FSLR BOM
y
y
j
Acufit P/N Description Q'ty
04-1656 Tower Frame 1
06-0108 Rectangular End Cap - 2 x 3" 4
xx Warning Label 1
xx Serial # Label 1
04-1654 Foot Plate Ass
06-0391 Plastic Sleeve - 49 x 42 x 200L 2
06-0162 Round End Cap - 38mm 2
10-0233 Left Grip Tape 1
10-0233 Right Grip Tape 1
04-1652 Lat/Low Boom 1
06-0046 Hook Cover 2
06-0108 Rectangular End Cap - 2 x 3" 1
xx Warning Label 1
04-1364 Knee Hold Down 1
06-0058 Round End Cap - 1-1/4" 2
11-0075 Ball Knob Spring Pin 1
04-1368 Lat/Low Seat 1
08-0048 Bearing, Flange - 25.4 x 19.05 x 20h 4
06-0055 Rectangular End Cap - 1 x 2" 2
06-0108 Rectangular End Cap - 2 x 3" 1
04-1363 Lat/Low Frame 1
08-0048 Bearing, Flange - 25.4 x 19.05 x 20h 6
06-0390 Bumper 1
. 1
04-1366 Swivel Pulle
08-0061 Bearing, Flange - 19.45 x 12.8 x 18h 2
02-1321 Plate, 1/4 x 1-1/2 x 15-1/2" 4
02-1320 Plate, Knee Hold Down Ad
uster 1
1
Page 1 of 4
06-0129 Bumper 1
y
y
y
y
j
g
g
04-1655 Base 1
06-0108 Rectangular End Cap - 2 x 3" 1
02-1296 Plate, Dual Pulle
2
04-1653 Guide Rod Holder 1
06-0030 Socket Bushing - 25.4 x 21.2 x 49h 2
06-0024 Pulle
06-0025 Pulle
02-1304 L Pulle
05-0349 Cable Ad
- 3-1/2"OD 1
- 4-1/2"OD 8
Cover 4
ustment Sleeve 1
DAEC03809016NB Button Head Allen Screw - 3/8" x 90L 12
06-0304 Wei
ht Stack Cushion 2
01-2375 Guide Rod 2
06-0382 Plastic Washer 4
ACU10-0204ASY
Head Plate + 20 Plate Stem 1
06-0376 Bearing, Sleeve 22.8 x 20 x 15L 4
05-0324 Spring Pin 1
DC100000000NB E-Ring 1
11-0067 Weight Selector Pin 1
05-0212 13/16" Shaft Collar 2
06-0388 1-1/4 Shaft Collar 2
05-0348 Shaft, Pivot - 19 x 10 x 140L 5
07-0157 Seat Pad 1
10-0215 Roller Pad 2
08-0085 3/8 x 19/32"H Flan
e Spacer 8
05-0350 Shaft, Pivot - 16 x 10 x 14.5L 1
DA1C03804316NU Hex Bolt - 3/8" x 43L 5
DA1C03805016NU Hex Bolt - 3/8" x 50L 4
DC1250100020U
Washer - 3/8" x 2.0t ZINC 6
DA1C03806716NU Hex Bolt - 3/8" x 67L 4
DA1C03807016NU Hex Bolt - 3/8" x 70L 4
Page 2 of 4
