Intel G52-B1032X1, M645, MS-1032 User Manual
Prefeace
General Introductions Chapter 1
Chapter 2
Getting Started
Chapter 3
Customizing this Notebook
Chapter 4
BIOS setup
G52-B1032X1
II
M645
Regulations Information
FCC-B Radio Frequency Interference Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
w Reorient or relocate the receiving antenna.
Preface
w Increase the separation between the equipment and receiver.
w Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
w Consult the dealer or an experienced radio TV technician for help.
NOTE
1. The changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate the
equipment.
2. Shield interface cables and AC power cord, if any must be used in order
to comply with the emission limits.
III
M645
MS-1032 Micro-Star International
FCC Conditions
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including
interference that may cause undesired operation.
Preface
IV
M645
fabrikat og type.
(English) CAUTION: Danger of explosion if battery is incorrectly replaced.
, jos se on virheellisesti asennettu.
atfabrikanten.
batterityp eller en ekvivalent typ som rekommenderas av apparattillverkaren.
Safety Guideline for Using Lithium Battery
(Danish) ADVARSEL! Lithiumbatteri --- Eksplosionsfare ved fejlagtig
håndtering. Udskiftning må kun ske med batteri af same
Levé det brugte batteri tilbage til leverandøren.
(Deutsch) VORSICHT: Explosionsgefahr bei unsachgemäßem Austausch der
Batterie. Ersatz nur durch denselben oder einen vom Hersteller empfohlenen
gleich-wertigen Typ. Entsorgung gebrauchter Batterien nach Angaben des
Herstellers.
Replace only with the same or equivalent type recommended by the equipment
manufacturer. Discard used batteries according to manufacturer’s instructions.
(Finnish) VAROITUS: Paristo voi räjähtää
Vaihda paristo ainoastaan valmistajan suosittelemaan tyyppiin. Hävitä käytetty
paristo valmistajan ohjeiden mukaisesti.
Preface
(French) ATTENTION: II y a danger d’ex;losion s’il y a remplacement incorrect
de la batterie. Remplacer uniquement avec une batterie du meme type ou d’un
type équivalent recommandé par le constructeur. Mettre au rebut les batteries
usages conformément aux instructions du fabricant.
(Norwegian) ADVARSEL: Eksplosjonsfare ved feilaktig skifte av batteri. Benytt
same batteritype eller en tilsvarende type anbefalt av appar
Brukte batterier kasseres I henhold til fabrikantens instruksjoner.
(Swedish) VARNING: Explosionsfara vid felaktigt batteribyte. Använd samma
Kassera använt batteri enligt fabrikantens instruction.
V
M645
Caution on Using Modem
1. Never install telephone wiring during a lightning storm.
2. Never install telephone jacks in wet locations unless the jack is specifically
designed for wet locations.
3. Never touch uninsulated telephone wires or terminals unless the telephone
line has been disconnected at the network interface.
4. Use caution when installing or modifying telephone lines.
5. Avoid using the telephone function (other than a cordless type) during an
electrical storm. There may be a remote risk of electric shock from
lightning.
6. Do not use the telephone function to report a gas leak in the vicinity of the
leak.
Preface
CD-ROM Drive Notice
CAUTION: This appliance contains a laser system and is classified as a
“CLASS 1 LASER PRODUCT.” To use this model properly, read the instruction
manual carefully and keep this manual for your future reference. In case of any
trouble with this model, please contact your nearest “AUTHORIZED service
station.” To prevent direct exposure to the laser beam, do not try to open the
enclosure.
VI
M645
Wireless LAN Notice
EU (R&TTE)
European Union CE Marking and Compliance Notices
Products intended for sale within the European Union are marked with the
Conformité Européene (CE) Marking, which indicates compliance with the
applicable Directives and European standards and amendments identified below.
This equipment also carries the Class 2 identifier.
Declaration of Conformity (MiniPCI Adapter)
Product Descriptions:
Intel® PRO/Wireless 2200BG Network Connection (model WM3B2200BG)
Preface
Warning: See 802.11b and 802.11g restrictions for specific countries or regions
within countries under the heading “European Economic Area Restrictions”
below.
Translated Statements of Compliance
[English]
This product follows the provisions of the European Directive 1999/5/EC.
[Danish]
Dette produkt er i overensstemmelse med det europæiske direktiv 1999/5/EC
VII
M645
[Dutch]
Dit product is in navolging van de bepalingen van Europees Directief 1999/5/EC.
[Finnish]
Tämä tuote noudattaa EU-direktiivin 1999/5/EC määräyksiä.
[French]
Ce produit est conforme aux exigences de la Directive Européenne 1999/5/EC.
[German]
Dieses Produkt entspricht den Bestimmungen der Europäischen Richtlinie
1999/5/EC
[Greek]
Το προϊόν αυτό πληροί τις προβλέψεις της Ευρωπαϊκής Οδηγίας 1999/5/ΕC.
Preface
[Icelandic]
Þessi vara stenst reglugerð Evrópska Efnahags Bandalagsins númer 1999/5/EC
[Italian]
Questo prodotto è conforme alla Direttiva Europea 1999/5/EC.
[Norwegian]
Dette produktet er i henhold til bestemmelsene i det europeiske direktivet
1999/5/EC.
[Portuguese]
VIII
M645
Este produto cumpre com as normas da Diretiva Européia 1999/5/EC.
[Spanish]
Este producto cumple con las normas del Directivo Europeo 1999/5/EC.
[Swedish]
Denna produkt har tillverkats i enlighet med EG-direktiv 1999/5/EC.
European Economic Area Restrictions
Local Restriction of 802.11b/802.11g Radio Usage
[Note to integrator: The following statements on local restrictions must be
published in all end-user documentation provided with the system or product
incorporating the Intel PRO/Wireless 2200BG Network Connection product.]
Caution: Due to the fact that the frequencies used by 802.11b/802.11g wireless
LAN devices may not yet be harmonized in all countries, 802.11b/802.11g
Preface
products are designed for use only in specific countries or regions, and are not
allowed to be operated in countries or regions other than those of designated
use. As a user of these products, you are responsible for ensuring that the
products are used only in the countries or regions for which they were intended
and for verifying that they are configured with the correct selection of frequency
and channel for the country or region of use. Any deviation from permissible
settings and restrictions in the country or region of use could be an infringement
of local law and may be punished as such.
The European variant is intended for use throughout the European Economic
Area. However, authorization for use is further restricted in particular countries or
IX
M645
regions within countries, as follows:
General
European standards dictate maximum radiated transmit power of 100 mW
effective isotropic radiated power (EIRP) and the frequency range 2400 – 2483.5
MHz.
Belgium
The product may be used outdoors, but for outdoor transmissions over a
distance of 300 m or more, a license from the BIPT is required.
This restriction should be indicated in the manual as follows:
Dans le cas d'une utilisation privé e, à l'extérieur d'un bâtiment, au-dessus d'un
espace public, aucun enregistrement n'est nécessaire pour une distance de
moins de 300m. Pour une distance supérieure à 300m un enregistrement auprès
Preface
de l'IBPT est requise. Pour une utilisation publique à l'extérieur de bâtiments,
une licence de l'IBPT est requise. Pour les enregistrements et licences, veuillez
contacter l'IBPT.
France
For Metropolitan departments:
2.400 - 2.4835 GHz for indoor use.
2.400 -2.454 GHz (channels 1 to 7) for outdoor use.
For Guadeloupe, Martinique, St Pierre et Miquelon, Mayotte:
2.400 - 2.4835 GHz for indoor and outdoor use.
For Reunion, Guyane:
X
M645
2.400 - 2.4835 GHz for indoor use.
2.420 - 2.4835 GHz for outdoor use (channels 5 to 13)
United States
USA and Canada Safety Requirements and Notices
The FCC with its action in ET Docket 93-62 has adopted a safety standard for
human exposure to radio frequency (RF) electromagnetic energy emitted by
FCC certified equipment. The Intel® PRO/Wireless 2200BG Network
Connection products meet the Human Exposure limits found in OET Bulletin 65,
2001, and ANSI/IEEE C95.1, 1992. Proper operation of this radio according to
the instructions found in this manual will result in exposure substantially below
the FCC’s recommended limits.
The following safety precautions should be observed:
Do not touch or move antenna while the unit is transmitting or receiving.
Preface
Do not hold any component containing the radio such that the antenna is very
close or touching any exposed parts of the body, especially the face or eyes,
while transmitting.
Do not operate the radio or attempt to transmit data unless the antenna is
connected; if not, the radio may be damaged.
Use in specific environments:
The use of wireless devices in hazardous locations is limited by the constraints
posed by the safety directors of such environments.
XI
M645
The use of wireless devices on airplanes is governed by the Federal Aviation
Administration (FAA).
The use of wireless devices in hospitals is restricted to the limits set forth by
each hospital.
Antenna use:
In order to comply with FCC RF exposure limits, low gain integrated antennas
should be located at a minimum distance of 20 cm (8 inches) or more from the
body of all persons.
Explosive Device Proximity Warning
Warning: Do not operate a portable transmitter (such as a wireless network
device) near unshielded blasting caps or in an explosive environment unless the
device has been modified to be qualified for such use.
Preface
Antenna Warning
Warning: To comply with the FCC and ANSI C95.1 RF exposure limits, it is
recommended for Intel® PRO/Wireless Network Connections installed in a
desktop or portable computer, that the antenna for this device be installed so as
to provide a separation distance of al least 20 cm (8 inches) from all persons and
that the antenna must not be co-located or operating in conjunction with any
other antenna or radio transmitter. It is recommended that the user limit
exposure time if the antenna is positioned closer than 20 cm (8 inches).
Use On Aircraft Caution
Caution: Regulations of the FCC and FAA prohibit airborne operation of
XII
M645
radio-frequency wireless devices because their signals could interfere with
critical aircraft instruments.
Other Wireless Devices
Safety Notices for Other Devices in the Wireless Network: Refer to the
documentation supplied with wireless Ethernet adapters or other devices in the
wireless network.
USA Radio Frequency Interference Requirements
FCC Regulations Part 15 Declaration of Conformity (DoC)
Intel Corporation declares that the equipment described in this document is
within the requirements of the Code of Federal Regulations listed below:
Title 47 Part 15, Subpart B, Class B for a digital device.
This declaration is based upon the compliance of the Intel PRO/Wireless
Preface
2200BG Network Connection to the above standards. Intel has determined that
the models listed have been shown to comply with the applicable technical
standards if no unauthorized change is made in the equipment and if the
equipment is properly maintained and operated.
These units are identical to the units tested and found acceptable with the
applicable standards. Records maintained by Intel continue to reflect that units
being produced under this Declaration of Conformity, within the variation that can
be expected due to quantity production and tested on a statistical basis, continue
to comply with the applicable technical standards.
XIII
M645
FCC Rules and Regulations - Part 15
This device uses, generates and radiates radio frequency energy. The radio
frequency energy produced by this device is well below the maximum exposure
allowed by the Federal Communications Commission (FCC).
• This device complies with the limits for a Class B digital device
pursuant to Part 15 subpart C of the FCC Rules and Regulations.
Operation is subject to the following two conditions:
• This device may not cause harmful interference.
• This device must accept any interference received, including
interference that may cause undesired operation.
The FCC limits are designed to provide reasonable protection against harmful
interference when the equipment is installed and used in accordance with the
instruction manual and operated in a commercial environment. However, there is
Preface
no guarantee that interference will not occur in a particular commercial
installation, or if operated in a residential area.
If harmful interference with radio or television reception occurs when the device
is turned on, the user must correct the situation at the user’s own expense. The
user is encouraged to try one or more of the following corrective measures:
• Re-orient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that on
which the receiver is connected.
XIV
M645
• Consult the dealer or an experienced radio/TV technician for help.
CAUTION: The Part 15 radio device operates on a non-interference basis with
other devices operating at this frequency. Any changes or modification to said
product not expressly approved by Intel could void the user's authority to operate
this device.
Underwriters Laboratories Inc. (UL) Regulatory Warning
For use in (or with) UL-Listed personal computers or compatible.
Macrovision Notice
This product incorporates copyright protection technology that is protected by
U.S. patents and other intellectual property rights. Use of this copyright
Preface
protection technology must be authorized by Macrovision, and is intended for
home and other limited viewing uses only unless otherwise authorized by
Macrovision. Reverse engineering or disassembly is prohibited.
XV
M645
Safety Instructions
1. Read the safety instructions carefully and thoroughly.
2. Save this User Guide for possible use later.
3. Keep this equipment away from humidity and high temperature.
4. Lay this equipment on a stable surface before setting it up.
5. The openings on the enclosure are used for air convection and to prevent
the equipment from overheating. Do not cover the openings.
6. Make sure that the power voltage is within its safety range and has been
adjusted properly to the value of 100~240V before connecting the
equipment to the power inlet.
7. Place the power cord in a way that people are unlikely to step on it. Do
not place anything on the power cord.
8. Always unplug the power cord before inserting any add-on card or module.
9. All cautions and warnings on the equipment should be noted.
Preface
10. If any of the following situations arises, get the equipment checked by a
service personnel:
w The power cord or plug is damaged.
w Liquid has penetrated into the equipment.
w The equipment has been exposed to moisture.
w The equipment has not worked well or you can not get it work
according to User’s Manual.
w The equipment was dropped and damaged.
w The equipment has obvious signs of breakage.
XVI
M645
11. Never pour any liquid into the opening that could damage the equipment or
cause an electrical shock.
12. Do not leave the equipment in an unconditioned environment with a
storage temperature of 60OC (140OF) or above, which may damage the
equipment.
13. To prevent explosion caused by improper battery replacement, use the
same or equivalent type of battery recommended by the manufacturer only.
Trademarks
All trademarks are the properties of their respective owners.
w Microsoft is a registered trademark of Microsoft Corporation.
Windows®98/ME, 2000/XP are registered trademarks of Microsoft
Corporation.
Preface
w AMI® is a registered trademark of American Megatrends Inc.
w PCMCIA and CardBus are registered trademarks of the Personal
Notebook Memory Card International Association.
Release History
Version Revision Note Date
1.0 First Release May 2005
XVII
M645
Copyright Notice
The material in this guide is the intellectual property of MICRO-STAR
INTERNATIONAL. We take every care in the preparation of this document, but
no guarantee is given as to the correctness of its contents. Our products are
under continual improvement and we reserve the right to make changes without
notice.
Please note that the setting diagrams or values in this guide are FOR YOUR
REFERENCE ONLY. The model you bought may be slightly different from the
illustrations and descriptions in this guide. If you are not sure about these
information, such as the Notebook specification and equipment, please ask your
local vendor for help.
Technical Support
Preface
Visit the MSI website for FAQ, technical guide, driver and software updates, and
other information: http://www.msi.com.tw/.
Contact our technical staff at: support@msi.com.tw.
XVIII
M645
Table of Content
Preface
Regulations Information.....................................................................................II
Safety Guideline for Using Lithium Battery....................................................IV
Caution on Using Modem...................................................................................V
CD-ROM Drive Notice..........................................................................................V
Wireless LAN Notice...........................................................................................VI
Macrovision Notice .......................................................................................XIV
FCC-B Radio Frequency Interference Statement........................................II
FCC Conditions............................................................................................III
EU (R&TTE)..................................................................................................VI
United States.................................................................................................X
Preface
Safety Instructions...........................................................................................XV
Trademarks.......................................................................................................XVI
Release History................................................................................................XVI
Copyright Notice.............................................................................................XVII
Technical Support...........................................................................................XVII
Introductions
How to Use This Manual..................................................................................1-2
Unpacking..........................................................................................................1-4
XIX
M645
Getting Started
Specification......................................................................................................2-2
Product View.....................................................................................................2-6
Top-open View............................................................................................2-6
Front View...................................................................................................2-8
Right-side View.........................................................................................2-10
Left-side View...........................................................................................2-12
Rear View.................................................................................................2-14
Bottom View..............................................................................................2-15
Power Management........................................................................................2-17
AC Adapter................................................................................................2-17
Battery Pack.............................................................................................2-19
Using the Battery Pack.............................................................................2-22
Basic Operations............................................................................................2-24
Preface
Safety and Comfort Tips...........................................................................2-24
Have a Good Work Habit.........................................................................2-25
Knowing the Keyboard.............................................................................2-26
Knowing the Touchpad.............................................................................2-32
About Hard Disk Drive..............................................................................2-36
Using the Optical Storage........................................................................2-37
Using the Video Function.........................................................................2-40
Using the Audio Function.........................................................................2-42
XX
M645
Customizing this Notebook
Connecting the External Devices...................................................................3-2
Connecting the Peripheral Devices...........................................................3-3
Connecting the Communication Devices...................................................3-6
PC Card Installation..........................................................................................3-7
Installing the PC card.................................................................................3-7
Removing the PC card...............................................................................3-8
Safely Remove Hardware.................................................................................3-9
BIOS Setup
About BIOS Setup.............................................................................................4-2
When to Use BIOS Setup..........................................................................4-2
How to Run BIOS Setup.............................................................................4-2
Preface
Control Keys...............................................................................................4-3
BIOS Setup Menu..............................................................................................4-4
Main menu..................................................................................................4-5
Advanced menu..........................................................................................4-7
Security menu.............................................................................................4-9
Boot menu.................................................................................................4-11
Exit menu..................................................................................................4-12
Chapter 2
Chapter 3
Chapter 4
General Introductions Chapter 1
Getting Started
Customizing this Notebook
Prefeace
BIOS setup
1-2
M645
General Introductions
Congratulations on becoming a new user of this notebook, the finely designed
notebook. This brand-new exquisite notebook will give you a delightful and
professional experience in using notebook. We are proud to tell our users that
this notebook is thoroughly tested and certified by our reputation for
unsurpassed dependability and customer satisfaction.
How to Use This Manual
This User’s Manual provides instructions and illustrations on how to operate this
notebook. It is recommended to read this manual carefully before using this
notebook.
Chapter 1, General Introductions, includes the descriptions of all the
accessories of this notebook. It is recommended to check out that if you have
all the accessories included when you open the packing box. If any item is
damaged or missing, please contact the vendor where you purchased this
notebook.
Chapter 2, Getting Started, provides the specification of this notebook, and
introduces the function buttons, quick launch buttons, connectors, LEDs and
externals of this notebook. Also, this chapter instructs the correct procedure of
installing or uninstalling the battery pack, and the brief ideas on how to use this
notebook.
1-3
M645
General Introductions
Chapter 3, Customizing this Notebook, gives instructions not only in
connecting the mouse, keyboard, webcam, printer, external monitor, IEEE 1394
devices, and communication devices, but also in installing and removing the PC
card.
Chapter 4, BIOS setup, provides information on BIOS Setup program and
allows you to configure the system for optimum use.
1-4
M645
General Introductions
Unpacking
First, unpack the shipping carton and check all items carefully. If any item
contained is damaged or missing, please contact your local dealer immediately.
Also, keep the box and packing materials in case you need to ship the unit in the
future.
The package should contain the following items:
w Notebook PC
w User’s Manual or Quick Start Guide
w Software CD containing the drivers and utilities
w Recovery CD
w High-capacity Li-ion battery pack
w AC adapter and power cord
w Phone cable/Phone jack (optional)
w Notebook carry bag (optional)
These accessories listed above may change without notice.
Chapter 2
Chapter 3
Chapter 4
General Introductions Chapter 1
Getting Started
Customizing this Notebook
Prefeace
BIOS setup
2-2
M645
Specification
Physical Characteristic
Dimension 355mm(L) x 255mm(D) x 30mm(H)
Weight 2.7 kg
CPU
Processor Type uFCPGA (479 pin)
Intel® Pentinum® M processor;Intel® Celeron
Support Processor
M processor
L1 Cache 64K
L2 Cache 2MB for Pentinum® M; 1M for Celeron® M
Getting Started
®
FSB Speed
533MHz for Pentinum® M; 400MHz for
Celeron® M
Core Chips
North Bridge Intel ® 915PM
South Bridge Intel ® ICH6-M
Memory
Technology DDR 333/400
Memory DDR SO-DIMM X 2 slots
128/256/512MB DDR SDRAM
Maximum 1GB (512MB DDR SO-DIMM X 2)
Power
AC Adapter 75W, 19 Volt
Battery Type I 8 cells (Li-lon)(4400mAh)
2-3
M645
Battery Type I Life 3.5 hrs for Battery Mark / Mobile Mark, 4.5hrs
for Instant On media play
Getting Started
Battery Type I Life In Stand
by Mode
S3, battery:7days
S4,S5:32~34days
Storage
HDD form factor 9.5mm(High)
IDE Controller Ultra DMA ATA-100
Optical Device CD-ROM/CD-RW/DVD-ROM/COMBO/ DVD
dual
I/O Port
Monitor(VGA) 15 pin Mini D-Sub x 1
USB x 4 (USB version 2.0)
Headphone Out x 1
Mic-in x 1
Comsumer IR x 1
TV-Out x 1
RJ11 x 1
RJ45 x 1
IEEE1394 x 1
Communication Port
56K Fax/MODEM
MDC (AC’97)
I/F --- AC97 S/W Modem
Controller --- AC 97 Embedded
Wake on Ring --- Support on S1/S2/S3
PTT Approval --- Yes (FCC/CTR21/JATE)
Loading...
