MODES

MODE1: The source material of the DVD video (film material or video
material) is determined from disc information.
MODE2: Suitable for playing film based content or video based material
recorded by the progressive scan method.
MODE3: Suitable for playing video based content with comparatively
little motion.

NOTE

The video mode setting only works when the Progressive Scan mode
is set to “On” in the Setup menu.

ITALIANO

PORTUGUÊS

25

SVENSKA

Reference

TROUBLESHOOTING

Check the following guide for the possible cause of a problem before contacting service.

ENGLISH FRANÇAIS

DEUTSCH

NEDERLANDS

ESPAÑOL

SYMPTOM

No power.

The power is on, but the DVD player does not
work.

No picture.

No sound.

The playback picture is poor.

CAUSE

• The power cord is disconnected.

• No disc is inserted.

• The TV is not set to receive DVD signal output.

• The video cable is not connected securely.

• The connected TV power is turned off.

• The equipment connected with the audio cable
is not set to receive DVD signal output.

• The audio cables are not connected securely.

• The power of the equipment connected with the
audio cable is turned off.

• The Digital Audio Output is set to the wrong
position.

• The disc is dirty.

CORRECTION

• Plug the power cord into the wall outlet securely.

• Insert a disc. (Check that the DVD or, audio CD
indicator in the display window is lit.)

• Select the appropriate video input mode on the
TV so the picture from the DVD player appears
on the TV screen.

• Connect the video cable securely.

•Turn on the TV.

• Select the correct input mode of the audio
receiver so you can listen to the sound from the
DVD player.

• Connect the audio cable securely.

•Turn on the equipment connected with the
audio cable.

• Set the Digital Audio Output to the correct
position, then turn on the DVD player again by
pressing ON.

• Clean the disc.

ITALIANO

PORTUGUÊS

SVENSKA

The DVD player does not start playback.

The remote control does not work properly.

• No disc is inserted.

• An unplayable disc is inserted.

• The disc is placed upside down.

• The disc is not placed within the guide.

• The disc is dirty.

• The Rating level is set.

• The remote control is not pointed at the remote
sensor of the DVD player.

• The remote control is too far from the DVD
player.

• There is an obstacle in the path of the remote
control and the DVD player.

• The batteries in the remote control are
exhausted.

• Insert a disc. (Check that the DVD or audio CD
indicator in the DVD display is lit.)

• Insert a playable disc. (Check the disc type, color
system, and Regional code.)

• Place the disc with the playback side down.

• Place the disc on the disc tray correctly inside the
guide.

• Clean the disc.

• Cancel the Rating function or change the rating
level.

• Point the remote control at the remote sensor of
the DVD player.

• Operate the remote control within 23 ft (7 m).

• Remove the obstacle.

• Replace the batteries with new ones.

26

TABLE OF LANGUAGES AND THEIR ABBREVIATIONS

Language Code List
Enter the appropriate code number for the initial settings “Disc Audio”, “Disc Subtitle” and/or “Disc Menu”

Code Language Code Language Code Language Code Language

6566 Abkhazian 7074 Fiji 7678 Lingala 8373 Singhalese
6565 Afar 7073 Finnish 7684 Lithuanian 8375 Slovak
6570 Afrikaans 7082 French 7775 Macedonian 8376 Slovenian
8381 Albanian 7089 Frisian 7771 Malagasy 8379 Somali
6577 Ameharic 7176 Galician 7783 Malay 6983 Spanish
6582 Arabic 7565 Georgian 7776 Malayalam 8385 Sudanese
7289 Armenian 6869 German 7784 Maltese 8387 Swahili
6583 Assamese 6976 Greek 7773 Maori 8386 Swedish
6588 Aymara 7576 Greenlandic 7782 Marathi 8476 Tagalog
6590 Azerbaijani 7178 Guarani 7779 Moldavian 8471 Tajik
6665 Bashkir 7185 Gujarati 7778 Mongolian 8465 Tamil
6985 Basque 7265 Hausa 7865 Nauru 8484 Tatar
6678 Bengali; Bangla 7387 Hebrew 7869 Nepali 8469 Telugu
6890 Bhutani 7273 Hindi 7879 Norwegian 8472 Thai
6672 Bihari 7285 Hungarian 7982 Oriya 6679 Tibetan
6682 Breton 7383 Icelandic 8065 Panjabi 8473 Tigrinya
6671 Bulgarian 7378 Indonesian 8083 Pashto, Pushto 8479 Tonga
7789 Burmese 7365 Interlingua 7065 Persian 8482 Turkish
6669 Byelorussian 7165 Irish 8076 Polish 8475 Turkmen
7577 Cambodian 7384 Italian 8084 Portuguese 8487 Twi
6765 Catalan 7465 Japanese 8185 Quechua 8575 Ukrainian
9072 Chinese 7487 Javanese 8277 Rhaeto-Romance 8582 Urdu
6779 Corsican 7578 Kannada 8279 Rumanian 8590 Uzbek
7282 Croatian 7583 Kashmiri 8285 Russian 8673 Vietnamese
6783 Czech 7575 Kazakh 8377 Samoan 8679 Volapük
6865 Danish 7589 Kirghiz 8365 Sanskrit 6789 Welsh
7876 Dutch 7579 Korean 7168 Scots Gaelic 8779 Wolof
6978 English 7585 Kurdish 8382 Serbian 8872 Xhosa
6979 Esperanto 7679 Laothian 8372 Serbo-Croatian 7473 Yiddish
6984 Estonian 7665 Latin 8378 Shona 8979 Yoruba
7079 Faroese 7686 Latvian, Lettish 8368 Sindhi 9085 Zulu

Reference

ENGLISH

FRANÇAISDEUTSCHNEDERLANDSESPAÑOL

27

ITALIANO

PORTUGUÊS

SVENSKA

ENGLISH FRANÇAIS

DEUTSCH

NEDERLANDS

ESPAÑOL

ITALIANO

PORTUGUÊS

SVENSKA

Reference

COUNTRY CODE LIST

Enter the appropriate code number for the initial setting “Country Code”

Code Country Code Country Code Country Code Country

AD Andorra ER Eritrea LC Saint Lucia SC Seychelles
AE United Arab Emirates ES Spain LI Liechtenstein SD Sudan

AF Afghanistan ET Ethiopia LK Sri Lanka SE Sweden

AG Antigua and Barbuda FI Finland LR Liberia SG Singapore

AI Anguilla FJ Fiji LS Lesotho SH Saint Helena

AL Albania FK Falkland Islands LT Lithuania SI Slovenia

AM Armenia FM Micronesia LU Luxembourg SJ

AN Netherlands Antilles FO Faroe Islands LV Latvia Islands
AO Angola FR France LY Libya SK Slovak Republic
AQ Antarctica FX France (European MA Morocco SL Sierra Leone
AR Argentina Territory) MC Monaco SM San Marino
AS American Samoa GA Gabon MD Moldavia SN Senegal

AT Austria GB Great Britain MG Madagascar SO Somalia

AU Australia GD Grenada MH Marshall Islands SR Suriname

AW Aruba GE Georgia MK Macedonia ST Saint Tome and Principe

AZ Azerbaidjan GF French Guyana ML Mali SU Former USSR
BA Bosnia-Herzegovina GH Ghana MM Myanmar SV El Salvador

BB Barbados GI Gibraltar MN Mongolia SY Syria

BD Bangladesh GL Greenland MO Macau SZ Swaziland

BE Belgium GM Gambia MP Northern Mariana Islands TC Turks and Caicos Islands

BF Burkina Faso GN Guinea MQ Martinique (French) TD Chad
BG Bulgaria GP Guadeloupe (French) MR Mauritania TF French Southern
BH Bahrain GQ Equatorial Guinea MS Montserrat Territories

BI Burundi GR Greece MT Malta TG Togo
BJ Benin GS S. Georgia & MU Mauritius TH Thailand

BM Bermuda S. Sandwich Isls. MV Maldives TJ Tadjikistan

BN Brunei Darussalam GT Guatemala MW Malawi TK Tokelau
BO Bolivia GU Guam (USA) MX Mexico TM Turkmenistan

BR Brazil GW Guinea Bissau MY Malaysia TN Tunisia

BS Bahamas GY Guyana MZ Mozambique TO Tonga

BT Bhutan HK Hong Kong NA Namibia TP East Timor
BV Bouvet Island HM Heard and McDonald NC New Caledonia (French) TR Turkey

BW Botswana Islands NE Niger TT Trinidad and Tobago

BY Belarus HN Honduras NF Norfolk Island TV Tuvalu

BZ Belize HR Croatia NG Nigeria TW Taiwan
CA Canada HT Haiti NI Nicaragua TZ Tanzania
CC Cocos (Keeling) Islands HU Hungary NL Netherlands UA Ukraine

CF Central African Republic ID Indonesia NO Norway UG Uganda
CG Congo IE Ireland NP Nepal UK United Kingdom
CH Switzerland IL Israel NR Nauru UM USA Minor Outlying

CI Ivory Coast IN India NU Niue Islands

CK Cook Islands IO British Indian Ocean NZ New Zealand US United States

CL Chile Territory OM Oman UY Uruguay

CM Cameroon IQ Iraq PA Panama UZ Uzbekistan

CN China IR Iran PE Peru VA Vatican City State
CO Colombia IS Iceland PF Polynesia (French) VC Saint Vincent &
CR Costa Rica IT Italy PG Papua New Guinea Grenadines
CS Former Czechoslovakia JM Jamaica PH Philippines VE Venezuela
CU Cuba JO Jordan PK Pakistan VG Virgin Islands (British)
CV Cape Verde JP Japan PL Poland VI Virgin Islands (USA)
CX Christmas Island KE Kenya PM Saint Pierre and Miquelon VN Vietnam
CY Cyprus KG Kyrgyzstan PN Pitcairn Island VU Vanuatu
CZ Czech Republic KH Cambodia6 PR Puerto Rico WF Wallis and Futuna Islands
DE Germany KI Kiribati PT Portugal WS Samoa

DJ Djibouti KM Comoros PW Palau YE Yemen
DK Denmark KN Saint Kitts & Nevis Anguilla PY Paraguay YT Mayotte

DM Dominica KP North Korea QA Qatar YU Yugoslavia

DO Dominican Republic KR South Korea RE Reunion (French) ZA South Africa
DZ Algeria KW Kuwait RO Romania ZM Zambia
EC Ecuador KY Cayman Islands RU Russian Federation ZR Zaire

EE Estonia KZ Kazakhstan RW Rwanda ZW Zimbabwe
EG Egypt LA Laos SA Saudi Arabia
EH Western Sahara LB Lebanon SB Solomon Islands

Svalbard and
Jan Mayen

28

GENERAL

SYSTEM

OUTPUTS

SPECIFICATIONS

Power requirements AC 110-240V, 50/60 Hz
Power consumption 14W

Dimensions (approx.) 435 X 55 X 241 mm (w x h x d)

Weight (approx.) 2.4 kg

Operating temperature 5˚C to 35˚C (41˚F to 95˚F)

Operating humidity 5 % to 90 %

Laser Semiconductor laser, wavelength 650 nm

Signal system NTSC

Frequency response DVD (PCM 96 kHz): 8 Hz to 44 kHz

DVD (PCM 48 kHz): 8 Hz to 22 kHz
CD: 8 Hz to 20 kHz

Signal-to-noise ratio More than 100dB (ANALOG OUT connectors only)

Harmonic distortion Less than 0.008%

Dynamic range More than 100 dB (DVD)

More than 95 dB (CD)

VIDEO OUT 1 Vp-p 75 ohms, sync negative, RCA jack x 1

S-VIDEO OUT (Y) 1.0 V (p-p), 75 ohms, negative sync, Mini DIN 4-pin x 1

(C) 0.3 V (p-p) 75 ohms

COMPONENT VIDEO OUT (Y) 1.0 V (p-p), 75 ohms, negative sync, RCA jack x 1

(Pb)/(Pr) 0.7 V (p-p), 75 ohms, RCA jack x 2

Audio output (digital audio) 0.5 V (p-p), 75 ohms, RCA jack x 1

Audio output (optical audio) 5 V (p-p), 75 ohms, Optical connector x 1
Audio output (analog audio) 2.0 Vrms (1 KHz, 0 dB), 600 ohms, RCA jack (L, R) x 1
Audio output (analog audio) 2.0 Vrms (1 KHz, 0 dB), 600 ohms, RCA jack (LF, RF, C, RR, LR, SW) x 6

Reference

ENGLISH

FRANÇAISDEUTSCHNEDERLANDSESPAÑOL

INPUTS

+ 12V Trigger input center pin +12V at 50 mA, subminiature banana jack x 1

ACCESSORIES

Video cable 1

Audio cable 1

Remote control 1

Batteries 2

Design and specifications are subject to change without notice.

Manufactured under license from Dolby Laboratories. Dolby, MLP Lossless and the double-D symbol are trademarks of Dolby Laboratories.
Confidential unpublished works. Copyright 1992-1997 Dolby Laboratories. All rights reserved.
“DTS’ and “DTS Digital Out” are trademarks of Digital Theater Systems, Inc.

ITALIANO

PORTUGUÊS

SVENSKA

29

www.NADelectronics.com

©2003 NAD ELECTRONICS INTERNATIONAL

A DIVISION OF LENBROOK INDUSTRIES LIMITED

All rights reserved. No part of this publication may be reproduced, stored or transmitted in any form without the written permission of NAD Electronics International

T 533 Manual AH Version 10/03
