INSTALLATION
INSTRUCTIONS
Commercial Stacked Washer/Dryer Gas or Electric
INSTRUCTIONS D’INSTALLATION
Laveuse/sécheuse superposées à usage commercial
À gaz ou électrique
TABLE OF CONTENTS
. |
Page |
Stacked Washer/Dryer Safety................................................................ |
2 |
Tools & Parts ............................................................................................... |
5 |
Alternate Parts and Accessories............................................................ |
6 |
Dimensions/Clearances ........................................................................... |
7 |
Stacked Washer/Gas Dryer Installation Requirements .................... |
8 |
Stacked Washer/Electric Dryer |
|
Installation Requirements ..................................................................... |
10 |
Dryer Venting Requirements ................................................................ |
12 |
Dryer Gas Supply Requirements ........................................................ |
15 |
Installing Stacked Washer/Dryer......................................................... |
16 |
Washer Drain System ........................................................................... |
19 |
Leveling ....................................................................................................... |
20 |
Complete Installation ............................................................................... |
21 |
Reversing Dryer Door Swing ................................................................. |
22 |
Stacked Washer/Dryer Maintenance Instructions ............................ |
24 |
If You Need Assistance ........................................................................... |
25 |
Electronic Control Setup Instructions ............................................... |
26 |
Warranty ................................................................................................... |
32 |
TABLE DES MATIÈRES
. |
Page |
Sécurité de la laveuse/sécheuse superposées................................ |
33 |
Outils et pièces ....................................................................................... |
36 |
Pièces supplémentaires et accessoires ............................................ |
37 |
Dimensions/Distances de dégagement ............................................ |
38 |
Exigences d’installation pour la laveuse/sécheuse à gaz |
|
superposées............................................................................................. |
39 |
Exigences d’installation pour la laveuse/sécheuse électriques |
|
superposées ........................................................................................... |
41 |
Exigences concernant l’évacuation de la sécheuse ....................... |
43 |
Spécifications de l’alimentation en gaz de la sécheuse ................ |
46 |
Installation de la laveuse/sécheuse superposées ........................... |
47 |
Système d’évacuation de la laveuse................................................... |
50 |
Nivellement ................................................................................................ |
51 |
Achever l’installation ................................................................................ |
52 |
Inversion du sens d’ouverture de la porte de la sécheuse ............. |
53 |
Instructions d’entretien de la laveuse/sécheuse superposées |
.....55 |
Si vous avez besoin d’assistance ......................................................... |
56 |
Instructions de réglage du tableau |
|
de commande électronique .................................................................. |
57 |
Garantie .................................................................................................... |
64 |
W10434041B |
www.maytagcommerciallaundry.com |
STACKED WASHER/DRYER SAFETY
νIt is recommended that the owner post, in a prominent location, instructions for the customer’s use in the event the customer smells gas. This information should be obtained from your gas supplier.
νPost the following warning in a prominent location.
2
STACKED WASHER/DRYER SAFETY
3
STACKED WASHER/DRYER SAFETY
4
TOOLS & PARTS
Tools Needed:
8" (203 mm) |
8" (203 mm) or 10" (254 mm) |
Flat-Blade Screwdriver |
Phillips Screwdriver |
or 10" (254 mm) |
Adjustable Wrench |
|
|
Pipe Wrench |
That Opens to 1" (25 mm) |
|
|
Torx®† T-20 Security |
1" (25 mm) Hex-Head |
5⁄16" Socket Wrench |
Pliers |
Screwdriver or Bit |
Socket Wrench |
|
(that open to 19/16" [39 mm]) |
Level |
Utility Knife |
1/4" (6 mm) Nut Driver |
Locking Pliers |
Caulk Gun and Caulk |
Vent Clamps |
Pipe-Joint Compound |
27" (686 mm) Wood Block |
(for installing new exhaust vent) |
|
Suitable for Gas Type |
|
Flashlight (optional) |
1/2" (13 mm) and 9/16" |
Ruler or Measuring Tape |
|
(14 mm) Open-End Wrenches |
|
Parts Supplied:
Water Inlet Hoses (2) |
Inlet Hose Washers (4) |
U-Shaped Hose Form |
Transit Bolt Hole Plug (4) |
Beaded Tie Strap
Drain Hose/Clamp
†® TORX is a registered trademark of Saturn Fasteners, Inc. |
5 |
|
ALTERNATE PARTS AND ACCESSORIES
Alternate Parts
Your installation may require additional parts. If you are interested in purchasing one of the items listed here, call the toll-free number in the “If You Need Assistance” section.
If You Have |
You Will Need to Buy |
|
|
|
|
Overhead sewer |
Standard 20 gal. (76 L) 39" |
|
|
(990 mm) tall drain tub or utility sink, |
|
|
sump pump and connectors (available |
|
|
from local plumbing suppliers) |
|
|
|
|
1" (25 mm) standpipe |
2" (51 mm) diameter to 1" (25 mm) |
|
|
diameter Standpipe Adapter |
|
|
Part Number 3363920 |
|
|
Connector Kit Part Number 285835 |
|
|
|
|
Drain hose too short |
Extension Drain Hose Part |
|
|
Number 285863 |
|
|
Connector Kit Part Number |
285835 |
|
|
|
Lint clogged drain |
Drain Protector Part Number 367031 |
|
|
Connector Kit Part Number |
285835 |
|
|
|
Floor drain system |
Siphon break, Part Number 285834 |
|
|
Connector Kit (x2) Part Number |
|
|
285835 |
|
|
Extension Drain Hose Part |
|
|
Number 285863 |
|
|
|
|
Water faucets |
2 longer water fill hoses: |
|
beyond reach |
6 ft. (1.8 m) 90° bend hose |
|
of fill hoses |
Part Number 76314 |
|
|
10 ft. (3.0 m) Part Number 350008 |
|
|
|
|
Accessories
Enhance your washer/dryer with these premium accessories.
For more high-quality items or to order, call 1-800-807-6777 or visit us at www.whirlpoolparts.ca.
Part Number |
Accessory |
|
|
8212526 |
Washer drip tray, fits under all |
|
|
31682 |
All-purpose appliance cleaner |
|
|
1903WH |
Laundry supply storage cart |
|
|
279818 |
3-way dryer venting kit |
|
|
285834 |
Siphon break kit |
|
|
6
DIMENSIONS/CLEARANCES
Dimensions
Front View |
|
Side View |
|
Back View |
|||||||||||||||||||
|
|
|
|
|
27" |
|
|
|
|
|
|
51" |
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
||||||||||||
|
|
|
|
|
(686 mm) |
|
|
|
(1295 mm) |
|
|
|
|
|
|
||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
74" |
74" |
|
(1880 mm) |
||
(1880 mm) |
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
29.15/2" |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
1" |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
(751 mm) |
|
|
1" |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||||||||||
(25 mm) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||||||||||||
|
|
|
|
|
|
|
|
(25 mm) |
|
|
|
|
|
|
|
||||||||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||||||
Clearances
Side Clearances |
|
|
|
|
|
|
Back/Top Clearances |
|||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
0" |
0" |
(0 mm) |
(0 mm) |
7
STACKED WASHER/GAS DRYER INSTALLATION REQUIREMENTS
Stacked Washer/Gas Dryer Location
Selecting the proper location for your washer/dryer improves performance and minimizes noise and possible washer “walk.”
Your washer/dryer can be installed in a basement, laundry room, or recessed area. See “Drain System.”
Companion appliance location requirements should also be considered.
IMPORTANT: Do not install or store the washer/dryer where it will be exposed to the weather. Do not store or operate the washer/ dryer in temperatures at or below 32°F (0°C). Some water can remain in the washer and can cause damage in low temperatures. Proper installation is your responsibility.
You will need:
νA water heater set to deliver 120°F (49°C) water to the washer.
νHot and cold water faucets located within 4 ft. (1.2 m) of the hot and cold water fill valves, and water pressure of 20–100 psi (137.9–689.6 kPa).
νA level floor with a maximum slope of 1" (25 mm) under entire washer/dryer. Installing the washer/dryer on soft floor
surfaces, such as carpets or surfaces with foam backing, is not recommended.
νA sturdy and solid floor to support the washer/dryer with a total weight (water and load) of 450 lbs (204 kg).
νA floor drain under the bulkhead. Prefabricated bulkheads with electrical outlets, water inlet lines, and drain facilities should be used only where local codes permit.
Stacked washer/gas dryer installation clearances
νThe location must be large enough to allow the washer and dryer doors to be fully opened.
νAdditional spacing should be considered for ease of installation and servicing. The doors open more than 180°. The washer door is not reversible.
νAdditional clearances might be required for wall, door, and floor moldings.
νAdditional spacing of 1" (25 mm) on all sides of the washer/ dryer is recommended to reduce noise transfer.
νCompanion appliance spacing should also be considered.
When installing a gas dryer:
IMPORTANT: Observe all governing codes and ordinances.
νCheck code requirements: Some codes limit or do not permit installation of clothes dryers in garages, closets,
or sleeping quarters. Contact your local building inspector.
νMake sure that lower edges of the cabinet, plus the back and bottom sides of the washer, are free of obstructions to permit adequate clearance of air openings for combustion air. See “Recessed Area Installation Instructions” below for minimum spacing requirements.
Recessed Area Installation Instructions
This washer/dryer may be installed in a recessed area. For recessed area installations, minimum clearances can be found on the warning label on the rear of the dryer or in “Dimensions/ Clearances.”
The installation spacing is in inches and is the minimum allowable. Additional spacing should be considered for ease of installation, servicing, and compliance with local codes and ordinances.
The dryer must be exhausted outdoors.
8
STACKED WASHER/GAS DRYER INSTALLATION REQUIREMENTS
Stacked Washer/Gas Dryer Electrical Requirements |
Stacked Washer/Gas Dryer Gas Supply |
IMPORTANT: The washer/dryer must be electrically grounded in accordance with local codes and ordinances or, in the absence of local codes, with the Canadian Electrical Code, CSA C22.1. If codes permit and a separate ground wire is used, it is
recommended that a qualified electrical installer determine that the ground path is adequate.
A copy of the above code standards can be obtained from:
CSA International
8501 East Pleasant Valley Road
Cleveland, Ohio 44131-5575
νDo not ground to a gas pipe.
νDo not have a fuse in the neutral or ground circuit.
νA 120 volt, 60 Hz, AC only, 15or 20-amp, fused electrical circuit is required. A time-delay fuse or circuit breaker is also recommended. It is recommended that a separate circuit serving only this washer/dryer be provided.
νIf codes permit and a separate ground wire is used, it is recommended that a qualified electrician determine that the ground path is adequate.
νCheck with a qualified electrician if you are not sure the washer/dryer is properly grounded.
Stacked Washer/Gas Dryer Grounding
IMPORTANT: Observe all governing codes and ordinances.
This installation must conform with all local codes and ordinances. In the absence of local codes, installation must conform with CAN/ CSA B149.
A copy of the above code standards can be obtained from:
CSA International
8501 East Pleasant Valley Road
Cleveland, Ohio 44131-5575
The design of this washer/dryer has been certified by CSA International for use at altitudes up to 10,000 feet (3048 m) above sea level at the B.T.U. rating indicated on the model/serial plate. Burner input adjustments are not required when the washer/dryer is operated up to this elevation.
When installed above 10,000 feet (3048 m), a four percent (4%) reduction of the burner B.T.U. rating shown on the model/serial plate is required for each 1,000 foot (305 m) increase in elevation. For assistance when converting to other gas types and/or installing above 10,000 feet (3048 m) elevation, contact your local service company.
9
STACKED WASHER/ELECTRIC DRYER INSTALLATION REQUIREMENTS
Stacked Washer/Electric Dryer Location
Selecting the proper location for your washer/dryer improves performance and minimizes noise and possible washer “walk.”
Your washer/dryer can be installed in a basement, laundry room, or recessed area. See “Drain System.”
Companion appliance location requirements should also be considered.
IMPORTANT: Do not install or store the washer/dryer where it will be exposed to the weather. Do not store or operate the washer/dryer in temperatures at or below 32°F (0°C). Some water can remain
in the washer and can cause damage in low temperatures. Proper installation is your responsibility.
You will need:
νA water heater set to deliver 120°F (49°C) water to the washer.
νHot and cold water faucets located within 4 ft. (1.2 m) of the hot and cold water fill valves, and water pressure of 20–100 psi (137.9–689.6 kPa).
νA level floor with a maximum slope of 1" (25 mm) under entire washer/dryer. Installing the washer/dryer on soft floor
surfaces, such as carpets or surfaces with foam backing, is not recommended.
νA sturdy and solid floor to support the washer/dryer with a total weight (water and load) of 450 lbs (204 kg).
νA floor drain under the bulkhead. Prefabricated bulkheads with electrical outlets, water inlet lines, and drain facilities should be used only where local codes permit.
Stacked washer/electric dryer installation clearances
νThe location must be large enough to allow the washer and dryer doors to be fully opened.
νAdditional spacing should be considered for ease of installation and servicing. The doors open more than 180°. The washer door is not reversible.
νAdditional clearances might be required for wall, door, and floor moldings.
νAdditional spacing of 1" (25 mm) on all sides of the washer/ dryer is recommended to reduce noise transfer.
νCompanion appliance spacing should also be considered.
Recessed Area Installation Instructions
This washer/dryer may be installed in a recessed area. For recessed area installations, minimum clearances can be found on the warning label on the rear of the dryer.
The installation spacing is in inches and is the minimum allowable. Additional spacing should be considered for ease of installation, servicing, and compliance with local codes and ordinances.
The dryer must be exhausted outdoors.
10
STACKED WASHER/ELECTRIC DRYER INSTALLATION REQUIREMENTS
Stacked Washer/Electric Dryer Electrical
Requirements
Washer Electrical Requirements
νDo not have a fuse in the neutral or ground circuit.
νIf codes permit and a separate ground wire is used, it is recommended that a qualified electrician determine that the ground path is adequate.
νCheck with a qualified electrician if you are not sure the washer is properly grounded.
Stacked Washer/Electric Dryer Grounding
Dryer Electrical Requirements
It is your responsibility:
νTo contact a qualified electrical installer.
νTo be sure that the electrical connection is adequate and in conformance with the Canadian Electrical Code.
The Canadian Electrical Code requires a 4-wire power supply connection.
νTo supply the required 4 wire, single phase, 240 volt, 60 Hz., AC only electrical supply (or 4 wire, 120/208 volt electrical supply, if specified on the serial/rating plate) on a separate 40-amp circuit, fused on both sides of the line. A time delay fuse or circuit breaker is recommended. Connect to an individual branch circuit. Do not have a fuse in the neutral
or grounding circuit.
νDo not use an extension cord.
νIf codes permit and a separate ground wire is used, it is recommended that a qualified electrician determine that the ground path is adequate.
Electrical Connection
This dryer is supplied/fitted with an electrical supply cord and plug. It should be connected to a 4-wire electrical supply receptacle of NEMA Type 14-50P, at the voltage shown on the rating plate. The dryer must be
positioned so that the plug is clearly visible and accessible. This plug also provides the function of an emergency stop control for the user. If the fitted plug is not used, the electrical connection
must be carried out by a competent electrician in accordance with local or national codes.
If the supply cord is damaged, it must be replaced with a specially terminated cord by an authorized service agent or a similarly competent person in order to avoid a hazard.
11
DRYER VENTING REQUIREMENTS
WARNING: To reduce the risk of fire, this dryer MUST BE EXHAUSTED OUTDOORS.
IMPORTANT: Observe all governing codes and ordinances.
Dryer exhaust must not be connected into any gas vent, chimney, wall, ceiling, attic, crawlspace, or a concealed space of a building. Only rigid or flexible metal vent shall be used for exhausting.
4" (102 mm)
4" (102 mm) heavy, metal exhaust vent
■■ Only a 4" (102 mm) heavy, metal exhaust vent and clamps may be used.
■■ Do not use plastic or metal foil vent.
Rigid metal vent:
■■ Recommended for best drying performance and to avoid crushing and kinking.
Flexible metal vent: (Acceptable only if accessible to clean)
■■ Must be fully extended and supported in final dryer location.
■■ Remove excess to avoid sagging and kinking that may result in reduced airflow and poor performance.
■■ Do not install in enclosed walls, ceilings, or floors. ■■ The total length should not exceed 73⁄4 ft. (2.4 m).
NOTE: If using an existing vent system, clean lint from entire length of the system and make sure exhaust hood is not plugged with lint. Replace plastic or metal foil vents with rigid metal or flexible metal vents. Review “Vent System Chart” and if necessary, modify existing vent system to achieve best drying performance.
Elbows:
■■ 45° elbows provide better airflow than 90° elbows.
Good |
Better |
Clamps:
■■ Use clamps to seal all joints.
■■ Exhaust vent must not be connected or secured with screws or other fastening devices that extend into interior of duct and catch lint. Do not use duct tape.
Improper venting can cause moisture and lint to collect indoors, which may result in:
Moisture damage to woodwork, furniture, paint, wallpaper, carpets, etc.
Housecleaning problems and health problems.
12
DRYER VENTING REQUIREMENTS
Vent Hoods
4" (102 mm) Diameter Exhaust Hoods |
Exhaust hood must be at least 12" (305 mm) from the ground or |
|
any object that may be in the path of the exhaust (such as flowers, |
|
rocks, bushes, or snow). |
Box Hood |
Louvered Hood |
Angled Hood |
12" min.
(305 mm)
Vent System Length
Maximum Vent Length/Vent Connection
Maximum length of vent system depends upon the type of vent used, number of elbows, and type of exhaust hood.
Vent System Chart (Rigid Metal Vent)
No. of |
Box and |
Angled |
90˚ Turns |
Louvered Hood |
Hood |
0 |
135 ft. (41.2 m) |
129 ft. (39.3 m) |
1 |
125 ft. (38.1 m) |
119 ft. (36.3 m) |
2 |
115 ft. (35.1 m) |
109 ft. (33.2 m) |
3 |
106 ft. (32.3 m) |
100 ft. (30.5 m) |
4 |
98 ft. (29.9 m) |
92 ft. (28.0 m) |
For vent systems not covered by the vent specification chart, see your parts distributor.
Provision must be made for enough air for combustion and ventilation. (Check governing codes and ordinances.) See “Recessed Area Installation Instructions” in the “Stacked Washer/ Gas Dryer Location” and “Stacked Washer/Electric Dryer Location” sections.
A 4" (102 mm) outlet hood is preferred. However, a 21⁄2" (64 mm) outlet exhaust hood may be used. A 21⁄2" (64 mm) outlet creates greater back pressure than other hood types. For permanent installation, a stationary vent system is required.
Connect Vent
1.If connecting to existing vent, make sure the vent is clean.
2.Using a 4" (102 mm) clamp, connect vent to exhaust outlet in
dryer.
3. Tighten hose clamp with Phillips screwdriver.
4.Make sure the vent is secured to exhaust hood with a 4" (102 mm) clamp.
5.Move dryer into final position. Do not crush or kink vent. Make sure dryer is level.
NOTE: Do not remove vent collar.
13
DRYER VENTING REQUIREMENTS
If an Exhaust Hood Cannot be Used
The outside end of main vent should have a sweep elbow directed downward.
12" min. 24" min.
(305 mm)* (610 mm)
*Minimum clearance above any accumulation of snow, ice, or debris such as leaves
If main vent travels vertically through the roof, rather than through wall, install a 180° sweep elbow on end of vent at least 2 ft. (610 mm) above surface of roof.
The opening in wall or roof shall have a diameter 1⁄2" (13 mm) larger than vent diameter. Vent should be centered in opening.
Do not install screening over end of vent for best performance.
Multiple Dryer Venting
A main vent can be used for venting a group of dryers. The main vent should be sized to remove 200 CFM of air per dryer.
Large-capacity lint screens of proper design may be used in main vent if checked and cleaned frequently. The room where the dryers are located should have make-up air equal to or greater than CFM of all the dryers in the room.
Back-draft Damper Kit, Part No. 3391910, is available from your distributor and should be installed in the vent of each dryer to keep exhausted air from returning into dryers and to keep exhaust in balance within main vent. Unobstructed return air openings are required.
Each vent should enter the main vent at an angle pointing in
the direction of the airflow. Vents entering from the opposite side should be staggered to reduce the exhausted air from interfering with the other vents.
air ow
The maximum angle of each vent entering the main vent should be no more than 30°.
14
DRYER GAS SUPPLY REQUIREMENTS
Type of Gas
This dryer is equipped for use with natural gas. It is design-certified by CSA International for LP (propane and butane) gases with appropriate conversion. No attempt shall be made to convert dryer from gas specified on serial/rating plate for use with a different gas without consulting the serving gas supplier. Conversion must be done by a qualified service technician.
Gas conversion kit part numbers are listed on gas valve burner base.
Gas Supply Line
Recommended Method
Provide a gas supply line of 1⁄2" (13 mm) rigid (IPS) pipe to dryer location. Pipe joint compounds that resist action of LP gas must be used. Do not use TEFLON®† tape. With LP gas, piping or tubing size can be 1⁄2" (13 mm) minimum. Usually, LP gas suppliers determine size and materials used in the system.
Gas Supply Pressure Testing
A 1/8" (3 mm) NPT minimum plugged tapping, accessible for gauge testing, must be installed immediately downstream of the installed shut-off valve to the dryer (as shown above). The dryer must be disconnected from the gas supply piping system during any pressure testing of the system at test pressures in excess of 1/2" psig (352 kg/m2).
Alternate Method
The gas supply may also be connected using 3⁄8" (10 mm) approved copper or aluminum tubing. If the total length of the supply line is more than 20 ft. (6.1 m), larger tubing will be required.
If using natural gas, do not use copper tubing. Pipe joint compounds that resist action of type of gas supplied must be used.
Shut-off valve required
The supply line must be equipped with an individual manual shut-off valve installed within 6 ft. (1.8 m) of dryer in accordance with the B149 installation codes CAN/CGA B149.1 and CAN/ CGA B149.2. This valve should be located in same room as dryer. It should be in a location that allows ease of opening and closing. Do not block access to shut-off valve.
Flexible Metal Appliance Connector
It is recommended that a new flexible stainless steel gas line, design-certified by CSA International, be used for connecting the dryer to the gas supply line. (The gas pipe which extends through the lower rear of the dryer is provided with 3⁄8" (10 mm) male pipe thread.)
NOTE: Do not kink or damage the flexible stainless steel gas line when moving the door.
Rigid Pipe Connection
The rigid pipe connection requires a combination of pipe fittings to obtain an in-line connection to dryer.
†®TEFLON is a registered trademark of E.I. Du Pont De Nemours and Company.
15
INSTALLING STACKED WASHER/DRYER
Remove Transport System
NOTE: Slide washer/dryer onto cardboard or hardboard before moving to avoid damaging floor covering.
IMPORTANT: Position the washer/dryer so that the rear of the washer is within approximately 3 ft. (900 mm) of its final location.
There are 4 shipping bolts in the rear panel of the washer that support the suspension system during transportation. These bolts also retain the power cord inside the washer until the bolts are removed.
1.Keep the washer/dryer in the upright position while removing the shipping bolts.
2.Using a 1/2" (13 mm) wrench, loosen each of the bolts.
4. Close the bolt holes with the 4 transport bolt hole plugs.
IMPORTANT: If the washer/dryer is to be transported, call your product distributor or installer. To avoid suspension and structural damage, your washer/dryer must be properly set up for relocation by a trained professional.
3.Once the bolt is loose, move it to the center of the hole
and completely pull out the bolt, including the plastic spacer covering the bolt. Once all 4 bolts are removed, discard the bolts and spacers.
16
INSTALLING STACKED WASHER/DRYER
Connect Inlet Hoses
Insert new hose washers (supplied) into each end of the inlet hoses. Firmly seat the washers in the couplings.
Washer Coupling
Connect Inlet Hoses to Water Faucets
Make sure the washer drum is empty.
1.Attach a hose to the hot water faucet. Screw on coupling by hand until it is seated on the washer.
2.Attach a hose to the cold water faucet. Screw on coupling by hand until it is seated on the washer.
3.Using pliers, tighten the couplings with an additional two-thirds turn.
NOTE: Do not overtighten or use tape or sealants on the valve. Damage to the valves can result.
Clear Water Lines
νRun water through both faucets and inlet hoses, into a laundry tub, drainpipe, or bucket, to get rid of particles
in the water lines that might clog the inlet valve screens.
νCheck the temperature of the water to make sure that the hot water hose is connected to the hot water faucet and that the cold water hose is connected to the cold water faucet.
Connect Inlet Hoses to Washer
1.Attach the cold water hose to the washer’s cold water inlet valve. Screw on coupling by hand until it is seated on the washer.
2.Attach the hot water hose to the washer’s hot water inlet valve. Screw on coupling by hand until it is seated on the washer.
3.Using pliers, tighten the couplings with an additional two-thirds turn.
NOTE: Do not overtighten. Damage to the valve can result. 4. Turn on the water faucets completely and check for leaks.
NOTE: Replace inlet hoses after 5 years of use to reduce the risk of hose failure. Record hose installation or replacement dates on the hoses for future reference.
Periodically inspect and replace hoses if bulges, kinks, cuts, wear, or leaks are found.
17
INSTALLING STACKED WASHER/DRYER
Route Drain Hose
Proper routing of the drain hose avoids damage to your floor due to water leakage. Read and follow these instructions.
Remove drain hose from the washer drum
1.Using locking pliers, squeeze hose clamp tabs together and insert over the end of the drain hose.
2. Slide the drain hose onto the washer connection.
3. Once the drain hose is in place, release the pliers.
4.The washer drain system can be installed using a floor drain, wall standpipe, floor standpipe, or laundry tub.
Laundry tub drain or standpipe drain
Connect the drain hose form to the corrugated drain hose.
Snap either end of the drain hose form to the drain hose at the point where the corrugation begins.
Bend drain hose over drain hose form and snap into place.
NOTE: Hose must not extend more than 1" (25 mm) past the end of the U bend.
To keep drain water from going back into the washer:
νDo not straighten the drain hose, do not force excess drain hose into standpipe. Hose should be secure, but loose enough to provide a gap for air.
νDo not lay excess hose on the bottom of the laundry tub.
Floor drain
You may need additional parts. See “Alternate Parts.”
Secure Drain Hose
1.Drape the power cord over the washer top.
2.Move the washer to its final location.
3.Place the drain hose in the
laundry tub or standpipe as shown.
4. Secure the drain hose using
the supplied beaded tie strap. 41/2" (114 mm)
41/2"
(114 mm)
5.If the washer faucets and the drain standpipe are recessed, put the hooked end of the drain hose in the standpipe as shown.
NOTES:
νDo not force excess drain hose back into the rear of the washer.
νTo avoid siphoning, do not seal the drain hose into the standpipe.
18
WASHER DRAIN SYSTEM
The washer can be installed using the standpipe drain system (floor or wall), the laundry tub drain system, or the floor drain system.
Standpipe drain system – wall or floor
The standpipe drain requires a minimum diameter standpipe of 2" (50 mm). The minimum carry-away capacity can be no less than
10 gal. (38 L) per minute.
Wall
Laundry tub drain system
The laundry tub needs a minimum 20 gal. (76 L) capacity. The top of the laundry tub must be at least 30" (762 mm) above the floor.
30" (762 mm)
The top of the standpipe must be at least 30" (762 mm) high and no higher than 96" (2.4 m) from the bottom of the washer.
Floor
30" min. (762 mm)
Floor drain system
The floor drain system requires a siphon break that may be purchased separately.
The siphon break (Part Number 285834) must be a minimum of 28" (710 mm) from the bottom of the washer. Additional hoses might be needed.
Syphonbreak
28" (710 mm)
19
LEVELING
Leveling Stacked Washer/Dryer
Leveling your washer/dryer properly reduces excess noise and vibration.
1.Remove cardboard from beneath washer/dryer. Place a level on top edges of washer/dryer, checking each side and front. If not level, tip washer/dryer and adjust feet up or down as shown in Steps 3 and 4, repeating as necessary.
3.If washer/dryer is not level, use a 9/16" or 14 mm openend or adjustable wrench to turn jam nuts clockwise (as viewed from above) on feet until they are about 1/2" (13 mm)
from the washer/dryer cabinet. Then turn the leveling foot counterclockwise to lower the washer/dryer or clockwise to raise the washer/dryer. Recheck levelness of washer/dryer and that all four feet are firmly in contact with the floor. Repeat as needed.
HELPFUL TIP: You may want to prop up front of washer/dryer about 4" (102 mm) with a wood block or similar object that will support weight of washer/dryer.
Jam nut
4.When washer/dryer is level and all four feet are firmly in contact with the floor, use a 9/16" or 14 mm open-end or adjustable wrench to turn jam nuts counterclockwise (as viewed from above) on leveling feet tightly against washer/dryer cabinet.
HELPFUL TIP: You may want to prop washer/dryer with wooden block.
|
|
|
|
|
|
|
|
|
|
|
Not Level |
|
LEVEL |
|
Not Level |
||||||
2.Grip washer/dryer from top and rock back and forth, making sure all four feet are firmly on floor. Repeat, rocking washer/dryer from side to side. If washer/dryer rocks, go to Step 3 and adjust leveling feet. If all four feet are in firm contact with floor, go to Step 4.
20
Loading...
