Portable DVD Player
User Manual
English
82-135-00010
Table of Contents |
|
FCC and Safety Information.................................................................................. |
3 |
Important Safety Instructions............................................................................... |
4 |
Precautions..................................................................................................... |
5 |
Selecting the type of disc for the type of TV connected................................................ |
6 |
Chapter 1. DVD |
|
1-1 DVD Playback.............................................................................................. |
7 |
Basic Playback........................................................................................................................... |
7 |
Stopping Playback and Returning to The Menu Screen (If a Menu Is Available on The Disc)................................. |
7 |
Stopping Playback....................................................................................................................... |
7 |
Rapid Advance (Rapid Reverse)....................................................................................................... |
8 |
Skipping Ahead or Back to Chapters................................................................................................. |
8 |
Still Picture(PAUSE)...................................................................................................................... |
8 |
Repeat Viewing.......................................................................................................................... |
8 |
Repeating Sections Between Two Specific Points (A-B Repeat).................................................................. |
8 |
1-2 Convenient functions................................................................................... |
9 |
Displaying the Information of the Scene............................................................................................ |
9 |
Changing Audio Soundtrack Language.............................................................................................. |
9 |
Clearing/Displaying Subtitles(A)...................................................................................................... |
9 |
Changing Subtitle Language(B)........................................................................................................ |
9 |
Viewing From Another Angle................................................................................. ......................... |
10 |
To Mute the DVD Player............................................................................................................... |
10 |
Using a DVD Menu...................................................................................................................... |
10 |
Using the Menu Function............................................................................................................. |
10 |
Playing Kodak Picture CDs and JPEG picture CDs................................................................................. |
11 |
Playing a JPEG picture with MP3 music............................................................................................. |
12 |
Chapter 2. Audio CD |
|
2-1 Audio CD Playback..................................................................................... |
13 |
Basic Playback.......................................................................................................................... |
13 |
Playing MP3 Music Discs.............................................................................................................. |
13 |
Stopping Playback..................................................................................................................... |
13 |
Rapid Advance (Rapid Reverse)...................................................................................................... |
14 |
Skipping Ahead or Back to Tracks................................................................................................... |
14 |
Pause Playback......................................................................................................................... |
14 |
2-2 Information [Audio CDs]................................................................................ |
14 |
Displaying the Information of the Playing Track.................................................................................. |
14 |
Chapter 3. Setup |
|
3-1 Language Setup........................................................................................ |
15 |
On Screen Display (OSD) Language Setting....................................................................................... |
15 |
MENU Language Setting.............................................................................................................. |
15 |
AUDIO Soundtrack Language Selection [DVD].................................................................................... |
16 |
SUBTITLE Language Selection [DVD]................................................................................................ |
16 |
3-2 Screen Setup........................................................................................... |
17 |
SCREEN SAVER Setting................................................................................................................. |
17 |
TV SYSTEM Setting..................................................................................................................... |
18 |
BRIGHTNESS Setting.................................................................................................................... |
19 |
CONTRAST Setting...................................................................................................................... |
19 |
3-3 Custom Setup........................................................................................... |
20 |
PARENTAL CONTROL Setting [DVD].................................................................................................. |
20 |
CHANGE PASSWORD Setting [DVD].................................................................................................. |
20 |
ANGLE MARK Setting [DVD]........................................................................................................... |
21 |
DEFAULT Setting....................................................................................................................... |
21 |
3-4 AUDIO Setup............................................................................................ |
22 |
OUTPUT Setting [DVD]................................................................................................................ |
22 |
Chapter 4.For Your Reference |
|
4-1 Trobleshooting......................................................................................... |
23 |
4-2 Disc Handling and Maintenance.................................................................... |
24 |
4-3 Defintion of Terms.................................................................................... |
25 |
En 2 |
|
FCC and Safety Information
CAUTION:
This unit employs a laser. Due to possible eye injury, only qualified service personnel should remove the cover or attempt to service this device. Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure.
NOTE:
This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
–Reorient or relocate the receiving antenna.
–Increase the separation between the equipment and receiver.
–Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
–Consult the dealer or an experienced radio/TV technician for help.
This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.
Since it is usual for DVD movies to be released at different times in different regions of the world, all players have region codes and disc can have an optional region code. If you load a disc of a different region code to your player, you will see the region code notice on the screen. The disc will not play, and should be unloaded.
Possible region codes:
There are 6 regions (also called “locals”). Each DVD player and disc will be played in one region ONLY.
1: Canada, U.S., U.S. Territories
2: Japan, Europe, South Africa, Middle East (including Egypt)
3:Southeast Asia, East Asia (including Hong Kong)
4:Australia, New Zealand, Pacific Islands, Central America, Mexico, South America, Caribbean
5:Former Soviet Union, Indian Subcontinent, Africa (also North Korea, Mongolia)
6:China
Never make or change connections with the power switched on.
CAUTION: VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN
AVOID EXPOSURE TO BEAM
(WARNING LOCATION: INSIDE ON LASER COVERSHIELD)
En 3
Important Safety Instructions
1.Read these instructions.
2.Keep these instructions.
3.Heed all warnings.
4.Follow all instructions.
5.Do not use this apparatus near water.
6.Clean only with a damp cloth.
7.Do not block any of the ventilation openings. Install in accordance with the manufacturer’s instructions.
8.Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
9.Do not defeat the safety purpose of the polarized-type plug. A polarized plug has two blades with one wider than the other. The wide blade is provided for your safety. When the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
10.Protect the power cord from being walked on or pinched particularly at plug, convenience receptacles, and the point where they exit from the apparatus.
11.Only use attachments/accessories specified by the manufacturer.
12.Use only with a cart, stand, tripod, bracket, or table specified by the manufacturer or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.
13.Unplug this apparatus during lighting storms or when unused for long periods of time.
14.Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way; such as when the power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture. The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus.
En 4
Precautions
Please read these precautions before operating this unit.
Power cord protection
To avoid any malfunctions of the unit, and to protect against electric shock, fire or personal injury, please observe the following.
Hold the plug firmly when connecting or disconnecting the AC power cord. Keep the AC power cord away from heating appliances.
Never put any heavy object on the AC power cord.
Do not attempt to repair or reconstruct the AC power cord in any way.
Placement
Avoid placing the unit in areas of:
direct sunlight or heating radiators, or closed automobiles high temperature (over 950F) or high humidity (over 90%) much dust as the internal parts may be seriously damaged.
Non-use periods
When the unit is not being used, turn it off. When left unused for a long period of time, the unit should be unplugged from the household AC outlet.
No fingers or other objects inside
Touching internal parts of this unit is dangerous, and may cause serious damage to the unit. Do not attempt to disassemble the unit.
Do not put any foreign object on the disc tray.
Keep away from water/magnet
Keep the unit away from flower vases, tubs, sinks, etc. If liquids are spilled into the unit, serious damage could occur.
Never bring a magnet or magnetized object near the unit.
Stacking
Place the unit in a horizontal position, and do not place anything heavy on it.
Condensation
Moisture may form on the lens in the following conditions: immediately after a heater has been turned on
in a steamy or very humid room
when the unit is suddenly moved from a cold environment to a warm one
If moisture forms inside this unit, it may not operate properly. In this case, turn on the power and wait about one hour for the moisture to evaporate.
If there is noise interference on the TV while a broadcast is being received
Depending on the reception condition of the TV, interference may appear on the TV monitor while you watch a TV broadcast and the unit is left on. This is not a malfunction of the unit or the TV. To watch a TV broadcast, turn off the unit.
En 5
Selecting the type of disc for the type of TV connected
DVD discs have the material recorded in the PAL and NTSC systems. Refer to the table below to select the correct disc type for the type of connected TV.
Connecting to the multi-system TV
Connecting to the NTSC TV |
Connecting to the PAL TV |
En 6
1-1 DVD Playback
Preparations
Please connect this portable DVD player to Power and connect it with head phones or connect it to outer equipments.
If connect it to outer equipment:
Press on the power button of the TV set, and select “Video” as the TV input.
Press on the power button of the stereo system if the player has been connected to a stereo system. Push the AV OUT/IN silde switch to AV OUT.
Basic Playback
1Open the display panel then press POWER on.
2Press OPEN to open the disc cover.
3Hold the edge of the disc to put it in the center with the printed side up.
Hold the disc without touching its surfaces, position it with the printed title side facing up, align it with the guides, and place it in its proper position.
4 Close the disc cover.
Close the disc cover and this portable DVD player starts playback if the disc does not have any menus recorded on it. If the disc has one or more titles recorded on it, a menu screen will appear on the screen.
NOTE: Proceed with steps 5 and 6 when a menu is available on the disc.
5Press
/
/
/
or the number button(s) to select the preferred title.
NOTE: To select a title, input the number, i.e. 1 for chapter 1, 10 for chapter 10, and etc.
6Press PLAY/SEL.
The player now starts playback the selected item.
Stopping Playback and Returning to The Menu Screen (If a Menu Screen Is Available on The
Disc)
Press MENU. This portable DVD player stops playback, and then displays the menu screen.
After operation
When this portable DVD player is not in use, remove the disc and press POWER to turn off the player. Then close the display panel.
NOTE:
The disc continues to rotate while the menu is displayed even after the player has finished playing a particular disc. When no further selections are to be played, be sure to press the STOP button to clear the menu screen.
If the disc is placed in upside down (and it is a single sided disc), the player’s display will appear “NO DISC”.
For your reference:
When “
” appears while a button is being operated, it means that the corresponding operation is prohibited by the player.
To Stop Playback
Press STOP.
1 Chapter
En 7
1 Chapter
1-1 DVD Playback-continued
Rapid Advance or Rapid Reverse
By the remote control:
Press
F.BWD or F.FWD
during playback.
Normal playback is resumed when you press PLAY/SEL.
The speed of advance (
x2,
x4, and etc) or reverse (
x2,
x4, and etc.) changes for each press of the F.FWD or F.BWD button.
Skipping Ahead or Back to Chapters
You can skip a specific chapter or track to playback.
Skipping Ahead
Press NEXT
during playback.
Skips a chapter each time you press the button.
Skipping Back
Press
PREVIOUS during playback.
When you press the button once midway through a chapter, this portable DVD player returns to the begining of the chapter to playback. The player skips back a chapter each time you press the button.
Still Picture (PAUSE)
Press PAUSE once during playback.
The screen is paused.
To return to normal playback
Press PLAY/SEL.
Repeat Viewing
1 Press 1/ALL REPEAT during playback.
Each time you press the button, it will cycle through the following.
Press once: REP CHAPTER (Repeat chapter)
Press twice: REP TITLE (Repeat title)
Press three times: REP DISC (Repeat disc)
Press four times: REP off (Repeat cancelled)
To return to normal playback
Press 1/ALL REPEAT several times until “REPEAT Off” appears.
NOTE:
Repeat playback works only with discs for which the elapsed playing time appears on the player’s display during playback. Repeat playback may not work correctly with some DVDs.
Repeating Sections Between Two Specific Points (A-B Repeat)
1 Press A-B during playback at the point where repeat play is to start (A).
“REP A” appears on the screen.
2 Press A-B again at the point where repeat play is to end (B).
“REP B” appears on the screen. Repeat playback of points A to B starts playback.
To return to normal playback
Press A-B again. (“REPEAT Off” appears on the screen.)
NOTE: A-B repeat playback works only within a chapter.
En 8
