Marantz PM5004 Quick Start

Integrated Amplier

PM5004

ENGLISHDEUTSCHFRANÇAISITALIANOESPAÑOLNEDERLANDSSVENSKA

SAFETY PRECAUTIONS

n

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION:

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

WARNING:

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

surface

The lightning fl ash with arrowhead symbol, within an equilateral
triangle, is intended to alert the user to the presence of
uninsulated “dangerous voltage” within the product’s enclosure
that may be of suffi cient magnitude to constitute a risk of
electric shock to persons.

The exclamation point within an equilateral triangle is intended
to alert the user to the presence of important operating
and maintenance (servicing) instructions in the literature
accompanying the appliance.

CAUTION:

HOT SURFACE. DO NOT TOUCH.

The top surface over the internal heat sink may become hot when
operating this product continuously.

Hot

mark

Do not touch hot areas, especially around the “Hot surface mark” and
the top panel.

VORSICHT:

HEISSE OBERFLÄCHE. NICHT ANFASSEN.

Die Oberseite über dem inneren Kühlkörper könnte heiß werden,
wenn dieses Produkt dauerhaft betrieben wird.
Berühren Sie keine heißen Bereiche, hier besonders um die
Kennzeichnung “Hot surface mark” und die Oberseite.

PRECAUTION:

SURFACE CHAUDE. NE PAS TOUCHER.

La surface supérieure du dissipateur de chaleur peut devenir chaude
si vous utilisez ce produit en continu.
Ne touchez pas les zones chaudes, tout particulièrement vers
l’inscription “Hot surface mark” et le panneau supérieur.

ATTENZIONE:

SUPERFICIE CALDA. NON TOCCARE.

La superfi cie superiore al di sopra del dissipatore interno può
riscaldarsi quando si adopera questo prodotto in maniera continuativa.
Non toccare parti calde, in particolare quelle intorno alla dicitura “Hot
surface mark” e al pannello superiore.

IMPOTANT SAFETY

INSTRUCTIONS

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings.
Install in accordance with the manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including amplifi ers) that produce heat.

9. Protect the power cord from being walked on or pinched particularly at
plugs, convenience receptacles, and the point where they exit from the
apparatus.

10. Only use attachments/accessories specifi ed by the manufacturer.

11. Use only with the cart, stand, tripod, bracket, or table
specifi ed by the manufacturer, or sold with the apparatus.
When a cart is used, use caution when moving the cart/
apparatus combination to avoid injury from tip-over.

12. Unplug this apparatus during lightning storms or when
unused for long periods of time.

13. Refer all servicing to qualifi ed service personnel.
Servicing is required when the apparatus has been damaged in any way,
such as power-supply cord or plug is damaged, liquid has been spilled or
objects have fallen into the apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or has been dropped.

14. Batteries shall not be exposed to excessive heat such as sunshine, fi re or
the like.

PRECAUCIÓN:

SUPERFICIE CALIENTE. NO TOCAR.

La superfi cie superior sobre el disipador de calor interno podría llegar
a calentarse al operar este producto de forma continua.
No toque las áreas calientes, especialmente las situadas alrededor de
la “Hot surface mark” y del panel superior.

WAARSCHUWING:

HEET OPPERVLAK. NIET AANRAKEN.

Bij ononderbroken bediening van dit product kan het oppervlak boven
de interne koelplaat heet worden.
Raak het toestel niet aan waar het heet is, vooral niet in de buurt van
het “Hot surface mark” en het bovenpaneel.

FÖRSIKTIHETSMÅTT:

VARM YTA. RÖR EJ.

Ytan ovanför den interna kylfl änsen kan bli varm när produkten
används kontinuerligt.
Rör inte varma områden. Var särskilt försiktig vid märkningen “Hot
surface mark” och på toppanelen.

ENGLISHDEUTSCHFRANÇAISITALIANOESPAÑOLNEDERLANDSSVENSKA

CAUTION:

To completely disconnect this product from the mains, disconnect
the plug from the wall socket outlet.
The mains plug is used to completely interrupt the power supply to

the unit and must be within easy access by the user.

VORSICHT:

Um dieses Gerät vollständig von der Stromversorgung abzutrennen,
ziehen Sie bitte den Stecker aus der Wandsteckdose.
Der Netzstecker wird verwendet, um die Stromversorgung zum
Gerät völlig zu unterbrechen; er muss für den Benutzer gut und

einfach zu erreichen sein.

PRECAUTION:

Pour déconnecter complètement ce produit du courant secteur,
débranchez la prise de la prise murale.
La prise secteur est utilisée pour couper complètement
l’alimentation de l’appareil et l’utilisateur doit pouvoir y accéder

facilement.

ATTENZIONE:

Per scollegare completamente questo prodotto dalla rete di
alimentazione elettrica, scollegare la spina dalla relativa presa a

muro.
La spina di rete viene utilizzata per interrompere completamente
l’alimentazione all’unità e deve essere facilmente accessibile
all’utente.

PRECAUCIÓN:

Para desconectar completamente este producto de la alimentación
eléctrica, desconecte el enchufe del enchufe de la pared.

El enchufe de la alimentación eléctrica se utiliza para interrumpir
por completo el suministro de alimentación eléctrica a la unidad

y debe de encontrarse en un lugar al que el usuario tenga fácil
acceso.

WAARSCHUWING:

Om de voeding van dit product volledig te onderbreken moet de
stekker uit het stopcontact worden getrokken.

De netstekker wordt gebruikt om de stroomtoevoer naar het toestel
volledig te onderbreken en moet voor de gebruiker gemakkelijk

bereikbaar zijn.

FÖRSIKTIHETSMÅTT:

Koppla loss stickproppen från eluttaget för att helt skilja produkten
från nätet.
Stickproppen används för att helt bryta strömförsörjningen till

apparaten, och den måste vara lättillgänglig för användaren.

I

ENGLISH DEUTSCH FRANÇAIS ITALIANO ESPAÑOL NEDERLANDS SVENSKA

NOTE ON USE / HINWEISE ZUM GEBRAUCH / OBSERVATIONS RELATIVES A L’UTILISATION / NOTE SULL’USO /

n

NOTAS SOBRE EL USO / ALVORENS TE GEBRUIKEN / OBSERVERA ANGÅENDE ANVÄNDNINGEN

WARNINGS WARNHINWEISE AVERTISSEMENTS AVVERTENZE ADVERTENCIAS WAARSCHUWINGEN VARNINGAR

• Avoid high temperatures.
Allow for suffi cient heat
dispersion when installed in a
rack.

• Handle the power cord carefully.
Hold the plug when unplugging
the cord.

• Keep the unit free from
moisture, water, and dust.

• Unplug the power cord when
not using the unit for long
periods of time.

• Do not obstruct the ventilation
holes.

• Do not let foreign objects into
the unit.

• Do not let insecticides,
benzene, and thinner come in
contact with the unit.

• Never disassemble or modify
the unit in any way.

• Ventilation should not be
impeded by covering the
ventilation openings with
items, such as newspapers,
tablecloths or curtains.

• Naked fl ame sources such as
lighted candles should not be
placed on the unit.

• Observe and follow local
regulations regarding battery
disposal.

• Do not expose the unit to
dripping or splashing fl uids.

• Do not place objects fi lled with
liquids, such as vases, on the
unit.

• Do not handle the mains cord
with wet hands.

• When the switch is in the OFF
position, the equipment is not
completely switched off from
MAINS.

• The equipment shall be
installed near the power supply
so that the power supply is
easily accessible.
