5320/5330/5340 IP PHONE USER GUIDE RELEASE 5.0

5320/5330/5340 IP Phone Quick Reference Guide

This guide provides information for frequently used features. For more information about these and other features, refer to the user guide. For voice mail information, refer to the voice mail user guide for your system.

Feature Buttons

Most of the following feature codes work when your IP phone is idle. However, if you are on an active call or if the IP phone is off-hook, you may need to press

(Special) to activate the feature before you enter the

feature code.

If you make a mistake when entering numbers or characters, you can press (Hold) to move the cursor to the left and delete the characters entered, or you can press

Button Action

(Up) (Down)

(Speaker)

(Mute) Mutes the microphone during a

(Applications) Activates the Applications menu

(Special)

(Redial) Calls the last external number

(Hold) Places the current call on hold.

(Message) Allows you to view station

* to cancel the feature.

Provides volume control. Scrolls through feature options.

Activates Handsfree Mode. Activates features.

call.

to use the conference unit or cordless devices, program various phone settings, and enable Clean Mode.

Activates features while on a call.

The (Special) button does not cancel features. To cancel features, press the Star button (*).

dialed. You cannot redial internal numbers.

Left/Backspace when entering dialpad characters.

(Transfer) Transfers the current call.

Right/Forward when entering dialpad characters.

messages. Toggles between Alpha Mode

and Numeric Mode.

Commonly Used Feature Codes

Contact your system administrator for more information about system features.

Feature Code

ACD Agent – Log In/Out 328 Automatic IC Call Access – On/Off 361 Automatic Trunk Call Access – On/Off 360 Background Music – On/Off 313 Call Forward – All Calls 355 Call Logging 333 Conference 5 Default Station 394 Directory 307 Display Time And Date 300 Do-Not-Disturb – On/Off 372 Dynamic Extension Express – On/Off 364 Dynamic Extension Express Handoff 388 Handsfree – On/Off 319 Headset – On/Off 317 Hold – Individual 336 Hold – System 335 Hot Desk On/Off 348 Hunt Group – Remove/Replace 324 Message – Cancel Left Message 366 Message – Delete Message 368 Message – Leave Message 367 Message – View Messages Menu 365 Microphone Mute – On/Off 314 Page Receive – On/Off 325 Program Buttons 397 Program Station Passcode 392 Programmable Buttons – Default 395 Queue (Callback) Request 6 Record-A-Call 385 Reverse Transfer (Call Pick-Up) 4 Ring Tone Selection 398 Station Speed Dial 382 Station Speed Dial – Programming 383 Switch Keymap 399 System Forward – On/Off 354 System Speed Dial 381 View Button Assignments 396

Mitel® 5320/5330/5340 IP Phone User Guide – Release 5.0, April 2013 Page iii

Answering Calls

Lift the handset, or press (Speaker) to answer a call while using a headset or to answer a call in Handsfree Mode.

Placing Emergency Calls

Dial the emergency number (911 U.S. or 999/112 Europe). The system immediately places the emergency call as soon as you dial the number, even if you do not select an outside line.

Placing Internal (Intercom) Calls

With or without the handset lifted, dial the extension number. If you enter incorrect digits, you can press (Hold) to move the cursor backward, deleting the last digits entered. If you are using Handsfree Mode, listen for the double tone, and then begin to speak.

Placing External Calls

Press the Outgoing button, an unlit Call button, or enter the Outgoing Call access code (8 is the default code), and then dial the number.

Redialing External Numbers

With or without the handset lifted, press the (Redial). The system automatically selects a line and dials the number.

Placing Ad Hoc Conference Calls

1. While on the first call, press the Conf button to place the call on hold. CALL NEXT PARTY TO CNF appears.

2. Place a call to the next conference party. For external calls, press the Outgoing button or enter the Outgoing Call access code (8 is the default code), and then dial the number.

3. After the party answers, announce the conference, and then press the Conf button to place the call on hold. If necessary, repeat this step to add the remaining conference party.

4. Press the Conf button again to start the conference. CNF IN PROGRESS appears.

Viewing and Responding to Messages

1. With the handset on-hook, press (Message) or the VIEW MESSAGE menu button (5340 IP Phones only). Messages are displayed as first in/ first out. If there is more than one message, you can repeatedly press (Message) to scroll through the messages.

2. When the desired message is displayed, press #, or lift the handset for privacy, and then press # to respond. (If your handset is off-hook and you press [Message], you automatically place a call to the party or message center who left the message.)

Transferring Calls to Other Extensions

1. While on the call, press (Transfer), and then enter the extension number.

2. Do one of the following:

• Wait for an answer, announce the call, and

then hang up. If the extension is unavailable, press the flashing IC or Call button to return to the caller.

• Hang up to transfer the call and disconnect

the call from your IP phone.

Forwarding Calls

1. Press the Fwd button, and then enter the feature code, if applicable. ENTER FORWARD DEST appears.

2. Enter the extension number, or press the Outgoing button or enter the Outgoing Call access code (8 is the default code), and then dial the telephone number.

Using Do-Not-Disturb

1. Press the DND button, and then do one of the following:

• Press (Up) or (Down) to scroll

through the messages.

• Enter the two-digit number for the DND

message.

2. If applicable, enter the additional text for the DND description.

3. Press (Speaker), or lift and replace the handset.

Placing a Page Announcement

1. Press 7.

2. Enter the page-zone number (0 to 9).

3. After the tone, make your announcement, and then hang up.

Page iv Mitel

5320/5330/5340 IP Phone User Guide – Release 5.0, April 2013

Notice

Enter provider information above.

This guide is released by Mitel Networks Corporation and provides information necessary to use the 5320/5330/5340 IP Phones. The guide contents, which reflect current Mitel standards, are subject to revision or change without notice.

Some features or applications mentioned may require a future release and are not available in the initial release. Future product features and applications are subject to availability and cost. Some features or applications may require additional hardware, software, or system administrator assistance.

For sales, service, or technical support, contact your local authorized provider:

If you do not know the contact information for your local provider, use the “Partners” link at the top of the Mitel home

page (www.mitel.com) to find a location near you.

If you have any questions or comments regarding this user guide or other technical documentation, contact the Technical Publications Department (USA) at:

tech_pubs@mitel.com

is a registered trademark of Mitel Networks Corporation.

Mitel

Personal use of this material is permitted. However, permission to reprint/republish this material for advertising or promotional purposes or for creating new collective works for resale or redistribution to servers or lists, or to reuse any copyrighted component of this work in other works must be obtained from Mitel.

Mitel® 5320/5330/5340 IP Phone User Guide – Release 5.0, April 2013 Page v

Important Safety Instructions and Precautions

Remember the following safety guidelines when using the IP phone.

Programming Emergency Numbers

Make sure to do the following when programming emergency numbers and/or making test calls to emergency numbers:

• Remain on the line and briefly explain to the dispatcher the reason for the call.

• Perform tests during off-peak hours such as early morning or late evenings.

Safety Notices

The following notices may appear on the product or in the technical documentation.

Notice Description

Caution indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury and/or damage to the equipment or property.

Warning indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.

Danger indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.

The exclamation point within an equilateral triangle indicates that important operating and

maintenance (servicing) instructions are included in the literature accompanying the product.

Maintenance and Repair

There are no user serviceable parts inside the IP phone. For repairs, return the IP phone to an authorized Mitel provider.

NOTE

Changes or modifications not expressly approved by Mitel may void the user’s right to operate the equipment.

Page vi Mitel

5320/5330/5340 IP Phone User Guide – Release 5.0, April 2013

Power Requirements

CAUTION

Phone Damage Hazard. To avoid damaging the IP phone, make sure the IP phone is connected to the proper power

supply before powering on. Contact your system administrator for more information.

The IP phone requires any one of the following power supplies:

• Mitel 48-volt DC Ethernet power adaptor 100-240 volt AC 50-60Hz (ES), part number 50005301

• An industry-standard IEEE 802.3af Power over Ethernet (PoE) power supply unit

If your IP phone uses a centralized PoE power supply unit, do not use the 48-volt DC Ethernet power adaptor. If necessary, contact your system administrator for assistance before connecting your IP phone to the centralized power source.

Make sure the IP phone is plugged into an uninterruptible power supply (UPS). If your IP phone is plugged into the UPS and the power fails, it should remain powered on for about 10 minutes. If the IP phone is not plugged into a UPS and the power fails, the current call is dropped and you will not be able to use the IP phone until the power is restored.

Software Updates

CAUTION

Phone Damage Hazard. Do not use your IP phone or disconnect it from the power supply while it is updating

software.

The IP phone may require occasional software updates when new versions are available. The IP phone is configured to download the updates automatically. Contact your system administrator for more information.

Product Disposal Instructions

This symbol indicates that the product is classified as electrical or electronic equipment and should not be disposed of with other commercial or household waste at the end of its working life. For appropriate disposal and recycling instructions, contact your local Mitel provider.

The Waste of Electrical and Electronic Equipment (WEEE) Directive (2002/96/EC) was established by the European Union to minimize negative impact on the environment, control hazardous substances, and curtail landfill expansion by using the best available recovery and recycling techniques.

Mitel® 5320/5330/5340 IP Phone User Guide – Release 5.0, April 2013 Page vii

Phone Usage

This equipment is not for connection to the telephone network or public coin phone service. It is only for use when connected to Mitel systems.

WARNING

When using your IP phone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following:

• Do not use this product near water, for example, near a bath tub, wash bowl, kitchen sink or laundry

tub, in a wet basement, or near a swimming pool.

• Avoid using a phone (other than a cordless type) during an electrical storm. There may be a remote

risk of electric shock from lightning.

• Do not use the IP phone to report a gas leak in the vicinity of a leak.

• Do not connect directly to the Public Switched Telephone Network (PSTN). Any connection of this

phone to an off premise application, an out of plant application, any other exposed plant application, or to any equipment other than the intended application may result in a safety hazard, and/or defective operation, and/or equipment damage. “Exposed plant” means where any portion of the circuit is subject to accidental contact with electric lighting or power conductors operating at a voltage exceeding 300 volts between conductors or is subject to lightning strikes.

• The socket outlet, if used, shall be located near the equipment and shall be easily located by the user.

• Use only Mitel approved power adaptors. See “Power Requirements” on page vii.

• The handset supplied with the IP phone is not certified for use with any other phone. Use of the

handset with any other phone may have the potential to cause hearing loss in the event of a lighting strike on the outside plant wiring.

Page viii Mitel

5320/5330/5340 IP Phone User Guide – Release 5.0, April 2013

Notice to Canadian Customers

The Class B digital apparatus complies with Canadian ICES-003.

Notice to U.S. Customers

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Notice to European Customers

We, Mitel Networks LTD.

Of, Mitel Castlegate Business Park

Portskewett

Caldicot

NP26 5YR

Declare that for the hereinafter mentioned product the presumption of

conformity with the applicable essential requirements of

DIRECTIVE 1999/5/EC OF THE EUROPEAN

PARLIAMENT (RTTE DIRECTIVE) AND OF THE COUNCIL is given.

Mitel IP Phones: 5320/5330/5340

Any unauthorized modification of the product voids this Declaration.

For a copy of the original signed Declaration of Conformity (in full conformance with EN45014), please contact the Regulatory Approvals Manager at the above address.

Mitel® 5320/5330/5340 IP Phone User Guide – Release 5.0, April 2013 Page ix
