CLASS 1 LASER PRODUCT
LUOKAN 1 LASERLAITE
KLASS 1 LASERAPPARAT
WARNINGS
CAUTIONS
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK)
NO USER-SERVICEABLE PARTS INSIDE
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL
The lightning flash with arrowhead symbol within an equilateral
triangle is intended to alert the user to the presence of uninsulated
"dangerous voltage" within the product's enclosure that may be of
sufficient magnitude to constitute a risk of electric shock to
persons.
The exclamation point within an equilateral triangle is intended to
alert the user to the presence of important operating and
maintenance (servicing) instructions in the literature
accompanying the product.
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
ENGLISH
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE
BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
ATTENTION: POUR ÉVITER LES CHOCS ÉLECTRIQUES,
INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE DANS
LA BORNE CORRESPON-DANTE DE LA PRISE ET POUSSER
JUSQU'AU FOND.
LASER SAFETY
This unit employs a laser. Only a qualified service person should remove the cover or
attempt to service this device due to possible eye injury.
CAUTION :
USE OF CONTROLS OR ADJUSTMENTS OR
PERFORMANCE OF PROCEDURE OTHER THAN
THOSE SPECIFIED HEREIN MAY RESULT IN
HAZARDOUS RADIATION EXPOSURE.
- 2 -
IMPORTANT SAFETY INSTRUCTIONS
READ BEFORE OPERATING EQUIPMENT
This product was designed and manufactured to meet strict quality
and safety standards. There are, however, some installation and
operation precautions which you should be particularly aware of.
1. Read Instructions – All the safety and operating instructions
should be read before the product is operated.
2. Retain Instructions – The safety and operating instructions
should be retained for future reference.
3. Heed Warnings – All warnings on the product and in the
operating instructions should be adhered to.
4. Follow Instructions – All operating and use instructions should
be followed.
5. Cleaning – Unplug this product from the wall outlet before
cleaning. Do not use liquid or aerosol cleaners. Use a damp
cloth for cleaning.
6. Attachments – Do not use attachments not recommended by
the product manufacturer as they may cause hazards.
7. Water and Moisture – Do not use this product near water–for
example, near a bath tub, wash bowl, kitchen sink, laundry tub,
swimming pool, in a wet basement, and the like.
8. Accessories – Do not place this product on an unstable cart,
stand, tripod, bracket, or table. The product may fall, causing
serious injury to a child or adult, and serious damage to the
product. Use only with a cart, stand, tripod, bracket or table
recommended by the manufacturer, or sold with the product.
Any mounting of the product should follow the manufacturer's
instructions, and should use a mounting accessory
recommended by the manufacturer.
9. A product and cart combination should be moved with care.
Quick stops, excessive force, and uneven surfaces may cause
the product and cart combination to overturn.
10. Ventilation – Slots and openings in the cabinet are provided for
ventilation and to ensure reliable
operation of the product and to
protect it from overheating. These
openings must not be blocked or
covered. The openings should never
be blocked by placing the product on
a bed, sofa, rug, or other similar
surface. This product should not be
placed in a built-in installation such
as a bookcase or rack unless proper
ventilation is provided or the
manufacturer's instructions have
been adhered to.
11. Power Sources – This product should be operated only from
the type of power source indicated on the marking label. If you
are not sure of the type of power supply to your home, consult
your product dealer or local power company. For products
intended to operate from battery power or other sources, refer
to the operating instructions.
12. Grounding or Polarization – This
product may be equipped with a
polarized alternating-current line
plug (a plug having one blade
wider than the other). This plug
will fit into the power outlet only
one way. This is a safety feature.
If you are unable to insert the
plug fully into the outlet, try
reversing the plug. If the plug should still fail to fit, contact your
electrician to replace your obsolete outlet. Do not defeat the
safety purpose of the polarized plug.
13. Power Cord Protection – Power supply cords should be routed
so that they are not likely to be walked on or pinched by items
placed upon or against them, paying particular attention to
cords at plugs, convenience receptacles, and the point where
they exit from the product.
14. Protective Attachment Plug – The product is equipped with an
attachment plug having overload protection. This is a safety
feature. See Instruction Manual for replacement or resetting of
AC POLARIZED PLUG
protective device. If replacement of the plug is required, be sure
the service technician has used a replacement plug specified
by the manufacturer that has the same overload protection as
the original plug.
15. Outdoor Antenna Grounding – If an outside antenna or cable
system is connected to the product, be sure the antenna or
cable system is grounded so as to provide some protection
against voltage surges and built-up static charges. Article 810
of the National Electrical Code, ANSI/NFPA 70, provides
information with regard to proper grounding of the mast and
supporting structure, grounding of the lead-in wire to an
antenna discharge unit, size of grounding conductors, location
of antenna-discharge unit, connection to grounding electrodes,
and requirements for the grounding electrode. See Figure 1.
16. Lightning – Lightning – Unplug the unit from the wall outlet and
disconnect the antenna or cable system for added protection
during a lightning storm or when it is left unattended and
unused for long periods of time. This will prevent damage to the
product due to lightning and power line surges.
17. Power Lines – An outside antenna system should not be
located in the vicinity of overhead power lines or other electric
light or power circuits, or where it can fall into such power lines
or circuits. When installing an outside antenna system, extreme
care should be taken to keep from touching such power lines or
circuits as contact with them might be fatal.
18. Overloading – Do not overload wall outlets, extension cords, or
integral convenience receptacles as this can result in a risk of
fire or electric shock.
19. Object and Liquid Entry – Never push objects of any kind into
this product through openings as they may touch dangerous
voltage points or short-out parts that could result in a fire or
electric shock. Never spill liquid of any kind on the product.
20. Servicing – Do not attempt to service this product yourself as
opening or removing covers may expose you to dangerous
voltage or other hazards. Refer all servicing to qualified service
personnel.
21. Damage Requiring Service – Unplug this product from the wall
outlet and refer servicing to qualified service personnel under
the following conditions:
a. When the power supply cord or plug is damaged.
b. If liquid has been spilled, or objects have fallen into the product.
c. If the product has been exposed to rain or water.
d. If the product does not operate normally by following the
operating instructions. Adjust only those controls that are
covered by the operating instructions, as an improper
adjustment of other controls may result in damage and will often
require extensive work by a qualified technician to restore the
product to its normal operation.
e. If the product has been dropped or damaged in any way, and
f. When the product exhibits a distinct change in performance –
this indicates a need for service.
22. Replacement Parts – When replacement parts are required, be
sure the service technician has used replacement parts
specified by the manufacturer or have the same characteristics
as the original part. Unauthorized substitutions may result in fire,
electric shock, or other hazards.
23. Safety Check – Upon completion of any service or repairs to this
product, ask the service technician to perform safety checks to
determine that the product is in proper operating condition.
24. Wall or Ceiling Mounting – The product should be mounted to a
wall or ceiling only as recommended by the manufacturer.
25. Heat – The product should be situated away from heat sources
such as radiators, heat registers, stoves, or other products
(including amplifiers) that produce heat.
ENGLISH
- 3 -
ANTENNA
LEAD IN
WIRE
GROUND
CLAMP
ELECTRIC
SERVICE
EQUIPMENT
GROUND CLAMPS
FIGURE 1
EXAMPLE OF ANTENNA GROUNDING AS PER
NATIONAL ELECTRICAL CODE, ANSI/NFPA 70
NEC - NATIONAL ELECTRICAL CODE
POWER SERVICE
GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
ANTENNA
DISCHARGE
UNIT
(NEC SECTION
810-20)
GROUNDING
CONDUCTORS
(NEC SECTION
810-21)
NOTE TO CATV SYSTEM INSTALLER:
WARNINGS
Do not expose the equipment to rain or moisture.
Do not remove the cover from the equipment.
ENGLISH
Do not insert an ything into the equipment through
the ventilation holes.
Do not cover the ventilation with any items such
as tablecloths, newspapers, curtains, etc.
No open flame sources, such as lighted candles,
should be placed on the equipment.
When disposing of used batteries, please comply
with governmental regulations or environmental
public instruction's rules that apply in your country
or area.
This reminder is provided to call the CATV (Cable-TV)
system installer's attention to Article 820-40 of the
NEC, which provides guidelines for proper grounding
and, in particular, specifies that the cable ground shall
be connected to the grounding system of the building,
as close to the point of cable entry as practical.
NOTE:
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful
interference to radio or television reception, which can
be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of the following measures:
• Re-orient or relocate the receiving antenna.
• Increase the separation between the equipment
and receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV
technician for help.
CE marking (only EU version)
This product is in conformity with the EMC
directive and low-voltage directive.
Equipment mains working system
This product complies with household power and
safety requirements in your area.
This Class B digital apparatus complies
with Canadian ICES-003.
Cet appareil numérique de la Classe B est
conforme á la norme NMB-003 du Canada.
NOTE: Changes or modifications may cause this
unit to fail to comply with Part 15 of the FCC Rules
and may void the user's authority to operate the
FEATURES ..................................................................................................................................................7
QUICK OPTICAL AUTO REVERSE ...................................................................................................7
TAPE AND CD PITCH CONTROL ......................................................................................................7
IR RECEIVER .....................................................................................................................................7
RC-5 REMOTE CONTROL COMPATIBILITY .....................................................................................7
Thank you for selecting the Marantz Professional
PMD351 combination Stereo Cassette Deck/CD
Player. Please read these operating instructions
carefully. We recommend that you read the entire
user guide prior to connecting and operating the unit.
It is also recommended that all connections be made
prior to operating the unit. Please refer to this manual
to identify controls and connections for operation of
the unit.
RC-5 REMOTE CONTROL COMPATIBILITY
The PMD351 comes equipped with an RC-5 remote
in and out port. Through the use of various remote
control options the major functions of the unit can be
operated via wired or wireless remote control.
ONE-TOUCH DUBBING
The PMD351 allows for the dubbing of a CD to a
tape with one-button start control. This feature allows
you to manually or automatically select the recording
level you desire.
ENGLISH
OPERATING PRECAUTIONS
When setting up the equipment ensure that:
• air is allowed to circulate freely around the
equipment,
• the equipment is on a vibration free surface,
• the equipment will not be exposed to interference
from an external source,
• the equipment will not be exposed to excessive
heat, cold, moisture or dust,
• the equipment will not be exposed to direct
sunlight, and
• heavy objects are not placed on the equipment,
• the unit is not exposed to moisture. If so, do not
operate the unit until it has been thoroughly
inspected by a electrically competent technician.
• Do not disconnect AC power by pulling the power
cord. Remove from the outlet by pulling on the
plug only.
FEATURES
QUICK OPTICAL AUTO REVERSE
In addition to the normal tension reversing circuitry,
the PMD351 tape transport also employs optically
sensed quick auto reverse circuitry. This circuitry
reacts to the clear areas of the tape, usually the
leader tape, and when detected, will reverse the
direction of the tape transport. This process minimizes the loss of signal being recorded or played
back. This reverse process applies to all tape playback and recording modes, including auto reverse
and continuous mode.
A-B REPEAT
The PMD351 allows you to select two points within
the CD playback mode and repeat the audio playback within these points until a stop command is
issued.
LOCKABLE REM TRACK TIME MODE
The CD time display can be toggled between the
various modes of display. In addition, when a display
mode is set, the unit will remain in the selected mode
until you change it. This is particularly useful for
monitoring the audio during performances and
programs.
ONE-TRACK PLAY
The PMD351 can be set to allow for the CD player to
play the selected track and return to the stop mode
rather than continue on to the next track on the CD.
CD-R/CD-RW PLAY
In addition to conventional music CDs and CD-R
(recordable) discs, this player can also play CD-RW
(rewritable) discs. It can also play unfinalized discs
that cannot be played by regular CD players.
MP3
This player can play discs containing MP3 files.
AUTO QUE CD PLAY
The CD pl
Que feature. This feature allows the CD player to
advance to the beginning of the audio within the track
rather than start from the track start flag. This feature
helps to minimize the silence at the beginning of a
CD track playback.
ayer on the PMD351 contains an Auto
TAPE AND CD PITCH CONTROL
The PMD351 tape player and CD player both allow
for adjustment of the playback pitch from -12% to
+12%. The feature is particularly useful for adjusting
the unit playback pitch to allow you to tune the
PMD351 to accompanying instruments and choirs.
IR RECEIVER
The PMD351 is equipped with an IR receiver for use
with remote control Model RC330 (not supplied)
available from Marantz Professional.
DOLBY NR SYSTEMS
The Dolby Noise Reduction systems compress and
amplify the tape during recording in order to raise the
signal-to-noise ratio on the tape. During playback,
these signals are expanded and attenuated by the
same amount in order to regain the original dynamic
range of music. An additional result of this expansion
and attenuation is that the noise floor of the recording
is reduced significantly. Dolby B typically reduces
noise by 10dB. Dolby C typically reduces noise by
20dB.
- 7 -
DOLBY HX PRO HEADROOM EXTENSION
The Dolby HX PRO system monitors the total amount
of effective bias during recording and instantaneously
compensates for any excess bias by reducing the
deck’s bias signal level accordingly. The system
operates independently on each channel. HX PRO is
unlike a noise reduction system because it functions
only during recording and no decoding is required.
Therefore a tape recorded with the HX PRO system
can be played back on any other cassette deck while
retaining the benefits of HX PRO.
MEMO button
6
Press the MEMO button to store a memory point
into the counter memory. Once this point is set,
the tape deck will rewind or fast forward until it
reaches this point in the tape and will stop. To
cancel the memory control, press the MEMO
button again.
RESET button
7
Press the RESET button to reset the current tape
counter reading from its existing point to “0000”
ENGLISH
FRONT PANEL CONTROLS
AND DISPLAYS
Power switch button
1
Push the POWER switch in to turn power to the
unit on and off. When power is turned off, all past
settings are removed from memory and the unit
returns to its default setting upon the next power
up.
EJECT button
2
Press the eject button to open the cassette tape
holder. The EJECT button will not function unless
the tape deck is in the stop mode. Thus, if the
power is turned off without hitting the STOP
button, the door may not open.
CASSETTE TAPE HOLDER
3
This section holds the cassette tape for tape Play
and Record functionality. Tapes that have the
record protect knock-out removed will not enter
into the record mode.
4
TAPE PITCH control
Rotate the TAPE DECK pitch control to adjust the
tape deck playback pitch from -12% to +12%.
While the control is in the center detent position,
the tape deck is at normal (0% pitch variance)
speed. This control has no effect on the tape
pitch during the record mode.
DUBB button
8
Press the DUBB button to engage the tape
transport into the dubbing mode from the CD
player. Once the DUBB button is pressed, the
CD player will copy directly to the tape deck.
REC indicator
9
Displayed when the tape deck is in the Record
mode. When the REC indicator is flashing, this
indicates the tape deck is in the Record Pause
mode.
REC/PAUSE button
10
Press the REC/PAUSE button to engage the
tape transport into the record pause mode. In this
mode, the tape deck is armed to begin recording.
The tape record mode can be engaged by
pressing the forward play or reverse play buttons.
IR sensor
11
Sensor for receiving infrared remote control
signals. Model RC330 IR control emitter is
available from Marantz Professional.
TAPE DECK AND CD PLAYER CONTROLS
12
PLAY PAUSE
PLAY
STOP
PLAY
5
DISPLAY
See next section for description of display
elements.
TAPE COUNTER buttons
The MEMO button 6 and RESET button 7
control the tape counter (DISPLAY a ). The tape
counters are only approximate measurements of
minutes and seconds and are not intended for
timing-critical applications. They are most accurate with 60 minute tapes.
- 8 -
TAPE
a
TAPE DECK CONTROL buttons
a
REWIND button
Press the REWIND button to engage the
tape transport into fast rewind mode from the
right (take-up) to the left (supply) reels.
PLAY
PLAY PAUSE
STOP
TAPE
PLAY
mode, this function is used along with the NEXT/
SEARCH FAST FORWARD button to select
the desired tracks to be played.
Note:
Automatic search operations cannot operate on
the Tape and CD at the same time.
ENGLISH
b c d e
b
REVERSE PLAY button
Press the REVERSE PLAY button to engage
the tape deck into the reverse play function.
STOP button
c
Press the STOP button to cancel all current
operations of the tape deck.
d
FORWARD PLAY button
Press the FORWARD PLAY button to engage
the tape deck into the forward play function.
Indicator light in the button is lit during forward
play, flashing during stop or pause.
e
FAST FORWARD button
Press the FAST FORWARD button to
engage the tape transport into the fast forward
wind mode from the left (supply) to the right
(take-up) reels.
PLAY /PAUSE
STOP/EJECT
g
PLAY/PAUSE button
Press the PLAY/PAUSE button to change
the CD player mode from CD play to CD pause
or from CD pause to CD play.
h
NEXT/SEARCH FAST FORWARD button
When the CD player is in the play or pause
mode, pressing the NEXT/SEARCH FAST
FORWARD button will skip forward one
track for every time the control button is pushed.
Keeping this control depressed causes the unit
to advance (scan) into the track. The track time
display will show your current location within the
song. During the program mode, this function is
used along with the PREVIOUS/SEARCH
REVERSE button to select the desired
tracks to be played.
i
STOP/EJECT button
Press the STOP/EJECT button to stop the
CD Player while in the play mode. Press the
STOP/EJECT button while in the Stop
mode to open the door and eject the disk.
During the program mode, the STOP/EJECT
button will cancel the current program as
long as the CD player is in the Stop mode.
CD
f g h i
CD PLAYER CONTROL buttons
f
PREVIOUS/SEARCH REVERSE button
When the CD player is in the play or pause
mode, press and release the PREVIOUS/
SEARCH REVERSE button to skip back to
the beginning of the current track and then skip
one track for every time the control button is
pressed and released. Keeping this control
pressed for more than 1/2 a second causes the
unit to retreat (backward scan) within the track.
The track time display will show your current
location within the song. During the program
- 9 -
13
HP SELECT switch
The HP SELECT switch (Headphone selector
switch) is used to switch the headphone output.
14
HEADPHONES jack
The HEADPHONES jack is used to allow
monitoring of the Tape, CD or Tape/CD Mix
through headphones. This jack requires that a
1/4" headphone jack connection be made and
the desired source can be selected by the HP
SELECT switch located directly above the
headphone input jack.
COMPACT DISC tray
15
The COMPACT DISC tray is used to hold the
desired CD for playback.
Loading...
+ 18 hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
