Operating instructions
for condenser tumble dryer
T 7944 C
To avoid the risk of accidents
or damage to the appliance
it is essential to read these
instructions before it is installed
and used for the first time.
en-GB
M.-Nr. 07 851 060
Caring for the environment
Disposal of the packing
material
The transport and protective packing
has been selected from materials which
are environmentally friendly for disposal
and should be recycled.
Ensure that any plastic wrappings,
bags, etc are disposed of safely and
kept out of the reach of babies and
young children. Danger of suffocation.
Disposal of your old appliance
Electrical and electronic appliances
often contain materials which, if
handled or disposed of incorrectly
could be potentially hazardous to
human health and to the environment.
They are, however, essential for the
correct functioning of your appliance.
Please do not therefore dispose it with
your household waste.
Energy saving tips
To avoid unnecessarily long drying
times and high consumption of energy:
Make sure that your laundry is
–
thoroughly spun before drying.
The higher the spin, the greater the
savings that can be made in energy
and time during drying.
Load according to the optimum
–
amount of laundry recommended for
the programme being used (see
Programme chart).
Underloading is uneconomical.
Overloading gives a poorer quality of
drying and may cause unnecessary
creasing.
– Make sure the room in which the
dryer is located is well ventilated.
– Make sure the fluff filters are clean
before using the dryer.
– Check the condenser unit from time
to time and clean it when necessary.
Please dispose of it at your local
community waste recycling centre or
contact your dealer for advice. Ensure
that it presents no danger to children
while being stored for disposal.
2
Contents
Caring for the environment..........................................2
Warning and Safety instructions .....................................6
Operating the tumble dryer.........................................14
Control panel .....................................................14
Notes on laundry care .............................................16
Garment care label symbols .........................................16
Tips on drying ....................................................16
How to dry correctly ..............................................17
Brief instructions ..................................................17
Extra options / Delay start..........................................20
Extra options .....................................................20
Low temperature................................................20
Buzzer........................................................20
Delay start .......................................................20
Programme chart .................................................21
Changing the programme sequence .................................24
Once a programme has started ......................................24
- changing the programme........................................24
- cancelling the programme and then selecting a different programme .....24
- cancelling the programme and then removing the laundry ..............24
Altering Delay start ................................................24
Adding or removing laundry after a programme has started ................24
Time remaining ...................................................24
Electronic system lock ............................................25
3
Contents
Cleaning and care ................................................26
Emptying the condensed water container...............................26
Cleaning the fluff filters .............................................27
Cleaning them whilst dry .........................................27
Cleaning them with water .........................................28
Cleaning the tumble dryer ...........................................29
Cleaning the condenser unit .........................................30
Removing the condenser unit......................................30
Checking the condenser unit ......................................31
Cleaning the condenser unit.......................................31
Replacing the condenser unit......................................32
Problem solving guide ............................................33
Check and fault messages ..........................................33
An unsatisfactory drying result .......................................36
Other problems ...................................................37
Changing the lamp ................................................39
After Sales service................................................40
Repairs..........................................................40
Future updates (PC) ...............................................40
Appliance guarantee ...............................................40
Optional accessories ...............................................40
Installation and connection ........................................41
Front view........................................................41
Rear view ........................................................42
Installation site ....................................................42
Transporting the machine to its installation site ........................42
Washer-dryer stack..............................................42
Levelling the machine............................................43
Room ventilation ................................................43
Before moving the tumble dryer again (e.g. when moving house) .........43
4
Contents
External condensed water outlet ......................................44
Arranging the drain hose .........................................44
External drainage via a sink or gully ................................45
Installation conditions requiring a non-return valve .....................45
Electrical connection .............................................47
Electrical connection U.K. ...........................................47
Consumption data ................................................48
Technical data ...................................................49
Programmable functions...........................................50
Altering the residual moisture level in the Cottons programme...............50
Altering the residual moisture level in the Minimum iron programme ..........51
Anti-crease ......................................................52
Altering the volume of the buzzer .....................................53
Altering the standard drying level in the Automatic plus programme ..........54
Extending the cooling down time .....................................55
Standby .........................................................56
Memory function ..................................................58
Clean out airways indicator ..........................................59
Keypad tone .....................................................60
Adjusting the dryer's electronics for very soft water .......................61
Extending the range of the drying levels ................................62
5
Warning and Safety instructions
It is essential to read these instructions.
~
This tumble dryer conforms to current safety requirements.
Inappropriate use can, however, lead to personal injury and
damage to property.
To avoid the risk of accidents and damage to the tumble dryer,
please read these instructions carefully before using it for the first
time. They contain important information on its safety, installation,
use and maintenance.
Keep these instructions in a safe place and ensure that new users
are familiar with the content. Pass them on to any future owner.
Correct application
This tumble dryer is not designed for commercial use. It is
~
intended for use in domestic households and similar working and
residential environments.
The tumble dryer is not intended for outdoor use.
~
It must only be used as a domestic appliance to dry items which
~
have been washed in a water solution and which are marked on the
manufacturer's care label as being suitable for tumble drying. If
using dry cleaning kits, do so at your own risk, and follow the
instructions provided on the packaging.
Any other usage is not supported by the manufacturer and could be
dangerous. Miele cannot be held liable for damage resulting from
incorrect or improper use or operation.
6
Warning and Safety instructions
The tumble dryer can only be used by people with reduced
~
physical, sensory or mental capabilities, or lack of experience or
knowledge, if they are are supervised whilst using it or have been
shown how to use it in a safe way and understand the hazards
involved.
Safety with children
Children under 8 years of age must be kept away from the tumble
~
dryer unless they are constantly supervised.
Children 8 years and older may only use, clean or maintain the
~
tumble dryer without supervision if they have been shown how to do
so in a safe way and understand the hazards involved.
The tumble dryer is not a toy! To prevent the risk of injury, do not
~
allow children to play with it or near it, or to play with the controls.
7
Warning and Safety instructions
Technical safety
Before setting up the tumble dryer, check it for any externally
~
visible damage.
Do not install or use a damaged tumble dryer.
Before connecting the tumble dryer, ensure that the connection
~
data on the data plate (voltage and frequency) match the mains
electricity supply. If in any doubt, consult a qualified electrician.
The electrical safety of this tumble dryer can only be guaranteed
~
when correctly earthed. It is most important that this basic safety
requirement is observed and regularly tested, and where there is
any doubt, the household wiring system should be inspected by a
qualified electrician. Miele cannot be held liable for the
consequences of an inadequate earthing system (e.g. electric
shock).
Do not connect the tumble dryer to the mains electricity supply by
~
an extension lead. Extension leads do not guarantee the required
safety of the tumble dryer (e.g. danger of overheating).
If the electrical connection cable is faulty it must only be replaced
~
by a Miele approved service technician to protect the user from
danger.
Unauthorised repairs could result in unforeseen dangers for the
~
user, for which Miele cannot accept liability. Repairs should only be
undertaken by a Miele approved service technician, otherwise any
subsequent damage will not be covered by the guarantee. Ensure
current is not supplied to the tumble dryer until after maintenance or
repair work has been carried out.
8
Warning and Safety instructions
Faulty components must only be replaced by genuine Miele
~
original spare parts. Only when these parts are fitted can the safety
standards of the tumble dryer be guaranteed.
The tumble dryer must be isolated from the electricity supply in
~
the event of a fault and during cleaning and maintenance.
The tumble dryer must not be used in a non-stationary location
~
(e.g. on a ship).
Do not make any alterations to the tumble dryer, unless
~
authorised to do so by Miele.
In areas which may be subject to infestation by cockroaches or
~
other vermin, pay particular attention to keeping the tumble dryer
and its surroundings in a clean condition at all times. Any damage
which may be caused by cockroaches or other vermin will not be
covered by the guarantee.
9
Warning and Safety instructions
Correct use
To prevent the risk of fire, the following textiles must not be dried
~
in this appliance:
items which have not been washed.
–
items, such as workwear, which have not been thoroughly
–
cleaned and which are still soiled with grease, oil or other
deposits (such as cosmetics, lotions etc).
If items have not been thoroughly cleaned there is a danger that
these might self-ignite when heated, even after they have been
removed from the dryer at the end of the programme.
– items (e.g. mops and floor cloths) which have been treated with
inflammable cleaning agents or which contain residues of
acetone, alcohol, benzine, petrol, kerosene, stain remover,
turpentine, wax and wax remover or other chemicals.
– items which have been splashed with hair lacquer, hair spray, nail
varnish remover or similar substances.
When washing such heavily soiled items, ensure that you use
additional detergent and select a high temperature. If in doubt,
wash the items several times.
Remove all items such as lighters and matches from pockets.
~
Warning: Do not switch the tumble dryer off before the drying
~
programme has finished. If this is done, the laundry must be hung
up or spread out to cool it down.
10
Warning and Safety instructions
Danger.
~
This tumble dryer must not be connected to a controllable socket
(e.g. a timer switch or a peak load shut-off device).
If the dryer programme were to be interrupted before the end of the
cooling down phase, the laundry could self-combust.
To prevent the risk of fire, the following must not be tumble dried:
~
items which have been cleaned using chemicals (e.g.
–
professional dry-cleaning agents).
fabrics which contain a large proportion of rubber, foam rubber or
–
rubber-like materials. For example, products made from latex
foam rubber, shower caps, waterproof textiles, rubberised articles
and items of clothing and pillows with foam rubber filling.
– damaged items which contain padding or fillings (e.g. pillows,
jackets). When damaged, the filling can get out with the risk of
igniting in the dryer.
In many programmes, the heating phase is followed by a cooling
~
down phase to ensure that the items are not too hot to handle when
you remove them (this also avoids the danger of the laundry
self-igniting). The programme is not finished until the cooling down
phase has been completed.
As soon as the programme has finished, remove all laundry from the
drum.
Fabric conditioner and similar products must be used according
~
to the instructions on the manufacturer's packaging.
Do not let anyone sit or lean on the door, as this can cause the
~
tumble dryer to tip up.
Always close the door after use. This way you will avoid the
~
danger of:
–
children climbing into the dryer or hiding things in it.
–
pets or other small animals climbing into it.
11
Warning and Safety instructions
The dryer must not be used without the fluff filters in place or if
~
the fluff filters are damaged in any way.
The fluff filters must be cleaned regularly.
~
The dryer must not be used without the condenser unit in place.
~
The fluff filters must be thoroughly dried after cleaning. Damp or
~
wet filters could cause operational faults.
Do not install the tumble dryer in a room where there is a risk of
~
frost occurring. At temperatures around freezing point the tumble
dryer may not be able to operate properly. There is a risk of damage
if the condensed water is allowed to freeze in the pump and in the
drain hose. The ambient room temperature should be between +2°C
and +35°C.
If the water is drained externally instead of being collected in the
~
condensed water container, make sure the drain hose is securely
attached if you hang it in a sink or basin to avoid the hose slipping
and the water causing damage.
Condensed water is not drinking water.
~
It can cause health problems in both people and animals.
Always keep the area around the tumble dryer free of dust and
~
fluff. Dust drawn into the tumble dryer can cause blockages in the
condenser unit over time.
The tumble dryer must not be hosed down.
~
12
Warning and Safety instructions
Accessories
Only use genuine Miele original spare parts and accessories with
~
this tumble dryer.
If non-Miele parts are used, guarantee, performance and product
liability claims may be invalidated.
Miele cannot be held liable for damage caused by
non-compliance with these Warning and Safety instructions.
13
Operating the tumble dryer
Control panel
a Perfect Dry indicator
For all drying level programmes. See
next page.
b Display
See next page.
c Delay start button
This button is used for:
- Delaying the start of a programme
- Selecting the duration of the timed
drying Warm air and Cool air
programmes
d Buzzer button
An audible tone sounds at the end of
the programme.
e Check lights
See "Problem solving guide" / "After
sales service".
f Start/Stop button
For starting or cancelling a
programme.
The button flashes while a
programme is being selected and
then lights up constantly when the
programme has started.
g Low temperature button
Delicate fabrics are dried at a lower
temperature.
h Drying level button
with indicator lights to show the
drying level selected.
i Programme selector
with indicator lights to show the
programme selected.
j Door button
Pressing this button will open the
door even when the dryer is
switched off at the mains.
k On/Off button jk
For switching the dryer on and off.
14
Operating the tumble dryer
The display shows:
Programme duration
–
Programme stage
–
Drying
Cooling down
Finish
Check and fault messages
–
The following are also selected via
the display:
Duration of the Warm air and Cool air
–
programmes
– Delay start
You can select a programme and set
it to start at a later time.
The programme will start
automatically once the delay start
time has a elapsed.
– Programmable functions
Default settings can be altered to
adapt the dryer to different
requirements. See "Programmable
functions" at the end of this booklet
for more details.
Perfect Dry indicator
The Perfect Dry system measures the
residual content in the laundry in the
sensor drying programmes to ensure
perfect drying results.
The Perfect Dry indicator will light up
again when the selected drying level is
reached and remain on until the
programme is finished.
The Perfect Dry indicator does not light
up during time controlled programmes:
Woollens handcare, Cool air, Warm air,
Gentle smoothing.
Programme duration /
Estimated time remaining
The estimated duration (time remaining)
will appear in the display.
The following factors all affect the
estimated time remaining: residual
moisture content after spinning; type of
fabric; size of load; room temperature;
fluctuations in power supply.
The electronics continually assess
conditions in the dryer and adjust the
estimated time remaining for a more
accurate reading. Because of this, the
time displayed can alter during the
course of a programme.
Programmes can also finish earlier than
expected, if, for example, particularly
fine fabrics are being dried, the load is
very small or items were partially dry
beforehand.
After a programme has started, the
electronics will estimate the duration of
the programme (time remaining). The
Perfect Dry indicator will flash while this
is happening.
After a short while, the programme
duration will appear in the display and
the indicator will go out.
15
Notes on laundry care
Garment care label symbols
Drying
q Normal/higher temperature
r Reduced temperature:
Select Low temperature
(for delicate textiles)
s Do not tumble dry
Ironing
I Very hot
H Hot
G Warm
J Do not iron
Tips on drying
– Always observe the maximum
recommended loads given in the
"Programme chart". Never overload
the drum.
Overloading can cause unnecessary
wear and tear to the laundry, give a
disappointing drying result and
cause more creasing.
–
Do not put soaking wet items into the
tumble dryer. Spin fabrics for at least
30 seconds before drying.
–
Open jackets
evenly.
–
Use the Automatic plus programme
for drying mixed loads of cotton and
minimum iron fabrics.
–
Woollens and wool blends
become matted and shrink if dried in
a tumble dryer. They can, however,
be "fluffed up" using the Woollens
handcare programme.
so that they can dry
tend to
Down-filled garments
–
which have a tendency to shrink,
depending on the quality of the item.
They can be partially dried using the
Gentle smoothing programme.
Pure linen
–
dried if specified as suitable by the
manufacturer on the care label, as
the surface of the fabric may
otherwise become rough.
Loopknit garments
–
underwear) tend to shrink depending
on their quality. Do not over-dry
these textiles. When purchasing
these garments it is advisable to take
their shrinkage properties into
account.
– Minimum iron fabrics
more, the larger the load. This is also
the case for garments made from
very fine weave fabrics, such as
shirts or blouses.
If in doubt, divide the garments into
smaller loads.
–
Starched laundry
tumble dryer. To achieve the usual
finish, double the amount of starch
should be used.
–
New dark coloured garments
be washed and dried separately
from light coloured garments to avoid
the danger of colours running and
discolouring other garments or even
plastic components in the dryer.
Dark coloured fibres can also settle
on light coloured garments and vice
versa.
should only be machine
have linings
(e.g. T-shirts and
tend to crease
can be dried in the
should
16
How to dry correctly
Brief instructions
The headings numbered (A, B, C ...)
show the operating sequence and can
be used as a brief guide to using your
dryer.
A Sort the laundry
To ensure an even drying result sort
laundry according to:
. . . the drying level required
. . . the type of fibre or weave
. . . size
. . . the moisture content after spinning.
Make sure that objects e.g.
,
detergent dispensing balls have
been removed from the laundry.
They could melt, and cause damage
to the dryer or the laundry.
– Check seams and stitching to ensure
that padding and linings are intact.
– Fasten duvet covers and pillow
cases to prevent small items from
being trapped inside them.
C Load the tumble dryer
Press the Door button to open the
^
door.
Load the laundry loosely into the
^
drum.
Do not overload the drum. See the
"Programme chart" for
recommended loads for each
programme.
Overloading can cause unnecessary
wear and tear to the laundry and
give a disappointing drying result.
^ Before closing the door make sure
the fluff filter is correctly positioned.
–
Fasten hooks and eyes etc.
–
Tie fabric belts and apron strings.
–
Sew in or remove underwiring from
bras.
B Turn on the tumble dryer
^
Switch the dryer on by pressing the
On/Off jk button in.
The tumble dryer may be switched on
after loading, saving energy as the light
will not come on.
Check the laundry is right inside the
drum so that it cannot get trapped or
damaged when the door is shut.
^
Shut the door either with a gentle
swing, or lean against it and push it
shut.
17
How to dry correctly
D Select a programme
Select the programme you want.
^
The indicator for the programme
selected will light up.
A drying level or extra option indicator
may also light up and the duration may
also be displayed.
Drying level programmes
– Cottons, Minimum iron, Delicates,
Express, Automatic plus, Denim
programmes and with some the drying
level is pre-set and cannot be changed.
Tip:
You can extend the range of the drying
levels for some programmes (see
"Programmable functions").
Woollens handcare, Gentle
smoothing
This programme cannot be changed.
–
Selecting the duration of the timed
drying Cool air and Warm air
programmes
The indicator light for the Delay start
button will flash when the Cool air or
Warm air programme is selected.
^ Press the Delay start button
repeatedly until the required duration
shows in the display.
Range:
^
Press the drying level button
repeatedly until the indicator for the
drying level you want lights up (for
almost all programmes).
Any of the four drying levels can be
selected for the Cottons and Express
programmes. A more limited range is
available when using other
18
–
Cool air: from 20 minutes up to i:00
hour.
–
Warm air: from i5 minutes up to 2:00
hour.
E Select any Extra options / Delay
start
^
Low temperature, Buzzer and Delay
start are selected by pressing the
appropriate button (see "Extra
options/Delay start").
Anti-crease (see next page) is
permanently switched on.
N.B.: It is not possible to select Delay
start when using the Warm air or Cool
air programme.
How to dry correctly
F Start the programme
The Start/Stop button will flash when a
programme is being selected. The
flashing indicates that a programme
can be started.
Press the Start/Stop button.
^
The Start/Stop button will now light up
constantly.
The Perfect Dry indicator will flash or
light up constantly with the sensor
controlled drying programmes. It will
not come on at all with timed drying
programmes (see "Operating the
tumble dryer").
Please note: The duration shown in the
display is an estimate and can vary.
Before the end of a programme
There is a cooling down phase at the
end of the drying sequence (Cooling
down will light up). The programme will
not finish until the cooling down phase
has been completed.
There is no cooling down phase at the
end of the Woollens handcare
programme.
G Remove the laundry when the
programme has finished
0 and Finish will appear in the display
to indicate that the programme has
finished. The buzzer (if selected) will
sound at intervals.
The drum will continue to rotate at
intervals for up to two hours to prevent
laundry creasing, if you do not wish to
remove it immediately (anti-crease).
There is no anti-crease phase at the
end of the Woollens handcare
programme.
^ Press the Door button.
^ Open the door.
^ Remove the laundry.
Check that all items have been
removed from the drum. If items are
left in the dryer, they could be
damaged by overdrying when the
dryer is next used.
If the dryer is switched on at the mains
and the door is opened, the drum
lighting will come on. It will go out a few
minutes later to save energy.
^
Press the jk button to switch the
dryer off.
^
Clean the fluff filters.
^
Close the door.
^
Empty the condensed water
container (unless the dryer has been
connected for external drainage).
^
The condenser unit should be
checked and cleaned on a regular
basis (see "Cleaning and care").
19
Extra options / Delay start
Extra options
Low temperature
Delicate and minimum iron fabrics with
the r symbol on the care label (e.g.
acrylic garments) are dried at a lower
temperature. The programme duration
is longer.
On some programmes Low
temperature is permanently activated
and so cannot be deselected.
Buzzer
A buzzer sounds (at intervals for a
maximum of 1 hr) to let you know the
programme has finished.
A continuous alarm will sound if there is
a fault even if the buzzer has been
switched off.
Delay start
You can delay the start of a programme
by 30 minutes up to 24 hours.
^
Select a programme.
^
Press the Delay start button
repeatedly until the required delay
period shows in the display.
–
The Delay start indicator light will
flash.
–
Times of up to 10^ are selected in
steps of half an hour, and more than
10^ in one-hour steps.
–
If you keep the Delay start button
pressed in, the time will continue to
increase up to 24^.
To begin delay start
Press the Start/Stop button.
^
The Delay start indicator will light up
–
constantly.
Delay start times of more than 10^
–
will count down in hours, and of less
than 10^ in minutes to the start of the
programme.
The drum will turn briefly every hour
–
to help prevent creasing.
To cancel / alter delay start
Press the Start/Stop button to cancel
^
delay start.
^ To alter the delay start time, press the
Delay start button repeatedly until the
required delay period shows in the
display.
^ Press the Start/Stop button to start
the altered delay start time counting
down from the beginning again.
To add laundry after the delay start
time has started counting down
While the delay start time is counting
down, you can still add laundry to the
drum:
^
Switch the dryer off.
Opening the door without switching the
dryer off will cancel delay start.
^
Open the door and add the laundry.
^
Close the door and switch the dryer
back on again.
20
Programme chart
Cottons Max. load 7 kg*
Extra dry, Normal**
Use for Single and multi-layered cotton fabrics such as towelling,
T-shirts, underwear, flannelette bed linen.
Notes
Low temperature Select the Low temperature option for delicate fabrics with the
Hand iron, Machine iron
Use for Cottons or linen fabrics, e.g.: table linen, bed linen, starched
Note – To prevent laundry from drying out it should be rolled up
Low temperature Select the Low temperature option for delicate fabrics with the
Minimum iron Max. load 3.5 kg*
Normal, Hand iron
Use for Minimum iron items made of cotton, synthetic or blended
Low temperature Select the Low temperature option for delicate fabrics with the
Delicates Max. load 2.5 kg*
Normal, Hand iron
Use for Delicate items made of synthetic fibres, easy care cotton or
Low temperature Low temperature cannot be deselected.
* Weight of dry laundry
** Note for test institutes:
Test programme (without selecting any Extra options) in accordance with
Regulation 392/2012/EU for energy labelling measured in accordance
with EN 61121.
Select Extra dry for multi-layered and very thick fabrics.
–
Do not use Extra dry for loopknit fabrics (e.g. T-shirts,
–
underwear, baby clothes), as they have a tendency to
shrink.
r symbol on the care label.
laundry.
until you are ready for ironing.
r symbol on the care label.
fabrics, e.g.: dresses, trousers, skirts and table cloths.
r symbol on the care label.
blended fabrics, e.g. shirts, blouses, lingerie and appliquéd
garments.
21
Programme chart
Woollens handcare Max. load 2 kg*
Use for Woollen items.
Notes
Low temperature Low temperature cannot be deselected.
Express Max. load 3.5 kg*
Extra dry, Normal, Hand iron, Machine iron
Use for Fabrics which can tolerate high temperatures with the q
Note The programme duration is shorter.
Automatic plus Max. load 5 kg*
Normal, Hand iron
Use for Mixed loads of garments suitable for the Cottons and
Denim Max. load 3 kg*
Normal, Hand iron
Use for Denim garments, e.g. jeans, jackets, skirts, shirts.
Low temperature Select the Low temperature option for delicate fabrics with
* Weight of dry laundry
This programme only fluffs up woollen garments. They are
–
not dried completely by this programme.
Remove garments as soon as the programme has finished
–
and leave to finish drying at room temperature.
symbol on the care label and which can be dried in the
Cottons programme.
Minimum iron programmes. Sort according to colour.
the r symbol on the care label.
22
Programme chart
Cool air Max. load 7 kg*
Use for Any item which only needs airing.
Warm air Max. load 7 kg*
Use for
Note Do not select the longest drying time to start with. Check the
Tip You can use the Warm air programme to help remove odours
Low temperature Select the Low temperature option for delicate fabrics with
Gentle smoothing Max. load 1 kg*
Use for – Cotton and linen fabric.
Note
Low temperature Low temperature cannot be deselected.
* Weight of dry laundry
Drying voluminous and multi-layered fabrics whose layers
–
have different drying characteristics, e.g. jackets, pillows.
Drying individual items, e.g. bath towels, swimwear,
–
tea-towels.
items as you are drying them to find the optimum time.
from clean cotton clothing (select a duration of between 1/2
and 1 hour). Items must be suitable for drying in a tumble
dryer. Dampen the garments a little beforehand or add a
fabric conditioner sheet. Odours will not be removed as
effectively from any parts of the garments which are made of
synthetic fibres.
the r symbol on the care label.
– Minimum iron mixed fibre, cotton or synthetic fabrics, e.g.
trousers, anoraks, shirts.
–
Suitable for both dry and damp laundry.
–
Smooths out creasing caused during the spin cycle in the
washing machine.
–
Remove garments as soon as the programme has finished
so that they are easy to iron.
23
Changing the programme sequence
Once a programme has started
- changing the programme
You cannot change to another
programme once a programme has
started (this prevents unintentional
alterations).
You will need to cancel the current
programme before you can select a
new one.
- cancelling the programme and then
selecting a different programme
^ Press the Start/Stop button.
The items will be cooled down,
depending on the temperature
reached and how long they have
been dried for.
If you press the Start/Stop button
again during the cooling down
phase, Finish will light up in the
display.
Altering Delay start
See "Delay start".
^
Adding or removing laundry
after a programme has started
Press the Door button.
^
Open the door.
^
Danger of burning:
,
Do not touch the back of the drum
when adding or removing items. The
drum and the items can get very hot.
^ Add or remove items as required.
^ Close the door.
^ Press the Start/Stop button.
Time remaining
The time left shown in the display may
now vary from the actual drying time.
^
Press the Door button.
^
Close the door.
^
Select another programme and start
it.
- cancelling the programme and then
removing the laundry
^
Proceed as described in "Adding or
removing laundry after a programme
has started" below.
^
Switch the dryer off after closing the
door.
24
The system lock prevents the dryer
being used without your knowledge.
It can be activated if wished.
The dryer's electronics are then locked.
The dryer can still be switched on but a
programme cannot be started.
If an attempt is made to start a
–
programme, the indicator light for the
Low temperature button will come on
and a key symbol 0-§ will appear in
the display.
The door is not locked and can be
opened at any time.
To activate the lock
Before you begin, first ensure that
– The tumble dryer is switched off.
– The door is closed.
A Press the Low temperature button
and keep it pressed in whilst carrying
out steps B to E.
B Press the jk button.
The Automatic plus indicator light will
come on.
:
Electronic system lock
D Now slowly turn the programme
selector six positions stage by stage
in an anti-clockwise direction.
Each of the six programme indicator
lights must come on one after the
other.
The indicator light for the Low
temperature button will flash, and the
key symbol 0-§ will appear in the
display.
E Release the Low temperature button.
The electronics have now been locked.
Switch the dryer off.
^
To deactivate the lock
Before you begin, first ensure that
– The tumble dryer is switched off.
– The door is closed.
^ The procedure is the same as for
activating the lock. Carry out steps A
to E as described previously.
At step E the indicator light for the Low
temperature button will stop flashing
and the key symbol 0-§ will go out.
The electronics are no longer locked.
:
C Slowly turn the programme selector
three positions stage by stage in a
clockwise direction.
Each of the three programme
indicator lights must come on one
after the other.
25
Cleaning and care
Emptying the condensed
water container
The condensed water will be collected
in the condensed water container
unless the appliance has been fitted
with a drain hose (see "Installation").
Empty the condensed water
container after every drying
programme.
The Empty out container indicator light
will come on if the maximum level of the
condensed water container is reached.
The indicator light will go out when the
door is opened and closed again.
Close the door fully.
,
Otherwise the door and the front
panel of the condensed water
container could suffer damage when
pulling the container out.
Empty the container.
^
^ Replace the container in the dryer.
Condensed water should not be
,
consumed. It could lead to health
problems for people and animals.
Condensed water can be put to
household use (e.g. in a steam iron or
humidifier). To ensure that any residual
particles of fluff in the condensed water
are removed before use, pass it
through a fine sieve or paper filter first.
^
Pull out the container.
^
Hold it at the front and towards the
back and keep it in a horizontal
position when carrying it.
26
Cleaning and care
Cleaning the fluff filters
The fluff which is created by the drying
process is collected by the fluff filters in
the door and the door opening. Clean
the filters after each drying
programme*.
Cleaning them whilst dry
Tip: You can also use a vacuum
cleaner to remove the fluff.
Use your fingers to remove the fluff
^
from the surface of the filter.
Remove any fluff from the hollow part
^
of the door opening. You could also
use a cleaning brush which is
available as an optional extra from
your Miele dealer or the Miele Spare
Parts Department, or use a vacuum
cleaner.
Also clean the door seal (2) with a
^
damp cloth.
Once clean, push the filter back into
^
the door holder until it clicks into
position. Ensure it is facing the
correct way.
^
Open the door and pull the fluff filter
(1) out of the door as illustrated.
^
Use your fingers or a vacuum cleaner
to remove the fluff from the two fluff
filters in the door opening.
^
Close the door.
* Always check the fluff filters if the
Clean out airways indicator light
comes on.
27
Cleaning and care
Cleaning them with water
If there is a great deal of compacted
fluff on any of the filters, they can be
removed and cleaned under hot
running water.
Open the door and pull the fluff filter
^
out of the door as described
previously.
The two filters in the door opening can
also be removed if you need to clean
them with water.
Do not replace them if they are
,
damp or wet. Damp or wet filters
could cause operational faults.
Push the large filter back into the
^
door holder until it clicks into position.
Ensure it is facing the correct way.
Replace the filters in the door
^
opening by first inserting them at the
bottom and then pressing them into
place at the top.
Lock both dials.
^
^
Turn dial a and pull the filter by the
dial out of the door opening as shown
b. Do the same on the other side.
^
Rinse all the filters under hot, running
water.
^
Then shake the filters until no more
water droplets are visible.
^
Dry the filters thoroughly with care.
^
Clean the area underneath these
filters, e.g. with a vacuum cleaner.
28
Cleaning the tumble dryer
Disconnect the tumble dryer from
the mains electricity supply.
Miele branded cleaning and
conditioning products are available to
order via the internet on
www.miele-shop.com.
Clean the housing and control panel
^
with a slightly damp cloth and a mild
detergent or soapy water.
The drum and other stainless steel
^
parts can be cleaned with a suitable
stainless steel cleaner following the
manufacturer's instructions.
Do not use solvents, abrasive
cleaners, glass cleaners or
all-purpose cleaners. These could
damage plastic sufaces and other
parts.
Cleaning and care
^ Dry all parts with a soft cloth.
29
Cleaning and care
Cleaning the condenser unit
Detergent residue, hair and fine fluff
from the dryer can get through the fluff
filters and block the condenser unit.
Dust from the room in which the dryer is
installed can also get into the
condenser unit and cause a blockage.
Check the condenser unit at least
once a year. Always check it if the
Clean out airways indicator light
comes on. Clean it if necessary.
Removing the condenser unit
^ Open the service panel. Hold the
panel securely when doing this.
^
Now remove the panel by pulling it
diagonally upwards and place it to
one side.
Turn the lever on the inner cover
^
downwards to the vertical position.
^ Tilt the cover forwards.
^ Remove it by pulling it diagonally
upwards.
^
Turn the lever on the condenser unit
upwards to the vertical position so
that the hook on the lever is no longer
in the groove at the bottom of the
condenser unit housing.
30
Pull the condenser unit out of its
^
housing by the handle.
Checking the condenser unit
Cleaning and care
If you cannot see any fluff:
Replace the condenser unit (see
^
following page).
If you can see some fluff:
Clean the condenser unit as
^
described below.
Cleaning the condenser unit
When rinsing the condenser unit,
^
make sure you position it as
shown in the next two illustrations.
^
Hold the condenser unit up to the
light as shown.
^
Check to see if there is any fluff
inside it.
The arrows in the illustration above
indicate where to look.
^
Use a shower head or similar to rinse
the unit out as shown.
31
Cleaning and care
Then flush the unit through from the
^
front.
^ Check the condenser unit again for
any visible fluff and if necessary flush
it through again until it has all gone.
^ Repeat as required.
^ Also make sure the rubber seals are
clean.
The rubber seals must not be
removed and must be free of kinks.
^
Shake the water off the condenser
unit until no more droplets of water
are visible.
Replacing the condenser unit
With the handle facing upwards,
^
push the condenser unit back into
position in its housing.
Turn the lever down to the horizontal
^
position, making sure that the hook
on the lever clicks into the groove.
When replacing the inner cover after
cleaning, ensure that the rubber seal
fits correctly into the groove.
Replace the inner cover making sure
^
the hooks locate correctly. Hold it at
an angle and push it gently
downwards.
^ Then turn the lever upwards into the
horizontal position to lock the cover.
^ Replace the service panel and press
the upper edge until it clicks into
position.
,
It is important to ensure that both
the condenser unit and the cover
are correctly positioned and locked,
otherwise water may leak from the
dryer.
Checking and cleaning the
condenser unit housing
^
Remove any soiling still visible inside
the housing unit by hand using a
damp cloth. Do not try and access
areas you cannot reach by hand!
32
Problem solving guide
With the help of the following notes minor faults in the performance of the
appliance, some of which may result from incorrect operation, can be put right
without contacting the Service Department.
Repair work to electrical appliances should only be carried out by a
,
suitably qualified person in strict accordance with current local and national
safety regulations. Repairs and other work by unqualified persons could be
dangerous. The manufacturer cannot be held liable for unauthorised work.
Check and fault messages
Problem Possible cause Remedy
0-§ appears in
the display.
The Low
temperature
indicator light is
flashing.
The programme
stops and
0 and Finish
appear in the
display.
The buzzer
sounds.
The programme
stops.
The buzzer
sounds.
Cooling down or
Finish may also
flash in the
display.
Bars are
flashing at the
end of the
programme:
—œ–...C~–...Cœ˜...
The electronic system lock is
activated.
This is not a fault.
The electronic unit has
recognised that there is no
laundry or insufficient laundry
in the drum and cancelled the
programme. Drying individual
garments or items which are
already dry can also cause the
programme to be cancelled.
No obvious cause.
The programme has finished
but the laundry is still being
cooled down.
You will need to deactivate
the system lock before the
dryer can be used (see
"Electronic system lock").
Use the Warm air
programme for drying
individual items.
– Open and shut the door.
–
Switch the dryer off and
back on again.
–
Then start the programme
again.
If this problem happens
again, there is a fault.
Contact Miele.
You can either unload the
drum and leave the laundry
to cool at room temperature
or leave it in the dryer to
continue cooling.
33
Problem solving guide
Problem Possible cause Remedy
The Clean out
airways indicator
light comes on.
The programme
stops and
the Clean out
airways indicator
light comes on.
The buzzer
sounds.
The Empty
container indicator
light comes on.
The buzzer
sounds.
The dryer is not working
efficiently or economically.
Possible cause: the filters
are clogged with fluff or with
detergent residues.
See above for possible
causes and their remedies.
The condensed water
container is full or there is
kink in the drain hose.
Cleaning the filters is
–
usually all that is required.
However, if the reminder
does not go out after you
have cleaned the filters,
then also check all the
possible causes
described under "The
drying process goes on
too long or even switches
off".
To switch off this
reminder:
– Open and shut the door
with the dryer switched
on.
The Clean out airways
indicator light can be
deactivated (see
"Programmable functions").
To switch off this warning:
– Open and shut the door
with the dryer switched
on.
–
Then start the programme
again.
–
If this problem happens
again, contact Miele.
–
Empty out the condensed
water container.
–
Check the drain hose.
To switch off this warning:
–
Open and shut the door
with the dryer switched
on.
34
Problem solving guide
Problem Possible cause Remedy
The Start/Stop button is
flashing slowly and the
display is dark.
Sometimes a
programme cannot be
started and the
corresponding
programme indicator
light does not light up.
The Start/Stop button
flashes on and off.
The dryer is in Standby
mode.
This is quite normal and
not indicative of any fault.
No obvious cause.
The flashing indicates
that a programme can be
started.
See "Programmable
functions".
Switch the dryer off
–
and back on again.
Select one of the
–
programmes that
would not start.
If it still will not start,
–
there is a fault. Contact
the Miele Service
Department.
After the programme has
started, the flashing will
change to a constant
light.
35
Problem solving guide
An unsatisfactory drying result
Problem Possible cause Remedy
The laundry is not
sufficiently dry.
Items made of synthetic
fibres are charged with
static electricity after
drying.
There is a build-up of
fluff.
* You can alter the drying levels for some programmes (see "Programmable
functions" at the the end of this booklet).
The load consisted of
different fabrics.
Synthetic fibres tend to
attract static charge.
Fluff is principally the
result of friction when
garments are being worn
and to some extent when
they are being washed.
Machine drying does not
affect the lifetime of the
fabric.
Finish drying using the
–
Warm air programme.
Select a different
–
programme next time *.
Static charge can be
reduced by adding a
fabric conditioner to the
final rinse in the washing
programme or a fabric
conditioner sheet to the
load when drying.
Fluff is collected by the
fluff filters and can be
removed easily (see
"Cleaning and care").
36
Problem solving guide
Other problems
Problem Possible cause Remedy
The drying process
goes on too long or
even switches off.
In some circumstances, the
Clean out airways indicator
light still comes on, even
though the filters are clean.
Ventilation to and from the
dryer may be insufficient,
e.g. because it is installed in
a room which is too small.
This can cause the
temperature in the room to
rise sharply.
The vents below the door are
blocked.
The fluff filters are clogged
up with fluff or were still wet
when they were replaced.
Detergent residues, hair and
fine fibres can block the
condenser unit.
The laundry has not been
spun sufficiently.
The tumble dryer has been
overloaded.
Metallic components, e.g.
zips have prevented the
dryer from registering the
correct moisture level in the
laundry.
Please check all the
possible causes and
switch the dryer off and
then back on again.
Open a door or window
while the dryer is in
operation for increased air
flow.
– Remove any objects
that are blocking the
vents.
– Remove any fluff.
– The fluff filters must be
completely dry.
Check the condenser unit
from time to time and
clean it if necessary.
Make sure that your
laundry is thoroughly spun
at the appropriate spin
speed in the washing
machine.
Do not exceed the
maximum load for the
programme selected.
–
Open zips next time.
If the problem occurs
again, dry garments with
long zips using the Warm
air programme (timed
drying).
37
Problem solving guide
Problem Possible cause Remedy
Water leaks from the
dryer after the
condenser unit has
been cleaned.
The programme does
not start.
Power cut. A programme which was running previously will
The interior drum
lighting does not come
on.
The inner cover of the
–
condenser unit has not
been locked properly
and/or the condenser
unit has not been
positioned correctly.
Fluff has collected in
–
the condenser unit
housing.
No obvious cause.
continue automatically when power is restored to the
tumble dryer as long as the Cooling down phase had
not been reached.
The lighting switches off
automatically (to save
energy).
Ensure that the
–
condenser unit is
positioned correctly
and lock the inner
cover.
Check the rubber
–
seals.
Use a cloth to remove
–
any visible fluff from the
inside of the condenser
unit housing.
Is the dryer switched
–
on?
– Is the plug correctly
inserted into the socket
and switched on?
– Is the door closed
properly?
– Has the fuse or circuit
breaker tripped?
–
Switch the dryer off
and then on again.
–
If the lamp needs to be
replaced, follow the
instructions in
"Changing the lamp".
38
Changing the lamp
Disconnect the tumble dryer from
the mains electricity supply.
Problem solving guide
The light specification and maximum
wattage is stated on the data plate
and on the light cover.
Open the door.
^
You will find the interior light cover at
the top of the drum aperture.
^ Insert a suitable tool, such as a wide
bladed screwdriver, under the side
edge of the light cover as illustrated.
^
Apply a little pressure and whilst
doing so turn your wrist in the
direction of the arrow to open the
cover.
Turn the light anti-clockwise to
^
remove.
Replace the lamp.
^
To close the cover push it upwards
^
and press it on the left and right until
you hear it click into position.
Ensure that it is fitted into
,
position securely, as any moisture
could cause a short circuit.
The cover will open downwards.
The temperature resistant lamp should
only be ordered from your Miele Dealer
or the Miele Spare Parts Department.
39
After Sales service
Repairs
In the event of any faults which you
cannot remedy yourself, please contact
your Miele dealer or
–
the Miele Service Department (see
–
back cover for contact details).
When contacting your dealer or the
Service Department, please quote the
model and serial number of your
appliance, both of which are shown on
the data plate. This is visible when you
open the door.
Future updates (PC)
The indicator or check light marked PC
on the fascia panel is the interface used
by the Miele service technicians during
service work for testing purposes and
for updating the appliance's
programme data.
Appliance guarantee
In the U.K. your appliance is
guaranteed for 2 years from the date of
purchase. However you must activate
your cover by calling 0845 365 6640 or
registering online at www. miele.co.uk.
For information on the appliance
guarantee specific to your country
please contact Miele. See back cover
for contact details.
Optional accessories
Optional accessories for this dryer are
available from your Miele Dealer, the
Miele Spare Parts Department or via the
internet at www.miele-shop.com.
N.B. A call-out charge will be
applied for service visits where the
problem could have been resolved
as described in these instructions.
40
Please note that telephone calls may
be monitored and recorded for
training purposes.
Front view
Installation and connection
a Mains connection cable
b Control panel
c Condensed water container
d Door
e Service panel for condenser unit
f Four height adjustable screw feet
g Air inlet and outlet vent for cooling
the condenser unit
h External drainage options (e.g. via
wash basin, wash basin drain outlet
or gully)
41
Installation and connection
Rear view
a Protruding lid for holding when
moving the machine (see arrows)
b Air inlet vent for cooling the
condenser unit
c Mains connection cable
d External drainage of the condensed
water
e Accessories for connection to a sink
drain outlet
Installation site
The machine lid must not be
,
removed.
The dryer can be pushed under a
worktop with its lid in place, providing
the worktop is high enough.
Make sure the dryer door can be
,
opened without hindrance after
installation.
Transporting the machine to its
installation site
When moving the machine, you can
hold it by the lid where it protrudes to
the rear of the dryer. To manoeuvre the
dryer out of its packing case to its
installation site you will also need to
hold it by the front feet.
Washer-dryer stack
The tumble dryer can also be
combined with a Miele washing
machine in a washer-dryer stack. The
appropriate "WTV" stacking kit
(available to order) to match your dryer
is required.
42
,
Stacking kits must only be
installed by a suitably qualified fitter.
Levelling the machine
The machine must be perfectly level to
ensure safe and proper operation.
Installation and connection
The air inlet and outlet vents on
,
the front and back of the machine
must not be covered as this would
prevent sufficient ventilation for
cooling the condenser unit.
Do not block the gap between
,
the bottom of the tumble dryer and
the floor with plinth facings, deep file
carpet etc. This would hinder a
sufficient flow of air to the dryer.
Room ventilation
The air which is taken in when the dryer
is in operation is blown out of the front
of the dryer and warms up the air in the
room. It is very important to ensure
adequate ventilation, e.g. by opening a
window. Otherwise drying times maybe
longer.
^
The screw feet can be adjusted to
compensate for any unevenness in
the floor.
Before moving the tumble dryer
again (e.g. when moving house)
After each use a small quantity of
condensed water will collect in the area
around the pump. This water can run
out if the dryer is tipped up when it is
being moved. It is a good idea to run
the Warm air programme for
approximately 1 minute before moving
it. Any remaining condensed water will
then be fed into the condensed water
container or out through the drain hose.
43
Installation and connection
External condensed water
outlet
General notes
When drying is in progress, condensed
water is pumped into the condensed
water container through the drain hose at
the back of the dryer. The condensed
water can also be drained off directly if
the tumble dryer is installed near a sink,
drain outlet etc. so that the condensed
water container does not have to be
emptied.
Drain hose length ............1.50 m
Maximum delivery head .......1.50 m
Maximum drain hose length ....4.00 m
If the on-site water drainage
,
system is not fitted with a non-return
valve or an appropriate air gap, one
must be fitted to prevent the risk of
back-flow. (See "Installation conditions
requiring a non-return valve").
There will be a small amount of
^
residual water in the drain hose.
Have a container ready to collect
this.
^ Pull the hose off its connection (see
arrow).
^ Allow any residual water to run into
the container.
^ Unwind the hose and pull it carefully
out of the holders.
The following optional accessories are
available:
–
an extension hose
–
a non-return valve kit for connection
to an external condensed water
outlet (includes an extension hose).
Maximum delivery head with
non-return valve fitted: 1.00 m
Arranging the drain hose
,
Do not pull on the drain hose and
do not stretch it or allow it to become
kinked as it could get damaged.
44
^
Position the hose to the right or left
hand side as necessary.
Leave the hose in the middle holder to
prevent it from becoming kinked
inadvertently.
Installation and connection
External drainage via a sink or gully
See "Front view" illustration.
^
If you want to drain the water off
,
into a sink you will need to secure
the hose carefully, e.g. by tying it to
a tap to make sure it cannot slip
during use. Otherwise there is a risk
of overflowing water which could
cause damage.
Use the bow-shaped guide to
^
prevent the drain hose from
becoming kinked.
Installation conditions requiring a
non-return valve
Certain installation conditions
,
require the fitting of a non-return
valve for external water
connection (available as an
optional accessory). A non-return
valve will prevent the risk of
back-flow out of the dryer which
could cause damage.
Example: Connection to a sink drain
outlet
The drain hose with non-return valve
fitted can be connected directly to a
suitable sink drain outlet.
^ Remove the following from the back
of the dryer at the top:
Adapter 1 and hose clip 3 behind it.
A non-return valve is required:
–
If the tumble dryer is connected to a
sink drain outlet (see the following
section).
–
If the tumble dryer is connected to a
drainage system already in use by
another appliance, e.g. a dishwasher
or washing machine.
45
Installation and connection
1 Adapter
2 Nut
3 Hose clip
4 End of the hose
5 Non-return valve
6 Tumble dryer drain hose
Fit adapter 1 to the sink drain outlet
^
using nut 2.
If this nut has a flat disc in it you
should take the disc out first.
Attach the end of hose 4 to adapter
^
1.
Use a screwdriver to tighten hose
^
clip 3 up close to the nut.
Non-return valve 5 has to be
,
fitted with the arrow pointing in the
direction of flow (i.e. towards the
sink). Otherwise water will not drain
out of the appliance.
^ Fit non-return valve 5 to tumble dryer
drain hose 6 (make sure it is fitted in
the correct direction - see arrow on
non-return valve).
^ Secure the non-return valve using
hose clips.
46
Electrical connection
Electrical connection U.K.
All electrical work should be carried out
by a suitably qualified and competent
person, in strict accordance with
current national and local safety
regulations (BS 7671 in the UK).
Ensure power is not supplied to the
appliance until after installation work
has been carried out.
The appliance is supplied with a mains
cable with moulded plug ready for
connection to a 230-240V mains
supply. Please ensure the connection
data quoted on the data plate match
the household mains supply.
Connection should be made via a
suitable switched socket which is easily
accessible after installation.
For extra safety it is advisable to protect
the appliance with a suitable residual
current device (RCD). Contact a
qualified electrician for advice.
Non-rewireable plugs BS 1363
The fuse cover must be refitted when
changing the fuse, and if the fuse cover
is lost, the plug must not be used until a
suitable replacement is obtained. The
colour of the correct replacement cover
is that of the coloured insert in the base
of the plug, or the colour that is
embossed in words on the base of the
plug (as applicable to the design of
plug fitted).
Replacement fuses should be ASTA
approved to BS 1362 and have the
correct rating. Replacement fuses and
fuse covers may be purchased from
your local electrical supplier.
WARNING: THIS APPLIANCE
MUST BE EARTHED
Do not connect via an extension lead.
Extension leads do not guarantee the
required safety of the appliance (e.g.
danger of overheating).
47
Consumption data
1
Load
Cottons Normal
Cottons Normal 7.0
Cottons Normal
+ Low temperature 7.0 1000 60 4.20 175
Cottons Hand iron 7.0
Minimum iron Normal 3.5 1200 40 1.40 45
Minimum iron Normal
+ Low temperature 3.5 1200 40 1.50 73
Minimum iron Hand iron 3.5 1200 40 1.20 39
Automatic plus Normal 5.0 600 50 2.70 114
Delicates Normal 2.5 700 50 1.55 116
Denim Normal 3.0 900 60 2.40 119
Gentle smoothing 1.0 1000 60 0.75 32
Woollens handcare 2.0 1000 50 0.15 4
1
Weight of dry laundry
2
Test programme in accordance with Regulation 392/2012/EU for energy labelling measured in
accordance with EN 61121.
All data was calculated using EN 61121 unless otherwise stated.
Notes for test institutes:
Before testing in accordance with EN 61121, drya3kgload of cotton laundry with 70% residual
moisture as per the above standard using the Cottons Normal programme without any extra options.
Consumption data can vary from the nominal values given above depending on the size of the
load, types of textiles, residual moisture levels after spinning, fluctuations in the electricity
supply and any extra options selected.
2
kg rpm % kWh min.
7.0
3.5
7.0
7.0
7.0
7.0
7.0
7.0
7.0
Final spin speed
in a domestic
washing machine
1000
1000
1200
1400
1600
1800
1000
1200
1400
1600
1800
Residual
moisture
60
60
53
50
44
43
60
53
50
44
43
Energy Duration
4.14
2.28
3.75
3.55
3.15
3.10
3.10
2.75
2.55
2.20
2.10
109
65
100
95
86
84
89
79
74
65
63
48
Technical data
Height 850 mm
Width 595 mm
Depth 634 mm
Depth with door open 1074 mm
Suitable for pushing under a
worktop
Height
–
Width
–
Suitable for stacking Yes
Weight 52 kg
Drum volume 111 l
Maximum capacity 7 kg dry weight
Capacity of condensed water
container
Drain hose length 1.50 m
Maximum delivery head 1.50 m
Maximum drain hose length 4.00 m
Length of connection cable 2.00 m
Voltage
Connected load
Fuse rating See data plate
Lamp wattage
Test certificates awarded
Energy consumption see "Consumption data"
Yes
850 mm
600 mm
approx. 4.2 l
49
Programmable functions
Altering the residual moisture
level in the Cottons
programme
The tumble dryer is designed to dry
effectively using as little energy as
possible.
However, if you require the laundry to
be drier or damper, you can reduce
or increase the default residual
moisture in the Cottons programme.
Follow the steps (A,B,C ...) to
programme and store in memory.
Before you begin, ensure that:
A number to show which option is
selected will appear in the display
alternating with the letter P.
0 Increased residual moisture.
Laundry damper.
I Standard residual moisture
(factory default setting)
(the Automatic plus indicator light will
also flash once).
2 Reduced residual moisture.
Laundry drier.
(the Automatic plus indicator light will
also flash twice).
– The tumble dryer is switched off.
– The door is closed.
A Press the Start/Stop button and keep
it pressed in whilst carrying out steps
B-C.
B Switch the dryer on.
Wait until the Start/Stop button lights up
constantly ...
C . . . and then release the Start/Stop
button.
–
The Low temperature indicator light
will flash once briefly.
D Pressing the Start/Stop button
switches between the options.
E Switch the dryer off.
The setting you have selected is now
stored in memory. You can change it
again at any time.
To check the setting:
^
Carry out steps A to C.
^
Switch the dryer off after step C.
50
Altering the residual moisture
level in the Minimum iron
programme
The tumble dryer is designed to dry
effectively using as little energy as
possible.
However, if you require the laundry to
be drier or damper, you can reduce
or increase the default residual
moisture in the Minimum iron
programme.
Follow the steps (A,B,C ...) to
programme and store in memory.
Before you begin, ensure that:
– The tumble dryer is switched off.
Programmable functions
A number to show which option is
selected will appear in the display
alternating with the letter P.
0 Increased residual moisture.
Laundry damper.
I Standard residual moisture
(factory default setting)
(the Automatic plus indicator light will
also flash once).
2 Reduced residual moisture.
Laundry drier.
(the Automatic plus indicator light will
also flash twice).
E Pressing the Start/Stop button
switches between the options.
– The door is closed.
A Press the Start/Stop button and keep
it pressed in whilst carrying out steps
B-C.
B Switch the dryer on.
Wait until the Start/Stop button lights up
constantly ...
C . . . and then release the Start/Stop
button.
D Press the Low temperature button
once.
–
The Low temperature indicator light
will flash twice briefly.
F Switch the dryer off.
The setting you have selected is now
stored in memory. You can change it
again at any time.
To check the setting:
^
Carry out steps A to D.
^
Switch the dryer off after step D.
51
Programmable functions
Anti-crease
Anti-crease helps prevent creasing, if
laundry is not normally removed im
mediately after the end of a
programme.
The anti-crease function
is activated when the tumble dryer is
–
delivered. You can shorten the
duration of the anti-crease phase or
deactivate it if wished.
is used in all programmes except
–
Woollens handcare.
– should be left activated.
A number to show which option is
selected will appear in the display
-
alternating with the letter P.
0 Anti-crease off
i 1 hour anti-crease
(the Automatic plus indicator light will
also flash once).
2 2 hours anti-crease
(factory default setting)
(the Automatic plus indicator light will
also flash twice).
E Pressing the Start/Stop button
switches between the options.
Follow the steps (A,B,C ...) to
programme and store in memory.
Before you begin, ensure that:
– The tumble dryer is switched off.
– The door is closed.
A Press the Start/Stop button and keep
it pressed in whilst carrying out steps
B-C.
B Switch the dryer on.
Wait until the Start/Stop button lights up
constantly ...
C . . . and then release the Start/Stop
button.
D Press the Low temperature button
twice.
–
The Low temperature indicator light
will flash 3 times briefly.
F Switch the dryer off.
The setting you have selected is now
stored in memory. You can change it
again at any time.
To check the setting:
^ Carry out steps A to D.
^
Switch the dryer off after step D.
52
Altering the volume of the
buzzer
The buzzer has two volumes.
Programmable functions
A number to show which option is
selected will appear in the display
alternating with the letter P.
Follow the steps (A,B,C ...) to
programme and store in memory.
Before you begin, ensure that:
The tumble dryer is switched off.
–
The door is closed.
–
A Press the Start/Stop button and keep
it pressed in whilst carrying out steps
B-C.
B Switch the dryer on.
Wait until the Start/Stop button lights up
constantly ...
C . . . and then release the Start/Stop
button.
D Press the Low temperature button
three times.
– The Low temperature indicator light
will flash four times briefly.
0 Normal buzzer
(factory default setting)
I Loud buzzer
(the Automatic plus indicator light will
also flash)
E Pressing the Start/Stop button
switches between the options.
F Switch the dryer off.
The setting you have selected is now
stored in memory. You can change it
again at any time.
To check the setting:
^ Carry out steps A to D.
^ Switch the dryer off after step D.
53
Programmable functions
Altering the standard drying
level in the Automatic plus
programme
The tumble dryer is designed to dry
effectively using as little energy as
possible.
However, if you require the laundry to
be drier or damper, you can reduce
or increase the default residual
moisture in the Automatic plus
programme.
Follow the steps (A,B,C ...) to
programme and store in memory.
Before you begin, ensure that:
– The tumble dryer is switched off.
A number to show which option is
selected will appear in the display
alternating with the letter P.
0 Increased residual moisture.
Laundry damper.
I Standard residual moisture
(factory default setting)
(the Automatic plus indicator light will
also flash once).
2 Reduced residual moisture.
Laundry drier.
(the Automatic plus indicator light will
also flash twice).
E Pressing the Start/Stop button
switches between the options.
– The door is closed.
A Press the Start/Stop button and keep
it pressed in whilst carrying out steps
B-C.
B Switch the dryer on.
Wait until the Start/Stop button lights up
constantly ...
C . . . and then release the Start/Stop
button.
D Press the Low temperature button
four times.
–
The Low temperature indicator light
will flash six times briefly.
F Switch the dryer off.
The setting you have selected is now
stored in memory. You can change it
again at any time.
To check the setting:
^
Carry out steps A to D.
^
Switch the dryer off after step D.
54
Extending the cooling down
time
The cooling down phase which takes
place before the end of a programme
can be extended by 5 or 10 minutes,
if required. This makes the garments
easier to handle.
The cooling down time can only be
extended for programmes with drying
levels.
Follow the steps (A,B,C ...) to
programme and store in memory.
Before you begin, ensure that:
– The tumble dryer is switched off.
– The door is closed.
A Press the Start/Stop button and keep
it pressed in whilst carrying out steps
B-C.
B Switch the dryer on.
Wait until the Start/Stop button lights up
constantly ...
C . . . and then release the Start/Stop
button.
Programmable functions
A number to show which option is
selected will appear in the display
alternating with the letter P.
0 Cooling down time not extended
(factory default setting)
i Cooling down time extended by
five minutes
(the Automatic plus indicator light will
also flash once).
2 Cooling down time extended by
ten minutes
(the Automatic plus indicator light will
also flash twice).
E Pressing the Start/Stop button
switches between the options.
F Switch the dryer off.
The setting you have selected is now
stored in memory. You can change it
again at any time.
To check the setting:
^
Carry out steps A to D.
^
Switch the dryer off after step D.
D Press the Low temperature button
five times.
–
The Low temperature indicator light
will flash seven times briefly.
55
Programmable functions
Standby
To save energy, the display and the
programme sequence/check lights
go out after 10 minutes and the
Start/Stop button starts flashing
slowly.
To come out of standby mode
Turn the programme selector or
^
press a button. Neither will have any
effect if a programme is running.
On
The standby function is activated and
the display and programme
sequence/check lights will go out after
10 minutes:
– if a programme is not selected after
the dryer has been switched on.
– after a programme has started.
They will, however, come on for 10
minutes after a delay start time has
counted down, at the end of the
programme or the end of the
anti-crease phase.
The buzzer (if selected ) will sound for
10 minutes at the end of the
programme.
Factory default. Not in current
programme
As described under "On".
However, the display and programme
sequence/check lights will stay on after
the programme has started and remain
visible during the programme.
Off
The display and programme
sequence/check lights will stay on while
the dryer is switched on.
Follow the steps (A,B,C ...) to
programme and store in memory.
^ See next page.
56
Before you begin, ensure that:
The tumble dryer is switched off.
–
The door is closed.
–
Programmable functions
A number to show which option is
selected will appear in the display
alternating with the letter P.
A Press the Start/Stop button and keep
it pressed in whilst carrying out steps
B-C.
B Switch the dryer on.
Wait until the Start/Stop button lights up
constantly ...
C . . . and then release the Start/Stop
button.
D Press the Low temperature button six
times.
– The Low temperature indicator light
will flash 8 times briefly.
0 On
I Factory default setting. Not in
current programme
(the Automatic plus indicator light will
also flash once).
2 Off
(the Automatic plus indicator light will
also flash twice).
E Pressing the Start/Stop button
switches between the options.
F Switch the dryer off.
The setting you have selected is now
stored in memory. You can change it
again at any time.
To check the setting:
^ Carry out steps A to D.
^
Switch the dryer off after step D.
57
Programmable functions
Memory function
The electronics will memorise any
extra options selected for a
programme. The duration selected
for the Warm air or Cool air timed
drying programmes will also be
stored in memory.
These settings will be selected
automatically the next time the
programme is chosen. You can either
accept these or change them by
pressing the appropriate button.
Follow the steps (A,B,C ...) to
programme and store in memory.
Before you begin, ensure that:
– The tumble dryer is switched off.
– The door is closed.
A Press the Start/Stop button and keep
it pressed in whilst carrying out steps
B-C.
A number to show which option is
selected will appear in the display
alternating with the letter P.
0 Memory deactivated
(factory default setting)
I Memory activated
(the Automatic plus indicator light will
also flash)
E Pressing the Start/Stop button
switches between the options.
F Switch the dryer off.
The setting you have selected is now
stored in memory. You can change it
again at any time.
To check the setting:
^ Carry out steps A to D.
^ Switch the dryer off after step D.
B Switch the dryer on.
Wait until the Start/Stop button lights up
constantly ...
C . . . and then release the Start/Stop
button.
D Press the Low temperature button
seven times.
–
The Low temperature indicator light
will flash 9 times briefly.
58
Clean out airways indicator
Fluff should be removed after drying.
The Clean out airways indicator will
remind you to clean the filters when a
certain amount of fluff has collected
in the filters. You can decide at what
level of fluff this reminder should be
given.
You will have an idea of how often this
should be done after a few drying
programmes.
Follow the steps (A,B,C ...) to
programme and store in memory.
Before you begin, ensure that:
– The tumble dryer is switched off.
– The door is closed.
A Press the Start/Stop button and keep
it pressed in whilst carrying out steps
B-C.
B Switch the dryer on.
Wait until the Start/Stop button lights up
constantly ...
C . . . and then release the Start/Stop
button.
D Press the Low temperature button
eight times.
–
The Low temperature indicator light
will flash on and off slowly once.
Programmable functions
A number to show which option is
selected will appear in the display
alternating with the letter P.
0 Clean out airways indicator light
deactivated
I Clean out airways indicator light
comes on when there is a heavy
build-up of fluff
(the Automatic plus indicator light will
also flash once).
2 Factory default setting
(the Automatic plus indicator light will
also flash twice).
3 Clean out airways indicator light
comes on when there is only a
light build-up of fluff
(the Automatic plus indicator light will
also flash three times).
E Pressing the Start/Stop button
switches between the options.
F Switch the dryer off.
The setting you have selected is now
stored in memory. You can change it
again at any time.
To check the setting:
^
Carry out steps A to D.
^
Switch the dryer off after step D.
59
Programmable functions
Keypad tone
An audible tone sounds each time a
button is pressed.
A number to show which option is
selected will appear in the display
alternating with the letter P.
Follow the steps (A,B,C ...) to
programme and store in memory.
Before you begin, ensure that:
The tumble dryer is switched off.
–
The door is closed.
–
A Press the Start/Stop button and keep
it pressed in whilst carrying out steps
B-C.
B Switch the dryer on.
Wait until the Start/Stop button lights up
constantly ...
C . . . and then release the Start/Stop
button.
D Press the Low temperature button
nine times.
– The Low temperature indicator light
will flash on and off slowly once and
then on and off quickly once.
0 Keypad tone deactivated
(factory default setting)
I Keypad tone activated
(the Automatic plus indicator light will
also flash)
E Pressing the Start/Stop button
switches between the options.
F Switch the dryer off.
The setting you have selected is now
stored in memory. You can change it
again at any time.
To check the setting:
^ Carry out steps A to D.
^ Switch the dryer off after step D.
60
Programmable functions
Adjusting the dryer's
electronics for very soft water
In some areas of the UK, water is
,
extremely soft which can affect the
sensitivity of the control electronics.
If the dryer is installed in an area of
very soft water, you should contact
your local water supplier for
information and advice regarding
water hardness and water
conductivity. If the water
conductivity is less than 150 µS, the
following programmable function will
need to be activated.
Important. This programmable function
should not be activated if, despite the
water being extremely soft (as would be
the case if a water softener were used),
its conductivity is greater than 150 µS.
Follow the steps (A,B,C ...) to
programme and store in memory.
Before you begin, ensure that:
–
The tumble dryer is switched off.
–
The door is closed.
The Low temperature indicator light
–
will flash on and off slowly once and
then on and off quickly twice.
A number to show which option is
selected will appear in the display
alternating with the letter P.
0 Factory default setting
I Adjusted for very soft water
(the Automatic plus indicator light will
also flash)
E Pressing the Start/Stop button
switches between the options.
F Switch the dryer off.
The setting you have selected is now
stored in memory. You can change it
again at any time.
To check the setting:
^ Carry out steps A to D.
^ Switch the dryer off after step D.
A Press the Start/Stop button and keep
it pressed in whilst carrying out steps
B-C.
B Switch the dryer on.
Wait until the Start/Stop button lights up
constantly ...
C . . . and then release the Start/Stop
button.
D Press the Low temperature button
ten times.
61
Programmable functions
Extending the range of the
drying levels
You can extend the range of the
drying levels for many of the
programmes:
Machine iron+
(drier than Machine iron).
Slightly dry
(drier than Hand iron).
Normal+
(drier than Normal).
This programmable function is only
available for programmes with drying
levels.
Follow the steps (A,B,C ...) to
programme and store in memory.
Before you begin, ensure that:
– The tumble dryer is switched off.
– The door is closed.
A Press the Start/Stop button and keep
it pressed in whilst carrying out steps
B-C.
B Switch the dryer on.
Wait until the Start/Stop button lights up
constantly ...
C . . . and then release the Start/Stop
button.
D Press the Low temperature button
eleven times.
–
The Low temperature indicator light
will flash on and off slowly once and
then on and off quickly three times.
A number to show which option is
selected will appear in the display
alternating with the letter P.
0 Factory default setting
I Drying level range extended
(the Automatic plus indicator light will
also flash).
E Pressing the Start/Stop button
switches between the options.
F Switch the dryer off.
The setting you have selected is now
stored in memory. You can change it
again at any time.
To check the setting:
^ Carry out steps A to D.
^ Switch the dryer off after step D.
To select the extended drying level
^ Select a programme.
^
Press the drying level button
repeatedly until one or two indicator
lights come on.
–
Indicator lights Extra dry and Normal
= Normal+
–
Indicator lights Normal and Hand
iron = Slightly dry
–
Indicator lights Hand iron and
Machine iron = Machine iron+
62
63
Alteration rights reserved/0113
M.-Nr. 07 851 060 / 05
