HP ProBook 640 G4 QuickSpecs
|
QuickSpecs |
HP ProBook 640 G4 |
|
|
|
|
|
|
|
Overview |
|
HP ProBook 640 G4 |
|
|
|
|
Right |
|
1. |
Webcam (Select models) |
9. |
HDMI port (Cable not included) |
2. |
Webcam LED (Select models) |
10. |
USB 3.1 Gen 1 port |
3. |
Internal microphones (2) |
11. |
USB 3.1 Gen 1 charging port |
4. |
Power connector |
12. |
USB Type-C™ charging port (PD+DP 1.2, Gen1) |
5. |
MicroSD card slot |
13. |
HDD LED indicator |
6. |
Docking connector |
14. |
Fingerprint reader (Select models) |
7. |
VGA port |
15. |
Clickpad |
8.Ethernet port
c05935170 — DA16163 — Worldwide — Version 17 — March 30, 2020 |
Page 1 |
QuickSpecs |
HP ProBook 640 G4 |
|
|
|
|
Overview
1.Smart Card Reader (Select models)
2.Audio combo jack
3.USB 3.1 Gen 1 port
Left
4.Security lock slot (Lock sold separately)
5.Power button
c05935170 — DA16163 — Worldwide — Version 17 — March 30, 2020 |
Page 2 |
QuickSpecs |
HP ProBook 640 G4 |
|
|
|
|
Overview
AT A GLANCE
•Windows 10 versions or FreeDOS 2.0
•Precision-crafted slim design with fingerprint resistant modern, fresh and comfortable natural silver finish
•Choice of 8th Generation Intel® Core™processors, with integrated graphics or optional AMD Radeon™ RX540 128 bit Discrete Graphics
•HP Advanced keyboard, spill resistant with optional backlit design
•Large Clickpad with gestures support
•Enhanced security features including TPM2.0, HP Privacy Camera, optional Smart Card Reader, optional FingerPrint2 Reader (select models), and HP Sure Start Gen4.
•LED-backlit display
35.56 cm (14") diagonal HD and FHD or Touch FHD with camera and with WWAN
•HDMI port for connecting to high-resolution displays
•Optional HD webcam with dual-microphone array for video conferencing
•Three USB 3.1 Gen1 ports (1 charging) and one USB-C port (PD+DP 1.2, Gen1)
•Flexible wireless connectivity options
•Battery life up to 14 hours and 30 minutes with fast charging technology
•Dual storage combines SSD fast boot up and app access with cost effective HDD mass storage
•Passed MIL-STD 810G testing1
•Compliance with FCC (Class B)
1.MIL-STD-810G testing is conducted on select HP products. Testing is not intended to demonstrate fitness of U.S. Department of Defense (DoD) contract requirements or for military use. Test results are not a guarantee of future performance under these test conditions. Accidental damage requires an optional HP Accidental Damage Protection Care Pack.
2.HP Fingerprint Sensor is an optional feature and requires configuration at purchase.
NOTE: See important legal disclosures for all listed specs in their respective features sections.
c05935170 — DA16163 — Worldwide — Version 17 — March 30, 2020 |
Page 3 |
QuickSpecs |
HP ProBook 640 G4 |
|
|
|
|
Technical Specifications |
|
PRODUCT NAME |
|
HP ProBook 640 G4
OPERATING SYSTEM
Preinstalled |
Windows 10 Pro 641 |
|
Windows 10 Pro 64 (National Academic only)1,2 |
|
Windows 10 Home 641 |
|
Windows 10 Home Single Language 641 |
|
FreeDOS 2.0 |
1.Not all features are available in all editions or versions of Windows. Systems may require upgraded and/or separately purchased hardware, drivers, software or BIOS update to take full advantage of Windows functionality. Windows 10 is automatically updated, which is always enabled. ISP fees may apply and additional requirements may apply over time for updates. See http://www.windows.com/.
2.Some devices for academic use will automatically be updated to Windows 10 Pro Education with the Windows 10 Anniversary Update. Features vary; see https://aka.ms/ProEducation for Windows 10 Pro Education feature information.
PROCESSORS
Intel® Core™ i7-8650U with Intel® UHD graphics 620
(1.9 GHz base frequency, up to 4.2 GHz with Intel® Turbo Boost Technology, 8 MB cache, 4 cores)3,4,5 Intel® Core™ i7-8550U with Intel® UHD graphics 620
(1.8 GHz base frequency, up to 4 GHz with Intel® Turbo Boost Technology, 8 MB cache, 4 cores)3,4,5 Intel® Core™ i5-8350U with Intel® UHD Graphics 620
(1.7 GHz base frequency, up to 3.6 GHz with Intel® Turbo Boost Technology, 6 MB cache, 4 cores)3,4,5 Intel® Core™ i5-8250U with Intel® UHD Graphics 620
(1.6 GHz base frequency, up to 3.4 GHz with Intel® Turbo Boost Technology, 6 MB cache, 4 cores)3,4,5 Intel® Core™ i5-7300U with Intel® HD Graphics 620
(2.6 GHz base frequency, up to 3.5 GHz with Intel® Turbo Boost Technology, 3 MB cache, 2 cores)3,4,5 Intel® Core™ i5-7200U with Intel® HD Graphics 620
(2.5 GHz base frequency, up to 3.1 GHz with Intel® Turbo Boost Technology, 3 MB cache, 2 cores)3,4,5 Intel® Core™ i3-8130U with Intel® HD Graphics 620
(2.2 GHz, 4 MB cache, 2 cores)3,4,5,6
Processor Family
8th Generation Intel® Core™ i7 processor (i7-8650U, i7-8550U models)5 8th Generation Intel® Core™ i5 processor (i5-8350U, i5-8250U models)5
8th Generation Intel® Core™ i3 processor (i3-8130U model)5,6
7th Generation Intel® Core™ i5 processor (i5-7300U, i5-7200U models)5
3.Multicore is designed to improve performance of certain software products. Not all customers or software applications will necessarily benefit from use of this technology. Performance and clock frequency will vary depending on application workload and your hardware and software configurations. Intel’s numbering, branding and/or naming is not a measurement of higher performance.
4.Processor speed denotes maximum performance mode; processors will run at lower speeds in battery optimization mode.
5.NOTE: In accordance with Microsoft’s support policy, HP does not support the Windows 8 or Windows 7 operating system on products configured with Intel and AMD 7th generation and forward processors or provide any Windows 8 or Windows 7 drivers on http://www.support.hp.com.
6.Intel® Core™ i3-8130U processor is planned to be availabe in 2Q 2018.
c05935170 — DA16163 — Worldwide — Version 17 — March 30, 2020 |
Page 4 |
QuickSpecs |
HP ProBook 640 G4 |
|
|
|
|
Technical Specifications |
|
CHIPSET |
|
Chipset is integrated with processor
GRAPHICS
Integrated
Intel® UHD graphics 6207
Intel® HD graphics 6207
Note: View processor section for details.
Discrete
AMD Radeon™ RX540 (2 GB GDDR5 dedicated)8
7.HD content required to view HD images.
8.AMD Dynamic Switchable Graphics technology requires an Intel processor, plus an AMD Radeon™ discrete graphics configuration and is not available on FreeDOS and Linux OS. With AMD Dynamic Switchable Graphics technology, full enablement of all discrete graphics video and display features may not be supported on all systems (e.g. OpenGL applications will run on the integrated GPU or the APU as the case may be).
DISPLAY
Non-Touch HD
35.56 cm (14") diagonal HD SVA eDP anti-glare LED-backlit, 220 cd/m², 45% NTSC (1366 x 768)7,9
35.56 cm (14") diagonal HD SVA eDP anti-glare LED-backlit, 220 cd/m², 45% NTSC, for camera (1366 x 768)7,9 35.56 cm (14") diagonal HD SVA eDP anti-glare LED-backlit, 220 cd/m², 45% NTSC, for WWAN (1366 x 768)7,9
35.56 cm (14") diagonal HD SVA eDP anti-glare LED-backlit, 220 cd/m², 45% NTSC, for camera and WWAN (1366 x 768)7,9
Non-Touch FHD
35.56 cm (14") diagonal FHD IPS eDP anti-glare LED-backlit, 220 cd/m², 45% NTSC (1920 x 1080)7,9
35.56 cm (14") diagonal FHD IPS eDP anti-glare LED-backlit, 220 cd/m², 45% NTSC, for camera (1920 x 1080)7,9 35.56 cm (14") diagonal FHD IPS eDP anti-glare LED-backlit, 220 cd/m², 45% NTSC, for WWAN (1920 x 1080)7,9
35.56 cm (14") diagonal FHD IPS eDP anti-glare LED-backlit, 220 cd/m², 45% NTSC, for camera and WWAN (1920 x 1080)7,9
Non-Touch FHD Privacy Panel
HP Sure View Integrated Privacy Screen 35.56 cm (14") diagonal FHD IPS eDP anti-glare LED-backlit, 700 cd/m², 72% NTSC (1920 x 1080)7,9,10
Touch FHD
35.56 cm (14") diagonal FHD IPS eDP LED-backlit touch screen, 220 cd/m², 45% NTSC, for camera and WWAN (1920 x 1080)7,9 7. HD content required to view HD images.
9.Resolutions are dependent upon monitor capability, and resolution and color depth settings.
10.HP Sure View is optional and must be configured at purchase.
c05935170 — DA16163 — Worldwide — Version 17 — March 30, 2020 |
Page 5 |
QuickSpecs |
HP ProBook 640 G4 |
|
|
|
|
Technical Specifications
Docking station model |
Total number |
Max. resolutions |
Dock Connectors |
Technical limitations |
|
|
of supported |
supported |
|
|
|
|
displays (incl. |
|
|
|
|
|
the notebook |
|
|
|
|
|
display) |
|
|
|
|
|
|
|
|
|
|
HP UltraSlim Docking |
3 |
Dual 2.5K @ 60Hz |
2xDP, 1xVGA |
Dual 2.5k only with both displays |
|
Station |
into DP |
||||
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
System will perform at USB 3.0 |
|
|
|
|
|
Gen1 speeds when connected to |
|
HP Thunderbolt Dock G2 |
3 |
Single 2.5K @60Hz |
2xDP, 1xVGA, 1xTB, |
the dock (5Gbits) |
|
(2560 x 1440) |
1xUSB-C alt-mode |
Thunderbolt port will function as a |
|||
|
|
||||
|
|
|
|
USB 2.0 port with data and power |
|
|
|
|
|
out (15W) only. |
|
|
|
|
|
|
|
|
|
Dual 2K @ 60Hz |
|
|
|
HP USB-C Dock G4 |
3 |
Single 4K @ 60Hz |
1xHDMI, 2xDP |
|
|
|
|
(3840 x 1440) |
|
|
|
|
|
|
|
|
|
HP USB-C Universal Dock |
3 |
Dual 4K @ 60Hz |
2xDP |
|
|
Single 5K @ 60Hz |
|
||||
|
|
|
|
||
|
|
|
|
|
|
HP USB-C Travel Dock |
2 |
Single 2K @ 60Hz |
1xHDMI, 1xVGA |
Single external display |
|
Only HDMI or VGA at the time |
|||||
|
|
|
|
||
|
|
|
|
|
|
HP USB-C Mini Dock |
2 |
Single 4K @ 30Hz |
1xHDMI, 1xVGA |
Single external display |
|
Only HDMI or VGA at the time |
|||||
|
|
|
|
||
|
|
|
|
|
c05935170 — DA16163 — Worldwide — Version 17 — March 30, 2020 |
Page 6 |
QuickSpecs |
HP ProBook 640 G4 |
|
|
|
|
Technical Specifications |
|
STORAGE AND DRIVES |
|
Primary Storage
500 GB 7200 rpm11
500 GB 7200 rpm Self Encrypting Drive (FIPS-140-2)11 1 TB 7200 rpm11
Primary M.2 Storage
16 GB Intel® Optane™ memory41
118 GB Intel® Optane™ SSD11
128 GB SATA-3 SS TLC11
256 GB SATA-3 TLC OPAL211
256 GB PCIe NVMe SS Value11
256 GB PCIe Gen3x4 NVMe SS TLC11
512 GB SATA SS TLC (FIPS)11
512 GB PCIe Gen3x4 NVMe SS TLC11
512 GB PCIe NVMe SS TCL Value (Available as option on select customer requested configurations)11 1 TB PCIe Gen3x4 NVMe SS TLC11
11. For storage drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 30 GB (for Windows 10. is reserved for system recovery software.
41. Intel® Optane™ memory system acceleration does not replace or increase the DRAM in your system.
MEMORY
Maximum Memory
32 GB DDR4-2400 SDRAM12
Memory
4 GB Total System Memory (4 GB x 1)12
8 GB Total System Memory (4 GB x 2)12
8 GB Total System Memory (8 GB x 1)12
12 GB Total System Memory (8 GB + 4 GB)12
16 GB Total System Memory (16 GB x 1)12
16 GB Total System Memory (8 GB x 2)12
32 GB Total System Memory (16 GB x2)12
Memory Slots
2 SODIMM
Both slots are customer accessible / upgradeable
DDR4 PC4 SODIMMS - System supports run rate at 2133 in 7th Gen Processor, 2400 in 8th Gen processor Supports Dual Channel Memory
12. Due to the non-industry standard nature of some third-party memory modules, we recommend HP branded memory to ensure compatibility. If you mix memory speeds, the system will perform at the lower memory speed.
c05935170 — DA16163 — Worldwide — Version 17 — March 30, 2020 |
Page 7 |
QuickSpecs |
HP ProBook 640 G4 |
|
|
|
|
Technical Specifications |
|
NETWORKING/COMMUNICATIONS |
|
WLAN
Intel® Dual Band Wireless-AC 3168 802.11a/b/g/n/ac (1x1) Wi-Fi® and Bluetooth® 4.2 Combo, non-vPro™13 Intel® Dual Band Wireless-AC 8265 802.11a/b/g/n/ac (2x2) Wi-Fi® and Bluetooth® 4.2 Combo, vPro™13 Intel® Dual Band Wireless-AC 8265 802.11a/b/g/n/ac (2x2) Wi-Fi® and Bluetooth® 4.2 Combo, non-vPro™13
Intel® Dual Band Wireless-AC 9260 802.11 a/b/g/n/ac (2x2) Wi-Fi® and Bluetooth® 5 Combo, vPro (Available as option on select customer requested configurations) ™13
Realtek RTL8822BE 802.11ac 2x2 Wi-Fi® and Bluetooth® 4.2 Combo Adapter13
Realtek RTL8821CE 802.11ac 1x1 Wi-Fi® and Bluetooth® 4.2 Combo Adapter13
WWAN
LTE CAT4: Huawei HP lt4132, LTE/HSPA+ w/GPS M.214
LTE CAT9: Fibocom Intel(R) XMM(TM) 7360 LTE-Advanced lt4210 LTE/HSPA+ w/GPS14
NFC
NXP NPC300 Near Field Communication Module14
WPAN Bluetooth
Bluetooth® 4.2 supported via all supported WLAN modules15
Ethernet
Intel® Ethernet Connection I219-LM 10/100/1000 (vPro™)16
Intel® Ethernet Connection I219-V 10/100/1000 (Non-vPro™)16
13.Wireless access point and Internet service required and sold separately. Availability of public wireless access points limited. The specifications for the 802.11ac WLAN are draft specifications and are not final. If the final specifications differ from the draft specifications, it may affect the ability of the notebook to communicate with other 802.11ac WLAN devices.
14.WWAN module requires separately purchased service contract. Check with service provider for coverage and availability in your area. Connection speeds will vary due to location, environment, network conditions, and other factors. 4G LTE not available on all products, in all regions.
15.Sold separately or as an optional feature.
16.The term ""10/100/1000"" or ""Gigabit"" Ethernet indicates compatibility with IEEE standard 802.3ab for Gigabit Ethernet, and does not connote actual operating speed of 1 Gb/s. For high-speed transmission, connection to a Gigabit
Ethernet server and network infrastructure is required.
AUDIO/MULTIMEDIA
Audio
2 Integrated stereo speakers Integrated dual array microphone
Webcam
720p HD HP Privacy Camera7,15,17
7. HD content required to view HD images.
15. Sold separately or as an optional feature.
17. Internet access required.
c05935170 — DA16163 — Worldwide — Version 17 — March 30, 2020 |
Page 8 |
QuickSpecs |
HP ProBook 640 G4 |
|
|
|
|
Technical Specifications |
|
KEYBOARDS/POINTING DEVICES/BUTTONS & FUNCTION KEYS |
|
Keyboard
HP Advanced Keyboard
ClickPad, Spill-resistant with drain
ClickPad, Spill-resistant with drain, DuraKeys & Backlit
Dual Point, Spill-resistant with drain, DuraKeys & Backlit
Dual Point, Spill-resistant with drain, DuraKeys & Backlit Privacy
Function Keys
ESC: system information
F1 - Display Switching
F2 - Blank or Privacy
F3 - Brightness Down
F4 - Brightness Up
F5 - Speaker Mute
F6 - Volume Down
F7 – Volume Up
F8 - Mic Mute
F9 - Backlight Toggle (for backlit keyboard) or Blank
F10 - NumLock
F11 - Wifi Toggle
F12 – Sleep
Clickpad requirements:
On/off control by driver Taps enabled as default Gestures:
(Win 10):
Disabled by default: 3 Finger Flick
2 Finger Rotate Momentum Motion
1 Finger Vertical Scroll Win 10:
Support PTP with Miniport driver Settings enabled by default by MSFT: 2 Finger Scrolling
2 Finger Zoom (Pinch)
OSD (enable/disable) 3 finger tap - Cortana
3finger flick –App switch
4finger tap – Action Center
c05935170 — DA16163 — Worldwide — Version 17 — March 30, 2020 |
Page 9 |
QuickSpecs |
HP ProBook 640 G4 |
|
|
|
|
Technical Specifications |
|
SOFTWARE AND SECURITY |
|
Preinstalled Software
BIOS
HP BIOSphere Gen418
HP DriveLock & Automatic DriveLock
BIOS Update via Network
Master Boot Record Security
Power On Authentication
Secure Erase19
Absolute Persistence Module20
Pre-boot Authentication
HP Wireless Wakeup
Software
HP Native Miracast Support21
HP LAN-Wireless Protection
HP Velocity
HP 3D DriveGuard
HP ePrint + JetAdvantage22
HP Hotkey Support - CMIT
HP Recovery Manager
HP Jumpstart
HP Support Assistant23
HP Noise Cancellation Software
HP Host Based MAC Address Manager
Buy Office
Manageability Features
HP Driver Packs23
HP System Software Manager (SSM)
HP BIOS Config Utility (BCU)
HP Client Catalog
HP Manageability Integration Kit Gen224
Ivanti Management Suite25
Client Security Software
HP Client Security Suite Gen4 including:26
HP Security Manager27 (including Credential Manager, HP Password Manager, HP Spare Key)
Power On Authentication
HP Fingerprint Sensor29 (select models)
HP Device Access Manager
c05935170 — DA16163 — Worldwide — Version 17 — March 30, 2020 |
Page 10 |
QuickSpecs |
HP ProBook 640 G4 |
|
|
|
|
Technical Specifications
Microsoft Defender28
Security Management
Secure Erase19
TPM 2.0 Embedded Security Chip shipped with Windows 10 (Common Criteria EAL4+ Certified)
SATA 0,1 port disablement (viaBIOS)
RAID configurations30
Serial, USB enable/disable (viaBIOS)
Power-on password (viaBIOS)
Setup password (viaBIOS)
Support for chassis padlocks and cable lock devices
Integrated hood sensor
HP Sure Click31
HP Sure Start Gen4
Security
TPM
Model: TPM SLB9670 VQ2.0 FW7.63RS3 913310-002
Version: TPM 2.0
Revision: 1.16
FIPS 140-2 Compliant: Yes (Select models only)
Smartcard Reader
Model number: Alcor AU9560
FIPS 201 Compliant: Yes
IPv6 Certification
No
MD5 Hash
Please follow the instructions below to access MD5 Hash.
Log-on to http://hp.com/support, enter your product name, select software and drivers, select OS, select driver. After selecting the driver, click on “Associated files” and then click on “Download”. When opening the file, under “Purpose” you should see the appropriate “SOFTPAQ MD5:” Field
Is the BIOS on this notebook ISO/IEC 19678:2015 (formerly NIST 800-147) compliant?:
Yes
UEFI version: 2.5
c05935170 — DA16163 — Worldwide — Version 17 — March 30, 2020 |
Page 11 |
Loading...
