For Husqvarna Parts Call 606-678-9623 or 606-561-4983
Ride Mower
YTH2148
(LO21H48E), 954572035
Illustrated
Parts List
2004-04
I0402028
Repair Parts Manual
www.mymowerparts.com
For Husqvarna Parts Call 606-678-9623 or 606-561-4983
www.mymowerparts.com
For Husqvarna Parts Call 606-678-9623 or 606-561-4983
TRACTOR - MODEL NO. YTH2148 (LO21H48E), PRODUCT NO. 954 57 20-35
SCHEMATIC
AMMETER
(OPTIONAL)
RED
G
IGNITION
SWITCH
BLACK
BROWN
RED
BATTERY
A
RED
FUSE
WHITE
S
B
BLACK
M
A1
CG
B
RED
WHITE
F
H
A2L
E
BLACK
A
D
ORANGE
PTO (DISENGAGED)
BLACK
CLUTCH / BRAKE
BLACK
(PEDAL UP)
RED
BLACK
RED
WHITE
SOLENOID
ELECTRIC CLUTCH
SEAT SWITCH
(NOT OCCUPIED)
RED
M
STARTER
BLACK
GROUNDING
BLUE
HOUR
METER
(OPTIONAL)
CONNECTOR
BLACK
IGNITION SWITCH
CIRCUITPOSITION
OFF
M+G+A1
B+A1ON + LIGHTS
B+A1ON
B+S+A1START
“MAKE”
NONE
L+A2
NONE
NONE
FUEL
LINE
RED
FUEL SHUT-OFF
SOLENOID
WIRING INSULATED CLIPS
NOTE: IF WIRING INSULATED
CLIPS WERE REMOVED FOR
SERVICING OF UNIT, THEY
SHOULD BE REPLACED TO
PROPERLY SECURE YOUR
WIRING.
02757
CHARGING SYSTEM OUTPUT
16 AMP DC @ 3600 RPM
RED
REMOVABLE
CONNECTIONS
IGNITION
UNIT
REGULATOR
PTO SWITCH
OFF
SPARK PLUGS
ON TWIN CYL. ENGINES)
BROWN
HEADLIGHTS
CIRCUITPOSITION
C+G,B+H
C+F,B+E,A+DON
NON-REMOVABLE
CONNECTIONS
GAP
(2 PLUGS
28 VOLTS AC @ 3600 RPM
(REGULATOR DISCONNECTED)
ALTERNATOR
BLACK
FC
G
H
PTO SWITCH
CONNECTOR
E
A
D
B
29
www.mymowerparts.com
For Husqvarna Parts Call 606-678-9623 or 606-561-4983
REPAIR PARTS
TRACTOR - MODEL NO. YTH2148 (LO21H48E), PRODUCT NO. 954 57 20-35
ELECTRICAL
22
24
90
27
43
27
42
25
41
27
27
21
40
26
16
33
30
50
2
91
27
1
D
.
C
.
A
M
P
E
R
E
S
89
29
46
45
55
8
_27
Battery
28
30
www.mymowerparts.com
For Husqvarna Parts Call 606-678-9623 or 606-561-4983
REPAIR PARTS
TRACTOR - MODEL NO. YTH2148 (LO21H48E), PRODUCT NO. 954 57 20-35
ELECTRICAL
KEY PART
NO. NO. DESCRIPTION
1 532 14 49-27 Battery
2 874 76 04-12 Bolt Hex Hd 1/4-20 unc x 3/4
8 532 18 64-91 Box Battery
16 532 17 61-38 Switch Interlock Push-In
21 532 18 37-59 Harness Asm Light W/4152j
22 532 00 41-52 Bulb Light #1156
24 532 12 47-80 Cable Battery 6 Ga. 11" red
25 532 14 61-48 Cable Battery 6 Ga. 22" red w/16 wire
26 532 17 51-58 Fuse 20 AMP
27 873 51 04-00 Nut Keps Hex 1/4-20 unc
28 532 14 54-91 Cable Ground black
29 532 12 13-05 Switch Plunger Nc Gray
30 532 18 96-87 Switch Ign
33 532 14 04-01 Key Ign Molded Generic
40 532 18 80-24 Harness Ign.
41 871 11 04-08 Bolt Blk Fin Hex 1/4 - 20 x 1/2
42 532 13 15-63 Cover Terminal Red
43 532 17 88-61 Solenoid
45 532 12 28-22 Ammeter
46 532 16 96-35 Hourmeter Snap-In
50 532 17 46-51 Switch PTO
55 817 49 05-08 Screw Throl 5/16-18 x 1/2
89 532 16 96-39 Bracket Snap-In Hourmeter
90 532 18 04-49 Cover Terminal
91 532 19 02-70 Strap Battery
NOTE: All component dimensions given in U.S. inches.
1 inch = 25.4 mm.
31
www.mymowerparts.com
For Husqvarna Parts Call 606-678-9623 or 606-561-4983
REPAIR PARTS
TRACTOR - MODEL NO. YTH2148 (LO21H48E), PRODUCT NO. 954 57 20-35
CHASSIS AND ENCLOSURES
259
212
28
212
17
213
258
90
208
31
209
11
217
10
159
278
280
30
55
277
9
276
209
53
278
10
209
209
39
278
214
58
280
158
64
1
13
145
37
208
chassis_elite husqy_4
38
144
142
14
209
60
37
144
26
26
38
14
209
60
142
2
26
26
143
74
209
32
