Intel MI910, MI910F User Manual

MI910/MI910F
Intel ® CoreTM 2 Duo/
Mini-ITX Motherboard
USER’S MANUAL
Version 1.0
Acknowledgments
Award is a registered trademark of Award Software International, Inc. PS/2 is a trademark of International Business Machines Corporation. Intel and Intel® Core 2 Duo and Intel® Celeron processors are registered trademarks of Intel Corporation. Microsoft Windows is a registered trademark of Microsoft Corporation. Winbond is a registered trademark of Winbond Electronics Corporation. All other product names or trademarks are properties of their respective owners.
ii MI910 User’s Manual
Table of Contents
Introduction.......................................................1
Product Description.............................................................1
Checklist..............................................................................2
MI910 Specifications ..........................................................3
Board Dimensions...............................................................4
Installations.......................................................5
Installing the CPU...............................................................6
Installing the Memory.........................................................7
Setting the Jumpers .............................................................8
Connectors on MI910........................................................11
BIOS Setup.......................................................27
Drivers Installation......................................49
Intel Chipset Software Installation Utility.........................50
VGA Drivers Installation ..................................................52
AC97 Codec Audio Driver Installation.............................54
LAN Drivers Installation...................................................55
Appendix...........................................................57
A. I/O Port Address Map...................................................57
B. Interrupt Request Lines (IRQ)......................................58
C. Watchdog Timer Configuration....................................59
MI910 User’s Manual iii
IMPORTANT NOTE: When the system boots without the CRT being connected, there will be no image on screen when you insert the CRT/VGA cable. To show the image on screen, the hotkey must be pressed (CTRL-ALT-F1).
THE MI910 MINI ITX MOTHERBOARD
iv MI910 User’s Manual
INTRODUCTION
Introduction
Product Description
The MI910 Mini ITX board incorporates the Mobile Intel® GM965 Express Chipset for Embedded Computing, consisting of the Intel® GM965 Graphic Memory Controller Hub (GMCH) and Intel® I/O Controller Hub (ICH8-M), an optimized integrated graphics solution with a 533MHz and 800MHz front-side bus. Dimensions of the board are 170mm x 170mm.
The integrated powerful 3D graphics engine, based on Intel® Graphics Media Accelerator X3100 (Intel® GMA X3100) architecture, operates at core speeds of up to 400 MHz. It features a low-power design, is validated with the Intel® Core 2 Duo and Intel® Celeron processors on 65nm process. With dual channel DDR2 667MHz two DIMM socket on board, the board supports up to 4GB of DDR2 system memory.
Intel® Graphics supports a unique intelligent memory management scheme called Dynamic Video Memory Technology (DVMT). DVMT handles diverse applications by providing the maximum (384MB) availability of system memory for general computer usage, while supplying additional graphics memory when a 3D-intensive application requests it. The Intel GMA X3100 graphics architecture also takes advantage of the high-performance Intel processor. Intel GMA X3100 graphics supports Dual Independent Display technology.
The main features of the board are:
Supports Intel® CoreSupports up to 2.4GHz, 533MHz/800MHz FSB Two DDR2 SDRAM DIMM, Max. 4GB memory Onboard 10/100 BaseT and Marvell PCI-Express Gigabit LAN Intel® GM965 Express VGA for CRT / LVDS 2x SATA, 6x USB 2.0, 2x COM, Watchdog timer, 1394 1x MiniPCI, 1x PCI, 1xPCI-E(x1) slots, optional DVI
Optional daughter cards: ID390: Chrontel 7308, supports 24 bit single or dual LVDS channel ID390C: Chrontel 7021, supports CRT ID391: Chrontel 7307C, single DVI (connector on cable) ID391D: Chrontel 7307C, dual DVI (connector on cable) ID392D: Chrontel 7307C, dual DVI (one connector on card and one on cable) MI910/MI910L only
TM
2 Duo (Merom 800MHz), Intel® Celeron
MI910 User’s Manual 1
INTRODUCTION
Checklist
Your MI910 package should include the items listed below.
The MI910 Mini-ITX motherboard
This User’s Manual
1 CD containing chipset drivers and flash memory utility
Cable kit (IDE, Serial port, Serial ATA)
2 MI910 User’s Manual
MI910 Specifications
INTRODUCTION
CPU Supported CPU Voltage System Speed CPU FSB Cache Green /APM CPU Socket Chipset
BIOS Memory VGA SDVO (Dual CH)
LVDS LCD Panel
LAN
Intel® Core
0.700V ~ 1.5V (IMVP-6) Up to 2.4GHz or above 533MHz/800MHz FSB 1MB/2MB/4MB APM1.2 mPGA Socket 478 Intel GM965 Chipset
GMCH: GM965 1299-pin Micro-FCBGA ICH8M: 82801HBM 678-pin mBGA Award BIOS, support ACPI Function
DDR2 667/533 SDRAM DIMM x2 (w/o ECC function), Max. 4GB GMA965 built-in, supports CRT Through ID390 card (Chrontel 7308, 24+24 bits single/dual channel
LVDS, Chrontel 7021, CRT) Through ID391 card (Chrontel 7307C, DVI single or Dual) GM965 built-in, supports 24+24 bits (Type 1 only), single or dual channel
LVDS
1. ICH8M 10/100/gigabit MAC + PHY (dual footprint option):
2. Marvell 88E8053 PCI-e Gigabit LAN controller x1 (MI910F)
USB Serial ATA Ports 1394 Parallel IDE Audio
LPC I/O
Digital IO Keyboard/Mouse Expansion Slots Edge Connector
Onboard Header/ Connector
Watchdog Timer System Voltage Others Board Size
ICH8M built-in USB 2.0 host controller, support 6 ports ICH8M built-in SATA controller, supports 2 ports TI TSB43LV22(dual port) ICH8M built-in one channel Ultra DMA 33/66/100,CF Type II ICH8M Built-in audio controller + AC97 Codec ALC885 w/ 7.1 channels,
SPDIF-OUT W83627EHF: COM1, COM2 (RS232/RS422/RS485), slim FDC 1.44MB, IrDA x1 & hardware monitor (3 thermal, 4 voltage monitor inputs, 2 fan headers) 4 in & 4 out Supports PS/2 Keyboard/Mouse Connector PCI slot x1, PIC-E (x1) slot x1 and Mini PCI socket x1 PS/2 connector x1 for keyboard/mouse Gbit LAN RJ-45 + dual USB stack connector 10/100 LAN RJ45 + dual USB stack connector DB9 x1 for COM 1; DB15 x1 for VGA SPDIF-OUT connector x1; 1394 connector x1 RCA Jack 3x2 for Audio (Front-Out, Line-In, Mic, Center/LFE, Surround & Surround Back) 40 pins box-header x1 for IDE1; 26 pins header x1 for slim floppy CF Connector x1 @ solder side 10 pins pin-headerx1 for Digital I/O; 10 pins pin-header x1 for COM2 10 pins pin-header x 1 for USB 5,6; 5 pins pin-header x 1 for IrDA DF13 connector x2 for LVDS; 10 pins pin-header x1 for audio Line-Out & Mic 4 pins pin-header x1 for CD in; 7 pins pin-header x1 for 1394 SATA connector x2 for SATA ports Yes (256 segments, 0, 1, 2…255 sec/min) +5V, +3.3V, +12V, -12V, 5VSB (2A) Modem Wakeup, LAN Wakeup 170mm x 170mm (Mini ITX)
Note: MI910L uses GL960 chipset. It supports FSB 533MHz, DDR2
533MHz only.
TM
2 Duo, Intel Celeron mobile processors
Intel 82566DC Nineveh 10/100/1000 (MI910)
Intel 82562V Ekron-N 10/100 (MI910L)
MI910 User’s Manual 3
INTRODUCTION
[
Board Dimensions
4 MI910 User’s Manual
INSTALLATIONS
Installations
This section provides information on how to use the jumpers and connectors on the MI910 in order to set up a workable system. The topics covered are:
Installing the CPU........................................................................ 6
Installing the Memory.................................................................. 7
Setting the Jumpers...................................................................... 8
Connectors on MI910 ................................................................ 11
MI910 User’s Manual 5
INSTALLATIONS
Installing the CPU
The MI910 board supports a Socket 478MN (MEROM) processor socket for Intel® Core The processor socket comes with a screw to secure the processor. As shown in the left picture below, loosen the screw first before inserting the processor. Place the processor into the socket by making sure the notch on the corner of the CPU corresponds with the notch on the inside of the socket. Once the processor has slide into the socket, fasten the screw. Refer to the figures below.
TM
2 Duo, Intel® Celeron mobile processors.
NOTE:
Ensure that the CPU heat sink and the CPU top surface are in total contact to avoid CPU overheating problem that would cause your system to hang or be unstable.
6 MI910 User’s Manual
INSTALLATIONS
Installing the Memory
The Mi910 board supports two DDR2 memory socket for a maximum total memory of 4GB in DDR2 memory type.
Installing and Removing Memory Modules
To install the DDR2 modules, locate the memory slot on the board and perform the following steps:
1. Hold the DDR2 module so that the key of the DDR2 module aligned with that on the memory slot.
2. Gently push the DDR2 module in an upright position until the clips of the slot close to hold the DDR2 module in place when the DDR2 module touches the bottom of the slot.
3. To remove the DDR2 module, press the clips with both hands.
Lock Lock
DDR2 Module
Lock Lock
MI910 User’s Manual 7
INSTALLATIONS
Setting the Jumpers
Jumpers are used on MI910 to select various settings and features according to your needs and applications. Contact your supplier if you have doubts about the best configuration for your needs. The following lists the connectors on MI910 and their respective functions.
Jumper Locations on MI910...........................................................9
JP5: LCD Panel Power Selection..................................................10
JP9: PCI/PCIE Riser Card Selection ............................................ 10
JBAT1: Clear CMOS Setting ....................................................... 10
JP8: CompactFlash Slave/Master Selection..................................10
IMPORTANT NOTE: When the system boots without the CRT being connected, there will be no image on screen when you insert the CRT/VGA cable. To show the image on screen, the hotkey must be pressed.
8 MI910 User’s Manual
Jumper Locations on MI910
INSTALLATIONS
Jumpers on MI910............................................................................Page
JP5: LCD Panel Power Selection................................................. 10
JP9: PCI/PCIE Riser Card Selection............................................ 10
JBAT1: Clear CMOS Setting....................................................... 10
JP8: CompactFlash Slave/Master Selection ................................. 10
MI910 User’s Manual 9
INSTALLATIONS
JP5: LCD Panel Power Selection
JP5 LCD Panel Power
3.3V
5V
JP9: PCI/PCIE Riser Card Selection
JP9 Riser Card
IP390 Riser Card
Install
IP151, IP240 Riser Card
Install
JBAT1: Clear CMOS Setting
JBAT1 Setting
JP8: CompactFlash Slave/Master Selection
Normal
Clear CMOS
JP8 CF Setting
Master
[
10 MI910 User’s Manual
Slave
Connectors on MI910
CN1: PS/2 Keyboard and PS/2 Mouse Connectors...................... 14
CN2, CN3: COM1 and VGA Connector...................................... 14
USB_LAN1: 10/100 RJ-45(MI910), GbE RJ45(MI910G) and
USB1/2 Ports................................................................................ 15
CN4: 1394 Connector................................................................... 15
J6: SPDIF Out Connector ............................................................. 15
CN5, CN6: GbE RJ-45(MI910F) and USB3/4 Ports ................... 15
CN7: Audio Connector................................................................. 15
FAN1: System Fan Power Connector .......................................... 15
FAN2: CPU Fan Power Connector .............................................. 15
IDE1: IDE Connector................................................................... 16
FDD1: Floppy Drive Connector................................................... 16
ATX1: ATX Power Supply Connector ........................................ 17
J1 (F_PANEL): System Function Connector............................... 17
F_USB1: USB0/USB1 Connector................................................ 19
JP1, JP2, JP3: RS232/422/485 (COM2) Selection....................... 19
J2: COM2 Serial Port................................................................... 20
J3, J4: LVDS Connectors (1st channel, 2nd channel).................. 20
J5: LCD Backlight Connector...................................................... 20
J7: Mini PCI Connector................................................................ 20
CN8, CN9: SATA Connectors..................................................... 20
J8: Digital I/O............................................................................... 21
J9: CD-In Pin Header................................................................... 21
J10: SPI Flash Connector (factory use only)................................ 21
J11: 1394 Connector..................................................................... 21
J12: Front Audio Connector......................................................... 21
J13: PCI-E(x1) Slot...................................................................... 21
J14: IrDA Connector.................................................................... 22
J15: Compact Flash Connector..................................................... 22
PCI1: PCI Slot (supports 2 Master).............................................. 22
CON1: SDVO Port Connector ..................................................... 22
Headers and Connectors on MI910 Daughter Cards.................... 23
ID390 – JP4 LCD Panel Power Selection ....................................................... 23
INSTALLATIONS
ID390 – J1 LCD Backlight Setting ................................................................ 23
ID390 – J3 and J2 1st/2
ID390C – J4 VGA Connector ....................................................................... 24
ID391 – J2 DVI Connector........................................................................... 25
ID391D – J1, J2 1st/2
nd
LVDS Channel Connectors....................................... 23
nd
DVI Connectors......................................................... 25
MI910 User’s Manual 11
INSTALLATIONS
Connector Locations on MI910
12 MI910 User’s Manual
INSTALLATIONS
MI910 Solder Side
MI910 User’s Manual 13
INSTALLATIONS
CN1: PS/2 Keyboard and PS/2 Mouse Connectors
PS/2 Mouse
PS/2 Keyboard
Signal Name Keyboard Mouse Signal Name
Keyboard data 1 1 Mouse data
N.C. 2 2 N.C.
GND 3 3 GND
5V 4 4 5V
Keyboard clock 5 5 Mouse clock
N.C. 6 6 N.C.
CN2, CN3: COM1 and VGA Connector
[
Signal Name Pin # Pin # Signal Name
DCD 1 6 DSR RXD 2 7 RTS TXD 3 8 CTS
[[[[
DTR 4 9 RI
GND 5 10 Not Used
Signal Name Pin # Pin # Signal Name
Red 1 2 Green
Blue 3 4 N.C. GND 5 6 GND GND 7 8 GND
N.C. 9 10 GND
N.C. 11 12 N.C.
HSYNC 13 14 VSYNC
NC 15
14 MI910 User’s Manual
USB_LAN1: 10/100 RJ-45(MI910), 10/100/1000 RJ45(MI910G)
and USB1/2 Ports CN4: 1394 Connector J6: SPDIF Out Connector CN5, CN6: GbE RJ-45(MI910F) and USB3/4 Ports CN7: Audio Connector
INSTALLATIONS
FAN1: System Fan Power Connector
FAN1 is a 3-pin header for system fans. The fan must be a 12V (500mA).
Pin # Signal Name
1 Ground 2 +12V 3 Rotation detection
FAN2: CPU Fan Power Connector
FAN2 is a 3-pin header for the CPU fan. The fan must be a 12V fan.
Pin # Signal Name
1 Ground
MI910 User’s Manual 15
2 +12V 3 Rotation detection
INSTALLATIONS
IDE1: IDE Connector
Signal Name Pin # Pin # Signal Name
Reset IDE 1 2 Ground Host data 7 3 4 Host data 8 Host data 6 5 6 Host data 9 Host data 5 7 8 Host data 10 Host data 4 9 10 Host data 11 Host data 3 11 12 Host data 12 Host data 2 13 14 Host data 13 Host data 1 15 16 Host data 14 Host data 0 17 18 Host data 15
Ground 19 20 Protect pin
DRQ0 21 22 Ground
Host IOW 23 24 Ground
Host IOR 25 26 Ground
IOCHRDY 27 28 Host ALE
DACK0 29 30 Ground
IRQ14 31 32 No connect Address 1 33 34 No connect Address 0 35 36 Address 2
Chip select 0 37 38 Chip select 1
Activity 39 40 Ground
FDD1: Floppy Drive Connector
FDD1is a slim 26-pin connector and will support up to 2.88MB FDD.
Signal Name Pin # Pin # Signal Name
VCC 1 2 INDEX VCC 3 4 DRV_SEL VCC 5 6 DSK_CH
NC 7 8 NC NC 9 10 MOTOR
DINST 11 12 DIR
NC 13 14 STEP GND 15 16 WDATA GND 17 18 WGATE GND 19 20 TRACK
NC 21 22 WPROT GND 23 24 RDATA GND 25 26 SIDE
16 MI910 User’s Manual
INSTALLATIONS
ATX1: ATX Power Supply Connector
11 1
Signal Name Pin # Pin # Signal Name
3.3V 11 1 3.3V
-12V 12 2 3.3V
Ground 13 3 Ground
PS-ON 14 4 +5V Ground 15 5 Ground Ground 16 6 +5V Ground 17 7 Ground
-5V 18 8 Power good +5V 19 9 5VSB +5V 20 10 +12V
20 10
J1 (F_PANEL): System Function Connector
J1 provides connectors for system indicators that provide light i ndication of the computer activities and switches to change the computer status. J1 is a 20-pin header that provides interfaces for the following functions.
Hard Disk Drive LED
Reset Switch
Not Defined
Not Defined
ATX Power On Switch
Power LED
Speaker
Speaker: Pins 1 - 4
This connector provides an interface to a speaker for audio tone generation. An 8-ohm speaker is recommended.
Pin # Signal Name
1 Speaker out 2 No connect 3 Ground 4 +5V
MI910 User’s Manual 17
INSTALLATIONS
Power LED: Pins 11 - 15
ATX Power ON Switch: Pins 7 and 17
This 2-pin connector is an “ATX Power Supply On/Off Switch” on the system that connects to the power switch on the case. When pressed, the power switch will force the system to power on. When pressed again, it will force the system to power off.
Reset Switch: Pins 9 and 19
The reset switch allows the user to reset the system without turning the main power switch off and then on again. Orientation is not required when making a connection to this header.
Pin # Signal Name
11 Power LED 12 No connect 13 Ground 14 No connect 15 Ground
Hard Disk Drive LED Connector: Pins 10 and 20
This connector connects to the hard drive activity LED on control panel. This LED will flash when the HDD is being accessed.
Pin # Signal Name
10 HDD Active 20 5V
18 MI910 User’s Manual
INSTALLATIONS
F_USB1: USB0/USB1 Connector
Signal Name Pin Pin Signal Name
Vcc 1 2 Vcc D0- 3 4 D1-
D0+ 5 6 D1+
Ground 7 8 Ground
NC 9 10 Ground
JP1, JP2, JP3: RS232/422/485 (COM2) Selection
COM1 is fixed for RS-232 use only. COM2 is selectable for RS232, RS-422 and RS-485. The following table describes the jumper settings for COM2 selection.
COM2 is jumper selectable for RS-232, RS-422 and RS-485.
COM2
Function
Jumper Setting
(pin closed)
RS-232 RS-422 RS-485
JP3:
1-2
JP2:
3-5 & 4-6
JP1:
3-5 & 4-6
Pin # Signal Name
RS-232 R2-422 RS-485
JP3:
3-4
JP2:
1-3 & 2-4
JP1:
1-3 & 2-4
JP3:
5-6
JP2:
1-3 & 2-4
JP1:
1-3 & 2-4
1 DCD TX- DATA­2 RX TX+ DATA+ 3 TX RX+ NC 4 DTR RX- NC 5 Ground Ground Ground 6 DSR RTS- NC 7 RTS RTS+ NC 8 CTS CTS+ NC 9 RI CTS- NC
10 NC NC NC
MI910 User’s Manual 19
INSTALLATIONS
J2: COM2 Serial Port
COM2
Signal Name Pin # Pin # Signal Name
DCD, Data carrier detect 1 6 DSR, Data set ready
RXD, Receive data 2 7 RTS, Request to send
TXD, Transmit data 3 8 CTS, Clear to send
DTR, Data terminal ready 4 9 RI, Ring indicator
GND, ground 5 10 Not Used
J3, J4: LVDS Connectors (1st channel, 2nd channel)
The LVDS connectors on board consist of the first channel (J3) and second channel (J4).
Signal Name Pin # Pin # Signal Name
TX0- 2 1 TX0+
Ground 4 3 Ground
TX1- 6 5 TX1+
5V/3.3V 8 7 Ground
NA 10 9 NA
TX2- 12 11 TX2+
Ground 14 13 Ground
TXC- 16 15 TXC+
5V/3.3V 18 17 ENABKL
+12V 20 19 +12V
J5: LCD Backlight Connector
Pin # Signal Name
1 +12V 2 Backlight Enable 3 Ground
J7: Mini PCI Connector CN8, CN9: SATA Connectors
20 MI910 User’s Manual
J8: Digital I/O
Signal Name Pin Pin Signal Name
GND 1 2 VCC OUT3 3 4 OUT1 OUT2 5 6 OUT0
IN3 7 8 IN1 IN2 9 10 IN0
J9: CD-In Pin Header
Pin # Signal Name
1 CD Audio R 2 Ground 3 Ground 4 CD Audio L
J10: SPI Flash Connector (factory use only) J11: 1394 Connector
Signal Name Pin Pin Signal Name
TPA+ 1 2 TPB+
TPA- 3 4 TPB-
+12V 5 6 NC
J12: Front Audio Connector
GND 7 8 NC
Signal Name Pin # Pin # Signal Name
MIC2_L 1 2 Ground
MIC2_R 3 4 Presence#
Line2_L 5 6 MIC2_ID
Sense 7 8 NC
Line2_R 9 10 Line2_ID
J13: PCI-E(x1) Slot
INSTALLATIONS
MI910 User’s Manual 21
INSTALLATIONS
J14: IrDA Connector
Pin # Signal Name
1 +5V 2 No connect 3 Ir RX 4 Ground 5 Ir TX
J15: Compact Flash Connector PCI1: PCI Slot (supports 2 Master)
CON1: SDVO Port Connector
Signal Name Pin # Pin # Signal Name
+12V A1 B1 +12V +12V A2 B2 +12V
+5V A3 B3 +5V
3.3V A4 B4 3.3V
RESET A5 B5 GND
GND A6 B6 GND SDVOC_CLK+ A7 B7 SDVOC_CLK­SDVOC_Blue+ A8 B8 SDVOC_Blue-
GND A9 B9 GND
SDVOC_Green+ A10 B10 SDVOC_Green-
SDVOC_Red+ A11 B11 SDVOC_Red-
GND A12 B12 GND
SDVO TVClkIn+ A13 B13 SDVO TVClkIn-
SDVOB Int+ A14 B14 SDVOB Int-
GND A15 B15 GND SDVO CtrlData A16 B16 SDVO CtrlClk
SDVOB Clk+ A17 B17 SDVOB Clk-
GND A18 B18 GND
SDVOB Blue+ A19 B19 SDVOB Blue-
SDVOB Green+ A20 B20 SDVOB Green-
GND A21 B21 GND
SDVOB Red+ A22 B22 SDVOB Red-
SDVO Stall+ A23 B23 SDVO Stall-
GND A24 B24 GND
22 MI910 User’s Manual
INSTALLATIONS
Headers and Connectors on MI910 Daughter Cards
ID390 – JP4 LCD Panel Power Selection
JP4 Voltage
3.3V
5V
ID390 – J1 LCD Backlight Setting
Pin # Signal Name
1 +12V 2 Backlight Enable 3 Ground
ID390 – J3 and J2 1st/2nd LVDS Channel Connectors
Signal Name Pin # Pin # Signal Name
TX0- 2 1 TX0+
Ground 4 3 Ground
TX1- 6 5 TX1+
5V/3.3V 8 7 Ground
TX3- 10 9 TX3+ TX2- 12 11 TX2+
Ground 14 13 Ground
TXC- 16 15 TXC+
5V/3.3V 18 17 ENABKL
+12V 20 19 +12V
MI910 User’s Manual 23
INSTALLATIONS
ID390C – J4 VGA Connector
[[[[
Signal Name Pin # Pin # Signal Name
+5V 2 1 RED
Ground 4 3 GREEN
N.C. 6 5 BLUE
SDA 8 7 N.C. HSYNC 10 9 Ground VSYNC 12 11 Ground
SCL 14 13 Ground N.C. 16 15 Ground
24 MI910 User’s Manual
ID391 – J2 DVI Connector
Signal Name Pin # Pin # Signal Name
TDC1- 2 1 TDC1+
Ground 4 3 Ground
TLC- 6 5 TLC+
+5V 8 7 Ground
NC 10 9 HPDET TDC2- 12 11 TDC2+ Ground 14 13 Ground TDC0- 16 15 TDC0+
NC 18 17 NC
DDC_SC 20 19 DDC_SD
INSTALLATIONS
ID391D – J1, J2 1st/2nd DVI Connectors
Signal Name Pin # Pin # Signal Name
TDC1- 2 1 TDC1+ Ground 4 3 Ground
TLC- 6 5 TLC+
+5V 8 7 Ground
NC 10 9 HPDET TDC2- 12 11 TDC2+ Ground 14 13 Ground TDC0- 16 15 TDC0+
NC 18 17 NC
DDC_SC 20 19 DDC_SD
Remarks: When using dual DVI, the first DVI video output is through J1. After setting the drivers in Windows, then the second DVI output (via J2) will function. ID391D and ID391 are different since the latter (ID391) has video output via J2. The pin assignments of J1 and J2 are the same.
MI910 User’s Manual 25
INSTALLATIONS
This page is intentionally left blank.
26 MI910 User’s Manual
BIOS SETUP
BIOS Setup
This chapter describes the different settings available in the Award BIOS that comes with the board. The topics covered in this chapter are as follows:
BIOS Introduction........................................................................ 28
BIOS Setup................................................................................... 28
Standard CMOS Setup ................................................................. 30
Advanced BIOS Features............................................................. 33
Advanced Chipset Features.......................................................... 36
Integrated Peripherals................................................................... 38
Power Management Setup............................................................ 42
PNP/PCI Configurations .............................................................. 45
PC Health Status........................................................................... 46
Frequency/Voltage Control.......................................................... 47
Load Fail-Safe Defaults................................................................ 48
Load Optimized Defaults ............................................................. 48
Set Supervisor/User Password...................................................... 48
Save & Exit Setup ........................................................................ 48
Exit Without Saving..................................................................... 48
MI910 User’s Manual 27
BIOS SETUP
BIOS Introduction
The Award BIOS (Basic Input/Output System) installed in your computer system’s ROM supports Intel processors. The BIOS provides critical low-level support for a standard device such as disk drives, serial ports and parallel ports. It also adds virus and password protection as well as special support for detailed fine-tuning of the chipset controlling the entire system.
BIOS Setup
The Award BIOS provides a Setup utility program for specifying the system configurations and settings. The BIOS ROM of the system stores the Setup utility. When you turn on the computer, the Award BIOS is immediately activated. Pressing the <Del> key immediately allows you to enter the Setup utility. If you are a little bit late pressing the <Del> key, POST (Power On Self Test) will continue with its test routines, thus preventing you from invoking the Setup. If you still wish to enter Setup, restart the system by pressing the ”Reset” button or simultaneously pressing the <Ctrl>, <Alt> and <Delete> keys. You can also restart by turning the system Off and back On again. The following message will appear on the screen:
Press <DEL> to Enter Setup
In general, you press the arrow keys to highlight items, <Enter> to select, the <PgUp> and <PgDn> keys to change entries, <F1> for help and <Esc> to quit.
When you enter the Setup utility, the Main Menu screen will appear on the screen. The Main Menu allows you to select from various setup functions and exit choices.
28 MI910 User’s Manual
BIOS SETUP
Standard CMOS Features Frequency/Voltage Control Advanced BIOS Features Load Fail-Safe Defaults Advanced Chipset Features Load Optimized Defaults Integrated Peripherals Set Supervisor Password Power Management Setup Set User Password PnP/PCI Configurations Save & Exit Setup PC Health Status Exit Without Saving ESC : Quit     : Select Item F10 : Save & Exit Setup
Phoenix - AwardBIOS CMOS Setup Utility
Time, Date, Hard Disk Type…
The section below the setup items of the Main Menu displays the control keys for this menu. At the bottom of the Main Menu just below the control keys section, there is another section, which displays information on the currently highlighted item in the list.
Note:
If the system cannot boot after making and saving system changes with Setup, the Award BIOS supports an override to the CMOS settings that resets your system to its default.
Warning:
It is strongly recommended that you avoid making any changes to the chipset defaults. These defaults have been carefully chosen by both Award and your system manufacturer to provide the absolute maximum performance and reliability. Changing the defaults could cause the system to become unstable and crash in some cases.
MI910 User’s Manual 29
BIOS SETUP
Standard CMOS Setup
“Standard CMOS Setup” choice allows you to record some basic hardware configurations in your computer system and set the system clock and error handling. If the motherboard is already installed in a working system, you will not need to select this option. You will need to run the Standard CMOS option, however, if you change your system hardware configurations, the onboard battery fails, or the configuration stored in the CMOS memory was lost or damaged.
Date (mm:dd:yy) Wed, Apr 28, 2007 Item Help Time (hh:mm:ss) 00 : 00 : 00 Menu Level >
IDE Channel 0 Master None IDE Channel 0 Slave None IDE Channel 1 Master None IDE Channel 1 Slave None
Drive A None Drive B None
Video EGA/VGA Halt On All Errors
Base Memory 640K Extended Memory 129024K Total Memory 130048K
At the bottom of the menu are the control keys for use on this menu. If you need any help in each item field, you can press the <F1> key. It will display the relevant information to help you. The memory display at the lower right-hand side of the menu is read-only. It will adjust automatically according to the memory changed. The following describes each item of this menu.
Date
The date format is:
Day : Sun to Sat Month : 1 to 12 Date : 1 to 31 Year : 1999 to 2099
Phoenix - AwardBIOS CMOS Setup Utility
Standard CMOS Features
Change the day, month, Year and century
30 MI910 User’s Manual
BIOS SETUP
To set the date, highlight the “Date” field and use the PageUp/ PageDown or +/- keys to set the current time.
Time
The time format is:
Minute : 00 to 59 Second : 00 to 59
Hour : 00 to 23
To set the time, highlight the “Time” field and use the <PgUp>/ <PgDn> or +/- keys to set the current time.
IDE Channel Master/Slave
The onboard PCI IDE connector provides Primary and Secondary channels for connecting up to two IDE hard disks or other IDE devices.
Press <Enter> to configure the hard disk. The selections include Auto, Manual, and None. Select ‘Manual’ to define the drive information manually. You will be asked to enter the following items.
CYLS : Number of cylinders HEAD : Number of read/write heads PRECOMP : Write precompensation LANDING ZONE : Landing zone SECTOR : Number of sectors
The Access Mode selections are as follows: CHS (HD < 528MB)
LBA (HD > 528MB and supports
Logical Block Addressing) Large (for MS-DOS only) Auto
Remarks: The main board supports two serial ATA ports and are represented in this setting as IDE Channel 0.
Drive A / Drive B
These fields identify the types of floppy disk drive A or drive B that has been installed in the computer. The available specifications are: 360KB
5.25 in.
1.2MB
5.25 in.
720KB
3.5 in.
1.44MB
3.5 in.
2.88MB
3.5 in.
MI910 User’s Manual 31
BIOS SETUP
Video
This field selects the type of video displ ay card i nstall ed in your sy stem . You can choose the following video display cards: EGA/VGA For EGA, VGA, SEGA, SVGA or PGA monitor adapters. (default) CGA 40 Power up in 40 column mode. CGA 80 Power up in 80 column mode. MONO For Hercules or MDA adapters.
Halt On
This field determines whether or not the system will halt if an error is detected during power up. No errors The system boot will not be halted for any error
that may be detected.
All errors Whenever the BIOS detects a non-fatal error,
the system will stop and you will be prompted.
All, But Keyboard The system boot will not be halted for a
keyboard error; it will stop for all other errors
All, But Diskette The system boot will not be halted for a disk
error; it will stop for all other errors.
All, But Disk/Key The system boot will not be halted for a key-
board or disk error; it will stop for all others.
32 MI910 User’s Manual
BIOS SETUP
Advanced BIOS Features
This section allows you to configure and improve your system and allows you to set up some system features according to your preference.
CPU Feature Press Enter ITEM HELP Hard Disk Boot Priority Press Enter Virus Warning Disabled
USB Hard Disk Boot First Disabled
CPU L3 Cache Enabled Quick Power On Self Test Enabled First Boot Device Hard Disk Second Boot Device CDROM Third Boot Device LS120 Boot Other Device Enabled Swap Floppy Drive Disabled Boot Up Floppy Seek Disabled Boot Up NumLock Status On Gate A20 Option Fast Typematic Rate Setting Disabled Typematic Rate (Chars/Sec) 6 Typematic Delay (Msec) 250 Security Option Setup APIC Mode Enabled MPS Version Control for OS 1.4 OS Select For DRAM>64MB Non-OS2 Report No FDD For WIN 95 Yes Small Logo (EPA) Show Enabled
CPU Feature
Press Enter to configure the settings relevant to CPU Feature.
Hard Disk Boot Priority
With the field, there is the option to choose, aside from the hard disks connected, Bootable add-in Cards which refers to other external devices.
Virus Warning
If this option is enabled, an alarm message will be displayed when trying to write on the boot sector or on the partition table on the disk, which is typical of the virus.
CPU L1 and L2 Cache
Cache memory is additional memory that is faster than conventional DRAM (system memory). CPUs from 486-type on up contain internal cache memory, and most, but not all, modern PCs have additional (external) cache memory. When the CPU requests data, the system transfers the requested data from the main DRAM into cache memory, for even faster access by the CPU. These allow you to enable (speed up memory access) or disable the cache function.
Phoenix - AwardBIOS CMOS Setup Utility
Advanced BIOS Features
Menu Level >
MI910 User’s Manual 33
BIOS SETUP
Quick Power On Self Test
When enabled, this field speeds up the Power On Self Test (POST) after the system is turned on. If it is set to Enabled, BIOS will skip some items.
First/Second/Third Boot Device
These fields determine the drive that the system searches first for an operating system. The options available include Floppy, LS120, Hard Disk, CDROM, ZIP100, USB-Floppy, USB-ZIP, USB-CDROM, LAN and Disable.
Boot Other Device
These fields allow the system to search for an OS from other devices other than the ones selected in the First/Second/Third Boot Device.
Swap Floppy Drive
This item allows you to determi ne whether or not to enable Swap Floppy Drive. When enabled, the BIOS swaps floppy drive assignments so that Drive A becomes Drive B, and Drive B becomes Drive A. By default, this field is set to Disabled.
Boot Up Floppy Seek
This feature controls whether the BIOS checks for a floppy drive while booting up. If it cannot detect one (either due to improper configuration or its absence), it will flash an error message.
Boot Up NumLock Status
This allows you to activate the NumLock function after you power up the system.
Gate A20 Option
This field allows you to select how Gate A20 is worked. Gate A2 0 is a device used to address memory above 1 MB.
Typematic Rate Setting
When disabled, continually holding dow n a key on your keyboard will generate only one instance. When enabled, you can set the two typematic controls listed next. By default, this field is set to Disabled.
Typematic Rate (Chars/Sec)
When the typematic rate is enabled, the system registers repeated keystrokes speeds. Settings are from 6 to 30 characters per second.
34 MI910 User’s Manual
BIOS SETUP
Typematic Delay (Msec)
When the typematic rate is enabled, this item allows you to set the time interval for displaying the first and second characters. By default, this item is set to 250msec.
Security Option
This field allows you to limit access to the System and Setup. The default value is Setup. When you select System, the system prompts for the User Password every time you boot up. When you select Setup, the system always boots up and prompts for the Supervisor Password only when the Setup utility is called up.
APIC Mode
APIC stands for Advanced Programmable Interrupt Controller. The default setting is Enabled.
MPS Version Control for OS
This option is specifies the MPS (Multiprocessor Specification) version for your operating system. MPS version 1.4 added extended configuration tables to improve support for multiple PCI bus configurations and improve future expand ability. The default setting is
1.4.
OS Select for DRAM > 64MB
This option allows the system to access greater than 64MB of DRAM memory when used with OS/2 that depends on certain BIOS calls to access memory. The default setting is Non-OS/2.
Report No FDD For WIN 95
If you are using Windows 95/98 without a floppy disk drive, select Enabled to release IRQ6. This is required to pass Windows 95/98's SC T test. You should also disable the Onboard FDC Controller in the Integrated Peripherals screen when there's no floppy drive in the sy stem. If you set this feature to Disabled, the BIOS will not report the missing floppy drive to Win95/98.
Small Logo (EPA) Show
The EPA logo appears at the right side of the monitor screen when the system is boot up. The default setting is Enabled.
MI910 User’s Manual 35
BIOS SETUP
Advanced Chipset Features
This Setup menu controls the configuration of the chipset.
System BIOS Cacheable Enabled ITEM HELP Memory Hole at 15M-16M Disabled PCI Express Root Port Func Press Enter
** VGA Setting ** PEG/On Chip VGA Control Auto PEG Force X1 Disabled On-Chip Frame Buffer Size 8MB DVMT Mode DVMT DVMT/FIXED memory Size 128MB SDVO Device Setting None SDVO LVDS Protocol 1CH SPWG, 18bit SDVO Panel Number 1024x768 Boot Display CRT+LVDS Panel Scaling Auto Panel Number 1024x768 18 bit SC
System BIOS Cacheable
The setting of Enabled allows caching of the system BIOS ROM at F000h-FFFFFh, resulting in better system performance. However, if any program writes to this memory area, a system error may result.
Memory Hole At 15M-16M
In order to improve performance, certain space in memory can be reserved for ISA cards. This memory must be mapped into the memory space below 16 MB. The choices are Enabled and Disabled.
Phoenix - AwardBIOS CMOS Setup Utility
Advanced Chipset Features
Note: SDVO Device Setting, SDVO LVDS Protocol and SDVO Panel Number Selection fields are available when ID390, ID390C, ID391, ID391D or ID392 daughter cards are installed.
36 MI910 User’s Manual
BIOS SETUP
On-Chip VGA Setting
The fields under the On-Chip VGA Setting and their default settings are:
PEG/On Chip VGA Control: Auto On-Chip Frame Buffer Size: 8MB DVMT Mode: DVTM DVMT/Fixed Memory Size: 128MB
SDVO Device Setting: (LVDS, DVI, Dual DVI, CRT); Dual LVDS [onboard + ID390]
Remarks: Set to LVDS for ID390, Set to CRT for ID390C, Set to DVI for ID391/ID392/ID391D/ID392D.
SDVO LVDS Protocol: 1Ch SPWG, 18bit SDVO Panel Number: 1024x768 Boot Display: CRT+LVDS Panel Scaling: Auto Panel Number: 1024x768 18 bit SC
Note: SDVO Device Setting, SDVO LVDS Protocol, SDVO Panel Number – for external device from connector CON1
Panel Scaling
The default setting is Auto. The options available include On and Off.
Panel Number
These fields allow you to select the LCD Panel type. The values for these ports are:
640x480 18bit SC 800x480 18bit SC 800x600 18bit SC 1024x768 18bit SC 1280x1024 18bit DC 1280x768 18bit SC 1400x1050 18bit DC 1600x1200 18bit DC
MI910 User’s Manual 37
BIOS SETUP
Integrated Peripherals
This section sets configurations for your hard disk and other integrated peripherals. The first screen shows three main items for user to select. Once an item selected, a submenu appears. Details follow.
OnChip IDE Device Onboard Device SuperIO Device USB Device Setting
IDE HDD Block Mode On-chip Primary PCI IDE IDE Primary Master PIO IDE Primary Slave PIO IDE Primary Master UDMA IDE Primary Slave UDMA On-Chip Secondary PCI IDE IDE Secondary Master PIO IDE Secondary Slave PIO IDE Secondary Master UDMA IDE Secondary Slave UDMA
SATA Mode IDE LEGACY Mode Support Disable
Marvell Gigabit Lan Control
Phoenix - AwardBIOS CMOS Setup Utility
Integrated Peripherals Press Enter ITEM HELP
Press Enter Menu Level > Press Enter Press Enter
Phoenix - AwardBIOS CMOS Setup Utility
OnChip IDE Device
Enabled ITEM HELP Enabled Auto Auto Auto Auto Enabled Auto Auto Auto Auto
Phoenix - AwardBIOS CMOS Setup Utility
Onboard Device
Menu Level >
Enable ITEM HELP
38 MI910 User’s Manual
BIOS SETUP
Phoenix - AwardBIOS CMOS Setup Utility
POWER ON Function BUTTON ONLY
KB Power ON Password Enter Hot Key power ON Ctrl-F1 Onboard Serial Port 1 3F8/IRQ4 Onboard Serial Port 2 2F8/IRQ3 UART Mode Select Normal RxD, TxD Active Hi, Lo IR Transmission Delay Disabled UR2 Duplex Mode Half Use IR Pins IR-Rx2Tx2 PWRON After PWR-Fail Off
SuperIO Device
ITEM HELP
Menu Level >
IDE HDD Block Mode
This field allows your hard disk controller to use the fast block mode to transfer data to and from your hard disk drive.
On-chip Primary PCI IDE Enabled
This field, by default, is enabled
On-chip Primary/Secondary PCI IDE
The integrated peripheral controller contains an IDE interface with support for two IDE channels. Select Enabled to activate each channel separately.
IDE Primary/Secondary Master/Slave PIO
These fields allow your system hard disk controller to work faster. Rather than have the BIOS issue a series of commands that transfer to or from the disk drive, PIO (Programmed Input /Output) allows the BIOS to communicate with the controller and CPU directly.
The system supports five modes, numbered from 0 (default) to 4, which primarily differ in timing. When Auto is selected, the BIOS will select the best available mode.
IDE Primary/Secondary Master/Slave UDMA
These fields allow your system to improve disk I/O throughput to 33Mb/sec with the Ultra DMA/33 feature. The options are Auto and Disabled.
MI910 User’s Manual 39
BIOS SETUP
On-Chip Serial ATA Setting
The fields under the SATA setting includes On-Chip Serial ATA (Auto), PATA IDE Mode (Secondary) and SATA Port (PO, P2 is Primary).
AC97 Audio Select
This field, by default, is set to Auto.
Power ON Function
This field is related to how the system is powered on – such as with th e use of conventional power button, keyboard or hot keys. The default is BUTTON ONLY.
KB Power ON Password
This field allows users to set the password when keyboard power on is the mode of the Power ON function.
Hot Key Power ON
This field sets certain keys, also known as hot keys, on the keyboard that can be used as a ‘switch’ to power on the system.
40 MI910 User’s Manual
BIOS SETUP
Onboard Serial Port
These fields allow you to select the onboard serial ports and their addresses. The default values for these ports are: Serial Port 1 3F8/IRQ4 Serial Port 2 2F8/IRQ3
UART Mode Select
This field determines the UART 2 mode in your computer. The default value is Normal. Other options include IrDA and ASKIR.
PWRON After PWR-Fail
This field sets the system power status whether on or off when power returns to the system from a power failure situation.
USB 1.0 Controller Enabled
USB 2.0 Controller Enabled USB Keyboard Function Disable USB Mouse Function Disable USB Storage Function Enabled
*** USB Mass Storage Device Boot Setting ***
Phoenix - AwardBIOS CMOS Setup Utility
USB Device Setting
ITEM HELP
Menu Level >
USB 1.0 Controller
The options for this field are Enabled and Disabled. By default, this field is set to Enabled.
USB 2.0 Controller
The options for this field are Enabled and Disabled. By default, this field is set to Enabled. In order to use USB 2.0, necessary OS drivers must be installed first. Please update your system to Windows 2000 SP4 or Windows XP SP2.
USB Keyboard/Mouse/Storage Function
The options for this field are Enabled and Disabled. By default, this field is set to Disabled.
MI910 User’s Manual 41
BIOS SETUP
Power Management Setup
ACPI Function ACPI Suspend RUN VGABIOS if S3 Resume Power Management Video Off Method Video Off In Suspend Suspend Type Modem Use IRQ Suspend Mode HDD Power Down
Soft-Off by PWR-BTTN Wake-Up by PCI Card Power On by Ring Resume by Alarm
Date (of Month) Alarm 0 Time (hh:mm:ss) Alarm 0 : 0 : 0
** Reload Global Timer Events ** Primary IDE 0 Primary IDE 1 Secondary IDE 0 Secondary IDE 1 FDD, COM, LPT Port PCI PIRQ[A-D] #
Phoenix - AwardBIOS CMOS Setup Utility
Power Management Setup
Enabled ITEM HELP S3(POS) Auto User Define DPMS Yes Stop Grant 3 Disabled Disabled
Instant-Off Disabled Disabled Disabled
Disabled Disabled Disabled Disabled Disabled Disabled
Menu Level >
ACPI Function
Enable this function to support ACPI (Advance Configuration and Power Interface).
ACPI Suspend
The default setting of the ACPI Suspend mode is S3(POS).
RUN VGABIOS if S3 Resume
The default setting of this field is Auto.
Power Management
This field allows you to select the type of power saving management modes. There are four selections for Power Management.
Min. Power Saving Minimum power management Max. Power Saving Maximum power management. User Define Each of the ranges is from 1 min. to
1hr. Except for HDD Power Down which ranges from 1 min. to 15 min.
42 MI910 User’s Manual
BIOS SETUP
Video Off Method
This field defines the Video Off features. There are three options.
V/H SYNC + Blank Default setting, blank the screen and turn
off vertical and horizontal scanning. DPMS Allows BIOS to control the video display. Blank Screen Writes blanks to the video buffer.
Video Off In Suspend
When enabled, the video is off in suspend mode. The default setting is Yes.
Suspend Type
The default setting for the Suspend Type field is Stop Grant.
Modem Use IRQ
This field sets the IRQ used by the Modem. By default, the setting is 3.
Suspend Mode
When enabled, and after the set time of system inactivity, all devices except the CPU will be shut off.
HDD Power Down
When enabled, and after the set time of system inactivity, the hard disk drive will be powered down while all other devices remain active.
Soft-Off by PWRBTN
This field defines the power-off mode when using an ATX power supply. The Instant Off mode allows powering off immediately upon pressing the power button. In the Delay 4 Sec mode, the system powers off when the power button is pressed for more than four seconds or enters the suspend mode when pressed for less than 4 seconds.
Wake up by PCI Card
By default, this field is disabled.
Power On by Ring
This field enables or disables the power on of the system through the modem connected to the serial port or LAN.
MI910 User’s Manual 43
BIOS SETUP
Resume by Alarm
This field enables or disables the resumption of the system operation. When enabled, the user is allowed to set the Date and Time.
Reload Global Timer Events
The HDD, FDD, COM, LPT Ports, and PCI PIRQ are I/O events that can prevent the system from entering a power saving mode or can awaken the system from such a mode. When an I/O device wants to gain the attention of the operating system, it signals this by causing an IRQ to occur. When the operating system is ready to respond to the request, it interrupts itself and performs the service.
44 MI910 User’s Manual
BIOS SETUP
PNP/PCI Configurations
This option configures the PCI bus system. All PCI bus systems on the system use INT#, thus all installed PCI cards must be set to this value.
Init Display First Reset Configuration Data
Resources Controlled By IRQ Resources
PCI/VGA Palette Snoop INT Pin 1 Assignment INT Pin 2 Assignment INT Pin 3 Assignment INT Pin 4 Assignment INT Pin 5 Assignment INT Pin 6 Assignment INT Pin 7 Assignment INT Pin 8 Assignment
**PCI Express relative items** Maximum Payload Size
Init Display First
The default setting is PCI Card.
Reset Configuration Data
This field allows you to determine whether to reset the conf iguration data or not. The default value is Disabled.
Resources Controlled by
This PnP BIOS can configure all of the boot and compatible devices with the use of a PnP operating system such as Windows 95.
PCI/VGA Palette Snoop
Some non-standard VGA display cards may not show colors properly. This field allows you to set whether or not MPEG ISA/VESA VGA cards can work with PCI/VGA. When this field is enabled, a PCI/VGA can work with an MPEG ISA/VESA VGA card. When this field is disabled, a PCI/VGA cannot work with an MPEG ISA/VESA card.
Maximum Payload Size
The default setting of the PCI Express Maximum Payload Size is 4096.
Phoenix - AwardBIOS CMOS Setup Utility
PnP/PCI Configurations
PCI Slot ITEM HELP Disabled
Auto (ESCD) Press Enter
Disabled Auto Auto Auto Auto Auto Auto Auto Auto
4096
Menu Level
Select Yes if you are using a Plug and Play capable operating system Select No if you need the BIOS to configure non-boot devices
MI910 User’s Manual 45
BIOS SETUP
PC Health Status
This section shows the parameters in determining the PC Health Status. These parameters include temperatures, fan speeds and voltages.
Shutdown Temperature Disabled CPU Warning Temperature Disabled Current System Temp 45°C/113°F Current CPU Temp 45°C/113°F FAN1 Speed 5400 RPM FAN2 Speed 5400 RPM Vcore(V) 1.02 V 12 V 1.32 V
1.8V 1.8V +5V 5.25 V
-12V -12.59
3.3V 3.37V VBAT (V) 3.21 V 5VSB(V) 5.67 V 1st Smart Fan Temperature Disabled
2st
Smart Fan Temperature Disabled
CPU Warning Temperature
This field allows the user to set the temperature so that when the temperature is reached, the system sounds a warning. This function can help prevent damage to the system that is caused by overheating.
Temperatures/Voltages
These fields are the parameters of the hardware monitoring function feature of the motherboard. The values are read-only values as monitored by the system and show the PC health status.
Shutdown Temperature
This field allows the user to set the temperature by which the system automatically shuts down once the threshold temperature is reached. This function can help prevent damage to the system that is caused by overheating.
1st 2st Smart Fan Temperature
This field enables or disables the smart fan feature. At a certain temperature, the fan starts turning. Once the temperature drops to a certain level, it stops turning again.
Phoenix - AwardBIOS CMOS Setup Utility
PC Health Status
Menu Level >
ITEM HELP
46 MI910 User’s Manual
BIOS SETUP
Frequency/Voltage Control
This section shows the user how to configure the processor frequency.
Auto Detect PCI Clk Spread Spectrum Modulated
Auto Detect PCI Clk
This field enables or disables the auto detection of the PCI clock.
Spread Spectrum Modulated
This field sets the value of the spread spectrum. The default setting is Disabled. This field is for CE testing use only
Phoenix - AwardBIOS CMOS Setup Utility
Frequency/Voltage Control
Disabled ITEM HELP Disabled Menu Level >
.
MI910 User’s Manual 47
BIOS SETUP
Load Fail-Safe Defaults
This option allows you to load the troubleshooting default values permanently stored in the BIOS ROM. These default settings are non-optimal and disable all high-performance features.
Load Optimized Defaults
This option allows you to load the default values to your system configuration. These default settings are optimal and enable all high performance features.
Set Supervisor Password
These two options set the system password. Supervisor Password sets a password that will be used to protect the system and Setup utility. User Password sets a password that will be used exclusively on the system. To specify a password, highlight the type you want and press <Enter>. The Enter Password: message prompts on the screen. Type the password, up to eight characters in length, and press <Enter>. The system confirms your password by asking you to type it again. After setting a password, the screen automatically returns to the main screen.
To disable a password, just press the <Enter> key when you are prompted to enter the password. A message will confirm the password to be disabled. Once the password is disabled, the system will boot and you can enter Setup freely.
Save & Exit Setup
This option allows you to determine whether or not to accept the modifications. If you type “Y”, you will quit the setup utility and save all changes into the CMOS memory. If you type “N”, you will return to Setup utility.
Exit Without Saving
Select this option to exit the Setup utility without saving the changes you have made in this session. Typing “Y” will quit the Setup utility without saving the modifications. Typing “N” will return you to Setup utility.
48 MI910 User’s Manual
DRIVERS INSTALLATION
Drivers Installation
This section describes the installation procedures for software and drivers under the Windows 2000 and Windows XP. The software and drivers are included with the motherboard. If you fi nd the items m issing, please contact the vendor where you made the purchase. The content s of this section include the following:
Intel Chipset Software Installation Utility ................................. 50
VGA Drivers Installation........................................................... 52
AC97 Codec Audio Driver Installation ..................................... 54
LAN Drivers Installation ........................................................... 55
IMPORTANT NOTE:
After installing your Windows operating system (Windows 2000/ XP), you must install first the Intel Chipset Software Installation Utility before proceeding with the drivers installation.
MI910 User’s Manual 49
DRIVER INSTALLATION
Intel Chipset Software Installation Utility
The Intel Chipset Drivers should be installed first before the software drivers to enable Plug & Play INF support for Intel chipset components. Follow the instructions below to complete the installation under Windows 2000/XP.
1. Insert the CD that comes with the board. Click Intel Chipsets and then Intel(R)GM 965Chipset Drivers.
2. Click Intel(R) Chipset Software Installation Utility.
3. When the Welcome screen appears, click Next to continue.
50 MI910 User’s Manual
DRIVERS INSTALLATION
4. Click Yes to accept the software license agreement and proceed with the installation process.
5. On Readme Information screen, click Next to continue the installation.
6. The Setup process is now complete. Click Finish to restart the computer and for changes to take effect. When the computer has restarted, the system will be able to find some devices. Restart your computer when prompted.
MI910 User’s Manual 51
DRIVER INSTALLATION
VGA Drivers Installation
To install the VGA drivers, follow the steps below to proceed with the installation.
1. Insert the CD that comes with the motherboard. Click Intel Chipsets and then Intel(R) GM965Chipset Drivers.
2. Click Intel(R) GM965Chipset Family Graphics Driver.
3. When the Welcome screen appears, click Next to continue.
52 MI910 User’s Manual
DRIVERS INSTALLATION
4. Click Yes to to agree with the license agreement and continue the installation.
5. Restart the computer as promted and for changes to take effect.
IMPORTANT NOTE: When you have restarted the computer, your computer screen will be blank. At this point, press CTRL-ALT-F1 simultaneously, if you are using CRT monitor. If you are using LVDS LCD panel, press CTRL-ALT-F3. If you are using DVI monitor, press CTRL-ALT-F4.
MI910 User’s Manual 53
DRIVER INSTALLATION
AC97 Codec Audio Driver Installation
Follow the steps below to install the Realtek AC97 Codec Audio Drivers.
1. Insert the CD that comes with the motherboard. Click Intel Chipsets and then Intel(R) GM965Chipset Drivers.
2. Click Realtek AC'97 Codec Audio Driver.
3. Click Finish to restart the computer and for changes to take effect. .
54 MI910 User’s Manual
DRIVERS INSTALLATION
LAN Drivers Installation
Follow the steps below to complete the installation of the Intel PRO LAN drivers.
1. Insert the CD that comes with the motherboard. Click Intel Chipsets and then Intel(R) GM965Chipset Drivers, then Intel(R) PRO LAN Network Drivers.
2. Click Install Base Software to continue.
3. When prompted, please to restart the computer for new settings to take effect.
MI910 User’s Manual 55
DRIVER INSTALLATION
Follow the steps below to install the Marvell Gigabit LAN drivers.
1. Insert the CD that comes with the motherboard. Click LAN Card and then Marvell LAN Controller Driver.
2. Click Next when the InstallShield Wizard welcome screen appears.
3. Click Next to agree with the license agreement.
4. Click Next when the Readme Information screen appears to proceed with the drives installation process.
5. When the Installation is complete, click Finish for the changes to take effect.
56 MI910 User’s Manual
APPENDIX
Appendix
A. I/O Port Address Map
Each peripheral device in the system is assigned a set of I/O port addresses which also becomes the identity of the device. The fo llowing table lists the I/O port addresses used.
Address Device Description
000h - 01Fh DMA Controller #1 020h - 03Fh Interrupt Controller #1 040h - 05Fh Timer 060h - 06Fh Keyboard Controller 070h - 07Fh Real Time Clock, NMI 080h - 09Fh DMA Page Register 0A0h - 0BFh Interrupt Controller #2 0C0h - 0DFh DMA Controller #2 0F0h Clear Math Coprocessor Busy Signal 0F1h Reset Math Coprocessor 1F0h - 1F7h IDE Interface 278 - 27F Parallel Port #2(LPT2) 2F8h - 2FFh Serial Port #2(COM2) 2B0 - 2DF Graphics adapter Controller 378h - 3FFh Parallel Port #1(LPT1) 360 - 36F Network Ports 3B0 - 3BF Monochrome & Printer adapter 3C0 - 3CF EGA adapter 3D0 - 3DF CGA adapter 3F0h - 3F7h Floppy Disk Controller 3F8h - 3FFh Serial Port #1(COM1)
MI910 User’s Manual 57
APPENDIX
B. Interrupt Request Lines (IRQ)
Peripheral devices use interrupt request lines to notify CPU for the service required. The following table shows the IRQ used by t he devices on board.
Level Function
IRQ0 System Timer Output IRQ1 Keyboard IRQ2 Interrupt Cascade IRQ3 Serial Port #2 IRQ4 Serial Port #1 IRQ5 Reserved IRQ6 Floppy Disk Controller IRQ7 Parallel Port #1 IRQ8 Real Time Clock IRQ9 Reserved IRQ10 Reserved IRQ11 Reserved IRQ12 PS/2 Mouse IRQ13 80287 IRQ14 Primary IDE IRQ15 Secondary IDE
58 MI910 User’s Manual
APPENDIX
C. Watchdog Timer Configuration
The WDT is used to generate a variety of output signals after a user programmable count. The WDT is suitable for use in the prevention of system lock-up, such as when software becomes trapped in a deadlock. Under these sorts of circumstances, the timer will count to zero and the selected outputs will be driven. Under normal circumstance, the user will restart the WDT at regular intervals before the timer counts to zero.
SAMPLE CODE:
//=========================================================================== // // THIS CODE AND INFORMATION IS PROVIDED "AS IS" WITHOUT WARRANTY OF ANY // KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE // IMPLIED WARRANTIES OF MERCHANTABILITY AND/OR FITNESS FOR A PARTICULAR // PURPOSE. // //=========================================================================== #include <stdio.h> #include <stdlib.h> #include "W627EHF.H" //=========================================================================== int main (int argc, char *argv[]); void copyright(void); void EnableWDT(int); void DisableWDT(void); //=========================================================================== int main (int argc, char *argv[]) { unsigned char bBuf; unsigned char bTime; char **endptr;
copyright();
if (argc != 2) { printf(" Parameter incorrect!!\n"); return 1; }
if (Init_W627EHF() == 0) { printf(" Winbond 83627HF is not detected, program abort.\n"); return 1; } bTime = strtol (argv[1], endptr, 10); printf("System will reset after %d seconds\n", bTime);
EnableWDT(bTime);
return 0; } //===========================================================================
MI910 User’s Manual 59
APPENDIX
void copyright(void) { printf("\n======== Winbond 83627EHF Watch Timer Tester (AUTO DETECT) ========\n"\ " Usage : W627E_WD reset_time\n"\ " Ex : W627E_WD 3 => reset system after 3 second\n"\ " W627E_WD 0 => disable watch dog timer\n"); } //=========================================================================== void EnableWDT(int interval) { unsigned char bBuf;
bBuf = Get_W627EHF_Reg( 0x2D); bBuf &= (!0x01); Set_W627EHF_Reg( 0x2D, bBuf); //Enable WDTO
Set_W627EHF_LD( 0x08); //switch to logic device 8 Set_W627EHF_Reg( 0x30, 0x01); //enable timer
bBuf = Get_W627EHF_Reg( 0xF5); bBuf &= (!0x08); Set_W627EHF_Reg( 0xF5, bBuf); //count mode is second
Set_W627EHF_Reg( 0xF6, interval); //set timer } //=========================================================================== void DisableWDT(void) { Set_W627EHF_LD(0x08); //switch to logic device 8 Set_W627EHF_Reg(0xF6, 0x00); //clear watchdog timer Set_W627EHF_Reg(0x30, 0x00); //watchdog disabled } //===========================================================================
60 MI910 User’s Manual
APPENDIX
//=========================================================================== // // THIS CODE AND INFORMATION IS PROVIDED "AS IS" WITHOUT WARRANTY OF ANY // KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE // IMPLIED WARRANTIES OF MERCHANTABILITY AND/OR FITNESS FOR A PARTICULAR // PURPOSE. // //=========================================================================== #include "W627EHF.H" #include <dos.h> //=========================================================================== unsigned int W627EHF_BASE; void Unlock_W627EHF (void); void Lock_W627EHF (void); //=========================================================================== unsigned int Init_W627EHF(void) { unsigned int result; unsigned char ucDid;
W627EHF_BASE = 0x2E; result = W627EHF_BASE;
ucDid = Get_W627EHF_Reg(0x20); if (ucDid == 0x88) { goto Init_Finish; }
W627EHF_BASE = 0x4E; result = W627EHF_BASE; ucDid = Get_W627EHF_Reg(0x20); if (ucDid == 0x88) { goto Init_Finish; }
W627EHF_BASE = 0x00; result = W627EHF_BASE;
Init_Finish: return (result); } //=========================================================================== void Unlock_W627EHF (void) { outportb(W627EHF_INDEX_PORT, W627EHF_UNLOCK); outportb(W627EHF_INDEX_PORT, W627EHF_UNLOCK); } //=========================================================================== void Lock_W627EHF (void) { outportb(W627EHF_INDEX_PORT, W627EHF_LOCK); } //=========================================================================== void Set_W627EHF_LD( unsigned char LD) { Unlock_W627EHF(); outportb(W627EHF_INDEX_PORT, W627EHF_REG_LD); outportb(W627EHF_DATA_PORT, LD); Lock_W627EHF(); }
MI910 User’s Manual 61
APPENDIX
//=========================================================================== void Set_W627EHF_Reg( unsigned char REG, unsigned char DATA) { Unlock_W627EHF(); outportb(W627EHF_INDEX_PORT, REG); outportb(W627EHF_DATA_PORT, DATA); Lock_W627EHF(); } //=========================================================================== unsigned char Get_W627EHF_Reg(unsigned char REG) { unsigned char Result; Unlock_W627EHF(); outportb(W627EHF_INDEX_PORT, REG); Result = inportb(W627EHF_DATA_PORT); Lock_W627EHF(); return Result; } //===========================================================================
//=========================================================================== // // THIS CODE AND INFORMATION IS PROVIDED "AS IS" WITHOUT WARRANTY OF ANY // KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE // IMPLIED WARRANTIES OF MERCHANTABILITY AND/OR FITNESS FOR A PARTICULAR // PURPOSE. // //=========================================================================== #ifndef __W627EHF_H #define __W627EHF_H 1 //=========================================================================== #define W627EHF_INDEX_PORT (W627EHF_BASE) #define W627EHF_DATA_PORT (W627EHF_BASE+1) //=========================================================================== #define W627EHF_REG_LD 0x07 //=========================================================================== #define W627EHF_UNLOCK 0x87 #define W627EHF_LOCK 0xAA //=========================================================================== unsigned int Init_W627EHF(void); void Set_W627EHF_LD( unsigned char); void Set_W627EHF_Reg( unsigned char, unsigned char); unsigned char Get_W627EHF_Reg( unsigned char); //===========================================================================
#endif //__W627EHF_H
62 MI910 User’s Manual
Loading...
