Leica M50

Leica M60

Leica M80

User Manual

General Instructions

Safety concept

Before using your microscope for the first time, please read the "Safety concept" brochure included with your instrument. It contains additional information about handling and care.

Use in clean rooms

The Leica M series can be used in clean rooms without any problems.

Cleaning

Do not use any unsuitable cleaning agents, chemicals or techniques for cleaning.

Never use chemicals to clean colored surfaces or accessories with rubberized parts. This may damage surfaces and abraded particles may contaminate preparations.

In most cases, we can provide special solutions on request. Some products can be modified, and we can offer other accessories for use in clean rooms.

Servicing

Repairs may only be carried out by Leica Microsystems-trained service technicians. Only original Leica Microsystems spare parts may be used.

Responsibilities of person in charge of instrument

Ensure that the Leica stereomicroscope is operated, maintained and repaired by authorized and trained personnel only.

Leica M-series

User Manual

2







Important Safety Notes

User Manual

The individual modules of the Leica M stereomicroscopy series include an interactive CD-ROM with all relevant user manuals in 20 other languages. Keep it in a safe place, and readily accessible to the user. User manuals and updates are also available for you to download and print from our web site at www.stereomicroscopy.com.

This operating manual describes the special functions of the individual modules of the Leica M stereomicroscopy series and contains important instructions for their operational safety, maintenance, and accessories.

The"Safetyconcept"bookletcontainsadditional safety information regarding the service work, requirements and the handling of the stereomicroscope, accessories and electrical accessories as well as general safety instructions­ .

You can combine individual system articles with articles from external suppliers (e.g. cold light sources, etc.). Please read the user manual and the safety requirements of the supplier.

Before installing, operating or using the instruments, read the user manuals listed above. In particular, please observe all safety regulations.

To maintain the unit in its original condition and to ensure safe operation, the user must follow the instructions and warnings contained in these user manuals.

Leica M-series

User Manual

3







Symbols Used

Warning of a danger

This symbol indicates especially important information that must be read and

complied with.

Failure to comply can cause the following:Hazards to personnel

Functional disturbances or damaged ­instruments

Warning of hazardous electrical voltage

This symbol indicates especially important information that is mandatory to

read and observe.

Failure to comply can cause the following:Hazards to personnel

Functional disturbances or damaged instruments­

Danger due to hot surface.

This symbol warns against touching hot surfaces, e.g. those of light bulbs.

Important information

This symbol indicates additional information or explanations that are intended to

provide clarity.

Explanatory notes

This symbol within the text stands for additional information and explanations.

Figures

(1)Numbers in parentheses within the descriptions relate to the figures and the items within those figures.

Leica M-series

User Manual

4







Safety Regulations

Description

The individual modules fulfill the highest requirements for observation and documentation of Leica stereomicroscopes of the M series.

Designated use

Refer to "Safety Concept" booklet

Non-intended use

Refer to "Safety Concept" booklet

Never use M series microscopes or their components for surgical procedures (e.g. on the eye) unless they are specifically intended for that purpose.

The instruments and accessories described in this operating manual have been tested for safety and potential hazards. The responsible Leica affiliate must be consulted whenever the instrument is altered, modified or used in conjunction with non-Leica components that are outside of the scope of this manual.

Unauthorized alterations to the instrument or noncompliant use shall void all rights to any warranty claims!

Place of use

Refer to "Safety Concept" booklet

Set up the electrical components at least 10 cm from walls and combustible objects.

Avoid large temperature fluctuations, direct sunlight and vibrations. These conditions can distort measurements and micrographic images.

In warm and warm-damp climatic zones, the individual components require special care in order to prevent the buildup of fungus.

Responsibilities of person in charge of instrument

Refer to "Safety Concept" booklet

Ensure that:

The M series stereomicroscopes and accessories are operated, maintained and repaired by authorized and trained personnel only.

All operators have read, understood and observe this User Manual, and particularly the safety regulations.

Leica M-series

User Manual

5







Safety Regulations (cont'd.)

Repairs, service work

Installation in third-party products

assignments and work flow (changing tasks

Refer to "Safety Concept" booklet

Refer to "Safety Concept" booklet

frequently), thorough training of the personnel,





giving consideration to ergonomic and organi-

Only original Leica Microsystems spare

Disposal

zational aspects.

parts may be used.

Refer to "Safety Concept" booklet

The ergonomic design and construction of the





Leica M stereomicroscopy series are intended to

Before opening the instruments, switch off

Legal requirements

reduce the exertion of the user to a minimum.

the power and unplug the power cable.

Refer to "Safety Concept" booklet







Direct contact with eyepieces can be a potential

Touching the live circuit can cause injury.

EC Declaration of Conformity

transmission path for bacterial and viral infec-



Refer to "Safety Concept" booklet

tions of the eye.

Transport



The risk can be kept to a minimum by using

Use the original packaging for shipping or

Health risks

personal eyepieces for each individual or

transporting the individual modules of the

Workplaces equipped with stereomicroscopes

detachable eyecups.

Leica M stereomicroscopy series and the

facilitate and improve the viewing task, but



accessory components.

they also impose high demands on the eyes





and holding muscles of the user. Depending



In order to prevent damage from vibrations,

on the duration of uninterrupted work, asthe-



disassemble all moving parts that (accord-

nopia and musculoskeletal problems may



ing to the user manual) can be assembled

occur. For this reason, appropriate measures



and disassembled by the customer and

for reduction of the workload must be taken:



pack them separately.

optimal arrangement of workplace, work



Leica M-series

User Manual

6







Safety Regulations (cont'd.)

Light sources: safety regulations

Protective measures of the manufacturer:

UV protection screen in front of the specimen plane prevents the user from looking directly into the UV rays.

Dummy filter carriers in the free positions of the rapid filter changer prevent direct UV radiation from reaching the eyes.

UV filters are installed in the observation beam paths to protect the eyes.

The stray-light protection on the lamp housing prevents irradiation of the hands.

Warning

UV radiation could damage the eyes. ­Therefore:

Never look into the light spot on the specimen plane without a UV protection screen.

Never look into the eyepieces if no excitation filter is in the beam path.

Fill empty filter positions with dummy filter carriers (e.g. M165 FC).

Do not select a white, strongly reflective background for the specimen.

Supply unit

Always unplug the supply unit from the power supply:

When installing and disassembling the lamp housing

Before opening the lamp housing

When replacing the high-pressure mercury lamp and other parts, such as the heatabsorbing filter or the collector

During maintenance work on the supply unit

Leica M-series

User Manual

7







Safety Regulations (cont'd.)

Lamp housing

Never open the lamp housing while the lamp is switched on. Risk of explosion, UV exposure, blinding!

Before opening the lamp housing, allow it to cool off for at least 15 minutes. Danger of explosion!

Never cover the air duct on the lamp housing. Danger of fire!

Mercury lamp

Follow the user manual and safety regulations provided by the lamp manufacturer, and, in particular, the section on how to proceed if a lamp breaks and releases mercury.

For transport, remove the mercury lamp, transport it in its original packaging and protect moving parts in the lamp housing using the transport anchors.

When it has reached the end of its rated life (follow the manufacturer's specifications and the minute meter on the supply unit).

To minimize the risk of explosion, replace a discolored mercury lamp promptly.

Leica Microsystems assumes no liability for damage caused by exploding, incorrectly installed or improperly used mercury lamps.

Leica M-series

User Manual

8







Table of Contents

Inhaltsverzeichnis

General Instructions

2

Important Safety Notes

3

Symbols Used

4

Safety Regulations

5

Safety Regulations (cont'd.)

6

Safety Regulations (cont'd.)

7

Safety Regulations (cont'd.)

8





M series



Congratulations!

12

The Modular Design: Everything is Relative

13

Maximum Compatibility

14

On We Go

15





Assembly



Base and Focusing Column

17

Microscope Carrier

18

Optics Carrier

19

Tube

20

Eyepieces

21

Objective

22

Leica LED5000 CXI (Coax Illumination)

23





Leica LED5000 CXI (cont'd.)

24

Leica LED3000 NVI™ (Near Vertical Illumination)

25

Leica LED3000 NVI™ (cont'd.)

26





Quick Start Guide



The Reliable Route to Success

28

Overview of an M Series Microscope

29

The Correct Interpupillary Distance

30

Using the Eyepieces

31

Focusing

32

Adjusting the Resistance of the Focus Drive

33

Changing the Magnification (Zoom)

34

Ratchet Steps and Magnification Levels

35





Eyepieces & Tubes



Magnification Factor of the Eyepieces

37

Health Notes

38

Dioptric Correction

39

Dioptric Correction and Parfocality

40

Graticules

41

ErgoTube 10° to 50°

42

Leica M-series

User Manual

9







Photography & Video



Photography & Video

44

Photo Tubes and C-mounts

45

Video/Phototubes HD F & HD V

46





Optical Accessories



The Different Types of Objectives

48





System Illumination



Leica LED3000 NVI™ (Near Vertical Illumination)

50

Leica LED5000 CXI (Coax Illumination)

51





Dimensional Drawings



Leica M50

53

Leica M50

54

Leica M50

55

Leica M60

56

Leica M80

57

Leica M80

58

Leica M80

59

Leica M80

60

Leica M80

61













Appendix



Calculating the Total Magnification and Field of View Diameter

63

Care, Maintenance, Contact Persons

64

Care, Maintenance, Contact Persons (cont'd.)

65







Leica M-series

User Manual

10







The Leica M series

Leica M-series

User Manual

11







Congratulations!

The New Leica M Series

The introduction of the Leica M50, M60 and M80 adds three new highquality routine stereomicroscopes to the proven M-Series range from Leica ­Microsystems. The optical brilliance and the wide range of accessories make them the ideal microscope for quality assurance and similar industrial applications.

Magnification in stages or zoom

The Leica M50 stereomicroscope includes precisely reproducible magnification levels for repeated examinations, measurements, drawing or photography of objects under absolutely identical conditions. The five easily selectable positions can be set without removing the eyes from the eyepieces. This ensures that your results remain comparable at all times without great efforts.

The Leica M60 and M80 stereomicroscopes can be used for a wide range of routine applications with the 6:1 / 8:1 zoom and switchable ratchet steps. The large working­ distance and the brilliant imaging power shows you the finest details of your specimens without losing your overview of large workpieces.

Common to all microscopes is the Leica range of accessories. Whether you need a variety of illumination types, a wide selection of objectives or the Leica swinging-arm system – there is a solution for everything there!

Do you already own stereomicroscopic equipment and are thinking of switching to Leica? No problem! Leica M50, M60 and M80 fit into microscope carrier with a diameter of 76 mm and are therefore compatible with many suppliers. You can simply continue to use your components and add the proven Leica stereomicroscopes.

Leica M-series

User Manual

12







The Modular Design: Everything is Relative

The Leica M series provides maximum flexibility in choosing equipment, thanks primarily to the modular configuration and the compatibility that Leica has painstakingly maintained for decades. The optics carriers, eyepieces, bases and more can be combined in any way you choose, allowing you to create the microscope that best suits your needs.

Despite this, you will notice that the controls and individual components do not differ significantly. Whichever configuration you choose, you will quickly feel right at home.

Have a special request? Let us know!

Leica Microsystems enjoys an exceptional reputation when it comes to devising customer-

specific solutions. If you have a special request that cannot be met with standard parts, contact your Leica consultant. We have a solution for every problem.

Leica M-series

User Manual

13







Maximum Compatibility

Leica engineers were careful to ensure that the new Leica M series—like its predecessors— remains compatible with existing series. This means that objectives, bases, tubes and so on can be reused.

Objectives

All objectives of this new generation have the same reference focal length as the objectives of the MZ generation. If you prefer, you can therefore continue to use the previous Leica objective series.

Tubes

The interface between the optics carrier and the tube has remained the same, so existing tubes fit the new M series. The new tubes are designed for eyepieces with field number 23, while the predecessor models were only designed for field number 21, resulting in a smaller object field.

Eyepieces

The new M-series eyepieces have an audible and tangible click to provide immediate feedback in case of accidental adjustment.

Leica M-series

User Manual

14







On We Go

If your new Leica microscope has already been assembled and commissioned by your Leica consultant, click here to skip through the installation instructions and go directly to the Quick Start Guide on Page 29.

If, on the other hand, you are assembling the microscope yourself, continue with the "Assembly" chapter, which begins on Page 16.

Leica M-series

User Manual

15







Assembly

Leica M-series

User Manual

16







Base and Focusing Column

The first step is to connect the focusing column

Assembling the column adapter

2. Install the base on the column using the

of the M series to the corresponding base.

1. Remove the three screws provided from the

three screws.



column.















Tools used

















Hex socket screwdriver, 3 mm



















































Tip: Place the column on the edge of a table to attach the base and have another person help you.

Leica M-series

User Manual

17







Microscope Carrier

Tools

Alternative installation options

Allen screwdriver provided

Depending on the desired working distance, the



microscope carrier can be installed in the stan-



dard way or upside down (see figure below).

Assembly



The microscope carrier is fastened to the column



using the screw provided.



Leica M-series

User Manual

18







Optics Carrier

Tools used

Assembling the optics carrier

None

1. Unscrew the clamping screw on the holder



for the optics carrier.

2. Place the optics carrier into the holder and align it in such a way that the notch in the optics carrier and the bottom clamping screw are on top of each other.

2.Tighten the clamping screw below the optics carrier.

Leica M-series

User Manual

19







Tube

All intermediate tubes that fit between the optics carrier and the binocular tube are fitted in the same manner.

Tools used

No tools required.

Preparation

1.Unscrew the positioning screw and remove the protective cover.

Assembling the tube

2.Push the tube (for example, the inclined binocular tube) into the dovetail ring and rotate it slightly in both directions until the positioning screw meshes with the guide groove.

3. While holding the tube only slightly, carefully tighten the positioning screw. It is automatically brought to the correct position­ .

Leica M-series

User Manual

20







Eyepieces

Tools used

Preparation

Inserting the eyepieces

No tools required.

1.

If you want to use an optional graticule,

3. Push the eyepieces into the tubes as far as





insert it now (Page 43).

they will go and check to ensure that they

Magnification range









fit tightly and accurately.

You can extend the overall magnification range

2.

Remove the plastic tube guard.



using available 10×, 16×, 25× and 40× wide-











field eyepieces for persons wearing glasses.











4. Securely tighten the clamping screws.

Leica M-series

User Manual

21







Objective

Tools used

No tools required.

Preparation

1.Remove the protective cap on the optics carrier by turning it.

Attaching the objective

Hold the objective firmly during assembly and disassembly so that it does not

fall onto the stage plate. This applies particularly to the 2x planapochromatic objective, which is very heavy. Remove all specimens from the stage plate first.

2.Screw the objective clockwise into the optics carrier.

Leica M-series

User Manual

22







Leica LED5000 CXI (Coax Illumination)

Required tools

Installing the Leica LED5000 CXI

None

1. Connect the Leica LED5000 CXI to the



focusing column via the CTL2 connection if



the focusing column is equipped with inte-



grated electronics.

2.Unscrew the positioning screw and remove the protective cover.

Alternative installation for manual columns

1.Connect the external power supply unit (10 450 266) to the Leica LED5000 CXI.

Leica M-series

User Manual

23







Leica LED5000 CXI (cont'd.)

3.Place the Leica LED5000 CXI on the optics carrier and tighten the positioning screw.

4.Push the tube (for example, the inclined binocular tube) into the dovetail ring and rotate it slightly in both directions until the positioning screw meshes with the guide groove.

5. While holding the tube only slightly, carefully tighten the positioning screw. It is automatically brought to the correct position­ .

Leica M-series

User Manual

24







Leica LED3000 NVI™ (Near Vertical Illumination)

Required tools

Installing the Leica LED3000 NVI™

Alternative installation for manual columns

None

1. Connect the Leica LED3000 NVI™ to the

1.

Connect the external power supply unit



focusing column via the CTL2 connection if



(10 450 266) to the Leica LED3000 NVI™.



the focusing column is equipped with inte-





The Leica LED 3000 NVI™ can be used

grated electronics.

2.

Place the Leica LED3000 NVI™ on the optics

with any objectives that have an outer





carrier from below and tighten the locking

diameter of 58 mm.





screw.

The supported working distance is between 50 mm and 150 mm.

Leica M-series

User Manual

25







Leica LED3000 NVI™ (cont'd.)

Ensure that the locking screw of the illuminator and the locking screw of the

optics carrier are on a straight line, as otherwise image shading may occur.

Leica M-series

User Manual

26







Quick Start Guide

Leica M-series

User Manual

27







The Reliable Route to Success

Your Leica stereomicroscope has been delivered in completely assembled condition by your Leica partner, and naturally you want to get right to work. This manual will familiarize you with the finer details of your microscope. The following pages contain important, practical information that makes using it every day easier.

Take time to read it – it's worth it!

Leica M-series

User Manual

28







Overview of an M Series Microscope















1







































2















8



















3







9



























4



















































































10

























5













































6

























































7







1Eyepieces for spectacle wearers with dioptric correction and eyecups

2Fastening screws for the eyepieces

3Ergo tube

4Optics carrier

5Magnification changer (zoom)

6Interchangeable objective

7Incident-light base

8Column

9Cable duct with cover

10Coarse/fine focusing

Leica M-series

User Manual

29







The Correct Interpupillary Distance

The interpupillary distance is correctly set if you see a single circular image field when looking at a specimen.

If you are still a novice microscope user, you may need a short time to become accustomed to this. Not to worry—after a little while, it will become automatic.

Reference value

The distance between eye and eyepiece measures approx. 22 mm for 10/23B wide-field eyepieces for persons wearing glasses.

Adjusting the interpupillary distance

1.Look into the eyepieces.

2.Hold the eyepieces with both hands. Push the eyepieces together or separate them until you see a circular image.

3.Slowly approach the eyepieces with your eyes until you can see the complete image field without corner cutting.





Leica M-series

User Manual

30







Using the Eyepieces

The eyepieces form the connection between the tube and the eye of the observer. Simply push them into the tube and they are ready to use.

Each eyepiece offers a certain magnification factor that has a determinative effect on the total magnification. Furthermore, all Leica eyepieces can be equipped with practical graticules that enable measuring and quantifying of specimens.

Dioptric correction

A built-in dioptric correction is available for eyeglass wearers. For more information, refer to page 39.

If you do not wear glasses:

1.Hold the eyepiece firmly and rotate the eyecups forwards counterclockwise.

2.If an eyepiece is equipped with the integrated dioptric correction, turn the value to the "0" mark.

If you wear glasses:

1.Hold the eyepiece firmly and rotate the eyecups counterclockwise towards the rear, as otherwise the viewing distance is too great.

2.If an eyepiece is equipped with the integrated dioptric correction, turn the value to the "0" mark.

By the way, one benefit of viewing with eyeglasses is a drastically lower risk of bacterial transmission (see page 38). The soft material of the eyecup also ensures that your glasses will not be scratched, even if they contact the eyepiece.

Leica M-series

User Manual

31







Focusing

Focusing raises or lowers the stereomicroscope using the focusing drive. The specimen detail is brought into sharp focus as soon as it is in the focal point of the objective.

The focusing drive can be operated either leftor right-handed.

The coarse/fine adjustment carries a load of up to 15 kg.

The resolution of the coarse/fine adjustment is 1 µm.

Leica M-series

User Manual

32







Adjusting the Resistance of the Focus Drive

Adjusting the resistance

Is the focus movement too loose or too tight? Does the outfit tend to slide downwards? The resistance can be adjusted individually depending on the equipment weight and personal preferences as follows:

1.Grip the outer drive knobs with both hands and turn them towards each other until the desired resistance is reached during focusing­ .

Leica M-series

User Manual

33







Changing the Magnification (Zoom)

All M series microscopes have an integrated zoom. The name indicates the zoom range covered:



Leica M50

= 5 increments



Leica M60

= 6:1 zoom



Leica M80

= 8:1 zoom

The rotary knob for the zoom can be used either left or right-handed.

Zooming

1.Look into the eyepieces.

2.Focus on the specimen.

3.Rotate the magnification changer until the desired magnification is configured.

Leica M-series

User Manual

34







Ratchet Steps and Magnification Levels

The zoom button can optionally be operated either with or without ratchet steps. Continuous zoom is possible when the ratchet steps are disabled, which many users find convenient. On the other hand, when the ratchet steps are enabled, photographs, measurement results etc. can be reproduced more accurately.

Enabling and disabling ratchet steps

1.Push the button towards the knob to enable the ratchet steps.

2.Push the button away from the knob to disable the ratchet steps.

Magnifications and fields of view

The formula on page 62 provide additional information about the magnifications and field of view diameters, with consideration given to the position of the magnification changer and the eyepiece and objective combination used.

Leica M-series

User Manual

35







Eyepieces & Tubes

Leica M-series

User Manual

36

Magnification Factor of the Eyepieces

An eyepiece not only makes it possible to look passively into the microscope, but also has a critical effect on the maximum magnification. The magnification factor is between 10x and 40x.

The following eyepieces are available for the M series:

Magnification

Dioptric correction

Order number







10×

± 5 diopter settings

10 450 023







16×

± 5 diopter settings

10 450 024







25×

± 5 diopter settings

10 450 025







40×

± 5 diopter settings

10 450 026







Leica M-series

User Manual

37







Health Notes

Potential sources of infection

Direct contact with eyepieces is a potential transmission method for

bacterial and viral infections of the eye. The risk can be kept to a minimum by using individual eyepieces or detachable eyecups. Eyecups can be ordered separately. Please contact your Leica partner.

Separate eyecups are an effective way of preventing infections.

Leica M-series

User Manual

38







Dioptric Correction

All Leica eyepieces are also available with builtin dioptric correction, allowing the microscope to be used without glasses even by those with vision problems. The correction comprises ±5 diopter settings.

Using the Dioptric Correction

1.Set the dioptric correction of both eyepieces to the mid position ("0" diopter settings).

2.While wearing your glasses, look through the eyepieces and focus on the specimen.

3.Rotate both eyepieces to the maximum value of "+5".

4.Hold one eye closed and rotate the other eyepiece in "-" direction until the specimen appears sharp.

5.Then, open the other eye and correct the diopter settings until the image is uniformly sharp.

Leica M-series

User Manual

39







Dioptric Correction and Parfocality

Leicastereomicroscopesareparfocallymatched. The prerequisite for this is the correct setting of the diopters and the parfocality. The following adjustments only have to be carried out once by each user.

Preparation

Move the lever of the video/phototube to the "observation" position and open the diaphragm.

Adjusting

1.Set the dioptric correction for both eyepieces to "0".

2.Select the lowest magnification and focus on a flat specimen.

3.Select the highest magnification and readjust the sharpness.

4.Select the lowest magnification again, but do not look into the eyepieces.

6. Rotate the eyepieces counterclockwise in the "+" direction as far as they will go (+5 diopter settings).

7.Look into the eyepieces.

8.Slowly rotate each eyepiece individually in the "–" direction until each eye sees the object sharply imaged.

9.Select the highest magnification and refocus if necessary.

Now, if you adjust the magnification from the lowest to the highest level, the specimen is always brought into sharp focus. If not, repeat the process.

Leica M-series

User Manual

40







Graticules

Use

Leica graticules make length measurements and counting easier, particularly for workstations that are not equipped with a digital camera and LAS software.

The Leica graticules for length measurements and numbering are fitted in mounts and are inserted into the eyepieces.

1. Screw the insert off of the eyepiece.

2.Clamp the graticule on the insert, applying moderate pressure. Ensure that the graticule fits tightly.

3.Screw the insert and graticule firmly into place and replace the eyepiece in the tube.

4.You can now align the graticule by rotating the eyepiece in the tube and then tightening it using the clamping screw.

Leica M-series

User Manual

41







ErgoTube 10° to 50°

ErgoTube™ 10° to 50°

The ErgoTube™ with continuously adjustable viewing angle from 10° to 50° allows for optimum sitting posture. Users who work with the same stereomicroscope can adjust the viewing height to their height with a simple hand movement. If the head posture is changed, the viewingheight canalsobe readjustedwithouthaving to adjust the height of the chair. Special long tubes enable the user to maintain an upright posture. In order to safeguard against ESD, the ErgoTube™ has been constructed from antistatic materials.

Assembly

Assembly of the ErgoTube 10° to 50° is exactly the same as that of any other tube (see Page 20).

Handling

1.Then grasp the tubes with both hands and adjust the desired tilt.

Leica M-series

User Manual

42







Photography & Video

Leica M-series

User Manual

43







Photography & Video

For most microscope users, digital documentation has become an invaluable part of their work. Research results can be presented in an attractive manner; measurements on the digital image provide clarity and, in conjunction with the motorized IsoPro™ cross-stage, even images of large specimens can be captured step by step and automatically joined to create a new complete image.

Adapter

If camera control using the Leica Application Suite is not required, conventional mirror reflex and rangefinder cameras from third-party manufacturers can be used. For this purpose, Leica Microsystems offers a variety of adapters that can be used together with the 50% and 100% trinocular tubes.

Leica DFC cameras

However, if you require absolute control over the camera and need the capability for measurement, evaluation and more in addition to photography, the digital Leica DFC cameras are exactly right for you. Together with the Leica Application Suite, they provide virtually limitless freedom of use. For additional information about Leica cameras, refer to the camera's documentation.

Leica Application Suite

The "Leica Application Suite", or "LAS" for short, is, as it were, the digital extension of the Leica M series microscopes. In addition to capturing images, it lets you control the microscope, illuminator, stages, cameras and more. For additional information, refer to the LAS online help.

Leica M-series

User Manual

44







Photo Tubes and C-mounts

Application

All Leica DFC cameras are equipped with a standardized C-mount interface. In turn, the C-mount adapter for the respective trinocular tube is connected to this interface. This adapter creates a solid mechanical connection between the microscope and camera and ensures optimum rendering of the microscopic image on the image sensor of the camera.

Usually, the ideal is for the digital camera to capture as much of the field of vision as possible, while excluding as much of the black edge of the field of vision as possible. To do so, the magnification factor of the C-mount adapter must match the image format of the sensor as closely as possible (see table).

If there is unwanted shading at the corners even with a compatible C-mount adapter installed, it can be corrected using the "Shading function" of the camera software.

Alternatively, you can also use a C-mount adapter with higher magnification. This primarily avoids the critical border area of the field of vision and concentrates on the center of the field of vision.

Camera

optimal

suitable



(large

(smaller



image field)

image field)







DFC295

0.5×

0.63×

DFC290 HD











DFC425

0.5×

0.63×

DFC425 C











DFC495

0.63×

0.8×







DFC500

0.63×

0.8×







Cameras from third-party suppliers

In addition to Leica DFC cameras with the standardized C-mount interfaces, you can connect third-party cameras to the microscope using a T2 bayonet adapter. To do so, instead of the C-mount adapter, simply use the corresponding SLR adapter with T2 connection. However, these third-party cameras are not integrated into the Leica Application Suite and have to be operated using the corresponding software from the camera manufacturer.

The Leica digital cameras are detailed in a separate user manual along with instructions for their assembly and use.

Leica M-series

User Manual

45







Video/Phototubes HD F & HD V

The video/phototubes HD F and HD V are optimized for adapting state-of-the-art digital cameras to obtain perfect results for image acquisition. The video/phototubes can be combined with the binocular tubes and the ErgoModules™ from the Leica ergonomics line. A range of high-quality video objectives with different self-magnifications and C-mount allows for the selection of different cameras.

Separation ratios

The HD V allows for selecting three different separation ratios:

50% light at all outputs, i.e. 50% light for stereoscopic observation and recording at 50% light.

100% light in the right eyepiece for monitoring the object and 100% light in the camera to have the maximum light for the recording under extremely poor light conditions.

Three-dimensional observation with 100% light in the binocular tube.

The HD F features a fixed separation ratio of 50% in the binocular tube and 50% in the photo beam path. This allows the user to conduct three-dimensional observations of the samples in the binocular tube, manipulate and edit them and simultaneously project the image live on the monitor. Since the sensors of state-of-the- art cameras are highly sensitive, the exposure time for most applications is short in spite of lower light intensity.

Videotube HD V

Phototube HD F

Leica M-series

User Manual

46







Objectives and

Optical Accessories

Leica M-series

User Manual

47







The Different Types of Objectives

To meet the various requirements regarding imaging properties, there is a choice of highquality interchangeable planachromatic and planapochromatic objectives and also lowerpriced interchangeable achromatic objectives.

Achromatic objectives are particularly suited for specimens with high-contrast structures.

Flat-field (planachromatic) objectives are particularly well suited for studying flat objects such as wafers and thin sections.

With planapochromatic objectives, the finest structures are visible with high contrast. The sophisticated apochromatic correction allows these objectives to attain the highest color brilliance and fidelity.

Achromatic objectives

The 0.32×, 0.5×, 0.63×, 0.8×, 1×, 1.5×, 2× achromatic objectives offer countless variants for selecting the object field diameter, magnification ranges and working distances (see page 63).

Planachromatic objective 1×

For the highest requirements for overall image quality, we recommend equipping the microscope with the 1× plan (flat-field) objective, which returns sharp, contrast-rich object fields.

Achromatic objectives with a long focal length:

For special applications achromatic objectives with long working distances and focal lengths of f=100 mm to 400 mm are available.

Leica M-series

User Manual

48







System Illumination

Leica M-series

User Manual

49







Leica LED3000 NVI™ (Near Vertical Illumination)

The intensity of the illuminator can be adjusted in 10 increments.

The Leica LED3000 NVI™ can also be controlled via the Leica Application Suite

(LAS) or the Leica SmartTouch.

The supported working distance is between 50 mm and 150 mm.

Use

The light of the Leica LED3000 NVI™ can be very bright. Therefore, always switch

on the illuminator before you look through the eyepieces!

1.Switch on the illuminator by briefly pressing the(ON/OFF) button.

2.Adjust the brightness by briefly pressing theorbuttons.

3.Switch off the illuminator by briefly pressing thebutton.

The green LED on the upper left corner now lights up.

Leica M-series

User Manual

50







Leica LED5000 CXI (Coax Illumination)

The intensity of the illuminator can be adjusted in 10 increments.

The Leica LED3000 NVI™ can also be controlled via the Leica Application Suite

(LAS) or the Leica SmartTouch.

Using the Leica LED5000 CXI results in an increased magnification level of 1.5×.

Depending on the components used, different intensities of vignetting may occur at low magnification. Vignetting is normal

and not a malfunction.

Use

2.

Adjust the brightness by briefly pressing

The light of the Leica LED5000 CXI can



the or

buttons.

be very bright. Therefore, always switch







on the illuminator before you look through the

3.

Switch off the illuminator by briefly press-

eyepieces!



ing the

button.

1. Switch on the illuminator by briefly pressing the(ON/OFF) button.

The green LED on the upper left corner now lights up.

Leica M-series

User Manual

51







Dimensional Drawings

Leica M-series

User Manual

52







Leica M50

Leica M50 with small incident-light base, transmitted-light base, Leica L2 illumination and 45° binocular tube

54













300

321





315

436

390



134









277





105

90













66

87





205



277







54











220



390







205

Leica M-series



User Manual







53

Leica M50

Leica M50 with large incident-light base and ErgoTube® 45°

278

Leica M-series

514 500

24





255



436

322





301

116

119







54



301

278



User Manual

54

Leica M50



Leica M50 with small swinging-arm stand and 45° binocular tube



54



260

500





345



173



170



709

260



54

220

Leica M-series

User Manual

55

Leica M60

Leica M60 with large incident light base and 45° binocular tube

54







66







330

24

116

119



278







301



255



288

301

54



278



Leica M-series

User Manual

56







Leica M80

Leica M80 with large incident-light base and 45° binocular tube

54







66







395

324





24

116

119



278

301







255



288

301

54



278



Leica M-series

User Manual

57

Leica M80

Leica M80 with transmitted-light base TL ST and binocular ErgoTube®

606 500

21

106

420 430

290

154

154

340

85

356

Leica M-series

User Manual

58

Leica M80



Leica M80 with standard swinging-arm stand and 45° binocular tube



54





598

470

345



173



230

794

330

54

220

Leica M-series

User Manual

59

Leica M80

Leica M80 with Leica LED2500 and binocular ErgoTube®

257

300



109

100

42

331

426

231

max.



min. 290 331

54

257

Leica M-series

User Manual

60

Leica M80

Leica M80 with universal stand, XL extension and binocular ErgoTube®

292

400







600

631





420





290

max.





min.





369

83.4









54

28.5

600





Leica M-series

User Manual

61

Appendix

Leica M-series

User Manual

62







Calculating the Total Magnification and Field of View Diameter

Parameter

MO

Magnification of objective





ME

Magnification of eyepiece





z

Magnification changer position





q

Tube factor, e.g. 1.5× for coaxial incident light, 1.6× for 45°



ErgoTube™

rFactor 1.25x if the planachromatic and planapochromatic objectives of the MZ125/MZ16 are used on the MS5, MZ6, MZ75 or MZ95

NFOV Field number of the eyepiece. Field numbers are printed on the eyepieces: 10× = 21, 16× = 14, 25× = 9.5, 40× = 6.

Example

MO

1× objective





ME

25×/9.5 eyepiece





z

Zoom position 4





q

Coaxial reflected light 1.5×, tube factor





r

Factor 1.25×





Calculation example: magnification in binocular tube

MTOT VIS = MO × ME × z × q × r or

1 × 25 × 4 × 1.5 × 1.25 = 187.5×

Calculation example: field of view diameter in the specimen

OF:

NFOV

MO × z ×q ×r

Leica M-series

User Manual

63







Care, Maintenance, Contact Persons

We hope you enjoy using your high-perfor-

Contact address

Care

mance microscope. Leica microscopes are

However, if your instrument should no longer

Protect your microscope from moisture,

renowned for their robustness and long service

function properly, contact your technician,

fumes and acids and from alkaline, caustic

life. Observing the following care and clean-

your Leica representative or Leica Microsystems

and corrosive materials and keep chemicals

ing tips will ensure that even after years and

(Schweiz) AG, CH-9435 Heerbrugg.

away from the instruments.

decades, your Leica microscope will continue to





work as well as it did on the very first day.



Plugs, optical systems and mechanical parts



E-mail contact:

must not be disassembled or replaced,

Warranty benefits

stereo.service@leica-microsystems.com

unless doing so is specifically permitted

The guarantee covers all faults in materials



and described in this manual.

and manufacture. It does not, however, cover





damage resulting from careless or improper



Protect your microscope from oil and

handling.



grease.





Do not grease guide surfaces or mechani-





cal parts.

Leica M-series

User Manual

64







Care, Maintenance, Contact Persons (cont'd.)

Protection from dirt

Dust and dirt will affect the quality of your results.

Put a dust cover over the microscope when it will not be used for a long time.

Use dust caps to protect tube openings, tubes without eyepieces, and eyepieces.

Keep accessories in a dust-free place when not in use.

Cleaning polymer components

Some components are made of polymer or are polymer-coated. They are, therefore, pleasant and convenient to handle. The use of unsuitable cleaning agents and techniques can damage polymers,

Permitted measures

Clean the microscope (or parts of it) using warm soapy water, then wipe using distilled water.

For stubborn dirt, you can also use ethanol (industrial alcohol) or isopropanol. When doing so, follow the corresponding safety regulations.

Remove dust with a pneumatic rubber bulb or with a soft brush.

Clean objectives and eyepieces with special optic cleaning cloths and with pure alcohol­ .

Leica M-series

User Manual

65
