JVC LT-32DE73 User Manual

LCD TV/DVD Combo

LT-32DE73

(32” classe/31,51 diagonale)

INSTRUCTIONS
MANUAL D’ INSTRUCTIONS

Please read the important
notice for energy efficiency
on page 8.

Veuillez lire l’avis important
d’efficacité énergétique à la
page 8.

ATTENTION

(32” class/31.51 diagonal)

If you purchase a universal remote control from your local retailer, please contact the remote manufacturer for the
required programming code.
Si vous utilisez avec cet appareil une télécommande universelle (autre que celle vendue avec ce téléviseur),
consultez la documentation accompagnant la télécommande universelle afin de connaître le code numérique cor­respondant au téléviseur.

AIR/CABLE MODE SELECTION

When shipped from the factory, the Signal Type option is set to the “Cable” (Cable Television) mode.
If not using Cable TV, set this menu option to the “Air” position.
Lorsque l’appareil sort de l’usine, l’option Signal Type est en mode « Cable » (câblodistribution). Si vous
n’utilisez pas la câblodistribution, sélectionnez l’option « Air ».

SÉLECTION DU MODE AIR/CABLE

ATTENTION

FRANÇAIS ENGLISH

IF CONTACT WITH CUSTOMER SERVICE IS REQUIRED

PLEASE HAVE THE MODEL NUMBER READY PRIOR TO THE CALL

SI VOUS DEVEZ COMMUNIQUER AVEC LE SERVICE CLIENTÈLE, PRENEZ NOTE

DU NUMÉRO DE MODÈLE AVANT D’APPELER.

CUSTOMER SERVICE : 1-800-289-0984

SERVICE/SERVICE CLIENTÈLE: 1-800-289-0984

POUR OBTENIR DES INFORMATIONS SUR RECYCLAGE, VEUILLEZ CONTACTER LE SERVICE CLIENTÈLE.

FOR RECYCLING INFORMATION, PLEASE CONTACT CUSTOMER SERVICE.

CUSTOMER SERVICE : 1-800-289-0984

SERVICE/SERVICE CLIENTÈLE: 1-800-289-0984

Before operating the unit, please read this manual thoroughly.

Avant de faire fonctionner l’appareil, veuillez lire le présent guide attentivement.

The lightning flash with arrowhead
symbol, within an equilateral triangle
is intended to alert the user to the
presence of uninsulated dangerous
voltage within the product's enclosure
that may be of sufficient magnitude to
constitute a risk of electric shock.

CAUTION: TO REDUCE THE RISK OF ELECTRIC

SHOCK, DO NOT REMOVE COVER
(OR BACK). NO USER-SERVICEABLE
PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.

The exclamation point within an
equilateral triangle is intended to
alert the user to the presence of
important operating and maintenance
(servicing) instructions in the literature
accompanying the appliance.

WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN

TO PREVENT THE SPREAD OF FIRE, KEEP CANDLES OR OPEN FLAMES AWAY

OR MOISTURE.

FROM THIS PRODUCT AT TIMES.

CAUTION: TO PREVENT ELECTRIC SHOCK, DO NOT USE THIS POLARIZED PLUG WITH AN

EXTENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN
BE FULLY INSERTED TO PREVENT BLADE EXPOSURE.

WARNING: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant

However, there is no guarantee that interference will not occur in a particular installation. If this equipment does

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

CAUTION: Changes or modifications not expressly approved by the partly responsible for compliance with the FCC Rules

Declaration of Conformity

Model Number : LT-32DE73
Trade Name : JVC
Responsible party : ORION AMERICA, INC.
Address : 1105 SOUTH MAIN STREET PRINCETON, INDIANA 47670 U.S.A.
Telephone Number : 1-800-289-0980
This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.

to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications.

cause harmful interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

could void the user’s authority to operate this equipment.

CAUTION:

THIS DIGITAL VIDEO PLAYER EMPLOYS A LASER SYSTEM.
TO ENSURE PROPER USE OF THIS PRODUCT, PLEASE

READ THIS OWNER'S MANUAL CAREFULLY AND RETAIN
FOR FUTURE REFERENCE. SHOULD THE UNIT REQUIRE
MAINTENANCE, CONTACT AN AUTHORIZED SERVICE
LOCATION-SEE SERVICE PROCEDURE.

USE OF CONTROLS, ADJUSTMENTS OR THE PERFORMANCE
OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN
MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

TO PREVENT DIRECT EXPOSURE TO THE LASER BEAM, DO
NOT TRY TO OPEN THE ENCLOSURE. RADIATION MAY BE
PRESENT WHEN THE ENCLOSURE IS OPENED. DO NOT
STARE INTO THE BEAM.

Important Note:

In the spaces below, enter the model and serial number of your television (located at the rear of the television
cabinet). Staple your sales receipt or invoice to the inside cover of this guide. Keep this user’s guide in a
convenient place for future reference. Keep the carton and original packaging for future use.

Location of the required marking

The rating sheet and the safety caution are
on the rear of the unit.

CERTIFICATION: COMPLIES WITH FDA
RADIATION PERFORMANCE STANDARDS, 21
CFR SUBCHAPTER J.

Complies with FDA performance standards
for laser products except for deviations
pursuant to Laser Notice No. 50, dated
June 24, 2007.

CLASS 1
LASER PRODUCT

Serial number _______________________________ Model number ______________________________

EN 2

NEC-NATIONAL

IMPORTANT SAFETY INSTRUCTIONS

15) Apparatus should not be exposed to dripping or splashing, and objects filled with liquids, such
as vases, should not be placed on the apparatus.

16) An outside antenna system should not be located in the vicinity of overhead power lines or
other electric light or power circuits, or where it can fall into such power lines or circuits. When
installing an outside antenna system, extreme care should be taken to keep from touching such
power lines or circuits, as contact with them might be fatal.

17) Do not overload wall outlets and extension cords, as this can result in a risk of fire or electric
shock.

18) Do not push objects through any openings in this unit, as they may touch dangerous voltage
points or short out parts that could result in fire or electric shock. Never spill or spray any type of
liquid into the unit.

19) If an outside antenna or cable system is
connected to the unit, be sure the antenna or
cable system is grounded to provide some
protection against voltage surges and built-up
static charges, Section 810 of the National
Electrical Code, ANSI/NFPA 70, provides
information with respect to proper grounding of
the mast and supporting structure, grounding
of the lead-in wire to an antenna discharge
unit, size of grounding conductors, location
of antenna discharge unit, connection to

ELECTRICAL CODE
S2898A

grounding electrodes, and requirements for the grounding electrode.

20) When replacement parts are required, be sure the service technician uses replacement parts
specified by the manufacturer or those that have the same characteristics as the original part.

Unauthorized substitutions may result in fire, electric shock or other hazards.

21) Upon completion of any service or repairs to this unit, ask the service technician to perform
safety checks to determine that the unit is in proper operating condition.

22) Keep your fingers clear of the disc slot as it is closing. It may cause injury.

EXAMPLE OF ANTENNA GROUNDING AS PER THE

NATIONAL ELECTRICAL CODE

GROUND

CLAMP

ELECTRIC SERVICE

EQUIPMENT

ANTENNA
LEAD IN WIRE

ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
GROUNDING CONDUCTORS
(NEC SECTION 810-21)

GROUND CLAMPS
POWER SERVICE GROUNDING

ELECTRODE SYSTEM
(NEC ART 250, PART H)

ENGLISH

3 EN

IMPORTANT SAFETY INSTRUCTIONS

23) When you connect the product to other equipment, turn off the power and unplug all of the equipment from
the wall outlet. Failure to do so may cause an electric shock and serious personal injury. Read the owner's
manual of the other equipment carefully and follow the instructions when making any connections.

24) Reduce the volume to the minimum level before you turn on the product. Otherwise, sudden high volume
sound may cause hearing or speaker damage.

25) Do not allow the product to output distorted sound for an extended period of time. It may cause speaker
overheating and fire.

26) When you use the headphones, keep the volume at a moderate level. If you use the headphones
continuously with high volume sound, it may cause hearing damage.

27) Do not look into the opening of the disc slot or ventilation opening of the product to see the source of the
laser beam. It may cause eye damage.

28) Do not use a cracked, deformed, or repaired disc. These discs are easily broken and may cause serious
personal injury and product malfunction.

29) This reminder is provided to call the cable TV system installer’s attention to Article 820-40 of the NEC
that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be
connected to the grounding system of the building, as close to the point of cable entry as practical.

30) The socket-outlet must be installed near the unit and easily accessible.

CONDENSATION

Moisture will form in the operating section of the player if the player is brought from cool surroundings into a warm
room or if the temperature of the room rises suddenly. When this happens, player's performance will be impaired.
To prevent this, let the player stand in its new surroundings for about an hour before switching it on, or make sure
that the room temperature rises gradually.
Condensation may also form during the summer if the player is exposed to the breeze from an air conditioner. In
such cases, change the location of the player.

HOW TO HANDLE THE LCD PANEL

Do not press hard or jolt the LCD panel. It may cause the LCD panel glass to break and injury may occur.

•

If the LCD panel is broken, make absolutely sure that you do not touch the liquid in the panel. This may cause

•

skin inflammation.
If the liquid gets in your mouth, immediately gargle and consult with your doctor. Also, if the liquid gets in your
eyes or touches your skin, consult with your doctor after rinsing for at least 15 minutes or longer in clean water.

CHILD SAFETY:
It Makes A Difference How and Where You Use Your Flat Panel Display

Congratulations on your purchase! As you enjoy your new product, please keep these safety tips in mind:

THE ISSUE

The home theater entertainment experience is a growing trend and larger flat panel displays are popular
purchases. However, flat panel displays are not always supported on the proper stands or installed
according to the manufacturer’s recommendations.
Flat panel displays that are inappropriately situated on dressers, bookcases, shelves, desks, speakers,
chests or carts may fall over and cause injury.

THIS MANUFACTURER CARES!

The consumer electronics industry is committed to making home entertainment enjoyable and safe.

TUNE INTO SAFETY

One size does NOT fit all. Follow the manufacturer’s recommendations for the safe installation and use of
your flat panel display.
Carefully read and understand all enclosed instructions for proper use of this product.
Don’t allow children to climb on or play with furniture and television sets.
Don’t place flat panel displays on furniture that can easily be used as steps, such as a chest of drawers.
Remember that children can become excited while watching a program, especially on a “larger than life” flat
panel display. Care should be taken to place or install the display where it cannot be pushed, pulled over, or
knocked down.
Care should be taken to route all cords and cables connected to the flat panel display so that they cannot be
pulled or grabbed by curious children.

WALL MOUNTING: IF YOU DECIDE TO WALL MOUNT YOUR FLAT PANEL DISPLAY, ALWAYS:

Use a mount that has been recommended by the display manufacturer and/or listed by an independent
laboratory (such as UL, CSA, ETL).
Follow all instructions supplied by the display and wall mount manufacturers.
If you have any doubts about your ability to safely install your flat panel display, contact your retailer about
professional installation.
Make sure that the wall where you are mounting the display is appropriate to support the weight of the unit/
product and wall mount. If you are unsure, contact a professional installer.
A minimum of two people are required for installation. Flat panel displays can be heavy.

EN 4

SAFETY PRECAUTIONS

The unit emits heat when in operation. Do not place
any covers or blankets on the unit, this may cause
overheating. Do not block ventilation holes, or set
up near radiators. Do not place in direct sunshine.
When placing on a shelf leave 4 inches (10 cm) free
space around the entire unit.

10 cm

(4 inches)

10 cm

(4 inches)

Notes when mounting the LCD TV on a wall

If the unit is to be mounted on the wall, contact the

•
retailer where you purchased the LCD TV for advice, and
have the equipment professionally installed. Incomplete
or improper installation may cause injury to you, and/or
damage to the LCD TV.
Bracket holes: To attach a wall mounting bracket (not

•
supplied) remove the screw, then attach where indicated
in the drawing right.
This manufacturer recommends professional installation.

•
Utilize an appropriate bracket and fasteners, sufficient to

•
accommodate the size and weight of the unit.
Assure the wall to which the unit is to be mounted will

•
safely support the size and weight of the unit, using the
bracket and fasteners you have selected.
Keep cords and cables connected to this flat panel

•
display out of reach of children.
To hang the television on a wall, remove these screws

•
and then remove a stand. Before performing work spread
cushioning over the base area to lay the TV on.
Before wall-mounting, please check carefully the location

•
of the TV’s mounting-holes.

34 cm

(13 inches)

10 cm

(4 inches)

10 cm

(4 inches)

Bracket holes

Screws

73 cm

(28 inches)

29 cm

(11 inches)

M4 × 10

5 cm

(2 inches)

7 cm

(3 inches)

IMPORTANT NOTICE

Possible Adverse Effects on LCD Panel: If a fixed (non-moving) pattern remains on the LCD Panel for

long periods of time, the image can become permanently engrained in the LCD Panel and cause subtle but
permanent ghost images. This type of damage is NOT COVERED BY YOUR WARRANTY. Never leave your
LCD Panel on for long periods of time while it is displaying the following formats or images:

•

Fixed Images, such as stock tickers, video game patterns, TV station logos, and websites.

•

Special Formats that do not use the entire screen. For example, viewing letterbox style (16:9) media on
a normal (4:3) display (black bars at top and bottom of screen); or viewing normal style (4:3) media on a
widescreen (16:9) display (black bars on left and right sides of screen).

The following symptoms are not signs of malfunction but technical limitation. Therefore we disclaim
any responsibility for these symptoms.

•

LCD Panels are manufactured using an extremely high level of precision technology, however sometimes
parts of the screen may be missing picture elements or have luminous spots.

This is not a sign of a malfunction.

•

Do not install the LCD Panel near electronic equipment that produces electromagnetic waves. Some
equipment placed too near this unit may cause interference.

•

Effect on infrared devices – There may be interference while using infrared devices such as infrared cordless
headphones.

5 EN

How to attach the stand

NOTE:

• Unplug the AC cord from the wall outlet.

• Before beginning this process, assure that the TV is laid on a clean, safe, and cushioned surface to avoid
any damage to the unit.

• Do not touch or press the TV-screen, glass might break under pressure.

Place the TV on its front onto a table.
Align the stand’s bottom-plate (supplied) as seen here.
It will fi t in only one direction.
Hold the unit and attache the stand slowly, as shown in fi gure 1.

LCD PANEL SIDE

Figure 1 Figure 2

Finally secure the bottom-plate with 4 screws (supplied) (4x16mm (5/32x5/8 inches)) as indicated by the arrows
in figure 2.

•

Be sure to follow the instructions. Insufficient tightening or incorrect installation of the stand will not support
your unit correctly, and could result in damage or injury from tip-over.

How to remove the stand

When you transport this product, remove the stand and pack fl at against the back of the unit in the carton. To
remove the stand, perform these steps in reverse order.

For wall mounting, the base must be removed. To disconnect the base/stand remove the 3 screws from the back
(see page 5).

EN 6

Features

LCD color TV With DVD/CD player

Unique space saving design combines a 32” LCD color TV and a DVD/CD player.
A DVD disc has much more capacity, but is the same size as an audio CD disc. The Picture/Audio quality of a
DVD exceeds other software. The picture quality is higher than Super VHS video cassettes. The audio quality
is higher than an audio CD. The DVD also has special options; audio language selection, subtitle language
selection, or multi-angle, etc.
The DVD PLAYER can playback both audio CDs and MP3/WMA/JPEG CDs.

Compatible with a wide range of DVD audio outputs

Digital Audio Jack (Coaxial)

•

When a component with a built-in Dolby Digital decoder is connected, Dolby Digital sound can produce the
effect of being in a movie theater or a concert hall.

•

Surround standard is different from Dolby Digital. This format is already in use in many theaters. By connecting
this unit to a DTS decoder or an AV amplifier with a built-in DTS decoder, the DTS audio of DVD discs
recorded in this format can be enjoyed. However, audio will not be output from the analog audio output jacks.

•

By connecting this unit to an AV amplifier with a built-in MPEG decoder, the MPEG audio of DVD discs
recorded in this format can be enjoyed.

•

The Linear PCM sound of a 48 kHz/24 bit through 96 kHz/24 bit exceeds audio CD sound.

Convenience Features

Direct selection of your desired scenes using Title/Chapter/Time/Track - You can playback from the

desired scene.

Recalling Up to 12 Scenes - You can program up to 12 scenes in memory and recall the marked scenes.
Frame Advance - The PAUSE/STILL and SEARCH moves one frame at a time.
Slow Motion - The SLOW moves you back and forth through the program by 4 steps of 1/16-1/2 times.
Repeat Playback - You can repeat chapter, track, title, sides or material between two selected points.
Program Playback DVD (DVD Audio CD/MP3/WMA) - You can playback tracks in programmed sequences.
Zoom - You can zoom in the selected subject on the screen during playback.

Note: Make sure that discs are suitable for the following functions.
Multi-Language - Maximum 32 language subtitles and maximum 8 language soundtracks can be played back

for movies or programs.
Multi-Angle - Pictures of Sports or a Live Concert are recorded with many cameras. When you play such a disc,
you can change the angles during playback.
Parental Control - You can limit the playback of scenes or sounds of DVD discs that have a rating level
encoded on the disc.

Video Aspect Ratio - You can change the aspect ratio of the screen for your monitor.

TV Features

Integrated Digital Tuner - You can view digital broadcasts without using a Digital TV Set-Top Box.
Closed Caption Decoder With Full Text Mode - Displays text captions or full screen text on the screen for

hearing impaired viewers.
Picture Adjustments Using The Remote Control - The On-Screen display allows precise remote control
adjustment of BRIGHTNESS, CONTRAST, COLOR, TINT and SHARPNESS.
Programmable TV Sleep Timer - Operable from the remote control, the TV can be programmed for up to 240
minutes to turn off automatically.
On-Screen 3 Languages Display - You can select one of 3 languages, English, Spanish or French for on­screen programming.
V-Chip - The V-Chip function can read the rating of a TV program or movie content if the program is encoded
with this information. V-Chip will allow you to set a restriction level.

7 EN

Logos & Licenses

This item incorporates copy protection technology that is protected by U.S. patents and other intellectual
property rights of Rovi Corporation. Reverse engineering and disassembly are prohibited.

is a trademark of DVD Format/Logo Licensing Corporation.

Manufactured under license from Dolby Laboratories. Dolby and the
double-D symbol are trademarks of Dolby Laboratories.

The terms HDMI and HDMI High-Definition Multimedia Interface, and the
HDMI Logo are trademarks or registered trademarks of HDMI Licensing
LLC in the United States and other countries.

Enabling certain features and functionality in this TV (e.g., DBC, Picture
Preference, Volume, Equalizer Settings) may increase its energy
consumption, possibly beyond the limits required for ENERGY STAR
qualification.

®

EN 8

Contents

Before using your unit

IMPORTANT SAFETY INSTRUCTIONS ...........3

SAFETY PRECAUTIONS .................................5

IMPORTANT NOTICE .......................................5

How to attach the stand ....................................6

How to remove the stand .................................. 6

Features ............................................................7

Logos & Licenses .............................................8

Contents ...........................................................9

Disc.................................................................10

Parts and functions .........................................12

Remote control ...............................................13

Power source ..................................................14

Antenna connections ......................................15

Cable TV connections .....................................15

TV operation

Starting setup .................................................16

TV operation ...................................................16

Quick guide for menu operation ......................17

Convenience functions ...................................18

Channel setup.................................................21

Labeling channels ...........................................22

Setting the V-Chip ...........................................22

Closed Caption ............................................... 24

CC options ......................................................24

Setting the picture size .................................... 25

Media Playback ..............................................25

DVD operation

Preparation .....................................................27

Status display of disc ...................................... 27

Playback procedure ........................................27

Special playback ............................................. 28

Zoom. ..............................................................28

Locating desired scene ...................................28

A-B Repeat playback ......................................28

Marking desired scenes ..................................29

Changing angles .............................................29

Changing soundtrack language ......................29

Subtitles .......................................................... 29

Using HOME MENU .......................................30

Play mode .......................................................30

Audio Settings menu ....................................... 31

Video Adjust menu .......................................... 32

Quick guide for DVD menu operation ..............32

Function Setup ................................................33

Parental Control ..............................................34

Additional information

Language Code List ........................................ 35

Country/Area Code List ..................................35

Connections to other equipment .....................36

Reception disturbances .................................. 39

Problems and troubleshooting ........................40

Specifications ................................................42

limited WARRANTY .......................................43

9 EN

Disc

Playable discs

Disc type and logo mark content

DVD Video

CD-DA

The following discs are also available.

DVD-ROM/-R/-RW/-R DL discs of DVD video

•
format and MP3/WMA/JPEG.
CD-ROM/-R/RW discs of MP3/WMA/JPEG.

•

(moving

pictures)

Audio

+

Video

Audio

CAUTION:

•

Only the left types of discs can be played on this
unit. DVD-ROM (for PC), CD-ROM (for PC), SVCD,
CVD, VCD, etc. cannot be played.

•

This unit cannot play an 8 cm disc. It cannot also be
played even using a disc adapter.

•

If you insert an irregular shaped disc, it may get
stuck and cause a malfunction.

•

The use of a ring protector or other disc
accessories will cause errors.

•

This unit is to be used exclusively with the NTSC
color system. PAL and SECAM system discs cannot
be used with this unit.

•

Some discs cannot be played back depending on
the recording conditions.

Region Number

Region number (Regional restriction code) is built-in to the unit and DVD video discs.
Region number “1” or “ALL” of DVD video discs can be used on this unit.

Title

When two or more movies are recorded on a disc, the disc
is divided into two or more sections. Each section is called
a “TITLE”.

TITLE 1 TITLE 2

CHAPTER 1

DVD DISC

CHAPTER 2 CHAPTER 2 CHAPTER 3CHAPTER 1

Chapter

The titles can be subdivided into many sections.
Each section is called a “CHAPTER”.

Track

An Audio CD can contain several items.
These are assigned to the tracks.

TRACK 1 TRACK 2 TRACK 3 TRACK 4 TRACK 5

Audio CD

ALL

1

Removing Disc from Case

Be sure to hold the edge of disc. Do not touch the surface of the disc.
Pick up the disc gently from the case.

•

Do not scratch the disc.

•

Do not get dirt on the surface of the disc.

•

Do not stick a label or adhesive tape on the disc.

•

Do not drop or bend the disc.

Storing Disc

•

Store the disc in the case to avoid risk of scratches, dirt or damage.

•

Do not leave disc exposed to direct sunlight or in hot or humid places.

Cleaning Disc

Wipe the disc with a clean, dry cloth from center to edge.

•

Do not wipe the disc in a circular motion.

•

Do not use liquid or aerosol cleaners.

EN 10

Disc

■ Title/Chapter/Track PC-created disc

• You may not be able to play discs recorded
using a personal computer or recorder for disc
compatibilities, scratches or marks on the disc, dirty
lenses of the unit or condensation and so on.

• Discs recorded using a personal computer may
not be playable in this unit due to the setting of the
application software used to create the disc. In
these particular instances, check with the software
publisher for more detailed information.

■ Playable files

• ISO 9660 Level 1 or 2 compliant.

Romeo and Joliet file systems are both compatible

with this player.

• DRM (Digital Rights Management) protected files
will not play in this player.

For detailed information, please see the instruction

manuals or help files that came with your PC and/or
software.

• File structure (may differ): Up to 299 folders on a
disc; up to 648 files within each folder.

• Folder and file names can be displayed as long
as they are typed in alphabets and numbers. If
folder and file names are other than alphabets and
numbers, they may be replaced and displayed like
as “_”. Garbled characters may also be displayed in
this case.

■ Playing image files

JPEG files recorded in DVD-ROM/-R/-RW/-R DL and
CD-ROM/-R/-RW can be played.

■ JPEG file compatibility

• Image files should be saved in JPEG format.

• Files recorded in Fuji Colour CD, Kodak Picture CD
or CD-R/-RW can be played.

• Compatible formats: Baseline JPEG and EXIF 2.2*
still image files up to a resolution of 3072 x 2048.

*File format used by digital still cameras.

• Files with extensions .jpg or .JPG can be played.

• Progressive JPEG formatted files do not work.

• It may take some more time to start to play larger
files than usual.

• JPEG files with different aspect ratio may be
displayed with black bands (either vertical or
horizontal).

■ Windows Media Audio (WMA)
compatibility

• WMA is an acronym for Windows Media Audio
and refers to an audio compression technology
developed by Microsoft Corporation.

• You can encode your files by using Windows
Media Player Ver.7, 7.1, Windows Media Player for
Windows XP or Windows Media Player 9 Series.

• When encoding your files, use only applications
approved by Microsoft Corporation. If you use non­approved application, it may not work properly.

• This unit is compatible with audio files recorded with
the following sampling frequency: 32 kHz, 44.1 kHz
and 48 kHz.

• It is not compatible with loss-less encoding.

• Files with extensions .wma or .WMA can be played.

■ Playing MP3 (MPEG-1 Audio Layer-3) files

• This unit is compatible with audio files recorded with
the following sampling frequency: 32 kHz, 44.1 kHz
and 48 kHz.

• Files with extensions .mp3 or .MP3 can be played.

• For the best quality of sound, 128 kbps or higher bit
rate is recommended.

■ Copy Control CD (CCCD)

This product is designed to conform to CD-DA
(Compact Disc Digital Audio). Any other discs than
CD-DA are not guaranteed with their operation and
performance in this product.

Note on copyright

• Unauthorized recording of copyrighted television
programs, films, video cassettes and other materials
may infringe the rights of copyright owners and be
contrary to copyright laws.

■ Playing Audio files

WMA and MP3 files recoded in DVD-ROM/-R/-RW/

-R DL, CD-ROM/-R/-RW can be played.

11 EN

Parts and functions

Right sideFront

INPUT/ENTER button
CH (CHANNEL)

/STOP (7) button/MENU 5
CH (CHANNEL) /
EJECT (0) button/MENU ∞
VOL (VOLUME) +/– buttons
/MENU 2/3

POWER button

/PLAY (£)

USB INPUT

HDMI/DVI1/2 IN jacks

AUDIO (L/R) IN jacks

(Y(VIDEO)/Pb/Pr) jacks

COAXIAL OUT jack

AUDIO (L/R) OUT jacks

VIDEO IN/

COMPONENT IN

Right side

Remote sensor

Power Indicator
Red : Standby
Green : On

Rear

Press and hold both VOL +/– at the same time
for 1 second to display the menu screen.

CH (CHANNEL)
(VOLUME) +/– buttons and INPUT/ENTER

button can be used to select the desired setting
during the menu screen operations.

PC MONITOR IN jack

/ buttons,

VOL

EN 12

ANT. (RF) IN jack

DISC slot

Remote control

POWER Power On/Off
DISPLAY/– Call TV information

TV/DVD Switch between TV and DVD

(EJECT) Eject a disc

0-9 Direct channel selection of TV

VOL +/– Adjust volume of the TV
MUTING Switch off the sound
SLEEP Sleep timer
SETUP/

TV MENU
DVD MENU Display DVD menu

/

CH
▲▼◀▶ Cursor buttons
ENTER Enter information in the menu
EXIT/

CANCEL
TOP MENU Select title
SEARCH Fast Forward/Review playback
PLAY Start playback
SKIP Skip chapter to forward or reverse direction
SUBTITLE Set subtitle
STOP Stop
SLOW Forward/Reverse- slow motion
PAUSE/

STILL
PLAY MODE Select playback mode
AUDIO Change soundtrack language
RETURN Remove DVD setup menu
REPEAT A-B Repeat playback between A and B
ANGLE Change playback angle
SCREEN SIZE Display Picture Size menu
MARKER Index
CCD/

JUMP
RECALL/

ZOOM
INPUT SELECT Display source selection menu

Call DVD information
Input “–” for digital channels

Enter a password

DVD mode - Call up initial setup mode
TV mode - Display menu of TV

Select channel of TV

Exit from On-Screen menu

Pause CD sound
Still picture of DVD

Closed Caption
Locating desired scene

Switch between present/last channel
Zoom

13 EN

Remote control

Inserting Batteries

Open the battery compartment

1

cover in the direction of the arrow.

Operation

Aim the remote control at the remote sensor and press control

•
buttons to operate.
Operate the remote control within a 30° angle on either side of

•
the remote sensor, up to a distance of approximately 15 feet.

BATTERY PRECAUTIONS:

Batteries should not be exposed to excessive heat such as sunshine, fire or the like.

•
The remote control unit uses infrared beams to transmit signals, so sunlight or fluorescent light on the remote

•
sensor may shorten operating distance.
Incorrect use of batteries may cause them to leak or burst. Read the battery warnings and use the batteries

•
properly.
Do not mix old and new batteries.

•
Do not mix alkaline, standard (carbon-zinc), or rechargeable, (Ni-Cd, Ni-MH, etc.) batteries.

•
Remove batteries if the remote control will not be operated for an extended period of time.

•

If this symbol is shown, it is only
valid in the European union.

Install two “AAA” batteries,

2

paying attention to the
polarity diagram in the battery
compartment.

Replace the compartment cover.

3

Approximately 15 feet

Power source

TO USE AC POWER SOURCE

Use the AC polarized line cord provided for operation on AC. Insert the AC cord plug into a standard 120V 60Hz
polarized AC outlet.

AC Outlet

Wider Hole and Blade

Polarized AC Cord Plug
(One blade is wider than the other.)

NOTE:

•

Never connect the AC line cord plug to other than the specified voltage (120V 60Hz).
Use the attached power cord only.

•

If the polarized AC cord does not fit into a non-polarized AC outlet, do not attempt to file or cut the blade.
It is the user’s responsibility to have an electrician replace the obsolete outlet.

•

If you cause a static discharge when touching the unit and the unit fails to function, simply unplug the unit from
the AC outlet and plug it back in. The unit should return to normal operation.

EN 14

Antenna connections

If you are using an indoor or outdoor antenna, follow the instructions below that correspond to your
antenna system. If you are using a Cable TV service, see “Cable TV connections”.

Combination VHF/UHF Antenna (Single 75 ohm cable)

Antenna

Jack

75 ohm
Coaxial
Cable

Connect the 75 ohm cable from the combination
VHF/UHF antenna to the Antenna Jack.

Cable TV connections

This TV has an extended tuning range and can tune most cable channels without using a Cable TV
Converter box. Some cable companies offer “premium pay channels” where the signal is scrambled.
Descrambling these signals for normal viewing requires the use of a descrambler device which is
generally provided by the Cable TV company.

For subscribers to basic Cable TV service

75 ohm

Antenna

Jack

Coaxial
Cable

For subscribers to scrambled Cable TV service

If you subscribe to a Cable TV service which requires the use of a Converter/Descrambler box, connect
the incoming 75 ohm Coaxial Cable to the Converter/Descrambler box. Using another 75 ohm Coaxial
Cable, connect the output jack of the Converter/Descrambler box to the Antenna Jack on the TV. Follow the
connections shown below. Set the TV to the output channel of the Converter/Descrambler box (usually channel
3 or 4) and use the Converter/Descrambler box to select channels.

Incoming
75 ohm
Cable TV
Cable

Converter/

Descrambler

For basic Cable TV service not requiring a Converter/
Descrambler box, connect the 75 ohm Coaxial Cable directly
to the Antenna Jack on the back of the TV.

Antenna

Jack

75 ohm Cable to TV

For subscribers to unscrambled Cable TV service with scrambled premium
channels

If you subscribe to a Cable TV service in which basic channels are unscrambled and premium channels require
the use of a Converter/Descrambler box, you may wish to use a signal Splitter and an A/B Switch box (available
from the Cable TV company or an electronics supply store). Follow the connections shown below. With the
switch in the “B” position, you can directly tune any nonscrambled channels on your TV. With the switch in the
“A” position, tune your TV to the output of the Converter/Descrambler box (usually channel 3 or 4) and use the
Converter/Descrambler box to tune scrambled channels.

Incoming
75 ohm
Cable TV
Cable

Splitter

Converter/

Descrambler

A/B Switch

75 ohm Cable to TV

A

B

Antenna

Jack

15 EN

Starting setup

TV operation

The Initial Setup menu appears the first time you
turn on the TV, and assists you to specify the
Air/Cable setting, and program your channels
automatically.

IMPORTANT: Make sure that the antenna or cable
TV system connection is made!

To turn on the TV, press (POWER). (POWER

1

indicator on the front of the unit changes green.
It may take approx. 10 seconds for a picture to
appear on screen.) The Initial Setup function
begins.

Initial Setup

TV Location

Go to next step

Press

▲ or ▼

2

◀ or ▶ to select “Store” or “Home”. This product
qualifies for ENERGY STAR In Home mode
default setting. Then press ▼ or ENTER.

Press ▶ or ENTER to go to next step.

3

Press ◀ or ▶ to select your time zone, then

4

press ▼ or ENTER.

In the rare event that you live within broadcast

•
range of two stations in two different time
zones, the TV may recognize the wrong
station for the auto clock set.

Press ◀ or ▶ to select daylight saving time on

5

or off, then press ▼ or ENTER.
Press ◀ or ▶ to select desired time format, then

6

press ▼ or ENTER.
Press ◀ or ▶ to set the “Auto Sleep”, then press

7

▼ or ENTER.
Press ▶ or ENTER to go to next step.

8

Press ▲ or ▼ to select “Air/Cable”, then press

9

◀ or ▶ to select signal type that you using, then
press ▼ or ENTER.

Press ▶ or ENTER to go to next step.

10

Auto scan will begin. After tuning is completed,

11

the TV channel appears on the screen.

Depending on the reception condition, it

•
may take up to 30 minutes to complete
memorizing digital cable channels. Please
allow the process to complete without
interruption.

NOTE:

If you press TV MENU or EXIT in the process of

•
“Automatic Search”, the auto scan stops and changes to
normal screen.
When you make a menu selection, your changes occur

•
immediately. You do not have to press TV MENU to see
your changes.

to select “TV Location”, then press

Store

To turn on the TV, press (POWER). (POWER

1

indicator on the front of the unit changes green.
It may take approx. 10 seconds for a picture to
appear on screen.)

Adjust the volume level by pressing VOL + or – .

2

The volume level will be indicated on the screen
by brown bars. As the volume level increases, so
do the number of bars. If the volume decreases,
the number of brown bars also decreases.

Set the signal type option to the appropriate

3

position (see “Air/Cable selection” on page 21).
Press the Direct Channel Selection (0-9, –)

4

buttons to select the channel.
(If you press only channel number, channel
selection will be delayed for a few seconds.)

TO SELECT ANALOG CHANNELS

1-9: Press 1-9 as needed. Example, to

10-99: Press the 2 digits in order. Example,

100-135: Press the 3 digits in order. Example, to

TO SELECT DIGITAL CHANNELS

Press the first 1-3 digits, then press the – button,
followed by the remaining number.
Example, to select channel 15-1, press 1, 5, –, 1,
then press ENTER.

•

•

The same program may be available on either

VHF/UHF/CABLE CHANNELS

VHF
2-13

UHF

14-69

NOTE:

If a channel with no broadcast is selected, the sound will

•
automatically be muted.
It may take a few seconds for a digital channel picture to

•
appear on screen after being selected.

To select the video input source

To view a signal from another device connected
to your TV, such as a VCR player, press INPUT
SELECT, then press ▲ or ▼, then press ENTER.

select channel 2, press 2, then press
ENTER.

to select channel 12, press 1, 2, then
press ENTER.

select channel 120, press 1, 2, 0, then
press ENTER.

If a channel is selected with only audio content,
“Audio Only” will be displayed on the screen.
If a channel is selected with a weak digital
signal, “No Signal” will be displayed on the
screen.

an analog channel or a digital channel. You may
choose to watch either format.

Air Cable

VHF
2-13

STD/HRC/IRC
14-36 (A) (W)
37-59 (AA) (WW)
60-85 (AAA) (ZZZ)
86-94 (86) (94)
95-99 (A-5) (A-1)
100-135 (100) (135)
01 (4A)

EN 16

CH /

Press and release CH / . The channel
automatically stops at the next channel set into
memory.
For proper operation, before selecting channels, they
should be set into the memory. See “Channel setup”
on page 21.

DISPLAY

Press DISPLAY to display the current information on
the screen.

When the TV receives a digital signal, the digital
information will appear.

15-1

CH-1

3_ARTE_Monosco_0820_0000_0030_Audio6_ABCDEFGHIJKLMNOPQ
RSTUVWXYZabcdefghijklmnopqrstuvwxyz_ABCDEFGHIJKLMNOPQR
STUVWXYZabcdefghijklmnopqrs tuvwxyz_ABCDEFGHIJKLMNOPQRS
TUVWXYZabcdefghijklmnopqrs

CC

SD

Service1

480i Audio 2/3

2013/01/01 17:10

Digital Air

Monoscope_480i_1

TV-14-D

Good

Channel number• DTV Signal condition•

Broadcast program name

Channel label (if preset)•

•
V-Chip rating• Current date and time•
Program guide• Audio language•
Resolution• Closed Caption•

Press DISPLAY again to clear the call display.

NOTE:

•

After a few seconds, DISPLAY screen will return to
normal TV operation automatically.

SLEEP

To set the TV to turn off after a preset amount of time,
press SLEEP on the remote control. The clock will
change for each press of the SLEEP button (Off, 5
min, 10 min, ..., 240 min).To confirm the sleep timer
setting, press SLEEP and the remaining time will
be displayed for a few seconds. To cancel the sleep
timer, press SLEEP repeatedly until the display turns
to Off.

Quick guide for menu
operation

Call menu and for example: Select Language.

Press INPUT SELECT to select TV mode.

1

Press TV MENU. The TV menu screen will

2

appear.

Picture Sound Time Setup Lock Channel

Picture Preference

Brightness

Contrast

Color

Tint

Sharpness

Color Temperature

Advanced Settings

Press ◀ or ▶ to select “Setup”, then press ▼.

3

Press ▲ or ▼ to select “Language”, then press ◀

4

or ▶ to select the desired language.
…on the following pages the menu can be called
in the same way as here.

Press TV MENU to return to the previous screen.

5

NOTE:

•

If no buttons are pressed for more than about 30
(depending on your setting) seconds, the menu
screen will return to normal operation automatically.

•

During TV or external input mode (except PC
input mode), if there is no signal reception with
no operation, the TV will change to standby after
approx. 15 minutes (in PC input mode: 1 minute).

Dynamic

Cool

50

100

50

50

50

17 EN

Convenience functions

You can change the default settings by pressing the TV MENU button on your remote, then select the one of the
icons at the top of the menu - follow the On-Screen prompts to set your preferences.

Icon Selected Items Setup hint


Picture Preference

Power Saving The darker the brightness for power-saving
Standard Standard picture quality
Dynamic Bright and dynamic picture
Soft Soft edge picture setting
User Your personal preferences

Brightness You can adjust the picture quality to your preference.
Contrast
Color
Tint

Sharpness
Color Temperature Cool (Bluish) / Standard (Neutral) / Warm (Reddish)
Advanced Settings

Picture Size See page 25.
Noise Reduction To set the level of decreasing noises included in the video

Medium / High / Off /

Low

DBC Use this feature to change the Black level automatically

Off / ECO / On

DLC DLC (Dynamic Luminance Contrast) function would adjust

Off / On

Film Mode A smoother motion may be obtained by setting the Film

Off / On

HDMI Mode Select the HDMI input signal as Video (for video) or Graphic

Video / Graphic

Available only when you selected “User”.

•
“Tint” is available only in Analog TV and AV mode.

•

signal.

according to the brightness of an image. The Black level will
become dark in a dark scene. If “ECO” is selected, the power
consumption is reduced.

DBC is not available in Media mode.•

the luminance follow the average brightness automatically

Mode to “On”.

(for PC).

NOTE:

•

The device may not conform to the Energy Star standard after Picture setting (e.g., DBC, Picture Preference)

Sound setting (e.g., volume, Equalizer Settings) are adjusted.

and

EN 18

Convenience functions

Icon Selected Items Setup hint

Sound

Equalizer Settings

Equalizer Mode

Time

Standard / Music /
Movie / Sports

User The setting of this item adjusts the audio level of its

150 Hz / 500 Hz/
1K Hz/5K Hz/
10K Hz

Balance Adjust the left and right sound channel volume.

MTS The multi-channel TV sound (MTS) feature provides high-

Stereo / SAP / Mono

Audio Language When two or more audio languages are included in a digital

English / French / Spanish

Digital Audio Output Select the format for your digital audio output If you have

Raw / Off / PCM

Surround

Off / On

Auto Volume Volume level can be adjusted automatically by the sound

Off / On

Sleep Timer Sleep Timer switches the TV to standby after a defined

Off / 5 / 10 / 15 / 30 / 60 / 90 /
120 / 180 / 240 min

Time Zone Select your local time zone for auto clock feature.

Daylight Saving Time If you want to activate the Daylight Saving Time, select “On”.

Off / On

Time Format Select the time format.

12-hour / 24-hour

Auto Clock The Auto Clock function will automatically set the built-in

Off / On

Clock Using the ▲/▼/◀/▶, the setting value is changed.

Auto Sleep When the Set and Remote button operation are not operated

Off / 3 / 4 / 5 Hours

On Timer

Power On Timer You can set the On Timer to automatically turn on the TV.

Off/Once/On
Timer Set the timer using ▲/▼/◀/▶.
Power On Channel You can set the channel that appear with power on.

Off Timer

Power Off Timer You can set the Off Timer to automatically turn off the TV.

Off/Once/On
Timer Set the timer using ▲/▼/◀/▶.

You can choose a basic equalizer mode. Depending on this
setting, the following detail setting is set to default value of
each mode.

frequency corresponding to each setting.

Available only when you selected “User”.•

fidelity stereo sound. MTS also can transmit a second audio
program (SAP) containing a second language or other audio
information. This item is valid only when the analog broad­cast.

signal, you can select one of the audio language. (This func­tion is available only for digital broadcast.)

connected an amplifier / receiver to the digital audio jack on
your TV.

The dynamic presence and sound created offers a thoroughly
enjoyable listening experience.

level.

period of time.
To cancel the Sleep Timer, set to “Off”.

You can select Newfoundland, Atlantic, Eastern, Central,
Mountain, Pacific, Alaska, Hawaii and Samoa.

clock (Year, Month, Day and Time) when the TV is connected
to an antenna or cable TV system and it is turned off. As
the TV searches for a receivable station in your area and it
receives a broadcast signal for Auto Clock, the Auto Clock
needs several minutes to set itself.

Available only when you selected “Auto Clock” to “Off”.•

with specified period by this setting (3/4/5 Hours), the power
status is changed to stand by mode automatically.

To cancel the On Timer, select “Off”.

To cancel the Off Timer, select “Off”.

19 EN

Convenience functions

Icon Selected Items Setup hint

Setup

Language

English / Français / Español You can choose from three different languages (English,

OSD Timeout

5 / 15 / 30 / 45 / 60 Sec. You can set the display time of OSD Menu.
Closed Caption See page 24.
Over Scan To adjust the size of the display by removing excess or

Off / On
Input Label The Input Label feature allows you to label each input source

Default / Antenna / Cable /

Satellite / DTV / DVD / Blu-ray /

HD-DVD / XBOX / Wii / PS3 /

Game / Computer / VCR / DV /

Custom (10 characters)
PC Settings (available only for PC mode)

H-Pos To adjust the horizontal placing of the image.

V-Pos To adjust the vertical placing of the image.

Clock Eliminates the vertical (CLOCK) interfering lines.

Phase Eliminates the horizontal (PHASE) interfering lines.

Auto To adjust the all PC settings automatically.
Other Settings

Audio Only You can turn off the picture on your TV and listen to the pro-

Off / On

TV Location Select location of TV. Usually, select “Home”.

Store / Home

Restore Default Select “Yes”, then press ENTER. Restore Picture, Sound

No / Yes

Initial Setup See page 16. (TV mode only)

Lock See page 22.
Channel See page 21.

Français (French) and Español (Spanish)) for the on-screen
displays.
Select the language you prefer first, then proceed with the
other menu options.

unattractive when set it to”On”.

for your TV.
You can select label from default value or input by yourself
with ▲/▼ (alphabet select) / ◀/▶ (select character / position).

gram audio only.
To exit audio only mode, press any buttons (except VOL +/-,
MUTING) on your remote control or unit.

(except “Audio Language”), Time (Sleep Timer, Time Format
and Auto Sleep only) and Setup (except “Language”)
settings to the default factory settings.

EN 20

Channel setup

This TV is equipped with a channel memory
feature which allows channels to skip up or down
to the next channel set into memory, skipping
over unwanted channels. Before selecting
channels, they must be programmed into the
TV’s memory. To use this TV with an antenna,
set the signal type option to the Air mode. When
shipped from the factory, this menu option is in
the Cable mode.

Air/Cable selection

Select “Channel ⇒ Air/Cable”.

1

Press ◀ or ▶ to select “Air” or “Cable”.

2

Air - VHF/UHF channels
Cable - CABLE TV channels

Picture Sound Time Setup Lock Channel

Air/Cable

Automatic Search

Channel List

Show/Hide

Channel Number

Channel Label

NOTE:

It may take a few seconds for a digital channel

•
picture to appear on screen after being selected.

Automatic Search

Select “Channel ⇒

1

▶ or ENTER.

Cable

23

CH-2

Automatic Search

”, then press

Should you require further assistance you may call
our toll-free customer service line at 1-800-289-0984.

•

New digital channels may be added to your area
periodically, it is recommended to perform the
“Automatic Search” procedure regularly.

The new channel will be added into the channel

3

memory.

Show/Hide channel

You can select the channel that you want to skip.

Select “Channel ⇒ Show/Hide”, then press ▶ or

1

ENTER.
Press ▲ or ▼ to select the channel that you want

2

to skip.

Sound Time Setup Lock

Picture Channel

Channel Channel Label Hide

4-0

7-0

12-0

23-2

CH-2

23-3

CH-3

CH-77

23-77

CH-999

23-999

Prev Next

Press ENTER to assign 3 mark for unwanted

3

channel.
Repeat steps 2 - 3 for other channels you want to

4

show/hide.

1/1

Sound Time Setup Lock

Picture Channel

Are you sure to

Automatic Search?

No Yes

In confirmation window, Press ▶ to select “Yes”,

2

then press ENTER. The TV will begin memorizing
all the channels available in your area.

•

Depending on the reception condition, it may
take up to 30 minutes to complete memorizing
digital cable channels. Please allow the
process to complete without interruption.

•

If you press TV MENU during search, channel
search will stop.

NOTE:

•

Memorizing channels is best accomplished during
evening “PRIMETIME” hours, as more stations are
broadcasting digital signals. Memorizing channels can
only be accomplished while a station is broadcasting
a digital signal to set that channel into memory.
If you are unsure of the digital channels available

•
in your area, you may visit www.antennaweb.org to
receive a list based on your address or zip code.

21 EN

Labeling channels

Channel label appear with the channel number
display each time you turn on the TV, select a
channel, or press DISPLAY.
You can choose any 7 characters to identify a
channel.

To create channel labels

Select “Channel ⇒ Channel Number”.

1

Press ◀ or ▶ to select a channel you want to

2

label, then press ▼ to select “Channel Label”.
Then press ▶ or ENTER.

Sound Time Setup Lock

Picture Channel

Air/Cable

Automatic Search

Channel List

Show/Hide

Channel Number

Channel Label

Press ▲ or ▼ repeatedly until the character you

3

want appears in the first space.

Sound Time Setup Lock

Picture Channel

CH 3

If the character which you desire appears, press ▶.
You can also change the position which input
character by pressing
Repeat this step to enter the rest of the characters,
then press ENTER.

Repeat steps 2-3 for other channel. You can

4

assign a label to each channel.
When you finish inputting the label name, press

5

EXIT to return to the normal screen.

NOTE:

The channel labels will be reset after “Automatic

•
Search” on page 21.

Cable

◀ or ▶

CH-2

23

.

Setting the V-Chip

An age limitation can be set to restrict children from
viewing or hearing violent scenes or pictures that you
may choose to exclude. The restriction applies to
“TV Rating” and “Movie Rating” if this data is
transmitted. You may set this restriction separately.
To use the V-Chip function, you must register a
password.

To register a password

Select “Lock”, then press ▼.

1

Press 0000 using Number buttons(0-9). (This is

2

default password.)

Sound Time Setup Lock

Picture Channel

Enter Password

“ ” appears instead of the number.

NOTE:

•

If you forget the password, contact Customer
Service at 1-800-289-0984 for assistance.
Your original remote control will be required.

•

To avoid forgetting the password, write it down and
keep in a safe place.

How to enter the V-Chip menu

Select “Lock” menu, then press ▼.

1

Use Number buttons (0-9) to enter your

2

password.

To Lock the connected devices

In the Lock menu, press ▲ or ▼ to select “V-Chip”,

1

then press ◀ or ▶ to set to “On”.

Press ▲ or ▼ to select “Input Block”, then press ▶

2

or ENTER.

Sound Time Setup Lock

Picture Channel

TV

AV

Component

HDMI1

HDMI2

PC

DVD

Media

Press ▲ or ▼ to select which device will be

3

blocked, then press ◀ or ▶ to select “Block”.

NOTE:

Blocked device will appear in Source Select

•
window. Enter your password before watching.
If you want to use such a device again, you should
setting “UnBlock” in step 3.

UnBlock

UnBlock

UnBlock

UnBlock

UnBlock

UnBlock

UnBlock

UnBlock

EN 22

To set the V-Chip

In the V-Chip menu, press ▲ or ▼ to select

1

“ V-Chip” then press ◀ or ▶ to set to “On”.

Press ▲ or ▼ to select “US Rating”, then press ▶

2

or ENTER.
Press ▲ or ▼ to select which rating will be used,

3

then press ▶ or ENTER. Each rating below will
appear.

TV Rating

Sound Time Setup Lock

Picture Channel

TV-Y

TV-Y7

TV-G

TV-PG

TV-14

TV-MA

You can set the rating using age level and genre.

Age:
TV-Y : All children
TV-Y7 : 7 years old and above
TV-G : General audience
TV-PG : Parental guidance
TV-14 : 14 years old and above
TV-MA : 17 years old and above

When you select TV-Y7, TV-PG, TV-14 or TV-MA,
press DISPLAY to explain the rating.

Genre:
FV : Fantasy Violence
V : Violence
S : Sex
L : Language
D : Dialogue

Press ▲/▼ to select the desired rating, then press

ENTER.
Movie Rating

Off : None
G : All ages
PG : Parental guidance
PG-13 : Parental guidance
R : Under 17 years old parental guidance

suggested

NC-17 : 17 years old and above
X : Adult only

Press ◀/▶ to select the desired rating.

Press EXIT to return to the normal screen.

4

V-Chip function is activated now.

less than 13 years old

To use the TV after the TV is protected.

When a program is received that is blocked by the
V-Chip, you should set the V-Chip to “Off” or set
appropriate TV/Movie Rating level for the blocked
program (see “To set the V-Chip” on left column).
After that, you should re-set the V-Chip, if you need.

NOTE:

The V-Chip function is activated only on programs

•
and input sources that include a rating signal.

To change the password

In the V-Chip menu, press ▲ or ▼ to select

1

“Change Password”, then press ▶ or ENTER.

Enter a current password using Number buttons

2

(0-9).

Enter a new password using Number buttons

3

(0-9).

Enter the same password again to confirm.

4

The password is now registered.

Downloading the additional V-Chip rating system

As a supplement to the standard V-Chip rating
system, your television will be able to download an
additional rating system, if such a system becomes
available in the future.

To download the additional V-Chip rating system
(when available)

In the V-Chip menu, press ▲ or ▼ to select

1

“ V-Chip” then press ◀ or ▶ to set to “On”.
Press ▲ or ▼ to select “V-Chip Set (DTV)”, then

2

press ▶ or ENTER.
If the TV is not storing the additional rating

3

system, the TV will begin downloading it, which
may take some time to be completed.

Set your preferred content rating limits for the

4

additional rating system.

NOTE:

•

You can only download the additional V-Chip rating
system when your TV is receiving a digital signal.

•

When you download the additional rating system, it
may take some time for the download to occur.

•

The V-Chip rating information and system are not
determined or controlled by the TV.

•

The standard V-Chip rating system is available
whether your TV is receiving a digital signal or not,
and will block both analog and digital programs.
To set the restriction level using the standard V-Chip
rating system, select “US Rating” in step 2.

•

The downloadable V-Chip rating system is an
evolving technology, and availability, content, and
format may vary.

To clear the V-Chip Set (DTV)

In the V-Chip menu, press ▲ or ▼ to select

1

“ V-Chip” then press ◀ or ▶ to set to “On”.
Press ▲ or ▼ to select “RRT Clear”, then press

2

▶ or ENTER.
The confirmation window will appear.

Press ▶ to select “Yes”, then press ENTER.

3

Your V-Chip Set (DTV) will clear.

23 EN

Closed Caption

WHAT IS CLOSED CAPTIONING?

This television has the capability to decode and
display Closed Captioned television programs.
Closed Captioning will display text on the screen
for hearing impaired viewers or it will translate and
display text in another language.

Captions: This Closed Caption mode will display
text on the screen in English or another language.
Generally, Closed Captions in English are transmitted
on CC1 and Closed Captions in other languages are
transmitted on CC2.
Text: The Text Closed Caption mode will usually fill
1/2 of the screen with a programming schedule or
other information.

Select “Setup ⇒ Closed Caption”, then press ▶ or

1

ENTER.

Press ◀ or ▶ to set “CC Setting” to “CC On” or

2

“CC on Muting”.

CC On: Captions will be displayed on the screen.
CC on Muting: Only when you press MUTING,

captions will be displayed.
CC Off: Captions will not be displayed on the screen.

Press ▲ or ▼ to select “Analog Caption” or “Digital

3

Caption”.
When you select “Analog Caption”, you can

choose from CC1~4, Text1~4.
When you select “Digital Caption”, you can

choose from Service1~6 and Off.
Press ◀ or ▶ to select the desired Closed

4

mode for both Digital and Analog Captions.

NOTE:

Depending on the broadcast signal, some

•
Analog Captions will function with a Digital
broadcast signal. This step prevent that two
kind of captions are overlapping.

NOTE:

If the program or video you selected is not closed-

•
captioned, no captions will display on-screen.
If text is not available in your viewing area, a black

•
rectangle may appear on-screen. If this happens,
set the CC Setting to “CC Off”.
When selecting Closed Captions, the captioning

•
will be delayed approx. 10 seconds.
If no caption signal is received, no captions will

•
appear, but the television will remain in the Caption
mode.
Misspellings or unusual characters may

•
occasionally appear during Closed Captioning.
This is normal with Closed Captioning, especially
with live programs. This is because during live
programs, captions are also entered live. These
transmissions do not allow time for editing.
When Captions are being displayed, on-screen

•
displays, such as volume may be seen but may
interfere with Closed Captions.
Some cable systems and copy protection systems

•
may interfere with the Closed Captioned signal.
If using an indoor antenna or if TV reception is

•
very poor, the closed caption decoder may not
appear or may appear with strange characters or
misspelled words. In this case, adjust the antenna
for better reception or use an outdoor antenna.

Caption

•

CC Setting will be change to”CC Off”,”CC On” or “CC
on

Muting

control.

” by each pressing CCD on the remote

CC options

When you have selected “Custom” as the display
method, you can adjust the various setting listed
below as follows:

This feature is designed to customize Digital Caption
only.

Select “Setup ⇒ Closed Caption”, then press ▶ or

1

ENTER.
Press ◀ or ▶ to set “CC Setting” to “CC On” or

2

“CC on Muting”.
Press ▲ or ▼ to select “Digital Caption Style”,

3

then press ▶ or ENTER.
Press ◀ or ▶ to set the “Digital CC Preset” to

4

“Custom”.
Press ▲ or ▼ to select the desired item, then

5

press ◀ or ▶ to change the setting.

Sound Time Setup Lock

Picture Channel

Digital CC Preset Default

Font Style

Font Size

Font Edge Style

Font Edge Color

FG Color

BG Color

FG Opacity

BG Opacity

You can select from among the following items
and parameters.

Font Style:

Select display font style.

Font Size:

Select display font size.

Font Edge Style:

Select display font edge style.

Font Edge Color:

Select display font edge color.

FG Color:

Select foreground color.

BG Color:

Select background color.

FG Opacity:

Select foreground opacity level.

BG Opacity:

Select background opacity level.

NOTE:

You cannot set both “FG Color” and “BG Color” as a

•
same color.
You cannot set both “FG Opacity” and “BG Opacity”

•
to “Transparent”.

Default

Default

Default

Default

Default

Default

Default

Default

EN 24

Setting the picture size

You can change to a variety of picture sizes—
Natural, Full, Zoom, Cinema, Native
(For PC mode only).

Selecting the picture size

Select “Picture ⇒

1

Size

”.

Press

2

◀ or ▶

described below.

NOTE:

Selectable picture sizes may vary depending on the

•
input source or broadcast signal.
You can be select desired size of picture by

•
pressing SCREEN SIZE on the remote control.

Natural

In some cases, this image will display the size of
standard 4:3 with a black side bar.

Full

Full will display the picture at the maximum size.

Zoom (for letter box programs with
subtitles)

To fill the width of the screen, it is extended
horizontally. However; it is only slightly extended at the
top and the bottom.

The top and bottom edges of the picture may be hidden.

Advanced Settings ⇒ Picture

to select the desired picture size, as

Native (for PC mode only)

Detects the resolution of the signal of the image and it
will be shown on the screen with same amount of pixels.

Media Playback

You can enjoy viewing pictures and movies from
your USB storage device.

Connect the USB storage device into the USB

1

Input terminal.
Press INPUT SELECT then press

2

“Media”, then press ENTER.

NOTE:

•

Do not disconnect a USB storage device while it is
being accessed. Doing so can damage the device
or the files stored on the device. You can safely
connect or disconnect the USB storage device
when the TV is not in media mode.

•

Back up all the data in the USB storage device in
case if data was lost due to unexpected accident.
We do not assume any liability for the losses by
misuse or malfunction.

•

Not all USB storage devices are compatible with
this TV.

•

The character that exceeds the display area is not
displayed.

•

Do not use USB extension cable.

•

Playable files are JPEG (.jpg/.jpeg) and Motion
JPEG (.avi (MJPEG format)).

Media Browser

Media Selection

▲ or ▼

to select

A B C D E F G - - - - - - - - -

A B C D E F G - - - - - - - - -

Cinema (for letter box programs)

The entire picture is uniformly enlarged—it is
stretched the same amount both wider and taller
(retains its original proportion).

The top and bottom edges of the picture may be hidden.

Movie


File Selection

C:\ 1 / 1

Return Up Folder Folder 1 Photo1.mpg

Photo2.jpg Photo3.jpg Photo4.jpg Photo5.mpg


Photo6.jpg Photo7.jpg Photo8.jpg Photo9.jpg

Resolution:

1920 x 1080

Size:

2000Kbytes

Date:

---- / -- / --

Time:

--: -- : --

Information window

NOTE:

The content will change in accordance with each

•
media setting screen.

25 EN

Playback files

Press

◀ or ▶

1

Selection and press ENTER.

Press ◀ or ▶ to select “C”, then press ENTER.

2

Select folder or file with ▲/▼/◀/▶, and then start

3

the playback with ENTER.

You can playback the files with the following remote
control buttons.

Button Action

ENTER

▌▌

▶

■

¡

1

Details of operation commands

Icon Operation

▐▐

▶

■

to select Photo or Movie

Press to start the playback.
Press to open the folder.
Press to open the operation window.

Press to pause the playback.

Press to start the playback or slideshow.

Press to stop the playback.

During the playback, press to select the next
file.

During the playback, press to select the
previous file.

During the playback, press to select search
forward.

During the playback, press to select search
backward.

Play / Resume playback.
Pause.

Skip file to reverse / forward direction.

Stop.
Repeat playback.

Press ENTER repeatedly to select desired
repeat option.

Show the playlist.
Press ▲ or ▼ and ENTER to select the playback

Show the file information.

Rotate the image.

Zoom in / out.

Move the frame from the center position.

Review / Fast playback.
Select start point, then select end point.

Repeat material between two selected points.
Slow-motion Playback.
One frame is advanced each time select this

command.
Direct jump by desired time.

at Media

EN 26
