Boost Mobile

i290 iDEN Handset

User’s Guide

DECLARATION OF CONFORMITY

Per FCC CFR 47 Part 2 Section 2.1077(a)

Responsible Party Name: Motorola, Inc. Address: 8000 West Sunrise Boulevard

Plantation, FL 33322 USA

Phone Number: 1 (800) 453-0920 Hereby declares that the product: Product Name: i290 Model Number: H98XAH6JR4AN FCC-ID: IHDT56HG1 Conforms to the following regulations: FCC Part 15, subpart B, section 15.107(a), 15.107(d)

and section 15.109(a)

FCC Notice to Users

The following statement applies to all products that have received FCC approval. Applicable products bear the FCC logo, and/or an FCC ID in the format FCC-ID: IHDT56HG1 on the product label.

Motorola has not approved any changes or modifications to this device by the user. Any changes or modifications could void the user’s authority to operate the equipment. See 47 CFR Sec. 15.21.

Class B Digital Device

As a personal computer peripheral, this device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. See 47 CFR Sec. 15.19(3).

Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Getting Started

Introduction

Welcome to Boost Mobile

With Boost Mobile, you can stay in control of your monthly costs and get all the mobile freedom you want. No hidden fees, no contracts, no credit checks. Just peace of mind.

Your phone has the latest features including Nationwide Boost

Walkie-Talkie, GPS Technology, Text and Multi-Media Messaging, Instant Messaging, and Wireless Web.

Activate

If you haven’t done so already, activate your phone by going to

boostmobile.com/activate

calling Boost Customer Care at 1-888-BOOST-4U (1-888-266-7848) from a landline or another phone.

or by

Re-Boost®

Now that your phone is activated, you’ll want to add funds to your account so you can start using your phone and personalizing it. Boost Mobile makes it easy to recharge your account by offering lots of options — whether you want to add funds with your favorite credit card or you want to pay cash at your local retailer.

Pay Anytime With A Credit Card

By registering your credit card with us, you can instantly recharge your account by dialing #ADD (#233) from your Boost mobile phone and press Send. Or sign up for Auto Re-Boost online and automatically replenish your account.

Getting Started

Pay With Cash

Simply find a Re-Boost Location using your Boost Mobile phone’s

Locator

. Star your phone’s

, go to down to 5-digit zip code to get the names, addresses and phone numbers of retailers in that zip code.

Re-Boost

Re-Boost Locator

Re-Boost

Main

, then scroll

.Punch in a

Personalize

Boost Mobile® offers some of the best options in wireless entertainment

services such as Boost Boost™ Loopt as well as the latest games, real music ringtones, wallpapers and more.

Two easy ways to purchase content and get information on the latest services:

• From your handset: from the Main Menu

• On the web: Check out

boostmobile.com

Call Tones, and

boostLIVE

Purchases are deducted from your Boost Mobile

needed.

account. No credit card

Boost Loyalty Program

We appreciate your business and we want you to know it. Sign up today for the Boost Loyalty Program and get the latest and greatest from Boost. You can’t afford not to sign up. It’s free! Go to

boostmobile.com

Note:

Program subject to change. Full access to the Boost Loyalty Program is exclusively for Boost Mobile customers. Restrictions apply.

to sign up now.

Lost/Stolen Service

We can help if your phone is ever lost or stolen. Call us immediately at 1-888-BOOST-4U. We will secure your account balance, account information and help you keep your phone number.

Getting Started

Boost® Customer Care

Dial #611 from your handset or 1-888-BOOST-4U to reach Boost Customer Care. Airtime charges do not apply.

For more information about your i290 mobile phone, please refer to your

Boost Mobile on

boostmobile.com

Important: Before using your phone please read the "Boost Mobile

General Terms & Conditions of Service", "Driving Tips" and "Safety and General Information".

User's Guide available

Getting Started

Check it out

Speaker

On/Off Key

WT Button

Audio Jack

Volume Keys

Speaker and

microphone

beneath keypad

USB Connector

Internal Antenna

located here

Left Soft Key

Perform function

in lower left

display.

Talk Key

Make &

answer calls.

Menu Key

From home screen,

open main menu.

4-Way

Navigation Key

Right Soft Key

Perform function in lower right display.

Power/Home/End Key

End calls, exit menu system.

OK Key

In menus & lists, press to select highlighted option.

Introducing your Motorola i290 wireless phone. Here is a quick anatomy lesson.

Check it out

up, down, left or right ( )

Customizable

key that can be used to open the

Settings

screen

Press and hold the

Power Key

for a few seconds, or until the screen lights up, to turn on your

phone.

Press the

key

to select.

Press the Navigation Key

to highlight a menu feature.

Home Screen

Main Menu

Exit

Main Menu

g l

Check it out

Motorola, Inc. Consumer Advocacy Office 1307 East Algonquin Road Schaumburg, IL 60196

www.hellomoto.com

Note:

Do not ship your phone to the above address. If you need to return your phone for repairs, replacement, or warranty service, please contact the Motorola Customer Support Center at:

1-800-453-0920 (United States) 1-877-483-2840 (TTY/TDD United States for hearing impaired)

Certain mobile phone features are dependent on the capabilities and settings of your service provider’s network. Additionally, certain features may not be activated by your service provider, and/or the provider's network settings may limit the feature’s functionality. Always contact your service provider about feature availability and functionality. All features, functionality, and other product specifications, as well as the information contained in this user's guide are based upon the latest available information and are believed to be accurate at the time of printing. Motorola reserves the right to change or modify any information or specifications without notice or obligation.

MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark Office. All other product or service names are the property of their respective owners. Java and all other Java-based marks are trademarks or registered trademarks of Sun Microsystems, Inc. in the U.S. and other countries.

Manual Number: NNTN7610A

Contents

Getting Started. . . . . . . . . 1

Introduction . . . . . . . . . 1

Activate. . . . . . . . . . . . . 1

Re-Boost® . . . . . . . . . . 1

Boost Loyalty Program 2 Lost/Stolen Service. . . 2 Boost® Customer

Care . . . . . . . . . . . . . . . . 3

Check it out. . . . . . . . . . . . 4

Menu Map. . . . . . . . . . . . 10

Use and Care. . . . . . . . . . 12

Essentials . . . . . . . . . . . . 13

About this guide. . . . . 13

SIM chip . . . . . . . . . . . 14

Battery. . . . . . . . . . . . . 15

Turn it on & off . . . . . . 19

Make a phone call. . . 19 Answer a phone call. 20 Make a Walkie-Talkie

call . . . . . . . . . . . . . . . . 20

Answer a Walkie-Talkie call . . . 20 Store a phone number or

Walkie-Talkie ID. . . . . 21

Contents

Call a stored phone number or

Walkie-Talkie ID . . . . 21

Your phone number and Walkie-Talkie ID 22

Main Attractions . . . . . . 23

boostLIVE. . . . . . . . . . 23

WT Services . . . . . . . 23

One touch WT . . . . . . 27

MMS. . . . . . . . . . . . . . 28

Basics . . . . . . . . . . . . . . . 43

Display . . . . . . . . . . . . 43

Text entry . . . . . . . . . . 44

Volume . . . . . . . . . . . . 46

Navigation key . . . . . 46

Hands-free

Speakerphone. . . . . . 47

Codes & passwords. 47 Lock & unlock phone 47

Transmitters. . . . . . . . 48

Use GPS with map

software. . . . . . . . . . . 48

Boost Mobile® Services 51

Accessories. . . . . . . . 51

Wireless local number portability: Bringing your phone number from another

carrier . . . . . . . . . . . . 51

Boost Customer Care 51

Customize. . . . . . . . . . . . 52

Ringtones. . . . . . . . . . 52

Wallpaper . . . . . . . . . 53

Backlight . . . . . . . . . . 54

Time & date. . . . . . . . 54

Hide or show location information. 54

Calls . . . . . . . . . . . . . . . . 56

Turn off a call alert. . 56

Recent calls . . . . . . . 56

Store an item to contacts from recent

calls . . . . . . . . . . . . . . 56

Redial . . . . . . . . . . . . . 57

Voice name . . . . . . . . 57

Call forward. . . . . . . . 57

Return a call . . . . . . . 58

Walkie-Talkie calls. . 59

Caller ID. . . . . . . . . . . 59

Emergency calls . . . . 60

International calls. . . 60

Speed dial. . . . . . . . . . 61

Turbo dial . . . . . . . . . . 61

Voice Mail. . . . . . . . . . 61

Receiving a Message 61

Other Features . . . . . . . . 62

Advanced calling. . . . 62

Contacts . . . . . . . . . . . 62

Datebook. . . . . . . . . . . 63

GPS . . . . . . . . . . . . . . . 64

Hands-free . . . . . . . . . 66

Messages. . . . . . . . . . 66

Personalize. . . . . . . . . 67

Security. . . . . . . . . . . . 67

Safety and General

Information . . . . . . . . . . . 70

Motorola Limited Warranty for the United

States and Canada. . . . . 77

Hearing Aid

Compatibility. . . . . . . . . . 82

Information From the World Health

Organization . . . . . . . . . . 84

California Perchlorate

Label. . . . . . . . . . . . . . . . . 86

Privacy and Data

Security . . . . . . . . . . . . . . 87

Smart Practices While

Driving . . . . . . . . . . . . . . . 88

Index . . . . . . . . . . . . . . . . . 90

Contents

Main Menu

Re-Boost

WT Service

• Send Picture

• Send Event

• Send My Info

• Send Contact

•Configure

Web

Games & Apps.

Ringtones

• Buy Ringtone s

• Vibrate All: On/Off

•Ringers

•Vibrate

• Silent

Recent Cal ls

Settings

• (see next page )

My Info

•My Name

•Line 1

• Walkie-Talkie #

•Group ID

• Carrier IP

• IP1 Address

• IP2 Address

•

j e

Circuit Data

Datebook

•[New Event]

My Pictures

Contacts

• [New Contact]

Menu Map

Messages

• [Create M essage]

• Voice Mail

• Inbox

•Drafts

•Sent Items

•Net Alert

•SMS

Voice Notes

•[New VoiceRec]

Profiles

• [New Profile]

• Standard

•Car

• At Work/In Class

• At Concer t

•On a Date

• Using Headset

• Rec WT Only

• Rec Cntcs Only

boostLIVE

Memo

Shortcuts

• [New Entry ]

• Shortcuts

• Cntcs[New Contact]

• Recent Calls

• Contacts

•Re-Boost

• Messages

• VoiceRecord

•Web

• Ring Tones

Call Timers

•Last Call

• Phone Rese t

• Phone Life time

• WT Reset

• WT Lifetime

• Circuit Reset

• Circuit Lifetime

• Kbytes Reset

GPS

• Position

•Privacy

• Interface

Call Alert

Call Forward

•Forward

• To: On/Off

This is the standard Main Menu layout. Your phone’s menu may be a little different.

Settings Menu

Display/Info

• Wallpaper

•Text Size

•Theme

• Home Icons

• Backlight

•Java Timer

• Logo Flash : On/Off

• WT Backlight: On/Off

•Clock

• Menu View

• Large Dialing

•Contrast

• Language

Phone Calls

• Any Key Ans

• Auto Redial

• Call Waiting

• Auto Ans

• Minute Beep

• Call Duration

•TTY

• Notificat ions

• DTMF Dialing

• Prepend

WT Options

• Tkgrp Silent: On/Off

•Tkgrp Area

• One Touch WT

• Alert Type

• On/Off WT Features

•Pictures

•Events

• Store Recei ved Info

• WT Backlight : On/Off

Personaliz e

• Menu Option s

• Up Key

• Down Key

• Left Key

• Right Key

• Center Key

• Left Softkey

• Right Softkey

• Power Up

Volu me

•Line 1

•Messages

• Earpiece

• Speaker

•Keypad

• Java Earpie ce

• Java Speaker

•Data

Security

• Phone Lock

• Keypad Lock

• SIM PIN

• GPS PIN

• Change Pas swords

Advanced

• Alert Timeout

• Headset/Spkr

• Connectiv ity

• Reset Defaults

• Return to Ho me

• Transmitters: On/Off

• Baud Rate

Use and Care

To care for your Motorola phone, please keep it away from:

liquids of any kind dust and dirt

Don’t expose your phone to water, rain, extreme humidity, sweat, or other moisture.

extreme heat or cold cleaning solutions

Avoid temperature s below

-10°C/14°F or above 45°C/113°F.

microwaves the ground

Don’t try to dry your phone in a microwave oven.

Don’t expose your phone to dust, dirt, sand, food, or other inappropriate materials.

To clean your phone, use only a dry soft cloth. Don’t use alcohol or other cleaning solutions.

Don’t drop your phone.

Use and Care

Essentials

CAUTION:

first time, read the Important Safety and Legal Information included in the gray-edged pages at the back of this guide.

About this guide

This guide shows how to locate a menu feature as follows:

Find it: M >

This means that, from the home screen: 1 Press the Menu Button M to open

Before using the phone for the

Settings.

the Main Menu.

032257o

2 Press the navigation key to

scroll to

center key

symbols

Settings

, and press the

to select it.

This means a feature is network/subscription dependent and may not be available in all areas. Contact your service provider for more information.

This means a feature requires an optional accessory.

Essentials

SIM chip

SIM ID

000815914837300

000000000000000

Activation Number: 00000000000000

For questions relating to Boost MobileTM Pay-As-You-Go service while in the United States, call Boost Mobile Customer Care at 1-888-BOOST-4U (1-800-266-7848) or 611 from your handset.

For more information on Boost Mobile products and services, or Boost Mobile events and Team Riders, check our boostmobile.com

Part

000815914837300

SIMGBK005R

asdkfasdlkfasdfaksdj ;alsdkfalkdjfalkdjfalsk a;ldkjf;alksdj;falsdjflak ;alsdkjf;alkdjf;alksjd;lf a;dlkjfa;ldkjf;alkdjf;alk

SIM ID 0000000000000000000

Your Subscriber Identity Module (SIM) chip can be found attached to a piece of plastic about the size of a credit card inside the “Starter Kit” that came with your phone. Your SIM chip contains personal information like your phone number and phonebook entries.

To activate your phone, you will need the SIM ID and the Activation Number located on the back of the plastic.

Pop out the SIM chip from the plastic card and insert it into the back of your phone as described next.

Essentials

Caution: Don’t bend or scratch your SIM chip. Keep it away from static electricity, water, and dirt.

Installing the SIM chip

Turn off your phone and remove your battery before you install or remove a SIM chip.

1 Carefully slide the SIM chip into

your phone, until it lies flat in the SIM chip holder.

Removing the SIM Chip

Warning: To avoid loss or damage, do not remove your SIM chip from your phone unless absolutely necessary.

Battery

Battery Use & Battery Safety

• Motorola recommends you always use Motorola-branded batteries and chargers. The warranty does not cover damage caused by nonMotorola batteries and/or chargers. Caution: Use of an unqualified battery or charger may present a risk of fire, explosion, leakage, or other hazard. Improper battery use, or use of a damaged battery, may result in a fire, explosion, or other hazard.

• Battery usage by children should be supervised.

• Important: Motorola mobile devices are designed to work best with qualified batteries. If you see a message on your display such as Invalid Battery

Essentials

Unable to Charge

, take the

following steps:

• Remove the battery and inspect it to confirm that it bears a Motorola “Original Equipment” hologram;

• If there is no hologram, the battery is not a qualified battery;

• If there is a hologram, replace the battery and retry charging it;

• If the message remains, contact a Motorola Authorized Service Center.

• New batteries or batteries stored for a long time may take more time to charge.

•

Charging precautions: When

charging your battery, keep it near room temperature. Never expose batteries to temperatures below 0°C (32°F) or above 45°C

(113°F) when charging. Always take your mobile device with you when you leave your vehicle

• When storing your battery, keep it in a cool, dry place.

• It is normal over time for battery life to decrease, and for the battery to exhibit shorter runtime between charges or require more frequent or longer charging times.

•

Avoid damage to battery and mobile device.

Do not disassemble, open, crush, bend, deform, puncture, shred, or submerge the battery or mobile device. Avoid dropping the battery or mobile device, especially on a hard surface. If your battery or mobile device has been subjected to such damage, take it to a Motorola Authorized Service Center before using.

not attempt to dry it

Essentials

with an appliance or heat source, such as a hair dryer or microwave oven.

•

Use care when handling a charged battery

when placing it inside a pocket, purse, or other container with metal objects. Contact with metal objects (e.g., jewelry, keys, beaded chains) could complete an electrical circuit (short circuit), causing the battery to become very hot, which could cause damage or injury.

Promptly dispose of used batteries in accordance with local regulations. Contact your local recycling center for proper battery disposal.

Warning: Never dispose of batteries in a fire because they may explode.

—

particularly

Battery installation

1 Remove battery cover.

2 Insert battery as shown below.

Push the battery down until it snaps in place.

3 Replace the battery cover.

Essentials

Battery charging

New batteries are not fully charged. Plug the battery charger into your phone and an electrical outlet. Your phone might take several seconds to start charging the battery.

To charge using the charger: 1 Insert the charger into the USB

connector on your phone as shown.

Plug the other end of the charger into the appropriate electrical outlet

3 When your phone displays

Complete

, remove the charger.

Charge

When you charge the battery, the battery level indicator at the upper right of the screen shows charging progress. At least one segment of the indicator must be visible to ensure full phone functionality while charging.

Tip: Motorola batteries have circuitry that protects the battery from damage from overcharging. Of course, unplugging the charger from the wall will avoid current drain.

To charge from your computer: You can charge your phone’s

battery by connecting a cable from your phone’s mini-USB port to a highpower USB connector on a computer (not a low-power one, such as the USB connector on your keyboard or buspowered USB hub). Typically, USB highpower connectors are located directly on your computer.

Note: The phone will be charged at a slower rate than it is charged with the rapid charger.

Essentials

Your computer must be turned on, and you must have correct software drivers installed on your computer. If the phone is off when the USB cable is connected between the computer and the phoen, the phone will power up in charging mode. This mode allows the phone to charge fastest and quickest.

Note: If the battery is very low, the phone will not turn On, but it will continue to charge at a low rate.

If the phone is turned on while charging from a computer, it will not fully charge the battery. In this case, the battery charge will be maintained approximately between 80% and 95% of the battery’s capacity. Cables and software drivers are available in Motorola Original separately.

Tip: Motorola batteris have circuitry that protects the battery from damage from overcharging.

data kits, sold

Turn it on & off

To turn on your phone, press and hold a few seconds or until the display turns on.

To turn off your phone, press and hold

for

for two seconds.

Make a phone call

Enter a phone number and press S to make a call, or use a voice name command. See “Voice name” on page 57.

Note: For best quality, avoid covering the internal antenna with your hand.

To hang up press E.

Essentials

Answer a phone call

When your phone rings and/or vibrates, you have the following options to answer:

1 If you want to answer the call on the

handsfree speaker phone, press the speaker key

2 If you want to hear the audio

through the earphone, press

3 To hang up press

2 Push and hold the PTT button. Begin

talking after your phone emits a

chirping sound. 3 Release the PTT button to listen. 4 To end the call press

A WT call ends automatically if

there is no activity on the call for a

few seconds. Tip: To let someone know you want to

talk to them on a WT call, press under

Alert

under

Exit

Make a Walkie-Talkie call

With Walkie-Talkie calls service, you use your phone as a long-range, digital Walkie-Talkie using one-to-one WT calls.

Your Walkie-Talkie ID is the number at which you recieve one-to-one WT calls.

1 To make a WT call enter the Walkie-

Talkie ID you want to call.

Essentials

Answer a Walkie-Talkie call

1 When your phone emits a chriping

sound or vibrates to indicate you are

receiving a WT call, wait for the

caller to finish speaking. 2 Push and hold the PTT button and

begin talking after your phone emits

a chirping sound.

3 Release the PTT button to listen. 4 To end the call press

under

Exit

Store a phone number or Walkie-Talkie ID

You can store a phone number or a Walkie-Talkie ID in

Shortcut: From the home screen press under

Contcs

Find it: M > e >

1 Enter a name for the new entry and

press

contain up to 20 characters.

2 Select a specific

press

3 Select a type for the entry (

Walkie-Talkie, Work1, Work2 Home, Fax, Pager

press

Contacts

[New Contact]

Each entry’s name can

Ringtone

, or

Other

and

Mobile

) and

4 Enter the number for the entry and

press

under

entry

Tip: You can scroll left or right to store and view other information for the entry. You can choose a special ringer, store an Email address, assign a Group, and more.

After you have saved the number, the new Contacts entry is displayed.

Done

Call a stored phone number or Walkie-Talkie ID

Shortcut: From the home screen press under

Contcs

Find it: M > e

1 Scroll to the

Tip: By pressing the first letter of the name of the contact you want, you

Contacts

to save the

entry.

Essentials

will be taken to all the contact names starting with the letter you pressed.

2 If the contacts entry contains more

than one number, scroll left or right until the type of the number you want to call is displayed (

Walkie-Talkie, Work 1, Work 2, Home,

etc.).

3 If you choose a phone number,

press or If you choose a Walkie-Talkie number

or Talkgroup ID, press and hold the Walkie-Talkie button to call the number.

Tip: If the contact you scrolled to contains a Walkie-Talkie number, you can make an instant Walkie-Talkie call to that Walkie-Talkie ID by pressing and holding the Walkie-Talkie button, even if the Walkie-Talkie ID is not the type of number displayed on the screen.

to call the entry.

Mobile,

Your phone number and Walkie-Talkie ID

Find it: M > e >

Tip: Want to see your phone number and/or Walkie-Talkie ID while you’re on a call? Press

> X

> O.

Essentials

Main Attractions

boostLIVE

Your i290 comes with a main menu icon that takes you directly to the web site.

You can download ringtones, wallpapers and Java applications over the air.

boostLIVE

WT Services

Your phone can send and receive the following items through Walkie-Talkie calls with other phones that have this capability:

• Events from the Datebook

• My Info

• Contacts

•Pictures

You can choose to send Events, My Info, Pictures or Contacts to any Walkie-Talkie number on the recent calls list, or Walkie-Talkie numbers stored in Contacts.

When you make or receive a WalkieTalkie call, your phone automatically determines whether the phone you are in a Walkie-Talkie call with is able to receive each of these items. Your phone saves this information for as long as the Walkie-Talkie number is on your recent calls list or is saved in your Contacts. Your phone updates the saved information each time you make or receive a call to or from that Walkie-Talkie number.

*. Additional charges may apply.

Main Attractions

You can turn your phone’s ability to send and receive events from the datebook or pictures on and off.

Find it: M > R > WT Options > On/Off WT Features.

1 Select 2Press My Info and Contact information are set

to ON by default and they cannot be turned off.

Pictures

under

and/or

Done

Events

Send Events

To send an event from the

Find it: M > b

1 Find the event you want to send.

2Press 3 Select a contact from the

list or 4 Press the WT button to send. The event is sent to the person you

selected.

Send via WT

Recent Calls

Datebook

Contacts

Send My Info

To send My Info from the 1Press 2 Scroll to any contact and press M. 3 Select

4 Select a contact from

5 Press the WT button to send. Your contact information is sent to the

person you selected.

WT Send My Info

under

Contacts

under

Browse

list or

Contcs.

Memo

Send Contacts

To send contacts from the 1Press 2 Scroll to any contact and press M. 3 Select 4 Select a contact from

5 Press the WT button to send.

under

Transfer > Send Via PTT

Contacts

list or

Contcs.

Memo

Contacts

list:

and press

Recent Calls

Contacts

Recent Calls

list:

Main Attractions

The contact is sent to the person you selected.

Send a Picture

When you send a picture, it appears on the phone you are in a Walkie-Talkie call with.

If the other user accepts the picture, their phone saves it. The picture then appears in that phone’s recent call list and in My Pictures.

Send a stored picture during a Walkie-Talkie call

While in a Walkie-Talkie call

under

1 Press

or Press

Send Picture

A list of pictures that can be included in a WT call appears.


> Use WT Feature >

2 Select the picture you want to

send.

3 Press the WT button to send the

picture.

4 Wait while the picture is being

transmitted. The WT call is temporarily interrupted while a picture is transmitted.

5 When prompted, press the WT

button to resume the call.

The first time you send a stored picture after turning the phone on, you will see the following message:

May Apply. Continue?

If you answer following message:

Limited. Limit 30KB.

Yes

Picture Fees

, you will see the

File Size for PTV Is

Start a call by sending a picture

You can start a call by choosing a picture:

From

My Pictures:

Main Attractions

1Press M > WT Send 2 Select

3 Select the name of the person you

4 Press the WT button to send the

5 Wait while the picture is

6 When prompted, press the WT

A Contact

A list of Contacts that have Walkie-

Talkie numbers and are able to

receive pictures appear in each

case.

want to send the picture to.

picture.

transmitted. The Walkie-Talkie call

is temporarily interrupted while a

picture is transmitted.

button to resume the Walkie-Talkie

call.

A Recent Call

Receive a picture

When someone sends you a picture, your phone emits a tone or vibrates and a message appears asking if you want to accept the picture.

Pictures you receive are saved to your phone’s memory and they are accessible through My Pictures.

When you see a message asking if you want to accept the picture, press accept or

Tip: To stop the transmission before it is finished, press

Note: The first time you accept a stored picture after turning the phone on, the following message appears:

Fees May Apply. Continue?

prompted to respond. Press accept the picture. Press the picture.

to decline.

Yes

Messaging

and you are

Yes

to decline

Clear a picture from the display

If you want to remove a picture from your phone’s display while still on a call, press

Clear Screen

The picture will not appear on the display again the next time you receive a

Main Attractions

call from person who sent it. This does not delete the picture from your phone.

One touch WT

One Touch WT sets your phone to do any of the following each time you press the WT button:

• Call the most recent WalkieTalkie number or Group on the recent calls list

• Call a Walkie-Talkie number you assign

• Go to Quick WT

• Go to WT Manager

• Go to the first screen to send a message, Picture, My Info, or a Contact information during a call

Set one touch WT to call recent calls

Find it: M > R > WT Options > One Touch WT > Last Call.

Set one touch WT to call assigned IDs

Find it: M > R > WT Options > One Touch WT > Assigned No.

To enter the Walkie-Talkie number you want your phone to call every time you press the WT button:

1 Enter the number using your

keypad or press

Recent Calls

number you want to enter.

2 Press

, or

Memo

Contacts

> select the

Turn off one touch WT

Find it: M > R > WT Options > One Touch WT > Off.

Set My Info sending option

You can control what portion of the information in whether it is sent automatically in every call or only when you choose to send it.

My Info

is sent and

Main Attractions

The information your phone sends always includes

Talkie

. You may also send

, and

Circuit Data

sending options. To change the fields you send:

Find it: M > X > M > WT Send Setup > Info To Send.

1 Add or remove the checkmarks. 2Press

My Name

, depending on your

under

Done.

and

Walkie-

Line 1, Carrier

Automatic sending

To control whether you send your information automatically:

Find it: M > X > M > WT Send Setup > Auto Send.

1 Select On or When you make a call in which your

information is sent automatically, the name you entered in the of

My Info

recipient’s phone, even if your name and

Off

My Name

appears on the display of the

field

Walkie-Talkie number are not stored in the recipient’s

Contacts

MMS

Multi-Media Messaging Service (MMS) lets you send and receive messages that may include text, pictures and audio recordings.

Create a message

To begin creating a message from the idle screen press press

To address the message: 1 Select 2 Add the phone number or email

address.

3 Select from

Calls

4Press

>Y>

under

Mesg.

[Create Mesg]

Contacts

Recent

Main Attractions

Tip: To remove a phone number or email address from the list of message recipients, scroll to the phone number or email address and press

Remove

When you are finished addressing the

message, press To enter or edit the body of the

message: 1 Select 2 Enter text or use a

press

3 Press

under

Message

under

Back

Quick Note

Send

under

and

More message options

View more message fields in a message you are creating, select

To create or edit the subject line, select

Subject

1 Enter text and press

2 Select You can insert a list of replies the

recipient can choose from when replying to your message by selecting

Auto Replies

choices. To set the priority of the message,

select you need.

To receive a report confirming your message delivery, select

Delivery

To set a date after which attempts to deliver the message end, select

Until

1 Select a date by scrolling or

2 Select 3 Press

Quick Note

and entering several text

Priority

entering numbers. or

No Date

under

>O.

and select the priority

Report

Valid

> O.

Send

or M >

Send

Main Attractions

Reply to a message

You can reply to a message while you are viewing it, or while a previously viewed message is highlighted in the message center. You cannot reply to unread messages.

To reply to a message: 1 View the message you want to reply

to.

2 To reply to the sender only, press

under

or if you wish to include all the people copied in the message, press

3 A list of short phrases appears.

Select any of these phrases to add it to your messages or select

Reply]

4 Edit any message fields you want to

change.

5 Send the message.

under

Reply All

[Create

Quick notes

When you are filling in the

Subject

message fields, you can add ready-made words or short phrases called Quick Notes. After you add these words or phrases, you can edit them as you would any other text.

1 While you are creating a message,

scroll to or select

Subject

2Press

3 Select the Quick Note you want to

under

Insert QuickNotes

insert into the message.

Message

QNotes

Attach a picture and audio recording or a ringtone

You can attach one or more pictures audio recordings or ringtones from your phone into the body of the message. You can include text in the body of your message in addition to these items.

Message

or M >

and

Main Attractions

Attach items

While you are filling in the press

[New]

My Pictures,

VoiceRecord

A list of available pictures, audio recordings and ringtones appears.

Select the picture, voice record or ringtone you want to attach.

Tip: To view or listen to the item before attaching it, highlight it and press under

View

or -

Ringtones

under

Attach

Play

field,

Create a new voice record

You can create a new voice record to send with a message:

1 Press 2 Select

3 Say the message you want to

4 When you are finished recording,

or select

VoiceRecord

VoiceRec].

record into the microphone.

press

Attach

[New

[New]

5 When you are finished, press

under

Back

and - under

The voice record is attached to the message and saved to the list of voice records.

Remove an attachment

To remove an attachment in a message you are creating:

1 Select 2 Scroll to the attachment you want

3 Press

Attach

to remove.

Unattach

Drafts

While you are creating a message, you

can save it in the MMS drafts folder before you send it.

You can view, edit, send, or delete saved drafts.

Done

Main Attractions

Save a message in the MMS drafts folder

From the Message center press M >

Save.

You can continue to create the message. The version you saved in the MMS drafts folder will not change.

To delete a message in the MMS drafts folder without sending it, scroll to the message you want to delete and press

under

Delete

and - under

Yes

MMS outbox

MMS messages you have sent or tried to send are stored in the MMS Outbox.

Send a draft

Find it: M > Y > Drafts.

1 Select the draft you want to send. 2Press

Send.

Edit a draft

Find it: M > Y > Drafts.

1 Select the draft you want to edit. 2Press

Delete a draft

When you send a draft, it is removed from the MMS drafts folder.

Main Attractions

Forward items from the outbox

Find it: M > Y > Sent Items.

1 Scroll to the message you want to

forward. 2Press 3 Edit and send your message.

Forward

Resend

If a message was not sent from your handset, you can resend it.

Find it: M > Y > Sent Items.

1 Scroll to the message you want to

resend.

2 Press - under Note: If your message was sent

successfully, an option.

Resend

will not appear as

Check delivery status

If a message was successfully sent and you set the message to give a report confirming delivery, you can check the delivery status:

Find it: M > Y > Sent Items.

1 Scroll to the message you want to

view.

2 Press

Delivery Status

Delete a message

1 Scroll to the message you want to

delete.

under

Delete

2 Press 3Pres 4 Select the message or messages

Delete Multiple

you want to delete

, or

under

Delete

5 Press

to confirm.

Receive a message

When you receive an MMS message, a message notification appears on the display.

To view the message: 1 Press 2 If the message fills more than one

screen, use the navigation key to scroll down and read the remaining text.

Message Notifications

When you receive a message, your phone notifies you with text on the display, a notification tone or vibration, and by flashing the Boost logo backlight slowly.

You can access the message or dismiss the notification.

Main Attractions

If you dismiss the notification, the message is not deleted. It can be accessed through the message center.

If you are not on a phone call when you receive a message, your phone sounds a notification tone every 30 seconds until you access the message or dismiss the alert.

If you are on a call when you receive a message, your phone may sound a notification tone during the call or after you end the call, depending on how you set your notification options.

Setting Notification Options

To control whether your phone sounds message notification tones while you are on phone calls:

Find it: M > R > Phone Calls > Notifications.

1 Select the option you want:

•

Receive All

during calls for all types of messages.

•

Msg Mail Only

during calls for mail messages; tones for all other types of messages are held until you end calls.

•

Delay All

messages are held until you end calls.

Note: Delay All is the default

setting.

Tip: To set notification options during a call press

Notifications

— Tones sound

— Tones for all types of

In Call Setup

Embedded objects and attachments

Messages may contain pictures or audio recordings as part of the body of the message or as attachments.

Main Attractions

If a message contains pictures or audio recordings in the body of the message, highlight each picture or audio recording to view or play it.

If a message contains a picture or audio recording as an attachment, open the attachment to view the picture or play the audio recording.

Open attachments

1 View the message. 2 Highlight the attachment you want

to open. Attachments appear at the end of a message.

3 Press Note: Attachments that are of an

unknown type cannot be opened, but they can be deleted.

View received messages from the message center

1 Press M > Y >

Inbox

2 Select the message. If the message has not yet been

downloaded from the message server, it is downloaded now.

Delete unread messages

1 Scroll to the message you want to

delete. 2 Press 3 Press

under under

Delete

Yes

to confirm.

Forward a message

1 Press M > 2 Create and send your message.

Embedded objects and

attachments are included when

you forward a message.

Forward

Lock and unlock messages

Locked messages cannot be deleted until you unlock them.

Main Attractions

1 View the message you want to lock

or unlock. 2Press 3 Select

Lock Message

Message

Unlock

Call a number in a message

If a message you receive contains a phone number, Walkie-Talkie number, or Talkgroup ID in the From field, the To field, the Cc field, the subject line, or the body of the message, you can call or send a call alert to that number.

Send a call alert

1 View the message. 2 Highlight the Walkie-Talkie number

or Talkgroup ID you want to alert. 3Press 4 Press the WT button.

Alert

Make a group call

1 View the message. 2Press 3 Highlight the Talkgroup ID you want

4 Select 5 Press the WT button.

to call.

Talkgroup

Store message information to contacts

If a message you receive contains a phone number, Walkie-Talkie number, Talkgroup ID, or an email address in the From field, the To field, the Cc field, the subject line, or the body of the message, you can store this information to Contacts.

1 View the message. 2 Highlight the number or email

address you want to save.

3Press

Main Attractions

4 Select 5 To store the number or email

To store the number or email address to an existing entry, select the entry.

6 With the Contacts type field

7 Press

Save Number

address as a new entry, select

[New Contact]

highlighted, scroll left or right to display the Contacts type you want to assign the number or email address.

Save

Save Email

Go to a website

If a message contains one or more website URLs, you can go to that website.

1 View the message. 2 Highlight the website URL you want

to go to.

3 Press 4 Select

Go To Website

Note: The entire URL must appear in the message to allow you to open the website.

Save an embedded picture or audio recording

To save a picture or audio recording that is part of the body of a message you receive:

1 View the message. 2 Highlight the picture or audio

recording you want to save. 3 Press 4 Select The item will save in the default storage

location. Note: Some types of pictures and audio

recordings can be viewed or played, but not saved.

Save Picture

Save Audio

Main Attractions

Delete an embedded picture or audio recording

To delete a picture or audio recording that is part of the body of a message you receive:

1 View the message. 2 Highlight the picture or audio

recording you want to delete. 3Press 4 Select

Note: You may save or delete pictures and audio recordings from slide shows individually as you view or listen to them.

Audio

Delete Picture

Delete

Save attachments

1 View the message. 2 Highlight the attachment you want

to save.

3Press

4 Select Selected items save to the default

storage location. Note: Some types of pictures and audio

recordings can be viewed or played, but not saved.

Save Attachment

Delete attachments

1 View the message. 2 Highlight the attachment you want

to delete.

3Press 4 Select 5Press

Delete Attachment

Yes

to confirm.

Save a picture

1 View the slide show. 2 When the picture you want to save

appears, press

3 Select

Save Picture

Main Attractions

Save audio

1 View the slide show. 2 Press 3 Select 4 If the slide show contains more

Save Audio

than one audio recording, a list of the audio recordings appears. Select the audio recording you want to save.

Delete a slide show

1 Highlight the slide show or view the

slide show.

2 Press 3 Select

Message transmission

After you start to send a message you have created or start to download a message you have been sent, you can still stop the message transmission

Delete Slideshow

from being completed by pressing the soft key

Customize MMS

The MMS Setup menu lets you customize MMS for your handset:

Friendly Name —

create a friendly name. Your friendly name is the name displayed in the From field on other iDEN handsets when they receive messages from you.

Signature —

signature. Your signature is text that is automatically inserted at the end of all messages you create. You can edit the text before sending the message.

Quick Notes —

Quick Notes and edit or delete Quick Notes you have created.

Replies —

phrases and edit or delete reply phrases you have created.

Enter text here to

Enter text here to create a

Lets you create new

Lets you create new reply

Main Attractions

Cleanup —

remain in the Inbox and Outbox before they are deleted.

Downloads —

phone automatically downloads new messages when they arrive, or only after you respond to a prompt or read the message from the Inbox. Set this option to

Automatic

download new messages automatically; set the option to your phone to prompt you before downloading new messages.

Memory Size —

Used, Free

phone’s memory. To access the MMS Setup menu:

Find it: M > Y > M > Setup

Tip: This option is available from many context-sensitive menus when you are using MMS.

Controls how long messages

Controls whether your

if you want your phone to

Manual

if you want

Shows the total amount

and total

Capacity

of the

New quick notes and reply phrases

To create quick notes: 1 From the MMS Setup menu, select

Quick Notes

2 Select

Reply].

3 Enter text from the keypad. 4Press To edit quick notes: You can edit only Quick Notes and reply

phrases you have created. 1 From the MMS Setup menu, select

Quick Notes

2 Select the Quick Note or reply

phrase you want to edit. 3 Edit the text. 4Press To delete only Quick Notes and reply

phrases you have created:

Replies

[New Quicknote]

Replies

[New

Main Attractions

1 From the MMS Setup menu, select

Quick Notes

2 Scroll to the Quick Note or reply

phrase you want to delete. 3 Press 4 Press To delete all Quick Notes or all reply

phrases you have created: 1 From the MMS Setup menu, select

Quick Notes

2 Press 3 Select 4 Press

Delete

Yes

to confirm.

Delete All

Yes

to confirm.

Replies

Set the clean-up option

The clean-up option controls how long messages remain in the Inbox and Outbox before they are deleted. You set the clean-up option for the Inbox and Outbox separately.

The clean-up option deletes only read, unlocked messages.

Clean-up options

Off —

Messages are never

automatically deleted.

5 Messages —

messages, messages are deleted in the order they were received, starting with the oldest, until 5 are left.

10 Messages —

10 messages, messages are deleted in the order they were received, starting with the oldest, until 10 are left.

With these options, messages are deleted in the order they were received, starting with the oldest, until the selected number are left.

1 Day —

are older than 1 day.

3 Days —

are older than 3 days.

If you have more than 5

If you have more than

Messages are deleted if they

Main Attractions

With these options, messages are deleted when you exit the message center after setting the option.

Custom —

option of up to 99 messages or 99 days.

Lets you create a clean-up

From the Inbox

1 From the MMS Setup menu, select

Cleanup

2 Choose a clean-up option. 3 To automatically delete messages

now, press messages later.

Inbox

Yes

or press No to delete

From the Outbox

1 From the MMS Setup menu, select

Cleanup

2 Choose a clean-up option. 3 To automatically delete messages

now, press messages later.

Sent Items

Yes

or No to delete

Delete all messages

To delete all unlocked messages from the MMS Inbox, all messages in the MMS drafts folder, or all successfully sent messages in the MMS Outbox:

1Press 2 Go to the MMS Inbox, the MMS

drafts folder, or the MMS outbox. 3Press 4 Select 5Press

Messages

Delete All

Yes

to confirm.

Main Attractions

Basics

Time &

Date

Right Soft Key Label

Left Soft

Key Label

Exit

See page 4 for a basic phone diagram.

Display

The home screen shows when you turn on the phone. To dial a number from the home screen, press number keys and

Note: Your home screen may look different.

Soft key labels show the current soft key functions. For soft key see page 4.

locations,

Status indicators

Status indicators are shown at the top of the home screen:

Signal Strength Indicator – Vertical

bars show the strength of the network connection. You can’t make or receive calls when

shows.

Active Phone Line – 1 indicates

phone line 1 is ready to make calls.

Speaker Off – Sounds associated

with Walkie-Talkie calls and group calls are set to come through the

1 or

Basics

earpiece rather than through the speaker.

Ringer Off – Your phone is set to not

ring.

Message Indicator – Shows

when you receive a text message.

Packet Data – Your handset is ready

to transfer or is transferring packet data.

Battery Charge Indicator –

battery indicates a greater charge. Recharge the battery when your phone shows

Low Battery

A fuller

Text entry

Some features let you enter text. Your phone provides convenient ways to

enter words, letters, punctuation, and numbers whenever you are prompted to enter text (for example, when adding a

Contacts entry or when SMS text messaging).

To change the character input mode: 1 When you see a screen where you

can enter text, press

the character input mode. 2 Select one of the following options:

entry modes Alpha

Word

Symbols Numeric

Tip: When entering text, press change letter capitalization ( >

abc

Press a key several times for each character.

Enter words using a predictive text entering system that lets you enter a word with fewer keypresses.

Enter symbols. Enter numbers by

pressing the numbers on the keypad.

to change

Abc

ABC

Basics

Word mode

Word English Text Input lets you enter text into your phone by pressing keys just once per letter.

Word English Text Input analyzes the letters you enter using an intuitive word database and creates a suitable word. (The word may change as you type.)

To enter a word using Word Character Input:

1 Select the

mode.

2 Press the corresponding keys once

per letter to enter a word (for example, to enter the word press a mistake, press single character. Press and hold

3 To accept a word and insert a

space, press

Word

character input

5333

to delete an entire entry.)

). (If you make

to erase a

Jeff

To accept a word completion (such as Jeffrey when you entered Jeff), press

right

Alpha mode

To enter characters by tapping the keypad:

1 Select the 2 Press the corresponding keys

repeatedly until the desired letter appears. (For example, to enter the word times, three times again. If you make a mistake, press single character. Press and hold

Delete

By default, the first letter of an entry is capitalized and the following letters are lowercased. After a character is entered, the cursor automatically advances to the next space after two seconds or when you enter a character on a different key.

Alpha

mode.

Jeff

, press 5 once, 3 two

three times, and 3

Delete

to erase a

to erase an entire word.)

Basics

Characters scroll in the following order:

characters

2 3 4 5 6 7 8 9 0 # *

. ? ! , @ & : ; “ - ( ) ‘ ¿ ¡ %

£ ¥ A B C 2 Á Ã Â À Ç D E F 3 É Ê È G H I 4 Í Ì J K L 5 M N O 6 Ó Õ Ô Ò P Q R S 7 ß T U V 8 Ú Ü Û Ù W X Y Z 9 + - 0 * / \ [ ] = > < # Space Back

Volume

Press the volume keys to:

• turn off an incoming call alert

• change the earpiece volume during calls

• change the ringer volume from the home screen

Tip: Sometimes silence really is golden. That’s why you can quickly set your ringer to

All

by holding the down volume

key in the home screen.

Navigation key

Press the navigation key up, down, left, or right to scroll to items in the display.

Vibrate

Basics

When you scroll to something, press

Hands-free Speakerphone

You can use your phone’s hands-free speaker to make calls without holding the phone to your ear.

During a call press the speaker ON/OFF key

to turn the hands-free speaker

on. The hands-free speaker stays on until

you press thespeaker ON/OFF key or end the call. The next phone call will redirect the audio back to the earpiece.

Codes & passwords

The Security menu lets you turn security features on and off and change passwords:

SIM PIN

phone’s SIM PIN security feature.

— Enables and disables your

GPS PIN

phone’s GPS PIN security feature.

Change Passwords

phone unlock code, security code, SIM PIN, and GPS PIN.

— Enables and disables your

— Changes your

Lock & unlock phone

Phone Lock — Turns on a feature that

locks your phone: effect immediately; effect when your phone is powered off and then on. An unlock code is required to enable this feature, to unlock the phone, and to set a new unlock code. Contact your service provider for your default unlock code.

Keypad Lock

keypad, either immediately or automatically after a set period of inactivity.

Lock Now

Auto Lock

— Locks the phone’s

takes

Basics

lock keypad

You can lock your phone’s external keys to prevent accidental key presses.

To lock the external keys automatically after a specified time:

Find it: O

Auto Lock.

Tip: You can lock the keypad inmediately by pressing

> Security > Keypad Lock >

and *.

Transmitters

Note: Consult airline staff about the use of the Transmitters feature during flight. Turn off your phone whenever instructed to do so by airline staff.

Transmitters turns off your phone’s calling features in situations where wireless phone use is prohibited. You can use the phone’s other non-calling features when Transmitters is turned off.

Find it: O > Advanced

Off

Transmitters

Use GPS with map software

Your phone is enabled with a highlycapable GPS receiver that sends location information to a USB port on a PC, laptop, or PDA.

Note: No serial port connectivity is provided by your phone. Applications on the host device which are expecting to receive the GPS location information via a serial port must instead use a Virtual Serial Comm Port.

The data sent to the host device is formatted as prescribed in the National Marine Electronics Association 0183 V3.0 (NMEA-0183) standard. As such it supports the following sentences: GGA, GLL, GSA, GSV, RMC, and VTG.

Note: This handset is not a full NMEA0183 compliant device supporting electrical RS-422/RS-232 connectivity as dictated by the NMEA-0183 standard. Consequently it's unsuitable for

Basics

conventional marine NMEA-0183 equipment use. Its intended use is for normal "terrestrial" mobile users who want to enable their USB hosting computing devices such as a PC, laptop or PDA with the phone's highly-capable GPS functionality.

Get Connected

1 Slide open the phone's

bottom connector and insert a miniUSB cable into the phone's bottom connector.

2 Insert the other end of the mini-

USB cable into a vacant USB receptacle of your host device. A virtual USB Comm Port will be created on your host device upon successful enumeration of the phone as a USB Communications Device Class device.

3 Ensure no application in your host

device is using the created COMM port. You may need to ensure that

the created virtual COMM port settings are set as follows:

• Bits per second: 4800

• Data bits: 8

• Parity: None

• Stop bits: 1

• Flow control: None.

4 Start the GPS application on your

host device. Set the GPS application to start accepting NMEA-0183 formatted data from the created Virtual COMM port.

5 Set your phone to start sending

NMEA-0183 formatted location information.

Find it: M > i > Interface > NMEA OUT

> USB.

Your phone is now actively sending location NMEA-0183 formatted GPS data to your USB host device.

To stop your phone from sending location data:

Basics

Find it: M > i > Interface > NMEA OUT >

Off.

Note: Each time you power your phone Off, NMEA OUT is automatically set to Off and you need to manually restart it using the menu selections above.

Note: Your USB host device will generally provide charging power (5V, up to 500mA) to your phone via the miniUSB cable therefore no other charging power to it will normally be required. However some laptops may require that you provide external AC/DC power to the laptop in order for it to provide full 500mA charging current capability to the phone.

Basics

Boost Mobile® Services

Accessories

Your phone comes with a Lithium Ion Battery and travel charger.

Various accessories are available for use with your vehicle power charger, data cables, hands-free accessories and more.

To order additional accessories, go to boostmobile.com. You can also contact your Boost Authorized Dealer. For information on Boost retail store locations, go to boostmobile.com.

i290

phone, cases,

Wireless local number portability: Bringing your phone number from another carrier

Please contact for information about this service.

Boost Customer Care

1-888-BOOST-4U (1-888-266-7848) or dial 6-1-1 from your i290 phone.

Boost Mobile® Services

Boost Customer Care

Customize

Ringtones

To set the ringtone your phone makes when you receive phone calls, call alerts, message notifications, pictures sent using Send via WT or Datebook reminders:

Note: Only ringtones stored in your phone’s memory are available in the ringtones list. Not all audio files can be assigned as ringtones.

Find it: M > T.

1Make sure 2 Scroll through the list of ringtones

and select the one you want to assign. vibrate instead of making a sound;

Silent

vibrate nor make a sound.

Customize

Vibrate All

Vibrate

sets your phone to neither

is set to

sets your phone to

Off

Tip: Highlighting a ringtone lets you hear it.

3 Select the features you want to

assign the ringtone to.

4 When you are finished, press

Note: This icon display if you set your phone to neither vibrate nor make a sound for phone calls.

appears on the

Done

Setting your phone to vibrate

You can set your phone to vibrate instead of making a sound when you receive all phone calls, Walkie-Talkie calls, group calls, call alerts, messages notifications, pictures sent using Send via WT, and Datebook reminders.

Find it:

> Vibrate All

1 Set this option to On or

Locked

Setting this option to On lets you turn

Vibrate All

up volume control. Setting this option to press and hold the up volume control to turn

Locked

from accidentally turning

All

off.

Tip: To set using the volume controls: Press the volume controls to turn down the volume as far as possible to set

All

volume control to set

Locked

To set your phone to vibrate instead of making a sound for some features but not others:

1 From the Main Menu, select

2 Make sure 3 Select

Vibrate All

to On. Continue to hold the down

Ringtones

Vibrate

ringtones.

off by pressing the

Locked

requires you to

Vibrate All

option helps prevent you

to On or

Vibrate All

from the list of

off. The

Vibrate

Vibrate All

is set to

Locked

Vibrate

Off

4 Select the features you want to set

to make no sound.

5 When you are finished, press

Wallpaper

Set a photo or picture as a wallpaper (background) image in your phone’s home screen or throughout all menu screens.

Find it: O

To select a wallpaper image:

1 Scroll through the list of pictures

Note: You can set the wallpaper to change automatically after a certain period of time by turning on the

Cycle

menu.

> Display/Info > Wallpaper.

and press of your choice.

feature located in the Wallpaper

to select the picture

Done

Auto

Customize

Backlight

Set the amount of time that the display, java apps., the Boost logo and the PTT button backlights remain on, or turn off backlights to extend battery life.

Find it: O

> Display/Info > Backlight

Time & date

Time Shift

all Datebook events. This is useful if you are traveling to a different time zone.

Alert Timeout

time a tone continues to sound when you receive a Datebook reminder.

Clock

date appear on the home screen; sets time and date format.

— Lets you shift the times of

— Sets the amount of

— Controls whether the time and

To access Datebook set up options:

Find it: M > b >

You can view or change these options:

Start View

day view, week view, or month view when you access Datebook.

Daily Begin

your day. This is the earliest time of day displayed in week view, if you have a 12hour day view.

Delete After

Datebook waits to delete an event after it occurs.

— Sets Datebook to start in

Customize

> Setup

— Sets the beginning of

— Sets the amount of time

Hide or show location information

Your phone is equipped with a Location feature for use in connection with location-based services that may be available in the future.

The Location feature allows the network to detect your position. Turning Location off will hide your location from everyone except 911.

Note: Turning Location on will allow the network to detect your position using

GPS technology, making some applications and services easier to use. Turning Location off will disable the GPS location function for all purposes except 911, but will not hide your general location based on the cell site serving your call. No application or service may use your location without your request or permission. GPSenhanced 911 is not available in all areas.

To set your Privacy Options:

Find it:

1 Select

> Privacy

Restricted, Unrestricted

Ask Access.

, or

Customize

Calls

To make and answer calls, see page 19.

Turn off a call alert

You can press the volume keys to turn off a call alert before answering the call.

Recent calls

The recent calls list contains information associated with calls you have made and received and call alerts you have received.

When you send or receive Walkie-Talkie calls, the recent call list contains the following WT items with those calls:

• Contacts received

• My Info received

• Pictures sent or received

Calls

The recent calls list displays up to 20 of the most recent calls and call alerts.

Find it: M >

Tip: You can also access the Recent Calls list by pressing the navigation key

down. 1 Scroll through the list. 2 Highlight the item you want to view

or perform some action on.

3 To view more details of the items

press

Store an item to contacts from recent calls

Phone calls, Private calls, My Info received from other phones, or Contacts entries received from other phones can

be stored to the Contacts list from the Recent Calls list.

Find it: M > c.

1 Scroll to or select the item you

want to store.

2 Press

3If

4 Press

Save

to store the information

as a new entry in the Contacts list. or

Save

is not one or you options,

press

Update Contacts

select the contact you want to update.

Done

to save your changes.

. And

Redial

To redial your last outgoing call, press

and hold

previously assigned a voice name to your contacts.

To assign voice names to contacs: 1 Press - under

[New Contact]

2 Assing a name, phone number and

select

[Options]

3 Select

4 Press

To place a call using voice command: 1 From the home screen press and

The handset will automatically place the call.

Voice Name

propmt to record the voice name.

Done

to save the entry.

hold the speaker key until you are prompted to say the voice name.

under

Contcs

and follow the

Back

and - under

and select

Voice name

You can place calls by speaking comands to your phone if you have

Call forward

Call forwarding sends calls to the phone numbers you specify. You can

Calls

forward all calls to one number or forward missed calls to different numbers depending on the reason you missed the call. You can forward phone lines 1 and 2 independently.

Find it: M > c.

1 To forward all calls select

and select number you want all your calls forwarded to.

2 You can specify a forwarding

number for each type of missed call by selecting following options:

If Busy call or transferring data.

If No Answer answer on the first 4 rings.

If Unreachable handset is out of coverage or powered off.

To:

to enter the phone

Detailed

: When your handset is on a

: When you do not

: When your

All Calls

and chosing the

Return a call

When an incoming call is not answered, the Missed Call log is displayed on your screen.

To display the Missed Call entry from the notification screen, highlight the entry and press

To dial the phone number, press under

To display a Missed Call entry from standby mode:

1Press 2 Scroll to the item containing the

Call

number you want to call.

• If you scroll to a call, you can make a call to the number that made the call. If the number is stored in Contacts, you can make a call to any of the numbers stored with it.

• If you scroll to contact information from another phone,

Calls

you can make a call to any of the numbers in the contact information.

3 To place the call now press

Walkie-Talkie calls

A Boost Walkie-Talkie call ends automatically if there is no activity on the call for a few seconds.

Tip: To let someone know you want to talk to them on a Walkie-Talkie call, press the soft key under

Alert.

With Walkie-Talkie calls, you use your phone as a long-range, digital walkietalkie.

Make Walkie-Talkie calls:

1 From the home screen enter the

Walkie-Talkie number you want to call, or if you have stored contacts with Walkie-Talkie numbers, browse your contacts list.

2 Press and hold the WT button on

the side of your phone. Begin talking after your phone emits a chirping sound.

3 Release the WT button to listen.

Caller ID

Caller ID allows people to identify a caller before answering the phone by displaying the number of the incoming call. If you do not want your number displayed when you make a call, just follow these easy steps.

To block your phone number from being displayed for a specific outgoing call:

1 Press 2 Enter the number you want to call. 3 Press To permanently block your number, call

Boost Customer Care.

*67

Calls

Emergency calls

Your service provider programs one or more emergency phone numbers that you can call under any circumstances, even when your phone is locked or the SIM card is not inserted.

Note: Emergency numbers vary by country. Your phone’s preprogrammed emergency number(s) may not work in all locations, and sometimes an emergency call cannot be placed due to network, environmental, or interference issues.

Your phone supports emergency calling. Emergency phone calls can be made even when your SIM card is blocked or not in your phone.

Dial 911 or your local emergency number to be connected to an emergency response center. If you are on an active call, you must end it before making an emergency call.

When you make an emergency call, your phone’s GPS Enabled feature can help

emergency service personnel find you, if you are in a location where your phone's GPS antenna has established a clear view of the open sky and your local emergency response center has the equipment to process location information. Because of the limitations of this feature, always provide your best knowledge of your location to the emergency response center when you make an emergency call.

Note: Emergency calls cannot be placed while the keypad is locked.

Note: If you have not registered on the network, emergency calls cannot be placed while your SIM card is in your phone.

International calls

Call Boost Customer Care to activate international dialing. Press and hold 0 to insert your local international access code (indicated by +). Then, press the keypad keys to dial the country code and phone number.

Calls

Speed dial

Each phone number stored in Contacts is assigned a Speed Dial number, which you can use to call that number.

1 From the idle screen, use the

keypad to enter the Speed Dial number assigned to the phone

number you want to call. 2 Press 3 Press

# S

. .

Turbo dial

From the idle screen, press and hold the Speed Dial number (1 through 9) assigned to the phone number you want to call.

Voice Mail

Note: To receive voice mail messages, you must first set up a

voice mail account with your service provider.

Receiving a Message

When you receive a voice mail message, appears on the display.

To call your service provider’s voice mail system and listen to the message: Press

To dismiss the message notification: Press

If the caller leaves a message, this icon

you that you have a new message.

New VoiceMail Message

under

Call

, or - under

appears on the display, reminding

Back

Calls

Other Features

Advanced calling Contacts

feature call waiting

call forward

Other Features

To accept the second call and put the active call on hold:

Press

under

Yes

To accept the second call and end the active call:

Press

To forward your phone calls to another number:

Press

> d

feature voice name

command

To make a call with voice name command:

Press and hold the speaker phone key > wait to see

Name

Say the name of the person you'd like to call.

Say

on the display.

feature edit/delete

contact entry

set ringer ID

Display a Contacts entry:

Press

> select contact > select content to be edited > and/or edit the desired information >

Display a Contacts entry:

Press contact >

Ringer

desired ringer >

Back

Edit

> add

> select

Edit

> O > select

Save

Datebook

feature create

datebook events

change datebook view

see datebook event

To create a new Datebook event:

Press

> b >

[New Event]

Press M > b >

Month View, Week View

To see a calendar event:

Press left or right to day >

up or down to

event >

, or

Day View

> b >

Other Features

GPS

To improve GPS performance:

• Move away from other electrical or electronic devices

• Remain stationary.

• Avoid covering the internal antenna with your hands.

feature view

approximate location

To see where you currently are:

Press

> i >

Position

Scroll to view the entire screen.

To recalculate position: press

Refresh

. This may

take several minutes.

feature set GPS

privacy options

To set the level of privacy for your GPS system:

Press

> i >

Privacy

If your GPS PIN security feature is enabled, enter your GPS PIN and select the privacy option you want.

Other Features

feature set GPS

PIN security

Press M > R

Security On

Off

current GPS PIN. Note: Your default GPS

PIN is 0000. To change your GPS

PIN: Press

Security Passwords

Enter the current GPS PIN >

new 4- to 8-digit GPS PIN >

new 4- to 8-digit GPS PIN to confirm >

GPS PIN

> Enter the

> R >

Change

> enter the

> re-enter the

GPS PIN

feature make an

emergency call

Dial

9-1-1

to be connected to an emergency response center. If you are on an active call, you must end it before calling 9-1-1.

Other Features

Hands-free Messages

feature speaker-

phone

auto answer

Other Features

When the call is active, press

under Spkr

Automatically answer calls when connected to a car kit or headset:

Press

Phone Calls Auto Ans

amount of rings before answering

> R >

> select the

feature read

messages

reply to messages

When you receive a text message, it will automatically appear on your phone's main display screen. To view the entire message press down. If the messages is urgent, the message icon blinks in your display.

While the message is open:

Press

> type

message > or Press

[Create Reply]

quick reply

Send

under

> Send

Personalize Security

feature language

backlight time length

menu style

clock display

Set menu language:

Language

Backlight

Menu View

Clock

Display/

Press

Info

Select how long the display screen and keypad are backlit:

Press

Info

Show the Main Menu as graphic icons or a text-based list:

Press

Info

Press O >

Info

feature lock feature

Press O > >

Phone Lock

Now

Tip:

press

Other Features

Security

Auto Lock

To lock the keypad

Lock

Other Features

Important Safety and

Legal Information

Safety and General Information

Safety Information

This section contains important information on the safe and efficient operation of your mobile device. Read this information before using your integrated multi-service portable radio.*

Exposure to Radio Frequency (RF) Energy

Your phone contains a transmiter and receiver. When it is ON, it receives and transmits RF energy. When you communicate with your phone, the system handling your call controls the power level at which your phone transmits.

Your Motorola phone is designed to comply with local regulatory requirements in your country concerning exposure of human beings to RF energy.

Portable Radio Product Operation and EME Exposure

Your Motorola radio product is designed to comply with the following national and international standards and guidelines regarding exposure of human beings to radio frequency electromagnetic energy (EME):

• United States Federal Communications

• American National Standards Institute

• Institute of Electrical and Electronics

• International Commission on Non-Ionizing

• Ministry of Health (Canada). Safety Code 6.

• Australian Communications Authority

• ANATEL, Brasil Regulatory Authority,

* The information provided in this document

superseedes the general safety information in user’s guides published prior to May 1, 2006

Commission, Code of Federal Regulations; 47 CFR part 2 sub-part J.

(ANSI) / Institute of Electrical and Electronics Engineers (IEEE). C95. 1-1992.

Engineers (IEEE). C95. 1-2005 Edition.*

Radiation Protection (ICNIRP) 1998.

Limits of Human Exposure to Radiofrequency Electromagnetic Fields in the Frequency Range from 3 kHz to 300 GHz, 1999.

Radiocommunications (Electromagnetic Radiation - Human Exposure) Standard

2003.

Resolution 303 (July 2, 2002) "Regulation of the limitation of exposure to electrical, magnetic, and electromagnetic fields in the

Safety Information

radio frequency range between 9 kHz and 300 GHz." "Attachment to Resolution 303 from July 2, 2002."

Operational Precautions

To assure optimal radio product performance and to be sure that human exposure to RF does not exceed the guidelines set forth in the relevant standards, always follow these instructions and precautions :

Two-way radio operation

Your radio product has been designed and tested to comply with national and international standards and guidelines regarding human exposure to RF electromagnetic energy, when operated in the two-way mode (at the face, or at the abdomen when using an audio accessory) at usage factors of up to 50% talk/50% listen.

Transmit no more than the rated duty factor of 50% of the time. To transmit (talk), push the Walkie-Talkie (WT) button. To receive calls, release the WT button. Transmitting 50% of the time or less, is important because this radio generates measurable RF energy only when transmitting (in terms of measuring for standards compliance).

When using your radio product as a traditional two-way radio,

hold the radio product in a vertical position with the microphone one to two inches (2.5 to 5 cm) away from the lip

Product Operation

When placing or receiving a phone call, hold your radio product as you would a wireline telephone.

Speak directly into the microphone

If you wear a radio product on your body when transmitting, always place the radio product in a Motorola approved clip, holder, holster, case or body harness. If you do not use a body-worn accessory supplied or approved by Motorola and are not using the radio product in the intended use positions along side the head in the phone mode or in front of the face in the two-way radio mode—or if you hang your device from a lanyard around your neck—keep the device at least 2.5 centimeters (1 inch) from your body when transmitting.

Safety Information

ALL MODELS WITH FCC ID IHDT56HG1 MEET THE GOVERNMENT’S REQUIREMENTS FOR EXPOSURE TO RADIO WAVES.

Your wireless phone is a radio transmitter and receiver. It is designed and manufactured not to exceed the emission limits for exposure to radiofrequency (RF) energy set by the Federal Communications Commission of the U.S. Government. These limits are part of comprehensive guidelines and establish permitted levels of RF energy for the general population. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a substantial safety margin designed to assure the safety of all persons, regardless of age and health.

The exposure standard for wireless mobile phones employs a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6W/kg. conducted using standard operating positions reviewed by the FCC with the phone transmitting at its highest certified power level in all tested frequency bands. Although the SAR is determined at the highest certified power level, the actual SAR level of the phone while operating can be well below the maximum value. This is because the phone is designed to operate at multiple power levels so as to use only the power required to reach the network. In general, the closer you are

Tests for SAR are

to a wireless base station antenna, the lower the power output.

Before a phone model is available for sale to the public, it must be tested and certified to the FCC that is does not exceed the limit established by the government-adopted requirement for safe exposure. The tests are performed in positions and locations (e.g., at the ear and worn on the body) as required by the FCC for each model. The highest SAR value for this model phone when tested for use at the ear is 1.54 W/kg and when tested on the body, as described in this user guide, is 1.48 W/kg during packet data transmission. (Body-worn measurements differ among phone models, depending upon available accessories and FCC requirements.)

While there may be differences between the SAR levels of various phones and at various positions, they all meet the government requirement for safe exposure.

The FCC has granted an Equipment Authorization for this model phone with all reported SAR levels evaluated as in compliance with the FCC RF exposure guidelines. SAR information on this model phone is on file with the FCC and can be found under the Display Grant section of http://www.fcc.gov/oet/fccid FCC ID IHDT56HG1.

Additional information on Specific Absorption Rates (SAR) can be found on the Cellular Telecommunications Industry Association (CTIA) web-site at http://www.wow-com.com

after searching on

Safety Information

In the United States and Canada, the SAR limit for mobile phones used by the public is 1.6 watts/kg (W/kg) averaged over one gram of tissue. The standard incorporates a substantial margin of safety to give additional protection for the public and to account for any variations in measurements.

The SAR information reported to the FCC includes the FCC-accepted Motorola testing protocol, assessment procedure, and measurement uncertainty range for this product.

Approved Accessories

For a list of approved Motorola accessories call 1-800-453-0920, or visit our website at www.motorola.com/iden

RF Energy Interference/Compatibility

Nearly every electronic device is subject to RF energy interference from external sources if inadequately shielded, designed or otherwise configured for RF energy compatibility. In some circumstances your handset may cause interference with other devices.

Follow Instructions to Avoid Interference Problems

Turn OFF your radio product where posted notices instruct you to do so.

In an aricraft, turn off your radio product whenever instructed to do so by airline staff. If your radio product offers an airplane mode or similar feature, consult airline staff about using it in flight.

Implantable Medical Devices

If you have an implantable medical devices, such as a pacemaker or defibrillator, consult your physician before using this radio product.

Persons with implantable medical devices should observe the following precautions:

• ALWAYS keep the phone more than 20 centimeters (8 inches) from the the implantable medical device when the phone is turned ON.

• DO NOT carry the phone in a breast pocket;

• Use the ear opposite the implantable medical device to minimize the potential for interference.

• Turn OFF the phone inmediately if you have any reason to suspect that the interference is taking place.

Read and follow the directions from the manufacturer of your implantable medical device. If you have any questions about using your wireless phone with your implantable medical device, consult your health care provider.

Safety Information

Hearing Aids

Some mobile devices may interfere with some hearing aids. In the event of such interference, you may want to consult your hearing aid manufacturer or physician to discuss alternatives.

Other Medical Devices and Health Care Facilities

If you use any other personal medical devices, consult your physician or the manufacturer or your device to determine if it is adequately shielded from RF energy. Turn off your radio product when instructed to do so in hospitals or health care facilities that may be using equipment that is sensitive to external RF energy.

Driving Precautions

Check the laws and regulations on the use of radio products in the area where you drive. Always obey them.

When using your radio product while driving, please:

• Give full attention to driving and to the road. Using a mobile device may be distracting. Discontinue a call if you can’t concentrate on driving.

• Use handsfree operation, if available.

• Pull off the road and park before making or answering a call if driving conditions so require.

• Do not place a handset in the airbag deployment area.

Responsible driving practices can be found in the “Smart Practices While Driving” section at the end of this guide and/or at the Motorola Web site: www.motorola.com/callsmart

Note: The use of wireless phones while driving may cause distraction. Discontinue a call if you can’t concentrate on driving. Additionally, the use of wireless devices and their accessories may be prohibited or restricted in certain areas. Always obey the laws and regulations on the use of these products.

Operational Warnings

Obey all posted signs when using mobile devices in public areas.

Potentially Explosive Atmospheres

Areas with potentially explosive atmospheres are often but not always posted, and can include fueling areas such as below decks on boats, fuel or chemical transfer or storage facilities, or areas where the air contains chemicals or particles, such as grain, dust or metal powders.

When you are in such area, turn off your hanset, and do not remove, install, or charge batteries unless it is a radio product type especially qualified for use in such areas as “Intrinsically Safe” (for example, Factory Mutual, CSA, or UL approved). In such areas, sparks can occur and cause an explosion or fire.

Safety Information

Batteries and Chargers

032374o

032376o

032378o

Li Ion BATT

Caution: Improper treatment or use of batteries may present a danger of fire, explosion, leakage, or other hazard. For more information, see the “Battery Use and Battery Safety” section in this user’s guide.

Your battery, charger, or portable radio may contain symbols, defined as follows:

Symbol Definition

Important safety information follows.

Do not dispose of your battery or mobile device in a fire.

032375o

Your battery or mobile device may require recycling in accordance with local laws. Contact your local regulatory authorities for more information.

Do not throw your battery or mobile device in the trash.

Your mobile device contains an internal lithium ion battery.

Symbol Definition

Do not let your battery, charger, or mobile device get wet.

Listening at full volume to music or voice through a headset may damage your hearing.

Choking Hazards

Your portable radio or its accessories may include detachable parts, which may present a choking hazard to small children. Keep your device and its accessories away from small children.

Glass Parts

Some parts of your mobile device may be made of glass. This glass could break if the product is dropped on a hard surface or receives a substantial impact. If glass breaks, do not touch or attempt to remove. Stop using your mobile device until the glass is replaced by a qualified service center.

Seizures/Blackouts

Some people may be susceptible to epileptic seizures or blackouts when exposed to flashing lights, such as when playing video games. These may occur even if a person has never had a previous seizure or blackout.

Safety Information

If you have experienced seizures or blackouts, or if you have a family history of such occurrences, please consult with your physician before playing video games or enabling a flashing-lights feature (if available) on your mobile device.

Discontinue use and consult a physician if any of the following symptoms occur: convulsion, eye or muscle twitching, loss of awareness, involuntary movements, or disorientation. It is always a good idea to hold the screen away from your eyes, leave the lights on in the room, take a 15-minute break every hour, and stop use if you are very tired.

Caution About High Volume Usage

Listening at full volume to music or voice through a headset may damage your hearing.

Repetitive Motion

When you repetitively perform actions such as pressing keys or entering finger-written characters, you may experience occasional discomfort in your hands, arms, shoulders, neck, or other parts of your body. If you continue to have discomfort during or after such use, stop use and see a physician.

Service & Repairs

If you have questions or need assistance, we’re here to help.

Go to www.motorola.com/iden/support can select from a number of customer care

, where you

options. You can also contact the Motorola Customer Support Center at 1-800-453-0920 (United States), 1-877-483-2840 (TTY/TDD United States for hearing impaired).

Safety Information

Motorola Limited Warranty for the United States and Canada

What Does this Warranty Cover?

Note: FOR IDEN SUBSCRIBER PRODUCTS, ACCESSORIES AND SOFTWARE PURCHASED IN THE UNITED STATES OR CANADA

What Does this Warranty Cover?

Subject to the exclusions contained below, Motorola, Inc. warrants its Motorola iDEN Digital Mobile and Portable Handsets ("Products"), Motorola-branded or certified accessories sold for use with these Products ("Accessories") and Motorola software contained on CD-Roms or other tangible media and sold for use with these Products ("Software") to be free from defects in materials and workmanship under normal consumer usage for the period(s) outlined below.

This limited warranty is a consumer's exclusive remedy, and applies as follows to new Products, Accessories and Software purchased by consumers in the United States or Canada,

which are accompanied by this written warranty:

Products Covered Length of Coverage

Products as defined above.

Accessories as defined above.

Products or Accessories that are Repaired or Replaced.

One (1) year

date of purchase by the first consumer purchaser of the product.

One (1) year

date of purchase by the first consumer purchaser of the product.

The balance of the original warranty or for ninety (90) days

from the date returned to the consumer, whichever is longer.

from the

Safety Information

Products Covered Length of Coverage

Software

as defined above. Applies only to physical defects in the media that embodies the copy of the software (e.g. CD-ROM, or floppy disk).

What is not covered? (Exclusions)

Normal Wear and Tear

repair and replacement of parts due to normal wear and tear are excluded from coverage.

Ornamental Decorations. Ornamental decorations

such as emblems, graphics, rhinestones, jewels, gemstones and their settings, and other decorative elements, are excluded from coverage.

Batteries

. Only batteries whose fully charged capacity falls below 80% of their rated capacity and batteries that leak are covered by this limited warranty.

Abuse & Misuse

from: (a) improper operation, storage, misuse or abuse, accident or neglect, such as physical damage (cracks, scratches, etc.) to the surface of the product resulting from misuse; (b) contact with liquid, water, rain, extreme humidity or heavy perspiration, sand, dirt or the like, extreme heat, or food; (c) use of the Products or Accessories for commercial purposes or subjecting the Product or Accessory to abnormal usage or conditions; or (d)

Ninety (90) days from the date of purchase.

. Periodic maintenance,

. Defects or damage that result

other acts which are not the fault of Motorola, are excluded from coverage.

Use of Non-Motorola Products and Accessories.

Defects or damage that result from the use of Non-Motorola branded or certified Products, Accessories, Software or other peripheral equipment are excluded from coverage.

Unauthorized Service or Modification

damages resulting from service, testing, adjustment, installation, maintenance, alteration, including without limitation, software changes, or modification in any way by someone other than Motorola, or its authorized service centers, are excluded from coverage.

Altered Products

(a) serial numbers or date tags that have been removed, altered or obliterated; (b) broken seals or that show evidence of tampering; (c) mismatched board serial numbers; or (d) nonconforming or non-Motorola housings, antennas, or parts, are excluded from coverage.

Communication Services

the failure of Products, Accessories or Software due to any communication service or signal you may subscribe to or use with the Products, Accessories or Software is excluded from coverage.

Software Embodied in Physical Media.

warranty is made that the software will meet your requirements or will work in combination with any hardware or software applications provided by third parties, that the operation of the software products will be uninterrupted or error free, or that

. Products or Accessories with

. Defects, damages, or

. Defects or

Safety Information

all defects in the software products will be corrected.

Software NOT Embodied in Physical Media

Software that is not embodied in physical media (e.g. software that is downloaded from the internet), is provided "as is" and without warranty.

Who is covered?

the first consumer purchaser, and is not transferable.

What will Motorola Do?

will at no charge repair, replace or refund the purchase price of any Products, Accessories or Software that does not conform to this warranty. We may use functionally equivalent reconditioned/refurbished/pre-owned or new Products, Accessories or parts. No data, software or applications added to your Product, Accessory or Software, including but not limited to personal contacts, games and ringer tones, will be reinstalled. To avoid losing such data, software and applications please create a back up prior to requesting service.

How to Obtain Warranty Service or Other Information?

please call: Motorola iDEN Customer Services 1-800-453-0920

or 954-723-4910 TTY-877-483-2840 Or visit us online at

http://www.motorola.com/iden/support You will receive instructions on how to ship the

Products, Accessories or Software, at your

This warranty extends only to

Motorola, at its option,

To obtain service or information,

expense, to a Motorola Authorized Repair Center. To obtain service, you must include: (a) a copy of your receipt, bill of sale or other comparable proof of purchase; (b) a written description of the problem; (c) the name of your service provider, if applicable; (d) the name and location of the installation facility (if applicable) and, most importantly; (e) your address and telephone number.

What Other Limitations Are There? ANY IMPLIED

WARRANTIES, INCLUDING WITHOUT LIMITATION THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, SHALL BE LIMITED TO THE DURATION OF THIS LIMITED WARRANTY, OTHERWISE THE REPAIR, REPLACEMENT, OR REFUND AS PROVIDED UNDER THIS EXPRESS LIMITED WARRANTY IS THE EXCLUSIVE REMEDY OF THE CONSUMER, AND IS PROVIDED IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OF IMPLIED. IN NO EVENT SHALL MOTOROLA BE LIABLE, WHETHER IN CONTRACT OR TORT (INCLUDING NEGLIGENCE) FOR DAMAGES IN EXCESS OF THE PURCHASE PRICE OF THE PRODUCT, ACCESSORY OR SOFTWARE, OR FOR ANY INDIRECT, INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES OF ANY KIND, OR LOSS OF REVENUE OR PROFITS, LOSS OF BUSINESS, LOSS OF INFORMATION OR DATA, SOFTWARE OR APPLICATIONS OR OTHER FINANCIAL LOSS ARISING OUT OF OR IN CONNECTION WITH THE ABILITY OR INABILITY TO USE THE PRODUCTS, ACCESSORIES OR

Safety Information

SOFTWARE TO THE FULL EXTENT THESE DAMAGES MAY BE DISCLAIMED BY LAW.

Some states and jurisdictions do not allow the limitation or exclusion of incidental or consequential damages, or limitation on the length of an implied warranty, so the above limitations or exclusions may not apply to you. This warranty gives you specific legal rights, and you may also have other rights that vary from state to state or from one jurisdiction to another.

Laws in the United States and other countries preserve for Motorola certain exclusive rights for copyrighted Motorola software such as the exclusive rights to reproduce and distribute copies of the Motorola software. Motorola software may only be copied into, used in, and redistributed with, the Products associated with such Motorola software. No other use, including without limitation disassembly of such Motorola software or exercise of the exclusive rights reserved for Motorola, is permitted.

Patent and Software Provisions

MOTOROLA will defend, at its own expense, any suit brought against the end user purchaser to the extent that it is based on a claim that the Product or parts infringe a United States patent, and Motorola will pay those costs and damages finally awarded against the end user purchaser in any such suit which are attributable to any such claim, but such defense and payments are conditioned on the following:

a.That MOTOROLA will be notified promptly in writing by such purchaser of any notice of such claim;

b.That MOTOROLA will have sole control of the defense of such suit and all negotiations for its settlement or compromise; and

c.Should the Product or parts become, or in MOTOROLA'S opinion be likely to become, the subject of a claim of infringement of a United States patent, that such purchaser will permit MOTOROLA, at its option and expense, either to procure for such purchaser the right to continue using the Product or parts or to replace or modify the same so that it becomes non-infringing or to grant such purchaser a credit for the Product or parts as depreciated and accept its return. The depreciation will be an equal amount per year over the lifetime of the Product or parts as established by MOTOROLA.

MOTOROLA will have no liability with respect to any claim of patent infringement which is based upon the combination of the Product or parts furnished hereunder with software, apparatus or devices not furnished by MOTOROLA, nor will MOTOROLA have any liability for the use of ancillary equipment or software not furnished by MOTOROLA which is attached to or used in connection with the Product or any parts thereof.

Laws in the United States and other countries preserve for MOTOROLA certain exclusive rights for copyrighted MOTOROLA software, such as the exclusive rights to reproduce in copies and

Safety Information

distribute copies of such MOTOROLA software. MOTOROLA software may be used in only the Product in which the software was originally embodied and such software in such Product may not be replaced, copied, distributed, modified in any way, or used to produce any derivative thereof. No other use including, without limitation, alteration, modification, reproduction, distribution, or reverse engineering of such MOTOROLA software or exercise or rights in such MOTOROLA software is permitted. No license is granted by implication, estoppel or otherwise under MOTOROLA patent rights or copyrights.

Safety Information

Hearing Aid Compatibility

A number of Motorola phones have been tested for hearing aid compatibility. When some wireless phones are used with certain hearing aids, users may detect a noise which can interfere with the effectiveness of the hearing aid.

Some hearing aids are more “immune” than others to this interference noise, and phones can also vary in the amount of interference noise they may generate. ANSI standard C63.19 was developed to provide a standardized means of measuring both mobile phone and hearing aids to determine usability rating categories for both.

Ratings have been developed for mobile phones to assist hearing aid users find phones that may be compatible with their hearing aid. Not all phones have been rated for compatibility with hearing aids. Phones that have been rated have a label with the rating(s) located on the box, and at www.motorola.com/accessibility

These ratings are not guarantees of compatibility. Results will vary depending on the user's hearing aid and individual type and degree of hearing loss. If a hearing aid is particularly vulnerable to interference, even a phone with a higher rating may still cause unacceptable noise levels in the hearing aid Trying out the phone with your hearing aid is the best way to evaluate it for your personal needs.

Safety Information

“M” Rating

requirements for hearing aid compatibility and are likely to generate less interference to hearing aids than unrated phones. (M4 is the “better” or higher of the two ratings.) On those models with an extendable antenna, this rating is determined only with the antenna extended.

“T” Rating: Phones rated T3 or T4 meet FCC

requirements and are likely to be more usable with a hearing aid's telecoil (“T Switch” or “Telephone Switch”) than unrated phones. (T4 is the “better” or higher of the two ratings.) On those models with a telecoil mode setting, this rating is determined only with the phone so set. For setting instructions, see “Features for the Hearing Impaired” in the section entitled “Advanced Calling Features”. Note that not all hearing aids have telecoils in them.

Hearing aids may also be measured for immunity to interference from wireless phones and may have ratings similar to wireless phones. Ask your hearing healthcare professional for the rating of your hearing aid. Add the rating of your hearing aid and your phone to determine the estimated usability:

: Phones rated M3 or M4 meet FCC

• Any combined rating equal to or greater than six offers excellent use.

• Any combined rating equal to five is considered normal use.

• Any combined rating equal to four is considered usable.

Thus, if you use an M3 phone with a M3 hearing aid you will have a combined rating of six for “excellent use.” This methodology applies equally for T ratings.

More information about hearing aid compatibility may be found at: www.motorola.com/accessibility www.fda.gov www.hearingloss.org/learn/cellphonetech.asp

, and

, www.fcc.gov,

Safety Information

Information From the World Health Organization

WHO Information

Present scientific information does not indicate the need for any special precautions for the use of mobile phones. If you are concerned, you may want to limit your own or your children’s RF exposure by limiting the length of calls or by using

hands-free devices to keep mobile phones away from your head and body.

Source: WHO Fact Sheet 193 Further information: http://www.who.int./peh-emf

Product Registration

Registration

Online Product Registration: http://direct.motorola.com/hellomoto/

Motosupport/source/registration.asp Product registration is an important step toward

enjoying your new Motorola product. Registering helps us facilitate warranty service, and permits us to contact you should your product require an update or other service. Registration is for U.S.

residents only and is not required for warranty coverage.

Please retain your original dated sales receipt for your records. For warranty service of your Motorola Personal Communications Product you will need to provide a copy of your dated sales receipt to confirm warranty status.

Thank you for choosing a Motorola product.

Export Law Assurances

Export Law

This product is controlled under the export regulations of the United States of America and Canada. The Governments of the United States of America and Canada may restrict the exportation or re-exportation of this product to certain destinations. For further information contact the

U.S. Department of Commerce or the Canadian Department of Foreign Affairs and International Trade.

WHO Information

Wireless: The New Recyclable

Recycling

Your wireless mobile device can be recycled. Recycling your mobile device reduces the amount of waste disposed in landfills and allows recycled materials to be incorporated into new products.

The Cellular Telecommunications Industry Association (CTIA) and its members encourage consumers to recycle their mobile devices and have taken steps to promote the collection and environmentally sound recycling of end-of-life devices.

As a mobile device user, you have an important role in ensuring that this device is recycled properly. When it comes time to give this mobile device up or trade it in for a new one, please remember that the mobile device, the charger, and many of its accessories can be recycled. It's easy. To learn more about CTIA's Recycling Program for Used Wireless Devices, please visit us at: http://recycling.motorola.young-america.com/ index.html

Recycling

California Perchlorate Label

Perchlorate Label

Some mobile phones use an internal, permanent backup battery on the printed circuit board that may contain very small amounts of perchlorate. In such cases, California law requires the following label:

“Perchlorate Material - special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate.

There is no special handling required by consumer.

”

Perchlorate Label

Privacy and Data Security

Motorola understands that privacy and data security are important to everyone. Because some features of your mobile device may affect your privacy or data security, please follow these recommendations to enhance protection of your information:

Monitor access

• device with you and do not leave it where others may have unmonitored access. Lock your device’s keypad where this feature is available.

Keep software up to date

• or a software/application vendor releases a patch or software fix for your mobile device which updates the device’s security, install it as soon as possible.

Erase before recycling

• personal information or data from your mobile device prior to disposing of it or turning it in for recycling. For step-by-step instructions on how to delete all personal information from your device, please contact Boost Customer Care.

Note: Note: For information on backing up your mobile device data before erasing it, go to www.motorola.com and then navigate to the “downloads” section of the consumer Web page for “Motorola Backup” or “Motorola Phone Tools.”

— Keep your mobile

— If Motorola

— Delete

Understanding AGPS

• comply with emergency caller location requirements of the FCC, certain Motorola mobile devices incorporate Assisted Global Positioning System (AGPS) technology. AGPS technology also can be used in non-emergency applications to track and monitor a user’s location—for example, to provide driving directions. Users who prefer not to permit such tracking and monitoring should avoid using such applications.

If you have further questions regarding how use of your mobile device may impact your privacy or data security, please contact Motorola at privacy@motorola.com, or contact your service provider.

— In order to

Privacy and Data Security

Smart Practices While Driving

Driving Safety

Check the laws and regulations on the use of mobile devices and their accessories in the areas where you drive. Always obey them. The use of these devices may be prohibited or restricted in certain areas. Go to for more information.

Your mobile device lets you communicate by voice and data—almost anywhere, anytime, wherever wireless service is available and safe conditions allow. When driving a car, driving is your first responsibility. If you choose to use your mobile device while driving, remember the following tips:

Drive Safe, Call Smart

www.motorola.com/callsmart

Get to know your Motorola mobile device

•

and its features such as speed dial and

If available, these features help you

redial.

to place your call without taking your attention off the road.

When available, use a

•

hands-free device.

possible, add an additional layer of convenience to your mobile device with one of the many Motorola Original hands-free accessories available today.

Position your mobile device within easy

•

reach.

Be able to access your mobile device without removing your eyes from the road. If you receive an incoming call at

Driving Safety

an inconvenient time, if possible, let your voice mail answer it for you.

Let the person you are speaking with

•

know you are driving; if necessary, suspend the call in heavy traffic or hazardous weather conditions.

snow, ice, and even heavy traffic can be hazardous.

Do not take notes or look up phone

•

numbers while driving.

do” list or going through your address book takes attention away from your primary responsibility—driving safely.

Dial sensibly and assess the traffic; if

•

possible, place calls when your car is not moving or before pulling into traffic.

must make a call while moving, dial only a few numbers, check the road and your mirrors, then continue.

Do not engage in stressful or emotional

•

conversations that may be distracting.

Make people you are talking with aware you are driving and suspend conversations that can divert your attention away from the road.

Use your mobile device to call for help.

• Dial 911 or other local emergency number in the case of fire, traffic accident, or medical emergencies.*

Rain, sleet,

Jotting down a “to

If you

•

Use your mobile device to help others in emergencies.

crime in progress, or other serious emergency where lives are in danger, call 911 or other local emergency number, as you would want others to do for you.*

Call roadside assistance or a special

•

non-emergency wireless assistance number when necessary.

broken-down vehicle posing no serious hazard, a broken traffic signal, a minor traffic accident where no one appears injured, or a vehicle you know to be stolen, call roadside assistance or other special non-emergency wireless number.*

* Wherever wireless phone service is available.

If you see an auto accident,

If you see a

Index

accessories active phone line advanced calling alert

set turn off

answer a call

backlight battery battery indicator battery life, extend boostLIVE

accessing

13, 51, 66

46, 52

46, 56

17, 18

43 62

make

call forward call waiting caller ID calls center key center select key codes combined power/end/home key contacts

datebook dial a phone number dialed calls display

19, 20

call

answer end

19, 20

Index

earpiece volume emergency number end a call

19, 20

export regulations

frequently asked questions

service and repairs

GPS

GPS enabled

emergency calls

GPS PIN GPS, see GPS enabled

handsfree handsfree speaker Hearing Aid Compatibility home screen

keypad

locking

lock

phone

logo backlight low battery message

make a call message indicator messages missed calls message MMS

auto replies priority

incoming call message international calls iTAP text entry mode

navigation key

one touch WT

13, 46

Index

optional accessory optional feature

packet data passwords passwords. See codes personalize phone

locking

phone number power on

combined power/end/home key

radio frequency received calls recent calls recycling redial return a call ring style indicator ring style, setting ring tones

off

13, 66

66, 67

setting

vibrate

52, 53

ringer volume

safety

radio frequency RF energy interference

safety information safety tips security security code send contacts send events send key send my info send pictures send via WT SIM chip SIM PIN soft keys speaker speed dial store your number

47, 67

19, 20

Index

tap text entry mode text entry time & date transmitters turn on/off

WHO information WT calls

answer

make

WT Features WT services

unlock

phone

unlock code

voice mail

receiving

setting up

voice name voicemail voicemail message indicator volume

61 57

Walkie-Talkie calls wallpaper

your phone number

Index

Motorola i290 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Getting Started

Introduction

Activate

Re-Boost®

Boost Loyalty Program

Lost/Stolen Service

Boost® Customer Care

Check it out

Essentials

About this guide

SIM chip

Battery

Turn it on & off

Make a phone call

Answer a phone call

Make a Walkie-Talkie call

Answer a Walkie-Talkie call

Store a phone number or Walkie-Talkie ID

Call a stored phone number or Walkie-Talkie ID

Your phone number and Walkie-Talkie ID

Main Attractions

boostLIVE

WT Services

One touch WT

Basics

Display

Text entry

Volume

Navigation key

Hands-free Speakerphone

Codes & passwords

Lock & unlock phone

Transmitters

Use GPS with map software

Boost Mobile® Services

Accessories

Wireless local number portability: Bringing your phone number from another carrier

Boost Customer Care

Customize

Ringtones

Wallpaper

Backlight

Time & date

Hide or show location information

Calls

Turn off a call alert

Recent calls

Store an item to contacts from recent calls

Redial

Voice Name

Call forward

Return a call

Walkie-Talkie calls

Caller ID

Emergency calls

International calls

Speed dial

Turbo dial

Voice Mail

Receiving a Message

Other Features

Advanced calling Contacts

Datebook

Hands-free Messages

messages

Personalize Security

Security

Index
