Motorola RAZR V3 User Manual [vi]

RAZR

motorola.com

GSM

HELLOMOTO

Introducing your new Motorola RAZR V3 GSM wireless phone.

Smart Key

Volume Keys

Menu Key

Open menus.

Left Soft Key

Send Key

Make & answer calls.

Voi c e Key

Right Soft Key

Power/End Key

Turn on/off, hang up, exit menus.

Navigation Key

Navigate menus.

Center Select Key

Select menu items.

Camera lens

Adjust camera zoom when

Vol u me Key s

flip is closed.

Smart Key

Take camera photo when

flip is closed.

Accessory Connector Port

Insert battery charger &

phone accessories.

Bluetooth® Indicator Light

Voi c e Key

External Display

See incoming call information, use as camera viewfinder when flip is closed.

Main MenuHome Screen

Service Provider

Headlines and graphics from your Service Provider

Setup Home

Press and hold the

for a few seconds to turn

on your phone.

10:15 am

Camera

Power Key

Press the

to open the

Main Menu

Menu Key

Press the

S to highlight a

Key

menu feature.

Navigation

Games & Apps

SelectExit

Press the

Select Key

select it.

Center

s to

Motorola, Inc. Consumer Advocacy Office 1307 East Algonquin Road Schaumburg, IL 60196

www.hellomoto.com

1-800-331-6456 (United States)

1-888-390-6456 (TTY/TDD United States for hearing impaired)

1-800-461-4575 (Canada)

Certain mobile phone features are dependent on the capabilities and settings of your service provider’s network. Additionally, certain features may not be activated by your service provider, and/or the provider’s network settings may limit the feature’s functionality. Always contact your service provider about feature availability and functionality. All features, functionality, and other product specifications, as well as the information contained in this user’s guide are based upon the latest available information and are believed to be accurate at the time of printing. Motorola reserves the right to

change or modify any information or specifications without notice or obligation.

MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark Office. The Bluetooth trademarks are owned by their proprietor and used by Motorola, Inc. under license. Java and all other Java-based marks are trademarks or registered trademarks of Sun Microsystems, Inc. in the U.S. and other countries. All other product or service names are the property of their respective owners.

Caution:

Changes or modifications made in the radio phone, not expressly approved by Motorola, will void the user’s authority to operate the equipment.

Software Copyright Notice

The Motorola products described in this manual may include copyrighted Motorola and third-party software stored in semiconductor memories or other media. Laws in the United States and other countries preserve for Motorola and third-party software providers certain exclusive rights for copyrighted software, such as the exclusive rights to distribute or reproduce the copyrighted software. Accordingly, any copyrighted software contained in the Motorola products may not be modified, reverse-engineered, distributed, or reproduced in any manner to the extent allowed by law. Furthermore, the purchase of the Motorola products shall not be deemed to grant either directly or by implication, estoppel, or otherwise, any license under the copyrights, patents, or patent applications of Motorola or any third-party software provider, except for the normal, non-exclusive, royalty-free license to use that arises by operation of law in the sale of a product.

contents

menu map . . . . . . . . . . . . 8

Safety Information . . . . 10

Use and Care . . . . . . . . . 16

EU Conformance. . . . . . 17

Recycling Information. . 18

essentials . . . . . . . . . . . . 19

about this guide. . . . . . 19

SIM card . . . . . . . . . . . 19

battery . . . . . . . . . . . . . 20

turn it on & off. . . . . . . 22

make a call. . . . . . . . . . 23

answer a call . . . . . . . . 23

store a phone number

in the phonebook. . . . . 23

call a stored phone

number . . . . . . . . . . . . 24

contents

search the phonebook. 24 your phone number . . . 24

main attractions . . . . . . 26

SCREEN3 headlines . . 26

photos . . . . . . . . . . . . . 28

video clips . . . . . . . . . . 30

multimedia messages . 32 Bluetooth® wireless . . 34

basics . . . . . . . . . . . . . . . 39

display . . . . . . . . . . . . . 39

text entry . . . . . . . . . . . 42

volume. . . . . . . . . . . . . 46

navigation key . . . . . . . 47

smart key. . . . . . . . . . . 47

external display . . . . . . 47

handsfree speaker. . . . 48

codes & passwords . . . 49 lock & unlock phone . . 49

customize. . . . . . . . . . . . 50

ring style . . . . . . . . . . . 50

time & date . . . . . . . . . 51

wallpaper . . . . . . . . . . . 51

screen saver . . . . . . . . 52

themes . . . . . . . . . . . . 52

display appearance . . . 53

answer options . . . . . . 53

calls. . . . . . . . . . . . . . . . . 55

turn off a call alert . . . . 55

recent calls . . . . . . . . . 55

redial . . . . . . . . . . . . . . 56

return a call . . . . . . . . . 56

notepad . . . . . . . . . . . . 57

hold or mute a call . . . . 57

call waiting. . . . . . . . . . 57

caller ID . . . . . . . . . . . . 58

emergency calls . . . . . 58

international calls . . . . 58

1-touch dial. . . . . . . . . 59

voicemail . . . . . . . . . . 59

other features . . . . . . . . 61

advanced calling. . . . . 61

phonebook . . . . . . . . . 63

messages. . . . . . . . . . 67

instant messaging . . . 69

personalize . . . . . . . . . 70

call times & costs . . . . 72

handsfree . . . . . . . . . . 73

data & fax calls . . . . . . 74

network . . . . . . . . . . . 75

personal organizer . . . 76

security. . . . . . . . . . . . 77

fun & games. . . . . . . . 78

SAR Data. . . . . . . . . . . . 80

WHO Information . . . . . 82

index . . . . . . . . . . . . . . . 83

contents

main menu

Phonebook

Recent Calls

• Received Calls

• Dialed Calls

• Notepad

•Call Times

•Call Cost*

•Data Times

•Data Volumes

Messages

• Create Message

• Inbox

• MMS Templates

• Quick Notes

•Voicemail

• Email Msgs

• Outbox

•Drafts

• Browser Msgs *

• Info Services *

menu map

Bluetooth Link

Games & Apps

Web Access

•Browser

• Web Shortcuts

•Stored Pages

• History

•Go To URL

•Browser Setup

• Web Sessions

Multimedia

•Themes

•Camera

•Pictures

• Sounds

• Videos

• Video Camera

Tools

• SIM Apps *

• Calculator

• Datebook

• Shortcuts

• Voice Records

•Alarm Clock

• Dialing Services

• Fixed Dial

• Service Dial *

• Quick Dial

•IM *

Settings

• (see next page)

This is the standard main menu layout.

Your phone’s

menu may be different.

* optional features

settings menu

Personalize

• Home Screen

•Main Menu

•Skin

• Greeting

• Wallpaper

• Screen Saver

•Quick Dial

Ring Styles

•Style

• style Detail

Connection

• Bluetooth Link

•Sync

Call Forward

•Voice Calls

• Fax Calls

• Data Calls

• Cancel All

• Forward Status

In-Call Setup

• Dialing Prefix

• In-Call Timer

• Call Cost Setup *

• My Caller ID

• Talk and Fax

• Answer Options

• Call Waiting

Initial Setup

• Time and Date

• 1-Touch Dial

• Display Timeout

• Backlight

• TTY Setup *

•Scroll

• Language

• Brightness

•DTMF

• Master Reset

•Master Clear

Phone Status

• My Tel. Numbers

• Credit Info/Available *

• Active Line *

• Battery Meter

• Software Update

• Other Information

Headset

• Auto Answer

• Voice Dial

Car Settings

• Auto Answer

• Auto Handsfree

• Power-Off Delay

• Charger Time

Network

•New Network

•Network Setup

• Available Networks

• My Network List

• Service Tone

• Network Jingle

• Call Drop Tone

Security

• Phone Lock

• Lock Application

• Fixed Dial

•Call Barring*

• SIM PIN

• New Passwords

• Certificate Mgmt

Java Settings

• Java System

• Delete All Apps

• App Vibration

• App Volume

• App Priority *

• App Backlight

• Set Standby App *

•DNS IP*

* optional features

menu map

Safety and General Information

Safety Information

This section contains important information on the safe and efficient operation of your mobile device. Read this information before using your mobile device.

Exposure To Radio Frequency (RF) Energy

Your mobile device contains a transmitter and receiver. When it is ON, it receives and transmits RF energy. When you communicate with your mobile device, the system handling your call controls the power level at which your mobile device transmits.

* The information provided in this document supersedes

the general safety information in user’s guides published prior to September 1, 2005.

Safety Information

Your Motorola mobile device is designed to comply with local regulatory requirements in your country concerning exposure of human beings to RF energy.

Operational Precautions

For optimal mobile device performance and to be sure that human exposure to RF energy does not exceed the guidelines set forth in the relevant standards, always follow these instructions and precautions.

External Antenna Care

If your mobile device has an external antenna, use only a Motorola-supplied or approved replacement antenna. Use of unauthorized antennas, modifications, or attachments could damage the mobile device and/or may result in your device not

complying with local regulatory requirements in your country.

DO NOT hold the external antenna when the mobile device is IN USE. Holding the external antenna affects call quality and may cause the mobile device to operate at a higher power level than needed.

Product Operation

When placing or receiving a phone call, hold your mobile device just like you would a landline phone.

If you wear the mobile device on your body, always place the mobile device in a Motorola-supplied or approved clip, holder, holster, case, or body harness. If you do not use a body-worn accessory supplied or approved by Motorola, keep the mobile device and its antenna at least 2.5 centimeters (1 inch) from your body when transmitting.

When using any data feature of the mobile device, with or without an accessory cable, position the mobile device and its antenna at least

2.5 centimeters (1 inch) from your body.

Using accessories not supplied or approved by Motorola may cause your mobile device to exceed RF energy exposure guidelines. For a list of Motorola-supplied or approved accessories, visit our website at

www.motorola.com

RF Energy Interference/Compatibility

Nearly every electronic device is subject to RF energy interference from external sources if inadequately shielded, designed, or otherwise configured for RF energy compatibility. In some circumstances your mobile device may cause interference with other devices.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Safety Information

Follow Instructions to Avoid Interference Problems

Turn off your mobile device in any location where posted notices instruct you to do so. These locations include hospitals or health care facilities that may be using equipment that is sensitive to external RF energy.

In an aircraft, turn off your mobile device whenever instructed to do so by airline staff. If your mobile device offers an airplane mode or similar feature, consult airline staff about using it in flight.

Pacemakers

If you have a pacemaker, consult your physician before using this device.

Persons with pacemakers should observe the following precautions:

•

ALWAYS keep the mobile device more than 20 centimeters (8 inches) from your pacemaker when the mobile device is turned ON.

Safety Information

•

DO NOT carry the mobile device in the breast pocket.

•

Use the ear opposite the pacemaker to minimize the potential for interference.

•

Turn OFF the mobile device immediately if you have any reason to suspect that interference is taking place.

Hearing Aids

Some digital mobile devices may interfere with some hearing aids. In the event of such interference, you may want to consult your hearing aid manufacturer or physician to discuss alternatives.

Other Medical Devices

If you use any other personal medical device, consult your physician or the manufacturer of your device to determine if it is adequately shielded from RF energy.

Driving Precautions

Operational Warnings

Check the laws and regulations on the use of mobile devices in the area where you drive. Always obey them.

When using your mobile device while driving, please:

•

Give full attention to driving and to the road. Using a mobile device may be distracting. Discontinue a call if you can’t concentrate on driving.

•

Use handsfree operation, if available.

•

Pull off the road and park before making or answering a call if driving conditions so require.

Responsible driving practices can be found in the “Smart Practices While Driving” section at the end of this guide and/or at the Motorola website:

www.motorola.com/callsmart

Obey all posted signs when using mobile devices in public areas, such as health care facilities or blasting areas.

Automobile Air Bags

Do not place a mobile device in the air bag deployment area.

Potentially Explosive Atmospheres

Areas with potentially explosive atmospheres are often but not always posted, and can include fueling areas such as below decks on boats, fuel or chemical transfer or storage facilities, or areas where the air contains chemicals or particles, such as grain, dust, or metal powders.

When you are in such an area, turn off your mobile device, and do not remove, install, or charge batteries. In such areas, sparks can occur and cause an explosion or fire.

Safety Information

Damaged Products

If your mobile device or battery has been submerged in water, punctured, or subjected to a severe fall, do not use it until you take it to a Motorola Authorized Service Center. Do not attempt to dry it with an external heat source, such as a microwave oven.

Batteries and Chargers

If jewelry, keys, beaded chains, or other conductive materials touch exposed battery terminals, this could complete an electrical circuit (short circuit), become very hot, and could cause damage or injury. Be careful when handling a charged battery, particularly when placing it inside a pocket, purse, or other container with metal objects.

Motorola Original ™ batteries and chargers.

Caution:

To avoid risk of personal injury, do not

dispose of your battery in a fire.

Your battery, charger, or mobile device may contain symbols, defined as follows:

Safety Information

Use only

Symbol Definition

032374o

Important safety information follows.

032376o

032375o

Do not dispose of your battery or mobile device in a fire.

Your battery or mobile device may require recycling in accordance with local laws. Contact your local regulatory authorities for more information.

032377o

Li Ion BATT

032378o

Do not throw your battery or mobile device in the trash.

Your mobile device contains an internal lithium ion battery.

Choking Hazards

Your mobile device or its accessories may include detachable parts, which may present a choking hazard to small children. Keep your mobile device and its accessories away from small children.

Glass Parts

Some parts of your mobile device may be made of glass. This glass could break if the product is dropped on a hard surface or receives a substantial impact. If glass breaks, do not touch or attempt to remove. Stop using your mobile device until the glass is replaced by a qualified service center.

Seizures/Blackouts

Some people may be susceptible to epileptic seizures or blackouts when exposed to flashing lights, such as when playing video games. These may occur even if a person has never had a previous seizure or blackout.

If you have experienced seizures or blackouts, or if you have a family history of such occurrences, please consult with your physician before playing video games or enabling a flashing-lights feature (if available) on your mobile device.

Discontinue use and consult a physician if any of the following symptoms occur: convulsion, eye or muscle twitching, loss of awareness, involuntary movements, or disorientation. It is always a good idea to hold the screen away from your eyes, leave the lights on in the room, take a 15-minute break every hour, and stop use if you are very tired.

Repetitive Motion

When you repetitively perform actions such as pressing keys or entering finger-written characters, you may experience occasional discomfort in your hands, arms, shoulders, neck, or other parts of your body. If you continue to have discomfort during or after such use, stop use and see a physician.

Safety Information

Use and Care

To care for your Motorola phone, please keep it away from:

liquids of any kind dust and dirt

Don’t expose your phone to water, rain, extreme humidity, sweat, or other moisture.

extreme heat or cold cleaning solutions

Avoid temperatures below

-10°C/14°F or above 45°C/113°F.

microwaves the ground

Don’t try to dry your phone in a microwave oven.

Use and Care

Don’t expose your phone to dust, dirt, sand, food, or other inappropriate materials.

To clean your phone, use only a dry soft cloth. Don’t use alcohol or other cleaning solutions.

Don’t drop your phone.

European Union Directives Conformance Statement

EU Conformance

IMEI: 350034/40/394721/9

The above gives an example of a typical Product Approval Number.

Hereby, Motorola declares that this product is in compliance with:

•

The essential requirements and other

relevant provisions of Directive 1999/5/EC

•

All other relevant EU Directives

0168

Type: MC2-41H14

Product

Approval

Number

You can view your product’s Declaration of Conformity (DoC) to Directive 1999/5/EC (to R&TTE Directive) at your DoC, enter the product Approval Number from your product’s label in the “Search” bar on the Web site.

www.motorola.com/rtte

EU Conformance

. To find

Recycling Information

Caring for the Environment by Recycling

When you see this symbol on a Motorola product, do not dispose the product with household waste.

Recycling Mobile Phones and Accessories

Do not dispose of mobile phones or electrical accessories, such as chargers or headsets, with your household waste. In some countries or regions, collection systems are set up to handle electrical and electronic waste items. Contact your regional authorities for more details. If collection systems aren’t available, return unwanted mobile phones or electrical accessories to any Motorola Approved Service Centre in your region.

Recycling Information

essentials

about this guide

This guide shows how to locate a menu feature as follows:

Find it:

This example shows that, from the home screen, you press the menu key the menu, scroll to and select then scroll to and select

Press the navigation key highlight a menu feature. Press the center

select key

feature.

Press a >

s Recent Calls >Dialed Calls

s Recent Calls

Dialed Calls

to scroll to and

to select the highlighted menu

to open

symbols

This means a feature is network/subscription dependent and may not be available in all areas. Contact your service provider for more information.

This means a feature requires an optional accessory.

SIM card

Yo ur Subscriber Identity Module (SIM) card contains personal information like your phone number and phonebook entries.

Caution:

card. Keep it away from static electricity, water, and dirt.

Don’t bend or scratch your SIM

essentials

If necessary, press in the battery door release latch and remove the battery door.

Hold the SIM card with the notch in the lower left corner and the gold plate facing down. Slide the SIM card under the metal clip and into the card slot as shown.

essentials

battery

battery tips

Battery life depends on the network, signal strength, temperature, features, and accessories you use.

•

Always use Motorola Original batteries and chargers. The warranty does not cover damage caused by non-Motorola batteries and/or chargers.

•

New batteries or batteries stored for a long time may take more time to charge.

•

When charging your battery, keep it near room temperature.

•

When storing your battery, keep it uncharged in a cool, dark, dry place.

•

Never expose batteries to temperatures below -10°C (14°F) or above 45°C (113°F). Always take your phone with you when you leave your vehicle.

•

It is normal for batteries to gradually wear down and require longer charging times. If you notice a change in your battery life, it is probably time to purchase a new battery.

Contact your local recycling center for

032375o

proper battery disposal.

Warning:

Never dispose of batteries in a fire

because they may explode.

Before using your phone, read the battery safety information in the “Safety and General Information” section included in this guide.

battery installation

essentials

battery charging

New batteries are not fully charged. Plug the travel charger into your phone as shown. Plug the other end into an electrical outlet. Your phone might take several seconds to start charging the battery. The display shows finished.

essentials

Charge Complete

when

Tip:

Relax, you can’t overcharge your battery. It will perform best after you fully charge and discharge it a few times.

Note:

You can charge your battery by connecting a cable from your phone’s mini-USB accessory connector port to a USB port on a computer. Both your phone and the computer must be turned on, and your computer must have the correct software drivers installed. Cables and software drivers are available in Motorola Original data kits, sold separately.

turn it on & off

Caution:

prompt you to enter your SIM card PIN code to unlock the SIM card. If you enter an incorrect PIN code three times in a row, your SIM card is disabled and your display shows

SIM Blocked

On power up, the phone may

. Contact your service provider.

To turn on your phone, press and hold few seconds or until the display turns on. If prompted, enter your six-digit SIM card PIN code and/or four-digit unlock code.

To turn off your phone, press and hold two seconds.

for a

for

answer a call

When your phone rings and/or vibrates, just open the flip or press

To “hang up,” close the flip or press

Note:

Closing the flip doesn’t end a call when the handsfree speaker is turned on (for more information about the handsfree speaker, see page 48).

to answer.

make a call

Enter a phone number and press N to make a call.

To “hang up,” close the flip or press

Note:

Closing the flip doesn’t end a call when the handsfree speaker is turned on (for more information about the handsfree speaker, see page 48).

store a phone number in the phonebook

You can store a phone number in your

Phonebook

Note:

phone memory or on your SIM card. You can’t set a picture ID, ringer ID, or voice name for entries stored on the SIM card.

You can store a phonebook entry in

essentials

Enter a phone number in the home screen.

Press the

Enter a name and other details for the phone number. To edit details, scroll to them and press the center select key

Press the

To edit or delete a phonebook entry, see page 63.

To store an email address, press

a>n Phonebook a>New>Email Address

Store

Done

essentials

key.

key to store the number.

, then press

call a stored phone number

Find it: a >

Scroll to the contact.

Press N to call the contact.

n Phonebook

search the phonebook

To set the phonebook search method, press

a>n Phonebook

Search Method >Jump To

To search for a phonebook entry, press the keypad key that contains the first letter of the

Jump To

entry. the first entry that begin with the key’s letters.

Find

name or speed number for the entry, depending on how the phonebook list is sorted.

, then press a>

Find

method immediately jumps to

method prompts you to enter the

Setup

your phone number

From the home screen, press your number.

Tip:

Want to see your phone number while

you’re on a call? Press

To store or edit your name and phone number on your SIM card, press the

Edit

key while showing your number. If you don’t know your phone number, contact your service provider.

to see

a>My Tel. Numbers

essentials

main attractions

You can do much more with your phone than make and receive calls!

SCREEN3 headlines

A few minutes after you turn on your phone, headlines begin scrolling at the bottom of the home screen. You can subscribe to channels in different categories (such as news, sports, weather, and entertainment), and receive regularly updated headlines on the channels you select.

read headlines

To see the next or previous headline, press

right or left.

main attractions

To go to the next or previous headline channel, press and hold

To see more information about the current headline, press the center select key When viewing headline details, press or left to see details for the next or previous headline. If a full article is available, you can press the

key to see it.

right or left.

. right

change headline settings

In the home screen, press the to select the following headline options:

Setup Home

key

options

Headlines

Add New Channel

Turn headlines on or off.

Note:

Turning headlines off in the home screen does not cancel your paid subscriptions. You are still billed for current subscriptions.

Open a list of channel categories. To subscribe to a channel, select it from a category or select

Search Channels

to search for it.

options

Manage My Channels

Open a list of channels to which you subscribe. Select a channel to see its details and license information, cancel its subscription, or remove it from the list.

Note:

If you cancel a subscription, the channel stays in this list until you remove it or

What Are Headlines?

the subscription period ends. See a description of the

headline service.

main attractions

options

Home Keys

Display

Connections

main attractions

Show or hide feature icons in your home screen, or change the features for the soft keys and navigation key in the home screen.

Note:

Some of these feature settings are locked when headlines are turned on.

Change headline animation speed, home screen clock appearance, and home screen text layout.

Change your settings for downloading headlines, and see details of your last connection.

Note:

To manually update headline contents, select

Connection Details

, then

Refresh

photos

take a photo

Press a > camera viewfinder.

Press

up/down to

zoom in/out.

Press

left/right to

decrease/

exposure.

Point the camera lens at the photo subject.

Press the

h Multimedia >Camera

increase

Capture


AREA

Photo Viewfinder Memory Used: 70%

CaptureBack

Return to previous screen.

key to take a photo.

to see the

Photo Storage space used

Take a photo.

Press a to open

Pictures Menu

Press the option:

Apply as Wallpaper, Apply as Screen Saver Apply as Phonebook Entry

Press the and return to the active viewfinder.

If you choose to send the photo in a message, see “send a multimedia message” on page 32.

Note:

phonebook entry stored on the SIM card.

Options

key to select a storage

Send in Message, Store Only

Discard

key to delete the photo

You can’t assign a photo to a

, or

self portrait

When the camera viewfinder is active, you can close the flip to show the viewfinder image in the external display. Press the smart key (see illustration on page 2) to take a photo. Open the flip to store or discard the photo.

camera settings

When the camera viewfinder is active, press

to open the

following options:

options

Go To Pictures

Auto-Timed Capture

Image Style

Pictures Setup

View Free Space

See stored pictures and photos. Press operations (such as

Rename

Set a timer for the camera to take a photo.

Set a photo style (such as or

Adjust photo settings.

See how much memory remains for storing pictures.

Pictures Menu

to perform various

, or

Move

Black and White

to select the

Delete

) on a picture.

Color

main attractions

+ 150 hidden pages
