Konica Minolta DiMAGE Xt Biz User Manual

Technical Specifications Xt Biz

Number of effective pixels: 3.2 million

CCD: 1/2.7-type interline primary-color CCD

Total pixels: 3.3 million

Camera sensitivity: Auto (between ISO 50 –160 equivalent), ISO 50,100,

200, 400 equivalents

Focal length: 5.7 – 17.1mm (35mm equivalent: 37 – 111mm)

Lens construction: 9 elements in 8 groups (includes 3 aspheric elements)

Maximum aperture: f/2.8 – f/3.6

Minimum focus distance: 0.15m / 5.9 in. from front of camera

Maximum magnification: 0.1x (1:10)

Equivalent to 0.58x (1: 1.72) in 35mm format

Area covered at maximum magnification:

55.2 x 41.4mm / 2.17 x 1.63 in.

Viewfinder type: Optical real-image zoom viewfinder

Monitor LCD: 3.8cm (1.5 inch) low-temperature polysilicon TFT

color monitor with anti-reflection coating

Shutter: CCD electronic shutter and mechanical shutter

Shutter speed range: 4 - 1/1000 s

Autofocus system: Video AF

Autofocus areas: Wide focus area (five-point AF)

Metering: Multi-segment, Spot

Multi-segment metering: 256 segments

Exposure control: Programmed AE

Exposure compensation: ±2 Ev in 1/3 increments

Flash range: Wide: 0.15 – 3.2m / 0.5 – 10.5 ft. (approx.)

Telephoto: 0.15 – 2.5m / 0.5 – 8.2 ft. (approx.)

(Camera sensitivity: auto)

Flash modes: Autoflash, Autoflash with red-eye reduction, Fill-flash,

Flash cancel, Night portrait

Continuous advance: Available

Self-timer: 10 s (approx.)

Movie recording: Recording time dependent on memory card capacity.

1

Frame rate: 15fps

Monaural audio only.

Audio: Audio recording: 180 min. (max.) *

*128MB MB memory card is required.

Voice memo: 15s (max)

Audio caption: 15s (max.)

Audio annotation recording: 10min. (max.)

Monaural audio only

White balance control: Automatic, Preset (Daylight, Cloudy, Tungsten,

Fluorescent)

Color modes: Color, Black and white, Sepia

Noise reduction: User selectable

Digital zoom: 4x (max.) in 0.1x increments

Digital zoom can be disabled.

E-mail Copy function: Creates a compressed 640x480 or 160x120 JPEG

image for transmission.

Date imprinting: Year/month/day (Format can be changed.)

Month/day/hour:minute

Imprinting can be disabled.

Image-quality modes: TIFF, Fine, Standard, Economy

Number of recorded pixels (Still images):

2048 x 1536, 1600 x 1200, 1280 x 960, 640 x 480

Number of recorded pixels (Movie clips):

320 x 240, 160 x 120

Storage capacity: Approximate storage capacity of a 16MB

SD (Secure

Digital) Memory Card:

TIFF 1 frame 2 frames 3 frames 14 frames

Fine 9 frames 14 frames 22 frames 69 frames

Standard 17 frames 27 frames 39 frames 100 frames

2048x1536 1600x1200 1280x960 640x480

Economy 32 frames 47 frames 69 frames 150 frames

Movie 41 seconds with 320x240 images

2 minutes 30 seconds with 160x120 images

2
