AUDIO/VIDEO CONTROL RECEIVER

DIGITAL

RECEPTEUR DE CONTROL AUDIO/VIDEO

RX-6510VBK

CATV/DBS VCR TV AUDIO

POWER POWER POWER POWER

DVD

FM/AM

TAPE/CDR

TV SOUND VCR

BASS

TREBLE

++−−

SURROUND

DSP

ANALOG/DIGITAL

SLEEP

MODE INPUTON/OFF

+ CENTER –

BASS BOOST EFFECT

231

TEST + REAR•L –

564

TUNING

CATV/DBS CONTROL

CONTROL

TV/VIDEO

SOUND

MUTING

−

REC

PAUSE

897/P

– SUB WOOFER +

RETURN FM MODE 100

+−+−+

CH TV VOL

PLAY

/REW FF/

PAUSE

STOP

RM-SRX6510J

A/V CONTROL RECEIVER

ENTER

– REAR•R +

VOLUME

CONTROL

FM/AM TUNING

DIGITAL

SURROUND

SURROUND ON/OFF

DSP MODE

FM/AM PRESET FM MODE

DIGITAL

INPUT

ANALOG/DIGITAL

INPUT ATT

MEMORY

BASS BOOST

SPEAKERS ON/OFF

+1010

STANDBY

POWER

−

PHONES

RX-6510V AUDIO/VIDEO CONTROL RECEIVER

DVD VCR TV SOUND

CD TAPE/CDR

SOURCE NAME

FM/AM

ADJUST

DOWN UP

CONTROL

COMPULINK

MASTER VOLUME

SETTING

Remote

MANUAL D’INSTRUCTIONS

INSTRUCTIONS

For Customer Use:

Enter below the Model No. and Serial No. which are located either on the rear, bottom or side of the cabinet. Retain this information for future reference.

Model No. Serial No.

LVT0578-007A

[C]

Warnings, Cautions and Others/ Mises en garde, précautions et indications diverses

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK. DO NOT REMOVE COVER (OR BACK) NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The lightning flash with arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated "dangerous voltage" within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

CAUTION

To reduce the risk of electrical shocks, fire, etc.:

1. Do not remove screws, covers or cabinet.

2. Do not expose this appliance to rain or moisture.

ATTENTION

Afin d’éviter tout risque d’électrocution, d’incendie, etc.:

1. Ne pas enlever les vis ni les panneaux et ne pas ouvrir le coffret de l’appareil.

2. Ne pas exposer l’appareil à la pluie ni à l’humidité.

Caution –– POWER switch!

Disconnect the mains plug to shut the power off completely. The POWER switch in any position does not disconnect the mains line. The power can be remote controlled.

Attention –– Commutateur POWER!

Déconnecter la fiche de secteur pour couper complètement le courant. Le commutateur POWER ne coupe jamais complètement la ligne de secteur, quelle que soit sa position. Le courant peut être télécommandé.

For Canada/pour Le Canada

THIS DIGITAL APPARATUS DOES NOT EXCEED THE CLASS B LIMITS FOR RADIO NOISE EMISSIONS FROM DIGITAL APPARATUS AS SET OUT IN THE INTERFERENCE-CAUSING EQUIPMENT STANDARD ENTITLED “DIGITAL APPARATUS,” ICES-003 OF THE DEPARTMENT OF COMMUNICATIONS. CET APPAREIL NUMERIQUE RESPECTE LES LIMITES DE BRUITS RADIOELECTRIQUES APPLICABLES AUX APPAREILS NUMERIQUES DE CLASSE B PRESCRITES DANS LA NORME SUR LE MATERIEL BROUILLEUR; “APPAREILS NUMERIQUES”, NMB-003 EDICTEE PAR LE MINISTRE DES COMMUNICATIONS.

For Canada/pour le Canada

CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE

BLADE OF PLUG TO WIDE SLOT, FULLY INSERT ATTENTION: POUR EVITER LES CHOCS ELECTRIQUES, INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQUAU FOND

For U.S.A.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help.

EnglishFrançais

Caution: Proper Ventilation

T o avoide risk of electric shock and fire and to protect from damage. Locate the apparatus as follows: Front: No obstructions open spacing. Sides: No obstructions in 10 cm from the sides. Top: No obstructions in 10 cm from the top. Back: No obstructions in 15 cm from the back Bottom: No obstructions, place on the level surface. In addition, maintain the best possible air circulation as illustrated.

Wall or obstructions Mur, ou obstruction

Spacing 15 cm or more Dégagement de 15 cm ou plus

RX-6510VBK

Attention: Ventilation Correcte

Pour éviter les chocs électriques, l’incendie et tout autre dégât. Disposer l’appareil en tenant compte des impératifs suivants Avant: Rien ne doit gêner le dégagement Flancs: Laisser 10 cm de dégagement latéral Dessus: Laisser 10 cm de dégagement supérieur Arrière: Laisser 15 cm de dégagement arrière Dessous: Rien ne doit obstruer par dessous; poser l’appareil

Veiller également à ce que l’air circule le mieux possible comme illustré.

sur une surface plate.

Stand height 15 cm or more Hauteur du socle: 15 cm ou plus

Floor Plancher

Front Avant

English

Table of Contents

Parts Identification ...................................... 2

Getting Started ........................................... 3

Before Installation ...................................................................... 3

Checking the Supplied Accessories ........................................... 3

Connecting the FM and AM Antennas ....................................... 3

Connecting the Speakers ............................................................ 4

Connecting Audio/Video Components....................................... 5

Connecting the Power Cord ....................................................... 8

Putting Batteries in the Remote Control .................................... 8

Basic Operations ......................................... 9

Turning the Power On and Off (Standby) .................................. 9

Selecting the Source to Play....................................................... 9

Adjusting the Volume ............................................................... 10

Selecting the Front Speakers .................................................... 10

Muting the Sound ..................................................................... 11

Reinforcing the Bass ................................................................ 11

Adjusting the Tone ................................................................... 11

Attenuating the Input Signal .................................................... 11

Adjusting the Subwoofer Output Level.................................... 11

Basic Settings........................................... 12

Recording a Source .................................................................. 12

Adjusting the Front Speaker Output Balance........................... 12

Changing the Source Name...................................................... 12

Setting the Subwoofer Information .......................................... 12

Setting the Speakers for the DSP Modes ................................. 13

Digital Input (DIGITAL IN) Terminal Setting......................... 15

Selecting the Analog or Digital Input Mode ............................ 15

Storing the Basic Settings and Adjustments............................. 16

Using the Sleep Timer.............................................................. 16

Receiving Radio Broadcasts ........................ 17

Tuning in Stations Manually .................................................... 17

Using Preset Tuning ................................................................. 17

Selecting the FM Reception Mode........................................... 18

Using the DSP Modes ................................ 19

What are the DSP Modes? ........................................................ 19

Reproducing the Sound Field .................................................... 20

Av ailable DSP Modes According to the Speaker Arrangement .. 21

Adjusting the Surround Modes ................................................ 22

Adjusting the DAP Modes ....................................................... 24

Activating the DSP Modes ....................................................... 25

COMPU LINK Remote Control System ......... 26

Operating JVC’s Audio/Video Components ... 27

Operating Audio Components .................................................. 27

Operating Video Components .................................................. 29

Operating Other Manufacturers’ Video

Equipment ............................................ 30

Troubleshooting ......................................... 34

Specifications ............................................ 35

Parts Identification

Become familiar with the buttons and controls on the receiver before use. Refer to the pages in parentheses for details.

61 2 345 7

RX-6510V AUDIO/VIDEO CONTROL RECEIVER

FM/AM TUNING

DIGITAL

SURROUND

SURROUND ON/OFF

DSP MODE

FM/AM PRESET FM MODE

DIGITAL

INPUT

ANALOG/DIGITAL

INPUT ATT

SPEAKERS ON/OFF

MEMORY

BASS BOOST

DVD VCR TV SOUND

FM/AMTAPE/CDR

SOURCE NAME

PHONES

STANDBY

POWER

ADJUST

CONTROL

DOWN UP

COMPULINK

MASTER VOLUME

SETTING

iue rwp

Remote

English

Remote Control

1 Display window (See below) *

CATV/DBS VCR TV AUDIO

4t 5

6 7

8 9

p q

w e

POWER POWER POWER

POWER

DVD

TV SOUND VCR

BASS

−−++

SURROUND

BASS BOOST EFFECT

SOUND

MUTING

CATV/DBS CONTROL

CONTROL

TV/VIDEO

TUNING

−

REC

PAUSE

TAPE/CDR

TREBLE

ANALOG/DIGITAL

DSP

MODE INPUTON/OFF

– CENTER +

231

– REAR • L +

TEST

564

ENTER

– REAR • R +

897/P

– SUB WOOFER +

RETURN FM MODE 100

+−+−+

CH TV VOL

PLAY

/REW FF/

PAUSE

STOP

RM-SRX6510J

A/V CONTROL RECEIVER

VOLUME

CONTROL

FM/AM

SLEEP

y u

+1010

;

−

a: Remote control operation mode indicator b: Signal transmission indicator

Lights up when transmitting the remote control signal.

2 Power buttons (9, 29 – 33)

CA TV/DBS, VCR, TV, AUDIO

3 Source selecting buttons (9, 16) *

DVD, CD, FM/AM, TV SOUND, VCR, TAPE/CDR

4 BASS +/– buttons (11) 5 SURROUND ON/OFF button (22, 25) 6 DSP MODE button (23 – 25) 7 BASS BOOST button (11) 8 SOUND button (11, 22 – 24) * 9 MUTING button (11) p CATV/DBS CONTROL button (31) * q TV/VIDEO button (29, 30) w CH(annel) +/– buttons (29 – 32) e TUNING +/– buttons (17) r REC PAUSE button (28, 29, 32) t TREBLE +/– buttons (11) y SLEEP button (16) u ANALOG/DIGITAL INPUT button (16) i • 10 keys for selecting preset channels (18, 27)

• 10 keys for adjusting sound (11, 22 – 24, 27)

• 10 keys for operating audio/video components (27 – 32)

o TV VOL(ume) +/– buttons (29, 30) ; VOLUME +/– buttons (10) a Operating buttons for audio/video components

(27 – 29, 32, 33)

s CONTROL button (28, 29) *

Front Panel

1 POWER button and STANDBY lamp (9) 2 FM/AM TUNING 5/∞ buttons (17) 3 FM/AM PRESET 5/∞ buttons (17) 4 FM MODE button (18) 5 MEMORY button (17) 6 Display (9) 7 Remote sensor (8) 8 MASTER VOLUME control (10) 9 PHONES jack (10) p SURROUND ON/OFF button (22, 25) q DSP MODE button (22 – 25) w INPUT ANALOG/DIGITAL button (15)

INPUT ATT button (11)

e SPEAKERS ON/OFF 1 button (10)

SPEAKERS ON/OFF 2 button (10)

r B ASS BOOST button (11) t Source selecting buttons (9, 15)

DVD, VCR, TV SOUND, CD, TAPE/CDR, FM/AM

y SOURCE NAME button (12)

•

The TAPE/CDR button also functions as the SOURCE NAME button.

u ADJUST button (11, 12, 22 – 24) i CONTROL UP 5/DOWN ∞ buttons o SETTING button (12 – 15)

* When you press one of these buttons, the remote control operation mode appears on

the display window for about 10 seconds.

Ex.: When you press CD button

Buttons on the Remote Control Remote Control Operation Mode

FM/AM TUNER

CD CD

T APE/CDR TAPE

DVD DVD

TV SOUND TV

VCR VCR

Buttons on the Remote Control Remote Control Operation Mode

CATV/DBS CONTROL DBS

CONTROL Current setting or VCR or TAPE

or CDDSC

SOUND SOUND

Getting Started

This section explains how to connect audio/video components and speakers to the receiver, and how to connect the power supply.

English

Before Installation

Connecting the FM and AM Antennas

General

• Be sure your hands are dry.

• Turn the power off to all components.

• Read the manuals supplied with the components you are going to connect.

Locations

• Install the receiver in a location that is level and protected from moisture.

• The temperature around the receiver must be between –5˚C and 35˚C (23˚F and 95˚F ).

• Make sure there is good ventilation around the receiver. Poor ventilation could cause overheating and damage the receiver.

Handling the receiver

• Do not insert any metal object into the receiver.

• Do not disassemble the receiver or remove screws, covers, or cabinet.

• Do not expose the receiver to rain or moisture.

Checking the Supplied Accessories

Check to be sure you have all of the following items, which are supplied with the receiver. The number in the parentheses indicates quantity of the pieces supplied.

• Remote Control (1)

• Batteries (2)

• AM Loop Antenna (1)

• FM Antenna (1)

If anything is missing, contact your dealer immediately.

FM Antenna Connections

A O

ANTENN

TENN

FM Antenna

LOOP

ANTENNA

Extend the supplied FM antenna horizontally .

FM 75

COAXIAL

Outdoor FM Antenna Cable

EXT

A. Using the Supplied FM Antenna

The FM antenna provided can be connected to the FM 75 Ω COAXIAL terminal as temporary measure.

B. Using the Standard Type Connector (Not Supplied)

A standard type connector should be connected to the FM 75 Ω COAXIAL terminal.

Note:

If reception is poor, connect the outdoor antenna. Before attaching a 75 going to an outdoor antenna), disconnect the supplied FM antenna.

Ω

coaxial cable (the kind with a round wire

AM Antenna Connections

FRONT

SPEAKERS

RIGHT LEFT

–

RIGHT LEFT

–

ANTENNA

FM 75

COAXIAL

Snap the tabs on the loop into the slots of the base to assemble the AM loop.

Basic connecting procedure

RIGHT

English

LOOP

AM EXT

AM Loop Antenna

1 Cut, twist and remove the insulation at the end of

each speaker signal cable (not supplied).

2 Turn the knob counterclockwise.

3 Insert the speaker signal cable.

4 Turn the knob clockwise.

Connecting the front speakers

You can connect two pairs of front speakers (one pair to the FRONT

Outdoor single vinyl-covered wire (not supplied)

Turn the loop until you have the best reception.

Notes:

• If the AM loop antenna wire is covered with vinyl, remove

the vinyl by twisting it as shown in the diagram.

• Make sure the antenna conductors do not touch any

other terminals, connecting cords and power cord. This could cause poor reception.

• If reception is poor, connect an outdoor single vinyl-covered wire to

the AM EXT terminal. (Keep the AM loop antenna connected.)

SPEAKERS 1 terminals, and another pair to the FRONT SPEAKERS 2 terminals).

Right speakerRight speaker

Connecting the Speakers

You can connect the following speakers:

• Two pairs of front speakers to produce normal stereo sound.

• One pair of rear speakers to enjoy the surround effect.

• One center speaker to produce more effective surround effect (to emphasize human voices).

• One subwoofer to enhance the bass.

IMPORTANT:

After connecting the speakers listed above, set the speaker setting information properly to obtain the best possible DSP effect. For details, see page 13.

For each speaker (except for a subwoofer), connect the (+) and (–) terminals on the rear panel to the (+) and (–) terminals marked on the speakers. For connecting a subwoofer, see page 5.

CAUTION:

Use speakers with the SPEAKER IMPEDANCE indicated by the speaker terminals.

FRONT

SPEAKERS

Left speaker

FRONT

SPEAKERS

Left speaker

About the speaker impedance

SUBWOOFER

OUT

VCR

OUT

(REC)

TAPE

CDR

OUT

(REC)

(PLAY)

English

The required speaker impedance of the front speakers does differ depending on whether both the FRONT SPEAKERS 1 and FRONT SPEAKERS 2 terminals are used or only one of them is used.

CASE 1 When you connect only one pair of front speakers

Connecting the subwoofer speaker

You can enhance the bass by connecting a subwoofer. Connect the input jack of a powered subwoofer to the SUBWOOFER OUT jack on the rear panel, using a cable with RCA pin plugs (not supplied).

Front

speaker

Front

speaker

Use front speakers with 8 Ω – 16 Ω impedance.

CASE 2 When you connect two pairs of front speakers

Front

speaker

Front

speaker

Front

speaker

Front

speaker

Use front speakers 16 Ω – 32 Ω impedance.

Powered subwoofer

Connecting Audio/Video Components

You can connect the following audio/video components to this receiver. Refer also to the manuals supplied with your components.

Audio Components Video Components

• CD player* • DVD player*

• Cassette deck • TV* or CD recorder* • VCR

You can connect these components using the methods described in “Analog connections” (below) or in “Digital connections” (see page 7).

Analog connections

Audio component connections

Use the cables with RCA pin plugs (not supplied). Connect the white plug to the audio left jack, and the red plug to the audio right jack.

Connecting the rear and center speakers

Connect rear speakers to the REAR SPEAKERS terminals and a center speaker to the CENTER SPEAKER terminals.

Center

speaker

CENTER

SPEAKER

Left rear

speaker

Right rear

speaker

–

REAR

SPEAKERS

RIGHT LEFT

CAUTION:

If you connect a sound-enhancing device such as a graphic equalizer between the source components and this receiver, the sound output through this receiver may be distorted.

CD player

To audio output

Cassette deck or CD recorder

AUDIO

VIDEO

VCR

OUT

(REC)

OUT

(REC)

(PLAY)

TAPE

CDR

OUT

(REC)

(PLAY)

MONITOR

OUT

RIGHT LEFT

DVD

TV SOUND

Cassette deck

To audio input

PHONO

OUT

(REC)

TAPE

CDR

(PLAY)

OUT

(REC)

VCR

(PLAY)

TV SOUND

RIGHT LEFT

AUDIO

To audio output

Video component connections

Use the cables with RCA pin plugs (not supplied). Connect the white plug to the audio left jack, the red plug to the audio right jack, and the yellow plug to the video jack. If your video components have S-video (Y/C-separation) terminals, connect them using S-video cables (not supplied). Connecting these video components through the S-video input/output terminals will give you better picture playback (or recording) quality.

IMPORTANT:

This receiver is equipped with both the composite video and S-video input/output terminals for connecting video components. You do not have to connect both the composite video and S-video terminals. However, remember that the video signals from the composite

video input terminals are output only through the composite video output terminals, while the ones from the S-video input terminals are output only through the S-video output terminals.

Therefore, if a recording video component and a playing video component are connected to the receiver through the different video terminals, you cannot record the picture from the playing component on the recording component. In addition, if the TV and a playing video component are connected to the receiver through the different video terminals, you cannot view the playback picture from the playing component on the TV.

English

To audio input

CD recorder

Note:

You can connect either a cassette deck or a CD recorder to the TAPE/ CDR jacks. When connecting a CD recorder to the TAPE/CDR jacks, change the source name, which will be shown on the display when selected as the source, to “CDR.” See page 12 for details.

If your audio components have a COMPU LINK jack

See also page 26 for detailed information about the connection and the COMPU LINK remote control system.

To audio output

VCR

S-VHS (or VHS) VCR

Å To left/right channel audio output ı To left/right channel audio input Ç To S-video output Î To composite video output ‰ To composite video input Ï To S-video input

English

DVD

DIGITAL 1

(DVD)

DIGITAL IN

DIGITAL 2 ( CD )

To audio output

To S-video input

To composite video input

PHONO

Connect the TV to the MONITOR OUT jack to view the playback

picture from the other connected video components.

OUT

(REC)

TAPE

CDR

(PLAY)

OUT

(REC)

VCR

(PLAY)

TV SOUND

RIGHT LEFT

AUDIO

MONITOR

OUT

DVD

OUT

(REC)

VCR

(PLAY)

VIDEO

Digital connections

This receiver is equipped with two DIGITAL IN terminals — one digital coaxial terminal and one digital optical terminal. You can connect any component to one of the digital terminals using a digital coaxial cable (not supplied) or digital optical cable (not supplied).

IMPORTANT:

• When connecting the DVD player or digital TV broadcast tuner using the digital terminal, you also need to connect it to the video jack (either composite video terminal or S-video terminal) on the rear. Without connecting it to the video jack, you can view no playback picture.

• After connecting the components using the DIGITAL IN terminals, set the following correctly if necessary. – Set the digital input (DIGITAL IN) terminal setting correctly. For

details, see “Digital Input (DIGITAL IN) Terminal Setting” on page

15.

– Select the digital input mode correctly. For details, see “Selecting

the Analog or Digital Input Mode” on page 15.

Digital TV

DVD player

• When you connect the DVD player with stereo output jacks:

RIGHT

DVD

AUDIO

DVD player

LEFT

DVD

MONITOR

OUT

DVD

OUT

(REC)

VCR

(PLAY)

VIDEO

Å To front left/right channel audio output (or to audio mixed

output if necessary)

ı To S-video output Ç To composite video output

CD player

When the component has a digital coaxial output terminal, connect it to the DIGITAL 1 (DVD) terminal, using the digital coaxial cable (not supplied).

When the component has a digital optical output terminal, connect it to the DIGITAL 2 (CD) terminal, using the digital optical cable (not supplied).

Before connecting a digital optical cable, unplug the protective plug.

DVD player

CD recorder

Notes:

• When shipped from the factory, the DIGITAL IN terminals have

been set for use with the following components. – DIGITAL 1 (coaxial): For DVD player – DIGITAL 2 (optical): For CD player

• When you want to operate the CD player or CD recorder using the

COMPU LINK remote control system, connect the target component also as described in “Analog connections” (see page 5).

Connecting the Power Cord

Before plugging the receiver into an AC outlet, make sure that all connections have been made.

Plug the power cord into an AC outlet.

Keep the power cord away from the connecting cables and the antenna. The power cord may cause noise or screen interference. We recommend that you use a coaxial cable to connect the antenna, since it is well-shielded against interference.

Note:

The preset settings such as preset channels and sound adjustment may be erased in a few days in the following cases:

– When you unplug the power cord. – When a power failure occurs.

CAUTIONS:

• Do not touch the power cord with wet hands.

• Do not pull on the power cord to unplug the cord. When unplugging the cord, always grasp the plug so as not to damage the cord.

Putting Batteries in the Remote Control

English

Before using the remote control, put two supplied batteries first. When using the remote control, aim the remote control directly at the remote sensor on the receiver.

R6P(SUM-3)/AA(15F)

1. On the back of the remote control, remove the battery cover.

2. Insert batteries. Make sure to match the polarity: (+) to (+) and (–) to (–).

3. Replace the cover.

If the range or effectiveness of the remote control decreases, replace the batteries. Use two R6P(SUM-3)/AA(15F) type dry-cell batteries.

CAUTION:

Follow these precautions to avoid leaking or cracking cells:

• Place batteries in the remote control so they match the polarity: (+) to (+) and (–) to (–).

• Use the correct type of batteries. Batteries that look similar may differ in voltage.

• Always replace both batteries at the same time.

• Do not expose batteries to heat or flame.

Basic Operations

LC S.WFR

LS RS

CH-

LFE

SPK

PRO LOGIC DSP H.PHONE AUTO MUTING TUNED STEREO

VOLUME

BASS BOOST INPUT ATT SLEEP

DIGITAL AUT O

ANALOG

DIGITAL

LINEAR PCM

The following operations are commonly used when you play any sound source.

English

Turning the Power On and Off (Standby)

On the front panel:

To turn on the power, press POWER. The STANDBY lamp goes off. The name of the current source (or station frequency) appears on the display.

STANDBY

POWER

Selected source name appears

Current source name appears

SPK

ANALOG

VOLUME

Current volume level is shown here

To turn off the power (into standby mode),

press POWER again. The STANDBY lamp lights up. A small amount of power is consumed in standby

STANDBY

POWER

mode. To turn the power off completely, unplug the AC power cord.

From the remote control:

To turn on the power, press AUDIO POWER.

AUDIO

POWER

The STANDBY lamp goes off. The name of the current source (or station frequency) appears on the display.

To turn off the power (into standby mode), press AUDIO POWER again. The STANDBY lamp lights up.

Selecting the Source to Play

Press one of the source selecting buttons.

On the front panel:

DVD Select the DVD player. VCR Select the video component connected to the

VCR jacks.

TV SOUND Select TV sounds. CD* Select the CD player. TAPE/CDR* Select the cassette deck (or the CD recorder). FM/AM* Select an FM or AM broadcast.

• Each time you press the button, the band alternates between FM and AM.

Notes:

• When connecting a CD recorder (to the TAPE/CDR jacks), change the source name shown on the display. For details, see page 12.

• When you press one of the source selecting buttons on the remote control marked above with an asterisk (*), the receiver automatically turns on.

Signal and speaker indicators on the display

The signal indicators light up in the following cases:

• Only the indicators for the incoming signals light up.

• When analog input is selected, “L” and “R” always light up.

The speaker indicators light up only —:

• When the corresponding speaker is activated.

AND

• When the corresponding speaker is required for the DSP mode

selected currently.

Signal indicators light up in red:

RCL

S.WFR

LFE

Speaker indicators light up in white:

RCL

S.WFR

LFE

DVD VCR TV SOUND

CD TAPE/CDR

SOURCE NAME

From the remote control:

DVD

TAPE/CDRTV SOUND VCR

FM/AM

LS RSS

L:•When digital input is selected: Lights up when the left

channel signal comes in.

• When analog input is selected: Always lights up.

R:•When digital input is selected: Lights up when the right

channel signal comes in.

• When analog input is selected: Always lights up.

C: Lights up when the center channel signal comes in. LS: Lights up when the left rear channel signal comes in. RS: Lights up when the right rear channel signal comes in. S: Lights up when the monaural rear channel signal comes in. LFE:Lights up when the LFE channel signal comes in.

Note:

When “SUBWOOFER” is set to “YES,”

S.WFR

lights up.

Selecting different sources for picture and sound

You can watch picture from a video component while listening to sound from another component.

Press one of the audio source selecting buttons — CD, TAPE/CDR, FM/AM, TV SOUND (or TV SOUND on the remote control), while viewing the picture from a video component such as the VCR or DVD player, etc.

Selecting the Front Speakers

On the front panel ONLY:

When you have connected two pairs of the front speakers, you can select which to use.

SPEAKERS ON/OFF

English

Note:

Once you have selected a video source, pictures of the selected source are sent to the TV until you select another video source.

Adjusting the Volume

On the front panel:

To increase the volume, turn MASTER VOLUME clockwise. To decrease the volume, turn it counterclockwise.

• When you turn MASTER VOLUME rapidly, the volume level also changes rapidly.

• When you turn MASTER VOLUME slowly, the volume level also changes slowly.

From the remote control:

To increase the volume, press VOLUME +. To decrease the volume, press VOLUME –.

MASTER VOLUME

VOLUME

−

CAUTION:

Always set the volume to the minimum before starting any source. If the volume is set at its high level, the sudden blast of sound energy can permanently damage your hearing and/or ruin your speakers.

Note:

The volume level can be adjusted within the range of “0” (minimum) to “80” (maximum).

To use the speakers connected to the FRONT SPEAKERS 1 terminals, press SPEAKERS ON/OFF 1 so that the SPK 1 indicator

lights up on the display. (Make sure that the SPK 2 is not on the display.)

To use the speakers connected to the FRONT SPEAKERS 2 terminals, press SPEAKERS ON/OFF 2 so that the SPK 2 indicator

lights up on the display. (Make sure that the SPK 1 is not on the display.) To use both sets of the speakers, press SPEAKERS ON/OFF 1 and 2 so that the SPK 1 and SPK 2 indicators light up on the display. To use neither sets of the speakers, press SPEAKERS ON/OFF 1 and 2 so that the SPK 1 and SPK 2 indicators disappear from the display.

Notes:

• If you select any of the DSP modes while using both the speakers connected to the FRONT SPEAKERS 1 and 2 terminals, the speakers connected to the FRONT SPEAKERS 2 terminals are deactivated.

• While the DSP MODE is in use, you can only select either the speakers connected to the FRONT SPEAKERS 1 or 2 terminals.

Listening only with headphones

You must turn off both pairs of speakers when you listen with headphones.

1. Connect a pair of headphones to the PHONES jack on the front

panel.

2. Press SPEAKERS ON/OFF 1 and SPEAKERS ON/OFF 2 so

that neither the SPK 1 nor SPK 2 indicator appears on the display. This cancels the DSP mode currently selected, and activates the HEADPHONE mode (see below).

• “HEADPHONE” appears and H. PHONE indicator lights up on the display.

HEADPHONE mode:

This mode can reproduce the LFE channel signals, mixing them with the front channel signals. So you will not miss the subwoofer sounds even if you listen to a source using the headphones.

Notes:

• While in the HEADPHONE mode, you cannot use any DSP modes (see page 19.)

• Activating the speaker cancels the HEADPHONE mode and turns on the DSP mode previously selected.

CAUTION:

Be sure to turn down the volume before connecting or putting on headphones, as high volume can damage both the headphones and your hearing.

Muting the Sound

TREBLE

−

INPUT

ANALOG/DIGITAL

INPUT ATT

SOUND

CONTROL

DOWN UP

BASS BOOST

English

From the remote control ONLY:

Press MUTING to mute the sound through all speakers and headphones connected.

“MUTING” appears on the display and the volume turns off (the volume level indicator goes off).

To restore the sound, press MUTING again so that “OFF” appears on the display.

• Turning MASTER VOLUME on the front panel or pressing VOLUME +/– on the remote control also restores the sound.

Reinforcing the Bass

You can boost the bass level.

Press BASS BOOST on the front panel or on the remote control to select the bass boost function.

BASS BOOST

On the front panel

• Each time you press the button, the bass boost function turns

on (“BASSBOOST ON”) and off (“BASSBOOST OFF”).

– Select “BASSBOOST ON” to activate the bass boost function.

The BASS BOOST indicator lights up on the display.

– Select “BASSBOOST OFF” to cancel it.

The indicator goes off.

On the remote control

MUTING

From the remote control:

Press BASS +/– or TREBLE +/– to

BASS

−+

adjust the bass or treble sound level (+10 dB to –10 dB).

Attenuating the Input Signal

When the input level of the playing source is too high, the sounds will be distorted. If this happens, you need to attenuate the input signal level to prevent the sound distortion.

On the front panel ONLY:

Press and hold INPUT ATT so that the INPUT ATT indicator lights up on the display.

• Each time you press and hold the button, the Input Attenuator mode turns on (“INPUT ATT ON”) or off (“INPUT NORMAL”).

Notes:

• This function is available only for the sources connected using the

analog terminals.

• This function takes effect when the DSP mode is in use.

Adjusting the Subwoofer Output Level

You can adjust the subwoofer output level if you have selected “YES” for the “SUBWOOFER” (see page 12). Once it has been adjusted, the receiver memorizes the adjustment.

Note:

This function affects the front speaker sounds only.

Adjusting the Tone

You can adjust the bass and treble sounds as you like.

Before you start, remember....

• There is a time limit in doing the following steps. If the setting is canceled before you finish, start from step 1 again.

On the front panel:

1. Press ADJUST repeatedly until

“BASS” or “TREBLE” appears on the display.

• Select “BASS” to adjust the bass sound level.

• Select “TREBLE” to adjust the treble sound level.

2. Press CONTROL UP 5/DOWN ∞

to adjust the bass or treble sound level (+10 dB to –10 dB).

• Each time you press the button, the sound level changes by ± 2 steps.

ADJUST SETTIN

CONTROL

DOWN UP

Before you start, remember....

• There is a time limit in doing the following steps. If the setting is canceled before you finish, start from step 1 again.

• When the front speakers are all deactivated, the subwoofer level cannot be adjusted.

On the front panel:

1. Press ADJUST repeatedly until

ADJUST SETTING

“SUBWFR LEVEL” appears on the display.

The display changes to show the current setting.

2. Press CONTROL UP 5/DOWN ∞

to adjust the subwoofer output level (+10 dB to –10 dB).

From the remote control:

1. Press SOUND.

The 10 keys are activated for sound adjustments.

2. Press SUBWOOFER +/– to adjust

the subwoofer output level (+10 dB

– SUB WOOFER +

0 +10

FM MODE 100

to –10 dB).

Basic Settings

CONTROL

DOWN UP

Some of the following settings are required after connecting and positioning your speakers in your listening room, while others will make operations easier.

Recording a Source

Changing the Source Name

English

You can record any source playing through the receiver to a cassette deck (or a CD recorder) connected to the TAPE/CDR jacks and the VCR connected to the VCR jacks at the same time.

While recording, you can listen to the selected sound source at whatever sound level you like without affecting the sound levels of the recording.

Note:

The output volume level, bass boost (see page 11), tone adjustment (see page 11), and DSP modes (see page 19) cannot affect the recording.

Adjusting the Front Speaker Output Balance

If the sounds you hear from the front right and left speakers are unequal, you can adjust the speaker output balance.

Before you start, remember....

• There is a time limit in doing the following steps. If the setting is canceled before you finish, start from step 1 again.

On the front panel ONLY:

1. Press ADJUST repeatedly until

ADJUST SETTING

“L/R BALANCE” appears on the display.

The display changes to show the current setting.

2. Press CONTROL UP 5/DOWN ∞

CONTROL

DOWN UP

to adjust the balance.

• Pressing CONTROL UP 5 decreases the left channel output from CNTR (Center) to –21.

• Pressing CONTROL DOWN ∞ decreases the right channel output from CNTR (Center) to –21.

When you have connected the CD recorder to the TAPE/CDR jacks on the rear panel, change the source name shown on the display when you select the CD recorder as the source.

On the front panel ONLY:

When changing the source name from “TAPE” to “CDR”:

1. Press TAPE/CDR.

• Make sure “TAPE” appears on the display.

TAPE/CDR

SOURCE NAME

2. Press and hold SOURCE NAME (TAPE/CDR) until “ASSGN. CDR” appears on the display.

To change the source name from “CDR” to “TAPE,”

repeat the same procedure above (in step 1, make sure “CDR”

appears on the display

Note:

Without changing the source name, you can still use the connected components. However, there may be some inconvenience. – “TAPE” will appear on the display when you select the CD

recorder. – You cannot use the digital input (see page 15) for the CD recorder. – You cannot use the COMPU LINK remote control system (see page

26) to operate the CD recorder.

Setting the Subwoofer Information

Before you start, remember....

• There is a time limit in doing the following steps. If the setting is

canceled before you finish, start from step 1 again.

On the front panel ONLY:

1. Press SETTING repeatedly until

SETTING

“SUBWOOFER” appears on the display.

The display changes to show the current setting.

2. Press CONTROL UP 5/DOWN ∞

to register whether you have connected a subwoofer or not.

• Each time you press the button, the subwoofer setting alternates between “YES” and “NO.”

YES: Select this when a subwoofer is used.

up on the display (see page 9.)

NO: Select this when no subwoofer is used.

S.WFR

lights

Setting the Speakers for the DSP Modes

CONTROL

DOWN UP

CONTROL

DOWN UP

English

To obtain the best possible surround sound of the DSP modes, you have to register the information about the speakers arrangement after all connections are completed.

Before you start, remember....

• There is a time limit in doing the following steps. If the setting is canceled before you finish, start from step 1 again.

Front, Center, and Rear Speaker Setting

• When you change your speakers, you need to register the information about the speakers again.

On the front panel ONLY:

1. Press SETTING repeatedly until

“FRONT SPK” (Front Speaker), “CENTER SPK” (Center Speaker) or “REAR SPK” (Rear Speaker) appears on the display.

The display changes to show the current setting.

2. Press CONTROL UP 5/DOWN ∞

to select the appropriate item about the speaker selected in the above step.

• Each time you press the button, the display changes to show the following:

ST SETTING

DOWN UP

CONTROL

Center Delay Time Setting

Register the delay time of the sound from the center speaker, comparing to that of the sound from the front speakers. If the distance from your listening point to the center speaker is equal to that to the front speakers, select 0 msec. As the distance to the center speaker becomes shorter, the delay time increases.

• 1 msec increase (or decrease) in delay time corresponds to

/16 inches (30 cm) decrease (or increase) in distance.

• When shipped from the factory, delay time is set to 0 msec.

On the front panel ONLY:

1. Press SETTING repeatedly until

SETTING

“CENTER DELAY” appears on the display.

The display changes to show the current setting.

2. Press CONTROL UP 5/DOWN ∞ to select the delay time of the center speaker output.

• Press CONTROL UP 5 to increase the delay

time from 0 msec (“C_DELAY 0MS”) to 5 msec (“C_DELAY 5MS”).

• Press CONTROL DOWN ∞ to decrease the

delay time from 5 msec (“C_DELAY 5MS”) to 0 msec (“C_DELAY 0MS”).

Note:

You cannot adjust the center delay time when you have set “CENTER SPK” to “NO.”

LARGE SMALL NO

LARGE: Select this when the speaker size is relatively large. SMALL: Select this when the speaker size is relatively small. NO: Select this when you have not connected a speaker.

(Not selectable for the front speakers)

3. Repeat steps 1 and 2 to select the appropriate items for the other speakers.

Notes:

• Keep the following comment in mind as reference when adjusting.

– If the size of the cone speaker unit built in your speaker is greater

than 4 3/4 inches (12 cm ), select “LARGE,” and if it is smaller than 4 3/4 inches (12 cm ), select “SMALL.”

• If you have selected “NO” for the subwoofer setting, you can only

select “LARGE” for the front speaker setting.

• If you have selected “SMALL” for the front speaker setting, you

cannot select “LARGE” for the center and rear speaker settings.

Rear Delay Time Setting

Register the delay time of the sound from the rear speakers, comparing to that of the sound from the front speakers. If the distance from your listening point to the rear speakers is equal to that to the front speakers, select 0 msec. As the distance to the rear speakers becomes shorter, the delay time increases.

• 1 msec increase (or decrease) in delay time corresponds to

/16 inches (30 cm) decrease (or increase) in distance.

• Rear delay time for Dolby Digital and DTS Digital Surround is to be set to 5 msec.

• When shipped from the factory, delay time is set to 5 msec.

On the front panel ONLY:

1. Press SETTING repeatedly until

SETTING

“REAR DELAY” appears on the display.

The display changes to show the current setting.

2. Press CONTROL UP 5/DOWN ∞

to select the delay time of the rear speaker output.

• Press CONTROL UP 5 to increase the delay time from 0 msec (“R_DELAY 0MS”) to 15 msec (“R_DELAY 15MS”).

• Press CONTROL DOWN ∞ to decrease the delay time from 15 msec (“R_DELAY 15MS”) to 0 msec (“R_DELAY 0MS”).

Note:

You cannot adjust the rear delay time when you have set “REAR SPK” to “NO. ”

Crossover Frequency Setting

CONTROL

DOWN UP

CONTROL

DOWN UP

Small speakers cannot reproduce the bass sound very well. So, if you have used a small speaker for any of the front, center, and rear channels, this receiver automatically reallocate the bass elements, originally assigned to the channel for which you have connected the small speaker, to another channel (for which you have connected the large speaker). To use this function properly, you need to set the crossover frequency level according to the size of the small speaker connected.

• If you have selected “LARGE” for all speakers (see page 13), this function is set to “OFF” and cannot be adjusted.

On the front panel ONLY:

1. Press SETTING repeatedly until

T SETTING

“CROSSOVER FRQ” (Crossover Frequency) appears on the display.

The display changes to show the current setting.

2. Press CONTROL UP 5/DOWN ∞

CONTROL

DOWN UP

to select the crossover frequency level according to the size of the small speaker connected.

• Each time you press the button, the display changes to show the following:

80HZ 100HZ 120HZ

• Use the following comments as reference when adjusting.

80HZ: Select this when the cone speaker unit built in the

speaker is about 4

100HZ: Select this when the cone speaker unit built in the

speaker is about 3

120HZ: Select this when the cone speaker unit built in the

speaker is about 3 3/16 inches (8 cm).

/4 inches (12 cm).

/16 inches (10 cm).

Note:

Crossover frequency is not valid for the HEADPHONE mode.

Low Frequency Effect Attenuator Setting

If the bass sound is distorted while playing back a source using Dolby Digital or DTS Digital Surround, follow the procedure below.

On the front panel ONLY:

1. Press SETTING repeatedly until

SETTING

“LFE ATT” (Low Frequency Effect Attenuator) appears on the display.

The display changes to show the current setting.

2. Press CONTROL UP 5/DOWN ∞ to select the low frequency effect attenuator level.

• Each time you press the button, the display

changes to show the following:

0dB 10dB

0dB: Normally select this. 10dB: Select this when the bass sound is distorted.

Note:

This function takes effect only when the subwoofer (LFE) signals come in, (with “SUBWOOFER” set to “YES.”)

Dynamic Range Compression Setting

You can compress the dynamic range (difference between maximum sound and minimum sound) of the reproduced sound. This is useful when enjoying surround sound at night.

• This function takes effect only when playing back a source using

Dolby Digital.

On the front panel ONLY:

1. Press SETTING repeatedly until “D_RANGE COMP” (Dynamic Range Compression) appears on the display.

The display changes to show the current setting.

2. Press CONTROL UP 5/DOWN ∞ to select the appropriate item about the compression level.

• Each time you press the button, the display

changes to show the following:

OFF MID MAX

OFF: Select this when you want to enjoy surround with its

full dynamic range. (No effect applied.)

MID: Select this when you want to reduce the dynamic

range a little. (Factory setting.)

MAX: Select this when you want to apply the compression

effect fully. (Useful at night.)

Note:

Dynamic Range Compression is not valid for the DTS Digital Surround.

English

DIGIT AL A UT O

LINEAR PCM

DVD VTR TV SOUND

CD TAPE/CDR

SOURCE NAME

FM/AM

Digital Input (DIGITAL IN) Terminal

English

Setting

Selecting the Analog or Digital Input Mode

When you use the digital input terminals, you have to register what components are connected to which terminals (DIGITAL IN 1/2).

Before you start, remember...

• There is a time limit in doing the following steps. If the setting is canceled before you finish, start from step 1 again.

On the front panel ONLY:

1. Press SETTING repeatedly until

SETTING

“DIGITAL IN” appears on the display.

The display changes to show the current setting.

DIGITAL 2 terminal setting

DIGITAL 1 terminal setting

2. Press CONTROL UP 5/DOWN ∞

CONTROL

DOWN UP

to select the appropriate digital terminal setting.

• Each time you press the button, the display changes to show the following:

1 DVD 2 CD “ 1 DVD 2 TV “ 1 DVD 2 CDR“ 1 CD 2 DVD “ 1 CD 2 TV “ 1 CD 2 CDR “ 1 TV 2 DVD “ 1 TV 2 CD “ 1 TV 2 CDR “ 1 CDR 2 DVD “ 1 CDR 2 CD “ 1 CDR 2 TV “ (back to the beginning)

Note:

When shipped from the factory, the DIGITAL IN terminals can be used as the digital input for the following components.

• DIGITAL 1 (coaxial): For DVD player

• DIGITAL 2 (optical): For CD player

When you have connected digital source components, you need to select the input mode correctly according to the connection you made.

Before you start, remember...

• The digital input (DIGITAL IN) terminal setting should be correctly done for the sources you want to select the digital input mode for. Without setting this digital input terminal

correctly, you cannot change the input mode from analog input to digital input even if you follow the procedure below.

On the front panel:

1. Press one of the

source selecting buttons (DVD, TV SOUND, CD, or TAPE/CDR)* for which you want to change the input mode.

Note:

Among the sources listed above, you can select the digital input only for the sources which you have selected the digital input terminals for. (See “Digital Input (DIGITAL IN) Terminal Setting.”)

2. Press INPUT ANALOG/DIGITAL

INPUT

ANALOG/DIGITAL

to change the input mode.

• Each time you press the button, the input mode changes as follows:

AUTO

(Digital)

AUTO: Select this for the digital input mode. The receiver

automatically detects the incoming signal format. (The DIGITAL AUTO indicator lights up on the display, and the digital signal indicator for the detected signals also light up.)*

ANALOG: Select this for the analog input mode.

ANALOG

INPUT ATT

* The followings are the analog/digital signal indicators on the

display to indicate what type of the signal comes into the receiver.

: Lights up when “AUTO” is selected as

the digital input mode.

ANALOG

: Lights up when the analog input is

selected.

: Lights up when Linear PCM signals

come in.

DIGIT AL

: Lights up when Dolby Digital signals

come in.

: Lights up when DTS Digital Surround

signals come in.

When playing a software encoded with the DTS Digital

SLEEP

2010 30 40 50 60 70 80 90

(Canceled)

Surround, “AUTO” may not work properly and the following symptoms may occur:

• Sound does not come out at the beginning of playback.

• Noise comes out while using the searching or skipping function.

In this case, press CONTROL UP 5/ DOWN ∞ to select “DTS” while “AUTO”

CONTROL

DOWN UP

is lit on the display.

• Each time you press the button, the input mode changes as follows:

AUTO

(Digital)

DTS

(Digital)

Note:

When you turn off the power or select another source, “DTS” setting is canceled and the digital input mode is automatically reset to “AUTO.”

To change the input mode back to analog input, select “ANALOG” by pressing INPUT ANALOG/DIGITAL again.

From the remote control:

1. Press the source selecting button (D VD, CD,

DVD

TAPE/CDRTV SOUND VCR

TV SOUND, or TAPE/CDR)* for which you want to change the input mode.

Note:

Among the sources listed above, you can select the digital input only for the sources which you have selected the digital input terminals for. (See “Digital Input (DIGITAL IN) Terminal Setting.”)

2. Press ANALOG/DIGIT AL to change the input mode.

• Each time you press the button, the

input mode changes as follows:

ANALOG/DIGITAL

INPUT

FM/AM

Storing the Basic Settings and Adjustments

You can assign and store different sound settings for each different playing source. By using this function, you do not have to change the settings every time you change the source. The stored settings for the newly selected source are automatically recalled.

The following can be stored for each source:

• Bass boost (see page 11)

• Tone adjustment (see page 11)

• Input attenuator mode (see page 11)

• Subwoofer output level (see page 11)

• Balance (see page 12)

• DSP modes – Surround mode (see page 22) – DAP mode (see page 24)

The above settings are stored automatically in the following cases:

• When you turn on the power.

• When you change the source.

• When you assign the source name.

Notes:

• You cannot assign and store different settings for digital input mode

and analog input mode.

• If the source is FM or AM, you can assign a different setting for

each band.

Using the Sleep Timer

Using the Sleep Timer, you can fall asleep to music and know the receiver will turn off by itself rather than play all night.

From the remote control ONLY:

Press SLEEP repeatedly.

The SLEEP indicator lights up on the display, and the shut-off time changes as follows (in minutes):

English

ANALOG

AUTO

(Digital)

When playing a software encoded with the DTS Digital Surround, “AUTO” may not work properly, In this case, press

CONTROL UP 5/DOWN ∞ on the front panel to select “DTS.” (See above.)

Note:

You can only select “ANALOG” and “AUTO” using the remote control.

When the shut-off time comes

The receiver turns off automatically.

To check or change the time remaining until the shut-off time

Press SLEEP once. The remaining time until the shut-off time appears in minutes.

• To change the shut-off time, press SLEEP repeatedly.

To cancel the Sleep Timer

Press SLEEP repeatedly until “SLEEP 00 MIN.” appears on the display. (The SLEEP indicator goes off.)

• Turning off the power also cancels the Sleep Timer.

Receiving Radio Broadcasts

MEMORY

You can browse through all the stations or use the preset function to go immediately to a particular station.

Tuning in Stations Manually

English

On the front panel:

1. Press FM/AM to select the band (FM or AM).

The last received station of the selected band is tuned in.

• Each time you press the button, the band alternates between

FM and AM.

SPK

ANALOG

TUNED

2. Press FM/AM TUNING 5/ ∞ until you find the frequency you want.

• Pressing FM/AM TUNING 5 increases

the frequency.

• Pressing FM/AM TUNING ∞ decreases

the frequency.

From the remote control:

1. Press FM/AM to select the band.

• Each time you press the button, the band

alternates between FM and AM.

2. Press TUNING +/– until you find the frequency you want.

• Pressing TUNING + increases the

frequency.

• Pressing TUNING – decreases the

frequency.

Notes:

• When a station of sufficient signal strength is tuned in, the TUNED

indicator lights up on the display.

• When an FM stereo program is received, the STEREO indicator

also lights up.

FM/AM

VOLUME

FM/AM TUNING

FM/AM

TUNING

−

Using Preset Tuning

Once a station is assigned to a channel number, the station can be quickly tuned. You can preset up to 30 FM and 15 AM stations.

To store the preset stations

Before you start, remember...

• There is a time limit in doing the following steps. If the setting is canceled before you finish, start from step 1 again.

On the front panel ONLY:

1. Tune in the station you want to preset (see

“Tuning in Stations Manually”).

• If you want to store the FM reception mode for this station, select the FM reception mode you want. See “Selecting the FM Reception Mode” on page 18.

SPK

ANALOG

TUNED

VOLUME

2. Press MEMORY.

SPK

ANALOG

CH-

TUNED

VOLUME

“CH-” appears and the channel number position starts flashing on the display for about 5 seconds.

3. Press FM/AM PRESET 5/ ∞ to

FM/AM PRESET

select a channel number while the channel number position is flashing.

SPK

ANALOG

CH-

TUNED

VOLUME

Note:

You can use the 10 keys on the remote control to select the preset number. When using the 10 keys, be sure that they are activated for the tuner, not for the CD and others. (See page 27.)

4. Press MEMORY again while the selected channel number is flashing on the display.

The selected channel number stops flashing. The station is assigned to the selected channel number.

SPK

ANALOG

CH-

TUNED

VOLUME

5. Repeat steps 1 to 4 until you store all the stations you want.

To erase a stored preset station

Storing a new station on a used number erases the previously stored one.

To tune in a preset station

FM MODE

On the front panel:

1. Press FM/AM to select the band (FM or AM).

The last received station of the selected band is tuned in.

FM/AM

Selecting the FM Reception Mode

English

When an FM stereo broadcast is hard to receive or noisy

You can change the FM reception mode while receiving an FM broadcast.

• You can store the FM reception mode for each preset station.

2. Press FM/AM PRESET 5/ ∞ until

FM/AM PRESET

you find the channel you want.

• Pressing FM/AM PRESET 5 increases the

channel numbers.

• Pressing FM/AM PRESET ∞ decreases the

channel numbers.

From the remote control:

1. Press FM/AM.

• Each time you press the button, the band

alternates between FM and AM.

2. Press the 10 keys to select a preset channel number.

• For channel number 5, press 5.

• For channel number 15, press +10 then 5.

• For channel number 20, press +10 then 10.

• For channel number 30, press +10, +10,

then 10.

Note:

When you use the 10 keys on the remote control, be sure that they are activated for the tuner, not for the CD and others. (See page 27.)

FM/AM

– CENTER +

EFFECT

231

– REAR • L +

TEST

564

ENTER

– REAR • R +

897/P

– SUB WOOFER +

RETURN FM MODE 100

+1010

Press FM MODE on the front panel or on the remote control.

• Each time you press the button, the FM reception mode alternates between “AUTO” and “MONO.”

– SUB WOOFER +

FM MODE

On the front panel On the remote control

SPK

ANALOG

AUTO: When a program is broadcasted in stereo, you will hear

MONO: Reception will be improved although you will lose the

SPK

AUTO MUTING TUNED STEREO

TUNED

stereo sound; when in monaural, you will hear monaural sounds. This mode is also useful to suppress static noise between stations. The AUTO MUTING indicator lights up on the display.

stereo effect. In this mode, you will hear noise while tuning into the stations. The AUTO MUTING indicator goes off from the display.

Note:

When using the FM MODE button on the remote control, be sure that the 10 keys are activated for the tuner, not for the CD and others. (See page 27.)

Using the DSP Modes

DOLBY SURROUND

The built-in Surround Processor provides two types of the DSP (Digital Signal Processor) mode — Surround mode and DAP (Digital Acoustic Processor) mode.

English

What are the DSP Modes?

Surround modes

With this receiver, you can use three types of the Surround mode.

Following modes cannot be used when only the front speakers are connected to this receiver (without the rear speakers or center speaker).

JVC Theater Surround

In order to reproduce a more realistic sound field in your listening room while playing soundtracks of software encoded with Dolby Surround (bearing the mark

), you can use JVC

Theater Surround.

Dolby Surround (Dolby Digital and Dolby Pro Logic)

Used to watch the soundtracks of software encoded with Dolby Digital (bearing the mark (bearing the mark

DOLBY SURROUND

DIGITAL

) or with Dolby Surround

). Dolby Surround encoding format records the left front channel, right front channel, center channel, and rear channel (total 4 channels) signals into 2 channels. The Dolby Pro Logic decoder built in this receiver decodes these 2 channel signals into original 4 channel signals — matrix-based multichannel reproduction, and allows you to enjoy the realistic stereo sounds in your listening room. On the other hand, Dolby Digital encoding method (so called discrete 5.1 channel digital audio format) records and compresses the left front channel, right front channel, center channel, left rear channel, right rear channel, and LFE channel (total 6 channels, but LFE channel is counted as 0.1 channel, therefore called 5.1 channels) signals digitally. Each channel is completely independent from other channel signals to avoid interference, therefore, you can obtain much better sound quality with much stereo and surround effects. The Dolby Digital decoder built in this receiver can create much more realistic sound field in your listening room. You may feel as if you were in a real theater. In addition, Dolby Digital enables stereo rear sounds, and sets the cutoff frequency of the rear treble at 20 kHz, compared to 7 kHz for Dolby Pro Logic. These facts enhance the sound movement and being-there feelings much more than Dolby Pro Logic.

• To enjoy the software encoded with Dolby Digital, you must

connect the source component using the digital terminal on the rear of this receiver. (See page 7.)

Notes:

• The DSP modes have no effect on monaural sources.

• The

PRO LOGIC

decoder built in this receiver is activated.

indicator lights up when the Dolby Pro Logic

DTS Digital Surround

DTS Digital Surround is another discrete 5.1 channel digital audio format available on CD, LD, and DVD software. Compared to Dolby Digital, audio compression rate is relatively low. This fact allows DTS Digital Surround format to add breadth and depth to the reproduced sounds. As a result, DTS Digital Surround features natural, solid and clear sound.

• To enjoy the software encoded with DTS Digital Surround, you

must connect the source component using the digital terminal on the rear of this receiver. (See page 7.)

Manufactured under license from Dolby Laboratories. “Dolby,” “Pro Logic,” and the double-D symbol are trademarks of Dolby Laboratories. Confidential Unpublished Works. ©1992–1997 Dolby Laboratories, Inc. All rights reserved.

Manufactured under license from Digital Theater Systems, Inc. US Pat. No. 5,451,942 and other world-wide patents issues and pending. “DTS” and “DTS Digital Surround” are trademarks of Digital Theater Systems, Inc. ©1996 Digital Theater Systems, Inc. All rights reserved.

DAP modes

In order to reproduce a more acoustic sound field in your listening room while playing soundtracks of stereo sources, you can use DAP modes. This mode can be used when the front speakers and the

rear speakers are connected to this receiver (without respect to the center speaker connection).

You can select one of the following to your preference.

LIVE CLUB: Gives the feeling of a live music club with a low

ceiling.

DANCE CLUB:Gives a throbbing bass beat. HALL: Gives clear vocal and the feeling of a concert hall. PAVILION: Gives the spacious feeling of a pavilion with a

high ceiling.

Reproducing the Sound Field

The sound heard in a concert hall or club consists of direct sound and indirect sound — early reflections and reflections from behind. Direct sounds reach the listener directly without any reflection. On the other hand, indirect sounds are delayed by the distances of the ceiling and walls. These direct sounds and indirect sounds are the most important elements of the acoustic surround effects. JVC Theater Surround and DAP modes can create these important elements, and give you a real “being there” feeling.

Reflections from

Early reflections

Direct sounds

behind

English

Available DSP modes according to the input mode

BUTTON SURROUND ON/OFF DSP MODE

MODE SURROUND ON THEATER LIVE CLUB DANCE CLUB HALL PAVILION

ANALOG V

(2 CH) (DOLBY PRO LOGIC)

LINEAR PCM

DOLBY DIGITAL

INPUT

DTS

*1When 2 channel signal comes in, DOLBY PRO LOGIC is selected. When other signals come in, DOLBY DIGITAL is selected. *2When 2 channel signal comes in, DOLBY PRO LOGIC is selected. When other signals come in, DTS SURROUND is selected.

(DOLBY PRO LOGIC)

V *

(DOLBY DIGITAL)

V *

(DTS SURROUND)

VV VVV V

22 222 V

V: Possible 2: Impossible

(SURROUND OFF)

DSP OFF

Available DSP Modes According to the Speaker Arrangement

English

Available DSP modes will vary depending on how many speakers are used with this receiver.

Make sure that you have set the speaker information correctly (see page 13).

Front

speaker

Rear

speaker

Front

speaker

Rear

speaker

Front

speaker

Speaker arrangements

Center speaker

Front

speaker

Rear

speaker

Front

speaker

Rear

speaker

Front

speaker

Available DSP modes

By pressing SURROUND ON/ OFF, the surround mode turns on and off:

• SURROUND ON (PRO LOGIC, DOLBY DIGITAL or DTS SURROUND)

• SURROUND OFF (DSP mode is canceled)

By pressing SURROUND ON/ OFF, the surround mode turns on and off:

• SURROUND ON (PRO LOGIC, DOLBY DIGITAL or DTS SURROUND)

• SURROUND OFF (DSP mode is canceled)

By pressing DSP MODE, the DSP modes change as follows:

• THEATER

• LIVE CLUB

• DANCE CLUB

• HALL

• PAVILION

• DSP OFF (DSP mode is canceled)

By pressing DSP MODE, the DSP modes change as follows:

• THEATER

• DSP OFF (DSP mode is canceled)

Adjusting the Surround Modes

– CENTER +

ENTER

– REAR • R +

TEST

SURROUND ON/OFF

ADJUST SETTING

CONTROL

DOWN UP

Once you have adjusted the Surround modes, the adjustment is memorized for each Surround mode.

Dolby and DTS Surround adjustments

Before you start, remember...

• Make sure that you have set the speaker information correctly (see page 13).

• There is a time limit in doing the following steps. If the setting is canceled before you finish, start from step 3 again.

• You cannot adjust the rear speaker output levels when you have set “REAR SPK” to “NO.” See page 13.

• You cannot adjust the center speaker output level when you have set “CENTER SPK” to “NO.” See page 13.

5. Adjust the speaker output levels.

• To adjust the center speaker level, press CENTER +/– (from +10 dB to –10 dB).

• To adjust the left rear speaker level, press REAR•L +/– (from +10 dB to –10 dB).

• To adjust the right rear speaker level, press REAR•R +/– (from +10 dB to –10 dB).

– REAR • L +

ENTER

6. Press TEST again to stop the test tone.

English

From the remote control:

1. Select and play a sound source.

• To enjoy Dolby Pro Logic, play back a software encoded with Dolby Surround and labeled with

• To enjoy Dolby Digital, play back a software encoded with Dolby Digital and labeled with

• To enjoy DTS Digital Surround, play back a software encoded with DTS Digital Surround and labeled with

2. Press SURROUND ON/OFF to activate an appropriate Surround

DOLBY SURROUND

DIGITAL

mark.

SURROUND

ON/OFF

mode — PRO LOGIC, DOLBY DIGITAL or DTS SURROUND.

When “PRO LOGIC” is selected, the PRO LOGIC indicator lights up on the display.

• Each time you press the button, the Surround mode turns on

and off alternately.

3. Press SOUND.

SOUND

The 10 keys are activated for sound adjustments.

4. Press TEST to check the speaker output balance.

“TEST TONE L” starts flashing on the display, and a test tone comes out of the speakers in the following order:

TEST TONE L

(Left front speaker)

TEST TONE LS

(Left rear speaker)

TEST TONE C

(Center speaker)

Notes:

• You can adjust the speaker output levels without outputting the

test tone.

• No test tone comes out of the center speaker when “CENTER

SPK” is set to “NO” (see page 13).

• No test tone comes out of the rear speakers when “REAR SPK”

is set to “NO” (see page 13).

TEST TONE R

(Right front speaker)

TEST TONE RS

(Right rear speaker)

TEST

On the front panel:

You can also use the buttons on the front panel to adjust the Surround modes. However, no test tone is available when using the buttons on the front panel. So, make adjustments while listening to the sound of the source played back.

1. Select and play a sound source.

• To enjoy Dolby Pro Logic, play back a software encoded with Dolby Surround and labeled with

• To enjoy Dolby Digital, play back a software encoded with Dolby Digital and labeled with

• To enjoy DTS Digital Surround, play back a software encoded with DTS Digital Surround and labeled with

DOLBY SURROUND

DIGITAL

mark.

2. Press SURROUND ON/OFF to activate an appropriate Surround mode — PRO LOGIC, DOLBY DIGITAL or DTS SURROUND.

When “PRO LOGIC” is selected, the PRO LOGIC indicator lights up on the display.

• Each time you press the button, the Surround mode turns on

and off alternately.

3. Adjust the speaker output levels.

1) Press ADJUST repeatedly until one of

the following indications appears on the display.

“CENTER LEVEL”:

To adjust the center speaker level.

“REAR L LEVEL”:

To adjust the left rear speaker level.

“REAR R LEVEL”:

To adjust the right rear speaker level.

2) Press CONTROL UP 5/DOWN ∞ to

adjust the selected speaker output level (from +10 dB to –10 dB).

3) Repeat 1) and 2) to adjust the other

speaker output levels.

JVC Theater Surround adjustments

DSP MODE

CONTROL

DOWN UP

ADJUST SETTING

CONTROL

DOWN UP

English

Before you start, remember...

• Make sure that you have set the speaker information correctly (see page 13).

• There is a time limit in doing the following steps. If the setting is canceled before you finish, start from step 2 again.

• You cannot adjust the rear speaker output levels when you have set “REAR SPK” to “NO.” See page 13.

• You cannot adjust the center speaker output level when you have set “CENTER SPK” to “NO.” See page 13.

From the remote control:

1. Press DSP MODE repeatedly until

“THEATER” appears on the display.

The PRO LOGIC and DSP indicators also light up on the display.

2. Press SOUND.

The 10 keys are activated for sound adjustments.

3. Press TEST to check the speaker

output balance.

“TEST TONE L” starts flashing on the display, and a test tone comes out of the speakers in the following order:

TEST TONE L

(Left front speaker)

TEST TONE LS

(Left rear speaker)

TEST TONE C

(Center speaker)

TEST TONE R

(Right front speaker)

TEST TONE RS

(Right rear speaker)

Notes:

• You can adjust the speaker output levels without outputting the test tone.

• No test tone comes out of the center speaker when “CENTER SPK” is set to “NO” (see page 13).

• No test tone comes out of the rear speakers when “REAR SPK” is set to “NO” (see page 13).

4. Adjust the speaker output levels.

• To adjust the center speaker level, press CENTER +/– (from

+10 dB to –10 dB).

• To adjust the left rear speaker level, press REAR•L +/– (from

+10 dB to –10 dB).

• To adjust the right rear speaker level, press REAR•R +/– (from

+10 dB to –10 dB).

– CENTER +

– REAR • L +

ENTER

DSP

MODE

SOUND

TEST

ENTER

– REAR • R +

5. Press TEST again to stop the test tone.

6. Press EFFECT to select an effect level you want.

TEST

EFFECT

• Each time you press the button, the effect

level changes as follows:

DSP EFFECT 1 DSP EFFECT 2 DSP EFFECT 3

DSP EFFECT 4DSP EFFECT 5

As the number increases, JVC Theater Surround becomes stronger (normally set it to “DSP EFFECT 3”).

On the front panel:

1. Press DSP MODE repeatedly until “THEATER” appears on the display.

The PRO LOGIC and DSP indicators also light up on the display.

2. Adjust the speaker output levels.

1) Press ADJUST repeatedly until one of

the following indications appears on the display.

“CENTER LEVEL”:

To adjust the center speaker level.

“REAR L LEVEL”:

To adjust the left rear speaker level.

“REAR R LEVEL”:

To adjust the right rear speaker level.

2) Press CONTROL UP 5/DOWN ∞ to

adjust the selected speaker output level (from +10 dB to –10 dB).

3) Repeat 1) and 2) to adjust the other

speaker output levels.

ADJUST SETTING

3. Adjust the effect level.

1) Press ADJUST repeatedly until “DSP

EFFECT” appears on the display.

The display changes to show the current setting.

2) Press CONTROL UP 5/DOWN ∞ to

select the effect level.

• Each time you press the button, the effect level changes as follows:

DSP EFFECT 1 DSP EFFECT 2 DSP EFFECT 3

DSP EFFECT 4DSP EFFECT 5

As the number increases, JVC Theater Surround becomes stronger (normally set it to “DSP EFFECT 3”).

Adjusting the DAP Modes

DSP

MODE

ENTER

– REAR • L +

ENTER

– REAR • R +

SOUND

EFFECT

DSP EFFECT 1 DSP EFFECT 2 DSP EFFECT 3

DSP EFFECT 4DSP EFFECT 5

Once you have adjusted the D AP modes, the adjustment is memorized for each DAP mode.

Before you start, remember...

• Make sure that you have set the speaker information correctly (see page 13).

• There is a time limit in doing the following steps. If the setting is canceled before you finish, start from step 1 again.

• You cannot adjust the rear speaker output level when you have set “REAR SPK” to “NO.” See page 13.

On the front panel:

1. Press DSP MODE repeatedly until

DSP MODE

the DAP mode — LIVE CLUB, DANCE CLUB, HALL, or PAVILION — appears on the display.

The DSP indicator also lights up on the display.

2. Adjust the rear speaker output levels.

1) Press ADJUST repeatedly until one of the following indications appears on the display.

“REAR L LEVEL”:

To adjust the left rear speaker level.

“REAR R LEVEL”:

To adjust the right rear speaker level.

2) Press CONTROL UP 5/DOWN ∞ to adjust the selected speaker output level (from +10 dB to –10 dB).

3) Repeat 1) and 2) to adjust the other speaker output level.

ADJUST SETTING

CONTROL

DOWN UP

From the remote control:

1. Press DSP MODE repeatedly until the DAP mode — LIVE CLUB, DANCE CLUB, HALL, or PAVILION — appears on the display.

The DSP indicator also lights up on the display.

2. Press SOUND.

The 10 keys are activated for sound adjustments.

3. Adjust the rear speaker output levels.

• To adjust the left rear speaker level, press

REAR•L +/– (from +10 dB to –10 dB).

• To adjust the right rear speaker level, press

REAR•R +/– (from +10 dB to –10 dB).

4. Press EFFECT to select an effect level you want.

• Each time you press the button, the effect

level changes as follows:

As the number increases, the selected DAP mode becomes stronger (normally set it to “DSP EFFECT 3”).

English

3. Adjust the effect level.

1) Press ADJUST repeatedly until “DSP EFFECT” appears on the display.

The display changes to show the current setting.

2) Press CONTROL UP 5/DOWN ∞ to select the effect level.

• Each time you press the button, the

effect level changes as follows:

DSP EFFECT 1 DSP EFFECT 2 DSP EFFECT 3

DSP EFFECT 4DSP EFFECT 5

As the number increases, the selected DAP mode becomes stronger (normally set it to “DSP EFFECT 3”).

DOWN UP

ADJUST SETTING

CONTROL

Activating the DSP Modes

English

You can use only one DSP mode at a time. When a DSP mode is activated, another DSP mode is canceled if in use.

For Dolby Pro Logic, Dolby Digital, and DTS Digital Surround

For the other DSP modes

1. Press DSP MODE repeatedly until the mode you want appears on the display.

• Each time you press the button, the DSP modes change. (See

page 21 for more details.)

1. Press SURROUND ON/OFF.

• Each time you press the button, the Dolby/DTS Surround turns on and off alternately.

SURROUND ON/OFF

On the front panel

SURROUND

ON/OFF

On the remote control

2. Select and play a sound source.

• To enjoy Dolby Pro Logic, play back a software encoded with Dolby Surround and labeled with

• To enjoy Dolby Digital, play back a software encoded with Dolby Digital and labeled with

• To enjoy DTS Digital Surround, play back a software encoded with DTS Digital Surround and labeled with

To cancel the Dolby/DTS Surround mode

Press SURROUND ON/OFF again. (“SURROUND OFF” appears on the display.)

SURROUND ON/OFF

DOLBY SURROUND

DIGITAL

SURROUND

mark.

ON/OFF

DSP MODE

On the front panel

DSP

MODE

On the remote control

2. Select and play a sound source.

• To enjoy JVC Theater Surround, play back a software encoded with Dolby Surround and labeled with

To cancel the DSP mode

Press DSP MODE repeatedly until “DSP OFF” appears on the display.

DSP MODE

On the front panel

On the remote control

DOLBY SURROUND

DSP

MODE

mark.

On the front panel

On the remote control

COMPU LINK Remote Control System

The COMPU LINK remote control system allows you to operate JVC audio components through the remote sensor on the receiver.

To use this remote control system, you need to connect JVC audio components through the COMPU LINK (SYNCHRO) jacks (see below) in addition to the connections using cables with RCA pin plugs (see pages 5 and 6).

• Make sure that the AC power cords of these components are unplugged before connection. Plug the AC power cords only after all connections are complete.

Cassette deck

CD recorder

COMPU LINK-4

(SYNCHRO)

CD player

Notes:

• There are four versions of COMPU LINK remote control system.

This receiver is equipped with the fourth version — COMPU LINK-

4. This version is added systematic operations with the CD recorder to the previous version — COMPU LINK-3.

• If your audio component has two COMPU LINK jacks, you can use

either one. If it has only one COMPU LINK jack, connect it so that it is the last item in the series of components. (For example, the CD player in the diagram above.)

• To operate the cassette deck or CD recorder using the COMPU

LINK remote control system, set the source name correctly. (See page 12.)

• Refer also to the manuals supplied with your audio components.

This remote control system allows you to use four functions listed below.

Remote Control through the Remote Sensor on the Receiver

You can control the connected audio components through the remote sensor on the receiver using this remote control. Aim the remote control directly at the remote sensor on the receiver. For details, see pages 27 and 28.

Automatic Power On/Off (Standby): only possible with the COMPU LINK-3 and COMPU LINK--4 connection

The connected components turn on and off (standby) along with the receiver. When you turn on the receiver, one of the connected component will turn on automatically, depending on which component has been previously selected. When you turn off the receiver, the connected components will turn off (standby).

Synchronized Recording

Synchronized recording means the cassette deck starts recording as soon as a CD begins playing.

To use synchronized recording, follow these steps:

1. Put a tape in the cassette deck, and a disc in the CD player.

2. Press the record (¶) button and the pause (8) button on the cassette deck at the same time.

This puts the cassette deck into recording pause. If you do not press the record (¶) button and pause (8) button at the same time, the synchronized recording feature will not operate.

3. Press the play (3) button on the CD player.

The source changes on the receiver, and as soon as play starts, the cassette deck starts recording. When the play ends, the cassette deck enters recording pause, and stops about 4 seconds later.

Notes:

• During synchronized recording, the selected source cannot be

changed.

• If the power of any component is shut off during synchronized

recording, the COMPU LINK remote control system may not operate properly. In this case, you must start again from the beginning.

English

Automatic Source Selection

When you press the play ( on its own remote control, the receiver automatically turns on and changes the source to the component. On the other hand, if you select a new source on the receiver or on the remote control, the selected component begins playing immediately. In both cases, the previously selected source continues playing without sound for a few seconds.

3) button on a connected component or

Operating JVC’s Audio/Video Components

You can operate JVC’s audio and video components with this receiver’s remote control, since control signals for JVC components are preset in the remote control.

English

Operating Audio Components

IMPORTANT:

To operate JVC’s audio components using this remote control:

• You need to connect JVC audio components through the COMPU LINK (SYNCHRO) jacks (see page 26) in addition to the connections using cables with RCA pin plugs (see pages 5 and 6).

• Aim the remote control directly at the remote sensor on the receiver.

• If you use the buttons on the front panel, the remote control will not operate that source. To operate a source with the remote control, the source must be selected using source selecting buttons on the remote control.

• To operate the cassette deck or CD recorder using the COMPU LINK remote control system, set the source name correctly. (See page 12.)

• Refer also to the manuals supplied with your components.

CATV/DB S VCR TV AUDIO

POWER POWER POWER

POWER

DVD

TV SOUND VCR

SURROUND

BASS BOOST EFFECT

SOUND

MUTING

CATV/DBS CONTROL

CONTROL

TV/VIDEO

TUNING

REC

PAUSE

* When you press one of the following buttons, the remote

control operation mode appears on the display window for about 10 seconds.

FM/AM

TAPE/CDR

TREBLE

BASS

−−++

DSP

ANALOG/DIGITAL

SLEEP

MODE INPUTON/OFF

– CENTER +

231

– REAR • L +

TEST

564

ENTER

– REAR • R +

897/P

– SUB WOOFER +

+1010

PLAY

PAUSE

STOP

VOLUME

CONTROL

−

RETURN FM MODE 100

+−+−+

CH TV VOL

−

RM-SRX6510J

A/V CONTROL RECEIVER

/REW FF/

Ex.: When you press CD button

Tuner

You can always perform the following operations: FM/AM: Alternates between FM and AM.

After pressing FM/AM, you can perform the following operations: 1 – 10, +10: Selects a preset channel number directly.

For channel number 5, press 5. For channel number 15, press +10, then 5. For channel number 20, press +10, then 10.

TUNING +/–: Tunes into stations. FM MODE: Changes the FM reception mode.

Sound control section (Amplifier)

You can always perform the following operations: SURROUND ON/OFF: Turns on or off the Surround modes –

Dolby Pro Logic, Dolby Digital, and DTS Digital Surround.

DSP MODE: Selects the DSP modes.

After pressing SOUND, you can perform the following operations:

SUBWOOFER +/–: Adjusts the subwoofer output level. CENTER +/–: Adjusts the center speaker output level. REAR•L +/–: Adjusts the left rear speaker output level. REAR•R +/–: Adjusts the right rear speaker output level. EFFECT: Selects the effect level. TEST: Turns on or off the test tone output.

Note:

After adjusting sounds, press the corresponding source selecting button to operate your target source by using the 10 keys; otherwise, the 10 keys cannot be used for operating your target source.

CD player

After pressing CD, you can perform the following operations on the CD player:

PLAY3: Starts playing.

4: Returns to the beginning of the current (or

previous) track.

¢¢

¢: Skips to the beginning of the next track.

¢¢

STOP7: Stops playing. PAUSE8: Pauses playing. To release it, press PLAY3. 1 – 10, +10: Selects a track number directly.

For track number 5, press 5. For track number 15, press +10, then 5. For track number 20, press +10, then 10. For track number 30, press +10, +10, then 10.

Buttons on the Remote Control Remote Control Operation Mode

FM/AM TUNER

CD CD

TAPE/CDR TAPE

DVD DVD

TV SOUND TV

VCR VCR

CATV/DBS CONTROL DBS

CONTROL

Current setting or VCR or TAPE

or CDDSC

SOUND SOUND

CD changer

After pressing CONTROL repeatedly until “CDDSC” appears on the display window, you can perform the following operations on the CD changer:

PLAY3: Starts playing.

4: Returns to the beginning of the current (or previous)

track.

¢¢

¢: Skips to the beginning of the next track.

¢¢

STOP7: Stops playing. PAUSE8: Pauses playing. To release it, press PLAY3. 1 – 6, 7/P: Selects the number of a disc installed in a CD

changer.

After pressing CD, you can perform the following operations on the CD changer:

1 – 10, +10: Selects a track number directly.

For track number 5, press 5. For track number 15, press +10, then 5. For track number 20, press +10, then 10. For track number 30, press +10, +10, then 10.

EXAMPLE:

• Selecting disc number 4, track number 12, and starting playback.

1. Press CONTROL repeatedly until “CDDSC” appears on the display window, then press 4.

2. Press CD, then press +10, 2.

If your CD changer is of 200-disc loading capability (except for XL-MC100 and XL-MC301)

you can do the following operations using the number buttons after pressing CD.

1. Select a disc number.

2. Then select a track number (always enter two digits).

3. Start playback.

EXAMPLES:

• Selecting disc number 3, track number 2, and starting playback. Press 3, then, 0, 2, then PLAY3.

• Selecting disc number 10, track number 5, and starting playback. Press 1, 0, then, 0, 5, then PLAY3.

• Selecting disc number 105, track number 12, and starting playback. Press 1, 0, 5, then 1, 2 then PLAY3.

Cassette deck

After pressing TAPE/CDR (or CONTROL repeatedly until “TAPE” appears on the display window), you can perform the following operations on a cassette deck:

PLAY3: Starts playing. REW: Fast winds the tape from right to left. FF: Fast winds the tape from left to right. STOP7: Stops operations. PAUSE8: Pauses playing. To release it, press PLAY3. REC PAUSE: Starts recording or enters recording pause.

CD recorder

After pressing TAPE/CDR (or CONTROL repeatedly until “TAPE” appears on the display window), you can perform the following operations on the CD recorder:

PLAY3: Starts playing.

4: Returns to the beginning of the current (or previous)

track.

¢¢

¢: Skips to the beginning of the next track.

¢¢

STOP7: Stops playing. PAUSE8: Pauses playing. To release it, press PLAY3. REC PAUSE: Starts recording or enters recording pause.

Note:

You can use either TAPE/CDR button or CONTROL button to activate the buttons listed above. If you press TAPE/CDR, the playing source also changes. On the other hand, if you press CONTROL repeatedly to select “TAPE,” the playing source does not change.

English

Operating Video Components

English

IMPORTANT:

To operate JVC’s video components using this remote control:

• Some JVC VCRs can accept two types of the control signals — remote code “A” and “B.” Before using this remote control, make sure that the remote control code of the VCR connected to the VCR jacks is set to code “A.”

• When using the remote control: – For the DVD player, TV and VCR operations, aim the remote

control directly at the remote sensor on each component, not on the receiver.

CATV/DBS VCR TV AUDIO

POWER POWER POWER

POWER

DVD

TV SOUND VCR

BASS

−−++

SURROUND

BASS BOOST EFFECT

SOUND

MUTING

CATV/DBS CONTROL

CONTROL

TV/VIDEO

TUNING

−

REC

PAUSE

TAPE/CDR

TREBLE

DSP

ANALOG/DIGITAL

MODE INPUTON/OFF

– CENTER +

231

– REAR • L +

TEST

564

ENTER

– REAR • R +

897/P

– SUB WOOFER +

RETURN FM MODE 100

+−+−+

CH TV VOL

/REW FF/

PLAY

PAUSE

STOP

VOLUME

CONTROL

FM/AM

SLEEP

+1010

−

VCR

You can always perform the following operations: VCR POWER: Turns on or off the VCR.

After pressing VCR (or CONTROL repeatedly until “VCR” appears on the display window), you can perform the following operations on the VCR:

1 – 9, 0: Selects the TV channels on VCR. PLAY3: Starts playing. REW: Rewinds a tape. FF: Fast winds a tape. STOP7: Stops operations. PAUSE8: Pauses playing. To release it, press PLAY3. REC P AUSE: Starts recording or enters recording pause. CH +/–: Changes the TV channels on the VCR.

Note:

You can use either VCR button or CONTROL button to activate the buttons listed above. If you press VCR, the playing source also changes. On the other hand, if you press CONTROL repeatedly to select “VCR,” the playing source does not change.

DVD player

After pressing DVD, you can perform the following operations on a DVD player:

PLAY3: Starts playing.

4: Returns to the beginning of the current (or previous)

track.

¢¢

¢: Skips to the beginning of the next track.

¢¢

STOP7: Stops playing. PAUSE8: Stops playing temporarily. To release it, press

PLAY3.

After pressing DVD, these buttons can be used for the DVD menu operations.

Note:

For detailed menu operations, refer to the instructions supplied with the discs or the DVD player.

TEST

– CENTER +

– REAR • L +

564

ENTER

– REAR • R +

RM-SRX6510J

A/V CONTROL RECEIVER

You can always perform the following operations:

TV POWER: Turns on or off the TV. TV VOL +/–: Adjusts the volume. TV/VIDEO: Sets the input mode (either TV or VIDEO).

After pressing TV SOUND, you can perform the following operations on a TV:

CH +/–: Changes the channels. 1 – 9, 0, 100+: Selects the channels. RETURN: Alternates between the previously selected channel

and the current channel.

Operating Other Manufacturers’ Video Equipment

This remote control supplied with the receiver can transmit control signals for other manufacturers’ VCRs, TVs, CATV converters, DBS tuners, and DVD players. By changing the transmittable signals from preset ones to the other manufacturers’, you can operate the other manufacturer’s components using this remote control.

When operating the other manufacturers’ components, refer also to the manuals supplied with them. To operate these components with the remote control, first you need to set the manufacturer’s code each for VCR, TV, CATV converters, DBS tuner, and DVD player.

When replacing batteries of the remote control, set the manufactures’ codes again.

CATV/DBS VCR TV AUDIO

POWER POWER POWER

POWER

DVD

TV SOUND VCR

BASS

−−++

SURROUND

BASS BOOST EFFECT

SOUND

MUTING

CATV/DBS CONTROL

CONTROL

TV/VIDEO

TUNING

−

REC

PAUSE

TAPE/CDR

TREBLE

ANALOG/DIGITAL

DSP

MODE INPUTON/OFF

– CENTER +

231

– REAR • L +

TEST

564

ENTER

– REAR • R +

897/P

– SUB WOOFER +

RETURN FM MODE 100

+−+−+

CH TV VOL

PLAY

/REW FF/

PAUSE

STOP

RM-SRX6510J

A/V CONTROL RECEIVER

FM/AM

SLEEP

+1010

VOLUME

−

CONTROL

Manufacturers’ codes are subject to change without notice. If they are changed, this remote control cannot operate the equipment.

To change the transmittable signals for operating another manufacturer’s TV

1. Press and hold TV POWER.

2. Press TV SOUND.

3. Enter manufacturer’s code using buttons 1–9, and 0.

See the list below to find the code.

4. Release TV POWER.

The following buttons can be used for operating the TV:

TV POWER: Turns on and off the TV. TV VOL +/–: Adjusts the volume. TV/VIDEO: Sets the input mode (either TV

or VIDEO).

After pressing TV SOUND, you can perform the following operations on a TV:

CH +/–: Changes the channels. 1 – 10, 0, 100+ (+10): Selects the channels.

The 10 button will function as the ENTER button if your TV requires pressing ENTER after selecting a channel number.

Note:

Refer to the manual supplied with your TV.

5. Try to operate your TV by pressing TV POWER.

When your TV turns on or off, you have entered the correct code.

If there are more than one code listed for your brand of TV,

try each one until the correct one is entered.

Manufacturer Codes

JVC 00, 02, 13, 14, 47, 74 AKAI 01, 02 BLAUPUNKT 03, 04 FISHER 01, 05 GRUNDIG 03, 06, 07 HITACHI 08, 09, 10, 49 IRADDIO 02 ITT/NOKIA 11, 12 LOEWE 06, 15, 16 MAGNAVOX 08, 17, 49 METS 50, 51, 52, 53 MITSUBISHI 08, 18, 19, 20 MIVAR 21 NORDMENDE 22, 23 OKANO 15 PANASONIC 24, 25, 26, 27, 76 PHILIPS 15, 17, 28, 75 QUELLE 52, 53, 54, 55, 56, 57, 58,

59, 60, 61, 62, 63, 64, 65,

66, 67 RCA/PROSCAN 08, 24, 29, 30, 31, 48 SABA 32, 33, 68, 69, 70 SAMSUNG 06, 08, 16, 34, 35, 49 SANYO 01, 05 SCHNEIDER 02, 15, 36 SHARP 37, 38, 77 SONY 39 TELEFUNKEN 40, 41, 42, 69 THOMSON 71, 72 TOSHIBA 37, 43, 44 ZENITH 45, 46

English

To change the transmittable signals for operating a CATV converter or DBS tuner

English

1. Press and hold CATV/DBS POWER.

2. Press CATV/DBS CONTROL.

3. Enter manufacturer’s code using buttons 1–9, and 0.

See the list to the right to find the code.

4. Release CATV/DBS POWER.

The following buttons can be used for operating the CATV converter or DBS tuner:

CA TV/DBS POWER: Turns on and off the CATV converter

or DBS tuner.

CH +/–: Changes the channels. 1 – 10, 0, 100+ (+10): Selects the channels.

The 10 button will function as the ENTER button if your equipment requires pressing ENTER after selecting a channel number.

Note:

Refer to the manual supplied with your CATV converter or DBS tuner.

5. Try to operate your CATV converter or DBS tuner by pressing CATV/DBS POWER.

When your CATV converter or DBS tuner turns on or off, you have entered the correct code.

If there are more than one code listed for your brand of CATV converter or DBS tuner , try each one until the correct

one is entered.

Note:

You cannot use both the CATV converter and DBS tuner at the same time.

For CATV converter

Manufacturer Codes

GENERAL INSTRUMENT 06, 07, 08, 09, 10,

11, 12, 13, 14, 29 HAMLIN/REGAL 01, 02, 03, 04, 05 JERROLD 06, 07, 08, 09, 10,

11, 12, 13, 14 OAK 15, 16, 17 PANASONIC 18, 19, 20 PIONEER 21, 22 SCIENTIFIC ATLANTA 23, 24, 25 TOCOM 26 ZENITH 27, 28

Manufacturers’ codes are subject to change without notice. If they are changed, this remote control cannot operate the equipment.

For DBS tuner

Manufacturer Codes

JVC 56, 57, 67 AMSTRAD 43, 44, 45, 46, 47, 48, 49 BLAUPUNKT 30 ECHOSTAR 50, 51, 67 GOLDSTAR 31 GRUNDIG 32, 33 HIRSHMANN 48, 52, 53, 54, 55 INSTRUMENT 68 ITT/NOKIA 34 KATHREIN 52, 58, 59, 60, 61, 62, 63 NEC 35, 36 ORBITECH 48 PHILIPS 37, 38 RCA 65 SAMSUNG 39, 40 SCHWAIGER 61, 64 SIEMENS 41, 42 SONY 66 TECHNISAT 48

Manufacturers’ codes are subject to change without notice. If they are changed, this remote control cannot operate the equipment.

To change the transmittable signals for operating another manufacturer’s VCR

1. Press and hold VCR POWER.

2. Press VCR.

3. Enter manufacturer’s code using buttons 1–9, and 0.

See the list to the right to find the code.

4. Release VCR POWER.

The following button can be used for operating the VCR: VCR POWER: Turns on and off the VCR. After pressing VCR, you can perform the following operations

on the VCR:

CH +/–: Changes the TV channels on the VCR. 1 – 10, 0, 100+ (+10): Selects the TV channels.

The 10 button will function as the ENTER button if your VCR requires pressing ENTER after selecting a channel number.

PLAY3: Starts playback. REW: Rewinds a video tape. FF: Fast winds a video tape. STOP7: Stops operation. PAUSE8: Pauses. REC PAUSE: Starts recording or enters recording pause.

Note:

Refer to the manual supplied with your VCR.

5. Try to operate your VCR by pressing VCR POWER.

When your VCR turns on or off, you have entered the correct code.

If there are more than one code listed for your brand of VCR, try each one until the correct one is entered.

English

Manufacturer Codes

JVC 00, 26, 27, 28, 29, 58 AIWA 01, 02 BELL & HOWELL 03 BLAUPUNKT 04, 05 CGM 06, 07 EMERSON 08, 10, 11, 12, 64, 65 FISHER 03, 14, 15, 16, 17 FUNAI 01 GE 18, 19, 20 GOLDSTAR 07 GOODMANS 13, 21 GRUNDIG 06, 22 HITACHI 18, 23, 24, 25, 66 LOEWE 07, 21 MAGNAVOX 04, 19, 24 MITSUBISHI 30, 31, 32, 33, 34, 35 NEC 26, 27 NOKIA 03, 36 NORDMENDE 38 ORION 09 PANASONIC 19, 24, 39, 40 PHILIPS 04, 19, 21, 24, 41, 42 PHONOLA 21 RCA/PROSCAN 04, 18, 19, 23, 24, 43, 44,

45 SABA 38, 46 SAMSUNG 45, 47, 59, 61, 62, 63 SANYO 03, 48, 49 SHARP 37, 50 SIEMENS 03, 51 SONY 52, 53, 54 TELEFUNKEN 55, 60 TOSHIBA 43, 44 ZENITH 57

Manufacturers’ codes are subject to change without notice. If they are changed, this remote control cannot operate the equipment.

To change the transmittable signals for operating another manufacturer’s DVD player

English

1. Press and hold AUDIO POWER.

2. Press DVD.

3. Enter manufacturer’s code using buttons 1–9, and 0.

See the list to the right to find the code.

4. Release AUDIO PO WER.

After pressing DVD, you can perform the following operations on a DVD player:

PLAY3: Starts playing. 4: Returns to the beginning of the current (or

previous) tracks.

¢: Skips to the beginning of the next track. STOP7: Stops playing. PAUSE8: Stops playing temporarily. To release it, press

PLAY3.

Manufacturer Codes

JVC 00, 02 DENON 01 PANASONIC 03 PHILIPS 13 PIONEER 04, 05, 06 RCA 07 SAMSUNG 08 SONY 09 TOSHIBA 10 YAMAHA 11, 12

Manufacturers’ codes are subject to change without notice. If they are changed, this remote control cannot operate the equipment.

After pressing DVD, these buttons can be used for the DVD menu operations.

Note:

For detailed menu operations, refer to the instructions supplied with the discs or the DVD player.

TEST

– CENTER +

– REAR • L +

564

ENTER

– REAR • R +

Note:

Refer to the manual supplied with your DVD player.

5. Try to operate your DVD player by pressing one of the above buttons.

• DO NOT forget to turn on the DVD player before pressing one

of the above buttons.

If there are more than one code listed for your brand of DVD player, try each one until the correct one is entered.

Troubleshooting

Use this chart to help you solve daily operational problems. If there is any problem you cannot solve, contact your JVC service center.

PROBLEM

POSSIBLE CAUSE

SOLUTION

English

The display does not light up.

No sound from speakers.

Sound from one speaker only.

Continuous hiss or buzzing during FM reception.

The power cord is not plugged in.

Speaker signal cables are not connected.

The SPEAKERS ON/OFF 1 and 2 buttons are not set correctly.

An incorrect source is selected.

Muting is activated.

An incorrect input mode (analog or digital) is selected.

Connections are incorrect.

Speaker signal cables are not connected properly.

The balance is set to one extreme.

Incoming signal is too weak.

The station is too far away.

An incorrect antenna is used.

Antennas are not connected properly.

Plug the power cord into an AC outlet.

Check speaker wiring and reconnect if necessary.

Press SPEAKERS ON/OFF 1 and 2 correctly.

Select the correct source.

Press MUTING to cancel the mute.

Select the correct input mode (analog or digital).

Check connections. For analog connections, see page 5. For digital connections, see page 7.

Check speaker wiring and reconnect if necessary.

Adjust the balance properly (see page 12).

Connect an outdoor FM antenna or contact your dealer.

Select a new station.

Check with your dealer to be sure you have the correct antenna.

Check connections.

Occasional cracking noise during FM reception.

“OVERLOAD” starts flashing on the display.

“DSP MICON NG” starts flashing on the display.

The STANDBY lamp lights up after turning on the power, but soon the receiver turns off (into standby mode).

Remote control does not work.

Remote control does not operate intendedly.

Ignition noise from automobiles.

Speakers are overloaded because of high volume.

Speakers are overloaded because of short circuit of speaker terminals.

The built-in microcomputer is not functioning correctly.

The receiver is overloaded because of a high voltage.

There is an obstruction in front of the remote sensor on the receiver.

Batteries are weak.

An incorrect remote control operation mode is selected.

Move the antenna farther from automobile traffic.

1. Press POWER on the front panel to turn off the receiver.

2. Stop the playback source.

3. Turn on the receiver again, and adjust the volume.

Press POWER on the front panel, then check the speaker wiring. If “OVERLOAD” does not disappear, unplug the AC power cord, then plug it back again. If speaker wiring is not short-circuited, contact your dealer.

Press POWER on the front panel to turn off the receiver. After unplugging the power cord, consult your dealer.

Remove the obstruction.

Replace batteries.

Select the correct remote control operation mode. (See page 27).

Amplifier

English

Specifications

Output Power

At Stereo operation: Front channels:

100 W per channel, min. RMS, driven into 8 Ω, 40 Hz to 20 kHz with no more than 0.8% total harmonic distortion.

At Surround operation: Front channels: 100 W per channel, min. RMS, driven into 8 Ω at 1 kHz with no

more than 0.8% total harmonic distortion.

Center channel: 100 W, min. RMS, driven into 8 Ω at 1 kHz, with no more than

0.8% total harmonic distortion.

Rear channels 100 W per channel, min. RMS, driven into 8 Ω at 1 kHz, with no

more than 0.8% total harmonic distortion.

Audio

Audio Input Sensitivity/Impedance (1 kHz): CD, TAPE/CDR, TV SOUND, VCR, DVD: 220 mV/47 kΩ

Audio Input (DIGITAL IN)* : Coaxial: DIGITAL 1 (DVD): 0.5 V(p-p)/75 Ω

Optical: DIGITAL 2 (CD): –21 dBm to –15 dBm (660 nm ±30 nm)

*Corresponding to Linear PCM, Dolby Digital, and DTS Digital Surround (with sampling frequency — 32 kHz, 44.1 kHz, 48 kHz).

Audio Output Level: TAPE/CDR, VCR: 220 mV

Signal-to-Noise Ratio (’66 IHF/’78 IHF): CD, TAPE/CDR, TV SOUND, VCR, DVD: 87 dB/67 dB

Video

Frequency Response (8 Ω) CD, TAPE/CDR, TV SOUND, VCR, DVD: 20 Hz to 20 kHz (±1 dB)

Bass boost: +3 dB ±1.0 dB at 100 Hz

Tone Control: Bass (100 Hz): ±10 dB

Treble (10 kHz): ±10 dB

Video Input Sensitivity/Impedance:

Composite video: VCR, DVD: 1 V(p-p)/75 Ω

S-video: VCR, DVD: (Y: luminance): 1 V(p-p)/75 Ω

(C: chrominance, burst): 0.286 V(p-p)/75 Ω

Video Output Level:

Composite video: VCR, MONITOR OUT: 1 V(p-p)/75 Ω

S-video: VCR, MONITOR OUT: (Y: luminance): 1 V(p-p)/75 Ω

(C: chrominance, burst): 0.286 V(p-p)/75 Ω

Synchronization: Negative

Signal-to-Noise Ratio: 45 dB

FM tuner (IHF)

Tuning Range: 87.5 MHz to 108.0 MHz

Usable Sensitivity: Monaural: 12.8 dBf (1.2 µV/75 Ω)

50 dB Quieting Sensitivity: Monaural: 21.3 dBf (3.2 µV/75 Ω)

Stereo: 41.3 dBf (31.5 µV/75 Ω)

Signal-to-Noise Ratio (IHF-A weighted): Monaural: 78 dB at 85 dBf

Stereo: 73 dB at 85 dBf

Total Harmonic Distortion: Monaural: 0.4% at 1 kHz

Stereo: 0.6% at 1 kHz

Stereo Separation at REC OUT: 35 dB at 1 kHz

Alternate Channel Selectivity: 45 dB: (±400 kHz)

Frequency Response: 30 Hz to 15 kHz: (+0.5 dB, –3 dB)

AM tuner

Tuning Range: 530 kHz to 1 710 kHz

Usable Sensitivity: Loop antenna 400 µV/m

Signal-to-Noise Ratio 50 dB (100 mV/m)

General

Power Requirements: AC 120V , 60 Hz

Power Consumption: 180 W/230 VA (at operation)

2 W (in standby mode)

Dimensions (W x H x D): 435 mm x 146.5 mm x 425.5 mm

Mass: 8.6 kg (19.0 lbs)

(17

/16 in. x 5 13/16 in. x 16 13/16 in.)

English

Designs & specifications are subject to change without notice.

VICTOR COMPANY OF JAPAN, LIMITED

EN, FR

0301NHMMDWJEIN

JVC

JVC RX-6510VBKC Instructions Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
