Miele CVA6401WH Owners Manual

Operating and installation instructions

Built-in coffee machine CVA 6401 (C)

To avoid the risk of accidents or damage to the machine,

it is essential to read these

instructions before it is installed and used for the first time.

en-GB

M.-Nr. 09 549 660

Caring for the environment

Disposal of the packing material

The packaging is designed to protect the appliance from damage during transportation. The packaging materials used are selected from materials which are environmentally friendly for disposal and should be recycled.

Recycling the packaging reduces the use of raw materials in the manufacturing process and also reduces the amount of waste in landfill sites.

Disposal of your old machine

Electrical and electronic machines often contain valuable materials. They also contain materials which, if handled or disposed of incorrectly, could be potentially hazardous to human health and to the environment. They are, however, essential for the correct functioning of your machine. Please do not therefore dispose of it with your household waste.

Please dispose of it at your local community waste collection/recycling centre, or contact your Dealer for advice. Ensure that it presents no danger to children while being stored for disposal.

Contents

Caring for the environment..........................................2

Guide to the machine ..............................................6

Guide to the machine ..............................................8

Display and controls ................................................8

Accessories ......................................................9

Warning and Safety instructions ....................................10

Using for the first time.............................................17

Before using for the first time.........................................17

Switching on for the first time.........................................17

Water hardness ...................................................18

Operation .......................................................20

Filling the water container .........................................21

Filling the coffee bean container ....................................22

Switching the coffee machine on and off .............................23

Adjusting the central spout to the correct cup height ...................24

Making drinks....................................................25

Espresso, Coffee or Long coffee ......................................25

Making two portions................................................25

Cancelling preparation .............................................26

Dispensing several cups of coffee one after the other (Coffee pot) ...........26

Making espresso and coffee using ready ground coffee ...................26

Drinks with milk ...................................................28

Milk flask ......................................................28

Making drinks with milk...........................................29

Dispensing hot water ...............................................29

Making drinks using a profile.........................................29

After making drinks ................................................29

Coffee the way you like it ..........................................30

Grinder setting ....................................................30

Displaying and altering the parameters for a drink ........................31

Amount of coffee ..................................................31

Brewing temperature ...............................................31

Pre-brewing the coffee .............................................32

Contents

Setting the portion size ............................................33

Setting the portion size when making a drink ............................33

Calling up portion sizes from the menu "Parameter" , .....................35

Setting the portion sizes for different profiles ............................35

Setting up profiles ................................................36

Calling up a profile.................................................36

Creating a profile ..................................................36

Selecting a profile .................................................37

Changing the name ................................................37

Deleting a profile ..................................................37

Changing a profile .................................................38

Settings ........................................................39

Calling up the "Settings" menu........................................39

Changing and saving settings........................................39

Possible setting options.............................................40

Language........................................................42

Time ...........................................................42

Date ............................................................42

Timer ...........................................................42

Eco mode........................................................44

Lighting .........................................................44

Info (Display information)............................................45

Locking the coffee machine (System lock 0)............................45

Water hardness ...................................................45

Display brightness .................................................45

Setting the volume .................................................45

Factory default ....................................................45

Demo mode (Showroom programme) ..................................46

Contents

Cleaning and care ................................................47

Quick guide ......................................................47

Rinsing the coffee machine ..........................................49

Milk pipework.....................................................49

Milk flask and lid ..................................................51

Central spout .....................................................52

Water container ...................................................54

Waste container ...................................................54

Drip tray ........................................................55

Drip tray cover ....................................................55

Coffee bean container ..............................................56

Central spout connector ............................................56

Interior and machine front ...........................................57

Brew unit ........................................................57

Removing the brew unit and washing by hand ........................57

Degreasing the brew unit .........................................58

Machine front .....................................................59

Descaling .......................................................60

Problem solving guide ............................................62

Cleaning blockages from the milk pipework...........................70

After Sales / Guarantee ............................................73

Saving energy ...................................................74

Electrical connection U.K., ZA, IRL ..................................75

Installation ......................................................76

Building-in and combination options ...................................76

Ventilation .....................................................77

Installation.....................................................77

Adjusting the hinges .............................................79

Guide to the machine

Exterior view

a On/Off sensor K

b Controls and display

c Handle

d Hot water spout

e Drip tray cover

f Height-adjustable central spout with lighting

g Milk flask and lid

Interior view

Guide to the machine

h Ground coffee chute cover

i Brew unit

j Ground coffee chute

k Slide control to select fineness of ground coffee

l Coffee bean container

m Water container with inlet device

n Drip tray with grid

o Waste container

p Drip catcher

q Central spout connector

r Maintenance panel

Guide to the machine

Display and controls

a On/Off sensor K For switching the coffee machine on and off

b Drinks sensors For dispensing

. Espresso / Coffee

H Cappuccino k Latte macchiato

c Further programmes x Other drinks such as Long coffee, Caffè latte, hot

milk, milk froth and hot water Maintenance menu

d Display Shows information about the current action or status

e Back # For returning to the previous menu, cancelling

unwanted actions

f Arrow sensors Y X For displaying further options and highlighting a

selection

g OK sensor For confirming display messages and saving

settings

h Profiles { For saving and editing profiles

i Settings X For altering settings, displaying information or

checking which settings are currently active

j Two portions ° For making two portions of a drink

k Parameters , Settings for checking or altering coffee preparation

l Optical interface (for service technician use only)

Accessories

Accessories supplied

Measuring spoon

–

for ready ground coffee

Milk flask with lid

–

for storing and heating/frothing milk

Milk pipework cleaner

–

for cleaning the milk system (Starter set)

2 containers (large and small)

–

for cleaning and maintenance

Descaling tablets

–

for descaling the water pipework (Starter set)

– Cleaning tablets

for degreasing the brew unit (Starter set)

– Test strips

for determining the water hardness level

– Cleaning brush

for cleaning the milk pipework

Optional accessories

Miele accessories and cleaning and conditioning products are available for your coffee machine.

Microfibre cloth

–

for removing finger marks and light soiling

Milk flask with lid

–

for storing and heating/frothing milk

Small lid

–

for storing the milk flask in the fridge

Milk pipework cleaner

–

for cleaning the milk system

– Descaling tablets

for descaling the water pipework

– Cleaning tablets

for degreasing the brew unit

– Silcone grease

for lubricating the cap on the central spout connector

–

Silcone grease

for lubricating the cap on the central spout connector

–

Central spout connector cap

–

Angled connector for milk pipework

Replacement part

These products and other useful accessories can be ordered via the internet, from Miele (see back cover for contact details) or from your Miele dealer.

Warning and Safety instructions

This coffee machine complies with all statutory safety requirements. Improper use can, however, lead to personal injury and damage to property.

To avoid the risk of accidents and damage to the machine, please read these instructions carefully before using it for the first time. They contain important information on installation, safety, use and maintenance.

Miele cannot be held liable for damage caused by non-compliance with these instructions.

Keep these instructions in a safe place and ensure that new users are familiar with the content. Pass them on to any future owner.

Correct application

This coffee machine is intended for use in domestic households

and similar working and residential environments. It is not intended for outdoor use.

It must be used as a domestic appliance and only to make

espresso, cappuccino, latte macchiato etc. Any other use is not permitted.

The coffee machine can only be used by people with reduced

physical, sensory or mental capabilities, or lack of experience and knowledge, if they are supervised whilst using it, or have been shown how to use it in a safe way and recognise and understand the consequences of incorrect operation.

Warning and Safety instructions

Safety with children

The spouts present a danger of burning or scalding.

Children's skin is very sensitive and reacts to hot temperatures. Do not allow them to touch hot components of the coffee machine or to place any part of their body under the spouts.

Install the coffee machine where it is out of the reach of children.

Children under 8 years of age must be kept away from the

machine unless they are constantly supervised.

Children 8 years and older may only use the machine

unsupervised if they have been shown how to use it in a safe way and recognise and understand the consequences of incorrect operation.

Children must not be allowed to clean the coffee machine

unsupervised.

Please supervise children in the vicinity of the coffee machine

and do not allow them to play with it.

Remember that coffee and espresso are not suitable drinks for children.

Danger of suffocation. Packaging, e.g. plastic wrappings, must

be kept out of the reach of babies and children. Whilst playing, children could become entangled in packaging or pull it over their head and suffocate.

Warning and Safety instructions

Technical safety

Installation and repairs may only be carried out by a Miele

authorised service technician. Installation, repairs and other work by unqualified persons can cause considerable danger to users. The manufacturer cannot be held liable for unauthorised work.

A damaged coffee machine could be dangerous. Before building

in the machine, check it for any externally visible damage. Do not use a damaged machine.

To avoid the risk of damage to the machine, make sure the

connection data (fuse rating,voltage and frequency) on the data plate corresponds to the household supply, before connecting the machine to the mains supply. Consult a qualified electrician if in any doubt.

The electrical safety of this machine can only be guaranteed if

correctly earthed. It is essential that this standard safety requirement is met. If in any doubt, please have the electrical installation tested by a qualified electrician.

Do not connect the coffee machine to the mains electricity supply

by a multi-socket adapter or an extension lead. These are a fire hazard and do not guarantee the required safety of the machine.

For safety reasons, this machine may only be used when it has

been built in.

If the coffee machine is to be built in above another appliance,

there must be a full-width, closed shelf between them.

The coffee machine must not be used in a non-stationary location

(e.g. on a ship).

Warning and Safety instructions

Only use the coffee machine in rooms where the ambient

temperature is between +10 °C and +38 °C.

Ensure that there is sufficient ventilation around the coffee

machine. The ventilation gaps in the furniture housing unit and the gap between the top of the housing unit and the ceiling must be at least 200 cm the machine or the housing unit.

If the coffee machine is installed behind a kitchen furniture door,

it may only be used with the furniture door open. Do not close the furniture door while the coffee machine is in use.

While the machine is under guarantee, repairs should only be

undertaken by a Miele authorised service technician. Otherwise the guarantee is invalidated.

Miele can only guarantee the safety of the machine when original

Miele replacement parts are used. Faulty components must only be replaced by genuine Miele original spare parts.

. Otherwise condensation can build up and damage

The machine must be disconnected from the electrical supply

during installation and repair work.

Warning and Safety instructions

Do not open the outer casing of the machine. Tampering with

electrical connections or components and mechanical parts is highly dangerous to the user and can cause operational faults.

Only use genuine original Miele accessories with this machine.

Using spare parts or accessories from other manufacturers will invalidate the guarantee, and Miele cannot accept liability.

Correct use

The spouts present a danger of burning or scalding.

The liquids and steam dispensed are very hot. Water in the drip tray can also be very hot. Take great care when emptying it.

Please note:

– Keep well away from the area underneath the spouts when hot

liquids and steam are being dispensed.

– Do not touch hot components.

– The spouts can spray hot liquid or steam. Make sure that the

central spout is clean and that it is fitted correctly.

Never look directly at the lighting or use optical instruments to

look at it.

The machine must not be used for cleaning objects.

Clean the coffee machine and the milk flask before using for the

first time (see "Cleaning and care").

Warning and Safety instructions

Please note the following regarding water:

Only use cold, fresh tap water to fill the water container. Hot water

–

and other liquids could damage the machine.

Change the water every day to prevent a build-up of bacteria.

–

Do not use mineral water. Mineral water will cause serious

–

limescale deposits to build up in your machine and damage it.

Do not use water from a reverse osmosis unit in this machine. This

–

would damage it.

Only fill the bean container with roasted espresso/coffee beans.

Do not fill the bean container with coffee beans which have been treated with additives or with ground coffee.

Sugar will damage the machine. Only use pure coffee beans. Do

not use coffee beans which have been treated with anything containing caramel, any kind of sugar or other substances. Do not put liquids containing sugar in the coffee machine.

Only add ground coffee or the Miele cleaning tablets for

degreasing the brew unit to the ground coffee chute.

Do not use milk with additives. Sugar additives will stick to the

milk pipework and damage the machine.

If using animal milk, use only pasteurised milk.

Do not place any alcohol mixtures which are alight underneath

the central spout. The flames could ignite plastic components and cause them to melt.

Do not swing from or hang anything on the machine front when it

is open as this could damage the machine.

Warning and Safety instructions

Please note the following with regard to cleaning the coffee

machine:

Always disconnect the coffee machine from the electrical supply

–

before cleaning.

Clean the coffee machine and the milk flask daily (see "Cleaning

–

and care").

Do not use a steam cleaning appliance to clean the coffee

–

machine. Steam could reach electrical components and cause a short circuit.

Descale the coffee machine regularly using the appropriate

–

number of Miele descaling tablets for the water hardness level in your area. Descale the machine more frequently in areas with very hard water. Miele cannot be held liable for damage arising from insufficient descaling.

– Degrease the brew unit regularly with Miele cleaning tablets.

Depending on the natural oil content of the coffee used, the brew unit can become blocked quite quickly.

For machines with stainless steel surfaces:

Do not use sticky notes, transparent adhesive tape, masking tape

or other types of adhesive on stainless steel surfaces. These damage the surface, causing it to lose its dirt repellent protective coating.

The finish on stainless steel surfaces is susceptible to scratching.

Even magnets can cause scratching.

Please read the operating instructions and take the time to familiarise yourself with the coffee machine before using it for the first time.

Before using for the first time

The machine must be correctly

installed and connected (see "Electrical connection" and "Installation") before it is used for the first time.

Remove any protective foil.

Clean the coffee machine thoroughly (see "Cleaning and Care") before filling it with water and coffee beans.

Using for the first time

Selecting the language

Touch the arrow sensors until the

language you want is highlighted. Touch the OK sensor.

Touch the arrow sensors until the

country you want is highlighted. Touch the OK sensor.

The setting is now saved.

Setting the date

Touch the arrow sensors until the

current year appears. Touch the OK sensor.

^ Repeat this for "Month" and "Day",

until the current date has been set.

The setting is now saved.

Switching on for the first time

When you switch the coffee machine on for the first time, after the welcome screen has appeared you will be prompted to set the following:

–

Language

–

Date

–

Time

–

Display (Time of day display)

Touch the On/Off sensor K.

The welcome message "Miele Willkommen" will appear in the display briefly.

Setting the Time of day

^ Touch the arrow sensors until the

current time appears. Touch the OK sensor.

The setting is now saved.

Using for the first time

Display

You can choose from the following options:

On: the display will always show the

–

date and time (even when the machine is switched off).

Off: the display is dark when the

–

machine is switched off.

Night dimming: the date and time

–

are only displayed between the hours of 5:00 and 23:00.

Touch the arrow sensors until the

option you want is highlighted. Touch the OK sensor.

The coffee machine will use more energy depending on the option you choose for the display. Information about this will appear in the display.

"Set-up successfully completed" will appear in the display.

"Fill and replace the water container" will appear in the display.

Fill the water container with fresh, cold tap water.

Tip: Please continue to work though the further steps outlined in the operating instructions so that you can familiarise yourself with the coffee machine and set it up for your specific requirements.

Water hardness

The water hardness level indicates how much calcium is dissolved in the water. The higher the calcium content, the harder the water, and the harder the water, the more often the coffee machine will need to be descaled.

The coffee machine measures the quantity of water and steam used. The number of drinks which can be dispensed before the machine needs to be descaled will depend on the water hardness level set.

Set the water hardness level on the coffee machine to the water hardness level for the local area to ensure that the machine functions correctly and is not damaged. This will ensure that the reminder to descale the machine will appear in the display at the correct time.

The machine has four programmable levels:

Water hardness Local water

0 - 8.4 °dH (0 -1.5 mmol/l)

8.4 - 14 °dH (1.5 - 2.5 mmol/l)

14-21°dH (2.5 - 3.7 mmol/l)

more than 21 °dH (more than

3.7 mmol/l)

hardness level

Soft Soft 1

Medium Medium 2

Hard Hard 3

Hard Very hard 4

Setting (Hardness level)

Checking the water hardness level

You can use the test strip supplied to check the water hardness level, or your local water supplier will be able to advise you on the hardness of the water in your area.

^ Dip the test strip in your drinking

water for a second, then shake off any excess water. The result will be evident after about a minute.

You can now set the water hardness level for the coffee machine.

Using for the first time

Setting the water hardness level

Touch X.

Touch the arrow sensors until "Water hardness" is highlighted. Touch the OK sensor.

Touch the arrow sensors until the hardness level you want is highlighted. Touch the OK sensor.

The setting is now saved.

Operation

The coffee machine is operated by touching the sensors.

You are in the drinks menu when the display shows:

{ Miele

Select drink

To make a drink, touch one of the drinks sensors

Other drinks are available in the "Further programmes" x menu.

Calling up and navigating in a menu

To call up a menu, touch the relevant sensor. You will be able to start actions or alter settings in the selected menu.

To select an option, touch the X and Y arrow sensors to highlight the option you want.

Touch the OK sensor to confirm your selection.

Exiting a menu or cancelling an action

Touch # to exit the current menu.

If none of the sensors has been touched for a while, the coffee machine will revert to the drinks menu.

Settings

Language F

Time of day

Timer

A scroll bar on the right hand side of the display indicates more options or text. These can be displayed using the arrow sensors.

The setting which is currently selected will have a tick ( beside it.

Bacteria can cause infection.

It is important to empty and fill the container with fresh tap water every day to avoid the risk of bacteria building up.

Only use fresh, cold tap water.

Hot or warm water or other liquids could damage the coffee machine.

Do not use mineral water. Mineral water will cause serious limescale deposits to build up in your machine and damage it.

Filling the water container

Open the front of the coffee machine.

Pull the water container forwards to remove it.

Take off the lid and fill the water container with fresh, cold tap water up to the "max." mark.

Push the water container into the machine until it clicks into place.

If the water container protrudes slightly or is a little high, check whether the surface that the water container sits on is dirty. If the water container is not positioned correctly, the outlet valve will not connect properly and could leak. Clean the surface, if necessary.

Filling the coffee bean container

If you want to use freshly ground coffee beans for each cup of espresso or coffee, fill the coffee bean container with roasted coffee beans.

Alternatively, you can make coffee or espresso with ready ground coffee (see "Making coffee or espresso using ready ground coffee").

Warning. Only put roasted espresso/coffee beans in the container. Anything else, including ground coffee, will damage the grinder.

Pull out the coffee bean container.

Push back the lid and fill the

container with roasted coffee beans.

Warning. Sugar will damage the coffee machine. Do not use coffee beans that have been treated with sugar, caramel, or other substances and do not put liquids containing sugar in the coffee bean container.

^ Slide the lid back into place, ^ Push the coffee bean container fully

back into the coffee machine. Close the front.

Switching the coffee machine on and off

Switching on

When the machine is switched on it heats up and rinses out the pipework. This cleans and heats the pipework in preparation for making coffee.

If the coffee machine still has an operating temperature higher than 60 °C, then rinsing will not take place.

Touch the On/Off sensor K.

Tip: If you do not want the water from the rinsing process to flow into the drip tray, place a suitable container, e.g. the small container supplied, underneath the central spout before making the first coffee of the day.

At first "Heating-up phase" will appear in the display and once the coffee machine has heated up, "Appliance rinsing" will appear. Hot water will be dispensed from the central spout.

Switching off

Touch the On/Off sensor K.

If coffee has been dispensed, the coffee machine will rinse the coffee pipework automatically before switching off.

Switching off for longer periods of time

If the machine is not going to be used for a longer period of time, e.g. whilst on holiday:

^ Empty the drip tray, the waste

container and the water container.

You can now make drinks.

Clean all components thoroughly, including the brew unit, the central spout connector and the drip catcher in the machine front.

Switch off the machine.

If you are leaving the front open while the coffee machine is not in being used for a long time, disconnect it from the mains to save energy.

Adjusting the central spout to the correct cup height

You can adjust the central spout to suit the height of the cup you are using so that the coffee or espresso will not cool down too quickly and the crema will have a better consistency.

^ Pull the central spout down to the

same level as the rim of the cup.

or ^ Push the spout up until there is

enough room to fit a larger cup or mug underneath.

+ 56 hidden pages
