Intel® Desktop Boards D850MD and D850MV Product Guide

Order Number: A57861-001

Revision History

Revision Revision History Date

-001 First release of the Intel® Desktop Boards D850MD and D850MV

Product Guide.

If an FCC declaration of conformity marking is present on the board, the following statement applies:

FCC Declaration of Conformity

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

For questions related to the EMC performance of this product, contact:

Intel Corporation 5200 N.E. Elam Young Parkway Hillsboro, OR 97124 1-800-628-8686

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and the receiver.

• Connect the equipment to an outlet on a circuit other than the one to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Canadian Department of Communications Compliance Statement

This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications.

Le présent appareil numerique német pas de bruits radioélectriques dépassant les limites applicables aux appareils numériques de la classe B prescrites dans le Réglement sur le broullage radioélectrique édicté par le ministére des Communications du Canada.

Disclaimer

INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH INTEL PROVIDED IN INTEL'S TERMS AND CONDITIONS OF SALE FOR SUCH PRODUCTS, INTEL ASSUMES NO LIABILITY WHATSOEVER, AND INTEL DISCLAIMS ANY EXPRESS OR IMPLIED WARRANTY, RELATING TO SALE AND/OR USE OF INTEL PRODUCTS INCLUDING LIABILITY OR WARRANTIES RELATING TO FITNESS FOR A PARTICULAR PURPOSE, MERCHANTABILITY, OR INFRINGEMENT OF ANY PATENT, COPYRIGHT, OR OTHER INTELLECTUAL PROPERTY RIGHT.

Intel Corporation may have patents or pending patent applications, trademarks, copyrights, or other intellectual property rights that relate to the presented subject matter. The furnishing of documents and other materials and information does not provide any license, express or implied, by estoppel or otherwise, to any such patents, trademarks, copyrights, or other intellectual property rights.

Intel products are not designed, intended or authorized for use in any medical, life saving, or life sustaining applications or for any other application in which the failure of the Intel product could create a situation where personal injury or death may occur.

Intel may make changes to specifications, product descriptions, and plans at any time, without notice.

The D850MD and D850MV desktop boards may contain design defects or errors known as errata which may cause the product to deviate from published specifications. Current characterized errata are available on request.

Contact your local Intel sales office or your distributor to obtain the latest specifications and before placing your product order.

Copies of documents which have an ordering number and are referenced in this document, or other Intel literature, may be obtained from Intel Corporation by going to the World Wide Web site at:

Intel and Pentium are registered trademarks of Intel Corporation or it subsidiaries in the United States and other countries.

†

Other names and brands may be claimed as the property of others.

http://www.intel.com/ or by calling: 1-800-548-4725.



PRODUCTS. . EXCEPT AS

July 2001

1 Desktop Board Features

Board Components .............................................................................................................. 9

Processor........................................................................................................................... 11

Main Memory .....................................................................................................................12

850 Chipset .............................................................................................................. 12

Intel

82850 Memory Controller Hub (MCH).............................................................. 12

Intel

82801BA I/O Controller Hub (ICH2) ................................................................. 13

Intel

Firmware Hub (FWH)................................................................................................. 13

Input/Output (I/O) Controller............................................................................................... 13

Real-Time Clock.................................................................................................................13

USB Support ...................................................................................................................... 14

PCI Enhanced IDE Interface .............................................................................................. 14

Expansion Slots.................................................................................................................. 14

AGP Connector ......................................................................................................... 15

Communication and Networking Riser (CNR) (Optional) ........................................... 15

Audio Subsystem ............................................................................................................... 15

BIOS .................................................................................................................................. 15

PCI Auto Configuration.............................................................................................. 15

IDE Auto Configuration.............................................................................................. 16

Security Passwords ................................................................................................... 16

LAN Subsystem (Optional)................................................................................................. 17

LAN Subsystem Software.......................................................................................... 17

RJ-45 LAN Connector LEDs...................................................................................... 17

Speaker.............................................................................................................................. 17

Battery................................................................................................................................ 17

Power Management Features ............................................................................................ 18

Instantly Available Technology .................................................................................. 18

Resume on Ring........................................................................................................ 20

2 Installing and Replacing Desktop Board Components

Before You Begin ............................................................................................................... 21

Installing the I/O Shield.......................................................................................................22

Installing and Removing the Desktop Board....................................................................... 23

Installing and Removing a Processor ................................................................................. 25

Installing the Processor Fan Heatsink Retention Mechanism Base ........................... 25

Installing a Processor ................................................................................................ 27

Installing the Processor Fan Heatsink........................................................................ 27

Connecting the Processor Fan Cable ........................................................................ 28

Removing a Processor .............................................................................................. 28

Installing and Removing Memory ....................................................................................... 29

Installing Memory ...................................................................................................... 29

Removing Memory .................................................................................................... 31

iii

Intel Desktop Boards D850MD and D850MV Product Guide

Installing and Removing an AGP Card Retention Mechanism and Card ............................ 32

Installing the AGP Card Retention Mechanism.......................................................... 32

Installing an AGP Card .............................................................................................. 34

Removing the AGP Card from the Retention Mechanism .......................................... 34

Removing the AGP Card Retention Mechanism ........................................................ 35

Connecting the IDE Cable.................................................................................................. 36

Setting the BIOS Configuration Jumper.............................................................................. 37

Clearing Passwords............................................................................................................ 38

Replacing the Battery ......................................................................................................... 39

3 Updating the BIOS

Updating the BIOS with the Intel® Express BIOS Update Utility ......................................... 43

Updating the BIOS with the Intel

Flash Memory Update Utility ......................................... 43

Obtaining the BIOS Update File................................................................................. 43

Updating the BIOS..................................................................................................... 44

Recovering the BIOS................................................................................................. 44

4 Using the Setup Program

Maintenance Menu............................................................................................................. 48

Extended Configuration Submenu............................................................................. 49

Main Menu ......................................................................................................................... 50

Advanced Menu ................................................................................................................. 51

PCI Configuration Submenu...................................................................................... 52

Boot Configuration Submenu..................................................................................... 53

Peripheral Configuration Submenu............................................................................ 54

IDE Configuration Submenu...................................................................................... 56

Primary/Secondary IDE Master/Slave Submenus...................................................... 57

Diskette Configuration Submenu ............................................................................... 58

Event Log Configuration Submenu............................................................................ 59

Video Configuration Submenu................................................................................... 59

Security Menu .................................................................................................................... 60

Power Menu....................................................................................................................... 61

APM Submenu .......................................................................................................... 62

ACPI Submenu.......................................................................................................... 62

Boot Menu.......................................................................................................................... 63

Boot Device Priority ................................................................................................... 63

Exit Menu ........................................................................................................................... 64

5 Technical Reference

Board Connectors .............................................................................................................. 65

Back Panel Connectors ............................................................................................. 66

Midboard Connectors ................................................................................................ 67

Audio Connectors.............................................................................................. 67

Power and Hardware Connectors ..................................................................... 68

Add-In Card and Peripheral Interface Connectors............................................. 70

Front Panel Connectors............................................................................................. 72

Desktop Board Resources.................................................................................................. 73

Memory Map ............................................................................................................. 73

DMA Channels .......................................................................................................... 73

I/O Map ..................................................................................................................... 74

Interrupts ................................................................................................................... 76

A Error Messages and Indicators

BIOS Beep Codes.............................................................................................................. 77

BIOS Error Messages ........................................................................................................ 78

B Regulatory Compliance

Safety Regulations ............................................................................................................. 81

EMC Regulations ............................................................................................................... 81

Product Certification Markings............................................................................................ 82

Installation Precautions ...................................................................................................... 83

Installation Instructions.......................................................................................................83

Ensure Electromagnetic Compatibility (EMC) Compliance......................................... 83

Chassis and Component Certifications ...................................................................... 84

Prevent Power Supply Overload................................................................................ 84

Place Battery Marking................................................................................................ 84

Use Only for Intended Applications............................................................................ 85

Contents

Figures

1. D850MD Board Components ......................................................................................... 9

2. D850MV Board Components ....................................................................................... 10

3. Location of Standby Power Indicator............................................................................ 19

4. Installing the I/O Shield................................................................................................ 22

5. D850MD Board Mounting Screw Holes........................................................................ 23

6. D850MV Board Mounting Screw Holes........................................................................ 24

7. Location of the Processor Fan Heatsink Base Mounting Holes.................................... 25

8. Installing the Processor Fan Heatsink RM Base to the Board ...................................... 26

9. Installing a Processor................................................................................................... 27

10. Connecting the Processor Fan Cable to the Processor Fan Connector ....................... 28

11. RDRAM and CRIMM Installation.................................................................................. 29

12. RIMM Installation ......................................................................................................... 30

13. Installing a Memory Module ......................................................................................... 31

14. AGP Card with a Retention Notch................................................................................ 32

15. Installing the AGP Card Retention Mechanism ............................................................ 33

16. Removing the AGP Card.............................................................................................. 34

17. Removing the AGP Card Retention Mechanism .......................................................... 35

18. Connecting the IDE Cable............................................................................................ 36

19. Location of the BIOS Configuration Jumper................................................................. 37

20. Removing the Battery .................................................................................................. 41

21. Back Panel Connectors................................................................................................ 66

22. Audio Connectors ........................................................................................................ 67

23. D850MD Board Power and Hardware Control Connectors .......................................... 68

24. D850MV Board Power and Hardware Control Connectors........................................... 69

25. D850MD Board Add-in Card and Peripheral Interface Connectors .............................. 70

Intel Desktop Boards D850MD and D850MV Product Guide

26. D850MV Board Add-in Card and Peripheral Interface Connectors............................... 71

27. Front Panel Connectors ............................................................................................... 72

Tables

1. Feature Summary.......................................................................................................... 7

2. Processors Supported by the Desktop Board .............................................................. 11

3. RJ-45 LAN Connector LEDs ........................................................................................ 17

4. Standby Current Requirements.................................................................................... 20

5. Jumper Settings for the BIOS Setup Program Modes (J9H2) ...................................... 37

6. BIOS Setup Program Menu Bar................................................................................... 47

7. BIOS Setup Program Function Keys............................................................................ 48

8. Maintenance Menu ...................................................................................................... 48

9. Extended Configuration Submenu ............................................................................... 49

10. Main Menu................................................................................................................... 50

11. Advanced Menu........................................................................................................... 51

12. PCI Configuration Submenu ........................................................................................ 52

13. Boot Configuration Submenu ....................................................................................... 53

14. Peripheral Configuration Submenu .............................................................................. 54

15. IDE Configuration Submenu ........................................................................................ 56

16. Primary/Secondary IDE Master/Slave Submenus........................................................ 57

17. Diskette Configuration Submenu.................................................................................. 58

18. Event Log Configuration Submenu .............................................................................. 59

19. Video Configuration Submenu ..................................................................................... 59

20. Security Menu.............................................................................................................. 60

21. Power Menu................................................................................................................. 61

22. APM Submenu............................................................................................................. 62

23. ACPI Submenu ............................................................................................................ 62

24. Boot Menu ................................................................................................................... 63

25. Boot Device Priority ..................................................................................................... 63

26. Exit Menu..................................................................................................................... 64

27. System Memory Map................................................................................................... 73

28. DMA Channels............................................................................................................. 73

29. I/O Map........................................................................................................................ 74

30. Interrupts ..................................................................................................................... 76

31. Beep Codes................................................................................................................. 77

32. BIOS Error Messages.................................................................................................. 78

33. Safety Regulations....................................................................................................... 81

34. EMC Regulations......................................................................................................... 81

1 Desktop Board Features

NOTE

✏

The D850MD board layout was used for illustrations unless otherwise noted.

Table 1 describes the major features of the D850MD and D850MV boards.

Table 1. Feature Summary

Form Factors

Processor

Memory

Chipset

I/O Control LAN

Graphics Audio

Peripheral Interfaces

Expansion Capabilities

• microATX at 9.6 inches by 9.6 inches (D850MD board)

• ATX at 9.6 inches by 12 inches (D850MV board)

• Support for an Intel

• 400 MHz system data bus

• Four 168-pin Direct Rambus† RIMM† sockets

• Support for up to 2 GB of system memory

Intel

850 chipset, consisting of:

• Intel

• 4 Mbit Firmware Hub (FWH)

SMSC LPC47M142 I/O controller

Optional Intel RJ-45 connector

AGP connector supporting 1.5 V 4X or 2X AGP cards

Analog Devices Inc. AD1885 analog codec (AC ’97) featuring SoundMAX software support

• Up to seven Universal Serial Bus (USB) ports

• Two IDE interfaces with Ultra DMA-33 and ATA-66/100 support

• One floppy drive interface

• One parallel port

• Two serial ports

• PS/2

D850MD board:

• Three PCI bus add-in card connectors

• One AGP connector

• One optional CNR connector (slot shared with PCI bus connector 3)

D850MV board:

• Five PCI bus add-in card connectors

• One AGP connector

• One optional CNR connector (slot shared with PCI bus connector 5)

82850 Memory Controller Hub (MCH) with Accelerated Hub Architecture

(AHA) bus

82801BA I/O Controller Hub (ICH2) with AHA bus

82562ET 10/100 Mbit/sec Platform LAN Connect (PLC) device and

 Four ports routed to the back panel

 Two ports routed to the front panel USB connector  One port routed to the optional CNR

†

keyboard and mouse ports

Pentium® 4 processor in an mPGA-478 socket

†

with SPX

†

continued

Intel Desktop Boards D850MD and D850MV Product Guide

Table 1. Feature Summary (continued)

BIOS

Power Management

Management Features

Instantly Available PC

Other Features

• Intel/AMI BIOS

• 4 Mbit symmetrical flash memory

• Support for SMBIOS

• Support for Advanced Configuration and Power Interface (ACPI 1.0)

• Support for Advanced Power Management (APM 1.2)

• Support for Plug and Play (PnP)

Hardware monitor with

• Two fan sensing inputs used to monitor fan activity

• Remote diode temperature sensing

• Voltage sensing to detect out of range values

• Support for PCI Local Bus Specification Revision 2.2

• Suspend to RAM (STR) support

• Wake on USB, PCI, CNR, RS-232, PS/2, LAN, and front panel

• SCSI hard drive activity LED connector for the front panel

• Speaker

NOTE

✏

For information about Intel® desktop boards, including technical product specifications, BIOS updates, and device drivers, go to the Intel World Wide Web site at:

http://support.intel.com/support/motherboards/desktop

Board Components

Figure 1 shows the location of the major components on the D850MD board.

B DA

Desktop Board Features

I J

Z Y

U S

A ADI AD1885 audio codec P Primary IDE connector B Auxiliary line-in connector (ATAPI) Q Secondary IDE connector C AGP connector R Front panel USB connector D CD-ROM connector (ATAPI) S Alternate power/sleep LED connector E Front panel audio connector T Front panel connector F Chassis intrusion connector U Chassis fan connector (fan 2)

G Back panel connectors V Battery H ATX12V processor core voltage connector W Speaker I Processor fan connector (CPU fan)

(tachometer input) J Intel 82850 Memory Controller Hub (MCH) Y SCSI hard drive activity LED connector K Processor socket Z Intel 82801BA I/O Controller Hub (ICH2) L RIMM sockets AA PCI bus add-in card connectors M RIMM fan connector (fan 1) BB Communication and Networking Riser (CNR) N Power connector (optional) O Floppy drive connector

X BIOS configuration jumper

(tachometer input)

NV T

OM11828

Figure 1. D850MD Board Components

Intel Desktop Boards D850MD and D850MV Product Guide

Figure 2 shows the location of the major components on the D850MV board.

B DA

U S

NV T

OM12073

(tachometer input) G Back panel connectors V Battery H ATX12V processor core voltage connector W Speaker I Processor fan connector (CPU fan)

X BIOS configuration jumper

Figure 2. D850MV Board Components

Desktop Board Features

Processor

CAUTION

Failure to use an ATX12V power supply, or not connecting the additional power supply lead to the D850MD or D850MV boards may result in damage to the desktop board and/or power supply.

The board supports a single Intel Pentium 4 processor. Processors are not included with the board and must be purchased separately.

The processor connects to the board through the mPGA 478-pin socket. The Pentium 4 processor may be removed and replaced to accommodate supported higher speed processors.

For instructions on how to install a processor, see Chapter 2 on page 21.

The board supports the processors listed in Table 2.

Table 2. Processors Supported by the Desktop Board

Type

Intel Pentium 4 processor in a mPGA-478 package

Designation

1.4, 1.5, 1.6, 1.7, and

1.8 GHz

System Bus Frequency L2 Cache Size

400 MHz 256 KB

For the latest information on processor support for the D850MD and D850MV boards, refer to the Intel desktop board World Wide Web site at:

http://support.intel.com/support/motherboards/desktop

For instructions on installing or upgrading the processor, see Chapter 2 on page 21.

The D850MD and D850MV boards require an ATX12V compliant power supply to function according to desktop board specifications. Both boards have two ATX12V compliant power supply connectors that are needed to provide extra power to the Intel 850 chipset and Pentium 4 processor.

Items B and E in Figure 23 on page 68 and items C and F in Figure 24 on page 69 show the two power connector locations.

Intel Desktop Boards D850MD and D850MV Product Guide

Main Memory

The board has four 2.5 V memory module sockets that support RIMMs containing Direct Rambus DRAM (RDRAM) devices.

The board supports the following memory features:

• Maximum of 32 RDRAM devices per channel

• 128 MB (minimum) to 2 GB (maximum) onboard capacity utilizing 128/144 Mbit or

256/288 Mbit technology

• Single- or double-sided RIMM modules

• PC600 or PC800 compliant RDRAM

• Serial Presence Detect (SPD) memory only

NOTE

✏

For information about vendors that support these memory requirements, refer to the D850MD or D850MV link on this Intel World Wide Web site:

http://support.intel.com/support/motherboards/desktop

For information about installing memory, see Chapter 2 on page 21.

Intel® 850 Chipset

The Intel 850 chipset consists of the following devices:

• Intel 82850 Memory Controller Hub (MCH) with AHA bus

• Intel 82801BA I/O Controller Hub (ICH2) with AHA bus

• Firmware Hub (FWH)

Intel® 82850 Memory Controller Hub (MCH)

The MCH has these features:

• Integrated dual Direct Rambus technology memory channel

• Support for 128 MB to 2 GB main system memory

• Auto-detection of RDRAM memory

• Support for a single AGP device

Desktop Board Features

Intel® 82801BA I/O Controller Hub (ICH2)

The ICH2 has these features:

• Integrated Intel® Ethernet LAN MAC (external PLC required)

• Support for the PCI interface

• Support for the Low Pin Count (LPC) interface

• Integrated IDE controller

• Support for USB

• Support for CNR

• General purpose I/O

• Power management logic

• Support for the System Management Bus

• Real-Time Clock

• Support for AC ’97 audio devices and modems

Firmware Hub (FWH)

The FWH has these features:

• System BIOS

• System security and manageability logic that enables protection for storing and updating of

platform information

Input/Output (I/O) Controller

The SMSC LPC47M142 LPC bus I/O controller features the following:

• Low pin count (LPC) interface

• 3.3 V operation

• Two serial ports

• One parallel port with Extended Capabilities Port (ECP) and Enhanced Parallel Port

(EPP) support

• Serial IRQ interface compatible with serialized IRQ support for PCI systems

• PS/2 mouse and keyboard interfaces

• Interface for one 1.2 MB, 1.44 MB, or 2.88 MB diskette drive

• Intelligent power management, including a programmable wake up event interface

• PCI power management support

• Two fan tachometer inputs

Real-Time Clock

The desktop boards have a time-of-day clock and 100-year calendar. A battery on the desktop board keeps the clock current when the computer is turned off.

Intel Desktop Boards D850MD and D850MV Product Guide

USB Support

The boards suppport up to seven USB ports; four ports routed to the back panel, two to the front panel connector, and one to the optional CNR. You can connect seven USB peripheral devices directly to the computer without an external hub. To attach additional devices, connect an external hub to either of the built-in ports. The board supports the standard universal host controller interface (UHCI) and takes advantage of standard software drivers written to be compatible with UHCI.

NOTE

✏

Computer systems that have an unshielded cable attached to a USB port might not meet FCC Class B requirements, even if no device or a low-speed USB device is attached to the cable. Use a shielded cable that meets the requirements for a full-speed USB device.

PCI Enhanced IDE Interface

The ICH2’s IDE interface handles the exchange of information between the processor and

†

peripheral devices like hard disks, CD-ROM drives, and Iomega Zip The interface supports:

• Up to four IDE devices (such as hard drives)

• ATAPI devices (such as CD-ROM drives)

• PIO Mode 3 and PIO Mode 4 devices

• Ultra DMA-33 and ATA-66/100 protocol

• Laser servo (LS-120) drives

drives inside the computer.

Expansion Slots

The D850MD board has:

• Three PCI bus add-in card connectors (PCI bus connector 3 slot shared with CNR)

• One AGP connector

• One optional CNR connector (slot shared with PCI bus connector 3)

The D850MV board has:

• Five PCI bus add-in card connectors (PCI bus connector 5 slot shared with CNR)

• One AGP connector

• One optional CNR connector (slot shared with PCI bus connector 5)

Desktop Board Features

AGP Connector

NOTE

✏

The boards are compatible with 1.5 V AGP cards only.

AGP is a high-performance interface for graphics-intensive applications such as 3D graphics. AGP is independent of the PCI bus and is intended for use with graphical display devices. The AGP connector supports 1.5 V AGP 4X and 2X add-in cards.

An AGP card retention mechanism (RM) may be included with the boxed desktop board to be used only with cards with retention notches (see Figure 14 on page 32).

For information about installing the AGP card RM and an AGP card, see Chapter 2 on page 21.

Communication and Networking Riser (CNR) (Optional)

The CNR provides an interface that supports various features such as audio, modem, USB, and LAN interfaces of the Intel 850 chipset.

Audio Subsystem

The AC ’97 compliant audio subsystem consists of the following:

• Intel 82801BA I/O Controller Hub (ICH2)

• Analog Devices Inc. AD1885 analog codec

NOTE

✏

The audio line out connector, located on the back panel, is designed to power either headphones or amplified speakers only. Poor audio quality may occur if passive (non-amplified) speakers are connected to this output.

Audio drivers and utilities are available from Intel’s World Wide Web site:

http://support.intel.com/support/motherboards/desktop

BIOS

The BIOS provides the Power-On Self-Test (POST), the BIOS Setup program, the PCI and IDE auto-configuration utilities, and the video BIOS. The BIOS is stored in the Firmware Hub. The BIOS can be updated by following the instructions in Chapter 3 on page 43.

PCI Auto Configuration

If you install a PCI add-in card in your computer, the PCI auto-configuration utility in the BIOS automatically detects and configures the resources (IRQs, DMA channels, and I/O space) for that add-in card. You do not need to run the BIOS Setup program after you install a PCI add-in card.

Intel Desktop Boards D850MD and D850MV Product Guide

IDE Auto Configuration

If you install an IDE device (such as a hard drive) in your computer, the IDE auto-configuration utility in the BIOS automatically detects and configures the device for your computer. You do not need to run the BIOS Setup program after installing an IDE device. You can override the autoconfiguration options by specifying manual configuration in the BIOS Setup program.

To use ATA-66/100 features, the following items are required:

• An ATA-66/100 peripheral device

• An ATA-66/100 compatible cable

• ATA-66/100 operating system device drivers

Security Passwords

The BIOS includes security features that restrict whether the BIOS Setup program can be accessed and who can boot the computer. A supervisor password and a user password can be set for the Setup and for booting the computer, with the following restrictions:

• The supervisor password gives unrestricted access to view and change all Setup options. If

only the supervisor password is set, pressing <Enter> at the password prompt of Setup gives the user restricted access to Setup.

• If both the supervisor and user passwords are set, you must enter either the supervisor

password or the user password to access Setup. Setup options are then available for viewing and changing depending on whether the supervisor or user password was entered.

• Setting a user password restricts who can boot the computer. The password prompt is

displayed before the computer is booted. If only the supervisor password is set, the computer boots without asking for a password. If both passwords are set, you can enter either password to boot the computer.

Desktop Board Features

LAN Subsystem (Optional)

The optional Intel 82562ET (in conjunction with the Intel 82801BA ICH2) provides a Fast Ethernet PCI LAN subsystem providing both 10Base-T and 100Base-TX connectivity. Features include:

• 32-bit, 33-MHz direct bus mastering on the PCI bus

• Shared memory structure in the host memory that copies data directly to/from host memory

• A single RJ-45 connector with connection and activity status LEDs

• Jumperless configuration; the LAN subsystem is completely software configurable

LAN Subsystem Software

For Intel 82562ET Fast Ethernet PCI LAN software and drivers, refer to the D850MD and D850MV link on Intel’s World Wide Web site at:

http://support.intel.com/support/motherboards/desktop

RJ-45 LAN Connector LEDs

Two LEDs are built into the RJ-45 LAN connector. Table 3 describes the LED states when the board is powered up and the LAN subsystem is operating.

Table 3. RJ-45 LAN Connector LEDs

LED Color LED State Indicates

Off 10 Mbit/sec data rate is selected.Green

On 100 Mbit/sec data rate is selected.

Yellow

Off LAN link is not established.

On (steady state) LAN link is established.

On (brighter and pulsing) The computer is communicating with another computer on

the LAN.

Speaker

A 47 Ω inductive speaker is mounted on the desktop board. The speaker provides audible error code (beep code) information during the Power-On Self-Test (POST).

Battery

A battery on the board keeps the values in CMOS RAM and the clock current when the computer is turned off.

See Chapter 2 on page 21 for instructions on how to replace the battery.

Intel Desktop Boards D850MD and D850MV Product Guide

Power Management Features

Power management is implemented at several levels, including:

• Software support:  Advanced Configuration and Power Interface (ACPI)  Advanced Power Management (APM)

• Hardware support:  Instantly Available technology  Resume on Ring  Wake from USB  Wake from PS/2 keyboard  PCI card wakeup support

If the board is used with an ACPI-aware operating system, the BIOS can provide ACPI support. Otherwise, it defaults to APM support.

Instantly Available Technology

CAUTION

For Instantly Available technology, the 5 V standby line for the power supply must be capable of providing adequate +5 V standby current. Failure to provide adequate standby current when using this feature can damage the power supply and/or affect ACPI S3 sleep state functionality.

CAUTION

If the standby current necessary to support multiple wake events from the PCI and/or USB buses exceeds power supply capacity, the desktop board may lose register settings stored in memory.

Instantly Available technology enables the board to enter the ACPI S3 (Suspend-to-RAM) sleep state. While in the S3 sleep state, the computer will appear to be off. When signaled by a wake-up device or event, the system quickly returns to its last known awake state.

The board’s standby power indicator, shown in Figure 3 on page 19, is lit when there is standby power to the system. This includes the memory modules and PCI bus connectors even when the computer appears to be off.

If the system has a dual-colored power LED on the front panel, the sleep state is indicated by the LED turning amber.

CR7F1

Desktop Board Features

OM11834

Figure 3. Location of Standby Power Indicator

Power supplies used with this board must be able to provide enough standby current to support the standard Instantly Available (ACPI S3 sleep state) configuration as outlined in Table 4. Values are determined by specifications such as PCI 2.2. Actual measurements may vary.

To estimate the total amount of standby current required for a particular system configuration, standby current requirements of all installed components must be added. Refer to the descriptions in Table 4 on page 20 and follow the steps outlined below:

1. Note the total D850MD or D850MV board standby current requirement.

2. Add to that the total PS/2 port standby current requirement if a wake-enabled device is connected.

3. Add, from the PCI 2.2 slots (wake-enabled) row, the total of the number of wake-enabled devices installed (PCI and AGP) multiplied by the standby current requirement.

4. Add, from the PCI 2.2 slots (nonwake-enabled) row, the total of the number of non-wakeenabled devices installed (PCI and AGP) multiplied by the standby current requirement.

5. Add all additional wake-enabled devices’ and non-wake-enabled devices’ standby current requirements as applicable.

6. Add all the required current totals from steps 1 through 5 to determine the total estimated standby current power supply requirement.

Intel Desktop Boards D850MD and D850MV Product Guide

Table 4. Standby Current Requirements

Instantly Available Current Support Description

Estimate for integrated board components

Estimate for add-on components (Add to integrated board components shown above)

* Refer to the Intel® Desktop Board D850MV/D850MD Technical Product Specification for the exact standby current

requirements

** Dependent upon system configuration

NOTE

✏

Total for the D850MD or D850MV boards

PS/2 ports

PCI 2.2 slots (wake-enabled) 375

PCI 2.2 slots (non-wake-enabled) 100

CNR** (wake enabled) 875

CNR** (non-wake enabled) 40

USB ports

Standby Current Requirements (mA)

770*

345

700

PCI requirements are calculated by totaling the following:

• One wake-enabled device @ 375 mA

• Five non- wake-enabled devices @ 20 mA each

PS/2 Ports requirements per the IBM PS/2 Port Specification (Sept 1991):

• Keyboard @ 275 mA

• Mouse @ 70 mA

USB requirements are calculated by totaling the following:

• One wake-enabled device @ 500 mA

• USB hub @ 100 mA

• Three USB non-wake-enabled devices @ 2.5 mA each

The USB ports are limited to a combined total of 700 mA.

Resume on Ring

The operation of Resume on Ring can be summarized as follows:

• Resumes operation from either the APM sleep mode or the ACPI S1 state

• Requires only one call to access the computer

• Detects incoming calls similarly for external and internal modems

• Requires modem interrupt be unmasked for correct operation

2 Installing and Replacing Desktop Board

Components

This chapter tells you how to:

• Install the I/O shield

• Install and remove the desktop board

• Install and remove a processor

• Install and remove memory

• Install and remove an AGP card retention mechanism and card

• Connect the IDE cable

• Set the BIOS jumper

• Clear passwords

• Replace the battery

Before You Begin

CAUTION

Before you install this board in a chassis, see Appendix B on page 81 for regulatory requirements and precautions.

• Always follow the steps in each procedure in the correct order.

• Set up a log to record information about your computer, such as model, serial number,

installed options, and configuration information.

• Electrostatic discharge (ESD) can damage components. Perform the procedures described in this chapter only at an ESD workstation using an antistatic wrist strap and a conductive foam pad. If such a station is not available, you can provide some ESD protection by wearing an antistatic wrist strap and attaching it to a metal part of the computer chassis.

WARNINGS

The procedures in this chapter assume familiarity with the general terminology associated with personal computers and with the safety practices and regulatory compliance required for using and modifying electronic equipment.

Disconnect the computer from its power source and from any telecommunications links, networks, or modems before performing any of the procedures described in this chapter. Failure to disconnect power, telecommunications links, networks, or modems before you open the computer or perform any procedures can result in personal injury or equipment damage. Some circuitry on the board can continue to operate even though the front panel power button is off.

Intel Desktop Boards D850MD and D850MV Product Guide

Installing the I/O Shield

NOTE

✏

Systems based on this desktop board require that the I/O shield be properly installed to comply with Class B emissions requirements.

The desktop board comes with an I/O shield. When installed in the chassis, the shield blocks radio frequency transmissions, protects internal components from dust and foreign objects, and promotes correct airflow within the chassis.

Install the I/O shield before installing the desktop board in the chassis. Place the shield inside the chassis as shown in the following figure. Press the shield into place so that it fits tightly and securely. If the shield doesn’t fit, obtain a properly sized shield from the chassis supplier.

Figure 4 shows how the I/O shield is installed inside the chassis.

OM12116

Figure 4. Installing the I/O Shield

Installing and Replacing Desktop Board Components

Installing and Removing the Desktop Board

Refer to your chassis manual for instructions on installing and removing the board. The D850MD board is secured to the chassis by eight screws and the D850MV board by 11 screws. See Figure 5 and Figure 6 for the locations of the mounting screw holes of each board.

WARNING

This procedure should be done only by qualified technical personnel. Disconnect the computer from its power source before performing the procedures described here. Failure to disconnect the power before you open the computer can result in personal injury or equipment damage.

NOTES

✏

You will need a Phillips† (#2 bit) screwdriver.

Refer to Appendix B on page 81 for regulatory requirements and installation instructions and precautions.

Figure 5 shows the location of the mounting holes for the D850MD board.

OM11831

Figure 5. D850MD Board Mounting Screw Holes

Intel Desktop Boards D850MD and D850MV Product Guide

Figure 6 shows the location of the mounting holes for the D850MV board.

Figure 6. D850MV Board Mounting Screw Holes

OM12178

Installing and Replacing Desktop Board Components

Installing and Removing a Processor

Instructions on how to install the processor fan heatsink retention mechanism (RM) base and processor to the desktop board are given below. For instruction on how to install the processor fan heatsink, refer to the processor installation manual or the Intel World Wide Web site at:

http://support.intel.com/support/motherboards/desktop

Installing the Processor Fan Heatsink Retention Mechanism Base

NOTE

✏

The following assembly operation should be performed after the desktop board is secured in the chassis.

To install the processor fan heatsink RM base, follow these instructions:

1. Observe the precautions in “Before You Begin” on page 21.

2. Locate the processor fan heatsink RM holes on the desktop board (see Figure 7).

OM12079

Figure 7. Location of the Processor Fan Heatsink Base Mounting Holes

Intel Desktop Boards D850MD and D850MV Product Guide

3. Align the four fasteners (B) of the processor fan heatsink RM base with the corresponding holes in the desktop board (C). Gently press the base down until all four corners snap into place. Verify that all four fasteners are fully engaged, then press down each of the four locking pushpins (A) to fully secure the base to the desktop board (see Figure 8).

OM12177

Figure 8. Installing the Processor Fan Heatsink RM Base to the Board

Installing and Replacing Desktop Board Components

Installing a Processor

CAUTION

Before installing or removing the processor, make sure that ac power has been removed by unplugging the power cord from the computer; the standby power LED should not be lit (see Figure 3 on page 19). Failure to do so could damage the processor and the board.

To install a processor, follow these instructions:

1. Observe the precautions in “Before You Begin” on page 21.

2. Locate the processor socket and raise the socket lever completely.

3. Install the processor so that the corner with the triangle marking (A) is aligned with the corner of the socket where the lever connects to the socket (see Figure 9).

4. Lower the lever to its original position.

mPGA478B

Figure 9. Installing a Processor

Installing the Processor Fan Heatsink

For instructions on how to install the processor fan heatsink, refer to the boxed processor manual or the Intel World Wide Web site at:

http://support.intel.com/support/motherboards/desktop

OM12078

Intel Desktop Boards D850MD and D850MV Product Guide

Connecting the Processor Fan Cable

Connect the processor fan cable to the processor fan connector (see Figure 10).

Figure 10. Connecting the Processor Fan Cable to the Processor Fan Connector

Removing a Processor

For instruction on how to remove the processor fan heatsink, refer to the processor installation manual or the Intel World Wide Web site at:

http://support.intel.com/support/motherboards/desktop

NOTE

✏

Once removed, the processor fan heatsink base push pins cannot be reused.

OM12083

Installing and Replacing Desktop Board Components

Installing and Removing Memory

CAUTIONS

Before installing or removing RIMM modules, make sure that ac power has been removed by unplugging the power cord from the computer. The standby power indicator LED should not be lit (see Figure 3 on page 19 for the location of the standby power indicator LED location). Failure to do so could damage the memory and the board.

The board supports combinations of no more than 32 RDRAM components per RDRAM channel. If the total number of RDRAM components installed in all RIMM sockets exceeds 64, the computer will not boot.

A Continuity RIMM (CRIMM) module must be installed in any unused memory connector or the board will not boot.

Incorrect insertion of a RIMM module or a CRIMM module in a RIMM connector can damage the D850MD and D850MV boards.

Installing Memory

The board has four memory module sockets arranged as bank 0 and bank 1. The pair of sockets closest to the processor is for bank 0, as shown in Figure 13. The memory module requirements are listed in the Main Memory section on page 12.

When adding memory:

• Install a pair of RIMMs in the sockets in bank 0 first. The RIMMs must be the same speed (PC600 or PC800), size (64 MB, 128 MB, 256 MB, or 512 MB), and density (single- or double-sided).

• If the desired memory configuration has been achieved in bank 0, install CRIMMs in the sockets in bank 1 (see Figure 11).

128 MB RDRAM Bank 0 128 MB RDRAM

CRIMM Bank 1 CRIMM

Figure 11. RDRAM and CRIMM Installation

Intel Desktop Boards D850MD and D850MV Product Guide

• If memory is to be installed in bank 1, the RIMM modules to be installed must be the same size and density to each other and match the speed of the RIMM modules in bank 0. For example, if bank 0 has two 128 MB RIMMs of PC800 RDRAM, bank 1 would require PC800 RDRAM also, however, any other supported RIMM modules such as 64 MB, 128 MB, 256 MB, or 512 MB could be used (see Figure 12).

128 MB RDRAM Bank 0 128 MB RDRAM

64 MB RDRAM Bank 1 64 MB RDRAM

128 MB RDRAM 128 MB RDRAM

128 MB RDRAM Bank 1 128 MB RDRAM

128 MB RDRAM 128 MB RDRAM

256 MB RDRAM Bank 1 256 MB RDRAM

128 MB RDRAM 128 MB RDRAM

512 MB RDRAM Bank 1 512 MB RDRAM

Figure 12. RIMM Installation

Bank 0

• The BIOS detects the size and type of installed memory.

Installing and Replacing Desktop Board Components

To install the memory modules, follow these steps (see Figure 13):

1. Observe the precautions in “Before You Begin” on page 21.

2. Holding the memory module by the edges, remove it from its antistatic package.

3. Make sure the clips at either end of the socket are pushed away from the socket.

4. Position the module above the socket. Align the two small notches in the bottom edge of the module with the keys in the socket.

5. Insert the bottom edge of the module into the socket.

6. When the module is seated, push down on the top edge of the module until the retaining clips snap into place. Make sure the clips are firmly in place.

Figure 13. Installing a Memory Module

Removing Memory

To remove a memory module, follow these steps:

1. Observe the precautions in "Before You Begin" on page 21.

2. Turn off all peripheral devices connected to the computer. Turn off the computer. Disconnect the computer’s power cord from the ac power source (wall outlet or power adapter).

3. Remove the computer cover.

4. Gently spread the retaining clips at each end of the socket. The memory pops out of the socket.

5. Hold the memory module by the edges, lift it away from the socket, and store it in an antistatic package.

6. Reinstall and reconnect any parts you removed or disconnected to reach the memory module sockets.

OM11832

Intel Desktop Boards D850MD and D850MV Product Guide

Installing and Removing an AGP Card Retention Mechanism and Card

The AGP connector supports 1.5 V 4X and 2X AGP cards. Newer cards have a retention notch as shown in Figure 14. When using notched cards, install the AGP card retention mechanism (RM) before installing a card. The AGP card RM is not used with unnotched cards.

To install and remove an AGP card RM and card, follow the instructions under these headings:

• Installing the AGP card RM

• Installing an AGP card

• Removing the AGP card from the RM

• Removing the AGP card RM

Installing the AGP Card Retention Mechanism

CAUTION

Install the AGP card RM only when using an AGP card with a retention notch (A) as shown in Figure 14. Use of the RM with an unnotched card may impair video operation. If you need to remove the RM, follow the instructions on page 35.

NOTE

✏

All D850MD and D850MV boxed desktop boards may not include an AGP RM. Skip to the Installing an AGP Card heading on page 34 if your boxed desktop board does not include an AGP RM.

OM10592

Figure 14. AGP Card with a Retention Notch

Installing and Replacing Desktop Board Components

The AGP card RM (see Figure 15) encloses the board’s AGP connector and stabilizes the AGP card. Place the board (component side up) on a flat, supportive surface. Follow the steps outlined below to attach the AGP card RM (A) to the AGP connector (B):

1. Locate the AGP connector on the board as shown below. Note that the board’s silkscreen (C) indicates the correct final position of the lever (D) on the AGP card RM.

OM11842

Figure 15. Installing the AGP Card Retention Mechanism

2. Position the AGP card RM over the AGP connector as shown below.

OM10111

3. Push the lever end of the AGP card RM in the direction of the arrow until the two rearmost

tabs (E) spread over the end of the AGP connector.

OM10180

4. Push the free end of the AGP card RM over the other end of the AGP connector and press down evenly on both ends of the RM until all four tabs click underneath the AGP connector. do To avoid damaging the board, not apply unnecessary pressure.

OM10181

Intel Desktop Boards D850MD and D850MV Product Guide

Installing an AGP Card

Follow these instructions to install an AGP card:

1. Place the AGP card in the AGP connector.

2. Press down on the card until it is completely seated in the AGP connector and the card retention notch snaps into place around the AGP card RM pin.

3. Secure the card’s metal bracket to the chassis back panel with a screw.

Removing the AGP Card from the Retention Mechanism

Follow these instructions to remove an AGP card from the AGP card RM:

1. Remove the screw (B) that secures the card’s metal bracket (A) to the chassis back panel.

2. Push back on the RM lever (D), as shown in Figure 16, until the retention pin (C) completely clears the notch in the card.

3. Pull the card straight up (E).

Figure 16. Removing the AGP Card

OM10595

Installing and Replacing Desktop Board Components

Removing the AGP Card Retention Mechanism

Follow these instructions to remove the AGP card RM:

1. Using diagonal cutters (A), cut the loop (B) joining the two sides of the AGP card RM (see Figure 17).

2. Spread the sides of the RM (C) and lift the AGP card RM off of the AGP connector.

NOTE

✏

Once removed using this method, the AGP card RM cannot be reused.

Figure 17. Removing the AGP Card Retention Mechanism

OM10593

Intel Desktop Boards D850MD and D850MV Product Guide

Connecting the IDE Cable

The Intel® boxed desktop board package includes two IDE cables. Both are capable of connecting two drives to the desktop board. The 40-contact cable supports the Ultra DMA-33 transfer protocol. The 40-contact, 80-conductor cable supports ATA-66 and ATA-100 transfer protocols and is backward compatible with drives using slower IDE transfer protocols.

NOTE

✏

ATA-66/100 compatible cables are backward compatible with drives using slower IDE transfer protocols. If an ATA-66/100 disk drive and a disk drive using any other IDE transfer protocol are attached to the same cable, the maximum transfer rate between the drives may be reduced to that of the slowest drive.

NOTE

✏

Do not connect an ATA device as a slave on the same IDE cable as an ATAPI master device. For example, do not connect an ATA hard drive as a slave to an ATAPI CD-ROM drive.

For correct function of the cable:

• Attach the cable end with the single connector to the board (see Figure 18, A).

• Attach the cable end with the two closely spaced connectors to the drives (see Figure 18, B).

OM11835

Figure 18. Connecting the IDE Cable

Installing and Replacing Desktop Board Components

Setting the BIOS Configuration Jumper

CAUTION

Always turn off the power and unplug the power cord from the computer before changing the jumper. Moving the jumper with the power on may result in unreliable computer operation.

The location of the board’s BIOS configuration jumper (J9H2) is shown in Figure 19.

J9H2

OM11836

Figure 19. Location of the BIOS Configuration Jumper

The three-pin BIOS jumper enables the board configuration to be done in BIOS Setup. Table 5 shows the jumper settings for the Setup program modes.

Table 5. Jumper Settings for the BIOS Setup Program Modes (J9H2)

Function / Mode Jumper Setting Configuration

Normal 1-2

Configure 2-3

Recovery None

The BIOS uses current configuration information and passwords for booting.

After the POST runs, the BIOS displays the maintenance menu. Use this menu to clear passwords.

The BIOS attempts to recover the BIOS configuration. A recovery diskette is required.

Intel Desktop Boards D850MD and D850MV Product Guide

Clearing Passwords

This procedure assumes that the board is installed in the computer and the configuration jumper is set to normal mode.

1. Observe the precautions in “Before You Begin” on page 21.

2. Turn off all peripheral devices connected to the computer. Turn off the computer. Disconnect the computer’s power cord from the ac power source (wall outlet or power adapter).

3. Remove the computer cover.

4. Find the configuration jumper (see Figure 19).

5. Place the jumper on pins 2-3 as shown below.

6. Replace the cover, plug in the computer, turn on the computer, and allow it to boot.

7. The computer starts the Setup program. Setup displays the maintenance menu.

8. Use the arrow keys to select Clear Passwords. Press <Enter> and Setup displays a pop-up screen requesting that you confirm clearing the password. Select Yes and press <Enter>. Setup displays the maintenance menu again.

9. Press <F10> to save the current values and exit Setup.

10. Turn off the computer. Disconnect the computer’s power cord from the ac power source.

11. Remove the computer cover.

12. To restore normal operation, place the jumper on pins 1-2 as shown below.

13. Replace the cover, plug in the computer, and turn on the computer.

Installing and Replacing Desktop Board Components

Replacing the Battery

A coin-cell battery (CR2032) powers the real-time clock and CMOS memory. When the computer is not plugged into a wall socket, the battery has an estimated life of three years. When the computer is plugged in, the standby current from the power supply extends the life of the battery. The clock is accurate to ± 13 minutes/year at 25 ºC with 3.3 VSB applied.

Figure 20 on page 41 shows the location of the battery.

When the voltage drops below a certain level, the BIOS Setup program settings stored in CMOS RAM (for example, the date and time) might not be accurate. Replace the battery with an equivalent one.

CAUTION

Risk of explosion if the battery is replaced with an incorrect type. Batteries should be recycled where possible. Disposal of used batteries must be in accordance with local environmental regulations.

PRECAUTION

Risque d'explosion si la pile usagée est remplacée par une pile de type incorrect. Les piles usagées doivent être recyclées dans la mesure du possible. La mise au rebut des piles usagées doit respecter les réglementations locales en vigueur en matière de protection de l'environnement.

(French)

FORHOLDSREGEL

Eksplosionsfare, hvis batteriet erstattes med et batteri af en forkert type. Batterier bør om muligt genbruges. Bortskaffelse af brugte batterier bør foregå i overensstemmelse med gældende miljølovgivning.

(Danish)

OBS!

Det kan oppstå eksplosjonsfare hvis batteriet skiftes ut med feil type. Brukte batterier bør kastes i henhold til gjeldende miljølovgivning.

(Norwegian)

VIKTIGT!

Risk för explosion om batteriet ersätts med felaktig batterityp. Batterier ska kasseras enligt de lokala miljövårdsbestämmelserna.

(Swedish)

VARO

Räjähdysvaara, jos pariston tyyppi on väärä. Paristot on kierrätettävä, jos se on mahdollista. Käytetyt paristot on hävitettävä paikallisten ympäristömääräysten mukaisesti.

(Finnish)

Intel Desktop Boards D850MD and D850MV Product Guide

VORSICHT

Bei falschem Einsetzen einer neuen Batterie besteht Explosionsgefahr. Die Batterie darf nur durch denselben oder einen entsprechenden, vom Hersteller empfohlenen Batterietyp ersetzt werden. Entsorgen Sie verbrauchte Batterien den Anweisungen des Herstellers entsprechend.

(German)

AVVERTIMENTO

Esiste il pericolo di un esplosione se la pila non viene sostituita in modo corretto. Utilizzare solo pile uguali o di tipo equivalente a quelle consigliate dal produttore. Per disfarsi delle pile usate, seguire le istruzioni del produttore.

(Italian)

PRECAUCIÓN

Existe peligro de explosión si la pila no se cambia de forma adecuada. Utilice solamente pilas iguales o del mismo tipo que las recomendadas por el fabricante del equipo. Para deshacerse de las pilas usadas, siga igualmente las instrucciones del fabricante.

(Spanish)

WAARSCHUWING

Er bestaat ontploffingsgevaar als de batterij wordt vervangen door een onjuist type batterij. Batterijen moeten zoveel mogelijk worden gerecycled. Houd u bij het weggooien van gebruikte batterijen aan de plaatselijke milieuwetgeving.

(Dutch)

ATENÇÃO

Haverá risco de explosão se a bateria for substituída por um tipo de bateria incorreto. As baterias devem ser recicladas nos locais apropriados. A eliminação de baterias usadas deve ser feita de acordo com as regulamentações ambientais da região.

(Brazilian Portuguese)

Installing and Replacing Desktop Board Components

To replace the battery, follow these steps:

1. Observe the precautions in “Before You Begin” on page 21.

2. Turn off all peripheral devices connected to the computer. Disconnect the computer’s power cord from the ac power source (wall outlet or power adapter).

3. Remove the computer cover.

4. Locate the battery on the board (see Figure 20).

5. With a medium flat-bladed screwdriver, gently pry the battery free from its connector. Note the orientation of the “+” and “-” on the battery.

6. Install the new battery in the connector, orienting the “+” and “-” correctly.

7. Replace the computer cover.

OM11833

Figure 20. Removing the Battery

Intel Desktop Boards D850MD and D850MV Product Guide

3 Updating the BIOS

This chapter tells you how to update the BIOS by either using the Intel® Express BIOS Update

utility or the Intel

Updating the BIOS with the Intel® Express BIOS Update Utility

With the Intel Express BIOS Update utility you can update the system BIOS while in the

†

Windows the functionality of the Intel Flash Memory Update Utility and the ease-of use of Windows-based installation wizards.

To update the BIOS with the Intel Express BIOS Update utility:

1. Go to the Intel World Wide Web site:

2. Navigate to the D850MV or D850MD page and click the Express BIOS Update utility file for

3. Download the file to your hard drive. (You can also save this file to a diskette. This is useful

4. Close all other applications. This step is required. Your system will be rebooted at the last

5. Double-click the executable file from the location on your hard drive where it was saved. This

6. Follow the instructions provided in the dialog boxes to complete the BIOS update.

environment. The BIOS file is included in an automated update utility which combines

http://support.intel.com/support/motherboards/desktop

the D850MV or D850MD board’s BIOS.

if you are updating the BIOS for multiple identical systems.)

Express BIOS Update window.

runs the update program.

Flash Memory Update Utility, and how to recover the BIOS if an update fails.

Updating the BIOS with the Intel® Flash Memory Update Utility

With the Intel Flash Memory Update Utility you can update the system BIOS from a floppy disk or other bootable media. The utility available from the Web provides a simple method for creating a bootable flash memory update floppy that will automatically update your BIOS.

Obtaining the BIOS Update File

You can update to a new version of the BIOS by using the BIOS update file. The BIOS update file is a compressed self-extracting archive that contains all the files you need to update the BIOS. The BIOS update file contains:

• New BIOS files

• BIOS recovery files

• Intel Flash Memory Update Utility

You can obtain the BIOS update file through your computer supplier or by navigating to the D850MD or D850MV page on the Intel World Wide Web site:

http://support.intel.com/support/motherboards/desktop

Intel Desktop Boards D850MD and D850MV Product Guide

NOTE

✏

Please review the instructions distributed with the update utility before attempting a BIOS update.

The Intel Flash Memory Update Utility allows you to:

• Update the BIOS in flash memory

• Update the language section of the BIOS

Updating the BIOS

CAUTION

The AUTOEXEC.BAT file provided with the update files updates the BIOS. Do not interrupt the process or the system may not function.

1. Boot the computer with the BIOS update diskette in drive A. During system boot, the

AUTOEXEC.BAT file provided with the update files will automatically run the BIOS update

process.

2. When the update process is complete, the monitor will display a message telling you to remove the diskette and to reboot the system.

3. As the computer boots, check the BIOS identifier (version number) to make sure the update was successful. If a logo appears, press

<Esc> to view the POST messages.

Recovering the BIOS

It is unlikely that anything will interrupt the BIOS update; however, if an interruption occurs, the BIOS could be damaged. The following steps explain how to recover the BIOS if an update fails. The following procedure uses recovery mode for the Setup program. See page 37 for more information on Setup modes.

NOTE

✏

Because of the small amount of code available in the boot block area, there is no video support. You will not see anything on the screen during this procedure. Monitor the procedure by listening to the speaker and looking at the diskette drive LED.

1. Turn off the computer, disconnect the computer’s power cord, and disconnect all external peripherals.

2. Remove the computer cover and locate the configuration jumper labeled J9H2 (see Figure 19).

3. Remove the jumper from all pins as shown below to set recovery mode for Setup.

4. Insert the bootable BIOS update diskette into diskette drive A.

5. Replace the computer cover, connect the power cord, turn on the computer, and allow it to boot. The recovery process will take a few minutes.

Updating the BIOS

6. Listen to the speaker:

• Upon applying power, drive A will begin to show activity. In about a minute, two beeps

are heard and drive A activity ceases (temporarily) indicating the successful recovery of the BIOS core. Drive A activity will begin again followed by two more beeps indicating the successful recovery of the boot block. This sequence of events indicates a successful BIOS recovery.

• A series of continuous beeps indicates a failed BIOS recovery.

7. If recovery fails, return to step 1 and repeat the recovery process.

8. If recovery is successful, turn off the computer, and disconnect its power cord.

9. Remove the computer cover and continue with the following steps.

10. Reinstall the jumper back on pins 1-2 as shown below to set normal mode for Setup.

11. Leave the update diskette in drive A, replace the computer cover, and connect the computer’s power cord.

12. Turn on the computer and continue with the BIOS update (see page 44).

Intel Desktop Boards D850MD and D850MV Product Guide

4 Using the Setup Program

The BIOS Setup program can be used to view and change the BIOS settings for the computer. The BIOS Setup program is accessed by pressing the <F2> key after the Power-On Self-Test (POST) memory test begins and before the operating system boot begins.

NOTE

✏

The BIOS Setup menus described in this section may not show the latest settings. For the latest BIOS settings, refer to the Intel Desktop Board D850MD/D850MV Technical Product Specification or the Intel World Wide Web site:

http://support.intel.com/support/motherboards/desktop

NOTE

✏

For reference purposes, you should write down the current Setup settings. When you make changes to the settings, update this record.

NOTE

✏

The Setup menus described in this section apply to the desktop boards with BIOS identifier MV85010A.86A. Boards with other BIOS identifiers might have differences in some of the Setup menu screens.

The Setup screen menu bar is shown below.

Maintenance Main Advanced Security Power Boot Exit

Table 6 shows the BIOS Setup program menu bar.

Table 6. BIOS Setup Program Menu Bar

Maintenance Main Advanced Security Power Boot Exit

Clears passwords and Boot Integrity Service (BIS)* credentials, and configures extended configuration memory settings

* For information about the BIS, refer to the Intel World Wide Web site at:

http://developer.intel.com/design/security/index1.htm

Allocates resources for hardware components

Configures advanced features available through the chipset

Sets passwords and security features

Configures power management features

Selects boot options and power supply controls

Saves or discards changes to set program options

Intel Desktop Boards D850MD and D850MV Product Guide

Table 7 shows the function keys available for menu screens.

Table 7. BIOS Setup Program Function Keys

BIOS Setup Program Function Key Description

<←> or <→> Selects a different menu screen <↑> or <↓> Moves cursor up or down

<Tab> Moves cursor to the next field

<Enter> Executes command or selects the submenu

<F9> Load the default configuration values for the current menu

<F10> Save the current values and exits the BIOS Setup program

<Esc> Exits the menu

Maintenance Menu

Maintenance

Main Advanced Security Power Boot Exit

The menu shown in Table 8 is used to clear the Setup passwords and enable extended configuration mode. Setup only displays this menu in configure mode. See page 37 for information about setting configure mode.

Table 8. Maintenance Menu

Feature Options Description

Processor Speed Processor

dependent

Clear All Passwords

Clear BIS * Credentials

Extended Configuration

CPU Information No options Displays processor information.

CPU Stepping Signature

CPU Microcode Update Revision

* For information about the BIS, refer to the Intel World Wide Web site at:

http://developer.intel.com/design/security/index1.htm

• Yes (default)

• No

• Yes (default)

• No

• Default (default)

• User-Defined

No options Displays the processor’s stepping signature.

No options Displays the processor’s microcode update revision.

Displays the processor speed.

Clears the user and administrative passwords.

Clears the Wired for Management Boot Integrity Service (BIS) credentials.

Invokes the Extended Configuration submenu.

Extended Configuration Submenu

Using the Setup Program

Maintenance

Main Advanced Security Power Boot Exit

Extended Configuration

The submenu shown in Table 9 is used to set system control and video memory cache mode. This submenu becomes available when User Defined is selected under Extended Configuration.

Table 9. Extended Configuration Submenu

Feature Options Description

Extended Configuration

Video Memory Cache Mode • USWC

• Default (default)

• User-Defined

• UC (default)

User-Defined allows setting memory control and video memory cache mode. If selected here, will also display in the Advanced Menu as “Extended Menu: Used.”

Selects Uncacheable Speculative Write-Combining (USWC) video memory cache mode. Full 32 byte contents of the Write Combining buffer are written to memory as required. Cache lookups are not performed. Both the video driver and the application must support Write Combining.

Selects Uncacheable (UC) video memory cache mode. This setting identifies the video memory range as uncacheable by the processor. Memory writes are performed in program order. Cache lookups are not performed. Well suited for applications not supporting Write Combining.

Intel Desktop Boards D850MD and D850MV Product Guide

Main Menu

Maintenance

Main

Advanced Security Power Boot Exit

Table 10 describes the Main Menu. This menu reports processor and memory information and is used to configure the system date and system time.

Table 10. Main Menu

Feature Options Description

BIOS Version No options Displays the version of the BIOS.

Processor Type No options Displays processor type.

Processor Speed No options Displays processor operating frequency.

System Bus Frequency

Cache RAM No options Displays the size of second-level cache and whether it is

Total Memory No options Displays the total amount of RAM.

RIMM 1 RIMM 2

RIMM 3

RIMM 4

Language

Memory Configuration

System Time Hour, minute, and

System Date Day of the week,

No options Displays the system bus frequency.

ECC-capable.

No options Displays the amount and type of RAM installed in the

memory banks.

• English (default)

• Espanol

• Deutsche

• Italiano

• Français

• Non-ECC

• ECC (default)

second

month, day, and year

Selects the default language used by the BIOS.

Allows the user to enable error reporting if the system and all installed memory supports ECC. If non-ECC memory is installed, BIOS will detect and change setting to non-ECC.

Specifies the current time.

Specifies the current date.

Advanced Menu

Using the Setup Program

Maintenance Main

Advanced

Security Power Boot Exit

Table 11 describes the Advanced Menu. This menu is used to set advanced features that are available through the chipset.

Table 11. Advanced Menu

Feature Options Description

Extended Configuration No options If Used is highlighted, User-Defined has been selected in

Extended Configuration under the Maintenance Menu.

PCI Configuration No options Configures individual PCI slot’s IRQ priority. When

selected, displays the PCI Configuration submenu.

Boot Configuration No options Configures Plug & Play and the Numlock key, and resets

configuration data. When selected, displays the Boot Configuration submenu.

Peripheral Configuration No options Configures peripheral ports and devices. When selected,

displays the Peripheral Configuration submenu.

IDE Configuration No options Specifies type of connected IDE device.

Diskette Configuration No options When selected, displays the Diskette Configuration

submenu.

Event Log Configuration No options Configures Event Logging. When selected, displays the

Event Log Configuration submenu.

Video Configuration No options Configures video features. When selected, displays the

Video Configuration submenu.

Intel Desktop Boards D850MD and D850MV Product Guide

PCI Configuration Submenu

Maintenance Main

Advanced

Security Power Boot Exit

PCI Configuration

Boot Configuration

Peripheral Configuration

IDE Configuration

Diskette Configuration

Event Log Configuration

Video Configuration

The submenu shown in Table 12 is used to configure the IRQ priority of PCI slots individually.

Table 12. PCI Configuration Submenu

Feature Options Description

PCI Slot 1 IRQ Priority

PCI Slot 2 IRQ Priority

PCI Slot 3 IRQ Priority

PCI Slot 4 IRQ Priority

PCI Slot 5 IRQ Priority No options Always set to Auto (D850MV only).

• Auto (default)

• 3

• 5

• 9

• 10

• 11

• Auto (default)

• 3

• 5

• 9

• 10

• 11

• Auto (default)

• 3

• 5

• 9

• 10

• 11

• Auto (default)

• 3

• 5

• 9

• 10

• 11

Allows selection of IRQ priority.

Allows selection of IRQ priority. IRQ Priority selections for PCI slots 3 and 5 are linked. Selections made to PCI Slot 3 IRQ Priority are repeated in PCI Slot 5 IRQ Priority.

Allows selection of IRQ priority (D850MV only).

Boot Configuration Submenu

Using the Setup Program

Maintenance Main

Advanced

Security Power Boot Exit

PCI Configuration

Boot Configuration

Peripheral Configuration

IDE Configuration

Diskette Configuration

Event Log Configuration

Video Configuration

The submenu shown in Table 13 is used to set the Plug & Play options, reset configuration data, and the power-on state of the Numlock key.

Table 13. Boot Configuration Submenu

Feature Options Description

Plug & Play O/S

Reset Config Data

Numlock • Off

• No (default)

• Yes

• No (default)

• Yes

• On (default)

Specifies if manual configuration is desired. No lets the BIOS configure all devices. This setting is appropriate when using a Plug and Play operating system. Yes lets the operating system configure Plug and Play devices not required to boot the system. This option is available for use during lab testing.

No does not clear the PCI/PnP configuration data stored in flash memory on the next boot. Yes clears the PCI/PnP configuration data stored in flash memory on the next boot.

Specifies the power-on state of the Numlock feature on the numeric keypad of the keyboard.

Intel Desktop Boards D850MD and D850MV Product Guide

Peripheral Configuration Submenu

Maintenance Main

Advanced

Security Power Boot Exit

PCI Configuration

Boot Configuration

Peripheral Configuration

IDE Configuration

Diskette Configuration

Event Log Configuration

Video Configuration

This submenu shown in Table 14 is used to enable onboard devices and USB legacy support.

Table 14. Peripheral Configuration Submenu

Feature Options Description

Serial Port A • Disabled

• Enabled

• Auto (default)

Base I/O address (This feature is displayed only if Serial Port A is set to Enabled.)

Interrupt (This feature is displayed only if Serial Port A is set to Enabled.)

Serial Port B • Disabled

Base I/O address (This feature is displayed only if Serial Port B is set to Enabled.)

Interrupt (This feature is displayed only if Serial Port A is set to Enabled.)

• 3F8 (default)

• 2F8

• 3E8

• 2E8

• IRQ 3

• IRQ 4 (default)

• Enabled

• Auto (default)

• 3F8

• 2F8 (default)

• 3E8

• 2E8

• IRQ 3 (default)

• IRQ 4

Configures serial port A.

Auto assigns the first free COM port, normally COM 1, the address 3F8h, and the interrupt IRQ4.

An * (asterisk) displayed next to an address indicates a conflict with another device.

Specifies the base I/O address for serial port A, if serial port A is set to Enabled.

Specifies the interrupt for serial port A, if serial port A is set to Enabled.

Configures serial port B.

Auto assigns the first free COM port, normally COM 2, the address 3F8h, and the interrupt IRQ4.

An * (asterisk) displayed next to an address indicates a conflict with another device.

Specifies the base I/O address for serial port B, if serial port B is set to Enabled.

Specifies the interrupt for serial port B, if serial port B is set to Enabled.

continued

Table 14. Peripheral Configuration Submenu (continued)

Feature Options Description

Parallel port • Disabled

• Enabled

• Auto (default)

Mode • Output Only

• Bi-directional

(default)

• EPP

• ECP

Base I/O address (This feature is displayed

• 378 (default)

• 278

only if Parallel Port is set to Enabled.)

Interrupt (This feature is displayed

• IRQ 5

• IRQ 7 (default)

only if Parallel Port is set to Enabled.)

Audio Device • Disabled

• Enabled (default)

LAN Device • Disabled

• Enabled (default)

Legacy USB Support • Disabled

• Enabled (default)

Configures the parallel port.

Auto assigns LPT1 the address 378h and the interrupt IRQ7.

An * (asterisk) displayed next to an address indicates a conflict with another device.

Selects the mode for the parallel port. Not available if the parallel port is disabled.

Output Only operates in AT Bi-directional operates in PS/2-compatible mode.

EPP is Extended Parallel Port mode, a high-speed

bi-directional mode.

ECP is Enhanced Capabilities Port mode, a high-speed bi-directional mode.

Specifies the base I/O address for the parallel port.

Specifies the interrupt for the parallel port.

Enables or disables the onboard audio subsystem.

Enables or disables the LAN device.

Enables or disables USB legacy support.

Using the Setup Program

†

-compatible mode.

Intel Desktop Boards D850MD and D850MV Product Guide

IDE Configuration Submenu

Maintenance Main

Advanced

Security Power Boot Exit

PCI Configuration

Boot Configuration

Peripheral Configuration

IDE Configuration

Diskette Configuration

Event Log Configuration

Video Configuration

This submenu shown in Table 15 is used to configure IDE device options.

Table 15. IDE Configuration Submenu

Feature Options Description

IDE Controller • Disabled

• Primary

• Secondary

• Both (default)

Hard Disk Pre-Delay

Primary IDE Master No options Reports type of connected IDE device. When selected,

Primary IDE Slave No options Reports type of connected IDE device. When selected,

Secondary IDE Master No options Reports type of connected IDE device. When selected,

Secondary IDE Slave No options Reports type of connected IDE device. When selected,

• Disabled (default)

• 3 Seconds

• 6 Seconds

• 9 Seconds

• 12 Seconds

• 15 Seconds

• 21 Seconds

• 30 Seconds

Specifies the integrated IDE controller.

Primary enables only the primary IDE controller. Secondary enables only the secondary IDE controller. Both enables both IDE controllers.

Specifies the hard disk drive pre-delay.

displays the Primary IDE Master submenu.

displays the Primary IDE Slave submenu.

displays the Secondary IDE Master submenu.

displays the Secondary IDE Slave submenu.

Primary/Secondary IDE Master/Slave Submenus

Using the Setup Program

Maintenance Main

Advanced

Security Power Boot Exit

Boot Configuration

Peripheral Configuration

IDE Configuration

Diskette Configuration

Event Log Configuration

Video Configuration

Primary IDE Master

➜

Primary IDE Slave

Secondary IDE Master

Secondary IDE Slave

There are four IDE submenus: Primary master, primary slave, secondary master, and secondary slave. Table 16 shows the format of these IDE submenus. For brevity, only one example is shown.

Table 16. Primary/Secondary IDE Master/Slave Submenus

Feature Options Description

Drive Installed None Displays the type of drive installed. Type • None

• User

• Auto (default)

• CD-ROM

• ATAPI Removable

• Other ATAPI

• IDE Removable

Maximum Capacity None Displays the capacity of the drive. LBA Mode Control • Disabled

• Enabled (default)

Multi-sector Transfers • Disabled

• 2 Sectors

• 4 Sectors

• 8 Sectors

• 16 Sectors (default)

PIO Mode None Specifies the PIO mode (these configuration options

Specifies the IDE configuration mode for IDE devices.

User allows capabilities to be changed.

Auto fills-in capabilities from ATA/ATAPI device.

Enables or disables LBA mode control.

Specifies the number of sectors per block for transfers from the hard disk drive to memory.

Check the hard disk drive’s specifications for optimum setting.

appear only if an IDE device is installed).

• 0

• 1

• 2

• 3

• 4

continued

Intel Desktop Boards D850MD and D850MV Product Guide

Table 16. Primary/Secondary IDE Master/Slave Submenus (continued)

Feature Options Description

Ultra DMA None Specifies the Ultra DMA mode for the drive.

• Mode 0

• Mode 1

• Mode 2

• Mode 3

• Mode 4

• Mode 5

Cable Detected None Displays the type of cable connected to the IDE interface:

40-conductor or 80-conductor (for Ultra ATA-100 devices).

Diskette Configuration Submenu

Maintenance Main

Advanced

Security Power Boot Exit

PCI Configuration

Boot Configuration

Peripheral Configuration

IDE Configuration

Diskette Configuration

Event Log Configuration

Video Configuration

This submenu shown in Table 17 is used to configure the diskette drive.

Table 17. Diskette Configuration Submenu

Feature Options Description

Diskette Controller • Disabled

• Enabled (default)

Floppy A • Not Installed

• 360 kB 5¼ inches

• 1.2 MB 5¼ inches

• 720 kB 3½ inches

• 1.44/1.25 MB 3½ inches

(default)

• 2.88 MB 3½ inches

Diskette Write-Protect

• Disabled (default)

• Enabled

Disables or enables the integrated diskette controller.

Specifies the capacity and physical size of diskette drive A.

Disables or enables write-protect for the diskette drive.

Event Log Configuration Submenu

Using the Setup Program

Maintenance Main

Advanced

Security Power Boot Exit

PCI Configuration

Boot Configuration

Peripheral Configuration

IDE Configuration

Diskette Configuration

Event Log Configuration

Video Configuration

The submenu shown in Table 18 is used to configure the event logging features.

Table 18. Event Log Configuration Submenu

Feature Options Description

Event Log No options Indicates if there is space available in the event log.

Event Log Validity No options Indicates if the contents of the event log are valid.

View Event Log [Enter] Displays the event log.

Clear All Event Logs

Event Logging • Disabled

ECC Event Logging • Disabled

Mark Events as Read [Enter] Marks all events as read.

• No (default)

• Yes

• Enabled (default)

Clears the event log after rebooting.

Enables logging of events.

Enables logging of ECC events.

Video Configuration Submenu

Maintenance Main

Advanced

PCI Configuration

Boot Configuration

Peripheral Configuration

IDE Configuration

Diskette Configuration

Event Log Configuration

Video Configuration

The submenu shown in Table 19 is used to configure video features.

Table 19. Video Configuration Submenu

Feature Options Description

AGP Aperture Size

Primary Video Adapter

• 64 MB (default)

• 256 MB

• AGP (default)

• PCI

Security Power Boot Exit

Specifies the aperture size for the AGP video controller.

Selects primary video adapter to be used during boot.

Intel Desktop Boards D850MD and D850MV Product Guide

Security Menu

Maintenance Main Advanced

Security

Power Boot Exit

The menu shown in Table 20 is used to set passwords and security features.

Table 20. Security Menu

If no password was entered previously: Feature Options Description

Supervisor Password Is No options Reports if there is a supervisor password set.

User Password Is No options Reports if there is a user password set.

Set Supervisor Password Password can be up to seven

alphanumeric characters.

Set User Password Password can be up to seven

alphanumeric characters.

Clear User Password

(Note 1)

User Access Level

(Note 2)

Unattended Start

(Note 1)

Notes:

1. This feature appears only if a user password has been set.

2. This feature appears only if a supervisor password has been set.

• Yes (default)

• No

• Limited

• No access

• View Only

• Full (default)

• Enabled

• Disabled (default)

Specifies the supervisor password.

Specifies the user password.

Clears the user password.

Sets BIOS Setup Utility access rights for user level.

Enabled allows system to complete the boot process without a password. The keyboard remains locked until a password is entered. A password is required to boot from a diskette.

Power Menu

Using the Setup Program

Maintenance Main Advanced Security

Power

Boot Exit

APM

ACPI

The menu shown in Table 21 is used to set power management features.

Table 21. Power Menu

Feature Options Description

APM No Options When selected, displays the APM submenu.

ACPI No Options When selected, displays the ACPI submenu.

After Power Failure

Wake on LAN

Wake on PME

Wake on Modem Ring

• Stay Off

• Last State (default)

• Power On

• Stay Off (default)

• Power On

• Stay Off (default)

• Power On

• Stay Off (default)

• Power On

Determines the mode of operation if a power loss occurs.

Stays Off keeps the power off until the power button is pressed.

Last State restores the previous power state before power looss occurred.

Power On restores power to the computer.

Determines how the system responds to a LAN wake up event.

Determines how the system responds to a PCI-PME wake up event.

Specifies how the computer responds to a Modem Ring wake up event on an installed modem.

NOTE

✏

When an ACPI-capable operating system is configured for ACPI, only the ACPI Suspend State option affects power management. The ACPI Suspend State is not supported if the system is configured for APM.

Intel Desktop Boards D850MD and D850MV Product Guide

APM Submenu

To access this menu, select Power on the menu bar, then APM.

Maintenance Main Advanced Security

Power

APM

ACPI

The menu shown in Table 22 shows the setting options for the APM features.

Table 22. APM Submenu

Feature Options Description

Power Management • Disabled

• Enabled (default)

Inactivity Timer • Off

• 1 Minute

• 5 Minutes

• 10 Minutes

• 20 Minutes (default)

• 30 Minutes

• 60 Minutes

• 120 Minutes

Hard Drive • Disabled

• Enabled (default)

Enables or disables the APM feature.

Specifies the amount of time before the computer enters APM standby mode.

Enables power management for hard disks during APM standby mode.

Boot Exit

ACPI Submenu

Maintenance Main Advanced Security

The submenu represented in Table 23 shows the setting options for ACPI.

Table 23. ACPI Submenu

Feature Options Description

ACPI Suspend State

Wake on LAN from S5

• S1 State (default)

• S3 State

• Stay Off (default)

• Power On

Specifies the ACPI sleep state.

In ACPI soft-off mode only, determines how the system responds to a LAN wake up event when the system is in the ACPI soft-off mode.

Power

APM

ACPI

Boot Exit

Boot Menu

Using the Setup Program

Maintenance Main Advanced Security Power

The menu shown in Table 24 is used to set the boot features and the boot sequence.

Table 24. Boot Menu

Feature Options Description

Quiet Boot • Disabled

• Enabled (default)

Intel® Rapid BIOS Boot

Scan User Flash Area

Boot Device Priority No options Specifies the boot sequence from the available types of

Hard Disk Drives No options Specifies the boot sequence from the available hard disk

Removable Devices No options Specifies the boot sequence from the available removable

• Disabled

• Enabled (default)

• Disabled (default)

• Enabled

Disabled displays normal POST messages.

Enabled displays OEM graphic instead of POST messages.

Enables the computer to boot without running certain POST tests.

Enables the BIOS to scan the flash memory for user binary files that are executed at boot time.

boot devices.

drives.

devices.

Boot Device Priority

Boot

Exit

Maintenance Main Advanced Security Power

Boot

Boot Device Priority

The menu shown in Table 25 shows the setting options for Boot Device Priority.

Table 25. Boot Device Priority

Feature Options Description

1st Boot Device

Boot Device

• Removable Device

• Hard Drive

• ATAPI CD-ROM

• Intel

• Disabled

Boot A

Specifies the boot sequence from the available devices. Select the boot device with the Up-Arrow or Down-Arrow key. Press the Enter key to set the selection as the intended boot device.

Exit

Intel Desktop Boards D850MD and D850MV Product Guide

Exit Menu

Maintenance Main Advanced Security Power Boot

Exit

The menu shown in Table 26 is used to exit the BIOS Setup program, saving changes, and loading and saving defaults.

Table 26. Exit Menu

Feature Description

Exit Saving Changes Exits and saves the changes made in the BIOS Setup program.

Exit Discarding Changes Exits without saving any changes made in the BIOS Setup program.

Load Setup Defaults Loads the factory default values for all the Setup options.

Load Custom Defaults Loads the custom defaults for Setup options.

Save Custom Defaults Saves the current values as custom defaults. Normally, the BIOS reads the

Setup values from flash memory. If this memory is corrupted, the BIOS reads the custom defaults. If no custom defaults are set, the BIOS reads the factory defaults.

Discard Changes Discards changes without exiting Setup. The option values present when the

computer was turned on are used.

5 Technical Reference

Board Connectors

The board connectors can be divided into three groups:

• Back panel connectors

• Midboard connectors  Audio connectors  Power and hardware connectors  Add-in board and peripheral interface connectors

• Front panel connectors

CAUTION

Many of the midboard and front panel connectors provide operating voltage (+5 V dc and +12 V dc, for example) to devices inside the computer chassis, such as fans and internal peripherals. These connectors are not overcurrent protected. Do not use these connectors for powering devices external to the computer chassis. A fault in the load presented by the external devices could cause damage to the computer, the interconnecting cable, and the external devices themselves.

Intel Desktop Boards D850MD and D850MV Product Guide

Back Panel Connectors

Figure 21 shows the back panel connectors on the board.

BF KJGDI

Item Description Color

A PS/2 mouse port Green B PS/2 keyboard port Purple C USB port 0 Black D USB port 1 Black E Parallel port Burgundy F Serial port Teal G Serial port Teal H RJ-45 (optional) Black I USB port 2 Black

J USB port 3 Black K Mic in Pink L Audio line out Lime green M Audio line in Light blue

Figure 21. Back Panel Connectors

L M

OM11830

NOTE

✏

Midboard Connectors

Audio Connectors

Figure 22 shows the location of the audio connectors.

Technical Reference

Item Description Color

A Auxiliary line in (ATAPI) White B CD-ROM (ATAPI) Black C Front panel audio Black

Figure 22. Audio Connectors

OM11838

Intel Desktop Boards D850MD and D850MV Product Guide

Power and Hardware Connectors

CAUTION

Failure to use an ATX12V power supply, or not connecting the additional power supply lead to the D850MD or D850MV board may result in damage to the desktop board.

Figure 23 shows the power and hardware connectors for the D850MD board.

2 1

20 10

11 1

OM11839

Item Description Item Description

A Chassis intrusion E Main power B ATX12V power connector F Chassis fan (fan 2)

(tachometer input)

C Processor fan (CPU fan)

(tachometer input)

G SCSI hard drive activity

LED

D RIMM fan (fan 1)

Figure 23. D850MD Board Power and Hardware Control Connectors

Figure 24 shows the power and hardware connectors for the D850MV board.

Technical Reference

2 1

20 10

11 1

Item Description Item Description

A Chassis fan (fan 3) E RIMM fan (fan 1)

(tachometer input) B Chassis intrusion F Main power C ATX12V power G Chassis fan (fan 2) D Processor fan (CPU fan)

H SCSI hard drive activity LED

(tachometer input)

Figure 24. D850MV Board Power and Hardware Control Connectors

OM12077

Intel Desktop Boards D850MD and D850MV Product Guide

Add-In Card and Peripheral Interface Connectors

Figure 25 shows the add-in card and peripheral interface connectors for the D850MD board.

DCB

2 1

39 40

2 1

34 33

OM11840

Item Description Item Description

A CNR (optional) E AGP B PCI bus connector 3 F Diskette drive C PCI bus connector 2 G Primary IDE D PCI bus connector 1 H Secondary IDE

Figure 25. D850MD Board Add-in Card and Peripheral Interface Connectors

Technical Reference

Figure 26 shows the add-in card and peripheral interface connectors for the D850MV board.

2 1

39 40

2 1

34 33

Item Description Item Description

A CNR (optional) F PCI bus connector 1 B PCI bus connector 5 G AGP C PCI bus connector 4 H Diskette drive D PCI bus connector 3 I Primary IDE E PCI bus connector 2 J Secondary IDE

Figure 26. D850MV Board Add-in Card and Peripheral Interface Connectors

OM12074

Intel Desktop Boards D850MD and D850MV Product Guide

Front Panel Connectors

Figure 27 shows the location of the front panel connectors.

CBA

Item Description

A Front panel

B Alternate power/sleep LED

C Front panel USB

D Front panel audio

Figure 27. Front Panel Connectors

OM11841

Desktop Board Resources

Memory Map

Table 27. System Memory Map

Address Range (decimal) Address Range (hex) Size Description

1024 K - 2097152 K 100000 - 1FFFFFFF 2047 MB Extended Memory

960 K - 1024 K F0000 - FFFFF 64 KB Runtime BIOS

896 K - 960 K E0000 - EFFFF 64 KB Reserved

800 K - 896 K C8000 - DFFFF 96 KB Available high DOS memory (open

640 K - 800 K A0000 - C7FFF 160 KB Video memory and BIOS

639 K - 640 K 9FC00 - 9FFFF 1 KB Extended BIOS data (movable by

512 K - 639 K 80000 - 9FBFF 127 KB Extended conventional memory

0 K - 512 K 00000 - 7FFFF 512 KB Conventional memory

Technical Reference

to the PCI bus)

memory manager software)

DMA Channels

Table 28. DMA Channels

DMA Channel Number Data Width System Resource

0 8 or 16 bits

1 8 or 16 bits Parallel port

2 8 or 16 bits Diskette drive

3 8 or 16 bits Parallel port (for ECP or EPP)

4 8 or 16 bits DMA controller

5 16 bits Open

6 16 bits Open

7 16 bits Open

Intel Desktop Boards D850MD and D850MV Product Guide

I/O Map

Table 29. I/O Map

Address (hex) Size Description

0000 - 000F 16 bytes DMA controller

0020 - 0021 2 bytes Programmable Interrupt Control (PIC)

0040 - 0043 4 bytes System timer

0060 1 byte Keyboard controller byte—reset IRQ

0061 1 byte System speaker

0064 1 byte Keyboard controller, CMD / STAT byte

0070 - 0071 2 bytes System CMOS / Real Time Clock

0072 - 0073 2 bytes System CMOS

0080 - 008F 16 bytes DMA controller

0092 1 byte Fast A20 and PIC

00A0 - 00A1 2 bytes PIC

00B2 - 00B3 2 bytes APM control

00C0 - 00DF 32 bytes DMA

00F0 1 byte Numeric data processor

0170 - 0177 8 bytes Secondary IDE channel

01F0 - 01F7 8 bytes Primary IDE channel

0228 - 022F* 8 bytes LPT3

0278 - 027F* 8 bytes LPT2

02E8 - 02EF* 8 bytes COM4 / video (8514A)

02F8 - 02FF* 8 bytes COM2

0376 1 byte Secondary IDE channel command port

0377, bits 6:0 7 bits Secondary IDE channel status port

0378 - 037F 8 bytes LPT1

03B0 - 03BB 12 bytes Video (VGA)

03C0 - 03DF 32 bytes Video (VGA)

03E8 - 03EF 8 bytes COM3

03F0 - 03F5 6 bytes Diskette channel 1

03F6 1 byte Primary IDE channel command port

03F8 - 03FF 8 bytes COM1

04D0 - 04D1 2 bytes Edge / level triggered PIC

LPTn + 400 8 bytes ECP port, LPTn base address + 400h

0CF8 - 0CFB** 4 bytes PCI configuration address register

0CF9*** 1 byte Turbo and reset control register

0CFC - 0CFF 4 bytes PCI configuration data register

FFA0 - FFA7 8 bytes Primary bus master IDE registers

FFA8 - FFAF 8 bytes Secondary bus master IDE registers

continued

Table 29. I/O Map (continued)

Address (hex) Description

96 contiguous bytes starting on a 128-byte divisible boundary

64 contiguous bytes starting on a 64-byte divisible boundary

32 contiguous bytes starting on a 32-byte divisible boundary

16 contiguous bytes starting on a 16-byte divisible boundary

4096 contiguous bytes starting on a 4096-byte divisible boundary

256 contiguous bytes starting on a 256-byte divisible boundary

64 contiguous bytes starting on a 64-byte divisible boundary

32 contiguous bytes starting on a 32-byte divisible boundary

64 contiguous bytes starting on a 64-byte divisible boundary

96 contiguous bytes starting on a 128-byte divisible boundary

* Default, but can be changed to another address range.

** Dword access only.

*** Byte access only.

ICH2 (ACPI + TCO)

D850MD and D850MV board resource

ICH2 (USB controller #1)

ICH2 (SMBus)

Intel 82801BA PCI bridge

ICH2 audio mixer

ICH2 audio bus mixer

ICH2 (USB controller #2)

ICH2/Intel 82562ET (optional)

LPC47M142

Technical Reference

Intel Desktop Boards D850MD and D850MV Product Guide

Interrupts

Table 30. Interrupts

IRQ System Resource

NMI I/O channel check

0 Reserved, interval timer

1 Reserved, keyboard buffer full

2 Reserved, cascade interrupt from slave PIC

3COM2*

4COM1*

5 LPT2 (Plug and Play option) / **

6 Diskette drive controller

7LPT1*

8 Real time clock

9**

10 **

11 **

12 Onboard mouse port (if present, else user available)

13 Reserved, math coprocessor

14 Primary IDE (if present, else user available)

15 Secondary IDE (if present, else user available)

* Default, but can be changed to another IRQ.

** Dynamically allocated for all PCI/AGP devices and slots.

A Error Messages and Indicators

The D850MD and D850MV boards report POST errors in two ways:

• By sounding a beep code

• By displaying an error message on the monitor

BIOS Beep Codes

The BIOS beep codes are listed in Table 31. The BIOS also issues a beep code (one long tone followed by two short tones) during POST if the video configuration fails (a faulty video card or no card installed) or if an external ROM module does not properly checksum to zero.

Table 31. Beep Codes

Number of Beeps Description

1 Refresh failure

2 Parity cannot be reset

3 First 64 K memory failure

4 Timer not operational

5 Processor failure (Reserved; not used)

6 8042 GateA20 cannot be toggled (memory failure or not present)

7 Exception interrupt error

8 Display memory R/W error

9 (Reserved; not used)

10 CMOS Shutdown register test error

11 Invalid BIOS (such as, POST module not found)

Intel Desktop Boards D850MD and D850MV Product Guide

BIOS Error Messages

When a recoverable error occurs during the POST, the BIOS displays an error message describing the problem.

Table 32. BIOS Error Messages

Error Message Explanation

GA20 Error An error occurred with GateA20 when switching to protected mode

during the memory test.

Pri Master HDD Error Pri Slave HDD Error Sec Master HDD Error Sec Slave HDD Error

Pri Master Drive - ATAPI Incompatible Pri Slave Drive - ATAPI Incompatible Sec Master Drive - ATAPI Incompatible Sec Slave Drive - ATAPI Incompatible

A: Drive Error B: Drive Error

CMOS Battery Low The battery may be losing power. Replace the battery soon.

CMOS Display Type Wrong The display type is different than what has been stored in CMOS.

CMOS Checksum Bad The CMOS checksum is incorrect. CMOS memory may have been

CMOS Settings Wrong CMOS values are not the same as the last boot. These values

CMOS Date/Time Not Set The time and/or date values stored in CMOS are invalid. Run

DMA Error Error during read/write test of DMA controller.

FDC Failure Error occurred trying to access diskette drive controller.

HDC Failure Error occurred trying to access hard disk controller.

Checking NVRAM..... NVRAM is being checked to see if it is valid.

Update OK! NVRAM was invalid and has been updated.

Updated Failed NVRAM was invalid but was unable to be updated.

Keyboard Is Locked The system keyboard lock is engaged. The system must be

Keyboard Error Error in the keyboard connection. Make sure keyboard is

KB/Interface Error Keyboard interface test failed.

Memory Size Decreased Memory size has decreased since the last boot. If no memory was

Could not read sector from corresponding drive.

Corresponding drive is not an ATAPI device. Run Setup to make sure device is selected correctly.

No response from diskette drive.

Check Setup to make sure type is correct.

corrupted. Run Setup to reset values.

have either been corrupted or the battery has failed.

Setup to set correct values.

unlocked to continue to boot.

connected properly.

removed, then memory may be bad.

continued

Error Messages and Indicators

Table 32. BIOS Error Messages (continued)

Error Message Explanation

Memory Size Increased Memory size has increased since the last boot. If no memory was

added, there may be a problem with the system.

Memory Size Changed Memory size has changed since the last boot. If no memory was

added or removed, then memory may be bad.

No Boot Device Available System did not find a device to boot.

Off Board Parity Error A parity error occurred on an offboard card. This error is followed

by an address.

On Board Parity Error A parity error occurred in onboard memory. This error is followed

by an address.

Parity Error A parity error occurred in onboard memory at an unknown

address.

NVRAM / CMOS / PASSWORD cleared by Jumper

<CTRL_N> Pressed CMOS is ignored and NVRAM is cleared. User must enter Setup.

NVRAM, CMOS, and passwords have been cleared. The system should be powered down and the jumper removed.

Intel Desktop Boards D850MD and D850MV Product Guide

B Regulatory Compliance

This appendix contains:

• Safety standards, electromagnetic compatibility (EMC) regulations, and product certification

markings for D850MD and D850MV desktop boards

• Instructions and precautions for integrators who are installing this desktop board in a chassis

Safety Regulations

This desktop board complies with the safety regulations stated in Table 33 when correctly installed in a compatible host system.

Table 33. Safety Regulations

Regulation Title

UL 1950/CSA C22.2 No. 950, 3rd edition

EN 60950, 2nd Edition, 1992 (with Amendments 1, 2, 3, and 4)

IEC 60950, 2nd edition, 1991 (with Amendments 1, 2, 3, and 4)

EMKO-TSE (74-SEC) 207/94 Summary of Nordic deviations to EN 60950. (Norway, Sweden,

Bi-National Standard for Safety of Information Technology Equipment including Electrical Business Equipment. (USA and Canada)

The Standard for Safety of Information Technology Equipment including Electrical Business Equipment. (European Union)

The Standard for Safety of Information Technology Equipment including Electrical Business Equipment. (International)

Denmark, and Finland)

EMC Regulations

The desktop board complies with the EMC regulations stated in Table 34 when correctly installed in a compatible host system.

Table 34. EMC Regulations

Regulation Title

FCC Class B Title 47 of the Code of Federal Regulations, Parts 2 and 15, Subpart B,

Radiofrequency Devices. (USA)

ICES-003 (Class B) Interference-Causing Equipment Standard, Digital Apparatus. (Canada)

EN55022: 1998 (Class B) Limits and methods of measurement of Radio Interference Characteristics of

Information Technology Equipment. (European Union)

EN55024: 1998 Information Technology Equipment – Immunity Characteristics Limits and

methods of measurement. (European Union)

AS/NZS 3548 (Class B) Australian Communications Authority, Standard for Electromagnetic

Compatibility. (Australia and New Zealand)

CISPR 22, 3rd Edition, (Class B)

CISPR 24: 1997 Information Technology Equipment – Immunity Characteristics – Limits and

Limits and methods of measurement of Radio Disturbance Characteristics of Information Technology Equipment. (International)

Methods of Measurement. (International)

Intel Desktop Boards D850MD and D850MV Product Guide

Product Certification Markings

The desktop boards have the following product certification markings:

• UL joint US/Canada Recognized Component mark: consists of small c followed by a stylized

backward UR and followed by a small US. Includes adjacent UL file number for Intel desktop boards: E210882 (component side).

• FCC Declaration of Conformity logo mark for Class B equipment; includes Intel name and

model designation (solder side).

• CE mark: declaring compliance to European Union (EU) EMC directive (89/336/EEC) and

Low Voltage directive (73/23/EEC) (component side).

• Australian Communications Authority (ACA) C-Tick mark: consists of a stylized C overlaid

with a check (tick) mark (component side), followed by Intel supplier code number, N-232.

• Printed wiring board manufacturer’s recognition mark: consists of a unique UL recognized

manufacturer’s logo, along with a flammability rating (94V-0) (solder side).

• PB part number: Intel bare circuit board part number (solder side):  A49682-002 (for D850MD board)  A56437-001 (for D850MV board)

Also includes SKU number starting with AA followed by additional alphanumeric characters.

• Battery “+ Side Up” marking: located on the component side of the board in close proximity to the battery holder.

• Korean MIC logo mark: denotes Korean EMC certification (component side). Additional certification information is provided below:

1. Product Name (model)

2. Certificate ID

3. Applicant: Intel Korea Ltd.

4. Date of manufacture as separate marking on product

5. Manufacturer (country of origin)

Korean MIC logo mark for the D850MD board

Korean MIC logo mark for the D850MV board

Error Messages and Indicators

Installation Precautions

When you install and test the desktop board, observe all warnings and cautions in the installation instructions.

To avoid injury, be careful of:

• Sharp pins on connectors

• Sharp pins on printed circuit assemblies

• Rough edges and sharp corners on the chassis

• Hot components (like processors, voltage regulators, and heat sinks)

• Damage to wires that could cause a short circuit

Observe all warnings and cautions that instruct you to refer computer servicing to qualified technical personnel.

Installation Instructions

CAUTION

Follow these guidelines to meet safety and regulatory requirements when installing this board assembly.

Read and adhere to all of these instructions and the instructions supplied with the chassis and associated modules. If the instructions for the chassis are inconsistent with these instructions or the instructions for associated modules, contact the supplier’s technical support to find out how you can ensure that your computer meets safety and regulatory requirements. If you do not follow these instructions and the instructions provided by chassis and module suppliers, you increase safety risk and the possibility of noncompliance with regional laws and regulations.

Ensure Electromagnetic Compatibility (EMC) Compliance

Before computer integration, make sure that the power supply and other modules or peripherals, as applicable, have passed Class B EMC testing and are marked accordingly.

In the installation instructions for the host chassis, power supply, and other modules pay close attention to the following:

• Product certifications or lack of certifications

• External I/O cable shielding and filtering

• Mounting, grounding, and bonding requirements

• Keying connectors when mating the wrong connectors could be hazardous

If the power supply and other modules or peripherals, as applicable, are not Class B EMC compliant before integration, then EMC testing is required on a representative sample of the newly completed computer.

Intel Desktop Boards D850MD and D850MV Product Guide

Chassis and Component Certifications

Ensure that the chassis and certain components; such as the power supply, peripheral drives, wiring, and cables; are components certified for the country or market where used. Agency certification marks on the product are proof of certification. Typical product certifications include:

In Europe

The CE marking signifies compliance with all applicable European requirements. If the chassis and other components are not properly CE marked, a supplier’s Declaration of Conformity statement to the European EMC directive and Low Voltage directive (as applicable), should be obtained. Additionally, other directives, such as the Radio and Telecommunications Terminal Equipment (R&TTE) directive may also apply depending on product features.

In the United States

A certification mark by a Nationally Recognized Testing Laboratory (NRTL) such as UL, CSA, or ETL signifies compliance with safety requirements. Wiring and cables must also be UL listed or recognized and suitable for the intended use. The FCC Class B logo for home or office use signifies compliance with electromagnetic interference (EMI) requirements.

In Canada

A nationally recognized certification mark such as CSA or cUL signifies compliance with safety requirements. The Industry Canada statement at the front of this product guide demonstrates compliance with Canadian EMC regulations. Industry Canada recognizes and accepts FCC certification as denoting compliance with national electromagnetic interference (emissions) requirements.

Prevent Power Supply Overload

Do not overload the power supply output. To avoid overloading the power supply, make sure that the calculated total current loads of all the modules within the computer is less than the output current rating of each of the power supplies output circuits.

Place Battery Marking

There is insufficient space on this desktop board to provide instructions for replacing and disposing of the Lithium ion coin cell battery. For system safety certification, the following statement or equivalent statement is required to be permanently and legibly marked on the chassis near the battery.

CAUTION

Risk of explosion if battery is incorrectly replaced.

Replace with only the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer’s instructions.

Error Messages and Indicators

Use Only for Intended Applications
