Intel® 440EX AGPset
Design Guide
April 1998
Order Number: 290637-001
Information in this document is provided in connection with Intel products. No license, express or implied, by estoppel or otherwise, to any intellectual
property rights is granted by this document. Except as provided in Intel's Terms and Conditions of Sale for such products, Intel assumes no liability
whatsoever, and Intel disclaims any express or implied warranty, relating to sale and/or use of Intel products including liability or warranties relating to
fitness for a particular purpose, merchantability, or infringement of any patent, copyright or other intellectual property right. Intel products are not
intended for use in medical, life saving, or life sustaining applications.
Intel may make changes to specifications and product descriptions at any time, without notice.
Contact your local Intel sales office or your distributor to obtain the latest specifications and before placing your product order.
The 82443EX may contain design defects or errors known as errata which may cause the products to deviate from published specifications. Such
errata are not covered by Intel’s warranty. Current characterized errata are available on request.
2
I
C is a two-wire communications bus/protocol developed by Philips. SMBus is a subset of the I2C bus/protocol and was developed by Intel.
Implementations of the I
North American Philips Corporation.
Copies of documents which have an ordering number and are referenced in this document, or other Intel literature may be obtained by:
calling 1-800-548-4725 or
by visiting Intel's website at http://www.intel.com.
Copyright © Intel Corporation, 1998
*Third-party brands and names are the property of their respective owners.
2
C bus/protocol or the SMBus bus/protocol may require licenses from various entities, including Philips Electronics N.V. and
®
Intel
440EX AGPset
Design Guide
Contents
1 Introduction................................................................................................................1-1
1.1 Reference Documents ..................................................................................1-1
1.2 82443EX/82443LX Pin Differences ..............................................................1-2
1.3 82443EX/82443LX Register Differences ......................................................1-3
1.4 Additional Information ...................................................................................1-3
®
Intel
440EX AGPset
Design G uide
iii
Revision History
Date of
Revision
April 1998 001 Initial Release
Revision Description
iv
®
Intel
440EX AGPset
Design Guide
Introduction
Introduction
This information is being provided to Intel customers designing with the Intel® 440EX AGPset.
The Intel
The guidelines in this document are provided in conjunction with the Intel
Guide. The Inte l
in this document.
The 82443EX is a full featured 82443LX with the following exceptions:
1.1 Reference Documents
®
440EX AGPset is the Basic PC solution for the Pentium® II processor platform.
®
440LX AGPset Design Guide should be followed in all areas except those listed
1.0.1 Maximum of 2 DIMM sockets
•
1.0.2 Maximum of 3 PCI slots (4-PCI masters including PIIX4)
•
1.0.3 NO ECC
•
1.0.4 Single processor with no support for IOAPIC
•
1.0.5 Nand Tree Test Mode not supported
•
Intel® 440EX AGPset datasheet
•
(www: order number 290616)
Intel® 440LX AGPset Design Guide
•
(http://developer.intel.com/design/pcisets/designex)
®
440LX AGPset Design
1
Intel® 440LX AGPset Application Notes and Specification Updates
•
(www.intel.com)
®
Intel
440EX AGPset
Design Guide
1-1
Introduction
1.2 82443EX/82443LX Pin Differences
:
Pin differences between the 82443LX and 82443EX are as follows:
Ball Number 82443LX Name
AF13 SRAS2# O NC 1.0.1
AF10 SCAS2# O NC 1.0.1
AC19 RCSA4# O NC 1.0.1
AB17 RCSA5# O NC 1.0.1
AF9 WE2# NC 1.0.1
AC12 WE3# NC 1.0.1
AD14 MAB0 O NC 1.0.1
AF14 MAB1 O NC 1.0.1
AE14 RCSA6#/MAB2 O NC 1.0.1
AB14 RCSA7#/MAB3 O NC 1.0.1
AE15 SCAS3#/MAB4 O NC 1 .0.1
AF15 SRAS3#/MAB5 O NC 1.0.1
AA19 RCSB0#/MAB6 O NC 1.0.1
AF16 RCSB1#/MAB7 O NC 1.0.1
AB19 RCSB2#/MAB8 O NC 1.0.1
AE16 RCSB3#/MAB9 O NC 1.0.1
AF18 RCSB4#/MAB10 O NC 1.0.1
AD18 RCSB5#/MAB11 O NC 1.0.1
AB18 RCSB6#/MAB12 O NC 1.0.1
AD17 RCSB7#/MAB13 O NC 1.0.1
AF12 CDQB1# O NC 1.0.1
AE12 CDQB5# O NC 1.0.1
B12 GNT3# O NC 1.0.2
D12 GNT4# O NC 1.0.2
B13 REQ3# I TM1 (PU) 1.0.2
D13 REQ4# I TM2 (PU) 1.0.2, 1.0.5
U23 ECCERR# O NC 1.0.3
AD8 MECC0 NC 1.0.3
AE8 MECC1 NC 1.0.3
AF22 MECC2 NC 1.0.3
AB21 MECC3 NC 1.0.3
AC8 MECC4 NC 1.0.3
AB9 MECC5 NC 1.0.3
AE22 MECC6 NC 1.0.3
AD22 MECC7 NC 1.0.3
V24 WSC# O NC 1.0.4
82443LX Type of
Pin
82443EX Name
Relationship to
Reduced Feature
1-2
NOTES:
1. All pins labeled NC are NO CONNECTS and should not be connected on the motherboard
2. All pins labeled (PU) should be connected to a 4.7K to 10K ohm pull-up resistor to 3.3V on the motherboard.
®
Intel
440EX AGPset
Design Guide
1.3 82443EX/82443LX Register Differences
Register changes between the 82443LX and 82 443 EX are shown below. These specific register/bit
combinations are now Reserved and should be set to their default state to support the Intel 440EX
AGPset. Refer to the Intel
PACCFG - PAC Configuration Register (Device 0) 50-51h Bit 15 - Set to “1”
MBSC - Memory Buffer Strength Control Register
(Device 0)
ERRCMD - Error Command Register (Device 0) 90h Bit 1 - Reserved/Default
ERRSTS0 - Error Status Register 0 (Device 0) 91h Bit 7:0 - Reserved/Default
®
440EX AGPset datasheet for more detail.
Register Name Address Offset Change To
Bit 14 - Reserved/Default
Bit 13:11 - Reserved/Default
Bit 8:7 - Reserved/Default
Bit 6 - Reserved/Default
Bit 4:3 - Reserved/Default
Bit 2 - Reserved
Bit 1:0 - Reserved/Default
6C-6Fh Bit 23:22 - Reserved/Default
Bit 13:12 - Reserved/Default
Bit 11:10 - Reserved/Default
Bit 5:4 - Reserved/Default
Bit 3:2 - Reserved/Default
Bit 1:0 - Reserved/Default
Bit 0 - Reserved/Default
Introduction
1.4 Additional Information
All Intel® 440LX AGPset Applications Notes and Specification Updates apply to the Intel® 440EX
AGPset. These documents are available on the WEB or through Intel Field Representatives.
http://developer.intel.com/pcisets
®
Intel
440EX AGPset
Design Guide
1-3
