Latitude 745 Users Manual
Bluetooth® GPS Watch
with Heart Rate
Measurement
User Manual
Spend a little Live a lot.
ID: #05007
m
y
h
a
n
s
e
c
o
n
t
r
o
l
.
c
o
m
M
A
N
U
A
L
D
E
V
E
L
O
P
E
D
I
N
G
E
R
M
A
N
Y
User-friendly
Manual
QR codes take you where you want to go
quickly and easily
Whether you require product information, spare parts or accessories, details on warranties or aftersales services, or if you want to
watch a product demonstration video, our QR codes will take you
there in no time at all.
What is a QR code?
A QR code (QR = Quick Response) is a type of matrix that can be read
with a smartphone camera and that contains a link to a website or
contact details, for example.
Advantage: You do not need to manually enter a website address or
contact details.
This is how it works
To scan the QR code, all you need is a smartphone with QR code reader software and an internet connection*. This type of software can
be downloaded for free from your app store.
Try it out now
Just scan the QR code with your smartphone and
find out more about the Aldi product you have
purchased.*
Your Aldi Service Portal
All details mentioned above can also be found in
the Aldi Service Portal at www.aldi.co.uk.
* Depending on your tarif plan you may be charged for the connection.
et connecti
from your
Dok./Rev.-Nr. 92989_20150302 neu
Overview .............................................................................4
Use ........................................................................................5
Scope of delivery/device parts ..........................................6
General information ...........................................................7
Reading and storing the instruction manual ...................7
Explanation of symbols .........................................................7
Checking the GPS watch and product contents .............. 9
S
afety
...................................................................................9
Proper use ...............................................................................9
Safety notes ...........................................................................10
Water-resistance ...................................................................16
Start-up ............................................................................. 18
Charging the battery pack of the GPS watch ..................18
Chest strap ............................................................................20
Bike holder ............................................................................ 22
Downloading and installing the Crane Connect app ... 23
General information about GPS ........................................ 24
Operation ..........................................................................27
Turning the GPS watch on and off .................................... 27
Locking keys ......................................................................... 27
Illumination of the display panel ......................................28
GPS watch modes ................................................................ 29
System setting mode ..........................................................30
Time mode ............................................................................ 37
Workout mode with GPS ..................................................... 37
Interval mode with GPS ...................................................... 42
History mode ........................................................................45
Alarm mode ..........................................................................48
Data transfer .........................................................................49
Cleaning and maintenance ............................................. 50
Changing the transmitter unit’s battery ..........................51
Storage ..............................................................................53
T
roubleshooting
.............................................................. 54
Technical data .................................................................. 58
Declaration of conformity ..................................................59
Disposal .............................................................................59
Disposing of the packaging ............................................... 59
Disposing of old devices .....................................................60
Warranty ........................................................................... 61
W
arranty Card
......................................................................6
1
Warranty conditions ...........................................................62
Contents
S wa
..............
he display
des
A
B C
1
2
3
4
5
6
16
17
20
19
18
15
22
23
21
24
14
13
9
11
10
12
7
8
4
GB IRE
V1
2 2 211 25
7
7 8
D
F
H
E
G
KRIPPL-WATCHES
WARENHANDELS GMBH
MARIA-THERESIA-STR. 41
4600 WELS, AUSTRIA
SERIAL NO.: PO7044
MODEL NO.: HO5-GPS-6A
TYPE: D92J63
EAN: 20023898
BLUETOOTH ID: D024216
PLU: 92412
3 BAR WATER RESISTANT
1 X 3.7 V 24mA
06/2015
36
5
GB IRE
V1
7
6
GB IRE
Product contents⁄device parts
1
GPS watch
2
USB connector cable
3
Cleaning brush
4
Bike holder
5
Cable strap for
4
6
Fixing plate for
4
7
Chest strap
8
Transmitter unit
9
ST./STP key (start/stop)
10
VIEW key
11
LAP/RESET key
12
MODE key
13
Display panel
14
LIGHT key (light)
15
Top row
16
GPS icon
17
Heart rate icon
18
Centre row
19
Bottom row
20
Battery charging level
icon
21
L icon (lap)
22
Heart rate icon
23
P icon (12 h time format)
24
Workout icon
25
Charging contacts
23
AFTER SALES SUPPORT
service@cranesportsconnect.com
GB
IRE
00800/52323000
General information
GBIRE
7
General information
Reading and storing the instruction
manual
This instruction manual accompanies this
Bluetooth® GPS “Watch with Heart Rate Measurement”. It contains important information on
start-up and handling.
For improved readability, the Bluetooth® GPS watch with
heart rate measurement will be referred to below merely
as the “GPS watch” below.
Before using the GPS watch, please read through the
instruction manual carefully. This particularly applies for
the safety notes. Failure to comply with the instruction
manual may result in damage to the GPS watch and
falsified workout results.
The instruction manual is based on the standards and
rules in force in the European Union. When abroad, you
must also observe country-specific guidelines and laws.
Store the instruction manual and packaging for future
use. If you pass the GPS watch on to third parties, please
be absolutely sure to include this instruction manual.
AFTER SALES SUPPORT
service@cranesportsconnect.com
GB
IRE
00800/52323000
IRE
General information
GB
8
Explanation of symbols
The following symbols and signal words are used in
this instruction manual, on the GPS watch or on the
packaging.
WARNING!
WARNING! This signal word designates a hazard with
moderate degree of risk which may lead to death or
severe injury if not avoided.
CAUTION!
CAUTION! This signal word designates a hazard with low risk
that, if not avoided, may result in minor or moderate injury.
NOTICE!
NOTICE! This signal word warns against potential
damages to property.
This symbol provides you with useful
supplementary information on assembly or
operation.
Declaration of conformity (see chapter
“Declaration of conformity”): Products
marked with this symbol fulfil the requirements of the EC directives.
AFTER SALES SUPPORT
service@cranesportsconnect.com
GB
IRE
00800/52323000
Safety
GBIRE
9
Checking the GPS watch and product
contents
1. Carefully take the GPS watch and its accessories out
of the packaging.
2.
Remove the packaging material and all pr
otective
wrapping.
3.
Check to make sure that the delivery is complete
(see fig. A).
4.
Check whether the GPS watch or the individual parts
exhibit damages. If this is the case, do not use the
GPS watch. Contact the manufacturer via the service
address indicated on the warranty card.
Safety
Proper use
The GPS watch has a navigation system. The US “GPS”
satellite network orbiting the earth can be used to
determine the position of the user. This can be done any
time and anywhere in the world when outdoors.
The GPS watch primarily serves to measure distance,
speed and altitude and is particularly suitable for sports
like running, cycling, hiking, sailing, skiing etc.
However, the GPS watch is not suitable for demanding
applications such as paragliding, skydiving or gliding.
The GPS watch is designed for private use and is not
suitable for commercial use.
AFTER SALES SUPPORT
service@cranesportsconnect.com
GB
IRE
00800/52323000
IRE
Safety
GB
10
The GPS watch can also be used as a workout aid for
measuring and displaying your heart rate. The
GPS watch is not a medical device.
Only use the GPS watch as described in this instruction
manual. Any other use is considered improper and may
result in damage to property.
The manufacturer or vendor accepts no liability for
damage caused by improper or incorrect use.
Safety notes
WARNING!
Risk of accident/injury!
Do not use the GPS watch when you are driving a vehicle. Looking away from the road is
dangerous and may cause an accident; you
or other persons could be injured as a result.
− Stop or let a passenger perform the
settings.
AFTER SALES SUPPORT
service@cranesportsconnect.com
GB
IRE
00800/52323000
Safety
GBIRE
11
WARNING!
Health hazard!
The GPS watch is not a medical device; it is
a workout aid for measuring and displaying
your heart rate.
− Always consult a physician before you
start a regular workout routine.
− Persons with pacemakers may only use
devices for measuring heart rate in
consultation with their physician.
− Do not use the chest strap if you are
allergic to latex. The chest strap may
contain latex constituents and cause
irritation and reddening of your skin.
− Batteries may pose a risk to health if
ingested. You should therefore store the
battery and the chest strap so that they
are not accessible for small children. If a
battery has been swallowed, you must
seek immediate medical attention.
AFTER SALES SUPPORT
service@cranesportsconnect.com
GB
IRE
00800/52323000
IRE
Safety
GB
12
− Promptly remove an empty battery from
the chest strap. Otherwise it could leak.
In this case, avoid contact with skin,
eyes or mucus membranes. In the event
of contact with battery acid, immediately
flush the applicable areas with plenty
of clean water and consult a physician
promptly.
WARNING!
Danger for children and persons with
impaired physical, sensory or mental
capacities (e.g. partially disabled persons,
older persons with reduced physical and
mental capacities) or lack of experience
and knowledge (e.g. older children).
− The GPS watch may be used by children
ages eight and over as well as persons
with impaired physical, sensory or
mental capacities or those lacking experience and knowledge if they are supervised or have been instructed in how
to safely use the GPS watch and have
understood the risks associated with
using it.
AFTER SALES SUPPORT
service@cranesportsconnect.com
GB
IRE
00800/52323000
Safety
GBIRE
13
− Children may not play with the GPS
watch. Cleaning and user maintenance
must not be performed by unsupervised
children.
− Keep children under the age of eight
away from the GPS watch and the accessories.
− Do not allow children to play with the
packaging wrapper. They could swallow
it and suffocate.
WARNING!
Risk of explosion and fire!
Lithium battery packs and batteries could
explode if handled improperly.
− Your GPS watch is operated with a lithium
polymer battery pack, which you cannot
replace.
− You may not heat, open or short circuit
battery packs and batteries or dispose of
them in fire. Do not drill through the GPS
watch.
− To avoid overheating the battery pack,
do not expose the GPS watch to direct
sunlight or other heat sources, e.g. in a
vehicle.
AFTER SALES SUPPORT
service@cranesportsconnect.com
GB
IRE
00800/52323000
IRE
Safety
GB
14
− Only use the enclosed charging cable
and a USB port on your PC or a USB
charger to charge the battery pack in
the GPS watch.
− Never charge the battery pack at temperatures below +10°C! This will damage the chemical composition of the cell
and may result in a fire.
− Only replace the battery for the chest
strap transmitter unit with an equivalent battery type (CR2032).
− Do not attempt to charge the battery or
reactivate it with other means.
NOTICE!
Risk of damage!
Improper handling of the GPS watch may
damage the GPS watch.
− Do not place any objects on the GPS
watch and do not apply pressure to the
display panel. Otherwise the display
panel could break.
− Avoid contact between the display panel and angular objects.
AFTER SALES SUPPORT
service@cranesportsconnect.com
GB
IRE
00800/52323000
Safety
GBIRE
15
− Avoid very strong magnetic fields
(e.g. transformers). Otherwise, they
could cause inconsistencies in measuring time and positioning. Failure to
observe these notes may result in faults
or damage to your GPS watch.
− For optimal battery pack power, avoid
deep discharges. Charge the battery
pack when only one bar is visible on the
battery pack indicator.
− Do not overcharge the battery pack.
Connecting a charged or partially
charged battery pack several times may
overcharge it and damage the cells.
− Do not leave the battery pack connected
to the charger for several days.
− Never open the housing of the GPS
watch or chest strap, it does not contain
any parts requiring maintenance (only
the battery must be changed; see section
“Changing the battery”).
− Only parts that comply with the original
device data may be used for repairs.
Electrical and mechanical parts, which
are essential for providing protection
against sources of danger, are located in
this device.
AFTER SALES SUPPORT
service@cranesportsconnect.com
GB
IRE
00800/52323000
IRE
Safety
GB
16
− Liability
and warranty claims are waived
in the event of repairs performed by the
user, improper connection of the device
or incorrect operation.
Water-resistance
The GPS watch is water-resistant up to 3 bar; the chest
strap is splash-proof.
Refer to the table below to determine the level of
water-resistance for your GPS watch and appropriate
use. The bar value refers to air overpressure that was
applied to test water-resistance (DIN 8310).
Water
resistant
up to
Rain,
splashes
Washing
hands
Shower-
ing
Bathing,
swimming
Water
sports
n/a
1
Yes No No No No
3 bar
1
Yes Yes No No No
1) The watch withstands a pressure of 3 bar for a limited amount of
time.
Shower
AFTER SALES SUPPORT
service@cranesportsconnect.com
GB
IRE
00800/52323000
Safety
GBIRE
17
NOTICE!
Risk of damage!
− Do not immerse the GPS watch or the
transmitter in water or other liquids.
− Do not press the keys when the GPS
watch is wet. Otherwise, water could
penetrate the housing and damage the
clockwork.
− Keep in mind that salt and thermal water
may cause metal parts to corrode.
− It is recommended that you do not wear
the watch in a sauna or in the shower as
differences in temperature may cause
condensation to form, which could
damage the clockwork.
− Peak pressures may occur when swimming or when exposed to a water jet
(e.g. when showering or washing your
hands). During such activities, affected
areas may be subjected to a significantly
greater pressure than expected for the
immersion depth. Only watches with a
classification of 5 bar or more can be considered water-proof (showering allowed).
AFTER SALES SUPPORT
service@cranesportsconnect.com
GB
IRE
00800/52323000
IRE
Start-up
GB
18
Watches with a classification of 10 bar
can also be used when swimming.
− If a watch is subjected to substantial
changes in temperature such as when
sun-bathing followed by a dip in cool
water, liquid may condense in the housing. This is not necessarily a sign that it is
not water proof; it is, however, imperative
that the moisture is removed. Contact our
customer service team in such cases.
Start-up
Charging the battery pack of the GPS watch
The GPS watch has an integrated lithium polymer
battery pack. Fully charge the GPS watch before first use
(approx. 3 hours).
1. If necessary and to avoid corrosion, dry the contact
points
25
of the GPS watch thoroughly before
starting the charge process.
2.
Secure the clip on the USB cable
2
on the GPS
watch
1
(see fig. D).
NOTICE!
Risk of damage!
AFTER SALES SUPPORT
service@cranesportsconnect.com
GB
IRE
00800/52323000
Start-up
GBIRE
19
Incorrectly connecting the cable may cause
the watch or cable to heat up.
− Make sure that the USB cable is connected
so that the metal pins on the clip lock
directly into the contact points of the
watch.
3. Connect the USB cable with a USB charger or a USB
port on your computer carrying power. There is no
need to install a driver for charging the battery pack.
If the GPS watch has been switched off, it automatically
switches on when charging.
The icon of a charging battery appears on the display
panel
13
during the charging process.
If the battery pack is fully charged, the “FULL” indicator
will appear.
4. Pull the USB plug out of the USB charger or PC.
5. Carefully take the clip for the USB cable off of the GPS
watch.
AFTER SALES SUPPORT
service@cranesportsconnect.com
GB
IRE
00800/52323000
IRE
Start-up
GB
20
Battery pack charging level
One battery pack charge is sufficient for max. 16 hours of
operation in workout mode with GPS and approx. one
year in watch mode.
The battery pack charging level is indicated with four
bars in the icon
20
on the display panel
13
.
−
If only one bar is visible, you should charge the
watch as soon as possible.
Chest strap
The elastic chest strap with the transmitter unit is for measuring the heart rate. The transmitter unit records heart
beats via the gummed area of the chest strap and transmits
the pulses to the GPS watch via Bluetooth®. Therefore, you
must establish a Bluetooth® connection between the GPS
watch and the transmitter unit (“Pairing”) after putting on
the chest strap. By factory default, the watch is paired with
the chest strap. Normally, re-pairing is only required after
changing the batteries of the chest strap of after changing
the
chest strap.
The battery is already inserted in the chest strap upon
delivery; it is operational. The section “Changing the
battery of the transmitter unit” explains how to change
the transmitter unit’s battery.
The transmitter unit becomes active when you put the
chest strap on and switches off when you take the chest
strap or transmitter unit off.
Loading...
