Operating and Installation Instructions Condenser Dryer T 8019 C

To prevent accidents and machine damage read these instructions

before

installation or use.

en - US, CA

M.-Nr. 06 881 341

Contents

IMPORTANT SAFETY INSTRUCTIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Before loading the dryer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Using the dryer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

1. Turn on the dryer and load the laundry ................................7

2. Select a program .................................................7

3. Select a drying option (if needed) ....................................9

4. Select the dryness level...........................................10

5. Select the buzzer (if desired).......................................10

6. Start the program................................................11

7. At the end of a program...........................................11

Canceling or changing a program ....................................12

Adding or removing laundry during a program...........................12

Child lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Dryer care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Cleaning the lint filter ...............................................14

Cleaning the exterior and the control panel .............................15

Cleaning the drum .................................................15

Emptying the condensed water container...............................16

Cleaning the condenser ............................................17

Changing the light bulb .............................................20

Quick Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Frequently asked questions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

After sales service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

INSTALLATION INSTRUCTIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

IMPORTANT SAFETY INSTRUCTIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Washer / Dryer Stack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Electrical connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Installation site ....................................................30

Installation beneath a counter ........................................30

Installation tips ....................................................31

Level the dryer ....................................................31

Caring for the environment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

IMPORTANT SAFETY INSTRUCTIONS

WARNING - To reduce the risk of

fire, electric shock, or injury to persons when using your appliance, follow basic precautions, including the following:

It is essential to read all instructions

before using the appliance.

Do not allow children to play on or in

the appliance. Close supervision is necessary when the appliance is used near children. Always close the door after use to prevent child hazards.

Before this appliance is removed for

service or discarded, remove the door to the drying compartment.

Do not reach into the dryer if the

drum is moving.

Do not install or store this appliance

where it will be exposed to the weather.

Do not tamper

with the controls.

Do not repair or replace any part of

the appliance or attempt any servicing unless specifically recommended in these operating instructions. Repairs to electrical appliances should only be performed by qualified personnel. Incorrectly repaired machines may pose a considerable risk to the user.

Do not use fabric softener sheets to

eliminate static in this dryer. Best results are achieved when a liquid softener is used in the washer. Follow the manufacturers instructions.

To prevent the risk of fire, the

following textiles must not be dried in this dryer:

items which have not been washed.

–

items, such as work-wear, exposed

–

to grease, oils, or other deposits (such as lotions or cosmetics) in your dryer. If these items have not been thoroughly cleaned there is a danger that they may contribute to a chemical reaction that could cause the laundry to ignite when heated even after being removed from the dryer.

– items that have been previously

cleaned, washed, soaked or spotted with gasoline, dry-cleaning solvents or other flammable or explosive substances. They may give off vapors that could ignite or explode.

– items treated with flammable

cleaning agents or items containing acetone, alcohol, petrol, stain remover, wax or chemicals from buffing, etc.

–

items which have been splashed with hair spray, nail polish remover, etc.

When washing heavily soiled items ensure that sufficient detergent is used with a high temperature. If in doubt wash the item several times.

–

items containing foam rubber or similarly textured rubber-like materials.

–

items with padding or filling (e.g. pillows or jackets) which have been damaged. Loose filling could catch fire.

IMPORTANT SAFETY INSTRUCTIONS

Allow the dryer to complete each

stage of the program selected, including the cooling down phase. This will ensure that the items being removed are not too hot to handle

Clean the lint filter before or after

each load.

Keep the area around the air intake

(toe kick) and adjacent surrounding areas free from lint, dust and dirt.

The interior of the machine should

be cleaned periodically by qualified personnel.

This dryer is intended for residential use only!

GROUNDING INSTRUCTIONS

This appliance must be grounded. In the event of malfunction or breakdown, grounding will reduce the risk of electric shock by providing a path of least resistance for electric current. This appliance is equipped with a cord having an equipment grounding conductor and a grounding plug. The plug must be plugged into an appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances.

WARNING – Improper connection of

the equipment-grounding conductor can result in a risk of electric shock. Contact a qualified electrician if you are in doubt as to whether the appliance is properly grounded.

Do not modify the plug provided

with the appliance: if it will not fit the outlet, have a proper outlet installed by a qualified electrician.

SAVE THESE INSTRUCTIONS

Control panel

a e- "Programs" buttons

For selecting a drying program.

b "Options" buttons

For selecting a drying option.

c "Dryness" button

For selecting the dryness level of the finished laundry.

d "Status" display

Shows the current cycle of the drying program.

e "Buzzer" button

When selected, a buzzer will sound at the end of the program.

f "FAULT" indicators

An illuminated indicator will alert you if the child lock has been activated or if a fault occurred.

g "Start/Stop" button

Starts and stops a program.

Interrupts a program when pressed.

Flashes during program selection and lights once the program starts.

h "Door" button

Opens the door when the program has finished. If the dryer is on, the drum interior will light when the door is opened. If the door is left open, the light will go off after a few minutes to save energy.

i "On/Off" button

Turns power to the machine on and off.

Before loading the dryer

The dryer must be correctly installed and connected before the first use. Please refer to the "Installation Instructions".

Program recommendations

Normal

Cottons and Permanent Press blends

–

Before using for the first time, clean

the drum with a cloth.

Before drying, check fabric care labels for special drying instructions.

q Dry with normal temperature r Dry with low temperature

(select "Gentle" option)

s Do not dry in a tumble dryer

– Do not overload the drum!

Overloading the dryer will result in poor drying results and wrinkling.

– Knitted fabrics and flannel tend to

shrink when washed and dried for the first time. Do not over dry these fabrics.

–

To prevent discoloration, do not dry new, dark-colored fabrics with light-colored items.

–

Close zippers and tie up fabric belts and apron ties to prevent tangles and damage to clothing.

–

Do not dry items that may melt or ignite in the dryer, such as plastics, rubber or sneakers.

Wrinkle-free

Permanent Press:

–

select the Hand Iron dryness level and reduce the load size for best drying results

Delicate fabrics, such as polyester:

–

select the Gentle option to reduce creasing

– Pure linen and down filled items

Woolens

– Wool and wool blends

Smooth

– Linen

– Permanent Press (cottons, blends

and synthetics)

Sturdy

–

Durable Cottons and Permanent Press

Fluff / 20 min / 45 min

–

All fabric types

Using the dryer

1. Turn on the dryer and load the laundry

Press the "On/Off" button to turn on

the dryer.

Press the "Door" button to open the

door.

Load the laundry loosely into the

drum.

Make sure the lint filters are in place.

Close the door with a firm swing - do

not push it shut.

For best results use liquid fabric softener when washing laundry. Fabric softener sheet may clog the filters and cause the dryer to overheat.

2. Select a program

^ Press the e or - button until the

desired program indicator lights.

To prevent fabric damage, check that laundry will not be caught in the closed door.

Using the dryer

Program Fabric Note

Normal Available drying options: Turbo, Gentle, Anti-crease

Extra Dry Multi-layer fabrics, mixed loads of

More Dry Uniform loads of cotton, e.g. sheets,

Normal Knitted cotton fabrics that may shrink,

Less Dry Cotton or linen fabrics to be left damp

Hand Iron If fabrics are too damp for ironing, dry

Rotary Iron Cotton or linen fabrics which will be

sturdy cottons, e.g. jeans, towels.

underwear, socks.

e.g. jersey material or lightweight cottons.

for ironing.

ironed with a rotary iron.

Wrinkle-free Available drying options: Turbo, Gentle, Anti-crease

More Dry Synthetic permanent press items,

Normal Permanent press and blended fabrics,

Less Dry Permanent press and blended fabrics

e.g. pants and shirts.

e.g. cotton/synthetic.

requiring an ironed finish.

Special Programs Available drying options: Anti-crease only available in

Fluff, Sturdy

Woolens Delicate items which allow machine

Smooth Program for reducing creasing of

Sturdy For mixed loads of cotton and

Fluff Individual items to be freshened and

drying.

cotton, linen or permanent press fabrics made of cotton, blends or synthetics.

permanent press items.

fluffed with cool air.

TIMED CYCLES Available drying options: Gentle, Anti-crease

20 min Individual items or very small loads,

45 min

e.g. beach towels, swimsuits.

The "Extra dry" program should not be selected for jersey materials.

Items may shrink.

If items are still damp, dry again using "More Dry".

again using "Less Dry".

To prevent moisture loss, roll up the laundry until ironing.

Reduce load size for fabrics that wrinkle easily.

Remove items immediately after the end of the program while still slightly damp. Allow items to air dry.

Reduce load size.

Using the dryer

3. Select a drying option (if needed)

^ A drying option can be selected or

deselected with each press of the button.

OPTIONS

Turbo

Fast drying for sturdy fabrics with increased temperature and a reduced program length.

Gentle

For drying delicate fabrics slowly at a lower temperature.

Anti-crease

Prevents wrinkles if laundry is not removed immediately after the end of a program. The drum periodically rotates for about 1 hour.

Using the dryer

4. Select the dryness level

The dryness level can be selected in the "Normal" and "Wrinkle-free" programs. (The dryness level of the other programs cannot be adjusted.)

^ Press the selection button until the

desired indicator illuminates.

In the "Wrinkle-free" program, only "More Dry", "Normal" and "Less Dry" can be selected.

5. Select the buzzer (if desired)

Press the "Buzzer" button to have a

tone beep at the end of the program.

Indicator light:

on = buzzer selected off = buzzer not selected

To adjust the buzzer volume:

turn the dryer on

–

close the door

–

– select a program

– if the indicator is lit, press the

"Buzzer" button so the indicator light

goes out.

^ Press and hold the "Buzzer" button

until its indicator is lit and you hear the desired volume and tone.

Using the dryer

6. Start the program

Press the "Start/Stop" button.

Once the program starts, the current cycle of the program will be indicated in the "STATUS" display.

7. At the end of a program

The "End/Anti-crease" indicator will light at the end of a program and the buzzer will sound if it was selected.

If a fault occurred, a "FAULT" indicator will light. See "Frequently asked questions" for details.

Press the "Door" button.

Open the door.

^ Remove the laundry.

^ Check that the drum is empty.

^ Clean the lint filter after each use

(see "Dryer care").

^ Close the door.

Press the "On/Off" button to turn off the dryer.

Empty the condensed water container weekly (if not connected to a drain).

Using the dryer

Canceling or changing a program

Press and release the "Start/Stop"

button to stop the drying program.

To continue drying:

Select the new program by pressing

the e or - button.

Select any desired options.

Select a dryness level (available in

the "Normal" and "Wrinkle-free" programs).

Press and release the "Start/Stop"

button to start the new program.

Adding or removing laundry during a program

Turn off the dryer using the "On/Off"

button.

Press the "Door" button.

Open the door.

CAUTION - Do not touch the rear

of the drum while adding or removing items! There is a danger of burns due to high temperatures in the drum.

^ Add or remove items.

^ Close the door.

^ Turn the dryer back on with the

"On/Off" button.

Child lock

When activated, the child lock prevents the dryer from being operated by locking the control panel functions.

The dryer can be turned on but not started. The "Child lock" indicator will flash.

The door can be opened.

To activate the child lock

1. Make sure the dryer is turned off and

the door is closed.

2. Press and hold the "Anti-crease" and "DRYNESS" buttons at the same time, hold until step 5.

3. Turn on the dryer with the "On/Off" button.

4. Press the "OPTIONS" button 3 times.

5. Release the "Anti-crease" and

"DRYNESS" buttons.

To deactivate the child lock

Repeat steps 1. to 5.

The "Child lock" indicator will go out.

The control panel is now unlocked.

6. Turn off the dryer using the "On/Off" button.

The "Child lock" indicator will flash and the dryer is now locked.

6. Turn off the dryer using the "On/Off" button.

Dryer care

Cleaning the lint filter

The lint filter must be cleaned after every program.

^ Open the door and remove the lint

filter 1 by gently lifting it upwards.

^ Remove the lint from the door frame

lint filter with your fingers.

^ Any lint remaining in the hollow

casing of the door can be removed through the gap at the bottom with a dust brush or vacuum.

^ Clean the gasket 2 with a damp

cloth.

Wipe the lint off the filter with your hand (do not use any sharp objects!)

^ Return the lint filter and close the

door.

The lint filters (once removed from the dryer) can be rinsed with hot water if necessary. The filters must be dried thoroughly before being returned to the dryer.

Take the door lint filters out by turning the knob at the filter top.

Cleaning the exterior and the control panel

To reduce the risk of electric

shock, disconnect the dryer from the power supply by shutting off the power main, tripping the circuit breaker or unplugging the power cord before performing maintenance. Never use abrasive cleaners, scouring pads, steel wool or caustic (oven) cleaners on the dryer. They will damage the surface.

^ The exterior and the control panel

can be cleaned with warm water and liquid dish soap applied with a soft sponge.

^ Wipe dry.

Dryer care

Cleaning the drum

^ The stainless steel surfaces of the

drum can be cleaned using a non-abrasive stainless steel cleaner.

Wipe clean with a soft cloth.

Dryer care

Emptying the condensed water container

Depending on the installation, the condensed water will either be pumped to a drain or collected in the condensed water container, located in the upper left corner of the machine. The container holds approximately 1 gallon of water.

The container should be emptied weekly.

Should the container be full when the tumble dryer is started, or if it becomes full during normal operation:

– The "Container" indicator will light.

– The buzzer will sound.

Pull out the container slightly to the

right with both hands.

Hold the cap open while emptying the container.

When the container is empty, push it back into its opening until it clicks into place.

Restart the drying program if needed.

Do not drink the condensed water!

Dryer care

Cleaning the condenser

To reduce the risk of electric

shock, disconnect the dryer from the power supply by shutting off the power main, tripping the circuit breaker or unplugging the power cord before performing maintenance.

Detergent residues, hair and lint in the drying air can penetrate filters and clog the condenser. Particles from the cool air sucked in from the install location can cause blockages.

^ Check the condenser at least twice a

year. If used often, check every 100 loads.

^ Clean if necessary.

Removing the condenser

Open the door.

^ Open the access panel, located on

the lower left corner of the machine, using the yellow tool supplied with the machine. Hold the panel when opening it.

Remove the panel up and out of the condenser access area.

Turn the condenser door lock down and remove the door.

Dryer care

Turn the condenser lock up.

Checking the condenser

Hold the condenser against the light.

^ Look through the front and left side

(as illustrated above) of the condenser to check for lint.

If no lint is visible:

^ Return the condenser.

Pull out the condenser.

If lint is visible:

^ Clean the condenser as described.

Dryer care

Cleaning the condenser

Rinse the condenser along all sides

with warm water as shown in pictures below.

^ Check the condenser for visible

soiling. Continue rinsing until the condenser until clean.

Returning the condenser

Put the condenser back in place in

the reverse order.

Check the gasket around the front of the condenser is flush and not crimped.

To prevent leaks, make certain the

condenser is pushed in all the way and locked in place.

Restore power.

Check the condenser gasket for soiling. Do not remove or kink the gasket!

Place the condenser lengthwise on a towel to air dry.

Dryer care

Changing the light bulb

To reduce the risk of electric

shock, disconnect the dryer from the power supply by shutting off the power main, tripping the circuit breaker or unplugging the power cord before performing maintenance.

Open the door.

The bulb cover is located along the upper rim of the drum opening.

Replace the light bulb with a

temperature proof bulb, available from Miele.

The light bulb must not exceed the maximum wattage listed on the data plate.

Flip up the light bulb cover and press

it firmly until it clicks into place.

Make sure the bulb cover is

securely closed to prevent a short circuit or penetrating moisture.

^ Restore power.

Slide a screwdriver with a wide head underneath the side edge of the bulb cover and twist (see illustration).

Flip down the bulb cover.

Quick Guide

Remove this guide for easy reference

Please read all instructions, especially the "Important Safety Instructions",

before using the dryer.

Quick Guide

1.Turn on the dryer and load the laundry

Press the "On/Off" button to turn on

the dryer.

Press the "Door" button to open the

door.

^ Load the laundry into the drum. Make

sure that there is enough space in the drum for clothes to tumble freely.

2. Select a program

^ Press the e or - button until the

desired program indicator lights.

3. Select a drying option (if needed)

To prevent fabric damage, check that laundry will not be caught in the closed door.

Close the door with a firm swing - do not push it shut.

A drying option can be selected or deselected with each press of the button.

Quick Guide

4. Select the dryness level

^ Press the selection button until the

desired indicator illuminates.

5. Select the buzzer (if desired)

6. Start the program

Press the "Start/Stop" button.

7. At the end of a program

The "Anti-crease / End" indicator will light.

Press "Door" and remove the laundry.

^ Clean the lint filter.

^ Press the "On/Off" button to turn off

the dryer.

Quick Guide

Program When to use Note

Normal Available drying options Turbo, Gentle, Anti-crease

Extra Dry For laundry to be folded and shelved

immediately, e.g. jeans, towels.

More Dry For uniform loads, e.g. sheets,

underwear, socks.

Normal For knitted items that may shrink, e.g.

jersey material or lightweight cottons.

Less Dry For items to be left damp for ironing.

Hand Iron If fabrics are too damp, dry again using

Rotary Iron For items to be ironed with a rotary

iron.

Wrinkle-free Available drying options Turbo, Gentle, Anti-crease

More Dry For items that do not require ironing,

e.g. pants and shirts.

Normal For items to be hung after drying.

Less Dry For items which require ironing. Reduce load size for fabrics that wrinkle

The "Extra Dry" program should not be selected for jersey materials.

Items may shrink.

If items are still damp, dry again using "More Dry".

"Less Dry".

To prevent moisture loss, roll up the laundry until ready to iron.

easily.

Special Programs Available drying options: Anti-crease only available in Fluff, Sturdy

Woolens Delicate items which allow machine

drying.

Smooth Program for reducing creasing in

delicate items.

Sturdy For mixed loads of durable items.

Fluff Individual items to be freshened and

fluffed with cool air.

Take items out immediately after the end of the program while still slightly damp. Allow items to air dry.

Reduce load size.

TIMED CYCLES Available drying options Gentle, Anti-crease

20 min Individual items or very small loads,

45 min

e.g. beach towels, swimsuits.

Frequently asked questions

What if the dryer will not run?

Possible fault Solution

The "Start/Stop" button was not pressed.

The circuit breaker tripped or the dryer is unplugged.

The door is not closed. Close the door properly.

How do I prevent static cling?

Add fabric softener to laundry when washing or select the "Less Dry" setting on the dryer.

Do not use fabric softener sheets in this dryer.

What if the drum light does not come on?

Possible fault Solution

The bulb may be bad or burned out. See "Changing the light bulb."

What if the "Child Lock" indicator flashes after turning the dryer on and a program cannot be started?

Possible fault Solution

The child lock is activated. Deactivate the child lock. See "Child

What if the program stops, the "End/Anti-crease" indicator lights and the buzzer sounds?

Make sure the dryer is on. Press the "Start/ Stop" button to begin the drying program.

Make sure the dryer is plugged in or reset the circuit breaker.

Lock."

Possible fault Solution

The drum is empty. Load laundry into the dryer. The dryer

will not operate when the drum is empty. Single items should be dried with "Sturdy" or a timed program and dry items in the "Fluff" program.

Frequently asked questions

What if the "Filter/Vent" fault indicator is lit?

Possible fault Solution

The lint filter is clogged. Clean the lint filters. See "Dryer care".

The air supply in the room is insufficient.

What if the program runs too long or stops?

Possible fault Solution

The airflow is insufficient in the area of the dryer.

The lint filters are clogged. Clean the lint filters (see "Dryer care").

The laundry was not spun sufficiently in the washer.

The dryer is overloaded. Reduce the load size.

Metal zippers interfere with the dryer’s moisture sensors.

The condenser is clogged with lint or detergent residue.

The air vent below the door is blocked. Remove any blockages.

What if the laundry is not dry enough?

Possible fault

The load contained too many dissimilar items (size and fabric.)

Open a window or door to increase airflow.

Select a higher spin speed in the wash program.

Select a timed program to avoid over drying.

Clean the condenser periodically (see "Dryer care").

What if water has collected around the drum opening?

Possible fault

This is condensed moisture from the laundry.

After sales service

Repairs

In the event of a fault which you cannot fix yourself, please contact Miele's Technical Service Dept.

When contacting Technical Service, please quote the model and serial number of your appliance. They can be found on the data plate located below the drum opening.

PC Update

The indicator on the control panel marked # allows a technician to update the dryer with new technology.

For example, if new programs or fabrics are developed, a service technician will be able to modify the existing program cycles accordingly.

MieleCare

(only USA)

MieleCare, our Extended Service Contract program; gives you the assurance of knowing that your appliance investment is covered by 5 years of worry free ownership. MieleCare is the only Extended Service Contract in the industry that guarantees repairs by a Miele Authorized Service Provider using genuine Miele parts. Only genuine Miele parts installed by factory trained professionals can guarantee the safety, reliability and longevity of your Miele appliance.

Please note that unless expressly approved in writing by the Miele Service department, Extended Service Contracts offered by other providers for Miele products will not be recognized by Miele. Our goal is to prevent unauthorized (and untrained) service personnel from working on your Miele products, possibly doing further damage to them, you and/or your home.

To learn more about MieleCare Extended Service Contracts, please contact your appliance dealer or visit us online at:

http://miele.com/mielecare

Installation Instructions

To prevent accidents and machine damage read these instructions

before

installation or use.

IMPORTANT SAFETY INSTRUCTIONS

, WARNING - Risk of Fire

To reduce the risk of severe injury or

death, follow all installation instructions.

Clothes dryer installation must be

performed by a qualified installer.

Install the clothes dryer according to

the manufacturer's instructions and local codes.

Repair and maintenance work

should be performed by a Miele authorized service technician. Work by unqualified persons could be dangerous and could void the warranty.

Before installation, disconnect the

tumble dryer from the electrical supply by shutting off the power main, unplugging the power cord or tripping the circuit breaker. Do not restore power until the installation is complete.

GROUNDING INSTRUCTIONS

WARNING – Improper connection of

the equipment grounding conductor can result in a risk of electric shock. Check with a qualified electrician or service representative or personnel if you are in doubt as to whether the appliance is properly grounded.

Do not modify the plug provided

with the appliance! If it will not fit the outlet, have a proper outlet installed by a qualified electrician.

Do not use an extension cord to

connect this appliance to the power supply. Extension cords do not guarantee the required safety of the appliance (e.g. danger of overheating).

The installation of this unit in non

stationary locations (e.g. ships) must be performed by a qualified installer or service agency, in strict accordance with national and local safety regulations and standards.

Do not install the machine in rooms

where temperatures below freezing may occur.

If there is any doubt concerning

installation, contact Miele’s Technical Service Department.

U 1-800-999-1360

techserv@mieleusa.com

V 1-800-565-6435

service@miele.ca

SAVE THESE INSTRUCTIONS

The tumble dryer can also be placed on top of a Miele washing machine for a stacked installation. An appropriate stacking kit is required. The stacking kit is available from your Miele dealer or the Miele Technical Service Department.

Installation of the stacking kit

must be performed by a Miele authorized technician.

Height of a stacked installation

5’ 6

/8" (168.6 cm)

(Stacking kit with a pull out shelf)

Washer / Dryer Stack

Electrical connection

GROUNDING INSTRUCTIONS This appliance must be grounded. In the event of malfunction or breakdown, grounding will reduce the risk of electric shock by providing a path of least resistance for electric current. This appliance is equipped with a cord having an equipment grounding conductor and a grounding plug. The plug must be plugged into an appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances.

WARNING – Improper connection of the equipment grounding conductor can result in a risk of electric shock. Check with a qualified electrician or service representative or personnel if you are in doubt as to whether the appliance is properly grounded.

The dryer comes witha5ftlong, 12/4 AWG cord and a NEMA 14-30 P plug.

It should be connected to a 120/208-240 V, 30 A, 60 Hz AC power supply. A 3 pole-4 wire grounding power outlet (NEMA type 14-30 R) is necessary.

Do not modify the plug provided with the appliance! If it will not fit the outlet, have a proper outlet installed by a qualified electrician.

Front view

Installation

a Power cord with plug

b Condensed water container

c Control panel

d Door (with decor option)

e Access panel to condenser

f Four height adjustable feet

g Optional drain hose:

An alternative to using the condensed water container is to drain condensed water into a sink, standpipe or gully.

Installation

Installation site

Do not install the dryer in an area

where it can be blocked, e.g. behind a door.

Transporting the dryer to the installation site

The rear excess end of the lid has a handle box for transport.

Use the front dryer feet and the rear

excess end to transport the dryer from the packaging base to the installation site.

Installation beneath a counter

When the machine lid needs to

be removed to reduce the height of the machine, a built under spacer kit* is necessary. It must be installed by a Miele Service Technician. The cover plate of the built under kit replaces the appliance lid and ensures electrical safety.

An installation manual is supplied with the built-under spacer kit.

The electrical connection should be near the dryer and accessible at all times.

Extended machine feet* are recommended at a built-in height of more that 33

^ Set the extended machine feet on a

height of 1 Remove the original machine feet and replace them with the extended ones.

/16" (840 mm).

/16" (40 mm).

One or two filler frames* are recommended at a niche height of

/4"/3413/16"to36"/365/8"

(870/885 - 915/930 mm).

* (optional accessory)

An existing continuous toe kick must be interrupted at the dryer location!

Reinstallation of the machine lid

When reinstalling the appliance lid, check the firm fit of the cover at the rear bracket for a safe transport of the dryer.

Installation

Installation tips

An airflow gap of3/8" (10 mm) must be provided between the machine and the floor. This airflow gap must not be blocked by a toe-kick or thick piled carpets.

Sufficient venting of the installation site, e.g. by opening a window or door, is essential for the dryer's operation. Otherwise drying times and energy usage may increase.

Do not install the dryer next to a refrigerator. The warm air which emanates from the dryer can affect the thermostat of the refrigerator, causing it to run continuously.

Room ventilation

The room air, which is taken in when the dryer is in operation, is blown out via the exhaust grill on the bottom front. This dry air heats the air in the room. It is important, particularly if the room is small, to ensure adequate ventilation. Opening a door or window, for example, will improve supply of cooler air. Otherwise drying times and energy usage may increase.

Level the dryer

^ The dryer must be level to ensure

safe and proper operation.

The machine can be leveled by turning the legs clockwise or counterclockwise as necessary.

Installation

Installing the decor panel

The door can be fitted with a customized door panel (optional accessory) to match the adjacent cabinets.

Decor panel measures

Width .............23

Height .............23

Thickness ....

Open the door.

/16"-3/16" (1.6 - 4.8 mm)

/4" (591 mm)

/8" (593 mm)

Unscrew the 4 screws at the top of the decor frame and pull it forward.

Loose the screws at the other sides of the decor frame but do not take them out.

A decor panel up to

/16" thickness can be inserted if the frame sides are pushed forward.

^ Insert the decor panel from above.

^ Press the frame sides onto the panel

und tighten the screws.

^ Push the top of the decor frame onto

the frame from the front and fix it with the four screws.

Installation

Shortening the door panel

The door panel can be shortened to match the height of the adjacent cabinetry.

The measure X equals the space from the bottom of the washer door to the bottom of the adjacent cabinet.

Cut the bottom of the door panel with a jigsaw according to X.

Cut the side decor bars with a hacksaw.

Installation

Open the door.

^ To remove the door panel unscrew

the 10 screws (arrows) from the door sheet panel.

^ Remove the three decor bars from

the door panel by unscrewing the screws.

^ Cut the bottom of the door panel and

the two side decor bars by X.

Drill four holes into the door panel to fix the lower decor bar.

Install the decor bars and the door panel.

To install a decor panel, check if it needs to be shortened.

Installation

External water drain

When drying is in progress, condensed water is pumped into the condensed water container through the drain hose at the back of the dryer. The condensed water can be drained directly into a drain if the machine is installed near a sink or standpipe so that the condensed water container does not have to be emptied.

Drain hose length:. . . approx. 3 ft. (1 m)

Extension hose (accessory) . . 6 ft. (2 m)

Maximum Drain height: . . 4’ 11" (1.5 m)

Maximum Drain length .....13ft.(4m)

Under special installation

circumstances this dryer must be fitted with a non-return valve (accessory), see "Special Installation".

Max. drain height

with non-return valve: ....3’3"ft.(1m)

Installing the drain hose

Do not pull or kink the drain hose,

this could cause damage!

^ Unclip the drain hose from the

clamps 1 and 2, and pull it off the holder, 3.

The lower clamps, 4, can be opened to install the drain hose or to feed the power cable through.

Installing the drain hose (sink, gully)

See illustration, front view.

If you want to drain the

condensed water into a sink, secure the hose carefully, e.g. by tying the hose to the water faucet, to avoid water damage.

Use the curved guide to prevent the

drain hose from becoming kinked (see "Front view" illustration).

Special Installation

In special installation

circumstances, the non-return valve must be installed. Water

flowing back from the dryer can cause damage.

Installation

1 Adapter

2 Sink coupling nut

3 Hose clamp

Special Installations are:

– Connection to a sink standpipe (see

example)

–

Miscellaneous connections where additional appliances like a washer or dishwasher are connected also.

Example: Connection to a standpipe

The drain hose can be connected to a special sink standpipe.

Remove the adapter and the hose clamp from behind from the lower rear side of the dryer.

4 Hose extension (Accessory)

5 Non-return valve (Accessory)

6 Dryer drain hose

Fit the adapter, 1, to the stand pipe using nut, 2. If this nut is sealed with a flat disc, take the disc out.

Attach the end of the hose to the adap ter 1 and secure the hose clamp 3.

The non-return valve 5 must be installed with the arrow pointing in the direction of the water flow (see illustration), otherwise it will not work properly.

Install the non-return valve 5 at the dryer drain hose 6, see illustration.

Secure the non-return valve firmly with the hose clamp (accessory).

Caring for the environment

Disposal of the packing materials

The packing materials protect the appliance during shipping. They have been designed to be biodegradable and recyclable.

To prevent suffocation, ensure that any plastic wrappings, bags, etc. are disposed of safely and kept out of the reach of children.

Disposal of an appliance

Old appliances may contain materials that can be recycled. Please contact your local recycling authority about the possibility of recycling these materials.

Ensure that a discarded dryer presents no danger to children. When being stored for disposal remove the door to the drying compartment.

363738

For the most updated manual check the Miele web site.

M.-Nr. 06 881 341 / 04

Miele T 8019 C Operating instructions

Specifications and Main Features

Frequently Asked Questions

User Manual
