LD Systems ECO 2X2 User Manual [en, de, fr, es, pl, it]

USER´S MANUAL
BEDIENUNGSANLEITUNG
MANUEL D`UTILISATION
MANUAL DE USUARIO
INSTRUKCJA OBSŁUGI
MANUALE D‘ USO

LD WSECO2 / LD WSECO2X2

UHF WIRELESS SYSTEMS

1

ENGLISHDEUTSCHFRANCAIS

You‘ve made the right choice!

We have designed this product to operate reliably over many years. LD Systems stands for this with its name and
many years of experience as a manufacturer of high-quality audio products.

Please read this User‘s Manual carefully, so that you can begin making optimum use of your LD Systems product
quickly.

You can find more information about LD SYSTEMS at our Internet site WWW.LD-SYSTEMS.COM

ESPAÑOLPOLSKIITALIANO

FRANCAISFRANCAIS

FRANCAISFRANCAIS

2

LD WSECO2 / LD WSECO2X2

UHF WIRELESS SYSTEMS

FRANCAIS

FRANCAIS

ENGLISH

DEUTSCH
FRANCAIS

FRANCAIS

FRANCAIS

ESPAÑOL

POLSKI

ITALIANO

3

PREVENTIVE MEASURES:

1. Please read these instructions carefully.

2. Keep all information and instructions in a safe place.

3. Follow the instructions.

4. Observe all safety warnings. Never remove safety warnings or other information from the equipment.

5. Use the equipment only in the intended manner and for the intended purpose.

ENGLISHDEUTSCHFRANCAIS

6. Use only sufficiently stable and compatible stands and/or mounts (for fixed installations). Make certain that wall
mounts are properly installed and secured. Make certain that the equipment is installed securely and cannot fall down.

7. During installation, observ e the applicable safety regulations for your country.

8. Never install and operate the equipment near radiators, heat registers, ovens or other sources of heat. Make certain
that the equipment is always installed so that is cooled sufficiently and cannot overheat.

9. Never place sources of ignition, e.g., burning candles, on the equipment.

10. Ventilation slits must not be blocked.

11. Do not use this equipment in the immediate vicinity of water (does not apply to special outdoor equipment ­in this case, observe the special instructions noted below. Do not expose this equipment to flammable materials,
fluids or gases.

12. Make certain that dripping or splashed water cannot enter the equipment. Do not place containers filled with
liquids, such as vases or drinking vessels, on the equipment.

13. Make certain that objects cannot fall into the device.

14. Use this equipment only with the accessories recommended and intended by the manufacturer.

15. Do not open or modify this equipment.

16. After connecting the equipment, check all cables in order to prevent damage or accidents, e.g., due to
tripping hazards.

17. During transport, make certain that the equipment cannot fall down and possibly cause property damage and
personal injuries.

18. If your equipment is no longer functioning properly, if fluids or objects have gotten inside the equipment or
if it has been damaged in anot her way, switch it off immediately and unplug it from the mains outlet (if it is a
powered device). This equipment may only be repaired by authorized, qualified personnel.

19. Clean the equipment using a dry cloth.

ESPAÑOLPOLSKIITALIANO

20. Comply with all applicable disposal laws in your country. During disposal of packaging, please separate
plastic and paper/cardboard.

21. Plastic bags must be kept out of reach of children.

Avoid direct sunlight!

FOR EQUIPMENT THAT CONNECTS TO THE POWER MAINS:

22. CAUTION: If the power cord of the device is equipped with an earthing contact, then it must be connected to
an outlet with a protective ground. Never deactivate the protective ground of a power cord.

FRANCAISFRANCAIS

FRANCAISFRANCAIS

23. If the equipment has been exposed to strong fluctuations in temperature (for example, after transport), do
not switch it on immediately. Moisture and condensation could damage the equipment. Do not switch on the
equipment until it has reached room temperature.

24. Before connecting the equipment to the power outlet, first verify that the mains voltage and frequency match
the values specified on the equipment. If the equipment has a voltage selection switch, connect the equipment to
the power outlet only if the equipment values and the mains power values match. If the included power cord or
power adapter does not fit in your wall outlet, contact your electrician.

25. Do not step on the power cord. Make certain that the power cable does not become kinked, especially at the
mains outlet and/or power adapter and the equipment connector.

26. When connecting the equipment, make certain that the power cord or power adapter is always freely
accessible. Always disconnect the equipment from the power supply if the equipment is not in use or if you want

4

SAFETY:

to clean the equipment. Always unplug the power cord and power adapter from the power outlet at the plug or
adapter and not by pulling on the cord. Never touch the power cord and power adapter with wet hands.

27. Whenever possible, avoid switching the equipment on and off in quick succession because otherwise this
can shorten the useful life of the equipment.

28. IMPORTANT INFORMATION: Replace fuses only with fuses of the same type and rating. If a fuse blows repea­tedly, please contact an authorised service centre.

29. To disconnect the equipment from the power mains completely, unplug the power cord or power adapter
from the power outlet.

30. If your device is equipped with a Volex power connector, the mating Volex equipment connector must be
unlocked before it can be removed. However, this also means that the equipment can slide and fall down if
the power cable is pulled, which can lead to personal injuries and/or other damage. For this reason, always be
careful when laying cables.

31. Unplug the power cord and power adapter from the power outlet if there is a risk of a lightning strike or
before extended periods of disuse.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION:

Never remove the cover, because otherwise there may be a risk of electric shock. There are no user serviceable
parts inside. Have repairs carried out only by qualified service personnel.

The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user
to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of electrical shock.

The exclamation mark within an equilateral triangle is intended to alert the user to the presence of
important operating and maintenance instructions.

FRANCAIS

FRANCAIS

ENGLISH

DEUTSCH
FRANCAIS

FRANCAIS

FRANCAIS

ESPAÑOL

CAUTION – HIGH VOLUME LEVELS WITH AUDIO PRODUCTS!

This equipment is intended for professional use. Therefore, commercial use of this equipment is subject to the
respectively applicable national accident prevention rules and regulations. As a manufacturer, Adam Hall is
obligated to notify you formally about the existence of potential health risks.
Hearing damage due to high volume and prolonged exposure: When in use, this product is capable of producing
high sound-pressure levels (SPL) that can lead to irreversible hearing damage in performers, employees, and
audience members. For this reason, avoid prolonged exposure to volumes in excess of 90 dB.

To prevent possible hearing damage, avoid listening at high volume levels over long periods of time.
Even exposure to short bursts of loud noise can result in hearing loss. Please keep the volume
constantly at a comfortable level.

POLSKI

ITALIANO

5

SYSTEM COMPONENTS WSECO2 SYSTEMS:

All sets include the following system components:

ENGLISHDEUTSCHFRANCAIS

ESPAÑOLPOLSKIITALIANO

FRANCAISFRANCAIS

FRANCAISFRANCAIS

Pocket transmitter

Receiver

Audio cable 6.3 mm mono jack to 6.3 mm mono jack

Power Supply

Batteries

Additionally, depending on the set, the following accessories are included:

LDWSECO2X2BPH - ECO2X2 Set with

pocket transmitter and headset

Headset

LDWSECO2HHD - ECO2 Set with handheld
transmitter

handheld transmitter with a

dynamic microphone capsule

LDWSECO2BPG - ECO2 Set with
pocket transmitter and guitar
cable

Pocket transmitterGuitar cable

6

-

-

SYSTEM COMPONENTS WSECO2X2 SYSTEMS:

All sets include the following system components:

FRANCAIS

FRANCAIS

ENGLISH

Dual receiver

Audio cable 6.3 mm mono jack to 6.3 mm mono jack

Additionally, depending on the set, the following accessories are included:

LDWSECO2X2BPH - ECO2X2 Set with
2 x pocket transmitters + 2 x headsets

or

+

Power Supply

+

Batteries

LDWSECO2X2HHD- ECO2X2 Set
with 2 x handheld transmitters

2 x handheld transmitter with a

dynamic microphone capsule

DEUTSCH
FRANCAIS

FRANCAIS

FRANCAIS

ESPAÑOL

POLSKI

2 x pocket transmitter

ITALIANO

2 x headset

7

CONNECTIONS, CONTROLS AND INDICATORS:

ECO2 RECEIVER

ENGLISHDEUTSCHFRANCAIS

5

ESPAÑOLPOLSKIITALIANO

FRANCAISFRANCAIS

FRANCAISFRANCAIS

8

1

6 7

2

3

4

8 9

CONNECTIONS, CONTROLS AND INDICATORS:

1

POWER LED

Lights up once the system is properly connected to the power mains and switched on (suitable power adapter included).

2

ANTENNA LEDS A / B

Indicate whether aerial input A or B is active.

3

NORM LED

Lights up as soon as an audio signal is present.

4

PEAK LED

Lights up if the receiver is operating at the distortion limit. To avoid distortion, reduce the signal level of the
transmitter unit.
Handheld Transmitter: Turn the GAIN knob with a suitable tool to the left.
Pocket Transmitter: 3-stage MIC / 0 dB / -10 dB switch, set to the next lowest value.

5

VOLUME

Volume controller of the receiver. Turning the knob to the right increases the volume and turning it to the left
decreases it.

6

AF OUTPUT

Balanced line output with XLR socket.

7

LOW VOLTAGE CONNECTOR

Connection for the voltage supply of the device. Please only use the power adapter included in the product package.

FRANCAIS

FRANCAIS

ENGLISH

DEUTSCH
FRANCAIS

FRANCAIS

FRANCAIS

ESPAÑOL

8

MUTE LEVEL

CAUTION: Before changing the Mute level, adjust the volume of the connected PA system to minimum.
The Mute function (noise reduction / Squelch) prevents any interference with the transmitter. In addition, sudden
noise is suppressed when the transmitted signal from the transmitter to the receiver is not strong enough.
With the transmitter switched off, adjust the Mute level with a suitable screwdriver so that noises are effectively
suppressed (when turned to the left, the noise reduction decreases, when turned to the right, it increases).
In unfavourable conditions, the transmission range may decrease when adjusting for strong noise reduction.
The Mute level controller is set to the left at the factory, therefore, the noise reduction is set at minimum strength.
This setting is suitable for the majority of applications and changes are only needed in rare cases.

9

UNBAL OUTPUT

Unbalanced line output with 6.3 mm jack.

POLSKI

ITALIANO

9

CONNECTIONS, CONTROLS AND INDICATORS:

ECO2X2 RECEIVER

ENGLISHDEUTSCHFRANCAIS

ESPAÑOLPOLSKIITALIANO

FRANCAISFRANCAIS

FRANCAISFRANCAIS

2

3

4 4

5 5

6 6

2

1

7

3

8

10

CONNECTIONS, CONTROLS AND INDICATORS:

1

POWER LED

Lights up once the system is properly connected to the power mains and switched on (suitable power adapter included).

2

RF-LED CH 1 / CH 2

Lights up when a radio signal is present on channel 1 (CH 1) or channel 2 (CH 2).

3

AUDIO LED

Lights up when a radio signal is present on channel 1 (CH 1) or channel 2 (CH 2).

4

VOLUME CH 1 / CH 2

Volume controller for the receiver on channel 1 (CH 1) or channel 2 (CH 2). Turning the knob to the right increases
the volume and turning it to the left decreases it.

5

AF OUTPUT CHANNEL 1 / CHANNEL 2

Balanced line output with XLR connector for the receiver on channel 1 (CH 1) or channel 2 (CH 2).

6

MUTE LEVEL CHANNEL 1 / CHANNEL 2

Mute controller for the receiver on channel 1 (CH 1) or channel 2 (CH 2).
CAUTION: Before changing the Mute level, adjust the volume of the connected PA system to minimum.
The Mute function (noise reduction / Squelch) prevents any interference with the transmitter. In addition, sudden
noise is suppressed when the transmitted signal from the transmitter to the receiver is not strong enough.
With the transmitter switched off, adjust the Mute level with a suitable screwdriver so that noises are effectively
suppressed (when turned to the left, the noise reduction decreases, when turned to the right, it increases).
In unfavourable conditions, the transmission range may decrease when adjusting for strong noise reduction.
The Mute level controller is set to the left at the factory, therefore, the noise reduction is set at minimum strength.
This setting is suitable for the majority of applications and changes are only needed in rare cases.

FRANCAIS

FRANCAIS

ENGLISH

DEUTSCH
FRANCAIS

FRANCAIS

FRANCAIS

ESPAÑOL

7

LOW VOLTAGE CONNECTOR

Connection for the voltage supply of the device. Please only use the power adapter included in the product package.

8

2 IN 1 MIX UNBAL OUTPUT

Unbalanced line output with 6.3 mm jack. The audio signal consists of a mix of signals from the channels 1 and 2
(CHANNEL 1 + CHANNEL 2). The volume ratio of the two channels can be adjusted using the volume knob (no. 4) of
channels 1 and 2.

POLSKI

ITALIANO

11

POCKET TRANSMITTER:

ENGLISHDEUTSCHFRANCAIS

ESPAÑOLPOLSKIITALIANO

A

8

514 3 2

k

c

a

p

y

d

o

B

F

H

U

6

Tra

1

TRANSMITTER ANTENNA

To ensure optimal radio transmission, do not touch,
bend or cover the antenna.

2

INPUT

3 pin mini XLR input for headset, lavalier and instrument
microphones, as well as guitar cable. A list of all models
is located in the specifications.

3

MIC / 0 DB / -10 DB

Adjust the input sensitivity.

r

itte

m

s

n

LDWSECO2: Adjust the sensitivity so that when a
signal is present (voice, vocals, guitar...), the green
signal LED (NORM) on the receiver lights up. As soon
as the red PEAK LED lights up, reduce the sensitivity
by turning the 3 stage MIC / 0 dB / -10 dB switch to
the next lowest value, otherwise unwanted distortion
may occur.
LDWSECO2X2: Adjust the sensitivity so that when a
signal is present (voice, vocals, guitar...), the green
signal LED (NORM) on the receiver lights up. As soon
as the audio signal begins to distort, reduce the

B

sensitivity by turning the 3 stage MIC / 0 dB / -10 dB
switch to the next lowest value.

4

ON / STANDBY / OFF

When the transmitter is turned on (switch is in
STANDBY / ON position), the red LED flashes briefly to
indicate the battery status and goes out immediately
if batteries with sufficient charge are inserted. In
STANDBY position, the transmitter is in operation, but
the audio signal is muted.

FRANCAISFRANCAIS

FRANCAISFRANCAIS

12

5

BATTERY STATUS LED

As soon as the red LED lights up to indicate the

7

battery status, replace the batteries immediately.

6

ATTACHING THE PACK TRANSMITTER

Attach the transmitter to a belt (Figure A) or guitar
strap (Figure B) as shown here.

7

BATTERY REPLACEMENT

As soon as the red LED lights up to indicate the
battery status, please replace the batteries by pres­sing down on the battery compartment cover at the
marked position (OPEN) and slide it to the side.
Insert two 1.5 V AA size alkaline batteries (LR6, AA)
as in the illustration on the transmitter back and
close the battery compartment cover by pressing the
marked position (CLOSE) of the cover and then slide
it to the side.
If the transmitter is not in use for a long period of time,
remove the batteries from the battery compartment.

8

CHARGE

Low voltage socket for 3.5 mm barrel connector for
charging size AA batteries ( + inside, - outside).

- Use only a charger suitable for the batteries used and
be aware of the maximum permissible charging time.

- Please note that batteries inserted in the battery
compartment are switched in series!

- Never try to charge non-rechargeable batteries

POCKET TRANSMITTER:

FRANCAIS

FRANCAIS

ENGLISH

DEUTSCH
FRANCAIS

FRANCAIS

FRANCAIS

Failure to comply with above instructions may result
in a fire or explosion hazard!

ESPAÑOL

POLSKI

ITALIANO

13

HANDHELD TRANSMITTER:

ENGLISHDEUTSCHFRANCAIS

1

2

3

ESPAÑOLPOLSKIITALIANO

1

MICROPHONE HEAD

With dynamic microphone capsule.

2

GAIN

Setting the microphone volume. Turning the knob to the right
increases the volume and turning it to the left decreases it.
LDWSECO2: Adjust the sensitivity so that when a signal is pre­sent (voice, vocals, guitar...), the green signal LED (NORM) on the
receiver lights up. As soon as the red PEAK LED lights up, reduce
the level accordingly, otherwise undesirable distortion may occur.
LDWSECO2X2: Adjust the sensitivity so that when a signal is
present (voice, vocals, guitar...), the green signal LED (NORM)

4

on the receiver lights up. Once the audio signal begins to
distort, reduce the level accordingly.

3

RF POWER H / L

For a majority of applications, set the switch to H (= high
power). To increase battery life, switch to L (= low power)
for applications with a small distance between transmitter
and receiver. Before the event, please check whether the low

5

6

transmission power is sufficient.

4

BATTERY COMPARTMENT

Insert two 1.5 V AA size alkaline batteries (LR6 Mignon) as in the
illustration inside the battery compartment. If the transmitter is
not in use for a long period of time, remove the batteries from
the battery compartment.

FRANCAISFRANCAIS

FRANCAISFRANCAIS

7

14

5

BATT LED

As soon as the red LED lights up to indicate battery status,
replace the batteries immediately.

6

ON/OFF SWITCH

When the transmitter is turned on, the red LED flashes briefly
to indicate the battery status and goes out immediately if
batteries with sufficient charge are inserted.

7

BATTERY REPLACEMENT

As soon as the red LED lights up for battery status display,
please replace the batteries by unscrewing the battery cover
counter-clockwise from the transmitter and after changing the
batteries screw it back on in the opposite direction.

OPTIMISATION OF THE RADIO TRANSMISSION:

• Aim the transmitter directly at the receiver ("line-of-sight" contact between the devices).

• Do not position the receiver near metal objects/surfaces or digital devices (CD players,

computers, etc.).

• Position the receiver so that it is not directly in front of a wall and is at least 1 m above

the floor.

• Mobile phones, two-way radios and the like, may affect the radio link between the transmitter and

recipient and should not be used near the transmitter.

FRANCAIS

FRANCAIS

ENGLISH

DEUTSCH
FRANCAIS

FRANCAIS

FRANCAIS

ESPAÑOL

POLSKI

ITALIANO

15

TROUBLESHOOTING:

PROBLEM DISPLAY SOLUTION

No audio signal or

ENGLISHDEUTSCHFRANCAIS

low level

ESPAÑOLPOLSKIITALIANO

FRANCAISFRANCAIS

FRANCAISFRANCAIS

Distortion and inter­ference

Distorted sound Transmitter: The red LED to indicate battery

Receiver ECO2: Neither antenna A nor
antenna B LED is lit.
Receiver ECO2X2: RF LED does not light up.

Receiver: Power LED is not lit Verify the power supply.
Receiver ECO2: Neither antenna A nor

antenna B LED is lit.
Receiver ECO2X2: RF LED does not light up.
Transmitter: Device is turned on. Charge
status of the batteries is ok.

Receiver ECO2: Antenna A or Antenna B
LED is lit.
Receiver ECO2X2: RF LED lights up.
Pocket Transmitter: The ON / STANDBY /
OFF switch is in the STANDBY position.

Receiver ECO2: Antenna A or Antenna B
LED is lit.
Receiver ECO2X2: RF LED lights up.
Receiver ECO2: Signal LED NORM is not lit
when an audio signal is present.
Receiver ECO2X2: Signal LED AUDIO
is not lit when an audio signal is present.

Receiver: Radio signal indicator lights up Remove possible sources of interference

status lights up.
Receiver ECO2: The red PEAK LED indicator
of the receiver lights up.

Verify that the transmitter is turned on.
Check the batteries in the transmitter.

Verify that transmitter and receiver have
the same radio frequency.

Bring the GAIN switch on the transmitter to
position H (= high power).

Reduce the distance between transmitter
and receiver.

Make sure that there is a direct line of
sight between the transmitter and receiver.

Make sure that the antennas of the receiver
are aligned upward and into a V-shape.

Reduce the amount of noise reduction
(MUTE LEVEL)

Turn the ON / STANDBY / OFF switch on the
transmitter to the ON position.

Increase the signal level or the sensitivity
of the transmitter.

(digital devices, other wireless systems).
Increase the level of noise reduction (MUTE
level) on the receiver.

Replace the batteries in the transmitter.
Reduce the signal level or the sensitivity of
the transmitter.

16

SPECIFICATIONS:

RECEIVER

Model name: LDWSECO2R LDWSECO2X2

Receiver type: diversity non diversity
Modulation: FM
Frequency range: 863.100 MHz - WSECO2R1

863.900 MHz - WSECO2R2

864.500 MHz - WSECO2R3

864.900 MHz - WSECO2R4
Channels: 1 2
Antenna connectors: Fixed Antenna
Frequency response: 60 - 16.000 Hz
Squelch: Mute Level
Signal-to-noise ratio: >105 dB
Balanced output: XLR 2 x XLR
Unbalanced output: 6.3 mm jack
Unbalanced mix output:
Audio output level (balanced): -12 dBV
Audio output level (unbalanced): -18 dBV
Controls: volume 2 x volume
Indicators: power, HF-indicator antenna A/B,

Operating voltage: 12 - 18 V DC, 300 mA 12 - 18 V DC, 300 mA
Operating temperature range: -10°C … 45°C
Relative humidity in operation: 25% … 85%
Dimensions (W x H x D): 235 x 44 x 118 mm
Weight: 0,4 kg 0,4 kg
Accessories included: power adapter, audio cable power adapter, audio cable

-

audio signal, peak

863.100 / 864.500 MHz ­WSECO2X2R1

863.900 / 864.900 MHz ­WSECO2X2R2

-

6.3 mm jack

power, RF-indicator channel 1 / 2,
audio signal channel 1 / 2

FRANCAIS

FRANCAIS

ENGLISH

DEUTSCH
FRANCAIS

FRANCAIS

FRANCAIS

ESPAÑOL

POLSKI

ITALIANO

17

SPECIFICATIONS:

HANDHELD TRANSMITTER

Model name: LDWSECO2MD

ENGLISHDEUTSCHFRANCAIS

Modulation: FM
Frequency range: 863.100 MHz - WSECO2MD1

863.900 MHz - WSECO2MD2

864.500 MHz - WSECO2MD3

864.900 MHz - WSECO2MD4
Channels: 1
Microphone type: dynamic
Polar pattern: cardioid
Frequency response: 60 - 16.000 Hz
RF output power: 10 mW
Controls: Power on/off, gain, HF power H / L
Indicators: battery low
Power supply: 2 x AA battery
Operating time: up to 10 h (depending on batteries)
Operating temperature range: -10°C … 45°C
Relative humidity range in operation: 25% … 85%
Dimensions (L x Ø): 250 x 53 mm
Weight: 0,28 kg
Accessories included: 2 x AA battery

ESPAÑOLPOLSKIITALIANO

FRANCAISFRANCAIS

FRANCAISFRANCAIS

18

SPECIFICATIONS:

BODYPACK TRANSMITTER

Model name: LDWSECO2BP

Modulation: FM
Frequency range: 863.100 MHz - WSECO2BP1

863.900 MHz - WSECO2BP2

864.500 MHz - WSECO2BP3

864.900 MHz - WSECO2BP4
Channels: 1
Input: 3-pin mini-XLR
Frequency response: 60 - 16.000 Hz
RF output power: 10 mW
Controls: On / Standby / Off, triple gain switch
Indicators: battery low
Power supply: 2 x AA batteries
Operating time: up to 10 h (depending on batteries)
Operating temperature range: -10°C … 45°C
Relative humidity range in operation: 25% … 85%
Dimensions (W x H x D): 65 x 85 x 23 mm
Weight (without batteries): 0,1 kg
Accessories included: 2 x AA battery

FRANCAIS

FRANCAIS

ENGLISH

DEUTSCH
FRANCAIS

FRANCAIS

FRANCAIS

ESPAÑOL

POLSKI

ITALIANO

19

SPECIFICATIONS:

MICROPHONE

Model name: LDWS100MH1 LDWS100MH3

ENGLISHDEUTSCHFRANCAIS

Microphone type: headset headset
Capsule: back-electret condenser back-electret condenser
Polar pattern: cardioid cardioid
Frequency response: 20 - 20.000 Hz 70 - 16.000 Hz
Connector: 3-pin mini-XLR 3-pin mini-XLR
Accessories included: foam windscreen foam windscreen
Features:

Model name: LDHSAE1 LDWS100ML

Microphone type: headset lavalier microphone
Capsule: back-electret condenser back-electret condenser
Polar pattern: bi-directional cardioid
Frequency response: 80 - 16.000 Hz 20 - 20.000 Hz
Connector: 3-pin mini-XLR 3-pin mini-XLR
Accessories included: foam windscreen foam windscreen
Features: water-repellent

Model name: LDWS1000MW LDHSM1

Microphone type: wind instrument microphone headset
Capsule: back-electret condenser back-electret condenser
Polar pattern: cardioid noise cancelling
Frequency response: 50 - 18.000 Hz 70 - 16.000 Hz

ESPAÑOLPOLSKIITALIANO

Connector: 3-pin mini-XLR 3-pin mini-XLR
Accessories included: foam windscreen foam windscreen
Features:

- -

-

-

water-repellent

FRANCAISFRANCAIS

FRANCAISFRANCAIS

Model name: LDWS100GC

Connector 1: 3-pin mini-XLR
Connector 2: 6.3 mm jack
Lenght: 1.5 m

GUITAR CABLE

20

MANUFACTURER´S DECLARATIONS:

MANUFACTURER‘S WARRANTY

This warranty extends to the LD SYSTEMS branded product you purchased from Adam Hall. The statutory warranty
rights against the vendor shall not be affected by this warranty. Rather, this warranty gives you additional independent
claims against Adam Hall.

FRANCAIS

FRANCAIS

ENGLISH

With this warranty, Adam Hall ensures that products you have purchased from Adam Hall or Adam Hall partners,
under normal use, are free of defects in material or workmanship for a period of 2 years from the date of purchase.
The warranty period begins on the date of purchase. In order to assert a claim for warranty service, the proof of
date of purchase is provided by the receipt bearing the date of purchase or the date of purchase on the delivery
note. You are entitled to warranty service under the conditions and provisions set out in this document, if a repair
within the warranty period is required.

This warranty applies only to the original purchaser of the products supplied by Adam Hall and is not transferable
to any person to whom the property is transferred by the original purchaser.
Within the warranty period, the defective parts or the product from Adam Hall will be repaired or replaced. Under
the terms of this warranty, all the replaced or removed components become the property of Adam Hall.

In the unlikely event that a product acquired from Adam Hall, repeatedly exhibits a defect, Adam Hall may decide,
at its discretion, to replace this product with a comparable product of at least the same performance.

Adam Hall does not guarantee that the operation of this product will be uninterrupted or error-free. Adam Hall
accepts no responsibility for any damage due to incorrect compliance with the instructions received in the delivery.

This warranty does not extend to:

- wearing parts (eg battery, tubes).

- devices that have had their serial number removed or damaged, or failed as a result of an accident

- inappropriate or abusive use or other external causes

- devices that were not used in accordance with the operating parameters defined in the user documentation
shipped with the product

- devices that have been repaired using parts not made or distributed by Adam Hall

- devices that have been serviced, modified or repaired by someone other than Adam Hall or an authorised service partner.
These terms and conditions constitute the complete and exclusive warranty agreement between you and Adam
Hall regarding the Adam Hall branded product you have purchased.

DEUTSCH
FRANCAIS

FRANCAIS

FRANCAIS

ESPAÑOL

POLSKI

This warranty is valid only within Europe. Outside of Europe please contact our official distributors.

ITALIANO

21

MANUFACTURER´S DECLARATIONS:

LIMITATION OF LIABILITY

If your Adam Hall branded hardware product fails to work as warranted above, your sole and exclusive remedy

ENGLISHDEUTSCHFRANCAIS

shall be repair or replacement. Adam Halls’ maximum liability under this limited warranty is expressly limited to
the lesser of the price you have paid for the product or the cost of repair or replacement of any components that
malfunction under conditions of normal use.

Adam Hall is not liable for any damages caused by the product or the failure of the product, including any lost
profits or savings or special, incidental, or consequential damages. Adam Hall is not liable for any claim made by
a third party or made by you for a third party.

This limitation of liability applies whether damages are sought, or claims are made, under this Limited Warranty
or as a tort claim (including negligence and strict product liability), a contract claim, or any other claim, and
cannot be rescinded or changed by anyone. This limitation of liability will be effective even if you have advised
Adam Hall or an authorized representative of Adam Hall of the possibility of any such damages, but not, however,
in the event of claims for damages in connection with personal injuries.

This manufacturer‘s warranty grants you specific rights; depending on jurisdiction (nation or state), you may be
be entitled to additional claims. You are advised to consult applicable state or national laws for a full determina­tion of your rights.

REQUESTING WARRANTY SERVICE

To request warranty service for the product, contact Adam Hall or the Adam Hall authorized reseller from which
you purchased the product.

ESPAÑOLPOLSKIITALIANO

EC DECLARATION OF CONFORMITY

The equipment marketed by Adam Hall complies (where applicable) with the essential requirements and other
relevant specifications of Directives 1999/5/EC (R&TTE), 2004/108/EC (EMC) und 2006/95/EC (LVD). Additional
information can be found at www.adamhall.com.

FRANCAISFRANCAIS

FRANCAISFRANCAIS

22

MANUFACTURER´S DECLARATIONS:

PROPER DISPOSAL OF THIS PRODUCT

(Valid in the European Union and other European countries with waste separation)

This symbol on the product, or the documents accompanying the product, indicates that this appliance may not
be treated as household waste. This is to avoid environmental damage or personal injury due to uncontrolled
waste disposal. Please dispose of this product separately from other waste and have it recycled to promote
sustainable economic activity.

Household users should contact either the retailer where they purchased this product, or their local government
office, for details on where and how they can recycle this item in an environmentally friendly manner.
Business users should contact their supplier and check the terms and conditions of the purchase contract. This
product should not be mixed with other commercial wastes for disposal .

FRANCAIS

FRANCAIS

ENGLISH

DEUTSCH
FRANCAIS

FRANCAIS

ENVIRONMENTAL PROTECTION AND ENERGY CONSERVATION

Energy conservation is an active contribution to environmental protection. Please turn off all unneeded electrical
devices. To prevent unneeded devices from consuming power in standby mode, disconnect the mains plug.

Adam Hall GmbH, all rights reserved. The technical data and the functional product characteristics can be subject
to modifications. The photocopying, the translation, and all other forms of copying of fragments or of the integrlity
of this user’s manual is prohibited.

FRANCAIS

ESPAÑOL

POLSKI

ITALIANO

23

ENGLISHDEUTSCHFRANCAIS

Sie haben die richtige Wahl getroffen!

Dieses Gerät wurde unter hohen Qualitätsanforderungen entwickelt und gefertigt, um viele Jahre einen reibungs­losen Betrieb zu gewährleisten. Dafür steht LD Systems mit seinem Namen und der langjährigen Erfahrung als
Hersteller hochwertiger Audioprodukte.

Bitte lesen Sie diese Bedienungsanleitung sorgfältig, damit Sie Ihr neues Produkt von LD Systems schnell optimal
einsetzen können.

Mehr Informationen zu LD SYSTEMS finden Sie auf unserer Internetseite WWW.LD-SYSTEMS.COM

ESPAÑOLPOLSKIITALIANO

FRANCAISFRANCAIS

FRANCAISFRANCAIS

24

LD WSECO2 / LD WSECO2X2

UHF WIRELESS SYSTEMS

FRANCAIS

FRANCAIS

ENGLISH

DEUTSCH
FRANCAIS

FRANCAIS

FRANCAIS

ESPAÑOL

POLSKI

ITALIANO

25

SICHERHEITSHINWEISE:

1. Lesen Sie diese Anleitung bitte sorgfältig durch.

2. Bewahren Sie alle Informationen und Anleitungen an einem sicheren Ort auf.

3. Befolgen Sie die Anweisungen.

4. Beachten Sie alle Warnhinweise. Entfernen Sie keine Sicherheitshinweise oder andere Informationen vom Gerät.

5. Verwenden Sie das Gerät nur in der vorgesehenen Art und Weise.

ENGLISHDEUTSCHFRANCAIS

6. Verwenden Sie ausschließlich stabile und passende Stative bzw. Befestigungen (bei Festinstallationen). Stellen
Sie sicher, dass Wandhalterungen ordnungsgemäß installiert und gesichert sind. Stellen Sie sicher, dass das
Gerät sicher installiert ist und nicht herunterfallen kann.

7. Beachten Sie bei der Installation die für Ihr Land geltenden Sicherheitsvorschriften.

8. Installieren und betreiben Sie das Gerät nicht in der Nähe von Heizkörpern, Wärmespeichern, Öfen oder
sonstigen Wärmequellen. Sorgen Sie dafür, dass das Gerät immer so installiert ist, dass es ausreichend gekühlt
wird und nicht überhitzen kann.

9. Platzieren Sie keine Zündquellen wie z.B. brennende Kerzen auf dem Gerät.

10. Lüftungsschlitze dürfen nicht blockiert werden.

11. Betreiben Sie das Gerät nicht in unmittelbarer Nähe von Wasser. Bringen Sie das Gerät nicht mit brennbaren
Materialien, Flüssigkeiten oder Gasen in Berührung.

12. Sorgen Sie dafür, dass kein Tropf- oder Spritzwasser in das Gerät eindringen kann. Stellen Sie keine mit
Flüssigkeit gefüllten Behältnisse wie Vasen oder Trinkgefäße auf das Gerät.

13. Sorgen Sie dafür, dass keine Gegenstände in das Gerät fallen können.

14. Betreiben Sie das Gerät nur mit dem vom Hersteller empfohlenen und vorgesehenen Zubehör.

15. Öffnen Sie das Gerät nicht und verändern Sie es nicht.

16. Überprüfen Sie nach dem Anschluss des Geräts alle Kabelwege, um Schäden oder Unfälle, z. B. durch
Stolperfallen zu vermeiden.

17. Achten Sie beim Transport darauf, dass das Gerät nicht herunterfallen und dabei möglicherweise Sach- und
Personenschäden verursachen kann.

18. Wenn Ihr Gerät nicht mehr ordnungsgemäß funktioniert, Flüssigkeiten oder Gegenstände in das Geräteinnere
gelangt sind, oder das Gerät anderweitig beschädigt wurde, schalten Sie es sofort aus und trennen es von der
Netzsteckdose (sofern es sich um ein aktives Gerät handelt). Dieses Gerät darf nur von autorisiertem Fachperso-

ESPAÑOLPOLSKIITALIANO

nal repariert werden.

19. Verwenden Sie zur Reinigung des Geräts ein trockenes Tuch.

20. Beachten Sie alle in Ihrem Land geltenden Entsorgungsgesetze. Trennen Sie bei der Entsorgung der Verpa­ckung bitte Kunststoff und Papier bzw. Kartonagen voneinander.

21. Kunststoffbeutel müssen außer Reichweite von Kindern aufbewahrt werden.

Direkte Sonneneinstrahlung vermeiden!

BEI GERÄTEN MIT NETZANSCHLUSS:

FRANCAISFRANCAIS

FRANCAISFRANCAIS

22. ACHTUNG: Wenn das Netzkabel des Geräts mit einem Schutzkontakt ausgestattet ist, muss es an einer
Steckdose mit Schutzleiter angeschlossen werden. Deaktivieren Sie niemals den Schutzleiter eines Netzkabels.

23. Schalten Sie das Gerät nicht sofort ein, wenn es starken Temperaturschwankungen ausgesetzt war (bei­spielsweise nach dem Transport). Feuchtigkeit und Kondensat könnten das Gerät beschädigen. Schalten Sie das
Gerät erst ein, wenn es Zimmertemperatur erreicht hat.

24. Bevor Sie das Gerät an die Steckdose anschließen, prüfen Sie zuerst, ob die Spannung und die Frequenz
des Stromnetzes mit den auf dem Gerät angegebenen Werten übereinstimmen. Verfügt das Gerät über einen
Spannungswahlschalter, schließen Sie das Gerät nur an die Steckdose an, wenn die Gerätewerte mit den Werten
des Stromnetzes übereinstimmen. Wenn das mitgelieferte Netzkabel bzw. der mitgelieferte Netzadapter nicht in
Ihre Netzsteckdose passt, wenden Sie sich an Ihren Elektriker.

25. Treten Sie nicht auf das Netzkabel. Sorgen Sie dafür, dass spannungsführende Kabel speziell an der Netz-

26

SICHERHEITSHINWEISE:

buchse bzw. am Netzadapter und der Gerätebuchse nicht geknickt werden.

26. Achten Sie bei der Verkabelung des Geräts immer darauf, dass das Netzkabel bzw. der Netzadapter stets frei
zugänglich ist. Trennen Sie das Gerät stets von der Stromzuführung, wenn das Gerät nicht benutzt wird, oder
Sie das Gerät reinigen möchten. Ziehen Sie Netzkabel und Netzadapter immer am Stecker bzw. am Adapter und
nicht am Kabel aus der Steckdose. Berühren Sie Netzkabel und Netzadapter niemals mit nassen Händen.

27. Schalten Sie das Gerät möglichst nicht schnell hintereinander ein und aus, da sonst die Lebensdauer des
Geräts beeinträchtigt werden könnte.

28. WICHTIGER HINWEIS: Ersetzen Sie Sicherungen ausschließlich durch Sicherungen des gleichen Typs und
Wertes. Sollte eine Sicherung wiederholt auslösen, wenden Sie sich bitte an ein autorisiertes Servicezentrum.

29. Um das Gerät vollständig vom Stromnetz zu trennen, entfernen Sie das Netzkabel bzw. den Netzadapter aus
der Steckdose.

30. Wenn Ihr Gerät mit einem verriegelbaren Netzanschluss bestückt ist, muss der passende Gerätestecker
entsperrt werden, bevor er entfernt werden kann. Das bedeutet aber auch, dass das Gerät durch ein Ziehen am
Netzkabel verrutschen und herunterfallen kann, wodurch Personen verletzt werden und/oder andere Schäden
auftreten können. Verlegen Sie Ihre Kabel daher immer sorgfältig.

31. Entfernen Sie Netzkabel und Netzadapter aus der Steckdose bei Gefahr eines Blitzschlags oder wenn Sie das
Gerät länger nicht verwenden.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

ACHTUNG:

Entfernen Sie niemals die Abdeckung, da sonst das Risiko eines elektrischen Schlages besteht. Im Inneren des
Geräts befinden sich keine Teile, die vom Bediener repariert oder gewartet werden können. Lassen Sie Repara­turen ausschließlich von qualifiziertem Servicepersonal durchführen.

Das gleichschenkelige Dreieck mit Blitzsymbol warnt vor nichtisolierten, gefährlichen Spannungen
im Geräteinneren, die einen elektrischen Schlag verursachen können.

Das gleichschenkelige Dreieck mit Ausrufungszeichen kennzeichnet wichtige Bedienungs- und
Wartungshinweise.

FRANCAIS

FRANCAIS

ENGLISH

DEUTSCH
FRANCAIS

FRANCAIS

FRANCAIS

ESPAÑOL

ACHTUNG HOHE LAUTSTÄRKEN BEI AUDIOPRODUKTEN!

Dieses Gerät ist für den professionellen Einsatz vorgesehen. Der kommerzielle Betrieb dieses Geräts unterliegt
den jeweils gültigen nationalen Vorschriften und Richtlinien zur Unfallverhütung. Als Hersteller ist Adam Hall
gesetzlich verpflichtet, Sie ausdrücklich auf mögliche Gesundheitsrisiken hinzuweisen.
Gehörschäden durch hohe Lautstärken und Dauerbelastung: Bei der Verwendung dieses Produkts können
hohe Schalldruckpegel (SPL) erzeugt werden, die bei Künstlern, Mitarbeitern und Zuschauern zu irreparablen
Gehörschäden führen können.

Um eine mögliche Schädigung des Hörsinns zu verhindern, vermeiden Sie das Hören bei großem
Lautsärkepegel über lange Zeiträume.
Lauter Schalleinfluss kann selbst bei kurzer Dauer zu Hörschäden führen. Bitte halten Sie die
Laustärke immer auf einem angenehmen Level.

POLSKI

ITALIANO

27

SYSTEMKOMPONENTEN WSECO2 SENDEANLAGEN:

Alle Sets beinhalten folgende Systemkomponenten:

ENGLISHDEUTSCHFRANCAIS

ESPAÑOLPOLSKIITALIANO

FRANCAISFRANCAIS

FRANCAISFRANCAIS

Taschensender

Empfänger

Audiokabel Klinke 6,3 mm mono auf Klinke 6,3 mm mono

Batterien

Zusätzlich sind je nach Set weitere Komponenten enthalten:

LDWSECO2BPH - ECO2 Set mit

Taschensender und Headset

Headset

LDWSECO2HHD - ECO2 Set mit Handsender

Handsender mit dynamischer

Mikrofonkapsel

LDWSECO2BPG - ECO2 Set mit
Taschensender und Gitarrenkabel

Netzteil

28

TaschensenderGitarrenkabel

SYSTEMKOMPONENTEN WSECO2X2 SENDEANLAGEN:

-

-

Alle Sets beinhalten folgende Systemkomponenten:

FRANCAIS

FRANCAIS

ENGLISH

Doppelempfänger

Audiokabel Klinke 6,3 mm mono auf Klinke 6,3 mm mono

Zusätzlich sind je nach Set weitere Komponenten enthalten:

LDWSECO2X2BPH - ECO2X2 Set mit
2 x Taschensender + 2 x Headset

oder

+

+

Batterien

LDWSECO2X2HHD- ECO2X2 Set
mit 2 x Handsender

2 x Handsender mit dynamischer

Netzteil

Mikrofonkapsel

DEUTSCH
FRANCAIS

FRANCAIS

FRANCAIS

ESPAÑOL

POLSKI

2 x Taschensender

ITALIANO

2 x Headset

29

ANSCHLÜSSE, BEDIEN- UND ANZEIGEELEMENTE:

ECO2 EMPFÄNGER

ENGLISHDEUTSCHFRANCAIS

5

ESPAÑOLPOLSKIITALIANO

FRANCAISFRANCAIS

FRANCAISFRANCAIS

30

1

6 7

2

3

4

8 9
