Operating and installation instructions
Ceramic hobs
To avoid the risk of accidents or damage to the appliance it is essential
to read these instructions before it is installed and used for the first time.
M.-Nr. 09 710 060en-GB
Contents
Warning and Safety instructions .....................................3
Caring for the environment.........................................11
Guide to the appliance ............................................12
Hob ............................................................12
Cooking zones ....................................................12
Before using for the first time.......................................13
Cleaning for the first time............................................13
Heating up for the first time ..........................................13
How the cooking zones work .......................................14
Operation .......................................................15
Switching on and off ...............................................15
Residual heat indicator .............................................15
Settings .........................................................16
Pans ...........................................................17
Tips on saving energy ............................................18
Overheating protection ............................................19
Cleaning and care ................................................20
Problem solving guide ............................................22
Optional accessories..............................................23
Safety instructions for installation...................................24
Building-in dimensions ...........................................28
Preparing the worktop.............................................29
Installing the hob .................................................31
Protective shelf ..................................................33
Connecting up to the cooker unit....................................34
Electrical connection..............................................35
After sales service, data plate ......................................37
2
Warning and Safety instructions
This appliance complies with all relevant safety requirements.
Inappropriate use can, however, lead to personal injury and
damage to property.
To avoid the risk of accidents and damage to the appliance,
please read these instructions carefully before installation and
before using it for the first time. They contain important notes on
installation, safety, use and maintenance. Miele cannot be held
liable for damage caused by non-compliance with these Warning
and Safety instructions.
Keep these instructions in a safe place and ensure that new users
are familiar with the content. Pass them on to any future owner.
3
Warning and Safety instructions
Correct application
This hob is not designed for commercial use. It is intended for
~
use in domestic households and similar working and residential
environments.
The appliance is not intended for outdoor use.
~
It is intended for domestic use only to cook food and keep it
~
warm. Any other use is not supported by the manufacturer and
could be dangerous.
The appliance can only be used by people with reduced
~
physical, sensory or mental capabilities, or lack of experience and
knowledge, if they are supervised whilst using it, or have been
shown how to use it in a safe way and understand the hazards
involved.
4
Warning and Safety instructions
Safety with children
Children under 8 years of age must be kept away from the
~
appliance unless they are constantly supervised.
Children 8 years and older may only use the appliance if they
~
have been shown how to use it in a safe way and understand the
hazards involved.
Children must not be allowed to clean the appliance
~
unsupervised.
This appliance is not a toy! To prevent the risk of injury, do not
~
allow children to play with the appliance or its controls.
The appliance gets hot when in use and remains hot for a while
~
after being switched off. Keep children well away from the appliance
until it has cooled down and there is no danger of burning.
Danger of suffocation. Packaging, e.g. cling film, polystyrene and
~
plastic wrappings, must be kept out of the reach of babies and
children. Whilst playing, children could become entangled in
packaging, or pull it over their head and suffocate.
Danger of burning.
~
Do not store anything which might arouse a child's interest in
storage areas above or behind the appliance. Otherwise they could
be tempted into climbing onto the appliance
Danger of burning or scalding.
~
Place pots and pans on the cooking zones in such a way that
children cannot pull them down and burn themselves.
Activate the system lock to ensure that children cannot switch on
~
the appliance inadvertently. Activate the safety lock when the hob is
in use to prevent children from altering the settings selected.
5
Warning and Safety instructions
Technical safety
Installation, maintenance and repairs may only be carried out by
~
a Miele-authorised person. Installation, maintenance and repairs by
unqualified persons could be dangerous.
A damaged appliance can be dangerous. Check the appliance
~
for visible signs of damage. Do not use a damaged appliance.
The electrical safety of this appliance can only be guaranteed if
~
correctly earthed. It is most important that this basic safety
requirement is observed and regularly tested, and where there is
any doubt, the household wiring system should be inspected by a
qualified electrician.
To avoid the risk of damage to the appliance, make sure that the
~
connection data (frequency and voltage) on the data plate
corresponds to the household supply, before connecting the
appliance to the mains supply.
Consult a qualified electrician if in any doubt.
Do not connect the appliance to the mains electricity supply by a
~
multi-socket adapter or an extension lead. These are a fire hazard
and do not guarantee the required safety of the appliance.
For safety reasons, this appliance may only be used after it has
~
been built in.
This appliance must not be used in a non-stationary location (e.g.
~
on a ship).
Do not open the casing of the appliance.
~
Tampering with electrical connections or components and
mechanical parts is highly dangerous to the user and can cause
operational faults.
6
Warning and Safety instructions
While the appliance is under guarantee, repairs should only be
~
undertaken by a service technician authorised by Miele. Otherwise
the guarantee is invalidated.
The manufacturer can only guarantee the safety of the appliance
~
when original Miele replacement parts are used. Faulty components
must only be replaced by genuine Miele original spare parts.
The hob is not intended for use with an external timer switch or a
~
remote control system.
The appliance must be disconnected from the mains electricity
~
supply during installation, maintenance and repair work. Ensure that
power is not supplied to the appliance until after it has been
installed or until any maintenance or repair work has been carried
out.
The hob may only be combined with cookers with integrated hob
~
controls as specified by Miele for use with that hob.
The manufacturer cannot guarantee trouble-free operation if the
appliance is operated in combination with appliances other than
those quoted by the manufacturer as being suitable.
Danger of electric shock.
~
Do not use the hob if it is faulty, or if the ceramic surface is cracked,
chipped or damaged in any way. Switch it off immediately, and
disconnect it from the mains electricity supply.
In areas which may be subject to infestation by cockroaches or
~
other vermin, pay particular attention to keeping the appliance and
its surroundings clean at all times. Any damage caused by
cockroaches or other vermin will not be covered by the guarantee.
7
Warning and Safety instructions
Correct use
Oil and fat can overheat and catch fire. Do not leave the
~
appliance unattended when cooking with oil or fat.
If oil or fat does catch fire, do not attempt to put out the flames with
water. Disconnect the appliance from the mains and use a suitable
fire blanket, saucepan lid, damp towel or similar to smother the
flames.
Flames could set the grease filters of a cooker hood on fire. Do
~
not flambé under a cooker hood.
Spray canisters, aerosols and other inflammable substances can
~
ignite when heated. Therefore do not store such items or
substances in a drawer under the hob. Cutlery inserts must be
heat-resistant.
Do not heat an empty pan.
~
Do not heat up unopened tins of food on the hob, as pressure will
~
build up in the tin, causing it to explode.
Do not cover the hob, e.g. with a hob cover, a cloth or protective
~
foil. The material could catch fire, shatter or melt if the appliance is
switched on by mistake or if residual heat is still present.
When using an electrical appliance, e.g. a hand-held food
~
blender, near the appliance, ensure that the cable of the electrical
appliance cannot come into contact with the hot appliance. The
insulation on the cable could become damaged.
Plastic and aluminium foil containers melt at high temperatures.
~
Do not use plastic or aluminium foil containers on the hob.
If the appliance is installed behind a kitchen furniture door, it may
~
only be used with the furniture door open. Do not close the door
whilst the hob in use or whilst there is any residual heat present.
8
Warning and Safety instructions
The appliance gets hot when in use and remains hot for a while
~
after being switched off. There is a danger of burning until the
residual heat indicators go out.
You could burn yourself on the hot hob. Protect your hands with
~
heat-resistant pot holders or gloves when handling hot pots and
pans. Do not let them get wet or damp, as this causes heat to
transfer through the material more quickly with the risk of scalding or
burning yourself.
When the appliance is switched on either deliberately or by
~
mistake, or when there is residual heat present, there is the risk of
any metal items left on the hob heating up, with the danger of
burning.
Depending on the material, other items left on the hob could also
melt or catch fire.
Damp pan lids might adhere to the ceramic surface and be difficult
to dislodge.
Do not use the appliance as a resting place.
Switch the cooking zones off after use.
Do not allow solid or liquid sugar, or pieces of plastic or
~
aluminium foil to get onto the cooking zones when they are hot, as
they can damage the ceramic surface when it cools down. If this
should occur, switch off the appliance and scrape off all the sugar,
plastic or aluminium residues from the hob whilst still hot, using a
shielded scraper blade. Wear oven gloves.
Allow the cooking zones to cool down and then clean them with a
suitable ceramic hob cleaning agent.
Pans which boil dry can cause damage to the ceramic glass. Do
~
not leave the appliance unattended whilst it is being used.
Do not use pots or pans on the hob with bases with pronounced
~
edges or ridges. These could scratch or scour the ceramic glass
surface permanently. Only use pots and pans with smooth bases.
9
Warning and Safety instructions
Grains of salt, sugar and sand (e.g. from cleaning vegetables)
~
can cause scratches if they get under pan bases. Make sure that
the ceramic surface is clean before placing pans on it.
Even a light object could cause damage in certain
~
circumstances. Do not drop anything on the ceramic surface.
Placing hot objects on the sensors and displays could damage
~
the electronics underneath them. Do not place hot pans on the
sensors and displays.
Due to the high temperatures radiated, objects left near the
~
appliance when it is in use could catch fire. Do not use the
appliance to heat up the room.
The frame of the hob can become hot due to the influence of the
~
following factors: operating duration, high power level(s), large pans
and the number of cooking zones being used.
Aluminium pans or pans with an aluminium base can cause
~
metallic, shiny marks to appear on the ceramic surface. These
marks can be removed using a ceramic and stainless steel hob
cleaner (see "Cleaning and care").
To prevent the risk of spillages etc. burning on, remove any
~
soiling as quickly as possible and ensure that pan bases are clean,
dry and free of grease.
Cleaning and care
Do not use a steam cleaning appliance to clean this appliance.
~
The steam could reach electrical components and cause a short
circuit.
10
Caring for the environment
Disposal of the packing
material
The transport and protective packing
has been selected from materials
which are environmentally friendly for
disposal and should be recycled.
Recycling the packaging reduces the
use of raw materials in the
manufacturing process and also
reduces the amount of waste in landfill
sites. Ensure that any plastic
wrappings, bags, etc are disposed of
safely and kept out of the reach of
babies and young children. Danger of
suffocation.
Disposing of your old
appliance
Electrical and electronic appliances
often contain materials which, if
handled or disposed of incorrectly,
could be potentially hazardous to
human health and to the environment.
They are, however, essential for the
correct functioning of your appliance.
Please do not dispose of it with
household waste.
Please dispose of it at your local
community waste collection / recycling
centre or contact your dealer for
advice.
Ensure that it presents no danger to
children while being stored for
disposal.
11
Guide to the appliance
Hob
a Double circle zone
bcd Single circle zones
e Residual heat indicators
Cooking zones
Cooking zone C in cm Rating in watts for 230 V
t 12.0 / 21.0 750 / 2200
12
q 14.5 1200
r 18.0 1800
s 14.5 1200
Total: 6400
Before using for the first time
Please stick the extra data plate for the
appliance supplied with this
documentation in the space provided in
the "After sales service, data plate,
guarantee" section of this booklet.
Cleaning for the first time
Remove any protective wrapping and
^
adhesive labels.
Before using for the first time, clean
^
the appliance with a damp cloth only
and then wipe dry
Heating up for the first time
The metal components have a
protective coating which may give off a
slight smell when heated up for the first
time. The smell and any vapours do not
indicate a faulty connection or
appliance, and they are not harmful to
health.
13
How the cooking zones work
Single circle cooking zones have one
heating element, whilst double circle
(vario) cooking zones and extended
zones have two. Depending on the mo
del, the heating elements may be
separated by an insulating ring.
Each cooking zone has overheating
protection (a temperature limiter), which
stops the ceramic surface from
becoming too hot (see "Overheating
protection").
When a power level is selected, the
heat switches on and the element can
be seen through the ceramic surface.
The temperature of the cooking zones
depends on the power level selected,
and is electronically regulated. This
controls the "timing" of a cooking zone,
switching the element on and off.
Single circle zone
-
a Overheating protection
b Heating element
Double circle zone
14
a Technically necessary, not defective
b Overheating protection
c Outer heating element
d Insulating ring
e Inner heat element
Operation
Switching on and off
The cookers units have two different
types of control dials for the cooking
zones:
Control with stop
–
Turn the control clockwise to the
^
power level required to switch it on.
Turn the control anti-clockwise to "0"
^
to switch it off.
Control without stop - can be
–
rotated 360°
Turn the control either clockwise or
^
anti-clockwise to switch the
applicable cooking zone on and off.
Do not leave the appliance
unattended whilst it is being used.
Switching the outer circle of a double
circle zone on and off
The outer circle of the double circle
zone can be switched on if a very large
pan or fish kettle is being used.
On
Residual heat indicator
When a cooking zone is switched on,
e.g. front left, the appropriate residual
heat indicator lights up when the zone
has reached a certain temperature.
The residual heat indicator will switch
off after the cooking zone has been
switched off once the temperature has
dropped to a safe level.
Do not touch the cooking zones
whilst the residual heat indicators
are still lit.
Fire hazard and danger of burning.
Do not place hot pans on or near the
residual heat indicators or on the
display. The electronic unit
underneath could get damaged.
^
Turn the cooking zone control
clockwise past "12" as far as it will
go.
^
Then turn the control anti-clockwise
back to the required setting.
Off
^
Turn the control back to the "0"
position.
When the same cooking zone is
switched on again, only the inner zone
will switch on.
15
Operation
Settings
Cooking process Settings
Melting butter, chocolate etc.
Dissolving gelatine
Preparing yoghurt
Thickening sauces containing egg yolk and butter
Warming small quantities of food/liquid
Keeping warm food which sticks easily
Cooking rice
Warming liquid and semi-solid foods
Thickening sauces, e.g. hollandaise
Making porridge
Preparing omelettes, lightly fried eggs
Steaming fruit
Defrosting deep frozen food
Steaming vegetables, fish
Cooking dumplings, potatoes, pulses
Cooking broths, pulse soups
Bringing to the boil and continued cooking of large
quantities of food
Gentle braising (without overheating the fat) of meat, fish,
vegetables, fried eggs etc.
Frying pancakes etc. 9 - 11
1-2
1-3
3-5
4-6
7
8-9
Boiling large quantities of water
Bringing to the boil
These settings, which envisage approx. 4 servings, should only be taken as a
guide. With deep pans, large quantities or when cooking without the lid, a higher
setting is required. For smaller quantities, select a lower setting.
16
11-12
The best pans are those with a thick
–
base which is very slightly concave
when cold. When heated, the base
flattens to rest evenly on the hob,
optimising the conduction of the
heat.
Cold Hot
Pans made of glass, ceramic or
–
stoneware are less suitable, as they
do not conduct the heat so well.
Pans
Lift pans into position on the hob.
–
Sliding them into place can cause
scuffs and scratches.
Check that the diameter of the pan
–
base is wide enough for the cooking
zone so that heat is not lost
unnecessarily. Please note that the
maximum diameter quoted by
manufacturers often refers to the
diameter of the top rim of the pot or
pan. The diameter of the base
(generally smaller) is more important.
– Aluminium pans or pans with an
aluminium base can cause metallic,
shiny marks to appear on the
ceramic surface. These marks can
be removed using a ceramic and
stainless steel hob cleaner (see
"Cleaning and care").
–
Do not use pots and pans on the
ceramic hob with bases with
pronounced edges or or ridges, e.g.
cast iron pans. These could scratch
or scour the hob surface
permanently. Only use pots and
pans with smooth bases.
Too small Suitable
17
Tips on saving energy
Use a pan lid whenever possible to
–
minimise heat loss.
Uncovered Covered
Select a smaller pan when cooking
–
small quantities. A small pan on a
small cooking zone uses less energy
than a large, partially filled pan on a
large cooking zone.
Use as little water as possible to
–
cook with, and reduce the power
setting once the water has come to
the boil or the oil is hot enough to fry
in.
When cooking for a long time, switch
–
the cooking zone off about 5 to
10 minutes before the end of the
cooking time. In this way, use is
made of the residual heat.
Cooking times are greatly reduced
–
when using a pressure cooker.
18
Overheating protection
Each cooking zone has a safety
switch-off feature (internal temperature
limiter). This automatically switches off
the heating elements in the cooking
zone before it overheats. Once the
cooking zone has cooled down to a
safe level the heating will automatically
switch back on again.
Overheating can be caused by:
a cooking zone being switched on
–
without a pan on it
Heating up an empty pan
–
the base of a pan not sitting evenly
–
on the cooking zone
the pan not conducting heat
–
properly.
On ceramic hobs you can tell that the
overheating protection has activated
because the heating switches on and
off even when the highest setting is
selected
19
Cleaning and care
For Miele branded cleaning and
conditioning products see "Optional
accessories".
Do not use a steam cleaning
,
appliance to clean this appliance.
The steam could reach electrical
components and cause a short
circuit.
The appliance should be cleaned after
each use. Let it cool down to room
temperature before cleaning.
To avoid water marks and limescale
deposits, use a soft cloth to dry
surfaces that have been cleaned with
water.
To avoid damaging the surface of
your appliance, do not use:
washing-up liquid,
–
cleaning agents containing soda,
–
alkalines, ammonia, acids or
chlorides,
cleaning agents containing
–
descaling agents,
stain or rust removers,
–
abrasive cleaning agents, e.g.
–
powder cleaners and cream
cleaners,
– solvent-based cleaning agents,
– dishwasher cleaner,
– grill and oven cleaners,
– glass cleaning agents,
– hard, abrasive brushes or sponges,
e.g. pot scourers, brushes or
sponges which have been previously
used with abrasive cleaning agents,
20
–
melamine eraser blocks,
–
sharp, pointed objects which could
damage the seal between the
ceramic surface and the surrounding
frame, and between the frame and
the worktop.
Do not use washing-up liquid to
clean the ceramic surface.
Washing-up liquid will not remove all
soiling and deposits. It will form an
invisible coating which will cause
permanent discolouration of the
ceramic surface.
Clean the hob regularly with a
suitable ceramic hob cleaner.
Wipe all coarse soiling off using a
damp cloth. Stubborn soiling may need
to be removed with a shielded scraper
blade.
Then clean the hob with Miele ceramic
and stainless steel hob cleaner (see
"Optional accessories") applied with
kitchen paper or a clean cloth. Do not
apply cleaner whilst the hob is still hot,
as this could result in marking. Please
follow the manufacturer's instructions.
Cleaning and care
Should any sugar, plastic or
aluminium foil spill or fall onto a hot
cooking zone while it is in use, first
switch off the appliance. Then carefully
scrape off all the sugar, plastic or
aluminium residues from the hob whilst
they are still hot, using a shielded
scraper blade. Take care not to burn
yourself.
Allow the appliance to cool down, and
then clean as described above.
Finally, wipe the hob with a damp cloth,
then polish with a soft, dry cloth. Ensure
that all cleaner residues are removed.
Residues can burn onto the hob the
next time it is used, and cause damage
to the ceramic surface.
Spots caused by limescale, water and
aluminium residues (spots with a
metallic appearance) can be removed
using Miele's ceramic and stainless
steel hob cleaner.
21
Problem solving guide
With the help of the following notes, minor faults in the performance of the
appliance, some of which may result from incorrect operation can be put right
without contacting the Service Department.
Installation work and repairs to electrical appliances must only be carried
,
out by a suitably qualified and competent person in strict accordance with
current local and national safety regulations. Do not attempt to open the
casing of the appliance. Repairs and other work by unqualified persons could
be dangerous and Miele cannot be held liable for unauthorised work.
Problem Cause and solution
After switching on,
the appliance does
not heat up.
The heating element
for one of the
cooking zones
switches on and off.
The mains fuse has tripped.
^ If the fuse has blown, contact a qualified electrician or
the Miele Service department.
This is quite normal, and due to the electronic regulation of
the temperature (see "How the cooking zones work").
If the heating element switches on and off when the highest
setting has been selected, this indicates that the
overheating protection mechanism has triggered (see
"Overheating protection").
22
Miele offer a comprehensive range of useful accessories as
well as cleaning and conditioning products for your
appliance.
These products can be ordered online:
or from Miele (see back cover for contact details)
Ceramic and stainless steel hob cleaner
250 ml
Removes heavy soiling, limescale deposits and aluminium
residues.
Optional accessories
E-cloth (microfibre cloth)
Removes finger marks and light soiling.
23
Safety instructions for installation
After installing the hob, you need to
To avoid the risk of damage fit the
wall units and extractor hood before
fitting the hob.
The veneer or laminate coatings of
~
worktops (or adjacent kitchen units)
must be treated with 100 °C
heat-resistant adhesive which will not
dissolve or distort.
Any backmoulds must be of
heat-resistant material.
This hob may only be installed in
~
mobile installations such as ships,
caravans, aircraft etc. if a risk
assessment of the installation has been
carried out by a suitably qualified
engineer.
The hob may not be built in over a
~
fridge, fridge freezer, freezer,
dishwasher, washing machine or
tumble dryer.
~
make sure that the underside of the
appliance cannot be accessed or
touched. In some cases a front panel
and a protective shelf must be fitted
(see "Protective shelf").
Observe carefully the safety
~
distances given on the following pages.
Do not use any sealant except
~
where expressly instructed to do so.
The seal underneath the appliance
provides a sufficient seal for the
worktop.
All dimensions in this instruction booklet
are given in mm.
Make sure that the cable for the hob
~
cannot be damaged by any mechanical
obstruction.
These hobs may only be combined
~
with certain cookers and control units
from the manufacturer's range.
The manufacturer cannot guarantee
trouble-free operation if the appliance is
operated in combination with
appliances other than those quoted by
the manufacturer as being suitable.
24
Safety instructions for installation
Safety distance above the appliance
A minimum safety distance must be
maintained between the appliance and
the cooker hood above it. See the
cooker hood manufacturer's operating
and installation instructions for details.
If the manufacturer's instructions are
not available for the cooker hood, a
minimum safety distance of at least
760 mm must be maintained. For any
flammable objects, e.g. utensil rails,
wall units etc. a minimum distance of at
least 760 mm must be maintained
between them and the appliance
below.
When two or more appliances which
have different safety distances are
installed together below a cooker
hood, you should observe the
greater safety distance of the two.
25
Safety instructions for installation
Safety distances to the sides and
back of the hob
Ideally the hob should be installed with
plenty of space on either side. There
may be a wall at the rear or a tall unit or
wall on one side (right or left) (see
illustrations).
a Minimum distance of 50 mm
between the back of the worktop
cut-out and the rear edge of the
worktop.
b Minimum distance of 50 mm
between the worktop cutout and a
wall or tall unit to the right of it.
c Minimum distance of 50 mm
between the worktop cutout and a
wall or tall unit to the left of it.
Not allowed
Recommended
Not recommended
26
Not recommended
Safety instructions for installation
Safety distance when installing the appliance near a wall with additional
niche cladding
A minimum safety distance must be maintained between the worktop cut-out and
any niche cladding to protect it from heat damage.
If the niche cladding is made from a combustible material (e. g. wood) a
minimum safety distance e of 50 mm must be maintained between the cut-out
and the cladding.
If the niche cladding is made from a non-combustible material (e. g. metal,
natural stone, ceramic tiles) a minimum safety distance e of 50 mm less the
thickness of the cladding must be maintained between the cut-out and the
cladding.
Example: 15 mm niche cladding
50 mm - 15 mm = minimum safety distance of 35 mm
Flush-fitted hobs Hob with frame or bevelled edges
a Masonry
b Niche cladding
Dimension x = thickness of niche cladding material
c Worktop
d Worktop cut-out
e Minimum safety distance
for combustible materials is 50 mm
for non-combustible materials is 50 mm less dimension x
27
Building-in dimensions
574
504
b
10
38
3
d
a
0
50
+
490
1
-
a Spring clamps
b Casing depth
c Front
d Space for fixings and electrical cable
560
a
ß
R4
1
+
-
75
0 20
c
75
28
Preparing the worktop
Make the worktop cut-out according
^
to the dimensions given in the
building-in diagram. Remember to
maintain the minimum safety
distances (see "Safety instructions
for installation").
Worktops made of wood
Seal the cut surfaces with a suitable
^
heat-resistant sealant to avoid
swelling caused by moisture.
The materials used must be
heat-resistant.
Make sure that the sealant does not
come into contact with the top of the
worktop.
^
Place the spring clamps (supplied)
a on the upper edge of the cut-out.
Please refer to the relevant
building-in dimensions diagram for
the hob for the exact positioning of
the spring clamps.
^
Secure the spring clamps with the
3.5 x 25 mm screws supplied.
29
Preparing the worktop
Granite and marble worktops
You will require double-sided tape
and silicone (not supplied).
^ Position the spring clamps a, and fix
in place using heavy-duty
double-sided tape f.
Apply silicone g to the side edges
^
and the lower edges of the spring
clamps.
30
Feed the hob connection cable down
^
through the cut-out.
Connect the hob to the cooker (see
^
section "Connecting up to the
cooker).
Position the hob on the spring
^
clamps.
Using both hands, press down
^
evenly on the sides of the hob until it
clicks into position. When doing this,
make sure that the seal under the
hob sits flush with the worktop on all
sides. This is important to ensure an
effective seal all round.
Do not use sealant (e.g. silicone).
If the seal does not meet the worktop
correctly on the corners, the corner
radius (ß R4) can be carefully
scribed to suit.
Installing the hob
^ Check that the hob works.
The hob can now only be removed
with a special tool.
31
Installing the hob
Seal between the hob and the
worktop
The sealing strip under the edge of the
top part of the appliance provides a
sufficient seal for the worktop.
The appliance must not be sealed
with sealant (e.g. silicone).
This could result in damage to the
appliance or the worktop if it ever
needs to be removed for servicing.
Tiled worktop
Grout lines a and the hatched area
underneath the hob frame must be
smooth and even. If they are not, the
hob will not sit flush with the worktop
and the sealing strip underneath the
hob will not provide a good seal
between the hob and the worktop.
32
After installing the hob, you need to
make sure that the underside of the
appliance cannot be accessed or
touched.
A fascia panel and a protective shelf
must be fitted if:
– the appliance is wider than the
oven/cooker/control unit.
– the appliance and the built-under
oven/cooker/control unit are offset
from one another.
Protective shelf
A minimum distance of 55 mm is
required between the upper surface of
the worktop and the protective shelf.
A gap of 10 mm must be maintained
between the shelf and the rear wall.
33
Connecting up to the cooker unit
The cable for the appliance has plug
connectors at the end of it which must
be connected up to the cooker/control
unit.
The earth cable must also be fed into
the plug connector.
The cooker/control unit is fitted with
connector sockets. The plug
connectors and the connector sockets
are constructed in such a way that they
cannot be connected the wrong way
round. Do not attempt to force the
plugs into the wrong sockets.
The EMV earth cable - located
underneath the hob (not on every mo
del) must be fixed to the cooker/control
unit as illustrated.
-
34
Electrical connection
Please read these instructions in
conjunction with those of the cooker
unit to which this hob is connected.
This hob should be connected to the
cooker/control unit by a suitably
qualified and competent person, in
strict accordance with current local
and national safety regulations.
Installation, repairs and other work
by unqualified persons could be
dangerous. The manufacturer
cannot be held liable for
unauthorised work.
A damaged cable must be replaced
by a suitably qualified electrician
with a special connection cable,
available from the Miele Spare Parts
Department.
Ensure power is not supplied to the
appliance until after installation or
repair work has been carried out.
The cooker/control unit should be
connected to a suitable isolator which
complies with national and local safety
regulations, and the On/Off switch
should be easily accessible after the
appliance has been built in.
If the switch is not accessible after
installation (depending on country) an
additional means of disconnection must
be provided for all poles.
For extra safety it is advisable to protect
the appliance with a residual current
device (RCD). Please contact a
qualified electrician for advice.
When switched off there must be an
all-pole contact gap of at least 3 mm in
the isolator switch (including switch,
fuses and relays).
The appliance must only be
operated when built-in. This is to
ensure that all electrical parts are
shielded. Live parts must not be
exposed.
Please make sure that the connection
data quoted on the cooker's / control
unit's data plate matches the household
mains supply.
35
Electrical connection
WARNING
THIS APPLIANCE MUST BE
EARTHED
The electrical safety of this appliance
can only be guaranteed when
continuity is complete between it and
an effective earthing system, which
complies with current local and national
safety regulations. It is most important
that this basic safety requirement is
present and regularly tested and where
there is any doubt, the electrical wiring
in the home should be inspected by a
qualified electrician. The manufacturer
cannot be held liable for the
consequences of an inadequate
earthing system such as an electric
shock.
The manufacturer cannot be held
liable for damage which is the direct
or indirect result of incorrect
installation or connection.
36
After sales service, data plate
In the event of any faults which you cannot remedy yourself, please contact:
your Miele dealer, or
–
Miele (see back cover for contact details).
–
When contacting your Dealer or Miele, please quote the model and serial number
of your appliance. These are given on the data plate.
Space in which to stick the extra data plate supplied with the appliance. Ensure
that the model number is the same as the one on the front of these instructions.
Guarantee
For information on the appliance guarantee specific to your country please
contact Miele. See back cover for contact details.
373839
KM 6012
M.-Nr. 09 710 060 / 00en-GB
