Motorola RAZR User Guide

MOTOROLA RAZR

Congratulations

MOTOROLA RAZR™

Introducing the powerful smartphone in a RAZR slim design! MOTOROLA RAZR has lots of advanced features for everything you want to do—video, web browsing, multimedia and more.

• A blistering fast dual-core 1.2 GHz processor lets you

download webpages in under a second, and makes multi-tasking a breeze.

• Use MotoCast to stream or download music, videos

and documents to your smartphone, and upload photos and files to your computer.

• Use your 8 MP camera to capture life's moments in

full 1080p HD video. Your smartphone's 4.3" qHD Super AMOLED Advanced display makes video playback crisper and more vivid than ever before.

Note: Certain apps and features may not be available in all countries.

Caution: Before assembling, charging or using your smartphone for the first time, please read the important safety, regulatory and legal information provided with your product.

This product meets the applicable limit for exposure to radio waves (known as SAR) of

2.0 W/kg (ICNIRP). The limits and guidelines include a substantial safety margin designed to assure the safety of all persons, regardless of age and health. The highest SAR values measured for this device are listed in the regulatory information packaged with your product.

Note: When using the product while worn on your body, either use an approved accessory, such as a holster, or maintain a distance of 2.5 cm (1 inch) from the body to ensure compliance with SAR requirements. Note that the product may be transmitting even if you are not making a phone call.

•Answers: Touch > Help centre.

• Updates: Smartphone updates, computer software,

user guides, online help and more at www.motorola.com/myrazr

• Accessories: Find accessories for your smartphone at

www.motorola.com/products.

1Congratulations

Notes:

11:23

Arturo Roman

JP Jordan

Tatia Tor rey

Kim Vonesh

Micro USB

connector

Micro HDMI

connector

HD webcam

Micro SIM slot

microSD slot

3.5 mm headset jack

Volume keys

Power key

Press = sleep hold = power

Back

Home

4.3" Super AMOLED Advanced Touchscreen

• All screens in this guide are simulated. Actual

displays may var y.

• Instructions to perform tasks in this guide may

change depending on the software version on your smartphone.

• Unless specified other wise, all instructions to

perform tasks in this guide assume that you are starting from the home screen.

Your smartphone

the important keys & connectors

ttp://www

BrowserEmail

Market

2 Your smartphone

Phone AppsText Camera

Note: Your smartphone might look a little different.

Let's go . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Touchscreen & keys. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Home screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Apps & updates. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Contacts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Messaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Text entry. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Social networking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Tips & tricks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Webtop application. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Digital living . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Photos & videos. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Music . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Web. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Personalise . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Wireless. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Memory card & file management. . . . . . . . . . . . . . . . . . . . . . . . 42

Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Management. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Product Safety & Legal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Let's go

let's get you up and running

Assemble & charge

Micro SIM in.

Note: Pull

down the access door to insert the

micro SIM and

microSD cards.

Note: This product uses a non-removable battery. The battery should only be replaced by a Motorola-approved service facility. Any attempt to remove or replace your battery may damage the product and void your warranty.

Charge up.

microSD in.

3Let's go

Tip: In the unlikely event that your device becomes

unresponsive, try a forced reboot—press and hold both Power and the down volume key for up to 10 seconds.

Tip: To save battery life, see "Battery tips" on page 24.

Set up & go

4 Let's go

Turn on.

Complete initial setup steps.

Data settings

The phone settings will be adapted to the data plan you have subscribed to.

Flat-rate data plan

Non-flat-rate data plan

Select a language.S

Welcome to MOTOROLA

Please choose a language

English (United Kingdom)

Add accounts.

Set up accounts

If you use any of the services below, tap the icon to set it up.

Corporate Sync Email Google

MotoCast ID

Note: This smartphone supports apps and services that use a lot of data, so make sure your data plan meets your needs. Contact your service provider for details.

Wi-Fi connect

If you want to use a Wi-Fi network for even faster Internet access, touch the status bar at the top of the home screen and drag it down. Touch the

networks available

notification to select a preferred

Wi-Fi

network.

You can also touch Menu > Settings > Wireless &

networks

> Wi-Fi settings to search for and connect to wireless networks. There's more in "Wi-Fi networks" on page 39.

Cool content & more

Browse and download thousands of the coolest apps on the planet from Android Market™.

Download new apps with "Browse & install apps" on page 10. An optional microSD memory card can be installed in your smartphone—you can fill it with photos, videos and music from your computer (see "micr oSD

memory card" on page 42).

Touchscreen & keys

a few essentials

Touchscreen on/off

Your touchscreen is on when you need it and off when you don't.

• When you hold the smartphone to your ear during

calls, your touchscreen sleeps to prevent accidental touches.

• To make your touchscreen sleep or wake up, just

press Power .

• To change how long your smartphone waits before

the screen goes to sleep automatically, touch Menu >

• To make the screen lock when it goes to sleep, see

"Screen lock" on page 50. To unlock the screen, press Power , then drag to the right.

Note: Your touchscreen might stay dark if the sensor just above it is covered. Don't use covers or screen protectors (even clear ones) that cover this sensor.

Settings > Display > Screen timeout.

Touch tips

It's all in the touch:

•Touch: Choose an icon or option.

• Touch & hold: Show options.

•Drag: Scroll or move slowly.

• Flick: Scroll or move quickly.

• Zoom: Slide fingers apart or together to zoom in or

out on Google Maps™, webpages or photos.

Displaying 297 contacts

In case of emergency

Abe Baudo

Allie Smyth

Abe Baudo

View contact

Anna Medina

Call contact

Astrid Fanning

Text contact

lark St

born St

Wacker Dr

E Randolph St

E Wacker Pl

State/lake

W Lake St W Lake St

Lake

Randolph/

Wabash

Touch & hold to show options.

N Michiga

Slide two fingers apart or together to zoom in or out.

Drag or flick to scroll.

5Touchscreen & keys

Key tips

Menu, home, back & search

Tou ch H o me t o close any menu or app and return to the home screen. On the home screen, touch and hold Home to show the most recent apps used, then touch an app to open it.

key

Home

key

Touch Menu to open menu options.

Touch Back to go back.

Touch Search for text search, or touch and hold for voice search.

Power key menu

Press and hold Power to open the power key menu, where you can turn off your smartphone (Power off), turn off all wireless connections and put the smartphone into low-power Sleep mode or turn Flight mode or Silent

mode

on and off.

6 Touchscreen & keys

Back

key

Adjust volume

Press the volume keys to change ring volume (on the home screen) or earpiece volume (during a call).

When playing music or video files, press the volume keys to adjust media volume.

Rotate the screen

When you turn your smartphone, the touchscreen can rotate to stay right-side up:

Find it: Menu > Settings > Display > Auto-rotate

screen

Quick tips

http

If you're not sure what to do next, try one of these:

To .. .

Get the details—Open a text

message, see details for a contact or open items in other lists.

See screen menu—Open a

menu for the current screen.

See item options—Open an

options menu (if available) for an item on the screen.

Start again—Go back to the

home screen.

Wake up your smartphone—Turn on a

sleeping touchscreen.

Reboot an unresponsive smartphone—Turn your

smartphone off then back on.

Touch the message, contact or item.

Touch Menu .

Touch & hold the item.

Tou ch H o me .

Press Power .

Press and hold both Power and the down volume key for up to 10 seconds.

Home screen

quick access to the things you need most

Quick start: Home screen

The home screen gives you all your latest information in one place. It's what you see when you turn on the smartphone or touch Home from a menu. It's basically like this:

11:23

Phone status bar

Tatia Torrey

://www.

BrowserEmail

Kim Vonesh

Market

Notifications

Drag this bar down to see details.

Flick left or right to see more panels of widgets & shortcuts.

Shortcuts

Touch to open.

Open the app menu.

JP Jordan

Arturo Roman

Phone AppsText Camera

7Home screen

Note: Your home screen might look a little different.

3pm

Budget Meeting

THU

JUL

The home screen extends left and right to give you more room for adding shortcuts, widgets and more. Flick the home screen left and right to see more panels or to add widgets or shortcuts.

Tip: From the home screen, touch Home to see thumbnails of the five home screen panels. Touch a thumbnail to go to the panel.

Use & change your home screen

On your home screen, shortcuts are icons that open your favourite apps, web bookmarks, contacts, mail labels or music playlists. Widgets show you news, weather, messages and other updates.

To see other panels of shortcuts and widgets, flick the home screen left or right. Or, touch Home and touch a thumbnail to go to the panel.

• To open something, touch it. Touch Home to

return to the home screen.

Tip: When you open a widget, touch Menu to see any options or settings (you can choose accounts for

8 Home screen

Calendar, Social networking, Social status or Universal inbox widgets).

There's more about social networking widgets in "Your social networking account" on page 22.

• To resize widgets, touch

and hold a corner until you feel a vibration, then drag.

• To add something or

THU

Kristine Kelley

Not even ready to

go back to school

Budget Meetin

change your wallpaper, touch and hold an empty spot until you see the

to Home

menu.

Add

You can add a folder to organise your shortcuts.

• To move or delete something, touch and hold it until

you feel a vibration, then drag it to another spot, another panel or the bin at the top of the screen.

Shortcuts in the dock row at the bottom of the home screen always appear in all panel views. You can change the dock shortcuts (except the app menu icon ). Touch and hold a dock shortcut, then select the shortcut you want to replace it.

Search

Touch Search , then use the window that appears.

Touch here to enter text.

Touch for more search options.

Touch to search by voice.

Smartphone status & notifications

Icons at the top of the screen notify you about messages and smartphone status. To view your notifications, touch the status bar and drag it down. Touch a notification to select it.

To dismiss a single notification, touch . To dismiss all notifications,

Clear

touch .

06 October 2012

Service provider

Notifications

Wi-Fi networks available

Select to open preferred n/w finder

Jim Somers

Meet me outside the...

New email

paul.wang6@gmail.com(2)

New voicemail

Dial *86

Tip: To see today's date, touch the status bar at the top of the screen.

11:23

Clear

14:47

14:45

14:41

Status bar icons

network (full signal) H+ (fastest data)

network (roaming) network (no

connection)

GPS active warning

Wi-Fi in range Wi-Fi connected

Bluetooth™ on Bluetooth

connected

USB connected background

data sync

active call missed call

flight mode microSD card

new text message alarm set

new email calendar event

reminder

new voicemail music player active

vibrate speakerphone on

sound off call muted

battery (charging) downloading

battery (full charge)

9Home screen

Tip: Blue connection icons (network, data, Wi-Fi) appear

when your smartphone is connected to your Google™ account. White connection icons mean your smartphone is not communicating with the Google servers.

Note: Applications you download from Android Market™ may show other icons in the status bar to alert you to specific events.

10 Apps & updates

Apps & updates

get the app you want

Quick start: Apps & updates

You can find all of your apps in one place. From the home screen, touch to open the app menu. To see all of your apps, flick left and right.

From the app menu, touch app groups.

All apps

New group

All apps

Recent

Downloaded

To close the app menu, touch Home or Back .

Browse & install apps

Get all the fun games and cool apps you want! Android Market™ provides direct access to apps, games and books that you can download and install on your smartphone.

All apps to view or create

Open the app groups menu.

Find new apps on Android Market™.

Create a new app group.

Choose which app group you want to see.

Find it: > Market

Scroll to and touch the app you want to install. Then, touch Install (if app is free) or Buy.

New apps that you install are added to the app menu.

Tip: Choose your apps and updates carefully, from trusted sites like Market, as some may have an impact on your smartphone's performance—see "Choose carefully" on page 11.

Note: When installing an app, make sure you read the alerts that tell you what information the app will access. If you don't want the app to have access to this information, cancel the installation.

Recent apps

Your smartphone remembers the apps that you used most recently. From the home screen, touch and hold Home to show the most recent apps used. From the app menu, touch >

Recent.

Manage & restore apps

From the home screen, touch Menu > Manage

apps

Touch an app in the list, then touch you downloaded), Clear cache or other options.

To reinstall apps from Android Market, touch > Market, then touch Menu > My apps. Apps

Uninstall (for apps

that you have previously purchased from Android Market are listed and available for download.

Choose carefully

Apps are great. There's something for everyone. Play, communicate, work or have fun. But remember, choose your apps carefully. Here are a few tips:

• To help prevent spyware, phishing or viruses from

affecting your smartphone or privacy, use apps from trusted sites, like

• In Market, check the apps' ratings and comments

before installing.

• If you doubt the safety of an app, don't install it.

• Like all apps, downloaded apps will use up memory,

data, battery and processing power—some more than others. For example, a simple battery level widget will use less than a streaming music player app. After installing an app, if you're not happy with how much memory, data, battery or processing power it's using, uninstall it. You can always install it again later.

• Just like web browsing, you may want to monitor

children's access to apps to help prevent exposure to inappropriate content.

• Certain apps may not provide completely accurate

information. Take care, especially when it comes to personal health.

Market.

11Apps & updates

Update my smartphone

You can check, download and install smartphone software updates using your smartphone or your computer:

• Using your smartphone:

You may get an automatic notification of an available update on your smartphone. Simply follow the instructions to download and install.

To manually check for updates, touch Menu >

Settings > About phone > System updates.

Your smartphone downloads any updates over your mobile network. Remember, these updates can be quite large (25 MB or more) and may not be available in all countries. If you don't have an unlimited data plan, or mobile network updates are not available in your country, you can update using a computer.

• Using your computer:

On your computer, go to www.motorola.com/myrazr and check the "Software" links. If an update is available, follow the installation instructions.

12 Calls

Calls

it's good to talk

Quick start: Calls

Dialling options

From the home screen, touch Phone.

Dialler FavouritesRecent

Most recent

Julie Smith

Mobile 1-555-555-5555 1 hour ago

GHI

PQRS

Contacts

ABC

JKL

TUV

Recent calls list

Touch an entry to call.

Return call

Backspace

Delete digits you entered.

DEF

MNO

Add number to contacts

WXYZ

Call

Enter a phone number & touch here to call it.

Voice dial

Tip: Search for contacts straight from the dial pad! For

Mobile 555-555-457

example, to find

Jeff in your contacts list, touch 5-3-3-3.

Matching contacts appear above the number field.

In-call options

Connected

Add call Dial padEnd call

To use a Bluetooth™ device, touch Bluetooth. (The device must be turned on and previously paired—see "Connect new devices" on page 41.)

00:12 service provider

Victor Harp

Mobile 555-555-4570

MuteBluetooth Speaker

Call timer

End call

Hang up.

Dial pad

Enter numbers during a call.

Speakerphone

Turn the speakerphone on or off.

Mute

Mute or unmute the call.

Tip: You can touch Home or Back to leave the active call display. To reopen it, touch Home >

Phone.

Note: Using a mobile device or accessory while driving may cause distraction and may be illegal. Always obey the laws and drive safely.

Make & answer calls

To make a call, touch Phone, enter a number, then touch .

Tip: If the screen is locked, drag to the right first.

To answer a call when the screen is active, touch . When the screen is locked, answer by dragging to the right.

To ignore a call when the screen is active,

Ignore

touch . When the screen is locked, ignore the call by dragging to the left. Your smartphone gives you the option to send a text message to the caller. Select a message and touch

OK to send it, or

touch Cancel to exit without sending a message.

Text message reply

Create new message

"Sorry I was unable to answer your call"

"Please call me again in a few minutes"

"I will call you back in a few minutes"

Turn off text message reply

OK Cancel

Answer

13Calls

Tip: To silence an incoming call alert, press Power or

the volume keys.

Note: When you hold the smartphone to your ear, the display goes dark to prevent accidental touches. When you move the smartphone away from your ear, the display lights up again.

Recent calls

Find it: Phone > Recent

• To select a call list, touch and select All calls,

Missed calls, Incoming calls or Outgoing calls.

• To call a number, touch next to the entry.

• To send a text message, create a contact, view a

contact or other options, touch and hold an entry.

• To clear the list, touch Menu >

Clear list.

Frequent calls

Find it: Phone > Favourites

• To view contact information, touch the contact.

• To call a contact, touch it, then touch next to the

entry.

• To text, email or see other options, touch and hold the

contact.

• To add a contact to your Favourites list, touch and hold

the contact, then touch

14 Calls

Add to favourites.

Conference calls

To start a conference call, call the first number. After the call connects, touch Add call. Dial the next number, or select it from contacts or favourites. When the next number answers, touch Merge.

Your phone number

Find it: Menu > Settings > About phone > Status > My phone number

TTY mode

Your smartphone can use an optional teletypewriter (TTY) device, for people who are hard of hearing or have a speech impairment.

1 Plug the TTY device into the smartphone's headset

jack.

2 Touch Menu >

mode

, and choose a TTY setting.

Settings > Call settings > TTY

Emergency calls

Note: Your service provider programs one or more emergency phone numbers that you can call under any circumstances, even when your smartphone is locked. Emergency numbers vary by country. Your pre-programmed emergency number(s) may not work in all locations, and sometimes an emergency call cannot

be placed due to network, environmental or interference issues.

1 Touch Phone (if your smartphone is locked, touch

Emergency call).

2 Enter the emergency number.

3 Touch to call the emergency number.

Note: Your smartphone can use location based services

(GPS and AGPS) to help emergency services find you. See "Location services" on page 56.

Cool down

In very limited circumstances, such as where your smartphone has been exposed to extreme heat, you may see "Cool Down" messages. To avoid possible damage to your battery and smartphone, you should follow these instructions until the smartphone is within its recommended temperature range. When your smartphone is in "Cool Down" mode, only emergency calls can be made.

Contacts

contacts like you've never had before

Quick start: Contacts

Find it: > Contacts

FavouritesRecent

Dialler

Displaying 297 contacts

In case of emergency

Contacts

Abe Baudo

Allie Smyth

Anna Medina

Astrid Fanning

Tip: To search the list, touch to open a touchscreen keypad, then type a name. When you flick or drag the list, a scroll bar appears that you can drag to move the list faster.

Group

Create & view groups of contacts.

# A B

Add contacts.

C D E F G H

Contacts list

I J

Touch to view contact

K L

information. Touch & hold

M N

to call, send a text message

O P

& more.

Q R S T U

Touch a letter to jump to

V W

contact names that start

with the letter.

15Contacts

Transfer contacts

Get all your contacts, all in one place. Here are a few helpful hints:

• Use Gmail™

All your Gmail contacts will automatically be synced to your smartphone. Various computer applications for mobile phones and email accounts allow you to export your contacts as a ".CSV" file. You can then use Gmail to import the file. For more details, go to www.motorola.com/transfercontacts Gmail account on your computer and select "Help".

• More

There are other methods and tools to help you at www.motorola.com/transfercontacts

or log into your

Link contacts

You might have two or more contacts for the same person, this could be a Gmail contact who is also stored on your smartphone, or one friend with two email addresses. To combine these contacts:

Find it: > Contacts

Touch a contact to open it, touch Menu > Join, then touch the second contact.

16 Contacts

Call or email contacts

Find it: > Contacts

• To view contact information, touch the contact.

• To call a contact, touch it, then touch next to the

entry.

• To text, email or see other options, touch and hold the

contact.

View & use contacts

When you set up a social networking account (see "Social networking" on page 22), you'll know what everybody's up to and when. Every time you answer a call, check a message or look up a friend's contact info, you'll see their name and number, but you can see their social network status and smiling face too.

Find it: >

• To find a contact, touch in the Contacts screen and

type the contact name.

Touch a contact to open its details. While viewing details, you can start a call or message by touching icons next to the phone number, email address or social network. To see your interactions with the person, touch

• To change which group of contacts is shown (All,

Facebook and so on), touch the filter name at the top.

Contacts

Contact history.

• To change how you view the list of contacts, touch

Menu >

Display options.

Create contacts

Find it: > Contacts >

Add contact

Google contact

from youraccount@gmail.com

Select a picture

First name

Last name

Phone

Home

Phone

Home

Postal address

Organisatio

Save Cancel

Touch any entry area to open the touchscreen keypad.

When you've finished, touch

for the contact.

Add more name details.

Add another number.

Remove this number.

Set the number type.

Save.

Where are contacts saved? Your smartphone saves

new contacts in its memory and on the Google Ser ver, if you have an account. It also updates your social networking account.

Favourites

To add a contact to your Favourites list, touch and hold the contact, then touch Add to favourites.

To see your Favourites list:

Find it: > Contacts > Favourites

Edit or delete contacts

Find it: > Contacts

Touch and hold the contact, then touch Edit contact or

Delete contact.

Synchronise contacts

When you change one of your contacts, your smartphone automatically updates your other social networking accounts. When you change a social networking friend, your smartphone updates your contacts.

17Contacts

Personalise contacts

Find it: > Contacts

Add a photo: Touch and hold the contact, then touch

Edit contact > .

Set a ringtone: Touch the contact, then touch Menu

> Options > Ringtone.

Groups

Find it: > Contacts > > group name

You can put your contacts into groups that you create (like "friends", "family" or "work"). You can then find contacts faster by showing one group at a time.

To create a new group, touch touch Menu > New group.

18 Messaging

Contacts > , then

Messaging

sometimes it's best to text, IM or email. . .

Quick start: Messaging

Find it: > Messaging > Universal inbox

Universal inbox (14)

Anna Medina

Copy revisions Please take a look at the new revisions and let...

Jim Somers

Meet me outside the theatre at 8 and don't don't forget your ID. Would you maybe like to...

Arther Bando

Meeting invitation Meeting is set for next Thursday at 10:00 am...

Jon Anderson

Your last message I'm fine with that.

Mary Morgan

Freelancers We're going to need help with the new interns...

Tip: To see more messages, flick or drag up.

Read & reply to messages

Find it: > Messaging > Universal inbox

Note: Universal inbox shows all of your messages

together—text, email and social networking messages.

Check for messages now.

Create messages.

19:39

Message type

17:47

Message list

14:45

Touch to open a message. Touch & hold to move, delete and more.

14:19

11:41

To show only one type of message, touch a message

type instead of

Universal inbox.

• To open a text message or social networking

message and all of its replies, touch it.

• To respond to a text message, just open it and enter

your response in the text box at the bottom.

For email, touch to choose a reply option.

• To forward an email message, open it and touch

Forward.

• To open options, touch and hold a message.

Create messages

Find it: > Messaging >

Choose a message type, such as Text message or

Facebook. Then enter the recipient and message. In text

messages and emails, touch Menu for options like

Insert... or Attach files.

Send & receive attachments

To send a file in a message, open a new message and touch Menu > Insert.

When you receive a message with an attachment, open the message and touch the file name to download it. Then, touch the name again to open it. Some file formats can be converted to HTML for faster viewing, and your smartphone will show

Get HTML version.

While viewing the attachment, touch it to save it, share it and more.

Tip: To send and receive large attachments faster, use a Wi-Fi connection (see "Wi-Fi networks" on page 39).

Set up messaging

To add email accounts, touch > Accounts > Add

account

• Corporate Sync is for Exchange server work email

accounts. Enter details from your IT administrator.

Tip: You might need to enter your domain name with your username (like domain/username).

•

Email is for most personal email accounts. For

account details, contact the account provider.

To change your settings, touch > Messaging, touch Menu , then touch:

•

Manage accounts to add or remove an account.

• Edit Universal inbox to choose which accounts show

messages in the Universal inbox.

• Messaging settings to set the notification for each

account type (along with other preferences, for email).

Tip: For social network accounts, see "Add accounts" on page 22.

ccount Manage

19Messaging

Email

The first time you turned on your smartphone (see "Set up & go" on page 4), you probably logged into your

Gmail™ account. You can also set up and use additional email accounts.

To add other email accounts to your Messages widget and

Universal inbox, touch > Accounts > Add

account

> Email.

ccount Manage

Instant messages

To send and receive instant messages, you can use Google Talk™.

Find it: >

Talk

Tip: You can also download an instant messaging app from Android Market™.

Voicemail

When you have a new voicemail, appears at the top of the screen. Drag down the status bar and touch the

New voicemail notification to listen to your voicemail

message.

If you need to change your voicemail number, on the home screen touch Menu > > Voicemailsettings.

20 Text entry

Settings > Call settings

Text entry

keys when you need them

Touchscreen keypad

You can open a keypad on your screen by touching a text box. To close the keypad, touch Back .

Text box

Touch to open the

Dinner at Bistro Fanta

21 09876543

ertyuiopqw

asdfghjk l

zxcvbnm

?123

Open a keypad for numbers & symbols.

Input methods

To select an input method, touch and hold a text entry area on the screen to open the

Input method, then touch the method you want.

touchscreen

Done

keypad.

Shift

Voice input/dictation

Delete

Return/ new line

Space

Edit text menu. Touch

Swype™ text entry

asdfgh j kl

xcvbnm

ert yuiopqw

21 09876543

(

)

;

= @ #

To enter a word, just trace a path through the letters. To capitalise, go above the keypad. For double letters, circle the letter.

Enter words with one continuous motion. Just drag your finger over the letters in the word.

Anne

Tips:

• To enter apostrophes in common words (like "I'll"),

drag through the

n as though it was an apostrophe.

• To enter other punctuation, numbers or symbols,

touch Symbols .

• To correct a word, double-touch it (tap twice, quickly).

Swype shows a small menu of other word options. Swype might also show a menu if it can't guess your word.

• If Swype doesn't know a word, you can still touch the

letter keys to enter it. Swype remembers, so next time you can just drag over the letters.

Done

Multi-touch keyboard

Enter text a letter at a time. As you type, your smartphone suggests words from your dictionar y and chosen language. The smartphone also automatically enters apostrophes in some words, like "dont".

To add a word to your dictionary, touch and hold the word, then select

Add "word" to dictionary.

Typing tips

To...

Enter one capital letter

Enter only capital letters, until you touch Shift again

Move the text entry

cursor

Select text Touch and hold text, then

Cut or Copy selected

text

Touch Shift .

Touch Shift twice. Touch again to revert to lowercase.

Touch the text where you want the cursor to go.

touch

Select word or Select

all

Touch and hold text, then touch

Cut or Copy.

21Text entry

To .. .

Paste cut or copied

text at cursor location

Delete character to left

of cursor

Touch and hold location to paste, then touch

Paste.

Touch Delete (hold to delete more).

Text input settings

Find it: Menu > Settings > Language & keyboard

• To edit your dictionary, touch User dictionary.

• To change the language and the style for your

touchscreen keypad, touch

• To change input method and settings, touch Swype or

Multi-touch keyboard.

22 Social networking

Select locale.

Social networking

my life, your life

Your social networking account

Integrate and sync all your contacts, emails and social networking sites. No opening and closing apps and menus. Just touch the

status

widgets on your home screen.

Tip: Use the gallery to view all of yours and your friends' online albums. Touch > Gallery.

Add accounts

You can add your Facebook, Twitter or other accounts to your social networking account. If you don't have accounts on these sites, visit their websites to set them up.

To set up email accounts, see "Set up messaging" on page

19.

Find it: >

Add an account by touching it. Then enter your username and password for that account.

When you sign into social networking accounts, you'll see your friends and contacts in your your status and updates can appear in your Social

networking

widget.

Social networking and Social

Accounts > Add account

ccount Manage

Contacts list, and

Twitter messages will always appear as "read" on your

smartphone, but your smartphone notifies you when you receive a new message.

Tip: To download updates faster, see "Wi-Fi networks" on page 39.

Edit & delete accounts

Find it: > Accounts

Touch an account to edit it or remove it (along with its contacts and messages).

Note: You can't delete the Google™ account you used or created when you set up your smartphone.

Account Manage

Tips & tricks

a few handy hints

General tips

• Screen brightness changes as your smartphone

senses the current lighting conditions.

• To return to the home screen, touch Home .

• To see recently dialled numbers, touch

> Recent.

• To sleep/wake your smartphone, press Power .

• To set screen timeout, touch Menu >

> Display > Screen timeout.

• To search, touch Search . To voice search, touch

and hold Search .

• To automate everyday tasks, touch > Smart

actions

• To show the most recent apps you've used, touch and

hold Home .

• To change one of the dock shortcuts at the bottom of

the home screen, touch and hold the shortcut, then select the shortcut you want to replace it.

• To turn sound on/off, press and hold Power

Silentmode.

• To turn flight mode on/off, press and hold Power

Flight mode.

Phone

Settings

23Tips & tricks

Battery tips

Want to extend your battery life? Try these:

• Use the Smart Actions app to manage smartphone

settings and help minimise battery use. For more information, touch > Smart actions, then touch Menu > Help.

• To turn off background data transfers, touch Menu

Settings > Data manager > Background data.

• To turn off Bluetooth™ power, touch Menu

> Settings > Wireless & networks > Bluetooth.

• To turn off Wi-Fi power, touch Menu > Settings

Wireless & networks > Wi-Fi.

Webtop application

smart mobile computing

Quick start: Webtop

Browse or use web apps, on a large screen in a full Firefox™ browser. Create and share documents, spreadsheets and presentations with online tools like Google Docs.

To open the webtop application, connect your smartphone to an HDTV or monitor using a dock accessory (sold separately).

Optional LapDock or HD dock

LapDock display, HDTV or monitor

Mobile view

Account manager

24 Webtop application

App tray Full desktop

browser

Connect the webtop application

Connect your smartphone to a Motorola LapDock™ to automatically launch the webtop application.

Connect your smartphone to an HDTV or monitor using the HD dock, HD station or adapter for webtop application, then choose the webtop application from the application menu.

When you've finished using the webtop application, just disconnect your smartphone from the accessory.

Control the webtop application

To navigate the webtop application display:

• In the Phone window, you can open your

smartphone apps.

• At the bottom of the screen, you'll see App shortcuts.

You can open multiple Firefox browsers.

• At the top right of the screen, you'll see icons for

status and

For help in the webtop application, open Settings > Help at the top right of the screen.

Settings.

Send current webpage to phone

When you find an interesting webpage in the webtop application, you can send it to your smartphone to view after undocking. In the Firefox browser, select File > Send to phone. If prompted to complete the action, select Browser. The webpage opens in your smartphone browser.

25Webtop application

Digital living

connect and enjoy

MotoCast

Stream or download music, pictures, videos and documents from your computer directly to your smartphone. MotoCast lets you pull content from your home or work computers at blazing-fast speeds, providing secure, nearly instant remote access to your files.

Note: Copyright—do you have the right? Always follow the rules. See "Content copyright" in your legal and safety information.

Device setup

To get started, touch > Accounts > Add account > MotoCast ID, and follow the on-screen instructions to create an account on your smartphone.

Desktop setup

MotoCast can be installed on one or more Microsoft™ Windows™ or Apple Macintosh computers to stream and download files. Your smartphone contains the application that needs to be installed on your computer. Connect your smartphone to the computer with a USB cable and follow the on-screen instructions to install the application. When installed, log in to the

26 Digital living

Account Manage

same account you created on your smartphone, then select which computer files you want to share.

Use remote files

You can use your smartphone's Music, Gallery and Files apps to access the shared files stored on your computer.

HD viewing

You can create your own HD videos (see "HD videos" on page 29) to view on your widescreen HDTV or monitor.

1 Connect a micro HDMI cable (sold separately) from

the micro HDMI port on your smartphone (see "Your smartphone" on page 2) to an HDMI port on the HDTV

or monitor.

2 Adjust the viewable area on the HDMI screen by

touching Menu >

Settings > HDMI.

Mirror mode

Connect your smartphone to your HDTV, monitor or projector so you can view and interact with your smartphone on the big screen. Show off your photos, videos and downloaded films. Enjoy the big screen for gaming, films, the web and more. Just connect your smartphone to an HDTV or monitor using a micro HDMI cable (sold separately). Everything you see on your display will appear on the big screen as well.

Photos & videos

756 San Francisco, CA

see it, capture it, share it!

Photos

Take & share photos

Take that family photo, and post it online for everyone to see.

Find it: > Camera

See your

last photo.

Shots remaining

756 San Francisco, CA

Adjust camera

settings.

Zoom in/out.

Auto-focus box

Touch screen to change

focus location.

Switch between front

& back cameras.

Tak e

photo.

Switch to

camcorder.

Note: Photos are stored in your smartphone's internal memory, unless you switch it to the microSD memory card. Photo resolution can be set to 8 MP or

Widescreen (6 MP).

Tip: Press the volume keys to zoom in and out on the viewfinder image.

To take the photo, touch in the viewfinder screen.

Your smartphone stores the photo, and shows a thumbnail image in the corner of the screen. To see the photo you just took, touch the thumbnail. Then:

• To set the photo as a wallpaper, contact photo or

social network photo, touch Menu >

Set as.

• To send the photo in a message or post it online,

touch . For more info on sharing your photos, see "Share photos & videos" on page 30.

• To upload the photo to an online photo album,

touch .

• To print the photo, touch Menu >

More > Print.

• To delete the photo, touch Menu > Delete.

Panoramic photos

In the viewfinder, touch Menu > Modes > Panorama to take a wide panoramic photo. The camera auto-captures up to six multiple shots as you move the camera, and joins them together to make one large image.

27Photos & videos

Camera settings

HD 00:13:50 San Francisco, CA

In the viewfinder, drag the tab in the lower-left corner of the screen (or touch Menu ) to adjust camera settings:

Options

Settings • Widescreen (6 MP) or 8 MP photo

Effects

Scenes Set the type of photo you want to

Modes Set to Single shot, Panorama,

Exposure Select an exposure setting.

Flash Set Flash on, Flash off or Auto-flash.

28 Photos & videos

resolution

•

Video resolution

• Storage location (smartphone or

microSD memory card)

• Geo-tag (auto-location information)

•

Video stabilisation

• Shutter tone

Set a photo effect: Normal, Black and

white

, Negative and more.

take: Auto, Portrait, Landscape, Sport and more.

Multi-shot or Timer.

Videos

Record & share videos

Find it: > Camera, then touch or drag the camera switch to the right to select the camcorder

Watch your

last video.

Time

remaining

HD 00:13:50 San Francisco, CA

Adjust camcorder

settings.

Zoom in/out.

To record a video, touch in the viewfinder screen. To

stop the video recording, touch again.

Switch between front

& back cameras.

Record

video.

Switch to

camera.

Your phone stores the video, and shows a thumbnail image of the video in the corner of the screen. To see the video you just took, touch the thumbnail. Then:

• To play the video, touch .

• To send the video in a message or post it online,

touch . For more info on sharing your video, see "Share photos & videos" on page 30.

• To upload the video to an online album, touch .

• To delete the video, touch Menu >

Delete.

HD videos

You can capture HD-quality videos to watch on an HDTV or monitor.

To record an HD-quality video, make sure you select the correct

Video resolution. From the active camcorder

viewfinder screen, touch Menu > Settings > Video

resolution

To enhance the video quality, touch Menu > Audio

scenes

> HD+ (1080p) or High definition (720p).

or Effects.

Camcorder settings

In the viewfinder, drag the tab in the lower-left corner of the screen (or touch Menu ) to adjust camcorder settings:

Options

Settings • Widescreen

• Video resolution (1080p, 720p,

DVD, VGA or QVGA)

• Storage location (smartphone or

microSD memory card)

• Geo-tag (auto-location information)

•

Video stabilisation (reduce

shakiness during video capture)

• Shutter tone

Effects

Audio scenes

Modes Set to Normal video or Video

Exposure Select an exposure setting.

Light Turn the camcorder light on or off.

Set a video effect: Normal, Black and

white

, Negative and more.

Set sound recording options: Stereo,

Wind reduction or Concert, Balanced

or Front facing.

message

29Photos & videos

View photos & videos

Find it: > Gallery

View all of your photos and your friends' photos/videos from different media sites like Picasa™, Flickr, PhotoBucket and Facebook™. You can add comments to others' photos, and see comments that others have posted. You can even view photos stored on your computer with MotoCast.

Add photos and videos to your phone

richie

Uploaded a photo Yesterday

My library Online.

Friends MotoCast

30 Photos & videos

Uploaded a photo Yesterday

Camera roll

richi

Uplo Yeste

Go to your friends'

online albums.

Sort your photos & videos.

See your captured photos & videos.

See your online albums (like Picasa, Flikr or Facebook).

Stream media from your computer with MotoCast.

Note: To see the controls when a video is playing, touch the display.

Share photos & videos

Find it: > Gallery > photo or video

Touch , then choose how you want to share—for example Bluetooth, Email, Text messaging or an online album.

Manage photos & videos

Find it: > Gallery > photo or video

Touch Menu , then select Edit, Delete, Add to

album

, Set as (photo) or Map (video). Touch More for

additional options.

Tip: To copy photos to/from a computer, go to "USB connection" on page 43.

Edit photos & videos

Find it: > Gallery > photo or video

Touch Menu > Edit. You can choose advanced editing features to resize, crop or change the colour.

Stream & sync photos & videos

Use MotoCast to stream photos and videos from your computer to your smartphone.

Find it: > Gallery > MotoCast

For more information about using MotoCast, see "MotoCast" on page 26.

Music

when music is what you need...

Quick start: Music

Keep your music with you! You can put music on your smartphone, or stream music from your computer with MotoCast.

Find it: >

Music

Add music to your phone

To play music stored on your smartphone or computer, touch

My library.

Open the categories menu.

Stream music from your computer with MotoCast.

Artists

Brooks Fairfa

Brooks Fairfax

2 songs

songs

Artists Albums

Jon Levy

on Levy

3 songs

songs

GenresPlaylists

Lisa Palleschi

isa Palleschi

14 songs

Max Keppler and AnnaLee...

12 songs

Songs

Search the music library.

Set up music

What music transfer tools do I need?

Note: Copyright—do you have the right? Always follow the rules. See "Content copyright" in your legal and safety information.

To put music on your computer and then load it on your smartphone, you need:

• Microsoft® Windows® computer or Apple Macintosh

computer.

• USB data cable (included with your smartphone).

Your smartphone supports removable microSD memory cards up to 32 GB capacity. To install an optional microSD card, see "Assemble & charge" on page 3.

Tip: To see the available memory on your microSD card, from the home screen touch Menu > > Storage.

What audio file formats can I play?

Your smartphone can play many types of files: AAC, AAC+, AAC+ Enhanced, AMR NB, AMR WB (not supported in all countries), MP3, WAV, WMA v9 and MIDI.

What headphones can I use?

Your smartphone has a 3.5 mm headset jack for wired stereo listening. You can go wireless with Bluetooth®

32 Music

Settings

stereo headphones or speakers (see "Blu etooth™ hands-free devices" on page 41).

Get music

Transfer

Transfer music from your computer to your smartphone using a USB cable connection. See "USB co nnection" on page 43 to learn how.

Stream & sync

Use MotoCast to stream music, podcasts and audio files from your computer to your smartphone.

Find it: >

For more information about using MotoCast, see "MotoCast" on page 26.

Music > Add music to your phone

Play music

Touch a song or playlist to start playing music.

Max Keppler and AnnaLee Scott

When you're around

Running roughshod

Song lyrics—Current line

Song lyrics—Next line

Artist & song title

Artist information

Album artwork

Song lyrics scroll up as the song plays.

Playlist

Music controls

Create playlist

Music player controls

To...

Play/pause To u c h / .

Select previous/next

Tou ch / .

song

Fast forward/rewind Touch and hold / .

View playlist To u c h .

Shuffle on/off Touch > .

Repeat all/off Touch > .

Adjust volume Press side volume keys.

Go to music home screen

Touch Menu >

home

Music

Manage speakers Touch Menu > More

Settings > Audioeffects.

Add song to playlist Touch Menu > More

> Add to playlist.

Use as ringtone Touch Menu > More

> Useasringtone.

Delete Touch Menu >

> Delete.

33Music

Hide, wake, turn off

Touch Home to use another app. Your music will continue to play.

When you see in the status bar, a song is playing. Flick down to see details. Touch the song to return to the music controls.

To turn off your music, touch .

Playlists

To add a song from the music library to a playlist, touch and hold the song, then touch Add to playlist. Choose an existing playlist, or touch Create playlist to create one.

To rename, edit and delete playlists, touch and hold the playlist in the music library.

Web

surf the web with your smartphone

Quick start: Browser

http//www

Find it: Browser

http://www.google.com/...

Web Images Places News more

Turn onInstant (beta) is off:

Restaurants Coee Bars More

Touch a link to select it. Touch & hold for more options.

34 Web

SettingsiGoogle Help

ForwardRefresh

WindowsNew window Bookmarks

Touch Menu for browser options.

Tip: To zoom, touch the display with two fingers, then move them apart.

Connect

Your smartphone uses the mobile phone network (over the air) or a Wi-Fi connection to automatically access the web.

Note: Your service provider may charge you to surf the web or download data.

If you want to use a Wi-Fi network for faster Internet access, touch the status bar at the top of the home screen and drag it down. Touch the

available

more info, see "Wi-Fi networks" on page 39.

Note:

notification to select a preferred network. For

If you can't connect, contact your ser vice provider.

Wi-Fi networks

Browser options

Touch Menu to see browser options:

Options

New window Open a new browser window.

Bookmarks See your bookmarks.

Windows View open browser windows.

Refresh Reload the current page.

Forward Go forward through viewed pages

(touch Back to go back).

More View additional browser options.

Play web videos

The browser features the Adobe™ Flash™ Player, which adds animation, video and interactivity to webpages. Touch to begin video playback. Double-touch the video to enlarge it for better viewing.

Downloads

To download files in your browser, touch a file link or touch and hold a picture to choose Save image.

To see the files you downloaded, touch >

Downloads. Touch and hold an item to open it,

see details or remove it from the list.

You can download "Apps & updates" on page 10.

YouTube™

Share videos with YouTube users everywhere. You don't need a YouTube account to browse and view videos.

Find it: > YouTube

Note: If you want a YouTube account, go to

www.youtube.com. To create an account or sign in, touch Menu > My channel. To Browse or Upload videos, touch Menu .

35Web

Personalise

add your personal touch

Widgets

Add widgets

1 Touch and hold an empty spot on your home screen.

Tip: Flick left or right to see other panels.

2 Touch Widgets and choose a widget.

Set up widgets

You can customise some widgets. Touch a widget to open it, then touch Menu .

Your home screen may already have these widgets:

• Favourite contacts: Quickly call, text or email your

favourite cont acts. To add contacts to your Favourites list, see "Favourites" on page 17.

•

Universal inbox: Change the widget name or choose

how long it shows new messages. To add email accounts, "Set up messaging" on page 19.

• Calendar: Sync your calendars and review upcoming

events at a glance with the scrollable calendar widget. To add calendar events, see "Calendar" on page 44.

•

Music: Set this widget to an artist, album, song,

playlist, genre or just touch Menu > Shuffle all. There's more about "Music" on page 31.

36 Personalise

• News: Change the widget name, choose how long it

shows new stories or choose a news source. To choose a source, touch , then choose preset

Bundles or Channels or choose Custom to enter a

URL for a webpage or an RSS feed.

• Weather: Change temperature units or add locations.

To add locations, touch , enter a city and touch

Search. When you open the weather widget, flick left

to see other locations you have added.

Shortcuts

To add shortcuts for apps, bookmarks and more to the home screen, touch and hold an empty spot on the home screen, touch

Tip: To change one of the dock shortcuts at the bottom of the home screen, touch and hold the shortcut, then select the shortcut you want to replace it.

Shortcuts and select a shortcut.

Ringtones

Personalise your ringtones:

Find it: Menu > Settings > Sound > Phone ringtone or Notification ringtone

To set your vibrate options:

Find it: Menu > Settings > Sound > Vibrate

To set a song as a ringtone:

Find it: > Menu > More > Use as ringtone

Music and play the song, then touch

Wallpaper

Apply a new wallpaper:

1 Touch and hold an empty spot on your home screen.

2 Touch Wallpapers.

3 Touch Gallery, Live wallpapers or Wallpapers, and

choose a wallpaper.

Display settings

• To set display brightness, touch Menu > Settings

> Display > Brightness.

• To set orientation, touch Menu > Settings

> Display > Auto-rotate screen.

• To set animation, touch Menu > Settings

Display > Animation.

Note: Some apps are designed so that your smartphone can "animate" them by rotating, fading, moving and stretching one or more images.

Sounds

• To set volume for ringtones, media and alarms, touch

Menu > Settings > Sound > Volume.

• To play dial pad tones, touch Menu > Settings

Sound > Audible touch tones.

• To play sound on a screen selection, touch Menu

> Settings > Sound > Audible selection.

• To customise the sound settings for media and

videos, touch Menu > Settings > Sound > Media

audio effects

> Phone speaker.

Date & time

Set date, time, time zone and formats:

Find it: Menu > Settings > Date & time

Language & region

Set your menu language and region:

Find it: Menu > Settings > Language & keyboard > Select locale

37Personalise

Location

Elmhurst

Addison

Cicero

East

oChicago

Evanston

Des Plaines

Elmwood

La Grange

Harvey

Calumet

City

Hammond

Orland Park

GGary

Tinley Park

Blue Island

Northbrook

Chicago

Heights

Highland

Highland Park

where you are, where you're going

Google Maps™

Find it: > Maps

Find places near your

Search Maps

lein

Highland Park

Grove

Northbrook

hts

Evanston

Des Plaines

Elmwood

Chicago, IL

Park

Addison

Oak Park

Elmhurst

294

Orland Park

Clear Map More

La Grange

Tinley Park

Cicero

290

Oak Lawn

Blue Island

Directions

Harvey

Join Latitude

Chicago

Heights

Hei

Calumet

Hammond

hts

City

My PlacesSearch

Highland

Note: The map image you see may be a little different.

38 Location

current location.

Centre the map on your current location.

Add layers of information to the map view.

East

Chicag

Touch Menu for map options.

Google Maps offers powerful, user-friendly mapping technology and local business information—including business locations, contact information and driving directions.

For help, touch Menu >

More > Help.

Tip: Want to know what's in your immediate area? Try Google Places™. Touch >

Places to see listings

for Restaurants, ATMs, Petrol stations and more based on your current location.

Google Maps™ Navigation

Google Maps Navigation is an Internet-connected GPS navigation system with voice guidance.

Find it: >

Follow the prompts to speak or type your destination.

For more information, go to www.google.com/mobile/navigation

Navigation

Wireless

lose the wires

Quick start: Wireless

Connect your smartphone to fast Wi-Fi networks or Bluetooth™ devices.

To connect, touch Menu >

networks

> Wi-Fi settings or Bluetooth settings.

Wi-Fi settings

Wi-Fi

Connected to Jenny's Coffee Shoppe

Network notification

Open network

Notify me when an open network is available

Secure network

Notify me when a secure network is available

Wi-Fi networks

Jenny's Coffee Shoppe

Connected

Add Wi-Fi network

Manage networks

Turn on & scan.

Connect to this device.

Settings > Wireless &

Turn on & scan.

Connect to this network.

Bluetooth settings

Bluetooth

Turn on Bluetooth

Device name

Motorola phone

Discoverable

Make device discoverable

Discoverable timeout

Set how long device will be discoverable

Scan for devices

Bluetooth devices

Motorola handset

Pair with this device

Wi-Fi networks

Turn Wi-Fi power on or off

Find it: Menu > Settings > Wireless & networks > Wi-Fi

Note: To extend battery life, turn off Wi-Fi power when not in use.

Wi-Fi search & connect

When Wi-Fi is turned on, the Wi-Fi in range indicator appears in the status bar when a network is available. Drag down the status bar and touch the Wi-Fi networks

available

network.

To search for a network when Wi-Fi is turned off:

1 Touch Menu > Settings > Wireless & networks

2 To uc h

3 Touch a network to connect. If necessary,

notification to select and connect to a

> Wi-Fi settings.

Wi-Fi to turn on and scan. If Wi-Fi power is

already on, touch Menu > Scan. Your smartphone lists the networks it finds within range.

Tip: To see your smartphone's MAC address or other Wi-Fi details, touch Menu > Advanced.

enter

Network SSID, Security and Wireless password

and touch Connect.

39Wireless

When your smartphone is connected to the network, the Wi-Fi connected indicator appears in the status bar.

Tip: When you are in range and Wi-Fi power is on, you will automatically reconnect to available networks you've connected to before.

Wi-Fi modes

For those who like to get a bit more technical, your smartphone supports the following Wi-Fi modes:

802.11 b, g, n.

Wi-Fi Hotspot

You can make your smartphone a Wi-Fi hotspot to provide portable, convenient Internet access to other Wi-Fi enabled devices.

Caution: This application significantly impacts battery life. You may want to run this application with the charger connected.

Note: You need to subscribe to Wi-Fi Hotspot service to use this feature. Contact your service provider.

To set up your smartphone as a Wi-Fi hotspot:

1 Turn off Wi-Fi power by touching Menu > Settings

Wireless & networks > Wi-Fi.

2 Touch > Mobilehotspot > Mobile hotspot to

turn on the hotspot.

40 Wireless

3 Tou ch Configure mobile hotspot to change hotspot

security and configuration settings:

• Network SSID—Enter a unique name for your

hotspot and touch

Next.

•Security—Select the type of security you want

and touch Save: WEP, WPA or WPA2. Enter a unique password. Other users can access your Wi-Fi hotspot only if they enter the correct password.

Note: Keep it secure. To protect your smartphone and hotspot from unauthorised access, it is strongly recommended that you set up hotspot

Security (WPA2 is the most secure), including

password.

• Broadcast channel—Select a channel that

minimises potential interference. You may need to try different channels after your Hotspot is active for a time.

4 To uc h

Save when the settings are complete.

When your Wi-Fi Hotspot is active, other Wi-Fi-enabled devices can connect by entering your Hotspot's SSID, selecting a Security type and entering the correct

Wireless password.

Bluetooth™ hands-free devices

Turn Bluetooth power on or off

Find it: Menu > Settings > Wireless & networks > Bluetooth

Note: To extend battery life, turn off Bluetooth power when not in use.

Connect new devices

Note: This feature requires an optional accessory.

To connect with a new device, you need to pair with it. You only need to do this once for each device—to connect again, just turn the device on.

1 Make sure the device you are pairing with is in

discoverable mode.

Note: Refer to the guide that came with the device for details.

2 Touch Menu >

> Bluetooth settings.

3 Touch Bluetooth to turn on and scan. If Bluetooth

power is already on, touch Scan for devices.

4 Touch a device to connect.

5 If necessary, touch

(like 0000) to connect to the device. When the device is connected, the Bluetooth connected indicator appears in the status bar.

Settings > Wireless & networks

OK, or enter the device passkey

Note: Using a mobile device or accessory while driving may cause distraction and may be illegal. Always obey the laws and drive safely.

Reconnect devices

To automatically reconnect your smartphone with a paired device, simply turn the device on.

To manually reconnect your smartphone with a paired device, touch the device name in the list.

Bluetooth devices

Disconnect devices

To automatically disconnect your smartphone from a paired device, simply turn the device off.

To manually disconnect your smartphone from a paired device, touch the device name in the devices list, then touch

OK.

Change device name

Touch Menu > Settings > Wireless & networks > Bluetooth settings > Device name. Enter a name and touch OK.

MOTOPRINT

Print email, documents, pictures and contacts directly to shared printers on a Wi-Fi network—no printer drivers necessary. MOTOPRINT automatically discovers networked printers for you. You can even save your

41Wireless

favourite printers and geo-tag their location for future use.

Print a document or file

To print something from the Email, Quickoffice or

Gallery apps, open it and touch Menu > Print.

To print something directly from the MOTOPRINT app, touch > type and follow the on-screen instructions.

MOTOPRINT, then select a document

Add a printer

Find it: > MOTOPRINT, touch Menu > Manage printers > Add printers > At home or At work

MOTOPRINT host

To print to a non-compatible or non-networked printer connected to your Windows™ computer, you need to install free MOTOPRINT Host software on the computer. You can download MOTOPRINT Host at www.motorola.com

To print something using MOTOPRINT Host:

Find it: > MOTOPRINT, touch Menu > Manage printers > Add printers > At home or At work > MOTOPRINT hosts

Select MOTOPRINT Host running on your computer, then select the printer you want to use.

42 Memory card & file management

Memory card & file management

copy photos, music and more

Download remote files

Use MotoCast to download documents and files from your computer to your smartphone.

Find it: >

For more information about using MotoCast, see "MotoCast" on page 26.

microSD memory card

Note: Your photos, videos and other files are automatically stored in your smartphone's internal memory. You can set individual applications (camera, camcorder etc.) to store files on a microSD card. To install an optional microSD card, see "Assemb le & charge" on page 3.

Tip: To move media from internal memory to the microSD card, touch Menu > > Manage internal storage.

Files > MotoCast computers

Settings > Storage

Delete or share files on your smartphone

Find it: > Files > Internal phone storage or SD

card

Touch a file or folder to open, then touch and hold a file to Delete or Share.

Remove or format the microSD card

Note: Do not remove the microSD card while your smartphone is using it or writing files on it.

Before you remove or format the microSD card you need to unmount it. Touch Menu > Settings > Storage > Unmount SD card.

To format the microSD card, touch

Format SD card.

Warning: All data on the microSD card will be deleted.

USB connection

You can connect your smartphone to a computer with a USB cable.

Note: The first time you use a USB connection, your computer may indicate that drivers are being installed. Follow any prompts you see to complete the installation. This may take a few minutes.

With your smartphone showing the home screen, connect a Motorola micro USB data cable from your smartphone's micro USB port to a USB port on your

computer. Your smartphone should show in the status bar.

Note: Make sure you connect the smartphone to a high power USB port. Typically, these are located directly on your computer.

2 Drag and drop files between your computer and

smartphone folders. When you have finished, use "Safely remove hardware" before disconnecting the USB cable.

Note: You can't use files on an installed microSD memory card while your smartphone is connected to the computer.

43Memory card & file management

Tools

stay on top of things

Calendar

Find it: > Calendar

Your calendar events can be viewed in different ways: Touch > Diary, Day, Week or Month. When you highlight an event, more details appear.

Tip: Add a calendar widget to your home screen by touching and holding an empty space. Then touch

Widgets > Calendar.

Add calendar events

From any view, touch . Enter the event start time and other details. You can even set a reminder so you don't forget about the event. (When you set the reminder time to 0minutes, it plays at the event start time.)

Tip: Reminders will play only if you've selected a notification ringtone (see "Ringtones" on page 36).

When you finish entering event details, touch

44 Tools

All calendars

July 2011

Sun Mon Tue Wed Thu Fri Sat

Save.

Manage calendar events

To edit an event, touch and hold it, then touch Edit

event

. When you're done, touch Save.

To delete an event, touch and hold it, then touch Delete

event

To go to today, touch > Show today.

Tasks

Find it: > Tasks

To add a task, touch .

From the tasks home screen, touch

All tasks to view

your tasks by due date, priority and more.

Calculator

Find it: > Calculator

12345

To switch between basic and advanced functions, touch Menu > Advanced panel or Basic panel. To clear history, touch Menu > Clear history.

All tasks

Phone task

Show completed

All tasks

Overdue Due today

Starred By priority Tags

OFF

Alarm clock

Find it: > Alarm & timer

To turn on an alarm, touch the tick box.

When an alarm sounds, select Dismiss to turn it off or touch the screen to snooze for five minutes.

To add an alarm, touch Menu > enter alarm details.

To enable or disable an alarm, touch the tick box.

Add alarm, then

Alarm Timer

07:00

every day

08:30

Mon, Tue, Wed, Thu, Fri

09:00

Accessibility

See, hear, speak, feel and use. Accessibility features are there for everyone, helping to make things easier.

Note: For general information, accessories and more, visit www.motorola.com/accessibility

Voice recognition

Use your voice—just touch and speak.

• Dialling and commands: Touch > Voice

commands

name or phone number. Or, say a command from the list shown, like "Send message" or "Go to".

•Search: Touch and hold Search , then say what

you want to search for, like "Motorola accessories".

• Text entry: Touch a text entry field to open the

touchscreen keypad. Touch , then say what you want to type.

Tip: Speak naturally, but clearly. Use the microphone in a similar way to a speakerphone, so there's no need to shout or hold the smartphone close to your mouth.

To change your voice settings, see "Voice settings" on page 46.

. To dial, say "Call" and then a contact

45Tools

Voice readouts (TalkBack)

Your navigation and selections, read out loud.

To turn on voice readouts (similar to TalkBack), touch Menu > Settings > Accessibility. Touch Accessibility to enable the settings, then touch Voice readouts.

Note: You may be asked to download additional "text-to-speech" software (data charges may apply).

To use voice readouts:

• Menus and screens: In menus and screens, touch an

item to highlight it (the item will be read out loud) and double-touch to open it.

Note: Touch a home screen widget or shortcut to open it.

• Dialler & text entry: As you type, each number or

letter is read out loud.

• Notification: When you drag the notifications bar

down, all notifications are read out loud.

Tip: Navigate through your apps and menus to hear how voice readouts work on your smartphone.

To change your voice settings, see "Voice settings" on page 46.

46 Tools

Caller ID

When you want to hear who's calling:

• Read out loud: Have your caller announced—touch

Menu > Settings > Call settings > Caller ID

readout

• Ringtones: Assign a unique ringtone to a

contact—touch touch Menu > Options > Ringtone.

To change your voice settings, see "Voice settings" on page 46.

Contacts, touch a contact, then

Voice settings

Personalise your voice settings:

• Voice recognition: Touch Menu > Settings

> Voice input & output > Voice recogniser settings. From here, you can set options like language and censorship.

• Voice commands: Touch >

> Menu > Settings. From here, you can refine recognition of your voice (Adaptation) and set options like prompts and shortcuts.

• Text-to-speech: Touch Menu > Settings > Voice

input & output

you can set options like speed and language.

> Text-to-speech settings. From here,

Voice commands

Volume & vibrate

Choose volume and vibrate settings that work for you. Touch Menu > Settings > Sound:

• Volume: Tou ch Volume and use the sliders.

Tip: To set separate ring and notification volumes,

deselect Use incoming call volume for notifications.

• Vibrate: Select

smartphone ring.

Vibrate > Always to feel your

Zoom

Get a closer look. Open a magnification window that you can drag around the screen, or slide your fingers apart to zoom in on maps, webpages and photos.

• Magnification window: Touch Menu >

> Accessibility. Touch Accessibility to enable the settings, then touch Zoom mode.

• Pinch to zoom: To zoom in, touch the screen with

two fingers and then slide them apart. To zoom out, slide your fingers together.

Settings

Display brightness

Set a brightness level that works for you. Touch Menu > Settings > Display > Brightness. Make sure that

Automatic brightness is deselected so you can set

your own level.

Touchscreen & keys

All these touch features are great, and sometimes it's nice to hear or feel your touches too. Touch Menu > Settings > Sound:

• Touchscreen: To hear screen touches (click), select

Audible selection.

•Keys: To feel key touches (vibrate), select

feedback

•Screen lock: To hear when you lock/unlock the screen

(click), select Screen lock sounds.

Haptic

Messages

From a simple text message to IM, email and more. Create, send and receive them all, in one place.

Find it: > Messaging > Universal inbox

And to make text entry even easier, you can use features like auto-correct, auto-punctuate and auto-capitalisation—touch Menu > Settings >

Language& keyboard > Multi-touch keyboard. Of

course if you don't want to type at all, then use your voice—touch on the touchscreen keypad.

Hearing aids

To help get a clear sound when using a hearing aid or cochlear implant, your smartphone may have been rated for use with hearing aids. If your smartphone's box has "Rated for hearing aids" printed on it, then please read the following guidance.

47Tools

Note: ratings are not a guarantee of compatibility. See

"Hearing aid compatibility with mobile phones" in your legal and safety information. You may also want to consult your hearing health professional, who should be able to help you get the best results.

• Settings: Touch Menu >

HAC mode settings to turn hearing aid compatibility

Settings > Call settings

mode on or off. HAC mode optimises your smartphone for use with a hearing aid.

• Call volume: During a call, press the side volume

keys to set a call volume that works for you.

• Position: During a call, hold the smartphone to your

ear as normal, and then rotate/move it to get the best position for speaking and listening.

TTY

You can use your smartphone in TTY mode with standard teletype machines. Touch Menu > Settings

48 Tools

> Call settings >TTY mode and select the mode you need:

•

TTY Full: Type and read text on your TTY device.

• TTY HCO: Hearing-Carry-Over—type text on your TTY

device and listen to voice replies on your smartphone's speaker.

•

TTY VCO: Voice-Carry-Over—speak into your

smartphone and read text replies on your TTY device.

Note: You'll need a cable/adapter to connect your TTY device to the headset jack on your smartphone.

Refer to your TTY device guide for mode and usage information.

Apps

Want more? No problem. Android Market™ provides access to thousands of apps and many provide useful accessibility features.

Find it: >

Select a category or touch Search to find the app you want.

Tip: Choose your apps carefully, from trusted sites like

Market, as some may have an impact on your

smartphone's performance.

Market

Management

stay in control

Smart actions

Tired of doing the same tasks over and over again? Let smart actions do them for you. You can create rules to do things like automatically dim the touch screen when the battery is low, set your ringer to vibrate at work and set a different wallpaper at home.

Find it: >

For more information, open the Smart Actions app and touch Menu >

Wireless manager

Find it: Menu > Settings > Wireless & networks

Manage all your wireless connections: Wi-Fi, Bluetooth™, Flight mode and mobile networks.

Flight mode

Use flight mode to turn all your wireless connections off—useful when flying. Press and hold Power > Flight mode.

Note: When you select flight mode, all wireless services are disabled. You can then turn Wi-Fi and/or Bluetooth back on, if permitted by your airline. Other wireless voice and data services (such as calls and text messages)

Smart actions

Help.

remain off in flight mode. Emergency calls to your region's emergency number can still be made.

Network

You should not need to change any network settings. Contact your service provider for help.

Touch Menu > > Mobile networks to show options for roaming networks, network selection, operator selection and access point names.

Settings > Wireless & networks

49Management

Security

help keep your smartphone safe

Quick start: Security

Find it: Menu > Settings > Location & security

Location & security settings

Security

Set up screen lock

Lock screen with a pattern, PIN or password

Security lock timer

20 minutes

Allow Bluetooth bypass

Allow Voice commands to be launched via the Bluetooth Multi-function button while device is locked

SIM card lock

Set up SIM card lock

Data encryption

Protect the data on your phone or memory card. Requires screen lock

Passwords

Visible passwords

Show password as you type.

50 Security

Select & set up a screen lock method.

Set lock timer.

See the passwords you enter.

Screen lock

To prevent accidental touches, you can make the screen lock when it goes to sleep. Touch Menu > Settings > Location & security > Set up screen lock, then select the lock type:

• Pattern—draw a pattern to unlock.

•

PIN—enter a numeric PIN to unlock.

• Password—enter a password to unlock.

Note: You can make emergency calls on a locked

smartphone (see "Emergency calls" on page 14). A locked smartphone still rings, but you need to unlock it to answer.

Lock pattern

To set the lock pattern, touch Menu > Settings >

Location & security

> Change screen lock > Pattern.

Follow the instructions to draw your lock pattern.

When prompted, draw the pattern to unlock the smartphone.

Draw an unlock pattern

PIN lock

To set a PIN, touch Menu > Settings > Location &

security

> Change screen lock > PIN.

Enter a numeric PIN, then confirm it.

When prompted, enter the PIN to unlock the smartphone.

Password lock

To set the password, touch Menu > Settings > Location & security > Change screen lock > Password.

Enter a password (up to eight characters), then confirm it.

When prompted, enter the password to unlock the smartphone.

Personalise your lock screen

To change your timeout, touch Menu > Settings > Location & security > Security lock timer. If you don't touch the screen or press any keys for the amount of time you select, the screen locks automatically.

Lock & unlock

To lock the screen/smartphone:

• Press Power .

• Let the screen time out (don't press anything).

• Switch off the power.

To unlock the screen/smartphone, press Power , or touch Home . Or switch on the smartphone to view the lock screen.

Forgotten your pattern, PIN or password?

If you forget your pattern, PIN or password, contact your service provider.

Reset

To reset your smartphone to factory settings and erase all the data on your smartphone, touch Menu > Settings > Privacy > Factory data reset > Reset

phone

Warn ing: All data on your smartphone will be deleted. (Nothing on the microSD memory card is deleted.)

Remote wipe a lost or stolen smartphone

Don't you just hate it when your life is on your smartphone and it all goes wrong? Lost, or even worse—stolen! If necessary, you can use your email account on a Microsoft™ Exchange ActiveSync 2007 server to clear the personal data from your smartphone and microSD memory card.

You need to be assigned permissions before you can remote wipe data from your smartphone and microSD card. Contact your IT system administrator for

51Security

the information and permissions you need to perform the remote wipe procedure.

Warning: All downloaded apps and user data on your smartphone and microSD card will be deleted.

52 Troubleshooting

Troubleshooting

Crash recovery

In the unlikely event that your smartphone stops responding to touches and key presses, try a forced reboot—press and hold both Power and the down volume key for up to 10 seconds.

Product Safety & Legal

032375o

Battery use & safety

The following battery use and safety information applies to all Motorola mobile devices. If your mobile device uses a non-removable main battery (as stated in your product information), details related to handling and replacing your battery should be disregarded — the battery should only be replaced by a Motorola-approved service facility and any attempt to remove or replace your battery may damage the product.

Important: Handle and store batteries properly to avoid injury or damage.

battery safety issues arise from improper handling of batteries, and particularly from the continued use of damaged batteries.

DON'Ts

• Don't disassemble, crush, puncture, shred or otherwise attempt to change the

form of your battery.

• Don't use tools, sharp objects or excessive force to insert or remove the battery

as this can damage the battery.

• Don't let the mobile device or battery come in contact with liquids.*

get into the mobile device's circuits, leading to corrosion.

• Don't allow the battery to touch metal objects.

stay in prolonged contact with the battery contact points, the battery could become very hot.

• Don't place your mobile device or battery near a heat source.*

can cause the battery to swell, leak or malfunction.

• Don't dry a wet or damp battery with an appliance or heat source

dryer or microwave oven.

DOs

• Do avoid leaving your mobile device in your car in high temperatures.*

• Do avoid dropping the mobile device or battery.*

on a hard surface, can potentially cause damage.*

• Do contact your service provider or Motorola if your mobile device or battery

has been damaged in any of the ways listed here.

Always make sure that any battery, connector and compartment covers are closed

* Note:

and secure to avoid direct exposure of the battery to any of these conditions, even if your product information states that your conditions.

mobile device

If metal objects, such as jewellery,

Dropping these items, especially

can resist damage from these

Most

Liquids can

High temperatures

, such as a hair

Important: Motorola recommends you always use Motorola-branded batteries and chargers for quality assurance and safeguards.

damage to the mobile device caused by non-Motorola batteries and/or chargers. To help you identify authentic Motorola batteries from non-original or counterfeit batteries (that may not have adequate safety protection), Motorola provides holograms on its batteries. You should confirm that any battery you purchase has a "Motorola Original" hologram. If you see a message on your display such as take the following steps:

•

Remove the battery and inspect it to confirm that it has a "Motorola Original" hologram;

•

If there is no hologram, the battery is not a Motorola battery;

•

If there is a hologram, replace the battery and try charging it again;

•

If the message remains, contact a Motorola authorised service centre.

Warning:

Use of a non-Motorola battery or charger may present a risk of fire, explosion,

leakage or other hazard.

Proper and safe battery disposal and recycling:

important for safety, it also benefits the environment. You can recycle your used batteries in many retail or service provider locations. Additional information on proper disposal and recycling can be found at

Disposal:

Promptly dispose of used batteries in accordance with local regulations. Contact your local recycling centre or national recyc ling organisations for more information on how to dispose of batteries.

Warning:

Never dispose of batteries in a fire because they may explode.

Battery charging

Notes for charging your product's battery:

During charging, keep your battery and charger near room temperature for efficient

•

battery charging.

•

New batteries are not fully charged.

•

New batteries or batteries stored for a long time may take more time to charge.

•

Motorola batteries and charging systems have circuitry that protects the battery from damage from overcharging.

www.motorola.com/recycling

Motorola's warranty does not cover

Invalidbattery

Unabletocharge

Proper battery disposal is not only

53Product Safety & Legal

Third party accessories

Use of third party accessories, including but not limited to batteries, chargers, headsets, covers, cases, screen protectors and memory cards, may impact your mobile device's performance. In some circumstances, third party accessories can be dangerous and may void your mobile device's warranty. For a list of Motorola accessories, visit www.motorola.com/products

Driving precautions

Responsible and safe driving is your primary responsibility when behind the wheel of a vehicle. Using a mobile device or accessory for a call or other application whilst driving may cause distraction, and may be prohibited or restricted in certain areas—always obey the laws and regulations on the use of these products.

While driving, NEVER:

Type, read, enter or review texts, emails, or any other written data.

•

Surf the web.

•

Input navigation information.

•

Perform any other functions that divert your attention from driving.

While driving, ALWAYS:

•

Keep your eyes on the road.

•

Use a hands-free device if available or required by law in your area.

•

Enter destination information into a navigation device

•

Use voice-activated features (such as voice dial) and speaking features (such as audible directions), if available.

•

Obey all local laws and regulations for the use of mobile devices and accessories in the vehicle.

•

End your call or other task if you cannot concentrate on driving. Remember to follow the "Smart practices whilst driving" at www.motorola.com/callsmart

(in English only).

before

driving.

Seizures, blackouts & eyestrain

To reduce eyestrain and avoid headaches, it is always a good idea to hold the screen at a comfortable distance from your eyes, use in a well-lit area, and take frequent breaks. Some people may be susceptible to seizures or blackouts (even if they have never had one before) when exposed to flashing lights or light patterns, such as when pl aying video games, or watching videos with flashing-light effects.

54 Product Safety & Legal

Discontinue use and consult a doctor if any of the following symptoms occur: seizures, blackout, convulsion, eye or muscle twitching, loss of awareness or disorientation. If you or someone in your family has experienced seizures or blackouts, please consult your doctor before using an application that produces flashing-light effects on your mobile device.

Caution about high volume usage

Warning:

Exposure to loud noise from any source for extended periods of time may affect your heari ng. The louder the volume sound level, the less time is required before your hearing could be affected. To protect your hearing:

•

Limit the amount of time you use headsets or headphones at high volume.

•

Avoid turning up the volume to block out noisy surroundings.

•

Turn the volume down if you can't hear people speaking near you. If you experience hearing discomfort, including the sensation of pressure or fullness in your ears, ringing in your ears or muffled speech, you should stop listening to the device through your headset or headphones and get your hearing checked. For more information about hearing, see our website at direct.motorola.com/hellomoto/nss/AcousticSafety.asp

(in English only).

Repetitive motion

When you repetitively perform actions such as pressing keys or entering finger-written characters, you may experien ce occasional discomfort in your hands, arms, sh oulders, neck or other parts of your body. If you continue to have discomfort during or after such use, stop use and see a doctor.

Children

Keep your mobile device and its accessories away from small children.

products are not toys and may be hazardous to small children. For example:

•

A choking hazard may exist for small, detachable parts.

•

Improper use could result in loud sounds, possibly causing hearing injury.

•

Improperly handled batteries could overheat and cause a burn.

Supervise access for older children.

your mobile device, you may want to monitor their access to help prevent:

•

Exposure to inappropriate apps or content.

•

Improper use of apps or content.

•

Loss of data.

Similar to a computer, if an older child does use

These

Glass parts

032374o

032376o

032375o

Some parts of your mobile device may be made of glass. This glass could break if the product receives a substantial impact. If glass breaks, do not touch or attempt to remove. Stop using your mobile device until the glass is replaced by a qualified service centre.

Operational warnings

Obey all posted signs when using mobile devices in public areas.

Potentially explosive areas

Potentially explosive areas are often, but not always, posted and can include blasting areas, fuelling stations, fuelling areas (such as below decks on boats), fuel or chemical transfer or storage facilities, or areas wher e the air contains chemicals or particles, such as grain dust or metal powders. When you are in such an area, turn off your mobile device, and do not remove, install or charge batteries, unless it is a radio product type especially qualified for use in such areas and certified as "Intrinsically safe" (for example, Factory Mutual, CSA or UL approved). In such areas, sparks can occur and cause an explosion or fire.

Symbol key

Your battery, charger or mobile device may contain symbols, defined as follows:

Symbol Definition

Important safety information follows.

Do not dispose of your battery or mobile device in a fire.

Your battery or mobile device may require recycling in accordance with local laws. Contact your local regulatory authorities for more information.

Symbol Definition

Do not dispose of your battery or mobile device with your household waste. See "Recycling" for more information.

Do not use tools.

For indoor use only.

Listening at full volume to music or voice through a headset may damage your hearing.

Radio frequency (RF) energy

Exposure to RF energy

Your mobile device contains a transmitter and receiver. When it is ON, it receives and transmits RF energy. When you communicate using your mobile device, the system handling your call controls the power level at which your mobile device transmits. Your mobile device is designed to comply with local regulatory requirements in your country concerning exposure of human beings to RF energy.

RF energy operational precautions

For optimal mobile device performance, and to be sure that human exposure to RF energy does not exceed the guidelines set forth in the relevant standards, always follow these instructions and precautions:

•

When placing or receiving a phone call, hold your mobile device just like you would a

landline phone.

•

If you wear the mobile device on your body, always place the mobile device in a

Motorola-supplied or approved accessory (e.g. clip, holder, holster, case or arm band). If

you do not use a body-worn accessory supplied or approved by Motorola, ensure that

55Product Safety & Legal

whatever product is used is free of any metal and that it positions the mobile device at least 2.5 cm (1 inch) away from the body.

•

Using accessories not supplied or approved by Motorola may cause your mobile device to exceed RF energy exposure guidelines. For a list of Motorola-supplied or approved accessories, visit our website at:

RF energy interference/compatibility

Nearly every electronic device is subject to RF energy interference from external sources if inadequately shielded, de signed or otherwise configured for RF energy compati bility. In some circumstances, your mobile device may cause interference with other devices.

Follow instructions to avoid interference problems

Turn off your mobile device in any location where posted notices instruct you to do so, such as hospitals or healthcare facilities. In an aircraft, turn off your mobile device whenever instructed to do so by airline staff. If your mobile device offers a flight mode or similar feature, consult airline staff about using it in-flight.

Medical devices

If you have a medical device, including an implantable medical device such as a pacemaker or defibrillator, consult your healthcare provider and the device manufacturer's directions before using this mobile device. Persons with implantable medical devices should observe the following precautions:

•

ALWAYS keep the mobile device more than 20 centimetres (8 inches) from the implantable medical device when the mobile device is turned ON.

•

DO NOT carry the mobile device in the breast pocket.

•

Use the ear opposite the implantable medical device to minimise the potential for interference.

•

Turn OFF the mobile device immediately if you have any reason to suspect that interference is taking place.

www.motorola.com

Regulatory information

Your Motorola mobile device is designed to comply with nati onal and international regulatory requirements. For full compliance statements and details, please refer to the regulatory information in your printed product guide.

56 Product Safety & Legal

Location services

GPS & AGPS

The following information is applicable to Motorola mobile devices that provide location-based functionality. Location sources can include GPS, AGPS and Wi-Fi. Your mobile device can use Global Positioning System (GPS) signals for location-based applications. GPS uses satellites controlled by the U.S. government that are subject to changes implemented in accordance with the Department of Defense policy and the Federal Radionavigation Plan. These changes may affect the performance of location technology on your mobile device. Your mobile device can also use Assisted Global Positioning System (AGPS), which obtains information from the mobile network to improve GPS performance. AGPS uses your wireless service provider's network and th erefore airtime, data charges and/or additional charges may apply in accordance with your service plan. Contact your wireless service provider for details. Your mobile device can also use Wi-Fi signals to determine your approximate location, using information from known and available Wi-Fi networks.

Your location

Location-based information includes information that can be used to determine the approximate location of a mobile device. Mobile devices that are connected to a wireless network transmit location-based information. Devices enabled with location technology also transmit location-based information. Additionally, if you use applications that require location-based information (e.g. driving directions), such applications tr ansmit location-based information. This location-based information may be shared with third pa rties, including your wireless service provider, applications providers, Motorola and other third parties providing services.

Emergency calls

When you make an emergency call, the mobile network may activate the AGPS technology in your mobile device to tell the emergency responders your approximate location. AGPS has limitations and

•

Always tell the emergency responder your location to the best of your ability; and

•

Remain on the phone for as long as the emergency responder instructs you.

might not work in your area

. Therefore:

Navigation

The following information is applicable to Motorola mobile devices that provide navigation features. When using navigation features, note that mapping information, directions and other navigational data may contain inaccurate or incomplete data. In some countries, complete information may not be avai lable. Therefore, you should visually confi rm that the navigational instructions are consistent with what you see. All drivers should pay attention to road conditions, closures, tr affic and all other factors that may impact driving. Always obey pos ted road signs.

Privacy & data security

Motorola understands that privacy and data security are important to everyone. Given that some features of your mobile device may affect your privacy or data security, please follow these recommendations to enhance protection of your information:

• Monitor access

may have unmonitored access. Use your device's security and lock features, where available.

• Keep software up to date

patch or software fix for your mobile device that updates the device's security, install it as soon as possible.

• Secure personal information

various locations including your SIM card, memory card and phone memory. Make sure you remove or clear all personal information before you recycle, return or give away your device. You can also back up your personal data to transfer to a new device.

Note:

www.motorola.com/support

• Online accounts

MOTOBLUR). Go to your account for information on how to manage the account and how to use security features such as remote wipe and device location (where available).

• Applications and updates

trusted sources only. Some apps can impact your phone's performance and/or have access to private information including account details, call data, location details and network resources.

•Wireless

networks. Also, when using your device as a hotspot (where available) use network security. These precautions will help prevent unauthorised access to your device.

—Keep your mobile device with you and do not leave it where others

—If Motorola or a software/application vendor releases a

—Your mobile device can store personal information in

For information on how to back up or wipe data from your mobile device, go to

—Some mobile devices provide a Motorola online account (such as

—Choose your apps and updates carefully and install from

—For mobile devices with Wi-Fi features, only connect to trusted Wi-Fi

• Location-based information

technologies such as GPS, AGPS or Wi-Fi, can transmit location-based information. See

"Location services" for more details.

• Other information your device may transmit

and other diagnostic (including location-based) information, and other non-personal

information to Motorola or other third-party servers. This information is used to help

improve products and services offered by Motorola. If you have further questions regarding how the use of your mobile device may impact your privacy or data security, please contact Motorola at your service provider.

Use & care

To care for your Motorola mobile device, please observe the following:

liquids

Don't expose your mobile device to water, rain, extreme humidity, sweat or other liquids.

drying

Don't try to dry your mobile device using a microwave oven, conventional oven or dryer, as this may damage the mobile device.

extreme heat or cold

Don't store or use your mobile device in temperatures below -10°C (14°F) or above 60°C (140°F). Don't recharge your mobile device in temperatures below 0°C (32°F) or above 45°C (113°F).

dust and dirt

Don't expose your mobile device to dust, dirt, sand, food or other inappropriate materials.

cleaning

To clean your mobile device, use only a dry soft cloth. Do not use alcohol or other cleaning solutions.

—Mobile devices enabled with location based

—Your device may also transmit testing

privacy@motorola.com

, or contact

57Product Safety & Legal

shock and vibration

Don't drop your mobile device.

protection

To help protect your mobile device, always make sure that any battery, connector and compartment covers are closed and secure.

Recycling

Mobile devices & accessories

Please do not dispose of mobile devices or electrical accessories (such as chargers, headsets or batteries) with your household waste or in a fire. These items should be disposed of in accordance with the national collection and recycling schemes operated by your local or regional authority. Alternatively, you may return unwanted mobile devices and electrical accessories to any Motorola approved service centre in your region. Details of Motorola-approved national recycling schemes and further information on Motorola recycling activities can be found at: www.motorola.com/recycling

Packaging & product guides

Product packaging and product guides sh ould only be disposed of in accordance with national collection and recycling requirements. Please contact your regional authorities for more details.

Software copyright

Software copyright notice

Motorola products may include copyrighted Motorola and third-party software stored in semiconductor memories or other media. Laws in the United States and other countries preserve for Motorola and third-party software providers certain exclusive rights for copyrighted software, such as the exclusive rights to distribute or reproduce the copyrighted software. Accordingly, any copyrighted software contained in Motorola products may not be modified, reverse-engineered, distributed or reproduced in any manner to the extent allowed by law. Furthermore, the purchase of Motorola products shall not be deemed to grant either directly or by implication, estoppel or otherwise, any licence under the copyrights, patents or patent applications of Motorola or any third-party software provider, except for the normal,

58 Product Safety & Legal

non-exclusive, royalty-free licence to use that arises by operation of law in the sale of a product.

Content copyright

The unauthorised copying of copyrighted materials is contrary to the provisions of the copyright laws of the United States and other countries. This device is intended solely for copying non-copyrighted materials, materials in which you own the copyright or materials which you are authorised or legally permitted to copy. If you are uncertain about your right to copy any material, please contact your legal advisor.

Open source software information

OSS information

For instructions on how to obtain a copy of any source code being made publicly available by Motorola related to software used in this Motorola mobile device, you may send your request in writing to the address below. Please make sure that the request includes the model number and the software version number. MOTOROLA MOBILITY, INC. OSS Management 600 North US Hwy 45 Libertyville, IL 60048 USA The Motorola website information regarding Motorola's use of open source. Motorola has created the interaction with the software community-at-large. To view additional information regarding licences, acknowledgments and required copyright notices for open source packages used in this Motorola mobile device, please press Menu key > >

Opensourcelicences

applications that present supplemental notices for open source packages used in those applications.

opensource.motorola.com

Settings

Aboutphone

. In addition, this Motorola device may include self-contained

(in English only) also contains

website to serve as a portal for

Legalinformation

How to obtain service or other information

1. Please access and review the online Customer support section of Motorola's consumer website prior to requesting warranty service.

2. If the Product is still not functioning properly after making use of this resource, please contact the Warrantor listed at the Motorola website or the contact information for the corresponding location.

3. A representative of Motorola, or of a Motorola Authorised repair centre, will help determine whether your Product requires service. You may be required to download or otherwise obtain and accept software updates from Motorola or a Motorola authorised repair centre. You are responsible for any applicable carrier service fees incurred while obtaining the required downloads. Complying with the warranty process, repair instructions and accepting such sof tware updates is required in order to receive additional warranty support.

4. If the software update does not fix the problem, you will receive instructions on how to ship the Product to a Motorola Authorised repair centre or other entity.

5. To obtain warranty service, as permi tted by applicable law, you are required to incl ude: (a) a copy of your receipt, bill of sale or other comparable proof of purchase; (b) a written description of the problem; (c) the name of your service provider, if applicable; (d) your address and telephone number. In the event the Product is not covered by the Motorola Limited Warranty, Motorola will inform the consumer of the availability, price and other conditions applicable to the repair of the Product.

To obtain service or other information, please access and review the online Customer Support section of Motorola's consumer website at

www.motorola.com

Copyright & trademarks

www.motorola.com Certain features, services and applications are network-dependent and may not be available in all areas; additional terms, conditions and/or charges may apply. Contact your service provider for details. All features, functionality and other product specifications, as well as the information contained in this guide, are based upon the latest available information and believed to be accurate at the time of printing. Motorola reserves the right to change or modify any information or specifications without notice or obligation.

Note:

The images in this guide are examples only. MOTOROLA and the Stylised M Logo are trademarks or registered trademarks of Motorola Trademark Holdings, LLC. Google, the Google logo, Google Maps, Google Talk, Google Latitude, Gmail, YouTube, Picasa, Google Books, Google Docs, Google Goggles, Google Finance, Google Places, Google Maps Navigation Beta, Google Calendar, Android and Android Market are trademarks of Google, Inc. All other product or service names are the property of their respective owners. © 2011 Motorola Mobility Inc. All rights reserved.

Caution:

Motorola does not take responsibility for changes/modification to the transceiver. Product ID: MOTOROLA RAZR (Model XT910) Manual number: 68016429004

59Product Safety & Legal

68016429004

Motorola RAZR User Guide

Specifications and Main Features

Frequently Asked Questions

User Manual

Congratulations

Your smartphone

Contents

Let's go

Assemble & charge

Set up & go

Wi-Fi connect

Cool content & more

Touchscreen & keys

Touchscreen on/off

Touch tips

Key tips

Rotate the screen

Quick tips

Home screen

Quick start: Home screen

Use & change your home screen

Search

Smartphone status & notifications

Apps & updates

Quick start: Apps & updates

Browse & install apps

Recent apps

Manage & restore apps

Choose carefully

Update my smartphone

Calls

Quick start: Calls

Make & answer calls

Recent calls

Frequent calls

Conference calls

Your phone number

TTY mode

Emergency calls

Cool down

Contacts

Quick start: Contacts

Transfer contacts

Link contacts

Call or email contacts

View & use contacts

Create contacts

Favourites

Edit or delete contacts

Synchronise contacts

Personalise contacts

Groups

Messaging

Quick start: Messaging

Read & reply to messages

Create messages

Send & receive attachments

Set up messaging

Email

Instant messages

Voicemail

Text entry

Touchscreen keypad

Input methods

Typing tips

Text input settings

Social networking

Your social networking account

Add accounts

Edit & delete accounts

Tips & tricks

General tips

Battery tips

Webtop application

Quick start: Webtop

Connect the webtop application

Control the webtop application

Send current webpage to phone

Digital living

MotoCast
