Jaguar XJ, X-TYPE Handbook
2004.5MY In-car Telephone Handbook
In-car Telephone Handbook
Foreword
JAGUAR CARS LIMITED, as manufacturer, is
dedicated to the design and production of vehicles which meet
the expectations of the world’s most discerning purchasers.
This handbook forms part of the owner literature supplied with
your vehicle. It is designed to complement the relevant features
and systems of the vehicle, and make them easy to understand
and operate.
The information contained in this handbook applies to a range
of vehicles and not to a specific vehicle. For the specification of
a particular vehicle, owners should consult their Jaguar Dealer.
The manufacturer reserves the right to vary its specifications
with or without notice, and at such times and in such manner as
it thinks fit. Major as well as minor changes may be involved in
accordance with the Manufacturer’s policy of constant product
improvement.
Published December 2003 by Technical Support and Communications Jaguar Cars Limited Publication Part No. JJM 10 31 26/45
To cover changes, it is sometimes necessary to issue one or
more handbook supplements. When reading this handbook,
check the owner literature for possible supplements.
For full details of the owner literature originally supplied with
the vehicle, owners should consult their Jaguar Dealer.
All rights reserved. No part of this publication may be
reproduced, stored in a retrieval system or transmitted, in any
form, electronic, mechanical, photocopying, recording or other
means without prior written permission from the Service
Division of Jaguar Cars Limited.
Contents
1. Introduction
Voice Activation (where fitted) . . . . . . . . . . . . . . . . . . 1- 2
Understanding the Manual. . . . . . . . . . . . . . . . . . . . . 1- 2
2. Safety
Exposure to Radio Frequency Signals . . . . . . . . . . . . . 2-1
Antenna Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2- 1
Phone Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2- 1
Driving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Electronic Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . 2- 1
Pacemakers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Other Medical Devices. . . . . . . . . . . . . . . . . . . . . . . . 2- 2
Vehicles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2- 2
Posted Facilities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
Blasting Areas. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
Potentially Explosive Atmospheres . . . . . . . . . . . . . . . 2- 2
For Vehicles Equipped with an Airbag . . . . . . . . . . . . 2-2
3. Handset – General Information
To Remove or Install the Handset. . . . . . . . . . . . . . . . 3- 1
SIM Card Insertion and Removal . . . . . . . . . . . . . . . . 3-1
Electronic Lock Feature . . . . . . . . . . . . . . . . . . . . . . . 3-2
Volume Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
The Start/Stop Record Button . . . . . . . . . . . . . . . . . . . 3- 2
Special Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
The Smart Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3
The Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3
Looking After Your Phone. . . . . . . . . . . . . . . . . . . . . . 3-4
Your SIM Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
4. Handsfree Controls
Audio Panel Controls . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
Steering Wheel Controls. . . . . . . . . . . . . . . . . . . . . . . 4 - 2
Audio Panel Control Functions. . . . . . . . . . . . . . . . . . 4 - 3
The Manufacturer reserves the right to make changes in technical and product specifications without prior notice.
Contents
5. Handsfree Operation
Receiving a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
Making a Call. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
Phone Operation Multizone Voice. . . . . . . . . . . . . . . 5-3
Touch-screen Controls. . . . . . . . . . . . . . . . . . . . . . . . 5 - 4
Touch-screen Operation . . . . . . . . . . . . . . . . . . . . . . 5 - 5
Text Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-8
Phone Operation Multizone Voice (Touch-control) . . 5- 9
Additional Information . . . . . . . . . . . . . . . . . . . . . . 5-10
6. Handset Introduction
Menu Navigation. . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
7. Handset Operation
Making and Receiving Calls . . . . . . . . . . . . . . . . . . . . 7 - 1
Making a Phone Call . . . . . . . . . . . . . . . . . . . . . . . . . 7-2
Receiving a Phone Call . . . . . . . . . . . . . . . . . . . . . . . 7-4
In-Call Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7- 4
Call Holding and Call Waiting . . . . . . . . . . . . . . . . . . 7-6
Making a Conference Call . . . . . . . . . . . . . . . . . . . . . 7 - 8
Transfer Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-9
8. Handset Voice Features
Using VoiceNotes™ . . . . . . . . . . . . . . . . . . . . . . . . . . 8-1
Using Voice Activation. . . . . . . . . . . . . . . . . . . . . . . . 8-2
9. Handset Options Menu
What is the Phone Book? . . . . . . . . . . . . . . . . . . . . . . 9-1
Call Related Features Menu . . . . . . . . . . . . . . . . . . . . 9-8
Messages Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-12
Phone Setup Menu . . . . . . . . . . . . . . . . . . . . . . . . . 9-16
Network Selection Menu . . . . . . . . . . . . . . . . . . . . . 9 - 21
Call Meters Menu . . . . . . . . . . . . . . . . . . . . . . . . . . 9-24
Accessory Setup Menu. . . . . . . . . . . . . . . . . . . . . . . 9 - 26
10. Handset Quick Access Menu
Using the Quick Access Menu . . . . . . . . . . . . . . . . . 10-1
Customising the Quick Access Menu . . . . . . . . . . . . 10-3
11. Troubleshooting
A comprehensive index is located at the back of this handbook.
The Manufacturer reserves the right to make changes in technical and product specifications without prior notice.
1 Introduction
Introduction 1-1
Introduction
The in-car telephone can be used as a
handsfree system or as a conventional
corded handset.
Powered by the vehicle electrical system,
the phone is a dual-band system capable
of maintaining high quality performance
in fringe and heavily congested network
areas.
Handsfree system
For handsfree operation the handset must
be correctly installed in the cradle in the
centre console storage compartment.
Interfacing with an overhead, directional
microphone and the audio system
speakers, the phone can then be
operated via the keypad and phone
buttons on the audio panel, navigation
screen and/or the steering wheel
switches.
Note: When installed in the cradle,
the handset controls may be used if
preferred. For further information see To
Remove or Install the Handset on
page 3- 1.
Conditions for handsfree operation
Whilst your Jaguar Dealer will have
ensured that the phone is correctly set up
for handsfree operation, the following
pre-requisites must be satisfied:
• The phone must be connected to a
GSM network and unlocked.
• Mute car radio on the handset menu
must be set to on (Jaguar phones are
preset to default to this setting).
• The handset must be correctly
installed in the cradle.
• The vehicle ignition switch must be in
position I (auxiliary) or II (ignition).
Note: The radio, cassette tape or CD
player can be OFF or ON.
If you require further guidance,
see Chapter 5: Handsfree Operation,
or consult your Jaguar Dealer.
Handset
The handset which is specifically
designed for in-car use, is permanently
connected to the vehicle audio and
electrical systems. For further details on
operation of the handset, see To
Remove or Install the Handset on
page 3-1 and Chapter 7: Handset
Operation.
Handsfree volume
In handsfree mode, the volume can be
adjusted independently for phone
operation. To adjust, operate the ON/
OFF volume control while the phone
system is in a call.
If the audio system is in use when the
phone becomes active, the audio system
source is suppressed for the duration of
the call.
Audio panel display
Phone related messages are shown on the
audio panel display when the phone
system is active.
1-2 Introduction
Voice Activation (where fitted)
The in-car telephone system can be used
in conjunction with the Voice Activation
System to provide the driver with
completely hands-free communication.
Voice commands are picked up by the
same roof-mounted directional
microphone that serves the hands-free
phone system.
For the recommended techniques and
general procedures to adopt when using
the Voice Activation system, refer to the
JaguarVoice chapter in the Audio Systems
and JaguarVoice Handbook or Touchscreen and JaguarVoice handbook where
applicable.
Note: The Voice Activation system must
not be used to call emergency numbers,
as voice patterns can change under stress,
resulting in commands becoming
unrecognisable.
Understanding the Manual
Many of your phone options are accessed
by a simple menu system.
A full description of the menus and how
to move around them is covered under
the heading Menu Navigation on
page 6-1.
When the manual describes the use of
each menu item, it will be assumed that
you are familiar with the menu system.
Key presses
Key presses are represented in this
manual using symbols so that you may
locate and use the required sequence
quickly. A sequence of key presses may
be shown as follows:
This means that you should press the
key followed by the key and
then the key, in sequence,
not simultaneously.
Entering information
When you are requested to enter
information, such as the number of the
phone you wish to call, this is
represented in bold type. For example:
Phone No. Enter the required
telephone number.
PIN Code Enter your Personal
Identification Number.
Unlock Code Enter your unlock code.
Location Enter the Phone Book
location number
Prompts and messages
Your phone responds to key presses by
displaying either easy to understand
prompts that guide you to the next
action, or simple messages confirming
that your action is complete. Prompts and
messages are represented in this manual
in Bold.
Other symbols
Take particular note of the following
symbols used throughout this manual:
Note: A Note contains additional
information which is relevant to the
feature/item.
Caution: A Caution contains
important additional information
which is relevant to the efficient and/
or safe usage of your phone.
This symbol indicates that the
feature is a Personality™ feature that can
be customised to meet your
requirements.
This symbol indicates a short key
sequence for the feature.
2Safety
Safety 2-1
!
WARNING:
Read this information before using
your in-car telephone system.
Exposure to Radio Frequency
Signals
Your fixed telephone is a low power radio
transmitter and receiver. When it is
switched ON, it receives and sends out
radio frequency (RF) signals.
International authorities have set
standards and recommendations for
protection of the public from exposure
to RF electromagnetic energy.
Your telephone is designed to satisfy all
international requirements when used as
described in this handbook.
Antenna Care
Only approved Jaguar antennae should
be installed on the vehicle. The use of
unauthorized antennae can damage the
phone and may violate local authority
regulations.
Phone Operation
Do not operate your fixed telephone
when a person is within 10 centimetres
(4 inches) of the antenna.
A person positioned within this range of
the antenna can adversely affect phone
performance and may cause the phone to
operate at abnormally high power levels
exposing that person to excessive
RF energy levels.
Driving
Check local regulations on the use of
fixed telephones in the areas where you
drive and always obey them. Observe the
following guidelines when using your
phone while driving:
• Give full attention to driving – safe
driving is your first responsibility.
• Always use handsfree operation when
driving.
• When receiving a call, if driving
conditions demand, pull off the road
and park.
Electronic Devices
Most modern electronic equipment is
shielded from RF signals.
However, certain equipment may not be
shielded against the RF signals from your
fixed telephone.
Pacemakers
The Health Industry Manufacturers
Association recommends that a minimum
separation of 15 centimetres (6 inches) is
maintained between a wireless phone
antenna and a pacemaker to avoid
potential interference with the
pacemaker. These recommendations are
consistent with the independent research
by and recommendations of Wireless
Technology Research.
Persons with pacemakers should:
• Preferably use the vehicle handsfree
phone system.
• ALWAYS keep the phone more than
15 centimetres (6 inches) from their
pacemaker when the phone is
switched ON.
• Turn the phone OFF immediately if
there is any reason to suspect that
interference is taking place.
2-2 Safety
Other Medical Devices
If you use any other personal medical
device, consult the manufacturer of your
device, or your doctor, to determine that
it is adequately shielded from external
RF energy.
Turn your phone OFF in health care
facilities when any regulations posted in
such areas instruct you to do so.
Hospitals or health care facilities may be
using equipment that could be sensitive
to external RF energy.
Vehicles
RF signals may affect non-Jaguar or
improperly installed equipment.
Always consult the manufacturer of any
equipment that has been retro-fitted to
your vehicle.
Posted Facilities
Turn your phone OFF in any facility
where posted notices so require.
Blasting Areas
To avoid interfering with blasting
operations, turn your phone OFF when in
a blasting area or in areas posted: ‘Turn
off two-way radios.’ Obey all signs and
instructions.
Potentially Explosive
Atmospheres
Areas with a potentially explosive
atmosphere are often but not always
clearly marked. Turn your phone OFF
when you are in such an area, as the use
of unapproved electrical equipment can
cause an explosion or fire resulting in
bodily injury or death.
For Vehicles Equipped with an
Airbag
Airbags inflate with great force. Do NOT
place objects, including both installed or
portable wireless equipment, in the area
over an airbag or in the airbag
deployment area. If in-vehicle wireless
equipment is improperly installed and the
airbag inflates, serious injury could result.
3 Handset – General Information
Handset – General Information 3-1
Note: Upon replacing the handset
handsfree control will default to the front.
Caution: To ensure a call has been
terminated press the end call button
in the vehicle as some calls to land
lines will not be terminated by
hanging up at the land line end alone.
SIM Card Insertion and
Removal
The phone is supplied with a Subscriber
Identity Module (SIM) card.
To Remove or Install the
Handset
To remove the handset, slide it forward to
release it from the rear of the cradle, then
lift the rear of the handset, slide it
rearward and remove it from the cradle.
To install the handset, locate the top in
the front of the cradle, slide it forward
and finally position it in the cradle by
lightly pressing downward until it fully
engages in the cradle.
Note: When changing to handsfree mode
during a call, the handset must be muted
before it is returned to the cradle.
For more information please refer
to pages 7- 4 and 10-2.
Removing the SIM card
1. Switch off the handset by pressing and
holding the key.
2. Withdraw the SIM card holder (B)
from the left-hand side of the handset.
3. Remove the SIM card (A) from holder.
Inserting the SIM card
1. Ensure that the handset is switched
off.
2. Ensuring the notched corner is
positioned top left, place the
SIM card (A) in the holder (B).
3. Push the holder into place so that it is
flush with the side of the handset.
Note: If the SIM card is damaged or
inserted incorrectly, Check Card will be
displayed. In this event, remove the card,
check that it is the right way round, then
re-insert it into the handset.
If Bad Card See Supplier or Blocked
See Supplier is displayed, contact your
Cellular Service Provider.
3-2 Handset – General Information
Electronic Lock Feature
For details of the electronic phone lock
facility, see Phone Lock on page 9- 17.
Note: When the electronic phone lock
has been selected, the unlock code is lost
when the engine is started (unless the
5-minute safety time has been enabled).
This renders the phone inoperable until
the code is entered again.
If the phone is locked, the handset
display will show Locked on entering
phone mode.
To unlock the phone, enter the unlock
code using the handset keypad.
Volume Button
The Volume button is on the front of
your phone, under the display.
The button is used for adjusting the
keypad and ringer volume.
A volume meter will display the current
volume setting. The meter will disappear
after a short time, or if you press
or .
• To adjust the keypad volume, press
the button with no other features
selected.
• To adjust the ringer volume, first
select the ‘Adjust Ring Volume’ option
in the Phone Setup Menu and then
use the button to set the required
volume.
The volume button can also be used to
scroll through the Phone Book entries
after pressing the Smart button.
The volume button is also used to scroll
through menu items after pressing the
Menu button.
Note: If you receive a call and you do not
want to answer it immediately, you can
press the volume button to stop the phone
from ringing. This will not answer the call.
The Start/Stop Record Button
The Start/Stop Record button is on the
bottom right of your phone above
the Power button. Press it to start and
stop recording VoiceNotes™. Refer
to Using VoiceNotes™ on page 8- 1 for
more information.
Special Keys
Turns the phone on and off.
Accept call, setting or option.
Reject call, setting or option.
Enter the Quick Access menu.
Press to access Options &
phone book menus.
Scroll left or right.
Scroll up and down.
Access voice annotator or
voice notes
Press to call voice mail.
Note: The shape of the keys that appear
in the manu al may vary slightl y from thos e
on the phone.
Handset – General Information 3-3
The Smart Button
The Smart button is on the left-hand
side of your phone, below the Clear
button. Press it to quickly access all your
Phone Book entries, and then either
scroll through the entries using the
volume button or press one of the
alphanumeric keys to search for a specific
name – for example, press to search
for the name Pam, or press four
times to search for the name Sam.
Note: If a Phone Book entry does not
have a name, it will not be displayed.
The Display
The display on your phone can show
alphanumeric characters as well as useful
information symbols. The various
elements of the display are as follows:
ABC123 (LCD display shown in bold)
Characters are used to display messages
and telephone numbers.
In Use. Displayed when a call is in
progress.
Roam. Displayed when you are
registered on a system other than your
home system.
Home Zone. Availability depends
on your service provider.
Short Message Service. Displayed
when the phone has received a message.
The symbol will flash when your message
storage area is full.
Voicemail Waiting Indicator.
Displayed when you have a voice
message waiting. The availability of this
feature depends on your service provider.
Ringer On. Displayed when the call
ringer is selected. If you select the No
Ring option this symbol will not be
displayed.
… Icons are displayed when you
are in the Quick Access menu.
Indicates that a menu item is
currently selected.
In addition, when you are expected to
press the key, a prompt will appear
in the display, for example Completed.
Low temperature use
The liquid crystal display used in your
phone will behave differently at
extremely low temperatures. You may
notice that the display responds slowly to
key presses; this is to be expected and
does not affect the phone operation in
any way.
3-4 Handset – General Information
Looking After Your Phone
• Never leave your phone in extreme
temperatures (over 60°C – 140°F),
for example behind glass in very hot,
direct sunlight.
• To clean your phone, use a moistened
or antistatic cloth. Do not use a dry
or electrostatically charged cloth.
Your SIM Card
You will not be able to make or receive
calls if you do not have a SIM card
inserted in your phone.
The SIM card is a ‘Smart Card’ that
contains your phone number, service
details and memory for storing Phone
Book numbers and messages.
You can therefore use your SIM card in
someone else’s GSM phone and you will
be charged for the call.
Like a bank or credit card, you should
keep your SIM card secure. Do not bend
or scratch your card and avoid exposure
to static electricity or water.
Caution: Switch off your phone
before inserting or removing the
SIM card. Failure to do so may
damage the memory on your
SIM card.
SIM/Phone number memory
The stored number memory is divided
into two parts, one on your SIM card, and
one in the phone.
The number capacity of your SIM card
is 99. Therefore if you transfer your SIM
to/from another phone you will only have
access to the first 99 stored number
positions.
4 Handsfree Controls
Audio Panel Controls
1. ON/OFF switch and volume control.
2. Phone send/end calls.
3. Phone mode button.
4. Phone memory recall button.
5. Cancel/correct telephone numbers.
6. Display.
7. Phone keypad – buttons 0 to 9
(except where touch-screen is fitted –
seepage5-4).
8. Scroll memory location.
The telephone can be operated either
direct from the handset in the
conventional manner, or in hands-free
mode using the audio panel keypad or
steering wheel mounted control buttons,
and an overhead microphone.
Display messages
Messages that may be displayed:
Call – There is an incoming call.
Calling – A call is being established.
Empty – Memory location is empty.
Insert Sim – SIM card missing or
incorrectly installed.
Location – Memory location number or
prompt for memory location number.
No Service – No cellular service
available.
Phone – System entering phone mode.
Pin – PIN required – enter the PIN on the
sound system keypad. Press button
to enter PIN.
Please Wait – phone book
information loading – A short delay
will be experienced whilst information is
transferred from the SIM card.
Handsfree Controls 4-1
Puk Required – SIM card is barred from
use. Contact your service provider.
Roam – Phone connected to different
network from ‘home’ system.
Sig – Indication of signal strength.
Note: Messages on the audio panel
display may not be in the same language
as the messages on the phone display.
4-2 Handsfree Controls
Steering Wheel Controls
The XJ and S-TYPE only
Four system control switches are situated
on the left-hand side of the steering
wheel, duplicating the functions of
buttons on the audio panel, these provide
finger-tip control of audio, telephone and
voice activation systems whilst driving.
Steering Wheel Controls
X-TYPE only
Note: Switches illustrated as 2 and 4 are:
• The XJ and S-TYPE – rocker switches.
• X-TYPE – part rotating switches which
self centre when released.
1. Press to start voice session, or mute
when voice is not fitted.
Answer phone call when ringing.
Send/End when in phone mode.
2. Press/rotate as required to increase or
decrease volume.
3. Press and hold for 2 seconds to select
Phone Ready mode. Press and release
to cycle through Radio FM, AM
Cassette, CD or MD and CD Changer.
4. In phone mode main screen, press/
rotate to scroll up or down through
the numbers stored in the phone
memory. In audio mode will scroll
through radio preset stations, the next
CD/MD track or tape AMS (automatic
music search). Press/rotate and hold
for at least two seconds to cycle to
next strong station, next CD or change
tape side.
Audio Panel Control Functions
Volume control and fader mode
Phone volume can be adjusted from the
audio panel volume control or the
steering wheel switches and the volume
set is memorised for future calls (this will
not alter the other audio volume settings).
To adjust: During a phone call,
press MODE on the audio panel
repeatedly until Fade is displayed.
Using the volume control knob or the
steering wheel button, set fade to
personal preference.
Phone mode
This button will activate the phone mode,
ready to make a call and the display will
indicate that phone mode has been
selected.
This function can also be controlled from
the steering wheel (press and hold
button 3 shown on the preceeding page).
Keypad
Press digits to enter the required
telephone number. Each key press will
beep and the digits are displayed on the
audio panel.
The keypad can also be used in Memory
Recall (MR), to enter a location number,
or to scroll up/down the memory
locations.
Cancel
Press and release CANCEL to clear the
last digit of a telephone number.
Press and hold to clear all digits entered.
Handsfree Controls 4-3
Send/end
Press this button to send the entered
telephone number. Also used to end a
call that is in progress.
This function can also be controlled from
the steering wheel by using button 1
shown on the preceding page.
Memory recall
Press to access the phone memory and
recall a number. Either a memory
location number can be entered from the
keypad, or memory locations can be
scrolled up and down from the keypad
scroll keys.
Note: Memory locations can only be
scrolled numerically.
This function can also be controlled from
steering wheel button 4 shown on
page 4-2. Press the upper or lower part
of the control to seek up or down through
the numbers stored in the phone
memory.
Last number redial may also be activated
by pressing and holding the MR button.
5 Handsfree Operation
Handsfree Operation 5-1
Receiving a Call
An incoming call automatically switches
the sound system into the phone mode.
The audio panel display will show Call
and ringing is heard through the sound
system.
If automatic answer has been
programmed the call will automatically
answer after two rings.
1. To answer:
Press the switch on the steering
wheel or press on the audio
panel.
The display shows Sig or Roam.
2. To end:
Press the switch on the steering
wheel or press on the audio
panel.
Receiving a call with ‘Call Line Ident’
If the caller has the ‘Call Line
Identity’ (CLI) feature, Call is shown on
the audio panel display followed by the
caller’s phone number and name when
available. The display of lengthy names
may be truncated by screen-size
limitation.
Making a Call
When making a call, there are four
methods of dialling:
Keypad, Turbo, memory search and last
number redial.
Keypad dialling
1. To dial:
Press and hold the switch on the
steering wheel or press on the
audio panel.
Phone is displayed for two seconds
followed by Sig or Roam.
2. Key in the phone number on the audio
panel keypad. The number will be
displayed.
3. To connect:
Press the switch on the steering
wheel or press on the audio
panel.
The display will show Calling.
When the call is connected the
display will show Sig or Roam.
4. To end:
Press the switch on the steering
wheel or press on the audio
panel.
Turbo dialling
Note: Turbo dialling selects the first nine
locations stored in the SIM card memory.
1. To dial:
Press and hold the switch on the
steering wheel or press on the
audio panel.
Phone is displayed for two seconds
followed by Sig or Roam.
2. On the audio panel keypad, press and
hold the required turbo dialling
memory location number 1 to 9,
which corresponds with
locations 1 to 9 on the
SIM memory.
After three seconds Calling will be
displayed.
3. To end:
Press the switch on the steering
wheel or press on the audio
panel.
5-2 Handsfree Operation
Memory recall dialling (audio panel
buttons only)
1. To dial:
Press on the audio panel.
Phone will be displayed for two
seconds followed by Sig or Roam.
2. Press the MR button.
Location will be displayed.
3. On the audio panel keypad, press the
required memory number 1 to 255
(depending on SIM card) or:
Press the button (for memory
recall location 1) or the button
(for the highest stored location
number), then repeatedly press either
button to scroll through until you
reach the location number you
require.
Note: You can key in any number
between 1 and 255 then use the
arrow keys to scroll up and down.
The memory location name is
displayed followed by the location
phone number.
4. To connect:
Press the switch on the steering
wheel or the switch on the audio
panel.
Calling will be displayed followed
by Sig or Roam when the call is
connected.
5. To end:
Press the switch on the steering
wheel, or the switch on the
audio panel.
Memory recall dialling (steering wheel
switches only)
1. To dial:
Press and hold the Select switch.
Phone will be displayed for two
seconds followed by Sig or Roam.
2. On the audio panel keypad, press the
required memory number 1 to 255
(depending on SIM card) or:
Press the button (for memory
recall location 1) or the button
(for the highest stored location
number), then repeatedly press either
button to scroll through until you
reach the location number you
require.
Note: You can key in any number
between 1 and 255 then use the
arrow keys to scroll up and down.
The memory location name is
displayed followed by the location
phone number.
3. To connect:
Press the switch on the steering
wheel or press on the audio
panel.
Calling is displayed followed by Sig
or Roam when the call is connected.
4. To end:
Press the switch on the steering
wheel or press on the audio
panel.
Handsfree Operation 5-3
Last number redial
Note: Last number redial recalls the
phone number of the last call made since
the ignition was switched on.
When the ignition is switched off, the last
number called may be lost from the
system memory.
1. To dial:
Press the switch on the steering
wheel or press on the audio
panel.
Phone will be displayed for two
seconds followed by Sig or Roam.
2. On the audio panel, press and hold
the MR button. The display will show
the last number called.
Note: If the last number was dialled
using keypad dialling, you can change
the number by pressing the Cancel
button.
3. To connect:
Press the switch on the steering
wheel or press the switch on the
audio panel.
Calling will be displayed followed
by Sig or Roam when the call is
connected.
4. To end:
Press the switch on the steering
wheel or press on the audio
panel.
Phone Operation Multizone
Voice
The XJ only (if fitted)
To transfer phone control from rear to
front when not on a call, press once.
The display will show Phone In Use,
press a second time and the display
will show Phone then Sig.
The rear system is now out of phone
mode and the front occupants have full
handsfree control.
To transfer phone control during a call
press the button. This will be
necessary to send DTMF tones, to use the
telephone scratchpad feature, or to end
the call from the front.
See System Operation – Telephone
(Rear Multimedia Handbook) for
detailed operation.
5-4 Handsfree Operation
Touch-screen Controls
On vehicles fitted with the Navigation
System, the audio panel keyboard is
replaced by touch-screen controls.
Conventional handset and steering wheel
button operation of the phone as
described in the preceding pages are
retained.
With the ignition switch in position I or II
pressing the Phone button on the left of
the screen will display the screen controls
shown top right. The Power On touchcontrol should be pressed to switch on
the telephone. The telephone can also be
switched on at the handset
(see Chapter 3).
Note: Normally the phone will be on
when in position I or II.
The above screen will then be shown.
The message bar at the top of the screen
will provide information on the
telephone’s status. The display will
show Ready if the phone is correctly
connected or No Phone if the phone is
not properly connected. Handset In Use
will be displayed if the handset has not
been correctly returned to the cradle.
Phone Book Not Ready will be
displayed whilst the information on your
SIM card is transferred to the telephone’s
memory. Depending on the amount of
information stored on your SIM card this
may take 20 – 60 seconds to complete.
Touch-screen Operation
Making a call
Handsfree Operation 5-5
Receiving a call
The screen will display Calling when
establishing a call. On connection,
Connected is displayed and the lower
telephone icon is illuminated.
If the ignition is switched off, the call will
be maintained and the screen can be
manually turned off. Calls are terminated
by use of the lower telephone icon touchcontrol.
Calls are made by using the digit and
touch-controls, or the memory
functions described on page 5-6.
Erroneous digits can be deleted by use of
the touch-control.
The number called is displayed at the top
of the screen and signal strength is
displayed in bars on the right.
When the phone registers to a network
other than the home network, the signal
strength icon is accompanied
by Roaming.
On receipt of a call, the screen will
display Incoming Call regardless of the
audio system operating mode.
This is accompanied by Accept
and Cancel touch-controls enabling the
user to answer the call or cancel it.
5-6 Handsfree Operation
Using the menu
Use of the Menu touch-control will
display the above screen, providing
access to memory functions, last number
redial and Text Messages (Short Message
Service).
When the vehicle is in motion it will not
be possible to use the Name and Text
Messages touch-controls.
Last number
The Last Number Redial memory
function enables the user to quickly recall
the previously used number.
Use of this touch-control automatically
calls the previous number and reverts to
the standard phone display, with the call
timer and control activated.
Use of the List touch-control will display
the last ten numbers dialled.
Note: Last number redial recalls the last
ten numbers called since the ignition
switch was turned to position I or II.
The last number redial list may be lost
each time the ignition is switched off.
Location number
The Location Number screen enables
the user to search the phone memory by
location.
Upon pressing the location number
touch-control, a location number is
requested. A list of locations is then
displayed as above (dependent upon
those stored in the memory). The desired
location may then be dialled by touching
the location number.
When the vehicle is in motion the ‘scroll’
touch-controls at the right hand side of
the screen will be partially inhibited for
safety.
Handsfree Operation 5-7
Name entry
On the phone menu select Name,
then with the alphabetical keyboard
above displayed, select the required
alphabetical group to narrow your search,
and then scroll through the list.
List by name
With the memory list displayed as above,
locate the required name by scrolling
using the arrowed buttons, then touch
the desired list number to make the call.
Use the touch-control to terminate
the call.
5-8 Handsfree Operation
Text Messages
Text message display
Producing a message
Sending a message
This service is initially accessed by
selecting Text Messages in the phone
menu display. The above screen is then
displayed, enabling short text messages to
be sent, received and viewed as follows:
Note: The Text Message function
cannot be used whilst the vehicle is in
motion.
Selection of the Write New Message
touch-control will present the above
display.
Using the touch-keys, enter the required
message in the upper window and
select .
Using the touch-keys, enter the
destination telephone number or press
search to dial from a memory location
number (see Location Number/Name
search.
Select Send, after a short delay the
display will show TEXT Message Sent on
the screen, as above.
Handsfree Operation 5-9
Viewing a message
On the main TEXT MESSAGES display
shown above, received messages may be
viewed by selecting the View All
Messages touch-control.
Viewing messages
On selection of the adjacent View All
Messages touch-control, ALL TEXT
MESSAGES received are displayed on the
screen shown above. Unread messages
are identified by a red dot in the left hand
column. Read messages are identified by
a blank box in the left hand column.
Arrowed touch-controls on the right
provide for ‘scrolling’ forwards and
backwards through the list of messages.
Cancel will return the screen to the main
text message display.
Note: Messages cannot be viewed whilst
the vehicle is in motion.
Phone Operation Multizone
Voice (Touch-control)
The XJ only (if fitted)
To transfer phone control from rear to
front when not on a call, press once.
The display will show Phone In Use,
press a second time and the display
will show the screen below:
The rear system is now out of phone
mode and the front occupants have full
handsfree control.
To transfer phone control during a call
press the button. This will be
necessary to send DTMF tones, to use the
telephone scratchpad feature, or to end
the call from the front.
See System Operation – Telephone
(Rear Multimedia Handbook) for
detailed operation.
Loading...
