JVC RX-5050B Instruction Manual
AUDIO/VIDEO CONTROL RECEIVER
For Customer Use:
Enter below the Model No. and Serial
No. which are located either on the rear,
bottom or side of the cabinet. Retain this
information for future reference.
Model No.
Serial No.
RX-5050B/RX-5052S
TA/NEWS/INFO
DISPLAY MODE
INSTRUCTIONS
LVT1290-001A
[J]
Warnings, Cautions and Others/
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK.
DO NOT REMOVE COVER (OR BACK)
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning flash with arrowhead symbol,
within an equilateral triangle is intended to
alert the user to the presence of uninsulated
"dangerous voltage" within the product's
enclosure that may be of sufficient
magnitude to constitute a risk of electric
shock to persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
CAUTION
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE
BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
ATTENTION: POUR EVITER LES CHOCS ELECTRIQUES,
INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE DANS LA
BORNE CORRESPONDANTE DE LA PRISE ET POUSSER
JUSQUAU FOND.
For U.S.A
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
WARNING: TO REDUCE THE RISK OF FIRE
OR ELECTRIC SHOCK, DO NOT EXPOSE
THIS APPLIANCE TO RAIN OR MOISTURE.
Mises en garde, précautions et indications diverses
CAUTION
To reduce the risk of electrical shocks, fire, etc.:
1. Do not remove screws, covers or cabinet.
2. Do not expose this appliance to rain or moisture.
ATTENTION
Afin d’éviter tout risque d’électrocution, d’incendie, etc.:
1. Ne pas enlever les vis ni les panneaux et ne pas ouvrir
le coffret de l’appareil.
2. Ne pas exposer l’appareil à la pluie ni à l’humidité.
Caution––STANDBY/ON button!
Disconnect the mains plug to shut the power off completely.
The STANDBY/ON
button in any position does not
disconnect the mains line. The power can be remote controlled.
Attention––Commutateur STANDBY/ON
Déconnecter la fiche de secteur pour couper complètement le
courant. Le commutateur STANDBY/ON ne coupe jamais
complètement la ligne de secteur, quelle que soit sa position.
Le courant peut être télécommandé.
G-1
!
Note to CATV system installer:
This reminder is provided to call the CATV system installer’s
attention to Section 820-40 of the NEC which provides
guidelines for proper grounding and, in particular, specifies
that the cable ground shall be connected to the grounding
system of the building, as close to the point of cable entry as
practical.
For Canada/pour le Canada
THIS DIGITAL APPARATUS DOES NOT EXCEED THE
CLASS B LIMITS FOR RADIO NOISE EMISSIONS FROM
DIGITAL APPARATUS AS SET OUT IN THE INTERFERENCE-CAUSING EQUIPMENT STANDARD ENTITLED
“DIGITAL APPARATUS,” ICES-003 OF THE DEPARTMENT
OF COMMUNICATIONS.
CET APPAREIL NUMERIQUE RESPECTE LES LIMITES
DE BRUITS RADIOELECTRIQUES APPLICABLES AUX
APPAREILS NUMERIQUES DE CLASSE B PRESCRITES
DANS LA NORME SUR LE MATERIEL BROUILLEUR;
“APPAREILS NUMERIQUES”, NMB-003 EDICTEE PAR LE
MINISTRE DES COMMUNICATIONS.
Table of Contents
Remote
NOT
Parts Identification ...................................... 2
Getting Started ........................................... 4
Before Installation ...................................................................... 4
Checking the Supplied Accessories ........................................... 4
Putting Batteries in the Remote Control .................................... 4
Connecting the FM and AM Antennas ....................................... 4
Connecting the Speakers and Subwoofer ................................... 5
Connecting Audio/Video Components ....................................... 6
7 Analog Connections ............................................................... 6
7 Digital Connections ................................................................ 8
Connecting the Power Cord ....................................................... 8
Basic Operations ......................................... 9
Daily Operational Procedure ...................................................... 9
Turning On the Power ................................................................ 9
Selecting the Source to Play ....................................................... 9
Adjusting the Volume ............................................................... 10
Turning On and Off the Subwoofer Sound .............................. 11
Selecting the Analog or Digital Input Mode ............................ 11
Changing the Display Brightness ............................................. 12
Attenuating the Input Signal .................................................... 12
Changing the Source Name ...................................................... 12
Muting the Sound ..................................................................... 13
Using the Sleep Timer .............................................................. 13
Adjusting Sound ........................................ 21
Basic Adjustment Items ............................................................ 21
Basic Procedure ........................................................................ 21
7 Adjusting the Equalization Patterns ..................................... 22
7 Adjusting the Speaker Output Levels ................................... 22
7 Adjusting the Sound Parameters for the Surround
and DSP Modes .................................................................... 22
Using the Surround Modes ..........................
Reproducing Theater Ambience ................................................ 23
Introducing the Surround Modes ............................................. 23
Activating the Surround Modes ............................................... 25
23
Using the DSP Modes ................................ 26
Reproducing the Sound Field ................................................... 26
Introducing the DSP Modes ..................................................... 26
Activating the DSP Modes ....................................................... 27
Operating JVC’s Audio/Video Components ... 28
Operating Audio Components .................................................. 28
Operating Video Components .................................................. 29
Operating Other Manufacturers’ Video
Equipment ............................................ 30
Receiving Radio Broadcasts ........................ 14
Tuning in to Stations Manually ................................................ 14
Using Preset Tuning ................................................................. 14
Selecting the FM Reception Mode ........................................... 15
Basic Settings ........................................... 16
Quick Speaker Setup ................................................................ 16
Basic Setting Items ................................................................... 17
Basic Procedure ........................................................................ 17
7 Setting the Speakers ............................................................. 18
7 Setting the Speaker Distance ................................................ 18
7 Setting the Bass Sounds ....................................................... 18
7 Selecting the Main or Sub Channel ...................................... 19
7 Setting for Easy and Effective Surround Operations............ 20
7 Setting the Digital Input Terminals ...................................... 20
Troubleshooting ......................................... 32
Specifications............................................ 33
This mark indicates that ONLY the remote control
CAN be used for the operation explained.
This mark indicates that the remote control
CANNOT be used for the operation explained.
Use the buttons and controls on the front panel.
1
Parts Identification
DIGITAL
PRO LOGIC
STANDBY
STANDBY/ON
PHONES
SURROUND
DSP
SPEAKERS
ON/OFF
SUBWOOFER OUT FM MODE MEMORY
ON/OFF
FM/AM TUNING
SURROUND/DSP
OFF
DIMMER
MASTER VOLUME
INPUT DIGITAL
RX—6030V
AUDIO/VIDEO CONTROL RECEIVER
SETTING
MULTI JOG
PUSH SET
QUICK SPEAKER
SETUP
ADJUST
EXIT
INPUT ANALOG
INPUT ATT
FM/AM PRESET
DVD VCR CD FM/AMTAPE/CDRTV SOUND
SOURCE NAME
3D - PHONIC
DUAL
MONO
H.PHONESBDSP
DIGITAL EQ
INPUT ATT
VOLUME
PRO LOGIC
VIRTUAL SB
TUNED
STEREO
AUTO MUTING
SLEEP
96/24
1
2
3
4
5
w
e
r
u
i
o;
s
d
t
y
6
7 8 9 p
q
a
3D - PHONIC
DUAL
MONO
H.PHONE
SB
DSP
DIGITAL EQ
INPUT ATT
VOLUME
PRO LOGIC
VIRTUAL SB
TUNED
STEREO
AUTO MUTING
SLEEP
96/24
-
$%
!
@
1324567890=~
#
Front Panel
See pages in parentheses for details.
1 STANDBY/ON
button and STANDBY lamp (9)
2 SURROUND/DSP OFF button (25, 27)
3 DSP button (26, 27)
4 SURROUND button (25)
5 Remote sensor
6 Display (For details, see “Display” below.)
7 Source selection buttons (9, 12)
DVD, VCR, TV SOUND, CD, TAPE/CDR (SOURCE
NAME), FM/AM
8 INPUT ANALOG button (12)
INPUT ATT button (12)
9 INPUT DIGITAL button (11)
Display
p DIMMER button (12)
q MASTER VOLUME control (10)
w PHONES jack (11)
e SPEAKERS ON/OFF button (11)
r SUBWOOFER OUT ON/OFF button (11)
t FM/AM TUNING 5/∞ buttons (14)
y FM/AM PRESET 5/∞ buttons (14)
u FM MODE button (15)
i MEMORY button (14)
o SETTING button (17)
; QUICK SPEAKER SETUP button (16)
a MULTI JOG (PUSH SET) dial (16, 17, 21)
s EXIT button (17, 21)
d ADJUST button (21)
See pages in parentheses for details.
1 ANALOG indicator (12)
2 DUAL MONO indicator (24)
3 H.PHONE indicator (11, 24, 26)
4 3D-PHONIC indicator (24, 26, 27)
5 VIRTUAL SB indicator (20)
PRO LOGIC II indicator (23, 26)
6
7 DSP indicator (26, 27)
8 DIGITAL EQ indicator (22)
9 TUNED indicator (14)
2
0 STEREO indicator (14)
- INPUT ATT indicator (12)
= AUTO MUTING indicator (15)
~ SLEEP indicator (13)
! VOLUME indicator (9)
@ Digital signal format indicators (11)
# Speaker indicators and signal indicators (10)
$ CH– indicator (14)
% Main display
Remote Control
AUDIO
TV/CATV
VCR
DVD
TEST
EFFECT
MENU
ENTER LEVEL
RETURN
SURROUND
/DSP
CD-DISC
SLEEP
REC PAUSE
FM MODE
SURROUND
DSP
DIMMER TV/VIDEO MUTING
OFF
VCR CH
TV/CATV CH
VOLUME
SURR R
SURR L
SUBWFR
CENTER
FRONT R
FRONT L
100
1
4
7/P
10
2
5
8
0
3
6
9
10
TV VOLUME
STANDBY/ON
TV CATV
A/V CONTROL
RECEIVER
TAPE/CDR CD DVD
FM/AM TV SOUND VCR
ANALOG
/DIGITAL
REW
FF
2
5
=
$
%
#
@
^
4
8
7
0
-
*
&
6
9
~
3
1
!
CAUTION :
SPEAKER IMPEDANCE
AM
LOOP
AM
EXT
CD
IN
OUT
(REC)
IN
(PLAY)
OUT
(REC)
VCR
TV SOUND
IN
ANTENNA
CENTER
SPEAKER
SURROUND
SPEAKERS
RIGHT LEFT
FRONT
SPEAKERS
RIGHT LEFT
AUDIO
RIGHT LEFT
IN
(PLAY)
TAPE
/CDR
DIGITAL 1
DIGITAL 2 ( CD )
DIGITAL IN
(DVD)
SUBWOOFER
OUT
AUDIO
COAXIAL
FM 75
816—
MONITOR
OUT
DVD
IN
OUT
(REC)
VCR
IN
(PLAY)
DVD
IN
RIGHT LEFT
14
85 67
2 3
See pages in parentheses for details.
1 TV/CATV selector (30)
2 10 keys for selecting preset channels (15, 28)
10 keys for sound adjustment (22, 28)
10 keys for operating audio/video components (28 – 30)
3 SOUND button (22, 28)
4 REC PAUSE button (29, 31)
5 Source selection buttons (9, 10)
TAPE/CDR, CD, DVD, FM/AM, TV SOUND, VCR
6 FM MODE button (15, 28)
7 SURROUND button (25, 28)
8 DIMMER button (12, 28)
9 TV/VIDEO button (29, 30)
0 VCR CH +/– buttons (29, 31)
- TV/CATV CH +/– buttons (29, 30)
= STANDBY/ON
buttons (9, 28 – 31)
AUDIO, TV/CATV, VCR, DVD
~ SLEEP button (13, 28)
! Operating buttons for audio/video components
3, 8, 7, ¢/4, FF/REW (28, 29, 31)
@ CD-DISC button (29)
# ANALOG/DIGITAL button (11, 12, 28)
$ SURROUND/DSP OFF button (25, 27, 28)
% DSP button (26 – 28)
^ MUTING button (13, 28)
& VOLUME +/– button (10, 28)
* TV VOLUME +/– buttons (29, 30)
Rear Panel
See pages in parentheses for details.
1 DIGITAL IN terminals (8)
• Coaxial: DIGITAL 1 (DVD)
• Optical: DIGITAL 2 (CD)
2 AUDIO input/output jacks (6, 7)
• Input: CD IN, TAPE/CDR IN (PLAY), VCR IN (PLAY),
• Output: TAPE/CDR OUT (REC), VCR OUT (REC),
TV SOUND IN, DVD IN
SUBWOOFER OUT
Note:
When you press the one of the audio source selection buttons—
TAPE/CDR, CD, and FM/AM—on the remote control, the receiver
automatically turns on.
3 VIDEO input/output jacks (7)
• Input: DVD IN, VCR IN (PLAY)
• Output: MONITOR OUT, VCR OUT (REC)
4 ANTENNA terminals (4, 5)
5 CENTER SPEAKER terminals (5)
6 SURROUND SPEAKERS terminals (5)
7 FRONT SPEAKERS terminals (5)
8 AC power cord (8)
3
AM
LOOP
AM
EXT
ANTENNA
COAXIAL
FM 75
FM 75
COAXIAL
A
M
LOO
P
A
M
EXT
ANTENNA
FM 75
COAXIAL
AM
LOO
P
AM
EXT
ANTENNA
Do not connect the AC power cord until all other connections
have been made.
Getting Started
This section explains how to connect audio/video components and speakers to the receiver, and how to connect the
power supply.
Before Installation
General Precautions
• Be sure your hands are dry.
• Turn the power off to all components.
• Read the manuals supplied with the components you are going to
connect.
Locations
• Install the receiver in a location that is level and protected from
moisture and dust.
• The temperature around the receiver must be between –5˚C and
35˚C (23˚F and 95˚F).
• Make sure there is good ventilation around the receiver. Poor
ventilation could cause overheating and damage the receiver.
Handling the receiver
• Do not insert any metal object into the receiver.
• Do not disassemble the receiver or remove screws, covers, or
cabinet.
• Do not expose the receiver to rain or moisture.
Checking the Supplied Accessories
Check to be sure you have all of the following items, which are
supplied with the receiver.
The number in the parentheses indicates quantity of the pieces
supplied.
• Remote Control (1)
• Batteries (2)
• AM Loop Antenna (1)
• FM Antenna (1)
If anything is missing, contact your dealer immediately.
Notes:
• Supplied batteries are for the initial setup. Replace for continued
use.
• After replacing the batteries, set the manufacturers’ codes again
(see pages 30 and 31).
CAUTION:
Follow these precautions to avoid leaking or cracking cells:
• Place batteries in the remote control so they match the
polarity: (+) to (+) and (–) to (–).
• Use the correct type of batteries. Batteries that look similar
may differ in voltage.
• Always replace both batteries at the same time.
• Do not expose batteries to heat or flame.
Connecting the FM and AM Antennas
FM antenna connections
A
Extend the supplied FM antenna
horizontally.
B
Putting Batteries in the Remote Control
Before using the remote control, insert the two supplied batteries
first.
1
2
R6(SUM-3)/
3
AA(15F)
1 Press and slide the battery cover on the back of
the remote control.
2 Insert the batteries.
• Make sure to match the polarity: (+) to (+) and (–) to (–).
3 Replace the cover.
If the remote control cannot transmit signals or operate the receiver
correctly, replace the batteries. Use two R6(SUM-3)/AA(15F) type
dry-cell batteries.
4
FM Antenna
(supplied)
Outdoor FM Antenna Cable
(not supplied)
Connect the supplied FM antenna as temporary measure to the
FM 75 Ω COAXIAL terminal—A
If reception is poor, connect the outdoor FM antenna (not
supplied)—B
1 Disconnect the supplied FM antenna.
2 Connect a 75 Ω coaxial cable (with the standard type connector).
AM
LOOP
AM
EXT
ANTENNA
COAXIAL
FM 75
CENTER
SPEAKER
SURROUND
SPEAKERS
RIGHT
LEFT
FRONT
SPEAKERS
RIGHT
LEFT
CAUTION :
SPEAKER IMPEDANCE
8
16
—
+
–
+
–
To center speaker
To right front speaker
To right surround speaker
To left surround
speaker
To left
front speaker
RIGHT
LEFT
+
–
RIGHT
LEFT
+
–
RIGHT
LEFT
+
–
Do not connect the AC power cord until all other connections
have been made.
AM antenna connections
1
Outdoor single vinyl-covered wire (not supplied)
23
AM Loop Antenna
(supplied)
Snap the tabs on the loop into
the slots of the base to
assemble the AM loop
antenna.
Connecting the Speakers and Subwoofer
You can connect five speakers (a pair of front speakers, a center
speaker, and a pair of surround speakers) and a subwoofer.
CAUTIONS:
• Use only the speakers of the SPEAKER IMPEDANCE
indicated by the speaker terminals.
• Do not connect more than one speaker to each speaker
terminal.
Connecting the speakers
1
2
3
4
1 Twist and remove the insulation at the end of
each speaker cord.
2 Press and hold the clamp of the speaker terminal.
3 Insert the speaker cord.
4 Release the finger from the clamp.
Turn the loop until you have the best reception.
Notes:
• If the AM loop antenna wire is covered with vinyl,
remove the vinyl by twisting it as illustrated.
• Make sure the antenna conductors do not touch any
other terminals, connecting cords and power cord.
This could cause poor reception.
• If reception is poor, connect an outdoor single vinyl-covered wire
(not supplied) to the AM EXT terminal. (Keep the AM loop antenna
connected.)
For each speaker (except for a subwoofer), connect the (+) and
(–) terminals on the rear panel to the (+) and (–) terminals
marked on the speakers.
5
SUBWOOFER
OUT
OUT
(REC)
IN
(PLAY)
TAPE
/CDR
L
R
R
L
CD
IN
R
L
Getting Started
45 – 60
Do not connect the AC power cord until all other connections
have been made.
Connecting the subwoofer
You can enhance the bass by connecting a subwoofer.
Connect the input jack of a powered subwoofer to the rear panel,
using a cable with RCA pin plugs (not supplied).
Powered subwoofer
Placing speakers
Front speakers (L/R) and center speaker (C)
• Place these speakers at the same height from the floor, at or near
ear level.
• Array across the front of the viewing area.
Surround speakers (LS/RS)
• Place these speakers alongside and slightly to the rear of (but not
behind) the listening position; well above ear level (60 cm (2 ft) to
90 cm (3 ft) higher).
• Point these speakers directly across the listening area, but not at
the listener’s ears.
Subwoofer (S.WFR)
• You can place it wherever you like since bass sound is nondirectional. Normally place it in front of you.
Connecting Audio/Video Components
When connecting individual components, refer also to the manuals
supplied with them.
Analog Connections
Audio component connections
Use the cables with RCA pin plugs (not supplied).
• Connect the white plug to the audio left jack, and the red plug to
the audio right jack.
CAUTION:
If you connect a sound-enhancing device such as a graphic
equalizer between the source components and this receiver,
the sound output through this receiver may be distorted.
CD player
CD player
To audio
output
Cassette deck/CD recorder
L
R
C
S.WFR
LS
RS
After connecting the speakers, set the speaker installation
information properly. You can use Quick Speaker Setup for
it (see page 16).
6
Cassette deck or CD recorder
To audio input
To audio output
Note:
When connecting a CD recorder to the TAPE/CDR jacks, change the
source name to “CDR,” which will be shown on the display when it is
selected as the source. See page 12 for details.
AUDIO
DVD
IN
RIGHT LEFT
A
B
DVD
IN
DVD
R
L
MONITOR
OUT
TV SOUND
IN
AUDIO
RIGHT LEFT
A
B
R
L
OUT
(REC)
VCR
IN
(PLAY)
OUT
(REC)
VCR
IN
(PLAY)
R
L
R
L
A B DC
Do not connect the AC power cord until all other connections
have been made.
Video component connections
Use the cables with RCA pin plugs (not supplied).
Connect the white plug to the audio left jack, the red plug to the
audio right jack, and the yellow plug to the video jack.
VCR
DVD player
DVD player
Å To composite video output
ı To left/right front channel audio output (or to audio-mixed
VCR
output if necessary)
Å To audio input
ı To audio output
Ç To composite video input
Î To composite video output
Note:
To enjoy Dolby Digital and DTS multi-channel software (including Dual
Mono software), connect the DVD player through the digital input/
output terminals.
TV
Connect the TV to appropriate MONITOR OUT jacks to view
the playback picture from any other connected video
components.
Å To audio output
ı To composite video input
TV
7
DIGITAL IN
DIGITAL 1
(DVD)
DIGITAL 2 (CD)
Getting Started
Do not connect the AC power cord until all other connections
have been made.
Digital Connections
By connecting the receiver and the source component through the
digital terminals, sound reproduction quality will be much improved.
In addition, you can enjoy multi-channel reproduction and some
other convenient functions.
IMPORTANT:
• When connecting a video component using the digital
terminals, you also need to connect it to the video jacks on
the rear. Without connecting it to the video jacks, you can
view no playback picture.
• After connecting the components using the DIGITAL IN
terminals, set the following correctly if necessary.
– Set the digital input (DIGITAL IN) terminal setting correctly.
For details, see “Setting the Digital Input Terminals” on
page 20.
– Select the digital input mode correctly. For details, see
“Selecting the Analog or Digital Input Mode” on page 11.
Digital input terminals
You can connect any digital components having coaxial or optical
digital output terminal.
Digital coaxial cable (not supplied)
between digital coaxial terminals
Note:
When shipped from the factory, the DIGITAL IN terminals have been
set for use with the following components:
– DIGITAL 1 (coaxial): For DVD player
– DIGITAL 2 (optical): For CD player
Connecting the Power Cord
Before plugging the receiver into an AC outlet, make sure that all
connections have been made.
Plug the power cord into an AC outlet.
Keep the power cord away from the connecting cables and the
antenna. The power cord may cause noise or screen interference.
Note:
The preset settings such as preset channels and sound adjustment
may be erased in a few days in the following cases:
– When you unplug the power cord.
– When a power failure occurs.
Digital optical cable (not supplied)
between digital optical terminals
When the component has a digital
coaxial output terminal, connect it to
the DIGITAL 1 (DVD) terminal, using a
digital coaxial cable (not supplied).
When the component has a digital
optical output terminal, connect it to the
DIGITAL 2 (CD) terminal, using a digital
optical cable (not supplied).
Before connecting a digital
optical cable, unplug the
protective plug.
CAUTIONS:
• Do not touch the power cord with wet hands.
• Do not pull on the power cord to unplug the cord. When
unplugging the cord, always grasp the plug so as not to
damage the cord.
8
Basic Operations
VOLUME
DVD
VCR
CD
FM/AM
TAPE/CDR
TV SOUND
SOURCE NAME
TAPE/CDR CD DVD
FM/AM TV SOUND VCR
VOLUME
The following operations are commonly used when you play any sound sources.
Operations hereafter will be explained using the buttons on the front panel.
You can also use the buttons on the remote control for the same functions if they have the same and similar names/marks.
Daily Operational Procedure
1 Turn on the power.
• See “Turning On the Power” below.
2 Select the source.
• See “Selecting the Source to Play” to the right.
3 Adjust the volume.
• See “Adjusting the Volume” on page 10.
4 Select the Surround or DSP modes.
• See “Activating the Surround Modes” (page 25) and
“Activating the DSP Modes” (page 27).
Turning On the Power
Selecting the Source to Play
When you have connected digital source components using the
digital terminals, first change the input mode for these components
to the digital input mode (see page 11).
Press one of the source selection buttons.
Selected source name appears.
On the front panel
Press STANDBY/ON (or STANDBY/ON AUDIO on
the remote control).
The STANDBY lamp goes off.
Current source name appears.
Current volume level appears.
To turn off the power (into standby mode),
press STANDBY/ON (or STANDBY/ON AUDIO on the
remote control) again.
The STANDBY lamp lights up.
Note:
A small amount of power is consumed in standby mode. To turn off
the power completely, unplug the AC power cord.
On the remote
Note:
When connecting a CD recorder to the TAPE/CDR jacks, change the
source name shown on the display. For details, see page 12.
9
SB SB
TAPE/CDR CD DVD
FM/AM TV SOUND VCR
Basic Operations
Speaker and signal indicators on the display
By checking the following indicators, you can easily confirm which
speakers you are activating and which signals are coming into this
receiver.
Signal indicatorsSpeaker indicators
What speaker indicators light depends on the speaker setting
(for details, see “Setting the Speakers” on page 18).
• The frames of “L,” “C,” “R,” “LS,” and “RS” light up, when the
corresponding speakers are set to “LARGE” or “SMALL.” Sounds
come out of the speakers whose speaker indicators is lit on the
display.
• The
pages 11 and 18).
The signal indicators light up to show the incoming signals.
L: • When digital input is selected: Lights up when the left
R: • When digital input is selected: Lights up when the right
C: Lights up when the center channel signal comes in.
LFE: Lights up when the LFE channel signal comes in.
LS: Lights up when the left surround channel signal comes in.
RS: Lights up when the right surround channel signal comes in.
S: Lights up when the monaural surround channel signal
SB: Lights up when the surround back channel signal comes in.
How to understand the speaker and signal indicator
illumination
indicator lights up when the subwoofer is activated (see
channel signal comes in.
• When analog input is selected: Always lights up.
channel signal comes in.
• When analog input is selected: Always lights up.
comes in.
Ex. No sound comes out of the
center speaker and surround
speakers though center
channel and surround
channel signals are coming
into this receiver.
Selecting different sources for picture and
sound
While watching pictures from a video source, you can listen to
sound of an audio source.
• Once you have selected a video source, pictures of the selected
source are sent to the TV until you select another video source.
Press one of the audio source selection buttons while viewing the
picture from a video component such as the VCR or DVD
player, etc.
CD
TAPE/CDR
SOURCE NAME
On the front panel
FM/AM
On the remote
Adjusting the Volume
On the front panel:
To increase the volume, turn MASTER VOLUME clockwise.
To decrease the volume, turn it counterclockwise.
On the remote control:
To increase the volume, press VOLUME +.
To decrease the volume, press VOLUME –.
CAUTION:
Always set the volume to the minimum before starting any
sources. If the volume is set at its high level, the sudden blast
of sound energy can permanently damage your hearing and/
or ruin your speakers.
Note:
The volume level can be adjusted within the range of “0” (minimum) to
“50” (maximum).
10
Loading...
