MSI MS-6702 Schematics 00E

5

4

3

2

1

Title Page

MS-6702 VER:0E ATX

*AMD PGA 754 K8-Processor (DDR 400)

D D

*VIA K8T400M / VT8237 Chipset

(AGP 8X / VLink 8X)
*Winbond 83697HF-VF LPC I/O
*VT6306 1394a OHCI Link Layer Controller

*PDC20378 Serial ATA Controller
*RTL 8110S Giga/ 8100C100/10 Bit LAN

Support
*USB 2.0 support (integrated into VT8237)

*Vcore Jumpless support
*ALC650/ALC655 6 channel S/W Audio

C C

*DDR DIMM * 3
*AGP SLOT * 1 ( 8X )
*PCI SLOT * 5

B B

Cover Sheet 1
Block Diagram

Clock Synthesizer & MS1 7
System Memory

DDR DIMM 1 & 2 & 3 8,9
DDR Terminations R & C
DDR Damping R & Bypass Cap.
NB VIA K8T400M/VER:0.4 (HT)
K8 Vcore
AGP SLOT 8X
VT8237
PCI Connectors * 5
ALC650/ALC655 6 channel S/W Audio
Serial ATA Controller PDC20378
IDE ATA 66/100 Connectors * 2
1394 Controller VT6306
Front USB Port *2
Rear USB Port *2
LPC I/O W83697HF & Floppy
Hardware monitor & FAN
BIOS ROM & VCORE ADJUSTI NG
Keyboard/Mouse Connectors
LPT/COM Port
Giga-Bit LAN RTL8110S/RTL8100C
ACPI Power CONTROLLER (MS-6)
SYSTEM VOLTAGE REGULATOR
Front Panel & POWER OK CIRCUIT
Decoupling Cap.
Power Sequence
History
OPTION PARTS

2
3GPIO SPEC
4,5,6AMD K8 -> 754 PGA Socket

10
11
12,13,14
15
16
17,18,19
20,21,22
23
24,25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42

1. Modify Circuit 6702-0A_0822-91.DSN 08/22/91 - > La y out F in i sh e d ( Ge r be r- O ut Ve r si on ).

1. Modify Circuit 6702-0A_0827A-91.DSN 08/27/91-> Release NEW B O M o f E S -BOM for Stan d a r d
( 6702-A20 ).

2. Modify Circuit 6702-0A_1001-91.DSN 10/01/91-> Af t er Pilot-Run ( Didn't release EC R ) .

1. Modify Circuit 6702-0B_1108-91.DSN 11/08/91=> VER:0A -> OB : Modify H/W issue & K8-CPU
& NB-K8T400M & Change H/W Audio to S/W Audio ( Gerber-Out Version ) .

2. Creat new BOM for MS6702/VER:0B , 6702-0B_1108A-91.dsn 11/08/91 .

3. Modify BOM for MS6702/VER:0B , 6702-0B_1118-91.dsn 11/18/91 .

1. Modify Circuit 6702-0C FROM 67020B.

2.GERBER OUT 1/29/2003.

Layout Gerber-Out 0822-91

Release ES-BOM

Modify MS6702/VER:0B 10/04/2002

Modify MS6702/VER:0C 1/03/2003

A A

Micro Star Restricted Secret

MS6702-0E

5

4

3

2

Title

Document Number

MICRO-STAR INT'L

No. 69, Li-De St, Jung-He City,

CO.,LTD.

Taipei Hsien, Taiwan
http://www.msi.com.tw

1

Cover Sheet

MS-6702

Last Revision Date:
Sheet

Rev

0E

Wednesday, June 25, 2003

142

of

5

Block Diagram

4

3

2

1

AMD K8 Socket 754

DDR400

D D

HT

A
G

C C

5 PCI Slots

P

S
L
O
T

AGP 8X /Fast Write

PCI-33

VIA
K8T400M

VLINK

Dual ATA
100/133

IDE Slot
==>ATA66,100,133 *2

DDR * 3

B B

1394
Front-Port *3

1394 Host
Controller
VT6306

AC97 => S/W Audio
ALC655 / 6 channel

AC97

SERIAL ATA *2

Serial ATA & IDE
RAID Controller
PDC20378

VT8237

USB

LPC BUS

SUPER I/O
W83697HF

ROM

X BUS

A A

Serial Port *2 ,
IDE Port *1

5

Giga Bit LAN
RTL8110S/8100C

4

Dual USB 1.1 OHCI
/2.0 EHCI 8 Ports
==> Front-Port *6 ,
Back-Port *2

3

Micro Star Restricted Secret

Title

Document Number

MICRO-STAR INT'L

No. 69, Li-De St, Jung-He City,

CO.,LTD.

Taipei Hsien, Taiwan

2

http://www.msi.com.tw

Block Diagram

MS-6702

1

Last Revision Date:
Sheet

Rev

0E

Wednesday, June 25, 2003

242

of

5

4

3

2

1

GPIO FUNCTION

VT8237 GPIO Function Define

PIN NAME

D D

GPO0 (VSUS33)

GPO1/SUSA#(VSUS33)

GPO2/SUSB#(VSUS33)

GPO3/SUSST1#(VSUS33)

GPO4/SUSCLK(VSUS33)

GPO5/CPUSTP#

GPO6/PCISTP#

GPO7/SLP#

GPO8/GPI8/IPBIN0

GPO9/GPI9/IPBIN1

C C

GPO10/GPI10/IPBRDFR

GPO11/GPI11/IPBRDCK

GPO12/GPI12/INTE#

GPO13/GPI13/INTF#

GPO14/GPI14/INTG#

GPO15/GPI15/INTH#

GPO16/SA16/STRAP

GPO17/SA17/STRAP

GPO18/SA18/STRAP

GPO19/SA19/STRAP

B B

GPO20/GPI20
/ACSDIN2/PCS0#/EI

GPO21/GPI21/ACSDIN3
/PCS1#/SLPBTN#

GPO22/GPI22/IOR#

GPO23/GPI23/DPSLP

GPO24/GPI24/GPIOA

GPO25/GPI25/GPIOC
GPO26/GPI26/SMBDT2

(VSUS33)
GPO27/GPI27/SMBCK2

(VSUS33)
GPO28/GPI28/

VIDSEL
GPO29/GPI29/

A A

VRDSLP

GPO30/GPI30/GPIOD

GPO31/GPI31/GPIOE

5

VCORE_ADJ

NA

SUSB#

SUSST#

NA (Exteranl Pull up to 3VDUAL)

NA (Exteranl Pull up to VCC3)

NA (Exteranl Pull up to VCC3)

LDTSTOP#

NA

NA

NA

NA

S_VID0

S_VID1

S_VID2

NA

LDT Freq Strapping Bit0

LDT Freq Strapping Bit1

LDT Width (Low=8 Bit)

Fast Command (Low=Disable)

POWERF1

POWERF2

NA

ROMLOCK

NA

NA

SMBDATA2/Slave SMBUS

SMBCLK2/Slave SMBUS

NA

NA

NA

NA

PIN NAME Function defineFunction define

GPI0

GPI1

GPI2/EXTSMI#

GPI3/RING#

GPI4/LID#

GPI5/BATLOW#

GPI6/AGPBZ#

GPI7/REQ#5

GPI16/INTRUDER#

GPI17/CPUMISS

GPI18/AOLGP1/THRM#

GPI19/IORDY

(Exteranl Pull up to VBAT)NA

ATADET0=>Detect IDE1 ATA100/66

EXTSMI#

RING#

ATADET1=>Detect IDE2 ATA100/66

(Exteranl Pull up to 3VDUAL)

NA

POWERF3

(Exteranl Pull up to 3VDUAL)

NA

(Exteranl Pull up to VBAT)

NA

(Exteranl Pull up to 3VDUAL)

NA

THRM#

(Exteranl Pull up to VCC3)NA

S/IO GPIO Function Define

PIN NAME Function define

GPBX/GP13

GPAY/GP15

GPAS1/GP10

GPAS2/GP17

GPAX/GP12

GPBY/GP14

GPBS1/GP11

GPBS2/GP16

4

LED#4

LED#2

LED1

LED4

LED#3

LED#1

LED2

LED3

3

PCI Routing

DEVICES

PCI SLOT 1

PCI SLOT 2

PCI SLOT 3

PCI SLOT 4

PCI SLOT 5

Giga-Bit
LAN

INT#

INT#A
INT#B
INT#C
INT#D

INT#B
INT#C
INT#D
INT#A

INT#C
INT#D
INT#A
INT#B

INT#D
INT#A
INT#B
INT#C

INT#B
INT#C
INT#D
INT#A

INT#A AD22 GLAN_PCLK

IDSEL

AD16

AD17

AD18

AD19

AD21

MS1 #1

SERIAL ATA INT#B AD24 SATAPCLK

1394 INT#D AD25 1394_PCLK( PREQ#5 )

REQ#/GNT#

PREQ#6
PGNT#6

PREQ#3

PGNT#3

PREQ#4
PGNT#4

PREQ#7
PGNT#7

PREQ#8
PGNT#8

PREQ#1
PGNT#1

PREQ#0
PGNT#0

( PREQ#2 )
( PGNT#2 )

( PGNT#5 )

Micro Star Restricted Secret

Title

Document Number

MICRO-STAR INT'L

No. 69, Li-De St, Jung-He City,

CO.,LTD.

Taipei Hsien, Taiwan

2

http://www.msi.com.tw

CLOCK

PCICLK1

PCICLK2

PCICLK3

PCICLK4

PCICLK5

MS1_PCLK

GPIO Spec.

MS-6702

Last Revision Date:
Sheet

1

Rev

0E

Wednesday, June 25, 2003

of

342

5

4

3

2

1
