Hp Spectre 13 Ultrabook, Spectre 13 PRO Ultrabook User Manual

HP Spectre 13 Pro Ultrabook and HP Spectre 13 Ultrabook

Maintenance and Service Guide IMPORTANT! This document is intended for HP authorized service providers only.

Bluetooth is a trademark owned by its proprietor and used by Hewlett-Packard Company under license. Intel and Core are U.S. registered trademarks of Intel Corporation. Microsoft, Windows, and Windows Vista are U.S. registered trademarks of Microsoft Corporation. SD Logo is a trademark of its proprietor.

The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.

Second Edition: December 2013

First Edition: October 2013

Document Part Number: 736655-002

Safety warning notice

WARNING! To reduce the possibility of heat-related injuries or of overheating the device, do not

place the device directly on your lap or obstruct the device air vents. Use the device only on a hard, flat surface. Do not allow another hard surface, such as an adjoining optional printer, or a soft surface, such as pillows or rugs or clothing, to block airflow. Also, do not allow the AC adapter to contact the skin or a soft surface, such as pillows or rugs or clothing, during operation. The device and the AC adapter comply with the user-accessible surface temperature limits defined by the International Standard for Safety of Information Technology Equipment (IEC 60950).

iii

iv Safety warning notice

Table of contents

1 Product description ........................................................................................................... 1

2 External component identification ..................................................................................... 4

Display ................................................................................................................................... 4

Top ........................................................................................................................................ 6

TouchPad ................................................................................................................. 6

Lights ....................................................................................................................... 7

Buttons ..................................................................................................................... 8

Keys ........................................................................................................................ 9

Left side ................................................................................................................................ 10

Right side .............................................................................................................................. 12

Bottom .................................................................................................................................. 13

Labels ................................................................................................................................... 14

3 Illustrated parts catalog .................................................................................................. 16

Computer major components ................................................................................................... 16

Rubber Kit ............................................................................................................................. 18

Mass storage devices ............................................................................................................. 18

Miscellaneous parts ................................................................................................................ 19

Sequential part number listing .................................................................................................. 20

4 Removal and replacement procedures ............................................................................ 23

Preliminary replacement requirements ....................................................................................... 23

Tools required ......................................................................................................... 23

Service considerations ............................................................................................. 23

Plastic parts ............................................................................................. 23

Cables and connectors ............................................................................. 23

Drive handling ......................................................................................... 24

Grounding guidelines .............................................................................................. 24

Electrostatic discharge damage .................................................................. 24

Packaging and transporting guidelines ........................................ 26

Component replacement procedures ........................................................................................ 28

Feet ....................................................................................................................... 28

Bottom cover .......................................................................................................... 29

Solid-state drive (SSD) .............................................................................................. 30

WLAN module ........................................................................................................ 32

Display assembly .................................................................................................... 34

Speaker assembly ................................................................................................... 37

Touchpad ............................................................................................................... 39

Fan ....................................................................................................................... 41

Heat sink ................................................................................................................ 43

Battery ................................................................................................................... 46

System board ......................................................................................................... 48

Power connector cable ............................................................................................ 51

Power button board ................................................................................................. 52

Keyboard and top cover .......................................................................................... 54

5 Using Setup Utility (BIOS) and HP PC Hardware Diagnostics (UEFI) .................................. 57

Starting Setup Utility (BIOS) ..................................................................................................... 57

Updating the BIOS ................................................................................................................. 57

Determining the BIOS version ................................................................................... 57

Downloading a BIOS update .................................................................................... 58

Using HP PC Hardware Diagnostics (UEFI) ................................................................................ 59

Downloading HP PC Hardware Diagnostics (UEFI) to a USB device ............................... 59

6 Specifications ................................................................................................................. 60

Computer specifications .......................................................................................................... 60

13.3-inch FHD display specifications ........................................................................................ 61

13.3-inch QHD display specifications ....................................................................................... 62

7 Backing up, restoring, and recovering ............................................................................ 63

Creating recovery media and backups ..................................................................................... 63

Creating HP Recovery media .................................................................................... 63

Restore and recovery .............................................................................................................. 65

Recovering using HP Recovery Manager .................................................................... 65

What you need to know ............................................................................ 66

Using the HP Recovery partition (select models only) ..................................... 66

Using HP Recovery media to recover .......................................................... 67

Changing the computer boot order ............................................................. 67

Removing the HP Recovery partition .......................................................................... 67

8 Power cord set requirements .......................................................................................... 68

Requirements for all countries .................................................................................................. 68

Requirements for specific countries and regions ......................................................................... 69

9 Recycling ........................................................................................................................ 70

Index ................................................................................................................................. 71

vii

viii

1 Product description

Category Description

Product Name HP Spectre 13 Pro Ultrabook

HP Spectre 13 Ultrabook

Processors Intel Quad Core i7-4500U 1.80-GHz processor (turbo up to 3.00-GHz;

1600-MHz FSB, 4.0-MB cache, dual core, 15 W; configured with 8-GB RAM only)

Intel® Quad Core® i5-4200U 1.60-GHz processor (turbo up to 2.60GHz; 1600-MHz FSB, 3.0-MB cache, dual core. 15 W)

Chipset Intel Lynx Point - LP PCH (Integrated in MCP)

Graphics Intel HD Graphics 4400

Supports HD Decode, DX11, and HDMI

Panel Flush glass design, touchscreen, multitouch enabled, 340 nits

●

(33.8-cm) 13.3-in display, WLED, full-high definition (FHD) (1920x1080), BrightView, 2.85-mm, UWVA (eDP 1.2) at 72% Color Gamut

●

(33.8-cm) 13.3-in display, WLED, Quad High Definition (QHD) (2560x1440), BrightView, 2.55-mm, UWVA (eDP1.3+PSR) at 72% Color Gamut

Memory No customer-accessible/upgradable memory module slots

DDR3L-1600-MHz dual channel support

Supports up to 8 GB of system RAM integrated into the system board in the following options:

●

8192-MB

●

4096-MB

Solid-state drive Single M.2 SSD Configuration as storage

Supports the following SSDs:

●

512-GB

●

256-GB

128-GB

Category Description

Audio and video Dual speakers

Beats Audio

Supports Microsoft Premium Requirements

Webcam and Microphone HP TrueVision Full HD: Full HD camera - Fixed (no tilt) + activity LED, 1PC,

USB 2.0, M-JPEG, 1920x1080 by 30 frames per second

Dual array digital microphones with software; beam forming, echo cancellation, noise suppression; supports voice recognition

Wireless Integrated Wireless options with dual antennas (NGFF/PCIe)

Intel WiDi support

Miracast support

●

Intel Dual Band Wireless-AC 7260 802.11 AC 2x2 WiFi + BT 4.0 Combo Adapter (except Indonesia, Russia, and Ukraine)

●

Intel Wireless 7260BN 802.11 bgn 2x2 WiFi + BT 4.0 Combo Adapter (default for Indonesia, Russia, and Ukraine)

External expansion cards HP Multi-Format Digital Media Card Reader

Supports SD/SDHC/SDXC

Push-push insertion/removal

Internal expansion cards One NGFF slot (2230) for WLAN

One NGFF slot (2280) for SSD

Ports Headphone output and microphone input combo jack (stereo)

One mini Display Port supporting 2560x1600 max. 3200x2000 @ 60 Hz resolution

Supports HP USB Boost (Sleep and Charge) on both ports

AC Smart Pin adapter plug

USB 3.0 ports (2)

HDMI v1.4b supporting: up to 1920x1200 @ 60Hz

Keyboard/pointing devices Full-size, backlit, island-style keyboard (Dura-coat, champagne gold color)

Touchpad: default on, 2-finger scroll, pinch, rotate, 2-finger click, 3-finger

flick

●

ClickPad with imaging sensor

●

Multitouch gestures enabled

●

Supports Windows 8 modern trackpad gestures

2 Chapter 1 Product description

●

Taps enabled as default

Category Description

Power requirements Supports 45W Smart Adapter (4.5mm barrel connector)

1.8 M length AC and DC power cords

4 cell battery, 51 WHr

Security Intel AT-p Ready support

Kensington Security Lock

Trust Platfom Module (TPM) support

Operating system Windows 8.1

Serviceability End user replaceable part:

AC adapter

2 External component identification

Display

Component Description

(1) Internal display switch Turns off the display and initiates Sleep if the display is closed

(2) WLAN antennas (2)* Send and receive wireless signals to communicate with wireless

(3) Internal microphones (2) Record sound.

(4) Ambient light sensor Automatically adjusts the display brightness based on the lighting

4 Chapter 2 External component identification

while the power is on.

NOTE: The internal display switch is not visible from the

outside of the computer.

local area networks (WLANs).

conditions in your environment.

Component Description

(5) Webcam Records video and captures photographs. Some models may

allow you to video conference and chat online using streaming video.

To use the webcam, from the Start screen, type cyberlink, and then select CyberLink YouCam from the list of applications.

(6) Webcam light On: The webcam is in use.

*The antennas are not visible from the outside of the computer. For optimal transmission, keep the areas immediately around the antennas free from obstructions. For wireless regulatory notices, see the section of the Regulatory, Safety, and Environmental Notices that applies to your country or region. To access this guide, from the Start screen, type support, and then select the HP Support Assistant app.

Display

Top

TouchPad

Component Description

(1) Left control zone Textured area that allows you to perform additional

gestures.

(2) TouchPad zone Moves the on-screen pointer and selects or activates items on

the screen.

NOTE: The TouchPad also supports edge-swipe gestures.

(3) Left TouchPad button Functions like the left button on an external mouse.

(4) Right TouchPad button Functions like the right button on an external mouse.

(5) Right control zone Textured area that allows you to perform additional

gestures.

6 Chapter 2 External component identification

Lights

Component Description

(1)

(2) Caps lock light On: Caps lock is on, switching the keys to all capital letters.

(3)

(4)

Power light

Mute light

Wireless light On: An integrated wireless device, such as a wireless local

●

On: The computer is on.

●

Blinking: The computer is in the Sleep state, a powersaving state. The computer shuts off power to the display and other unneeded components.

●

Off: The computer is off or in Hibernation. Hibernation is a power-saving state that uses the least amount of power.

NOTE: For select models, the Intel® Rapid Start

Technology feature is enabled at the factory. Rapid Start Technology allows your computer to resume quickly from inactivity.

●

Amber: Computer sound is off.

●

Off: Computer sound is on.

area network (WLAN) device and/or a Bluetooth® device, is on.

NOTE: On some models, the wireless light is amber when

all wireless devices are off.

Top

Buttons

Component Description

Power button

●

When the computer is off, press the button to turn on the computer.

●

When the computer is on, press the button briefly to initiate Sleep.

●

When the computer is in the Sleep state, press the button briefly to exit Sleep.

●

When the computer is in Hibernation, press the button briefly to exit Hibernation.

CAUTION: Pressing and holding down the power button

results in the loss of unsaved information.

If the computer has stopped responding and Windows® shutdown procedures are ineffective, press and hold the power button down for at least 5 seconds to turn off the computer.

NOTE: For select models, the Intel® Rapid Start Technology

feature is enabled at the factory. Rapid Start Technology allows your computer to resume quickly from inactivity.

To learn more about your power settings, from the Start screen, type power options, select Settings, and then select Power Options from the list of applications.

8 Chapter 2 External component identification

Keys

Component Description

(1) esc key Reveals system information when pressed in combination

with the fn key.

(2) fn key Executes frequently used system functions when pressed in

combination with the esc key.

(3)

(4) Action keys Execute frequently used system functions.

(5)

Windows key Returns you to the Start screen from any app or window.

NOTE: Pressing the Windows key again will return you to

the most recent app that you had open.

Windows applications key Reveals options for a selected object.

Top

Left side

Component Description

(1)

(2)

(3)

Security cable slot Attaches an optional security cable to the computer.

NOTE: The security cable is designed to act as a deterrent,

but it may not prevent the computer from being mishandled or stolen.

USB 3.0 charging (powered) port Connects an optional USB device. USB charging ports allow

you to charge connected USB devices. Standard USB ports will not charge all USB devices or will charge using a low current. Some USB devices require power and require you to use a powered port.

NOTE: USB charging ports can also charge select models

of cell phones and MP3 players, even when the computer is off.

Audio-out (headphone)/Audio-in (microphone) combo jack

Connects optional powered stereo speakers, headphones, earbuds, a headset, or a television audio cable. Also connects an optional headset microphone. This jack does not support optional microphone-only devices.

WARNING! To reduce the risk of personal injury, adjust

the volume before putting on headphones, earbuds, or a headset. For additional safety information, refer to the Regulatory, Safety, and Environmental Notices. To access this guide, from the Start screen, type support, and then select the HP Support Assistant app.

10 Chapter 2 External component identification

NOTE: When a device is connected to the jack, the

computer speakers are disabled.

NOTE: Be sure that the device cable has a 4-conductor

connector that supports both audio-out (headphone) and audio-in (microphone).

Component Description

(4)

(5)

Memory card reader Connects optional memory cards that store, manage, share,

or access information.

To insert, hold the card label side up with connectors facing the slot, and press in on the card until it is firmly seated.

To remove, press in on the card and quickly release it. The card pops out.

Hard drive light Blinking white: The hard drive is being accessed.

Left side

Right side

Component Description

(1)

(2)

(3)

(4) AC adapter light

(5)

USB 3.0 port Connects an optional USB device. USB charging ports allow

Mini DisplayPort Connects an optional digital display device, such as a high-

HDMI port Connects an optional video or audio device, such as a high-

Power connector Connects an AC adapter.

you to charge connected USB devices. Standard USB ports will not charge all USB devices or will charge using a low current. Some USB devices require power and require you to use a powered port.

NOTE: USB charging ports can also charge select models

of cell phones and MP3 players, even when the computer is off.

performance monitor or projector.

definition television, any compatible digital or audio component, or a high-speed HDMI device.

●

On: The AC adapter is connected and the battery is charged.

●

Off: The computer is using battery power.

12 Chapter 2 External component identification

Bottom

Component Description

(1) Vent Enables airflow to cool internal components.

NOTE: The computer fan starts up automatically to cool internal

components and prevent overheating. It is normal for the internal fan to cycle on and off during routine operation.

(2) Speakers (2) Produce sound.

Bottom

Labels

The labels affixed to the computer provide information you may need when you troubleshoot system problems or travel internationally with the computer.

IMPORTANT: All labels described in this section will be located in one of 3 places, depending on

your computer model: Affixed to the bottom of the computer, located in the battery bay, or under the service door.

●

Service label—Provides important information to identify your computer. When contacting support, you will probably be asked for the serial number, and possibly for the product number or the model number. Locate these numbers before you contact support.

NOTE: Your service labels will resemble one of the examples shown below. Refer to the

illustration that most closely matches the service label on your computer.

Component

(1) Product name

(2) Serial number

(3) Product number

(4) Warranty period

(5) Model number (select models only)

Component

(1) Serial number

(2) Product number

(3) Warranty period

14 Chapter 2 External component identification

Component

(4) Model number (select models only)

(5) Revision number

●

Regulatory label(s)—Provide(s) regulatory information about the computer.

●

Wireless certification label(s)—Provide(s) information about optional wireless devices and the approval markings for the countries or regions in which the devices have been approved for use.

Labels

3 Illustrated parts catalog

Computer major components

16 Chapter 3 Illustrated parts catalog

Item Component Spare part number

(1) Display assembly

NOTE: The display assembly is spared as a whole unit only.

QHD 744368-001

FHD 744369-001

(2) Top cover (includes TouchPad):

For use in the United States 744381-001

For use in the United Kingdom 744382-001

(3) Keyboard (includes keyboard cable and screws)

NOTE: For a complete list of keyboards and associated country codes, see

Sequential part number listing on page 20.

(4) Keyboard backplate 744366-001

(5) Touchpad 744361-001

(6) Heat sink (includes replacement thermal grease) 744364-001

(7) Fan (includes cable) 744363-001

(8) WLAN module:

For use on all computer models:

Intel Dual Band Wireless-AC 7260 802.11 AC 2x2 WiFi + BT 4.0 Combo Adapter 710663-001

Intel Wireless 7260BN 802.11 bgn 2x2 WiFi + BT 4.0 Combo Adapter 735532-001

Intel Dual Band Wireless-N 7260AN 802.11a/b/g/n 2×2 WiFi + BT 4.0 Combo

Adapter for use only on HP Spectre 13 Pro Ultrabook computer models

(9) Solid-state drive, mSATA:

512-MB 744380-001

256-MB 744379-001

743897-xx1

717381-005

128-MB 744378-001

(10) System board (includes replacement thermal material):

Intel Core i7-4500U processor and 8-GB system memory for use in models with non-

Windows 8 operating systems

Intel Core i7-4500U processor and 8-GB system memory for use in models with

Windows 8 Standard operating systems

Intel Core i7-4500U processor and 8-GB system memory for use in models with

Windows 8 Professional operating systems

Intel Core i5-4200U processor and 4-GB system memory for use in models with non-

Windows 8 operating systems

Intel Core i5-4200U processor and 4-GB system memory for use in models with

Windows 8 Standard operating systems

743849-601

743849-501

743849-001

743850-601

743850-501

Computer major components

Item Component Spare part number

Intel Core i5-4200U processor and 4-GB system memory for use in models with

Windows 8 Professional operating systems

Intel Core i5-4200U processor and 8-GB system memory for use in models with non-

Windows 8 operating systems

Intel Core i5-4200U processor and 8-GB system memory for use in models with

Windows 8 Standard operating systems

Intel Core i5-4200U processor and 8-GB system memory for use in models with

Windows 8 Professional operating systems

(11) Power button board 744370-001

(12) Power connector cable 744362-001

(13) Speaker assembly (includes cable) 744377-001

(14) Battery (4-cell, 51-Wh, 3.42-Ah) 734998-001

(15) Bottom cover 744360-001

Rubber Kit

743850-001

743851-601

743851-501

743851-001

Item Component Spare part number

Rubber Kit, includes: 744375-001

Bottom feet

Mass storage devices

Description Spare part number

Solid-state drive, mSATA

18 Chapter 3 Illustrated parts catalog

Description Spare part number

512-GB 744380-001

256-GB 744379-001

128-GB 744378-001

Miscellaneous parts

Component Spare part number

HP Smart AC adapter (45-W) 744892-001

Adapters

HDMI to VGA 701943-001

RJ-45 to USB 704927-001

Power cord (3-pin, black, 1.83-m):

For use on all computer models:

For use in Australia 490371-011

For use in Denmark 490371-081

For use in Europe 490371-021

For use in Israel 490371-BB1

For use in North America 490371-001

For use in South Korea 490371-AD1

For use in Switzerland 490371-111

For use in the United Kingdom and Singapore 490371-031

For use only on HP Spectre 13 Pro Ultrabook computer models:

For use in India 490371-D61

For use in Japan 490371-291

For use in the People's Republic of China 490371-AA1

For use in Taiwan 490371-AB1

For use in Thailand 490371-201

Screw Kit 744376-001

Miscellaneous parts

Sequential part number listing

Spare part number Description

490371-001 Power cord for use on all computer models in North America (3-pin, black, 1.83-m)

490371-011 Power cord for use on all computer models in Australia (3-pin, black, 1.83-m)

490371-021 Power cord for use on all computer models in Europe (3-pin, black, 1.83-m)

490371-031 Power cord for use on all computer models in the United Kingdom and Singapore (3-pin, black,

1.83-m)

490371-081 Power cord for use on all computer models in Denmark (3-pin, black, 1.83-m)

490371-111 Power cord for use on all computer models in Switzerland (3-pin, black, 1.83-m)

490371-201 Power cord for use only on HP Spectre 13 Pro Ultrabook computer models in Thailand (3-pin, black,

1.83-m)

490371-291 Power cord for use only on HP Spectre 13 Pro Ultrabook computer models in Japan (3-pin, black,

1.83-m)

490371-AA1 Power cord for use only on HP Spectre 13 Pro Ultrabook computer models in the People's Republic

of China (3-pin, black, 1.83-m)

490371-AB1 Power cord for use only on HP Spectre 13 Pro Ultrabook computer models in Taiwan (3-pin, black,

1.83-m)

490371-AD1 Power cord for use on all computer models in South Korea (3-pin, black, 1.83-m)

490371-BB1 Power cord for use on all computer models in Israel (3-pin, black, 1.83-m)

490371-D61 Power cord for use only on HP Spectre 13 Pro Ultrabook computer models in India (3-pin, black,

1.83-m)

701943-001 HDMI to VGA Adapter

704927-001 RJ-45 to USB adapter

710663-001 Intel Dual Band Wireless-AC 7260 802.11 AC 2x2 WiFi + BT 4.0 Combo Adapter

717381-005 Intel Dual Band Wireless-N 7260AN 802.11a/b/g/n 2×2 WiFi + BT 4.0 Combo Adapter for use

only on HP Spectre 13 Pro Ultrabook computer models

734998-001 4-cell, 51-Wh, 3.42-Ah, Li-ion battery

735532-001 Intel Wireless 7260BN 802.11 bgn 2x2 WiFi + BT 4.0 Combo Adapter

743849-001 System board with Intel Core i7-4500U processor and 8-GB system memory for use in models with

non-Windows 8 operating systems

743849-501 System board with Intel Core i7-4500U processor and 8-GB system memory for use in models with

Windows 8 Standard operating systems

743849-601 System board with Intel Core i7-4500U processor and 8-GB system memory for use in models with

Windows 8 Professional operating systems

743850-001 System board with Intel Core i5-4200U processor and 4-GB system memory for use in models with

non-Windows 8 operating systems

743850-501 System board with Intel Core i5-4200U processor and 4-GB system memory for use in models with

Windows 8 Standard operating systems

20 Chapter 3 Illustrated parts catalog

Spare part number Description

743850-601 System board with Intel Core i5-4200U processor and 4-GB system memory for use in models with

Windows 8 Professional operating systems

743851-001 System board with Intel Core i5-4200U processor and 8-GB system memory for use in models with

non-Windows 8 operating systems

743851-501 System board with Intel Core i5-4200U processor and 8-GB system memory for use in models with

Windows 8 Standard operating systems

743851-601 System board with Intel Core i5-4200U processor and 8-GB system memory for use in models with

Windows 8 Professional operating systems

743897-001 Keyboard for use in the United States (includes keyboard cable and screws)

743897-031 Keyboard for use in the United Kingdom and Singapore (includes keyboard cable and screws)

743897-041 Keyboard with for use in Germany (includes keyboard cable and screws)

743897-051 Keyboard for use in France (includes keyboard cable and screws)

743897-061 Keyboard for use in Italy (includes keyboard cable and screws)

743897-071 Keyboard for use in Spain (includes keyboard cable and screws)

743897-131 Keyboard for use in Portugal (includes keyboard cable and screws)

743897-141 Keyboard with for use in Turkey (includes keyboard cable and screws)

743897-151 Keyboard for use in Greece (includes keyboard cable and screws)

743897-161 Keyboard for use in Latin America (includes keyboard cable and screws)

743897-171 Keyboard for use in Saudi Arabia (includes keyboard cable and screws)

743897-251 Keyboard for use in Russia (includes keyboard cable and screws)

743897-A41 Keyboard for use in Belgium (includes keyboard cable and screws)

743897-AD1 Keyboard for use in South Korea (includes keyboard cable and screws)

743897-B31 Keyboard for use in the Netherlands (includes keyboard cable and screws)

743897-BB1 Keyboard for use in Israel (includes keyboard cable and screws)

743897-BG1 Keyboard for use in Switzerland (includes keyboard cable and screws)

743897-DB1 Keyboard for use in Canada (includes keyboard cable and screws)

743897-DH1 Keyboard for use in the Netherlands (includes keyboard cable and screws)

743897-FL1 Keyboard for use in the Czech Republic and Slovakia (includes keyboard cable and screws)

744360-001 Bottom cover

744361-001 Touchpad board

744362-001 Power connector cable

744363-001 Fan (includes cable)

744364-001 Heat sink (includes replacement thermal grease)

744366-001 Keyboard backplate

Sequential part number listing

Spare part number Description

744368-001 Display assembly, 33.8-cm (13.3-in), QHD, touchscreen

744369-001 Display assembly, 33.8-cm (13.3-in), FHD, touchscreen

744370-001 Power button board

744375-001 Rubber Kit (includes bottom feet)

744376-001 Screw Kit

744377-001 Speaker assembly (includes cable)

744378-001 128-GB mSATA solid-state drive

744379-001 256-GB mSATA solid-state drive

744380-001 512-GB mSATA solid-state drive

744381-001 Top cover for use in the United States

744382-001 Top cover for use in the United Kingdom

744892-001 45-W HP Smart AC adapter

22 Chapter 3 Illustrated parts catalog

4 Removal and replacement

procedures

Preliminary replacement requirements

Tools required

You will need the following tools to complete the removal and replacement procedures:

●

Flat-bladed screwdriver

●

Magnetic screwdriver

●

Phillips P0 and P1 screwdrivers

Service considerations

The following sections include some of the considerations that you must keep in mind during disassembly and assembly procedures.

NOTE: As you remove each subassembly from the computer, place the subassembly (and all

accompanying screws) away from the work area to prevent damage.

Plastic parts

CAUTION: Using excessive force during disassembly and reassembly can damage plastic parts. Use

care when handling the plastic parts. Apply pressure only at the points designated in the maintenance instructions.

Cables and connectors

CAUTION: When servicing the computer, be sure that cables are placed in their proper locations

during the reassembly process. Improper cable placement can damage the computer.

Cables must be handled with extreme care to avoid damage. Apply only the tension required to unseat or seat the cables during removal and insertion. Handle cables by the connector whenever possible. In all cases, avoid bending, twisting, or tearing cables. Be sure that cables are routed in such a way that they cannot be caught or snagged by parts being removed or replaced. Handle flex cables with extreme care; these cables tear easily.

Preliminary replacement requirements

Drive handling

CAUTION: Drives are fragile components that must be handled with care. To prevent damage to

the computer, damage to a drive, or loss of information, observe these precautions:

Before removing or inserting a hard drive, shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system.

Before handling a drive, be sure that you are discharged of static electricity. While handling a drive, avoid touching the connector.

Before removing a diskette drive or optical drive, be sure that a diskette or disc is not in the drive and be sure that the optical drive tray is closed.

Handle drives on surfaces covered with at least one inch of shock-proof foam.

Avoid dropping drives from any height onto any surface.

After removing a hard drive, an optical drive, or a diskette drive, place it in a static-proof bag.

Avoid exposing an internal hard drive to products that have magnetic fields, such as monitors or speakers.

Avoid exposing a drive to temperature extremes or liquids.

If a drive must be mailed, place the drive in a bubble pack mailer or other suitable form of protective packaging and label the package “FRAGILE.”

Grounding guidelines

Electrostatic discharge damage

Electronic components are sensitive to electrostatic discharge (ESD). Circuitry design and structure determine the degree of sensitivity. Networks built into many integrated circuits provide some protection, but in many cases, ESD contains enough power to alter device parameters or melt silicon junctions.

A discharge of static electricity from a finger or other conductor can destroy static-sensitive devices or microcircuitry. Even if the spark is neither felt nor heard, damage may have occurred.

An electronic device exposed to ESD may not be affected at all and can work perfectly throughout a normal cycle. Or the device may function normally for a while, then degrade in the internal layers, reducing its life expectancy.

24 Chapter 4 Removal and replacement procedures

CAUTION: To prevent damage to the computer when you are removing or installing internal

components, observe these precautions:

Keep components in their electrostatic-safe containers until you are ready to install them.

Before touching an electronic component, discharge static electricity by using the guidelines described in this section.

Avoid touching pins, leads, and circuitry. Handle electronic components as little as possible.

If you remove a component, place it in an electrostatic-safe container.

The following table shows how humidity affects the electrostatic voltage levels generated by different activities.

CAUTION: A product can be degraded by as little as 700 V.

Typical electrostatic voltage levels

Relative humidity

Event 10% 40% 55%

Walking across carpet 35,000 V 15,000 V 7,500 V

Walking across vinyl floor 12,000 V 5,000 V 3,000 V

Motions of bench worker 6,000 V 800 V 400 V

Removing DIPS from plastic tube 2,000 V 700 V 400 V

Removing DIPS from vinyl tray 11,500 V 4,000 V 2,000 V

Removing DIPS from Styrofoam 14,500 V 5,000 V 3,500 V

Removing bubble pack from PCB 26,500 V 20,000 V 7,000 V

Packing PCBs in foam-lined box 21,000 V 11,000 V 5,000 V

Preliminary replacement requirements

Packaging and transporting guidelines

Follow these grounding guidelines when packaging and transporting equipment:

●

To avoid hand contact, transport products in static-safe tubes, bags, or boxes.

●

Protect ESD-sensitive parts and assemblies with conductive or approved containers or packaging.

●

Keep ESD-sensitive parts in their containers until the parts arrive at static-free workstations.

●

Place items on a grounded surface before removing items from their containers.

●

Always be properly grounded when touching a component or assembly.

●

Store reusable ESD-sensitive parts from assemblies in protective packaging or nonconductive foam.

●

Use transporters and conveyors made of antistatic belts and roller bushings. Be sure that mechanized equipment used for moving materials is wired to ground and that proper materials are selected to avoid static charging. When grounding is not possible, use an ionizer to dissipate electric charges.

Workstation guidelines

Follow these grounding workstation guidelines:

●

Cover the workstation with approved static-shielding material.

●

Use a wrist strap connected to a properly grounded work surface and use properly grounded tools and equipment.

●

Use conductive field service tools, such as cutters, screwdrivers, and vacuums.

●

When fixtures must directly contact dissipative surfaces, use fixtures made only of staticsafe materials.

●

Keep the work area free of nonconductive materials, such as ordinary plastic assembly aids and Styrofoam.

●

Handle ESD-sensitive components, parts, and assemblies by the case or PCM laminate. Handle these items only at static-free workstations.

●

Avoid contact with pins, leads, or circuitry.

●

Turn off power and input signals before inserting or removing connectors or test equipment.

26 Chapter 4 Removal and replacement procedures

Equipment guidelines

Grounding equipment must include either a wrist strap or a foot strap at a grounded workstation.

●

When seated, wear a wrist strap connected to a grounded system. Wrist straps are flexible straps with a minimum of one megohm ±10% resistance in the ground cords. To provide proper ground, wear a strap snugly against the skin at all times. On grounded mats with banana-plug connectors, use alligator clips to connect a wrist strap.

●

When standing, use foot straps and a grounded floor mat. Foot straps (heel, toe, or boot straps) can be used at standing workstations and are compatible with most types of shoes or boots. On conductive floors or dissipative floor mats, use foot straps on both feet with a minimum of one megohm resistance between the operator and ground. To be effective, the conductive must be worn in contact with the skin.

The following grounding equipment is recommended to prevent electrostatic damage:

●

Antistatic tape

●

Antistatic smocks, aprons, and sleeve protectors

●

Conductive bins and other assembly or soldering aids

●

Nonconductive foam

●

Conductive tabletop workstations with ground cords of one megohm resistance

●

Static-dissipative tables or floor mats with hard ties to the ground

●

Field service kits

●

Static awareness labels

●

Material-handling packages

●

Nonconductive plastic bags, tubes, or boxes

●

Metal tote boxes

●

Electrostatic voltage levels and protective materials

The following table lists the shielding protection provided by antistatic bags and floor mats.

Material Use Voltage protection level

Antistatic plastics Bags 1,500 V

Carbon-loaded plastic Floor mats 7,500 V

Metallized laminate Floor mats 5,000 V

Preliminary replacement requirements

Component replacement procedures

This chapter provides removal and replacement procedures.

There are as many as 103 screws that must be removed, replaced, and/or loosened when servicing the computer. Make special note of each screw size and location during removal and replacement.

Feet

Description Spare part number

Rubber Kit 744375-001

Before removing the feet, follow these steps:

1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn

the computer on, and then shut it down through the operating system.

2. Disconnect the power from the computer by unplugging the power cord from the computer.

3. Disconnect all external devices from the computer.

Remove the feet:

1. Position the computer upside-down.

2. Lift/pry to disengage the adhesive that secures the feet to the bottom cover.

Reverse the removal procedures to install the feet.

28 Chapter 4 Removal and replacement procedures

Bottom cover

Description Spare part number

Bottom cover 744360-001

Before removing the bottom cover, follow these steps:

1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn

the computer on, and then shut it down through the operating system.

2. Disconnect the power from the computer by unplugging the power cord from the computer.

3. Disconnect all external devices from the computer.

Remove the bottom cover:

1. Position the computer upside-down.

2. Remove the 8 Torx T5M2.0×3.0 screws (1) that secure the bottom cover to the computer.

3. Lift the bottom cover off the computer (2).

Reverse the removal procedures to install the bottom cover.

Component replacement procedures

Solid-state drive (SSD)

Description Spare part number

512-GB mSATA, SSD 744380-001

256-GB mSATA, SSD 744379-001

128-GB mSATA, SSD 744378-001

Before removing the solid-state drive module, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the

computer on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet

and then unplugging the AC adapter from the computer.

4. Remove the bottom cover (see

5. Disconnect the battery.

Bottom cover on page 29).

Remove the solid-state drive:

Remove the Phillips PM2.0×3.0 screw (1) that secures the drive to the computer. The rear of the drive pops up.

30 Chapter 4 Removal and replacement procedures

Pull the drive out of the socket (2).

Reverse this procedure to install the solid-state drive.

Component replacement procedures

WLAN module

Description Spare part number

Intel Dual Band Wireless-AC 7260 802.11 AC 2x2 WiFi + BT 4.0 Combo Adapter for use on all computer models

Intel Wireless 7260BN 802.11 bgn 2x2 WiFi + BT 4.0 Combo Adapter for use on all computer models

Intel Dual Band Wireless-N 7260AN 802.11a/b/g/n 2×2 WiFi + BT 4.0 Combo Adapter for use only on HP Spectre 13 Pro Ultrabook computer models

710663-001

735532-001

717381-005

CAUTION: To prevent an unresponsive system, replace the wireless module only with a wireless

module authorized for use in the computer by the governmental agency that regulates wireless devices in your country or region. If you replace the module and then receive a warning message, remove the module to restore device functionality, and then contact technical support.

Before removing the WLAN module, follow these steps:

1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn

the computer on, and then shut it down through the operating system.

2. Disconnect the power from the computer by unplugging the power cord from the computer.

3. Disconnect all external devices from the computer.

4. Remove the bottom cover (see

Bottom cover on page 29).

5. Disconnect the battery.

32 Chapter 4 Removal and replacement procedures

Remove the WLAN module:

1. Disconnect the WLAN antenna cables (1) from the terminals on the WLAN module.

NOTE: The WLAN antenna cable labeled “1” connects to the WLAN module “Main” terminal

labeled “1”. The WLAN antenna cable labeled “2” connects to the WLAN module “Aux” terminal labeled “2”. If the computer is equipped with an 802.11a/b/g/n WLAN module, the yellow WLAN antenna cable connects to the middle terminal on the WLAN module.

2. Remove the Phillips PM2.0×3.0 screw (2) that secures the WLAN module to the base enclosure.

3. Remove the WLAN module (3) by pulling the module away from the slot.

NOTE: WLAN modules are designed with a notch to prevent incorrect insertion.

NOTE: If the WLAN antennas are not connected to the terminals on the WLAN module, the protective

sleeves must be installed on the antenna connectors, as shown in the following illustration.

Reverse this procedure to install the WLAN module.

Component replacement procedures

Display assembly

Description Spare part number

33.8-cm (13.3-in), QHD, touchscreen 744368-001

33.8-cm (13.3-in), FHD, touchscreen 744369-001

Before removing the display assembly, follow these steps:

1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn

the computer on, and then shut it down through the operating system.

2. Disconnect the power from the computer by unplugging the power cord from the computer.

3. Disconnect all external devices from the computer.

Remove the bottom cover (see

5. Disconnect the battery.

Bottom cover on page 29).

6. Disconnect the antennas from the WLAN module (see WLAN module on page 32).

Remove the display assembly:

1. Remove the Mylar tape from atop display cable connector (1)

34 Chapter 4 Removal and replacement procedures

Disconnect the display panel cable (2) and the control cable (3) from the system board.

3. Remove the 7 Phillips PM2.5×4.0 screws (1) that secure the display assembly to the computer.

4. Rotate the computer upward to open the display hinges, and then separate the display from

the computer (2).

5. If it is necessary to remove the clutch cover or the display hinges:

a. Remove the clutch cover (the plastic piece on the bottom of the display) by pulling it straight

up to disengage it (1).

b. Remove the 4 Phillips PM2.5×5.0 screws (2 from each hinge) that secure the hinges to the

display.

c. Remove the antennas and the control cable from the left hinge (2).

Component replacement procedures

Remove the display cable from the right hinge (3) and the control cable from the left hinge (4).

e. Lift the hinges from the display (5).

Reverse this procedure to reassemble and install the display assembly.

36 Chapter 4 Removal and replacement procedures

Speaker assembly

Description Spare part number

Speaker assembly (includes cable) 744377-001

Before removing the speaker assembly, follow these steps:

1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn

the computer on, and then shut it down through the operating system.

2. Disconnect the power from the computer by unplugging the power cord from the computer.

3. Disconnect all external devices from the computer.

Remove the bottom cover (see

5. Disconnect the battery.

Bottom cover on page 29).

Remove the speaker assembly:

1. Disconnect the speaker cable from the system board (1).

2. Remove the Mylar from atop the wire between the speakers (2).

3. Remove one Phillips PM2.5×4.0 screw (3) from each speaker.

Component replacement procedures

Lift the speakers (4) from the computer.

Reverse this procedure to install the speaker assembly.

38 Chapter 4 Removal and replacement procedures

Touchpad

Description Spare part number

Touchpad board (includes cable) 744361-001

Before removing the touchpad, follow these steps:

1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn

2. Disconnect the power from the computer by unplugging the power cord from the computer.

3. Disconnect all external devices from the computer.

5. Disconnect the battery.

the computer on, and then shut it down through the operating system.

Remove the bottom cover (see

Bottom cover on page 29).

Remove the touchpad:

1. Disconnect the touchpad cable from the system board (1).

2. Remove the 5 Phillips PM1.0×2.0 screws (2) that secure the touchpad to the top cover.

Component replacement procedures

Lift the touchpad straight up and off the top cover (3).

Reverse this procedure to install the touchpad.

40 Chapter 4 Removal and replacement procedures

Fan

Description Spare part number

Fan (includes cable) 744363-001

Before removing the fan, follow these steps:

1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn

the computer on, and then shut it down through the operating system.

2. Disconnect the power from the computer by unplugging the power cord from the computer.

3. Disconnect all external devices from the computer.

Remove the bottom cover (see

Bottom cover on page 29).

5. Disconnect the battery.

Remove the fan:

1. Disconnect the fan cable (1) from the system board.

2. Loosen the 3 Phillips PM2.0×3.0 screws (2) that secure the fan to the computer.

Component replacement procedures

Remove the fan (3) from the computer.

Reverse this procedure to install the fan.

42 Chapter 4 Removal and replacement procedures

Heat sink

NOTE: The heat sink spare part kit includes replacement thermal grease.

You do NOT have to remove the heat sink to remove the system board.

Description Spare part number

Heat sink 744364-001

Before removing the heat sink, follow these steps:

1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn

2. Disconnect the power from the computer by unplugging the power cord from the computer.

3. Disconnect all external devices from the computer.

the computer on, and then shut it down through the operating system.

4. Remove the bottom cover (see

5. Disconnect the battery.

Bottom cover on page 29).

Component replacement procedures

Remove the heat sink:

1. Loosen the 4 captive Philllips screws (1) – (4) that secure the heat sink to the system board, and

then remove the heat sink (5).

2. The following illustration shows the replacement thermal material locations on a computer model

equipped with a graphics subsystem with discrete memory.

NOTE: The thermal material must be thoroughly cleaned from the surfaces of the heat sink and

the system board components each time the heat sink is removed. Replacement thermal material is included with the heat sink and system board spare part kits.

Thermal grease is used on the processor (1) and the heat sink section (2) that services it

44 Chapter 4 Removal and replacement procedures

Reverse this procedure to install the heat sink.

Component replacement procedures

Battery

Description Spare part number

Battery, 4-cell, 51-Wh, 3.42-Ah 734998-001

Before disassembling the computer, follow these steps:

1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn

the computer on, and then shut it down through the operating system.

2. Disconnect the power from the computer by unplugging the power cord from the computer.

3. Disconnect all external devices from the computer.

Remove the bottom cover (see

Bottom cover on page 29).

Remove the battery:

1. Disconnect the battery cable from the system board (1).

2. Remove the Mylar from atop the broadhead screw near the top of the battery (2).

3. Remove the 2 Phillips PM2.0×3.0 broadhead screws (3) that secure the battery to the computer.

4. Remove the 2 Phillips PM2.0×4.0 screws (4) that secure the battery to the computer.

5. Remove the 4 Phillips PM2.0×3.0 screws (5) along the bottom of the battery that secure it to the

computer.

46 Chapter 4 Removal and replacement procedures

Remove the battery from the computer (6).

Remove the removal procedure to install the battery.

Component replacement procedures

System board

NOTE: The system board spare part kit includes replacement thermal material.

You do NOT have to remove the heat sink to remove the system board. You do have to remove the fan to remove the system board.

Description Spare part number

System board with Intel Core i7-4500U processor and 8-GB system memory for use in models with non-Windows 8 operating systems

System board with Intel Core i7-4500U processor and 8-GB system memory for use in models with Windows 8 Standard operating systems

System board with Intel Core i7-4500U processor and 8-GB system memory for use in models with Windows 8 Professional operating systems

System board with Intel Core i5-4200U processor and 4-GB system memory for use in models with non-Windows 8 operating systems

System board with Intel Core i5-4200U processor and 4-GB system memory for use in models with Windows 8 Standard operating systems

System board with Intel Core i5-4200U processor and 4-GB system memory for use in models with Windows 8 Professional operating systems

System board with Intel Core i5-4200U processor and 8-GB system memory for use in models with non-Windows 8 operating systems

System board with Intel Core i5-4200U processor and 8-GB system memory for use in models with Windows 8 Standard operating systems

System board with Intel Core i5-4200U processor and 8-GB system memory for use in models with Windows 8 Professional operating systems

743849-001

743849-501

743849-601

743850-001

743850-501

743850-601

743851-001

743851-501

743851-61

Before removing the system board, follow these steps:

1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn

the computer on, and then shut it down through the operating system.

2. Disconnect the power from the computer by unplugging the power cord from the computer.

Disconnect all external devices from the computer.

4. Remove the following components:

a. Bottom cover (see

b. Battery (see

c. WLAN module (see

d. Fan (see

Fan on page 41)

Bottom cover on page 29)

Battery on page 46)

WLAN module on page 32)

NOTE: If replacing the system board, be sure to remove the heat sink from the old board and install it

on the new board.

48 Chapter 4 Removal and replacement procedures

Remove the system board:

1. Disconnect the following cables from the system board.

●

(1): Display cable

●

(2): Power connector cable

●

(3): Large keyboard cable

●

(4): Small keyboard cable

●

(5): Power button board cable

●

(6): Speaker cable

●

(7): Control cable

Lift the Mylar tape (1) to gain access to one of the screws (2).

Remove the 4 Phillips PM2.0×3.0 screws (2) that secure the system board to the computer.

Remove the Phillips PM2.0×3.0 broadhead screw (3) that secures the system board to the computer.

Lift the left side of the board (4).

Component replacement procedures

Pull the board up and away toward the left (5).

Reverse this procedure to install the system board.

50 Chapter 4 Removal and replacement procedures

Power connector cable

Description Spare part number

Power connector cable 744362-001

Before removing the power connector cable, follow these steps:

1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn

the computer on, and then shut it down through the operating system.

2. Disconnect the power from the computer by unplugging the power cord from the computer.

3. Disconnect all external devices from the computer.

Remove the following components:

a. Bottom cover (see

b. Battery (see

c. WLAN module (see

d. Fan (see

Fan on page 41)

e. System board (see

Bottom cover on page 29)

Battery on page 46)

WLAN module on page 32)

System board on page 48)

Remove the power connector cable:

1. Remove the Phillips PM2.0×3.0 screw (1) that secures the power connector cable to the computer.

Lift the bracket from atop the connector (2).

Lift the connector straight up and out of the computer (3).

Reverse this procedure to install the power connector cable.

Component replacement procedures

Power button board

Description Spare part number

Power button board (includes cable and plastic power button) 744370-001

Before removing the power button board, follow these steps:

1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn

the computer on, and then shut it down through the operating system.

2. Disconnect the power from the computer by unplugging the power cord from the computer.

3. Disconnect all external devices from the computer.

Remove the following components:

a. Bottom cover (see

b. Battery (see

c. WLAN module (see

d. Fan (see

Fan on page 41)

e. System board (see

Bottom cover on page 29)

Battery on page 46)

WLAN module on page 32)

System board on page 48)

Remove the power button board:

1. Remove the Phillips PM2.0×3.0 screw (1) that secures the power button board to the computer.

Pull up on the cable to disconnect it from the adhesive that secures it to the computer (2).

52 Chapter 4 Removal and replacement procedures

Remove the power button board from the computer (3).

Reverse this procedure to install the power button board.

Component replacement procedures

Keyboard and top cover

Description Spare part number

Top cover for use in the United States 744381-001

Top cover for use in the United Kingdom 744382-001

Keyboard

NOTE: For a complete list of keyboards and associated country codes, see

number listing on page 20.

Keyboard backplate 744366-001

Sequential part

743897-xx1

Before separating the keyboard from the top cover, follow these steps:

Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system.

2. Disconnect the power from the computer by unplugging the power cord from the computer.

3. Disconnect all external devices from the computer.

Remove the following components:

a. Bottom cover (see

b. Battery (see

c. WLAN module (see

d. Fan (see

Fan on page 41)

Bottom cover on page 29)

Battery on page 46)

WLAN module on page 32)

e. System board (see

System board on page 48)

Separate the keyboard from the top cover:

1. Lift the tape over the left screw (1).

Remove the 12 Phillips PM1.0×2.0 screws (2) that secure the keyboard backplate to the top cover.

NOTE: Only one screw is shown in the following image, but you must remove 12 screws to

remove the keyboard backplate. Screw locations are shown as while dots on the backplate in the following image.

54 Chapter 4 Removal and replacement procedures

Lift the keyboard backplate from the top cover (3)

Lift the two pieces of Mylar tape that secure the keyboard to the top cover (1).

Remove the 47 Phillips PM1.0×2.0 screws (2) that secure the keyboard to the top cover.

NOTE: Only one screw is shown in the following image, but you must remove 47 screws to

remove the keyboard. Screw locations are shown as while dots on the keyboard in the following image.

Component replacement procedures

Separate the keyboard from the top cover (3).

7. Remove the keyboard.

Reverse this procedure to install the keyboard.

56 Chapter 4 Removal and replacement procedures

5 Using Setup Utility (BIOS) and HP

PC Hardware Diagnostics (UEFI)

Setup Utility, or Basic Input/Output System (BIOS), controls communication between all the input and output devices on the system (such as disk drives, display, keyboard, mouse, and printer). Setup Utility (BIOS) includes settings for the types of devices installed, the startup sequence of the computer, and the amount of system and extended memory.

Starting Setup Utility (BIOS)

To start Setup Utility (BIOS), turn on or restart the computer, quickly press esc, and then press f10.

NOTE: Use extreme care when making changes in Setup Utility (BIOS). Errors can prevent the

computer from operating properly.

Updating the BIOS

Updated versions of the BIOS may be available on the HP website.

Most BIOS updates on the HP website are packaged in compressed files called SoftPaqs.

Some download packages contain a file named Readme.txt, which contains information regarding installing and troubleshooting the file.

Determining the BIOS version

To determine whether available BIOS updates contain later BIOS versions than those currently installed on the computer, you need to know the version of the system BIOS currently installed.

BIOS version information (also known as ROM date and System BIOS) can be revealed by pressing fn +esc (if you are already in Windows) or by using Setup Utility (BIOS).

1. Start Setup Utility (BIOS) (see

2. Use the arrow keys to select Main. Be sure that you make note of the BIOS version.

3. To exit Setup Utility (BIOS) without saving your changes, use the arrow keys to select Exit, select

Exit Discarding Changes, and then press enter.

4. Select Yes.

Starting Setup Utility (BIOS) on page 57).

Starting Setup Utility (BIOS)

Downloading a BIOS update

CAUTION: To reduce the risk of damage to the computer or an unsuccessful installation, download

and install a BIOS update only when the computer is connected to reliable external power using the AC adapter. Do not download or install a BIOS update while the computer is running on battery power, docked in an optional docking device, or connected to an optional power source. During the download and installation, follow these instructions:

Do not disconnect power from the computer by unplugging the power cord from the AC outlet.

Do not shut down the computer or initiate Sleep.

Do not insert, remove, connect, or disconnect any device, cable, or cord.

1. From the Start screen, type support, and then select the HP Support Assistant app.

2. Click Updates and tune-ups, and then click Check for HP updates now.

3. Follow the on-screen instructions.

4. At the download area, follow these steps:

Identify the most recent BIOS update and compare it to the BIOS version currently installed on your computer. If the update is more recent than your BIOS, make a note of the date, name, or other identifier. You may need this information to locate the update later, after it has been downloaded to your hard drive.

b. Follow the on-screen instructions to download your selection to the hard drive.

If the update is more recent than your BIOS, make a note of the path to the location on your hard drive where the BIOS update is downloaded. You will need to access this path when you are ready to install the update.

NOTE: If you connect your computer to a network, consult the network administrator before

installing any software updates, especially system BIOS updates.

BIOS installation procedures vary. Follow any instructions that are revealed on the screen after the download is complete. If no instructions are revealed, follow these steps:

1. From the Start screen, type file, and then select File Explorer.

2. Click your hard drive designation. The hard drive designation is typically Local Disk (C:).

Using the hard drive path you recorded earlier, open the folder on your hard drive that contains the update.

4. Double-click the file that has an .exe extension (for example, filename.exe).

The BIOS installation begins.

5. Complete the installation by following the on-screen instructions.

NOTE: After a message on the screen reports a successful installation, you can delete the

downloaded file from your hard drive.

58 Chapter 5 Using Setup Utility (BIOS) and HP PC Hardware Diagnostics (UEFI)

Using HP PC Hardware Diagnostics (UEFI)

HP PC Hardware Diagnostics is a Unified Extensible Firmware Interface (UEFI) that allows you to run diagnostic tests to determine whether the computer hardware is functioning properly. The tool runs outside the operating system so that it can isolate hardware failures from issues that are caused by the operating system or other software components.

To start HP PC Hardware Diagnostics UEFI:

1. Turn on or restart the computer, quickly press esc, and then press f2.

The BIOS searches three places for the diagnostics tools in the following order:

a. Connected USB drive

NOTE: To download the HP PC Hardware Diagnostics (UEFI) tool to a USB drive, see

Downloading HP PC Hardware Diagnostics (UEFI) to a USB device on page 59.

Hard drive

c. BIOS

2. When the diagnostic tool opens, click the type of diagnostic test you want to run, and then follow

the on-screen instructions.

NOTE: If you need to stop a diagnostic test, press esc.

Downloading HP PC Hardware Diagnostics (UEFI) to a USB device

NOTE: Instructions for downloading HP PC Hardware Diagnostics (UEFI) are provided in English

only.

1. Go to http://www.hp.com.

2. Click Support & Drivers, and then click the Drivers & Downloads tab.

3. Enter the product name in the text box, and then click Go.

4. Select your computer model, and then select your operating system.

5. In the Diagnostic section, click HP UEFI Support Environment.

– or –

Click Download, and then select Run.

Using HP PC Hardware Diagnostics (UEFI)

6 Specifications

Computer specifications

Metric U.S.

Dimensions

Width 32.4 cm 14.72 in

Depth 22.0 cm 9.86 in

Height (front to back) 1.4 to 1.5 cm 1.34 to 1.42 in

Weight

1.62 kg 3.56 lbs

Input power

Operating voltage and current 18.5 V dc @ 3.5 A - 45 W

Temperature

Operating 5°C to 35°C 41°F to 95°F

Nonoperating -20°C to 60°C -4°F to 140°F

Relative humidity (noncondensing)

Operating 10% to 90%

Nonoperating 5% to 95%

Maximum altitude (unpressurized)

Operating -15 m to 3,048 m -50 ft to 10,000 ft

Nonoperating -15 m to 12,192 m -50 ft to 40,000 ft

NOTE: Applicable product safety standards specify thermal limits for plastic surfaces. The device operates well within this

range of temperatures.

60 Chapter 6 Specifications

13.3-inch FHD display specifications

Metric U.S.

Dimensions

Height 20.5 cm 8.1 in

Width 32.0 cm 12.6 in

Diagonal 33.8 cm 13.3 in

Resolution 1920x1080

Number of colors 16,777,216

Contrast ratio 700:1 (typical)

Brightness 340 nits (typical)

Pixel resolution

Pitch 0.1529 (H) x 0.1529 (V) mm

Format FHD (1920 x 1080)

Configuration RGB vertical stripe

Backlight LED

Total power consumption Total 6.10 W(Max.) @ cell 1.15W(Max.), BL 4.95 W(Max.)

Viewing angle 89° horizontal, 89° vertical (typical)

13.3-inch FHD display specifications

13.3-inch QHD display specifications

Metric U.S.

Dimensions

Height 20.5 cm 8.1 in

Width 32.0 cm 12.6 in

Diagonal 33.8 cm 13.3 in

Resolution 2560x1440

Number of colors 16,777,216

Contrast ratio 700:1 (typical)

Brightness 340 nits (typical)

Pixel resolution

Pitch 0.1146 (H) x 0.1146 (V) mm

Format QHD (2560 x 1440)

Configuration RGB vertical stripe

Backlight LED

Total power consumption Total 6.10 W(Max.) @ cell 1.15W(Max.), BL 4.95 W(Max.)

Viewing angle 85° horizontal, 85° vertical (typical)

62 Chapter 6 Specifications

7 Backing up, restoring, and

recovering

This chapter provides information about the following processes:

●

Creating recovery media and backups

●

Restoring and recovering your system

Creating recovery media and backups

1. After you successfully set up the computer, create HP Recovery media. This step creates a backup

of the HP Recovery partition on the computer. The backup can be used to reinstall the original operating system in cases where the hard drive is corrupted or has been replaced.

HP Recovery media you create will provide the following recovery options:

●

System Recovery—Reinstalls the original operating system and the programs that were installed at the factory.

●

Minimized Image Recovery—Reinstalls the operating system and all hardware-related drivers and software, but not other software applications.

●

Factory Reset—Restores the computer to its original factory state by deleting all information from the hard drive and re-creating the partitions. Then it reinstalls the operating system and the software that was installed at the factory.

See

Creating HP Recovery media on page 63.

2. Use the Windows tools to create system restore points and create backups of personal

information. For more information and steps, see Help and Support. From the Start screen, type

help, and then select Help and Support.

Creating HP Recovery media

HP Recovery Manager is a software program that offers a way to create recovery media after you successfully set up the computer. HP Recovery media can be used to perform system recovery if the hard drive becomes corrupted. System recovery reinstalls the original operating system and the software programs installed at the factory, and then configures the settings for the programs. HP

Creating recovery media and backups

Recovery media can also be used to customize the system or restore the factory image if you replace the hard drive.

●

Only one set of HP Recovery media can be created. Handle these recovery tools carefully, and keep them in a safe place.

●

HP Recovery Manager examines the computer and determines the required storage capacity for the blank USB flash drive or the number of blank DVD discs that will be required.

●

To create recovery discs, your computer must have an optical drive with DVD writer capability, and you must use only high-quality blank DVD-R, DVD+R, DVD-R DL, or DVD+R DL discs. Do not use rewritable discs such as CD±RW, DVD±RW, double-layer DVD±RW, or BD-RE (rewritable Bluray) discs; they are not compatible with HP Recovery Manager software. Or instead you can use a high-quality blank USB flash drive.

●

If your computer does not include an integrated optical drive with DVD writer capability, but you would like to create DVD recovery media, you can use an external optical drive (purchased separately) to create recovery discs, or you can obtain recovery discs from support. See the Worldwide Telephone Numbers booklet included with the computer. You can also find contact information from the HP website. Go to region, and follow the on-screen instructions. If you use an external optical drive, it must be connected directly to a USB port on the computer; the drive cannot be connected to a USB port on an external device, such as a USB hub.

http://www.hp.com/support, select your country or

●

Be sure that the computer is connected to AC power before you begin creating the recovery media.

●

The creation process can take up to an hour or more. Do not interrupt the creation process.

●

If necessary, you can exit the program before you have finished creating all of the recovery DVDs. HP Recovery Manager will finish burning the current DVD. The next time you start HP Recovery Manager, you will be prompted to continue, and the remaining discs will be burned.

To create HP Recovery media:

IMPORTANT: For tablets, connect to the keyboard dock before beginning these steps (select models

only).

1. From the Start screen, type recovery, and then select HP Recovery Manager.

Select Recovery Media Creation, and then follow the on-screen instructions.

If you ever need to recover the system, see

Recovering using HP Recovery Manager on page 65.

64 Chapter 7 Backing up, restoring, and recovering

Restore and recovery

There are several options for recovering your system. Choose the method that best matches your situation and level of expertise:

●

Windows offers several options for restoring from backup, refreshing the computer, and resetting the computer to its original state. For more information and steps, see Help and Support. From the Start screen, type help, and then select Help and Support.

●

If you need to correct a problem with a preinstalled application or driver, use the Drivers and Applications Reinstall option of HP Recovery Manager to reinstall the individual application or driver.

From the Start screen, type recovery, select HP Recovery Manager, select Drivers and Applications Reinstall, and then follow the on-screen instructions.

●

If you want to reset your computer using a minimized image, you can choose the HP Minimized Image Recovery option from the HP Recovery partition (select models only) or HP Recovery media. Minimized Image Recovery installs only drivers and hardware-enabling applications. Other applications included in the image continue to be available for installation through the Drivers and Applications Reinstall option in HP Recovery Manager. For more information, see

using HP Recovery Manager on page 65.

●

If you want to recover the computer's original factory partitioning and content, you can choose the System Recovery option from the HP Recovery partition (select models only) or use the HP Recovery media that you have created. For more information, see

on page 65. If you have not already created recovery media, see Creating HP Recovery media on page 63.

Recovering

Recovering using HP Recovery Manager

●

If you have replaced the hard drive, you can use the Factory Reset option of HP Recovery media to restore the factory image to the replacement drive. For more information, see

Recovery Manager on page 65.

●

If you wish to remove the recovery partition to reclaim hard drive space, HP Recovery Manager offers the Remove Recovery Partition option.

For more information, see

Removing the HP Recovery partition on page 67.

Recovering using HP Recovery Manager

HP Recovery Manager software allows you to recover the computer to its original factory state by using the HP Recovery media that you created or by using the HP Recovery partition (select models only). If you have not already created recovery media, see

Creating HP Recovery media on page 63.

Recovering using HP

Restore and recovery

Using HP Recovery media, you can choose from one of the following recovery options:

●

System Recovery—Reinstalls the original operating system, and then configures the settings for the programs that were installed at the factory.

●

Minimized Image Recovery (select models only)—Reinstalls the operating system and all hardwarerelated drivers and software, but not other software applications.

●

The HP Recovery partition (select models only) allows System Recovery and Minimized Image Recovery.

What you need to know

●

HP Recovery Manager recovers only software that was installed at the factory. For software not provided with this computer, you must either download the software from the manufacturer's website or reinstall the software from the media provided by the manufacturer.

●

Recovery through HP Recovery Manager should be used as a final attempt to correct computer issues.

●

HP Recovery media must be used if the computer hard drive fails. If you have not already created recovery media, see

Creating HP Recovery media on page 63.

●

To use the Factory Reset option, you must use HP Recovery media. If you have not already created recovery media, see

●

If the HP Recovery media does not work, you can obtain recovery media for your system from support. See the Worldwide Telephone Numbers booklet included with the computer. You can also find contact information from the HP website. Go to country or region, and follow the on-screen instructions.

IMPORTANT: HP Recovery Manager does not automatically provide backups of your personal data.

Before beginning recovery, back up any personal data you wish to retain.

Creating HP Recovery media on page 63.

http://www.hp.com/support, select your

Using the HP Recovery partition (select models only)

The HP Recovery partition (select models only) allows you to perform a system recovery or minimized image recovery without the need for recovery discs or a recovery USB flash drive. This type of recovery can only be used if the hard drive is still working.

To start HP Recovery Manager from the HP Recovery partition:

IMPORTANT: For tablets, connect to the keyboard dock before beginning these steps (select models

only).

1. Press f11 while the computer boots.

– or –

Press and hold f11 as you press the power button.

2. Choose your keyboard layout.

66 Chapter 7 Backing up, restoring, and recovering

Select Troubleshoot from the boot options menu.

Select Recovery Manager, and then follow the on-screen instructions.

Using HP Recovery media to recover

You can use HP Recovery media to recover the original system. This method can be used if your system does not have an HP Recovery partition or if the hard drive is not working properly.

1. If possible, back up all personal files.

2. Insert the HP Recovery disc you created, and then restart the computer.

NOTE: If the computer does not automatically restart in HP Recovery Manager, change the

computer boot order. See

3. Follow the on-screen instructions.

Changing the computer boot order on page 67.

Changing the computer boot order

If computer does not restart in HP Recovery Manager, you can change the computer boot order, which is the order of devices listed in BIOS where the computer looks for startup information. You can change the selection for an optical drive or a USB flash drive.

To change the boot order:

1. Insert the HP Recovery media you created.

Restart the computer, quickly press esc, and then press f9 for boot options.

Select the optical drive or USB flash drive you want to boot from.

4. Follow the on-screen instructions.

Removing the HP Recovery partition

HP Recovery Manager software allows you to remove the HP Recovery partition to free up hard drive space.

IMPORTANT: After you remove the HP Recovery partition, you can no longer use the Windows

Refresh option, the Windows option to remove everything and reinstall Windows, or the HP Recovery Manager option. So before you remove the Recovery partition, create HP Recovery media; see

Creating HP Recovery media on page 63.

Follow these steps to remove the HP Recovery partition:

1. From the Start screen, type recovery, and then select HP Recovery Manager.

2. Select Remove Recovery Partition, and then follow the on-screen instructions.

Restore and recovery

8 Power cord set requirements

The wide-range input feature of the computer permits it to operate from any line voltage from 100 to 120 volts AC, or from 220 to 240 volts AC.

The 3-conductor power cord set included with the computer meets the requirements for use in the country or region where the equipment is purchased.

Power cord sets for use in other countries and regions must meet the requirements of the country or region where the computer is used.

Requirements for all countries

The following requirements are applicable to all countries and regions:

●

The length of the power cord set must be at least 1.0 m (3.3 ft) and no more than 2.0 m (6.5 ft).

●

All power cord sets must be approved by an acceptable accredited agency responsible for evaluation in the country or region where the power cord set will be used.

●

The power cord sets must have a minimum current capacity of 10 amps and a nominal voltage rating of 125 or 250 V AC, as required by the power system of each country or region.

●

The appliance coupler must meet the mechanical configuration of an EN 60 320/IEC 320 Standard Sheet C13 connector for mating with the appliance inlet on the back of the computer.

68 Chapter 8 Power cord set requirements

Requirements for specific countries and regions

Country/region Accredited agency Applicable note number

Australia EANSW 1

Austria OVE 1

Belgium CEBC 1

Canada CSA 2

Denmark DEMKO 1

Finland FIMKO 1

France UTE 1

Germany VDE 1

Italy IMQ 1

Japan METI 3

The Netherlands KEMA 1

Norway NEMKO 1

The People's Republic of China COC 5

South Korea EK 4

Sweden SEMKO 1

Switzerland SEV 1

Taiwan BSMI 4

The United Kingdom BSI 1

The United States UL 2

1. The flexible cord must be Type HO5VV-F, 3-conductor, 1.0-mm² conductor size. Power cord set fittings (appliance coupler

and wall plug) must bear the certification mark of the agency responsible for evaluation in the country or region where it will be used.

2. The flexible cord must be Type SPT-3 or equivalent, No. 18 AWG, 3-conductor. The wall plug must be a two-pole

grounding type with a NEMA 5-15P (15 A, 125 V) or NEMA 6-15P (15 A, 250 V) configuration.

3. The appliance coupler, flexible cord, and wall plug must bear a “T” mark and registration number in accordance with the

Japanese Dentori Law. The flexible cord must be Type VCT or VCTF, 3-conductor, 1.00-mm² conductor size. The wall plug must be a two-pole grounding type with a Japanese Industrial Standard C8303 (7 A, 125 V) configuration.

4. The flexible cord must be Type RVV, 3-conductor, 0.75-mm² conductor size. Power cord set fittings (appliance coupler

and wall plug) must bear the certification mark of the agency responsible for evaluation in the country or region where it will be used.

5. The flexible cord must be Type VCTF, 3-conductor, 0.75-mm² conductor size. Power cord set fittings (appliance coupler

and wall plug) must bear the certification mark of the agency responsible for evaluation in the country or region where it will be used.

Requirements for specific countries and regions

9 Recycling

When a non-rechargeable or rechargeable battery has reached the end of its useful life, do not dispose of the battery in general household waste. Follow the local laws and regulations in your area for battery disposal.

HP encourages customers to recycle used electronic hardware, HP original print cartridges, and rechargeable batteries. For more information about recycling programs, see the HP Web site at

http://www.hp.com/recycle.

70 Chapter 9 Recycling

Index

AC adapter light, identifying 12 AC adapter, spare part numbers

19, 22

action keys

identifying 9

adapters, spare part numbers 19,

20 ambient light sensor, identifying 4 audio, product description 2 audio-out (headphone) jacks 10

backups 63 battery

removal 46 spare part number 18, 20, 46

BIOS

determining version 57 downloading an update 58 updating 57

Blu-ray ROM DVD±RW SuperMulti

DL Drive

precautions 24 Bluetooth label 15 boot order, changing HP Recovery

Manager 67 bottom 15 bottom cover

removal 29 spare part number 18, 21

buttons

left TouchPad 6 power 8 right TouchPad 6

cables, service considerations 23 caps lock light, identifying 7

chipset, product description 1 components

bottom 13 display 4 left side 10 right side 12

top 6 computer major components 16 computer specifications 60 connector, power 12 connectors, service

considerations 23

deleted files, restoring 65 display

specifications 61, 62 display assembly

removal 34 display hinge

removal 35 display panel

product description 1 drives, preventing damage 24 DVD-ROM Drive

precautions 24 DVD±RW Double-Layer with

SuperMulti Drive

precautions 24

electrostatic discharge 24 equipment guidelines 27 esc key, identifying 9

fan

removal 41

spare part number 17, 21, 41

feet, illustrated 18 feet, removal 28 fn key, identifying 9

graphics, product description 1 grounding guidelines 24 guidelines

equipment 27 grounding 24 packaging 26 transporting 26 workstation 26

hard drive

precautions 24 hard drive light 11 HDMI port

identifying 12 heat sink

removal 43

spare part numbers 17, 21,

HP PC Hardware Diagnostics

(UEFI), downloading 59

HP Recovery Manager

correcting boot problems 67

starting 66 HP Recovery media

creating 63

recovery 67 HP Recovery partition

recovery 66

removing 67

internal display switch,

identifying 4

Index

internal microphones, identifying

jacks

audio-out (headphone) 10

keyboard

product description 2 removal 54 spare part numbers 17, 21,

keyboard backplate

removal 54 spare part number 17, 21, 54

keys

action 9 esc 9 fn 9 Windows 9 Windows applications 9

labels

Bluetooth 15 regulatory 15 serial number 14 service 14 wireless certification 15

WLAN 15 left control zone, identifying 6 lights

AC adapter 12

caps lock 7

hard drive 11

mute 7

power 7

wireless 7

mass storage device

illustrated 18

precautions 24

spare part numbers 18 memory card reader, identifying

memory module

product description 1 microphone

product description 2

microphones, internal 4 Mini DisplayPort

identifying 12

minimized image

creating 65

recovery 66 model name 1 mute light, identifying 7

operating system, product

description 3

optical drive

precautions 24 original system recovery 65

packaging guidelines 26 plastic parts, service

considerations 23

pointing device, product

description 2

ports

HDMI 12

product description 2

USB 3.0 10 power button board

removal 52

spare part number 18, 22, 52 power button, identifying 8 power connector cable

removal 51

spare part number 18, 21, 51 power connector, identifying 12 power cord

set requirements 68

spare part numbers 19, 20 power lights, identifying 7 power requirements, product

description 3

processor

product description 1 product description

audio 2

chipset 1

display panel 1

external expansion cards 2

graphics 1

internal expansion cards 2

keyboard 2

memory module 1 microphone 2 operating system 3 pointing device 2 ports 2 power requirements 3 processors 1 product name 1 security 3 serviceability 3 solid-state drive 1 video 2 webcam 2

wireless 2 product name 1 product name and number,

computer 14

recovery

discs 64, 67

HP Recovery Manager 65

media 67

options 63

starting 66

supported discs 64

system 65

USB flash drive 67

using HP Recovery media 64 recovery media

creating 63

creating using HP Recovery

Manager 64

recovery partition

removing 67 regulatory information

regulatory label 15

wireless certification labels 15 removal/replacement

preliminaries 23

procedures 28 restore, Windows File History 65 right control zone, identifying 6 Rubber Kit

components 18 Rubber Kit, spare part number

18, 22, 28

72 Index

Screw Kit, spare part numbers

19, 22 security cable slot, identifying 10 security, product description 3 serial number 14 service considerations

cables 23 connectors 23

plastic parts 23 service labels, locating 14 serviceability, product description

3 Setup Utility (BIOS), using 57 slots

memory card reader 11 security cable 10

solid-state drive

precautions 24 product description 1 removal 30 spare part numbers 18, 22,

speaker assembly

removal 37 spare part number 18, 22, 37

speakers

identifying 13

specifications

computer 60

display 61, 62 supported discs, recovery 64 system board

removal 48

spare part numbers 17, 20,

21, 48 system recovery 66 system restore point

creating 63

touchpad board

removal 39

spare part number 17, 21, 39 TouchPad zone, identifying 6 transporting guidelines 26 traveling with the computer 15

USB 3.0 ports identifying 10 USB 3.0 ports, identifying 12

vents, identifying 13 video, product description 2

webcam

identifying 5 webcam light, identifying 5 webcam, product description 2 Windows

File History 65

restoring files 65

system restore point 63 Windows applications key,

identifying 9 Windows key, identifying 9 wireless certification label 15 wireless light 7 wireless, product description 2 WLAN antennas, identifying 4 WLAN device 15 WLAN label 15 WLAN module

removal 32 spare part numbers 17, 20,

workstation guidelines 26

tools required 23 top cover

removal 54

spare part numbers 22, 54 top cover, spare part numbers 17 TouchPad

buttons 6

left control zone 6

right control zone 6

Index

Hp Spectre 13 Ultrabook, Spectre 13 PRO Ultrabook User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

1 Product description

2 External component identification

Display

TouchPad

Lights

Buttons

Keys

Left side

Right side

Bottom

Labels

3 Illustrated parts catalog

Computer major components

Rubber Kit

Mass storage devices

Miscellaneous parts

Sequential part number listing

Preliminary replacement requirements

Tools required

Service considerations

Plastic parts

Cables and connectors

Drive handling

Grounding guidelines

Electrostatic discharge damage

Packaging and transporting guidelines

Workstation guidelines

Equipment guidelines

Component replacement procedures

Feet

Bottom cover

Solid-state drive (SSD)

WLAN module

Display assembly

Speaker assembly

Touchpad

Heat sink

Battery

System board

Power connector cable

Power button board

Keyboard and top cover

Starting Setup Utility (BIOS)

Updating the BIOS

Determining the BIOS version

Downloading a BIOS update

Using HP PC Hardware Diagnostics (UEFI)

Downloading HP PC Hardware Diagnostics (UEFI) to a USB device

6 Specifications

Computer specifications

13.3-inch FHD display specifications

13.3-inch QHD display specifications

Creating recovery media and backups

Creating HP Recovery media

Restore and recovery

Recovering using HP Recovery Manager

What you need to know

Using the HP Recovery partition (select models only)

Using HP Recovery media to recover

Changing the computer boot order

Removing the HP Recovery partition

8 Power cord set requirements

Requirements for all countries

Requirements for specific countries and regions

9 Recycling

Index
