Motorola Xoom 2 User Guide

MOTOROLA XOOM™ 2 media edition with 4G
Inboxbn
I
LIFE. POWERED.
Your tablet Start Touch Navigate Personalise Type Load up Surf Play & record Control Locate Email Chat Contact Read Work Note Connect Protect Accelerate Want more? Troubleshooting Safety, regulatory & legal
+
More Support
Back Next

Your tablet

Your tablet

At a glance

When you're up and running, make sure you explore what your tablet can do:
• Customise: Start up, then "Personalise" your tablet.
• Create: Check and send your "Email", and even create
and edit documents and calendar events for "Work".
• Enjoy: "Load up" your tablet's apps and games, or "Play &
record" media and "Control" your TV.
Headphone jack Notification light
Front camera lens
Power/sleep key (on back)
Hold=power, press=sleep
Volume keys (on back)
Micro USB/charger
Charging light
HDMI
SIM and microSD
Inbox
davidkelley4763@gmail.com
Google Calendar 14:55 Reminder: Executive review call @ 8 Apr 15:00–16:00 (David's calendar@moto
Justin Younger 14:52 Budget updates ― Hi everyone, I’ve updated all of the budget information for today's call
Me, Paul, Kim 3 14:50
content updates for marketing materials— Sounds like a plan. Let's move forward for now
Greg Poulimas 14:47 Site you should check out ― Thought that this was relevant to your current project. Also,
Julie Demler 14:45 Content approvals ― All of this is approved by me. Please forward along to the rest of the
Gmail Browser Talk Maps Gallery
Fri
APR
8
5
Laura's birthday
Executive review call
15:00–16:00 Dial in number: 1-888-55
Project mgr interview
16:00–17:00 My office
Happy hour
18:00–19:00 [wire] bar
Happy hour
18:00–19:00 [wire] bar
Tomorrow, 9 April
Apps
YouTube
Market
Camera
Tips & tricks
• Power/Sleep: To turn your tablet on or off, press and
hold Power/Sleep on the back. To make the screen sleep or wake up, press but don't hold.
Note: Wi-Fi-only devices don't have a SIM card. Certain
apps and features may not be available in all countries.
This product meets the applicable limit for exposure to radio waves (known as SAR) of
2.0 W/kg (ICNIRP). The limits and guidelines include a substantial safety margin designed to assure the safety of all persons, regardless of age and health. The highest SAR values measured for this device are listed in the regulatory information packaged with your product.
MOTOROLA XOOM™ 2 media edition with 4G
LIFE. POWERED.
Your tablet Start Touch Navigate Personalise Type Load up Surf Play & record Control Locate Email Chat Contact Read Work Note Connect Protect Accelerate Want more? Troubleshooting Safety, regulatory & legal
+
More Support
Back Next

Start

Start

Setup

Let's get you up and running.
Caution: Before assembling, charging or using your
device for the first time, please read the important safety, regulatory and legal information in this guide.
1
Charge up.
Note: This product uses a non-removable battery.
3
Insert your SIM and microSD cards.
5
Sign in.
Sign in with your Google Account
Email
Password
2
Remove the placeholder SIM and microSD cards.
4
Power up.
Power/Sleep key (on back)
Hold=power
SIM and microSD
Tips & tricks
• In the unlikely event that your tablet becomes
unresponsive, try a forced reboot—press and hold both Power/Sleep and the down volume key for more than 12 seconds.
Note: This product uses a non-removable battery. The
battery should only be replaced by a Motorola-approved service facility. Any attempt to remove or replace your battery may damage the product.
Note: Wi-Fi-only devices don't have a SIM card.
Note: This device supports apps and services that use a lot
of data, so make sure your data plan meets your needs. Contact your service provider for details.
MOTOROLA XOOM™ 2 media edition with 4G
oxob
n
LIFE. POWERED.
Your tablet Start Touch Navigate Personalise Type Load up Surf Play & record Control Locate Email Chat Contact Read Work Note Connect Protect Accelerate Want more? Troubleshooting Safety, regulatory & legal
+
More Support
Back Next

Touch

Touch

Quick start: Touch

It's all in the touch:
• Touch: Choose an icon or option.
• Touch & hold: Move items on the home screen, or open
options for items in lists.
• Drag or flick: Scroll slowly (drag) or quickly (flick).
• Pinch or double-tap: Zoom in and out on websites,
photos and maps.
Apps
Inbox
davidkelley4763@gmail.com
Google Calendar 14:55 Reminder: Executive review call @ 8 Apr 15:00–16:00 (David's calendar@moto
Justin Younger 14:52 Budget updates ― Hi everyone, I’ve updated
all the budget information for today's call
Me, Paul, Kim 3 14:50
content updates for marketing materials—
Sounds like a plan. Let's move forward for now
Greg Poulimas 2:47pm Site you should check out ― Thought that
this was relevant to your current project. Also,
Julie Demler 14:45 Content approvals ― All of this is approved
by me. Please forward along to the rest of the
Gmail Browser Talk Maps Gallery
Fri
APR
8
5
Laura's birthday
Executive review call
15:00–16:00 Dial in number: 1-888-55
Project mgr interview
16:00–17:00 My office
Happy hour
18:00–19:00 [wire] bar
Happy hour
18:00–19:00 [wire] bar
Tomorrow, 9 April
Touch & hold to move items on the home screen, or to open options for items in lists.
Flick or drag to scroll.
YouTube
Market
Camera
Touch to open.
Tips & tricks
• Flick & stop: When you flick a long list, touch the screen
to stop it from scrolling.
• Maps: Twist a map with two fingers to rotate it, and pull
two fingers down to tilt it.
MOTOROLA XOOM™ 2 media edition with 4G
oxob
n
LIFE. POWERED.
Your tablet Start Touch Navigate Personalise Type Load up Surf Play & record Control Locate Email Chat Contact Read Work Note Connect Protect Accelerate Want more? Troubleshooting Safety, regulatory & legal
+
More Support
Back Next

Navigate

Navigate

Quick start: Navigate

Find your way around:
• Search: Search with text or voice.
• App menu: See all your apps (if you have a lot, flick
left and right to see them all).
• Back: Go back one screen.
• Home: Return to the home screen at any point.
• Recent apps: Show thumbnails of your recent apps
(touch a thumbnail to open the app).
Apps
Open apps.
Inbox
davidkelley4763@gmail.com
Google Calendar 14:55 Reminder: Executive review call @ 8 Apr 15:00–16:00 (David's calendar@moto
Justin Younger 14:52 Budget updates ― Hi everyone, I’ve updated
all the budget information for today's call
Me, Paul, Kim 3 14:50
content updates for marketing materials—
Sounds like a plan. Let's move forward for now
Greg Poulimas 2:47pm Site you should check out ― Thought that
this was relevant to your current project. Also,
Julie Demler 14:45 Content approvals ― All of this is approved
by me. Please forward along to the rest of the
Gmail Browser Talk Maps Gallery
Fri
APR
8
5
Laura's birthday
Executive review call
15:00–16:00 Dial in number: 1-888-55
Project mgr interview
16:00–17:00 My office
Happy hour
18:00–19:00 [wire] bar
Happy hour
18:00–19:00 [wire] bar
Tomorrow, 9 April
YouTube
Market
Search.
Widgets
Flick left or right to see more panels.
Shortcuts
Back Home
Camera
Recent apps
Notifications & quick settings
Touch for details.
Tips & tricks
• Panel s: Flick left or right to show the five home screen
panels. To return to the centre panel, touch Home .
• Notifications: Touch the clock in the bottom right to
show your tablet's status and details about any new messages or other notifications.
• Menu: When you see in the top right, or in the
bottom left, you can touch them to open a menu for the screen you're on.
MOTOROLA XOOM™ 2 media edition with 4G
oxob
n
LIFE. POWERED.
Your tablet Start Touch Navigate Personalise Type Load up Surf Play & record Control Locate Email Chat Contact Read Work Note Connect Protect Accelerate Want more? Troubleshooting Safety, regulatory & legal
+
More Support
Back Next

Personalise

Personalise

Quick start: Personalise

Change your widgets, wallpaper and more—make it yours.
• Home screen: To move widgets or shortcuts, touch and
hold them. To add them or change wallpaper, touch in the top right.
• Sound & display: Touch the clock in the bottom right,
then touch and more.
Inbox
davidkelley4763@gmail.com
5
Google Calendar 14:55 Reminder: Executive review call @ 8 Apr 15:00–16:00 (David's calendar@moto
Justin Younger 14:52 Budget updates ― Hi everyone, I’ve updated all of the budget information for today's call
Me, Paul, Kim 3 14:50
content updates for marketing materials— Sounds like a plan. Let's move forward for now
Greg Poulimas 14:47 Site you should check out ― Thought that this was relevant to your current project. Also,
Julie Demler 14:45 Content approvals ― All of this is approved by me. Please forward along to the rest of the
Gmail Browser Talk Maps Gallery
Settings to choose Screen, Sound and
Apps
Add widgets, wallpaper and more to your home screen.
Fri
APR
8
Laura's birthday
Executive review call
15:00–16:00 Dial in number: 1-888-55
Project mgr interview
16:00–17:00 My office
Happy hour
18:00–19:00 [wire] bar
Happy hour
18:00–19:00 [wire] bar
Tomorrow, 9 April
YouTube
Market
Touch & hold, then drag widgets or shortcuts to a new spot or the bin in the top right.
Touch the status indicators, then touch twice to change your screen, sound or other settings.
Camera
Flight mode
Wi-Fi
Auto-rotate screen
AUTO
Notifications
Settings
3
2
1
Tips & tricks
• Add to your home screen: Just touch and hold an
empty spot on the home screen.
• Remove from your home screen: Touch and hold a
widget or shortcut, then drag it to the bin in the top right.
• Settings app: To open settings from the app menu,
touch
Apps > Settings.
MOTOROLA XOOM™ 2 media edition with 4G
LIFE. POWERED.
Your tablet Start Touch Navigate Personalise Type Load up Surf Play & record Control Locate Email Chat Contact Read Work Note Connect Protect Accelerate Want more? Troubleshooting Safety, regulatory & legal
+
More Support

Settings

Open the quick settings menu to change your settings or turn on Wi-Fi.
1 Touch the clock in the bottom right-hand corner of the
home screen.
2 Tou c h .
3 Change a quick setting, or touch to see all tablet
settings.
Friday 10 Dec. 2011
100%Wi-Fi
Flight mode
Wi-Fi
Auto-rotate screen
AUTO
Notifications
Settings
OFF
Connect Wi-Fi.
ON
ON
Change quick settings.
Change any settings.
Back Next
Personalise
MOTOROLA XOOM™ 2 media edition with 4G
?123
ABC
LIFE. POWERED.
Your tablet Start Touch Navigate Personalise Type Load up Surf Play & record Control Locate Email Chat Contact Read Work Note Connect Protect Accelerate Want more? Troubleshooting Safety, regulatory & legal
+
More Support
Back Next

Type

Type

Quick start: Type

Just touch a text field to open a touch keypad. Touch to close it.
?123
?
-
ABC
Backspace
Enter
(or start a new line)
Shift
Voice entry
• Numbers & symbols: Touch or for numbers or
letters.
• Capital letters: Touch to enter one capital letter, hold
it to enter capitals until you release it or double-tap it to lock capitals until you touch it again.
Compose
From:
you@gmail.com
To:
Subject:
Compose mail
Change input options.
Jump to the next text box in a message or online form.
Choose numbers/symbols or letters.
Tab
WE R T Y U I O PQ
?123
AS
DFGHJ
CVBNM
ZX
:-)
/
Send Save draft
K
+ Cc/Bcc
L
!
,
.
"
'
-
Tips & tricks
• Cut or copy: Touch and hold text, then touch Cut or
Copy at the top of the screen.
• Paste: Touch location to paste, then touch
Paste.
• Delete: Touch (hold to delete more).
• Input options: To change input options, touch for
capitalisation, correction, learnt words and other options.
• Accelerate: Use a dock or Bluetooth™ keyboard and
mouse when you want to make your tablet more like a laptop computer. Turn them on and touch
Settings > Wireless & networks > Bluetooth
>
settings
> Find devices nearby. To disconnect the
Apps
mouse, turn it off. To disconnect the keyboard, touch the keyboard icon in the bottom right of your screen, then drag the touch switch to
Off.
MOTOROLA XOOM™ 2 media edition with 4G
oice search
y
LIFE. POWERED.
Your tablet Start Touch Navigate Personalise Type Load up Surf Play & record Control Locate Email Chat Contact Read Work Note Connect Protect Accelerate Want more? Troubleshooting Safety, regulatory & legal
+
More Support

Load up

Quick start: Load up

Your tablet comes with fun games and apps—explore them, and download even more from Android Market™!
Find it:
• Find: To find a game or app, touch at the top.
• Review: To show the apps you've downloaded from
Browse apps or
Apps > Market
Market, touch My apps.
Search apps or
books.
Apps Books Search Market My apps
TRAVEL
books.
ver 3 million books.
Reading unbound.
FEATURED FOR TABLETS >
Gmail
Google Inc.
Google Maps
Google Inc.
TOP PAID >
Finance
Google Inc.
Free
Free
Google Pinyin
Google Inc.
Free
Free
Show your
downloaded apps.
Free
Google Goggles
Google Inc.
Free
Google Docs
Google Inc.
Free
Voice search
V
by
CATEGORIES
GAMES
BOOKS & REFERENCE
BUSINESS
COMICS
COMMUNICATION
EDUCATION
ENTERTAINMENT
Menu
Tips & tricks
• Help: To get help and more, touch Menu in the top
right-hand corner.
• On a computer: You can find and manage apps from
any computer. Just go to market.android.com
and log in
with the email and password for your Google account.
• Uninstall: To uninstall your apps from
apps
. Touch an app to show the Uninstall button.
Market, touch My
Back Next
Load up
MOTOROLA XOOM™ 2 media edition with 4G
LIFE. POWERED.
Your tablet Start Touch Navigate Personalise Type Load up Surf Play & record Control Locate Email Chat Contact Read Work Note Connect Protect Accelerate Want more? Troubleshooting Safety, regulatory & legal
+
More Support
Back Next
Load up

Apps

At a glance: Apps
You can find all of your apps in one place. From the home screen, just touch
• To manage your Android Market™ apps and check for updates, touch
• To manage all your apps, touch
Applications > Manage applications.
>
Apps to open the app menu.
Apps > Market > My apps.
Apps > Settings

Android Market™

Get all the apps, games and widgets you want, from developers and authors worldwide. Search and browse for what you need, or check out the latest recommendations. And with so much for free, you're sure to find something. If you need help or have questions about Android Market, touch Menu >
Find it:
Touch an app to see details and reviews, then install, buy or try it.
Tip: Apps and games will appear in your app menu.
Widgets can be added to your home screen.
On your computer, you can browse and manage apps for all your Android™ devices at market.android.com
Help.
Apps > Market
.

Choose carefully

Apps are great. There's something for everyone. Play, communicate, work or just for fun. But remember, choose your apps carefully. Here are a few tips to help:
• To help prevent spyware, phishing or viruses affecting your tablet or privacy, use apps from trusted sites, like
Market.
• In Android Market, check the apps' ratings and comments before installing. This will help you choose the best ones for you.
• If you doubt the safety of an app, don't install it.
• Like all apps, downloaded apps will use up memor y, data, battery and processing power—some more than others. After installing an app, if you're not happy with how much memory, data, battery or processing power it's using, uninstall it. You can always install it again later.

Recent apps

Your tablet remembers the apps you used most recently. Touch to see your recent apps. Touch an app to open it.

Manage & restore apps

Find it: Apps > Settings > Applications > Manage
applications
To uninstall a downloaded app, touch Downloaded, then the app, then Market™, touch Previously installed apps are listed and available for download.
To stop, change settings or manage other options, touch
All or Running. Touch the app, then the option you want.
Uninstall. To reinstall apps from Android
Apps > Market > My apps.
MOTOROLA XOOM™ 2 media edition with 4G
LIFE. POWERED.
Your tablet Start Touch Navigate Personalise Type Load up Surf Play & record Control Locate Email Chat Contact Read Work Note Connect Protect Accelerate Want more? Troubleshooting Safety, regulatory & legal
+
More Support

Update my tablet

You can check for, download and install software updates using your tablet or your computer:
• Using your tablet:
You may get an automatic notification of an available update on your tablet. Simply follow the instructions to download and install.
To manually check for updates, touch
Settings > About tablet > System updates.
Note: To minimise the impact of updating on your data
plan, you might want to use a Wi-Fi connection for updates. Updates can be quite large (25 MB or more) or may not be available over the mobile network in some countries.
• Using a computer:
Go to www.motorola.com/myxoom2 "Software" links. If an update is available, simply follow the installation instructions.
Apps >
and check the
Back Next
Load up
MOTOROLA XOOM™ 2 media edition with 4G
.
LIFE. POWERED.
Your tablet Start Touch Navigate Personalise Type Load up Surf Play & record Control Locate Email Chat Contact Read Work Note Connect Protect Accelerate Want more? Troubleshooting Safety, regulatory & legal
+
More Support

Surf

Quick start: Surf

You're surfing on the big screen.
Find it:
• Ta b s : Touch to open a new tab, then touch tabs to
go to them or touch to close them.
• Bookmarks: If you love that website, touch to
bookmark it. Touch to open your bookmarks.
Movie Tickets & Thea...
Home Showtimes Browse Movies DVDs Trailers Movie Guides
http://www.filmfans.com/
Younger Than Ever Exclusive Clip
With no way out, Bailey is forced to leave the city she loves and find the reason for her parents' untimely demise.
ttp://www
Apps > Browser
BLACK HOLE
COMING THIS SUMMER
Menu
Open bookmarks.
Search
Add a bookmark.
Touch and enter a URL.
Tabs (touch + to add a tab)
Back Forward Refresh
Tips & tricks
• Touch & hold: Touch and hold a link or text field for options.
• Zoom: To zoom in or out, pinch your fingers together or move them apart on the screen.
• Search: To search from the home screen, touch in the top left for a text search, or touch for a voice search.
• Share: To send a website link to a friend, just touch Menu >
Share page.
Back Next
Surf
MOTOROLA XOOM™ 2 media edition with 4G
.
LIFE. POWERED.
Your tablet Start Touch Navigate Personalise Type Load up Surf Play & record Control Locate Email Chat Contact Read Work Note Connect Protect Accelerate Want more? Troubleshooting Safety, regulatory & legal
+
More Support
Back Next
Surf

Tabbed browsing

You can open several webpages in the same window to multiply your web surfing fun. Touch to open a new tab. To see a webpage, just touch its tab. Touch on a tab to close it.

Select links

Touch a link to go to that webpage. Touch and hold a link to show options, like
Open in a new tab or Save link.

Play web videos

On many webpages, a message or an icon (like ) indicates that a video is available. Touch the link or icon to play the video. Touch the play and pause buttons to control video playback. (If you don't see them, touch the screen.)

Bookmarks

You can save bookmarks to your favourite webpages and navigate to them in seconds. To set a bookmark for the webpage you're on, touch , then bookmarked page, touch , then touch the thumbnail for the page you want.
OK. To go to a

Downloads

To see all of your downloads, touch Menu in the browser's top right corner and choose choose
Apps > Downloads from the home screen.
Downloads. Or, just

Download apps

Warn in g: Apps downloaded from unknown sources can
include spyware, phishing or viruses that affect your tablet, tablet performance and personal data.
For security, download apps only from trusted sites like
Apps > Market.
To download apps:
1 If you want to allow downloads from any webpage,
touch
sources
2 To launch the browser, touch
3 Find the app you want to download and touch the
download link.
Note: Downloaded apps are stored in your tablet's
memory.
Apps > Settings > Applications > Unknown
.
ttp://www
Apps > Browser.

Browser options

Touch Menu to see browser options:
Options
New tab Open a new tab in the same browser
New incognito tab
Find on page Enter & search for a term.
Share page Share the page URL over a
Page info View the page URL.
Downloads View and manage files you
Settings View & change browser settings.
window.
Open a new blank tab in the browser window to prevent the browser from storing information about your browsing session.
Bluetooth™ connection or in a Gmail™ message.
downloaded from webpages.
MOTOROLA XOOM™ 2 media edition with 4G
LIFE. POWERED.
Your tablet Start Touch Navigate Personalise Type Load up Surf Play & record Control Locate Email Chat Contact Read Work Note Connect Protect Accelerate Want more? Troubleshooting Safety, regulatory & legal
+
More Support

Play & record

Quick start: Play & record

See it, capture it, share it!
Find it:
• Photos & videos: In the camera, touch to take a
• Stream and transfer computer files: See "MotoCast".
• Transfer files: See "Bluetooth™ wireless"or "USB
On the back of your tablet:
Open the
Apps > Camera or Music
photo or touch to switch to videos.
To open photos & videos, touch
connection".
Camera flash Back camera lens
gallery.
Start/stop recording
video (or take photo).
Choose the front
or back camera.
Apps > Gallery.
Zoom
Choose photo
or video.
Tips & tricks
• YouTube™: To find YouTube videos, touch Apps
YouTube.
>
To upload videos to your account, open YouTube and touch Menu >
• Zoom: To zoom in or out on photos, pinch your fingers together or move them apart on the screen.
• Camera settings: In the photo viewfinder, touch to
Camera settings.
open
Sign in.
Back Next
Play & record
MOTOROLA XOOM™ 2 media edition with 4G
W
W
LIFE. POWERED.
Your tablet Start Touch Navigate Personalise Type Load up Surf Play & record Control Locate Email Chat Contact Read Work Note Connect Protect Accelerate Want more? Troubleshooting Safety, regulatory & legal
+
More Support
Back Next
Play & record

Photos

Take that family photo and post it online for everyone to see.
Find it:
To take the photo, touch
Photo modes—Get the best photo every time. Just touch
a photo mode:
•—Flash: Set to
•—White balance: Adjust for lighting conditions.
•—Colour effect: Pick a cool effect.
•—Scene mode: Choose your environment.
•—Camera settings: Choose general settings like
After you take the photo, you can touch the thumbnail to open your gallery. Touch the photo to open it:
• Start a slideshow: Touch .
• Share photo: Touch to send the photo in a
• Delete the photo: Touch .
Touch Menu to see details, rotate, crop or set as a contact photo or wallpaper.
Apps > Camera.
Auto, On or Off.
A
Picture quality.
message, transfer it using Bluetooth™ wireless or post it online.

Videos

Find it: Apps > Camera >
To start recording, touch . To stop recording, touch .
Video modes—Get the best video every time. Just touch
a video mode:
•—Flash: Set to
On or Off.
•—White balance: Adjust for lighting conditions.
A
•—Colour effect: Pick a cool effect.
•—Video quality: Select
(High, 15m)
•—Time lapse interval: Create a time lapse clip.
After you record the video, you can touch the thumbnail to open your gallery. Touch the video to view options:
• Play: Touch .
• Start a slideshow: Touch .
• Share: Touch to send the video in a message, transfer it using Bluetooth™ wireless or post it online.
• Delete: Touch .
.
High, Low or YouTube

Gallery

Find it: Apps > Gallery
Tip: To watch your photo slideshow or recorded HD videos
on your HDTV, just connect an HDMI cable from your TV or monitor.
1 Choose which photos and videos to show and how you
want them listed:
Camera—All your photos.
•
By album—Photos and videos grouped by album.
•
Images and videos—Photos only, videos only or
•
both.
2 Touch a folder name or tag name, if necessary.
Touch a photo or video thumbnail to select it for viewing or playback.
Loading...
+ 32 hidden pages
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
