HP ProBook 470 G0 Maintenance and Service Guide

HP ProBook 470 G0 Notebook PC

Maintenance and Service Guide

© Copyright 2013 Hewlett-Packard
Development Company, L.P.

Bluetooth is a trademark owned by its
proprietor and used by Hewlett-Packard
Company under license. Intel and Core are
trademarks or registered trademarks of Intel
Corporation in the United States and other
countries. Microsoft, Windows, and Windows
Vista are either trademarks or registered
trademarks of Microsoft Corporation in the
United States and/or other countries. SD Logo
is a trademark of its proprietor.

The information contained herein is subject to
change without notice. The only warranties for
HP products and services are set forth in the
express warranty statements accompanying
such products and services. Nothing herein
should be construed as constituting an
additional warranty. HP shall not be liable for
technical or editorial errors or omissions
contained herein.

First Edition: May 2013

Document Part Number: 720786-001

Product notice

This guide describes features that are common
to most models. Some features may not be
available on your computer.

Important Notice about Customer Self-Repair Parts

CAUTION: Your computer includes Customer Self-Repair parts and parts that should only be accessed by an

authorized service provider. See Chapter 5, "Removal and replacement procedures for Customer Self-Repair
parts," for details. Accessing parts described in Chapter 6, "Removal and replacement procedures for
Authorized Service Provider only parts," can damage the computer or void your warranty.

iii

iv Important Notice about Customer Self-Repair Parts

Safety warning notice

WARNING! To reduce the possibility of heat-related injuries or of overheating the computer, do not place

the computer directly on your lap or obstruct the computer air vents. Use the computer only on a hard, flat
surface. Do not allow another hard surface, such as an adjoining optional printer, or a soft surface, such as
pillows or rugs or clothing, to block airflow. Also, do not allow the AC adapter to contact the skin or a soft
surface, such as pillows or rugs or clothing, during operation. The computer and the AC adapter comply with
the user-accessible surface temperature limits defined by the International Standard for Safety of
Information Technology Equipment (IEC 60950).

v

vi Safety warning notice

Table of contents

1 Product description ....................................................................................................................................... 1

2 External component identification ................................................................................................................. 5

Display ................................................................................................................................................................... 5

Top ......................................................................................................................................................................... 6

TouchPad ............................................................................................................................................. 6

Lights ................................................................................................................................................... 7

Buttons and fingerprint reader (select models only) ......................................................................... 8

Keys ................................................................................................................................................... 10

Front ..................................................................................................................................................................... 11

Left ....................................................................................................................................................................... 12

Right ..................................................................................................................................................................... 13

Service tag and PCID label ................................................................................................................................... 14

Service tag ......................................................................................................................................... 14

PCID label ........................................................................................................................................... 15

3 Illustrated parts catalog .............................................................................................................................. 16

Computer major components ............................................................................................................................. 16

Display components ............................................................................................................................................ 19

Plastics Kit ........................................................................................................................................................... 20

Cable Kit ............................................................................................................................................................... 21

Mass storage devices .......................................................................................................................................... 22

Miscellaneous parts ............................................................................................................................................. 23

Sequential part number listing ........................................................................................................................... 24

4 Removal and replacement procedures preliminary requirements .................................................................... 28

Tools required ...................................................................................................................................................... 28

Service considerations ........................................................................................................................................ 28

Plastic parts ....................................................................................................................................... 28

Cables and connectors ...................................................................................................................... 29

Drive handling ................................................................................................................................... 29

Grounding guidelines ........................................................................................................................ 30

Electrostatic discharge damage ..................................................................................... 30

Packaging and transporting guidelines ....................................................... 31

Workstation guidelines ................................................................................ 31

Equipment guidelines ................................................................................... 32

vii

5 Removal and replacement procedures for Customer Self-Repair parts ............................................................. 33

Component replacement procedures ................................................................................................................. 33

Battery ............................................................................................................................................... 34

Service door ....................................................................................................................................... 35

Using the optional security screw ..................................................................................................... 36

Hard drive .......................................................................................................................................... 36

Optical drive ...................................................................................................................................... 39

Memory modules .............................................................................................................................. 41

WLAN/Bluetooth combo card ........................................................................................................... 43

Keyboard ........................................................................................................................................... 45

6 Removal and replacement procedures for Authorized Service Provider parts ................................................... 47

Component replacement procedures ................................................................................................................. 47

Top cover ........................................................................................................................................... 47

Fingerprint reader assembly ............................................................................................................. 52

Power button board .......................................................................................................................... 53

Function board .................................................................................................................................. 54

Card reader board ............................................................................................................................. 55

Speaker assembly ............................................................................................................................. 57

USB/audio board ............................................................................................................................... 59

System board .................................................................................................................................... 60

Power cable ....................................................................................................................................... 62

Battery cable ..................................................................................................................................... 63

RTC battery ........................................................................................................................................ 64

Optical drive extension board ........................................................................................................... 65

Hard drive extension board ............................................................................................................... 66

Fan/heat sink assembly .................................................................................................................... 67

Processor ........................................................................................................................................... 69

Latch assembly ................................................................................................................................. 71

Display assembly .............................................................................................................................. 73

7 Computer Setup (BIOS), MultiBoot, and System Diagnostics in Windows 8 ........................................................ 80

Using Computer Setup ......................................................................................................................................... 80

Starting Computer Setup .................................................................................................................. 80

Navigating and selecting in Computer Setup ................................................................................... 80

Restoring factory settings in Computer Setup ................................................................................. 81

Updating the BIOS ............................................................................................................................. 81

Determining the BIOS version ........................................................................................ 81

Downloading a BIOS update ........................................................................................... 82

Using MultiBoot ................................................................................................................................................... 83

viii

About the boot device order ............................................................................................................. 83

Choosing Multi Boot preferences ...................................................................................................... 83

Setting a new boot order in Computer Setup ................................................................. 83

Dynamically choosing a boot device using the f9 prompt ............................................. 84

Setting a MultiBoot Express prompt .............................................................................. 84

Entering MultiBoot Express preferences ....................................................................... 84

Using System Diagnostics ................................................................................................................................... 85

8 Setup Utility (BIOS) and System Diagnostics in Windows 7 .............................................................................. 86

Using Setup Utility ............................................................................................................................................... 86

Starting Setup Utility ......................................................................................................................... 86

Changing the language of Setup Utility ............................................................................................ 86

Navigating and selecting in Setup Utility .......................................................................................... 87

Displaying system information ......................................................................................................... 87

Restoring factory settings in Setup Utility ....................................................................................... 88

Exiting Setup Utility ........................................................................................................................... 88

Updating the BIOS ............................................................................................................................. 88

Determining the BIOS version ........................................................................................ 89

Downloading a BIOS update ........................................................................................... 89

Using System Diagnostics ................................................................................................................................... 90

9 Computer Setup (BIOS) and Advanced System Diagnostics in SUSE Linux .......................................................... 91

Starting Computer Setup ..................................................................................................................................... 91

Using Computer Setup ......................................................................................................................................... 91

Navigating and selecting in Computer Setup ................................................................................... 91

Restoring factory settings in Computer Setup ................................................................................. 92

Updating the BIOS ................................................................................................................................................ 92

Determining the BIOS version ........................................................................................................... 92

Downloading a BIOS update .............................................................................................................. 93

Using Advanced System Diagnostics .................................................................................................................. 93

10 Backup and recovery in Windows 8 .............................................................................................................. 95

Backing up your information ............................................................................................................................... 95

Performing a system recovery ............................................................................................................................ 96

Using the Windows recovery tools ................................................................................................... 96

Using f11 recovery tools ................................................................................................................... 96

Using Windows 8 operating system media (purchased separately) ................................................ 97

Using Windows Refresh for quick and easy recovery ....................................................................... 98

Remove everything and reinstall Windows ...................................................................................... 98

Using HP Software Setup .................................................................................................................. 99

ix

11 Backup and recovery in Windows 7 ............................................................................................................ 100

Creating recovery media with HP Recovery Disc Creator ................................................................................. 100

Creating recovery media ................................................................................................................. 101

Backing up your information ............................................................................................................................. 101

Performing a system recovery .......................................................................................................................... 102

Using the Windows recovery tools ................................................................................................. 102

Using f11 recovery tools ................................................................................................................. 103

Using a Windows 7 operating system DVD (purchased separately) .............................................. 103

12 Backup and Recovery in SUSE Linux ........................................................................................................... 105

Backing up your information ............................................................................................................................. 105

Performing a system recovery .......................................................................................................................... 105

13 Specifications .......................................................................................................................................... 107

Computer specifications .................................................................................................................................... 107

43.9-cm (17.3-in), HD+ display specifications ................................................................................................. 108

Hard drive specifications ................................................................................................................................... 109

DVD±RW SuperMulti DL Drive specifications .................................................................................................... 110

Blu-ray ROM DVD±RW SuperMulti DL Drive ...................................................................................................... 111

DVD-ROM drive .................................................................................................................................................. 111

Specification information in Device Manager ................................................................................................... 112

14 Statement of Volatility ............................................................................................................................ 113

Non-volatile memory usage ............................................................................................................................. 115

Questions and answers ..................................................................................................................................... 117

15 Power cord set requirements .................................................................................................................... 118

Requirements for all countries and regions ..................................................................................................... 118

Requirements for specific countries and regions ............................................................................................. 118

16 Recycling ................................................................................................................................................ 120

Battery ............................................................................................................................................................... 120

Display ............................................................................................................................................................... 120

Index ........................................................................................................................................................... 126

x

1 Product description

Category Description

Product Name HP ProBook 470 G0 Notebook PC

Processors Intel® Core™ i7 processor, Quad Core, 3rd generation (6-MB L3 cache, 35W)

3632QM, 2.20-GHz processor

Intel® Core i5 processors, Dual Core, 3rd generation (3-MB L3 cache, 35W)

3380M, 2.90-GHz processor

3340M, 2.70-GHz processor

3230M, 2.60-GHz processor

Intel Core i3 processors, Dual Core, 3rd generation (3-MB L3 cache, 35W)

3130M, 2.60-GHz processor

3120M, 2.50-GHz processor

Intel Pentium processor, Dual Core (2-MB L3 cache, 35W)

2020M, 2.40-GHz processor

Intel Celeron processor (2-MB L3 cache, 35W)

1000M, 1.80-GHz processor

Chipset Mobile Intel HM76 chipset

Graphics AMD Radeon™ HD 8750M, 1-GB or 2-GB (switchable discrete)

Supports HD decode, DX11, HDMI, PX5.5

Panel 43.9-cm (17.3-inch) HD+, 1600x900, 200 nits, anti-glare, 16:9, includes camera

All display assemblies include 2 wireless local area network (WLAN) antennas

Memory Two customer-accessible memory module slots supporting up to 16 GB of RAM

Supports dual-channel memory

PC3L-12800, 1600-MHz, DDR3L SODIMMs

Supports the following configurations:

●

16384 MB (8192 × 2; dual channel)

●

12288 MB (8192 + 4096; dual channel)

●

8192 MB (8192 × 1)

●

8192 MB (4096 × 2; dual channel)

●

6144 MB (4096 + 2048; dual channel)

●

4096 MB (2048 × 2; dual channel)

●

4096 MB (4096 × 1)

●

2048 MB (2048 × 1)

1

Category Description

Hard drives Supports 7-mm/9.5-mm, 2.5-in SATA hard drives with HP 3D DriveGuard

Customer-accessible

Supports the following drives:

●

1-TB, 5400-rpm

●

750-GB, 5400-rpm

●

500-GB, 7200-rpm,

●

500-GB, 5400-rpm, hybrid (8-GB SSD) MLC

●

320-GB, 5400-rpm

Fixed optical drives Supports the following 12.7-mm SATA optical drives:

●

Blu-ray ROM DVD+/-RW SuperMulti DL

●

DVD+/-RW SuperMulti DL

●

DVD-ROM

Supports no optical drive option

Audio/Visual Integrated webcam (720p HD)

Stereo speakers (2)

Integrated dual-array microphone (webcam models only)

Headphone and microphone jacks

IDT 92HD91

Skype-ready

HD audio with DTS Sound+

Ethernet Realtek RTL8151GH-CG 10/100/1000

S3/S4/S5 wake on LAN (AC mode and battery mode)

NIC power down technology

Ethernet cable not included

Wireless Integrated WLAN options by way of wireless module:

Two WLAN antennas built into display assembly

Supports “no WLAN” option

Supports the following WLAN formats:

●

Intel Centrino Advanced-N 6235

●

Atheros AR9485 802.11b/g/n 1x1 WiFi Adapter

●

Atheros AR9565 802.11bgn 1x1 WiFi + BT4.0 combo Adapter

●

Ralink RT3290LE 802.11bgn 1x1 Wi-Fi and Bluetooth® 4.0 Combo Adapter

●

Realtek RTL8188EE 802.11bgn Wi-Fi Adapter

●

Broadcom BCM943228HMB 802.11abgn 2x2 Wi-Fi + BT 4.0 Combo Adapter (Intel
models only)

Wireless Personal Area Network (PAN) only supported by Bluetooth 4.0 combo card

2 Chapter 1 Product description

Category Description

External media card Digital Media Reader Slot

Ports Audio-in (stereo microphone)

Audio-out (stereo headphone)

RJ-45 (Ethernet, includes link and activity lights)

USB 3.0 (2)

USB 2.0 (2)

VGA (Dsub 15-pin) supporting 2048 × 1536 external resolution at 75-GHz (hot plug/unplug

with auto-detect)

HDMI 1.4

Multi-pin AC port

Keyboard/pointing devices Full-sized keyboard with numeric keypad

Touchpad includes: on/off button on board; 2-way scroll with legend, taps enabled by

default, 2-finger scrolling and zoom enabled by default

Power requirements 90-W Smart AC adapter with localized cable plug support (3-wire plug with ground pin):

6-cell, 47-Wh, 2.2Ah, Li-ion battery (HP Fast Charge technology)

9-cell, 93-Wh, 2.8 Ah, Li-ion battery

Security Integrated fingerprint reader (optional)

Intel AT support

Security lock

No fingerprint reader option

Operating system Preinstalled:

Windows 7 Professional 64

Windows 7 Professional 64 – MSNA

Windows 7 Home Premium 64

Windows 7 Home Basic 64

Windows 8 Professional 64-bit Digital Product Key (DPK) with Windows 7 Professional 64

Windows 8 China (CH) 64-bit

Windows 8 Emerging Markets (EM) 64-bit

Windows 8 Multi-language (ML) 64-bit

Windows 8 Professional 64-bit

Novell™: SuSE Linux™ – SLED 11, 64-bit, SP2

FreeDOS 2.0

Restore Media (DRDVD/SRDVD):

DRDVD Windows 8

DRDVD Windows 7

3

Category Description

SRDVD SuSE Linux Enterprise (SLED) SP2 64-bit

Restore Media (OSDVD):

Windows 7 Home Basic 64

Windows 7 Home Premium 64

Windows 7 Professional 32

Windows 7 Professional 64

Windows 8 Professional 64

Web-only support:

Windows 7 Home Basic 32

Windows 7 Home Premium 32

Windows 7 Professional 32

Windows 8 Professional 32

Windows 8 ML 32

Windows 8 EM 32

Windows 8 CH 32

Certified:

Microsoft WHQL

SuSE Linux Enterprise (SLED) SP2 64-bit

Serviceability End-user replaceable parts:

AC adapter

Battery (system)

Hard drive

Memory module

Optical drive

WLAN module

Keyboard

4 Chapter 1 Product description

2 External component identification

Display

Component Description

(1) WLAN antennas (2)* (select models only) Send and receive wireless signals to communicate with wireless local

area networks (WLAN).

(2) Internal microphones (2) (select models only; SLED

models do not support WWAN)

(3) Webcam light (select models only) On: The webcam is in use.

(4) Webcam (select models only) Records video and captures still photographs.

(5) Internal display switch Turns off the display or initiates Sleep if the display is closed while

*The antennas are not visible on the outside of the computer. For optimal transmission, keep the areas immediately around the
antennas free from obstructions. To see wireless regulatory notices, see the section of the Regulatory, Safety, and Environmental
Notices that applies to your country or region. To access the user guides in Windows 8, select the HP Support Assistant app on the
Start screen, select My computer, and then select User guides. In Windows 7, these notices are located in Help and Support.

Record sound.

To use the webcam:

Windows 8: From the Start screen, type c, and then select CyberLink
YouCam from the list of applications.

Windows 7: Select Start > All Programs > Communication and Chat
> Cyberlink YouCam.

the power is on.

NOTE: The display switch is not visible on the outside of the

computer.

Display 5

Top

TouchPad

Component Description

(1) TouchPad on/off button Turns the TouchPad on and off.

(2) TouchPad zone Moves the pointer and selects or activates items on the screen.

(3) Left TouchPad button Functions like the left button on an external mouse.

(4) Right TouchPad button Functions like the right button on an external mouse.

6 Chapter 2 External component identification

Lights

NOTE: Your computer may look slightly different from the illustration in this section.

Component Description

(1)

(2)

(3) Num lock light On: Num lock is on.

(4)

(5)

(6) Caps lock light On: Caps lock is on.

Power light

Microphone mute light Amber: Microphone is off.

Wireless light

Mute light

●

On: The computer is on.

●

Blinking: The computer is in the Sleep state.

NOTE: The elapsed time between blinks is longer than on

previous models.

●

Off: The computer is off.

●

White: An integrated wireless device, such as a wireless
local area network (WLAN) device and/or a Bluetooth®
device, is on.

●

Amber: All wireless devices are off.

●

Amber: Computer sound is off.

●

Off: Computer sound is on.

Top 7

Buttons and fingerprint reader (select models only)

NOTE: Your computer may look slightly different from the illustration in this section.

Component Description

(1)

Power button

●

When the computer is off, press the button to turn on the
computer.

●

When the computer is on, press the button briefly to initiate
Sleep.

●

When the computer is in the Sleep state, press the button
briefly to exit Sleep.

●

When the computer is in Hibernation, press the button
briefly to exit Hibernation.

CAUTION: Pressing and holding down the power button will

result in the loss of unsaved information.

If the computer has stopped responding and Windows®
shutdown procedures are ineffective, press and hold the power
button for at least 5 seconds to turn off the computer.

To learn more about your power settings, see your power
options:

●

Windows 8: From the Start screen, type power, select
Settings, and then select Power Options.

●

Windows 7: Select Start > Control Panel > System and
Security > Power Options.

●

SLED: Select Computer > Control Center. In the left pane,
click System, and then click Power Management in the
right pane.

8 Chapter 2 External component identification

Component Description

(2) Speakers (2) Produce DTS Sound+ (select models only).

To use the DTS Sound+ software:

Windows 8: From the Start screen, type DTS, and then select DTS
Sound+.

Windows 7: Select Start > All Programs > DTS Sound+.

(3)

(4)

(5) Fingerprint reader (select models only) Allows a fingerprint logon instead of a password logon.

Wireless button Turns the wireless feature on or off but does not establish a

wireless connection.

Volume mute button Mutes and restores speaker sound.

Top 9

Keys

Component Description

(1) esc key Displays system information when pressed in combination with

(2) fn key Executes frequently used system functions when pressed in

(3)

(4) Function keys Execute frequently used system functions when pressed in

(5) num lk key Turns the embedded numeric keypad on and off when pressed

(6) Integrated numeric keypad When num lk has been enabled, it can be used like an external

Windows 7/8: Windows button

SLED: Operating system logo key

the fn key.

NOTE: Not applicable to SLED.

combination with a function key, the num lk key, or the esc key.

Windows 8: Returns you to the Start screen from an open app or
the Windows desktop. NOTE: Pressing the Windows button
again will return you to the previous screen.

Windows 7: Displays the Windows Start menu.

SLED: Displays the operating system menu.

combination with the fn key.

in combination with the fn key.

Alternates between the navigational and numeric functions on
the integrated numeric keypad.

numeric keypad.

10 Chapter 2 External component identification

Front

Component Description

(1)

(2) Media Card Reader Reads data from and writes data to digital memory cards

Hard drive light

●

Blinking white: The hard drive is being accessed.

●

Amber: HP 3D DriveGuard has temporarily parked the
hard drive.

such as Secure Digital (SD).

Front 11

Left

Component Description

(1)

(2) AC adapter/Battery light

(3) Vents (2) Enables airflow to cool internal components.

(4)

(5)

Power connector Connects an AC adapter.

●

White: The computer is connected to external power and
the battery is charged from 90 to 99 percent.

●

Amber: The computer is connected to external power and
the battery is charged from 0 to 89 percent.

●

Blinking amber: A battery that is the only available power
source has reached a low battery level. When the battery
reaches a critical battery level, the battery light begins
blinking rapidly.

●

Off: The battery is fully charged.

NOTE: The computer fan starts up automatically to cool

internal components and prevent overheating. It is normal for
the internal fan to cycle on and off during routine operation.

External monitor port Connects an external VGA monitor or projector.

RJ-45 (network) jack

RJ-45 (network) lights (2)

Connects a network cable.

●

Green (left): The network is connected.

●

Amber (right): The network is showing activity.

(6)

(7)

HDMI port Connects an optional video or audio device, such as a high-

USB 3.0 ports (2) Connect optional USB 3.0 devices and provide enhanced USB

12 Chapter 2 External component identification

definition television, or any compatible digital or audio
component.

power performance.

Right

Component Description

(1)

(2)

(3)

(4) Optical drive (select models only) Reads and writes (select models only) to an optical disc.

(5) Optical drive eject button (select models only) Releases the optical drive disc tray.

(6)

Audio-out (headphone) jack Produces sound when connected to optional powered stereo

speakers, headphones, earbuds, a headset, or television audio.

WARNING! To reduce the risk of personal injury, adjust the

volume before putting on headphones, earbuds, or a headset.
For additional safety information, see the Regulatory, Safety,
and Environmental Notices. To access the user guides in
Windows 8, select the HP Support Assistant app on the Start
screen, select My computer, and then select User guides.

NOTE: When a device is connected to the jack, the computer

speakers are disabled.

Audio-in (microphone) jack Connects an optional computer headset microphone, stereo

array microphone, or monaural microphone.

USB 2.0 ports (2) Connect optional USB devices.

Security cable slot Attaches an optional security cable to the computer.

NOTE: The security cable is designed to act as a deterrent, but

it may not prevent the computer from being mishandled or
stolen.

Right 13

Service tag and PCID label

Service tag

When ordering parts or requesting information, provide the computer serial number and model description
provided on the service tag.

●

Product name (1). This is the product name affixed to the front of the computer.

●

Serial number (s/n) (2). This is an alphanumeric identifier that is unique to each product.

●

Part number/Product number (p/n) (3). This number provides specific information about the product's
hardware components. The part number helps a service technician to determine what components and
parts are needed.

●

Warranty period (4). This number describes the duration (in years) of the warranty period for the
computer.

●

Model description (select models only) (5). This is the alphanumeric identifier used to locate documents,
drivers, and support for the computer.

14 Chapter 2 External component identification

PCID label

The PCID label provides the information required to properly reset the notebook firmware (BIOS) back to
factory shipped specifications when replacing the system board. The label may have a different number of
characters depending on the operating system on the computer.

NOTE: Computer details may vary from images.

Windows 8 models

Non-Windows 8 models

Service tag and PCID label 15

3 Illustrated parts catalog

Computer major components

NOTE: Details about your computer, including model, serial number, product key, and length of warranty,

are on the service tag at the bottom of your computer. See

Service tag and PCID label on page 14 for details.

Item Description Spare part number

(1) Display panel, 43.9-cm (17.3-inch), HD+, anti-glare, with webcam 723643-001

16 Chapter 3 Illustrated parts catalog

Item Description Spare part number

(2) Keyboard (includes cable)

NOTE: For a detailed list of available keyboards, see

on page 24.

For use in Windows 8 models 721953-xxx

(3) Top cover (includes touchpad assembly)

With a fingerprint reader (includes fingerprint reader assembly) 723644-001

Without a fingerprint reader (includes fingerprint reader plastic insert, bracket, and screws) 723645-001

(4) Power button board assembly 721531-001

(5) Function board 721943-001

(6) Speaker assembly 723674-001

(7) Card reader board 721535-001

(8) Fingerprint reader assembly (includes cable, bracket, holder, and screws) 723670-001

(9) System board (includes replacement thermal material)

For use in models without Windows 8:

For use in Windows 8 models:

●

1-GB discrete graphics memory 721521-001

●

2-GB discrete graphics memory 721522-001

Sequential part number listing

(10) USB/audio board 721542-001

(11) RTC battery 683601-001

(12) Processor (includes thermal material)

Intel Core i7 processor, Quad Core

3632QM, 2.2-GHz processor with 6-MB L3 cache 701658-001

Intel Core i5 processors, Dual Core

3380M, 2.9-GHz processor with 3-MB L3 cache (includes thermal grease) 708762-001

3340M, 2.7-GHz processor with 3-MB L3 cache (includes thermal grease) 708761-001

3230M, 2.6-GHz processor with 3-MB L3 cache (includes thermal grease) 711903-001

Intel Core i3 processors, Dual Core

3130M, 2.6-GHz processor with 3-MB L3 cache (includes thermal grease) 713163-001

3120M, 2.5-GHz processor with 3-MB L3 cache (includes thermal grease) 700627-001

●

Windows 8 Standard and 1-GB discrete graphics memory 721521-501

●

Windows 8 Professional and 1-GB discrete graphics memory 721521-601

●

Windows 8 Standard and 2-GB discrete graphics memory 721522-501

●

Windows 8 Professional and 2-GB discrete graphics memory 721522-601

Intel Pentium processor, Dual Core

2020M, 2.4-GHz, with 2-MB L3 cache 700628-001

Computer major components 17

Item Description Spare part number

Intel Celeron processor

1000M, 1.8-GHz, with 2-MB L3 cache 713162-001

(13) Hard drive extension board 725891-001

(14) Optical drive extension board 723675-001

(15) Fan/heat sink assembly (includes replacement thermal material) 721937-001

(16) Battery, Li-ion

9-cell (93 WHr, 2.8 Ah) 708458-001

6-cell (47 WHr, 2.2 Ah) 708457-001

(17) WLAN module

Intel Centrino Advanced-N 6235 670292-001

Atheros AR9485 802.11b/g/n 1x1 WiFi Adapter 675794-001

Atheros AR9565 802.11bgn 1x1 WiFi + BT4.0 combo Adapter 690019-001

Ralink RT3290LE 802.11bgn 1x1 Wi-Fi and Bluetooth 4.0 Combo Adapter 690020-001

Realtek RTL8188EE 802.11bgn Wi-Fi Adapter 709848-001

Broadcom BCM943228HMB 802.11abgn 2x2 Wi-Fi + BT 4.0 Combo Adapter (Intel models only) 731550-001

(18) Base enclosure 723669-001

(19) Hard drive

1-TB, 5400-rpm 676521-001

750-GB, 5400-rpm 634250-001

500-GB, 7200-rpm 703267-001

500-GB, 5400-rpm 683802-001

500-GB, 5400-rpm, hybrid (8-GB SSD) 732000-001

320-GB, 5400-rpm 645193-001

(20) Memory modules (PC3L-12800, 1600-MHz, DDR3L)

8-GB 693374-001

4-GB 691740-001

2-GB 691739-001

(21) Optical drive (includes bracket, bezel, and screws)

Blu-ray ROM DVD±RW SuperMulti DL Drive 723671-001

DVD±RW SuperMulti DL Drive 725890-001

DVD-ROM drive 725889-001

(22) Service door 723648-001

18 Chapter 3 Illustrated parts catalog

Display components

Item Description Spare part number

(1) Display bezel 723640-001

(2) Display panel (raw) not spared

(3) Display/webcam cable assembly 723646-001

(in Cable Kit)

(4) Webcam module for use in all models 721543-001

Display Hinge Kit 723642-001

(5) Display hinges (left and right)

(6) Display hinge covers

(7) Antennas 723641-001

(8) Display rear covers 723639-001

Display components 19

Plastics Kit

Item Description Spare part number

Plastics Kit 723647-001

(1) Optical drive protective insert

20 Chapter 3 Illustrated parts catalog

Cable Kit

Item Description Spare part number

Cable Kit 723646-001

(1) Display/webcam cable

(2) USB/audio board connector cable

(3) Battery connector cable

(4) Card reader cable

(5) Power connector cable

(6) Function board connector cable

(7) Power button board cable

Cable Kit 21

Mass storage devices

Description Spare part number

(1) Hard drives

1-GB, 5400-rpm 676521-001

750-GB, 5400-rpm 634250-001

500-GB, 7200-rpm 703267-001

500-GB, 5400-rpm 683802-001

500-GB, 5400-rpm, hybrid (8-GB SSD) 732000-001

320-GB, 5400-rpm 645193-001

Hard Drive Hardware Kit (includes hard drive bracket and screws; not illustrated) 721519-001

(2) Optical drives (include bezel, bracket, and screws)

DVD-ROM drive 725889-001

Blu-ray ROM DVD±RW SuperMulti DL Drive 723671-001

DVD±RW SuperMulti DL Drive 725890-001

22 Chapter 3 Illustrated parts catalog

Miscellaneous parts

Description Spare part number

AC adapters

90-W AC adapter 693712-001

90-W AC adapter for use in India 693713-001

Power cords:

For use in Denmark 490371-081

For use in Europe, the Middle East, and Africa 490371-021

For use in Israel 490371-BB1

For use in Italy 490371-061

For use in South Africa 490371-AR1

For use in Switzerland 490371-111

For use in Thailand 490371-201

For use in the United Kingdom 490371-031

For use in the United States 490371-001

Rubber Kit (includes rubber base enclosure screw covers and mylar display bezel screw covers) 723672-001

Screw Kit 723673-001

Miscellaneous parts 23

Sequential part number listing

CSR flag designations:

A = Mandatory

B = Optional

C = Service technician recommended

N = Non-user replaceable

Spare part
number

490371-001 A Power cord for use in North America

490371-021 A Power cord for use in Europe, the Middle East, and Africa

490371-031 A Power cord for use in the United Kingdom

490371-061 A Power cord for use in Italy

490371-081 A Power cord for use in Denmark

490371-111 A Power cord for use in Switzerland

490371-201 A Power cord for use in Thailand

490371-AR1 A Power cord for use in South Africa

490371-BB1 A Power cord for use in Israel

634250-001 A 750-GB, 5400-rpm hard drive

645193-001 A 320-GB, 5400-rpm hard drive

670292-001 A Intel Centrino Advanced-N 6235 WLAN card

675794-001 A Atheros AR9485 802.11b/g/n 1x1 WiFi Adapter

676521-001 A 1-TB, 5400-rpm, hard drive

683601-001 N RTC battery

CSR flag Description

683802-001 A 500-GB, 5400-rpm hard drive

690019-001 A Atheros AR9565 802.11bgn 1x1 WiFi + BT4.0 combo Adapter

690020-001 A Ralink RT3290LE 802.11bgn 1x1 Wi-Fi and Bluetooth 4.0 Combo Adapter

691739-001 A 2-GB memory module (PC3L-12800, 1600-MHz, DDR3L)

691740-001 A 4-GB memory module (PC3L-12800, 1600-MHz, DDR3L)

693374-001 A 8-GB memory module (PC3L-12800, 1600-MHz, DDR3L)

693712-001 A 90-W AC adapter

693713-001 A 90-W AC adapter for use in India

700627-001 N Intel Core i3 processor, 3120M, 2.5-GHz, 3-MB L3 cache (includes thermal material)

700628-001 N Intel Pentium 2020M processor, 2.4-GHz, 2-MB L3 cache (includes thermal material)

701658-001 N Intel Core i7 processor, 3632QM, 2.2-GHz, 6-MB L3 cache (include thermal material)

703267-001 A 500-GB, 7200-rpm hard drive

24 Chapter 3 Illustrated parts catalog

Spare part
number

708761-001 N Intel Core i5 processor, 3340M, 2.7-GHz, 3-MB L3 cache (include thermal material)

708762-001 N Intel Core i5 processor, 3380M, 2.9-GHz, 3-MB L3 cache (include thermal material)

709848-001 A Realtek RTL8188EE 802.11bgn Wi-Fi Adapter

708457-001 A 6-cell, 47 WHr, 2.2 Ah Li-ion battery

708458-001 A 9-cell, 93 WHr, 2.8 Ah Li-ion battery

711903-001 N Intel Core i5 processor, 3230M, 2.6-GHz, 3-MB L3 cache (includes thermal material)

713162-001 N Intel Celeron 1000M processor, 1.8-GHz processor, 3-MB L3 cache (includes thermal material)

713163-001 N Intel Core i3 processor, 3130M, 2.6-GHz, 3-MB L3 cache (includes thermal material)

721519-001 A Hard Drive Hardware Kit (includes bracket and screws)

721521-001 N System board for use in models without Windows 8 with 1-GB discrete graphics (includes thermal

721521-501 N System board for use in Windows 8 Standard models with 1-GB discrete graphics (includes thermal

721521-601 N System board for use in Windows 8 Professional models with 1-GB discrete graphics (includes thermal

721522-001 N System board for use in models without Windows 8 with 2-GB discrete graphics (includes thermal

CSR flag Description

material)

material)

material)

material)

721522-501 N System board for use in Windows 8 Standard models with 2-GB discrete graphics (includes thermal

material)

721522-601 N System board for use in Windows 8 Professional models with 2-GB discrete graphics (includes thermal

material)

721531-001 B Power button board

721535-001 B Card reader board

721542-001 B USB/audio board

721543-001 B Webcam module

721937-001 N Fan/heat sink assembly (includes replacement thermal material)

721943-001 B Function board

721953-001 A Keyboard for use in the United States

721953-031 A Keyboard for use in the United Kingdom

721953-041 A Keyboard for use in Germany

721953-051 A Keyboard for use in France

721953-061 A Keyboard for use in Italy

721953-071 A Keyboard for use in Spain

721953-081 A Keyboard for use in Denmark

721953-091 A Keyboard for use in Norway

721953-131 A Keyboard for use in Portugal

Sequential part number listing 25

Spare part
number

721953-141 A Keyboard for use in Turkey

721953-151 A Keyboard for use in Greece

721953-171 A Keyboard for use in Saudi Arabia

721953-211 A Keyboard for use in Hungary

721953-251 A Keyboard for use in Russia

721953-261 A Keyboard for use in Bulgaria

721953-271 A Keyboard for use in Romania

721953-281 A Keyboard for use in Thailand

721953-291 A Keyboard for use in Japan

721953-A41 A Keyboard for use in Belgium

721953-AB1 A Keyboard for use in Taiwan

721953-AD1 A Keyboard for use in South Korea

721953-B31 A Keyboard for use in the Netherlands and Europe

721953-B71 A Keyboard for use in Sweden and Finland

721953-BA1 A Keyboard for use in Slovenia

CSR flag Description

721953-BB1 A Keyboard for use in Israel

721953-BG1 A Keyboard for use in Switzerland

721953-D61 A Keyboard for use in India

721953-DD1 A Keyboard for use in Iceland

721953-DH1 A Keyboard for use in the Netherlands

721953-FL1 A Keyboard for use in the Czech Republic and Slovakia

721953-FP1 A Keyboard for use in northern Africa

723641-001 N Antennas

723639-001 C Display rear cover

723640-001 C Display bezel for use in models with a webcam

723642-001 C Display Hinge Kit (includes left and right hinges and hinge covers)

723643-001 B 43.9-cm (17.3-inch) display assembly, HD+ anti-glare, with webcam

723644-001 B Top cover for use in models with a fingerprint reader (includes fingerprint reader board and touchpad

assembly)

723645-001 B Top cover for use in models without a fingerprint reader (includes touchpad assembly, fingerprint

reader plastic insert, bracket, and screws)

723646-001 N Cable Kit (see

Cable Kit on page 21 for more Cable Kit spare part information)

723647-001 C Plastics Kit (includes optical drive protective insert)

723648-001 A Service door

26 Chapter 3 Illustrated parts catalog

Spare part
number

723669-001 C Base enclosure

723670-001 B Fingerprint reader assembly (includes cable, bracket, holder, and screws)

723671-001 A Blu-ray ROM DVD±RW SuperMulti DL Drive (includes bezel, bracket, and screws)

723672-001 A Rubber Kit (includes rubber base enclosure screw covers and mylar display bezel screw covers)

723673-001 B Screw Kit

723674-001 B Speaker assembly

723675-001 C Optical drive connector

725889-001 A DVD-ROM drive (includes bezel, bracket, and screws)

725890-001 A DVD±RW SuperMulti DL Drive (includes bezel, bracket, and screws)

725891-001 B Hard drive connector

731550-001 A Broadcom BCM943228HMB 802.11abgn 2x2 Wi-Fi + BT 4.0 Combo Adapter (Intel models only)

732000-001 A 500-GB, 5400-rpm, hybrid (8-GB SSD) hard drive

CSR flag Description

Sequential part number listing 27

4 Removal and replacement procedures

preliminary requirements

Tools required

You will need the following tools to complete the removal and replacement procedures:

●

Flat-bladed screwdriver

●

Phillips P0 and P1 screwdrivers

●

Torx T8 screwdriver

Service considerations

The following sections include some of the considerations that you must keep in mind during disassembly
and assembly procedures.

NOTE: As you remove each subassembly from the computer, place the subassembly (and all accompanying

screws) away from the work area to prevent damage.

Plastic parts

CAUTION: Using excessive force during disassembly and reassembly can damage plastic parts. Use care

when handling the plastic parts. Apply pressure only at the points designated in the maintenance
instructions.

28 Chapter 4 Removal and replacement procedures preliminary requirements

Cables and connectors

CAUTION: When servicing the computer, be sure that cables are placed in their proper locations during the

reassembly process. Improper cable placement can damage the computer.

Cables must be handled with extreme care to avoid damage. Apply only the tension required to unseat or
seat the cables during removal and insertion. Handle cables by the connector whenever possible. In all cases,
avoid bending, twisting, or tearing cables. Be sure that cables are routed in such a way that they cannot be
caught or snagged by parts being removed or replaced. Handle flex cables with extreme care; these cables
tear easily.

Drive handling

CAUTION: Drives are fragile components that must be handled with care. To prevent damage to the

computer, damage to a drive, or loss of information, observe these precautions:

Before removing or inserting a hard drive, shut down the computer. If you are unsure whether the computer
is off or in Hibernation, turn the computer on, and then shut it down through the operating system.

Before handling a drive, be sure that you are discharged of static electricity. While handling a drive, avoid
touching the connector.

Before removing a diskette drive or optical drive, be sure that a diskette or disc is not in the drive and be sure
that the optical drive tray is closed.

Handle drives on surfaces covered with at least one inch of shock-proof foam.

Avoid dropping drives from any height onto any surface.

After removing a hard drive, an optical drive, or a diskette drive, place it in a static-proof bag.

Avoid exposing a hard drive to products that have magnetic fields, such as monitors or speakers.

Avoid exposing a drive to temperature extremes or liquids.

If a drive must be mailed, place the drive in a bubble pack mailer or other suitable form of protective
packaging and label the package “FRAGILE.”

Service considerations 29

Grounding guidelines

Electrostatic discharge damage

Electronic components are sensitive to electrostatic discharge (ESD). Circuitry design and structure
determine the degree of sensitivity. Networks built into many integrated circuits provide some protection,
but in many cases, ESD contains enough power to alter device parameters or melt silicon junctions.

A discharge of static electricity from a finger or other conductor can destroy static-sensitive devices or
microcircuitry. Even if the spark is neither felt nor heard, damage may have occurred.

An electronic device exposed to ESD may not be affected at all and can work perfectly throughout a normal
cycle. Or the device may function normally for a while, and then degrade in the internal layers, reducing its
life expectancy.

CAUTION: To prevent damage to the computer when you are removing or installing internal components,

observe these precautions:

Keep components in their electrostatic-safe containers until you are ready to install them.

Use nonmagnetic tools.

Before touching an electronic component, discharge static electricity by using the guidelines described in this
section.

Avoid touching pins, leads, and circuitry. Handle electronic components as little as possible.

If you remove a component, place it in an electrostatic-safe container.

The following table shows how humidity affects the electrostatic voltage levels generated by different
activities.

CAUTION: A product can be degraded by as little as 700 V.

Typical electrostatic voltage levels

Relative humidity

Event 10% 40% 55%

Walking across carpet 35,000 V 15,000 V 7,500 V

Walking across vinyl floor 12,000 V 5,000 V 3,000 V

Motions of bench worker 6,000 V 800 V 400 V

Removing DIPS from plastic tube 2,000 V 700 V 400 V

Removing DIPS from vinyl tray 11,500 V 4,000 V 2,000 V

Removing DIPS from Styrofoam 14,500 V 5,000 V 3,500 V

Removing bubble pack from PCB 26,500 V 20,000 V 7,000 V

Packing PCBs in foam-lined box 21,000 V 11,000 V 5,000 V

30 Chapter 4 Removal and replacement procedures preliminary requirements

Packaging and transporting guidelines

Follow these grounding guidelines when packaging and transporting equipment:

●

To avoid hand contact, transport products in static-safe tubes, bags, or boxes.

●

Protect ESD-sensitive parts and assemblies with conductive or approved containers or packaging.

●

Keep ESD-sensitive parts in their containers until the parts arrive at static-free workstations.

●

Place items on a grounded surface before removing items from their containers.

●

Always be properly grounded when touching a component or assembly.

●

Store reusable ESD-sensitive parts from assemblies in protective packaging or nonconductive foam.

●

Use transporters and conveyors made of antistatic belts and roller bushings. Be sure that mechanized
equipment used for moving materials is wired to ground and that proper materials are selected to avoid
static charging. When grounding is not possible, use an ionizer to dissipate electric charges.

Workstation guidelines

Follow these grounding workstation guidelines:

●

Cover the workstation with approved static-shielding material.

●

Use a wrist strap connected to a properly grounded work surface and use properly grounded tools and
equipment.

●

Use conductive field service tools, such as cutters, screwdrivers, and vacuums.

●

When fixtures must directly contact dissipative surfaces, use fixtures made only of static-safe
materials.

●

Keep the work area free of nonconductive materials, such as ordinary plastic assembly aids and
Styrofoam.

●

Handle ESD-sensitive components, parts, and assemblies by the case or PCM laminate. Handle these
items only at static-free workstations.

●

Avoid contact with pins, leads, or circuitry.

●

Turn off power and input signals before inserting or removing connectors or test equipment.

Service considerations 31

Equipment guidelines

Grounding equipment must include either a wrist strap or a foot strap at a grounded workstation.

●

When seated, wear a wrist strap connected to a grounded system. Wrist straps are flexible straps with a
minimum of one megohm ±10% resistance in the ground cords. To provide proper ground, wear a strap
snugly against the skin at all times. On grounded mats with banana-plug connectors, use alligator clips
to connect a wrist strap.

●

When standing, use foot straps and a grounded floor mat. Foot straps (heel, toe, or boot straps) can be
used at standing workstations and are compatible with most types of shoes or boots. On conductive
floors or dissipative floor mats, use foot straps on both feet with a minimum of one megohm resistance
between the operator and ground. To be effective, the conductive strips must be worn in contact with
the skin.

The following grounding equipment is recommended to prevent electrostatic damage:

●

Antistatic tapes

●

Antistatic smocks, aprons, and sleeve protectors

●

Conductive bins and other assembly or soldering aids

●

Nonconductive foam

●

Conductive tabletop workstations with ground cords of one megohm resistance

●

Static-dissipative tables or floor mats with hard ties to the ground

●

Field service kits

●

Static awareness labels

●

Material-handling packages

●

Nonconductive plastic bags, tubes, or boxes

●

Metal tote boxes

●

Electrostatic voltage levels and protective materials

The following table lists the shielding protection provided by antistatic bags and floor mats.

Material Use Voltage protection level

Antistatic plastic Bags 1,500 V

Carbon-loaded plastic Floor mats 7,500 V

Metallized laminate Floor mats 5,000 V

32 Chapter 4 Removal and replacement procedures preliminary requirements

5 Removal and replacement procedures for

Customer Self-Repair parts

CAUTION: The Customer Self-Repair program is not available in all locations. Installing a part not

supported by the Customer Self-Repair program may void your warranty. Check your warranty to determine
if Customer Self-Repair is supported in your location.

Component replacement procedures

NOTE: Please read and follow the procedures described here to access and replace Customer Self-Repair

parts successfully.

NOTE: Details about your computer, including model, serial number, product key, and length of warranty,

are on the service tag at the bottom of your computer. See

This chapter provides removal and replacement procedures for Customer Self-Repair parts.

There are as many as 14 screws that must be removed, replaced, or loosened when servicing Customer Self­Repair parts. Make special note of each screw size and location during removal and replacement.

Service tag and PCID label on page 14 for details.

Component replacement procedures 33

Battery

Description Spare part number

9-cell, 93 WHr, 2.8 Ah Li-ion battery 708458-001

6-cell, 47 WHr, 2.2 Ah Li-ion battery 708457-001

Before removing the battery, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the

computer on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet, and

then unplugging the AC adapter from the computer.

To remove the battery:

CAUTION: Removing a battery that is the sole power source for the computer can cause loss of information.

To prevent loss of information, save your work and shut down the computer through Windows before
removing the battery.

1. Turn the computer upside down on a flat surface.

2. Slide the battery release latches (1) to release the battery.

NOTE: You can slide the battery release latches simultaneously or you can slide them one at a time.

3. Tilt the battery upward (2) and remove it from the computer.

34 Chapter 5 Removal and replacement procedures for Customer Self-Repair parts

Service door

Remove the service door to access the memory module slot, hard drive, and other components.

Before removing the service door, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet, and

computer on, and then shut it down through the operating system.

then unplugging the AC adapter from the computer.

4. Remove the battery (see

To remove the service door:

1. With the battery bay toward you, remove the optional security screw (1), (if the optional security screw

is being used, see
release latches (2) to release the service door.

NOTE: If you do not want to use the optional security screw, you can store it inside the battery bay.

2. Slide the service door toward the front of the computer (3) and lift (4) to remove the service door.

Battery on page 34).

Using the optional security screw on page 36), and then slide the service door

Component replacement procedures 35

Using the optional security screw

Use the optional security screw to lock the service door to the bottom of the computer. When not in use the
security screw can be stored inside the battery bay.

To use the security screw:

1. Remove the battery (see

2. Remove the security screw from inside the battery bay (1) and insert it (2) to lock the service door in

Hard drive

Battery on page 34).

place.

Description Spare part number

1-TB, 5400-rpm 676521-001

750-GB, 5400-rpm 634250-001

500-GB, 7200-rpm 703267-001

500-GB, 5400-rpm 683802-001

500-GB, 5400-rpm, hybrid (8-GB SSD) 732000-001

320-GB, 5400-rpm 645193-001

Before removing the hard drive, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the

computer on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet, and

then unplugging the AC adapter from the computer.

36 Chapter 5 Removal and replacement procedures for Customer Self-Repair parts

4. Remove the battery (see Battery on page 34).

5. Remove the service door (see

To remove a hard drive:

1. Turn the computer upside down on a flat surface.

2. Remove the 4 Phillips PM2.5×3.0 screws from the hard drive.

Service door on page 35).

3. Pull the hard drive tab (1) toward the side of the computer to disconnect the hard drive.

4. Lift the hard drive (2) out of the hard drive bay.

Component replacement procedures 37

5. To remove the hard drive from the hard drive cover, remove the 4 Phillips PM3.0×4.0 screws (1) that

secure the cover to the drive, and then lift the cover straight up and off the hard drive (2).

Reverse this procedure to install a hard drive.

38 Chapter 5 Removal and replacement procedures for Customer Self-Repair parts

Optical drive

NOTE: All optical drive spare part kits include an optical drive bezel, bracket, and screws.

Description Spare part number

Blu-ray ROM DVD±RW SuperMulti DL Drive 723671-001

DVD±RW SuperMulti DL Drive 725890-001

DVD-ROM drive 725889-001

Before removing the optical drive, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the

computer on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet, and

then unplugging the AC adapter from the computer.

4. Remove the battery (see

5. Remove the service door (see

Battery on page 34).

Service door on page 35).

Remove the optical drive:

1. Position the computer upside-down.

2. Remove the Phillips PM2.5×6.0 screw (1) that secures the optical drive to the computer.

3. Push the optical drive tab (2) to release the optical drive from the computer.

Component replacement procedures 39

4. Remove the optical drive (3) from the computer.

5. To remove the bracket from the optical drive, remove the Phillips PM2.0×3.0 screw (1) that secures the

bracket to the drive, and then remove the bracket from the drive (2).

Reverse this procedure to install an optical drive.

40 Chapter 5 Removal and replacement procedures for Customer Self-Repair parts

Memory modules

NOTE: Primary and expansion memory is installed in a stacked configuration in the bottom of the

computer.

If only one memory module is installed, it must be installed in the bottom socket.

Description Spare part number

2-GB (PC3L-12800, 1600-MHz, DDR3L) 691739-001

4-GB (PC3L-12800, 1600-MHz, DDR3L) 691740–001

8-GB (PC3L-12800, 1600-MHz, DDR3L) 693374-001

Update BIOS before adding memory modules

Before adding new memory, make sure you update the computer to the latest BIOS.

CAUTION: Failure to update the computer to the latest BIOS prior to installing new memory may result in

various system problems.

To update BIOS:

1. Navigate to

www.hp.com.

2. Click Support & Drivers > click Drivers & Software.

3. In the Enter a product name/number box, type the computer model information, and then click Search.

4. Click the link for the computer model.

5. Select the operating system, and then click Next.

6. Under Step 2: Select a Download, click the BIOS link.

7. Click the link for the most recent BIOS.

8. Click the Download button, and then follow the on-screen instructions.

Before removing the memory module, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the

computer on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet, and

then unplugging the AC adapter from the computer.

4. Remove the battery (see

5. Remove the service door (see

Battery on page 34).

Service door on page 35).

Remove the memory module:

1. Position the computer upside-down.

2. Spread the retaining tabs (1) on each side of the memory module slot to release the memory module.

(The edge of the module opposite the slot rises away from the computer.)

Component replacement procedures 41

3. Remove the memory module (2) by pulling the module away from the slot at an angle.

NOTE: Memory modules are designed with a notch to prevent incorrect insertion into the memory

module slot.

NOTE: The computer uses two memory sockets. The top socket houses the expansion memory

module and the bottom socket houses the primary memory module. The removal procedure is the same
for both memory sockets.

Reverse this procedure to install a memory module.

42 Chapter 5 Removal and replacement procedures for Customer Self-Repair parts

WLAN/Bluetooth combo card

The computer uses a card that provides both WLAN and Bluetooth functionality.

Description Spare part number

Intel Centrino Advanced-N 6235 670292-001

Atheros AR9485 802.11b/g/n 1x1 WiFi Adapter 675794-001

Atheros AR9565 802.11bgn 1x1 WiFi + BT4.0 combo Adapter 690019-001

Ralink RT3290LE 802.11bgn 1x1 Wi-Fi and Bluetooth 4.0 Combo Adapter 690020-001

Realtek RTL8188EE 802.11bgn Wi-Fi Adapter 709848-001

Broadcom BCM943228HMB 802.11abgn 2x2 Wi-Fi + BT 4.0 Combo Adapter (Intel models only) 731550-001

Before removing the WLAN module, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the

computer on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet, and

then unplugging the AC adapter from the computer.

4. Remove the battery (see

5. Remove the service door (see

Battery on page 34).

Service door on page 35).

Remove the WLAN module:

1. Position the computer upside-down.

2. Disconnect the WLAN antenna cables (1) from the terminals on the WLAN module.

NOTE: The WLAN antenna cable labeled “1” connects to the WLAN module “Main” terminal labeled

“1”. The WLAN antenna cable labeled “2” connects to the WLAN module “Aux” terminal labeled “2”. If
the computer is equipped with an 802.11a/b/g/n WLAN module, the yellow WLAN antenna cable
connects to the middle terminal on the WLAN module.

3. Remove the two Phillips PM2.5×3.0 screws (2) that secure the WLAN module to the computer. (The

edge of the module opposite the slot rises away from the computer.)

Component replacement procedures 43

4. Remove the WLAN module (3) by pulling the module away from the slot at an angle.

NOTE: WLAN modules are designed with a notch to prevent incorrect insertion.

NOTE: If the WLAN antennas are not connected to the terminals on the WLAN module, the protective

sleeves must be installed on the antenna connectors, as shown in the following illustration.

Reverse this procedure to install the WLAN module.

44 Chapter 5 Removal and replacement procedures for Customer Self-Repair parts

Keyboard

NOTE: For a detailed list of available keyboards, see Sequential part number listing on page 24.

Before removing the keyboard, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet, and

Description Spare part number

Keyboard 721953-xxx

computer on, and then shut it down through the operating system.

then unplugging the AC adapter from the computer.

4. Remove the battery (see

5. Remove the service door (see

Battery on page 34).

Service door on page 35).

Remove the keyboard:

1. Position the computer upside-down with the front toward you.

2. Remove the 2 Phillips PM2.5×6.0 screws that secure the keyboard to the computer.

3. Position the computer upright and open as far as possible.

4. Slide the keyboard slightly downward toward the palm rest to disengage the top of the keyboard from

the top cover (1).

Component replacement procedures 45

5. Lift the top of the keyboard up at an angle (2).

NOTE: Make sure not to prematurely pull the keyboard cable out of the system board connector.

6. Rotate the keyboard until it rests on the palm rest (1), and then disconnect the keyboard cable by lifting

the keyboard connector latch (2), and then disconnecting the keyboard cable from the system board
(3).

7. Remove the keyboard.

Reverse this procedure to install the keyboard.

46 Chapter 5 Removal and replacement procedures for Customer Self-Repair parts

6 Removal and replacement procedures for

Authorized Service Provider parts

CAUTION: Components described in this chapter should only be accessed by an authorized service provider.

Accessing these parts can damage the computer or void the warranty.

Component replacement procedures

NOTE: Details about your computer, including model, serial number, product key, and length of warranty,

are on the service tag at the bottom of your computer. See

This chapter provides removal and replacement procedures for Authorized Service Provider only parts.

There are as many as 61 screws that must be removed, replaced, or loosened when servicing Authorized
Service Provider only parts. Make special note of each screw size and location during removal and
replacement.

Top cover

NOTE: Top cover spare part kits include the touchpad assembly.

Service tag and PCID label on page 14 for details.

Description Spare part number

Top cover with a fingerprint reader (includes fingerprint reader assembly) 723644-001

Top cover without a fingerprint reader (includes fingerprint reader plastic insert, bracket, and screws 723645-001

Before removing the top cover, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the

computer on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet, and

then unplugging the AC adapter from the computer.

4. Remove the battery (see

5. Remove the following components:

a. Service door (see

b. Keyboard (see

c. Optical drive (

Remove the top cover:

Battery on page 34).

Service door on page 35).

Keyboard on page 45)

Optical drive on page 39)

1. Position the computer upside-down with the front toward you.

Component replacement procedures 47

2. Remove the following covers and screws that secure the top cover to the computer:

NOTE: Rubber screw covers come in three different sizes and are available in the Rubber Kit, spare

part number 723672-001.

(1) 2 rubber screw covers from the rear corners

(2) 2 rubber screw covers from each side

(3) 2 rubber screw covers from the front corners

(4) 6 Torx T8M2.5×6.0 screws from under each screw cover

3. Remove the remaining 7 Torx T8M2.5×6.0 screws from the bottom of the computer.

48 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts

4. Remove the following screws:

(1) 2 Phillips PM2.0×3.0 screws from the optical drive bay

(2) 5 Phillips PM2.5×3.0 screws from the battery bay

5. Position the computer upright and open it as far as possible.

6. Remove the 4 Torx T8M2.5×6.0 screws from the top of the computer.

7. Disconnect the following cables from the system board:

●

(1): Power button board cable

●

(2): Speaker cable

Component replacement procedures 49

●

(3): Function board cable

●

(4): Card reader cable

8. Pry the top cover off the computer to disengage it.

NOTE: Begin by attempting to pry the top cover loose near the optical drive.

9. Lift the top of the top cover (1), and the lift the top cover up slightly (2) to gain access to the connected

audio/USB cable and connector underneath.

CAUTION: To avoid damage to the cable and connector, make sure not to disconnect the cable when

you lift the top cover from the computer.

10. Disconnect the audio/USB board cable (3) from the system board, and then remove the top cover from

the computer.

Reverse this procedure to install the top cover.

Use the following image to determine proper routing of top cover cables. All cables are included in the Cable
Kit, spare part number 723646-001.

(1): Function board cable

50 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts

(2): Power button board cable

(3): USB/audio board cable

(4): Card reader cable

Reverse this procedure to install the top cover.

Component replacement procedures 51

Fingerprint reader assembly

Description Spare part number

Fingerprint reader assembly (includes cable, bracket, holder, and screws) 723670-001

Before removing the fingerprint reader assembly, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the

computer on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet, and

then unplugging the AC adapter from the computer.

4. Remove the battery (see

Battery on page 34).

5. Remove the following components:

a. Service door (see

b. Keyboard (see

c. Optical drive (

d. Top cover (see

Service door on page 35).

Keyboard on page 45)

Optical drive on page 39)

Top cover on page 47)

Remove the fingerprint reader assembly:

1. Position the top cover upside-down.

2. Remove the Phillips PM2.0×2.0 broadhead screw (1) that secures the fingerprint reader board bracket

to the top cover.

3. Slide the bracket toward the bottom of the top cover, and then lift it off the top cover (2).

4. Remove the fingerprint reader board and cable assembly from the top cover (3), and then lift the holder

from the top cover (4).

Reverse this procedure to install the fingerprint reader assembly.

52 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts

Power button board

Description Spare part number

Power button board assembly 721531-001

Before removing the power button board, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the

computer on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet, and

then unplugging the AC adapter from the computer.

4. Remove the battery (see

Battery on page 34).

5. Remove the following components:

a. Service door (see

b. Keyboard (see

c. Optical drive (

d. Top cover (see

Service door on page 35)

Keyboard on page 45)

Optical drive on page 39)

Top cover on page 47)

Remove the power button board:

1. Position the top cover upside-down.

2. Disconnect the cable from the board (1).

3. Remove the Phillips PM2.0×3.0 screw (2) that secures the power button board to the top cover.

4. Lift the top side of the board up at an angle, and then lift board out from under the tab to remove it

from the top cover (3).

Reverse this procedure to install the power button board.

Component replacement procedures 53

When installing the power button board, insert the bottom of the board into the slot, and then rotate board
down into place. If the cable is connected to the board, it blocks the view of the tab on the board and the slot
it inserts into.

Function board

Description Spare part number

Function board 721943-001

Before removing the function board, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the

computer on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet, and

then unplugging the AC adapter from the computer.

4. Remove the battery (see

Battery on page 34).

5. Remove the following components:

a. Service door (see

b. Keyboard (see

c. Optical drive (

d. Top cover (see

Service door on page 35)

Keyboard on page 45)

Optical drive on page 39)

Top cover on page 47)

Remove the function board:

1. Position the top cover upside-down.

2. Remove the Phillips PM2.0×3.0 screw (1) that secures the function board to the top cover.

3. Lift cable side of the board slightly, and then pull the board toward the right (inside of cover) until the

left side of the board comes out from under the holder (2).

54 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts

4. Turn the board upside down (3), and then disconnect the cable from the board (4).

5. Remove the function board from the top cover.

Reverse this procedure to install the function board.

Card reader board

Description Spare part number

Card reader board 721535-001

Before removing the card reader board, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the

computer on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet, and

then unplugging the AC adapter from the computer.

4. Remove the battery (see

5. Remove the following components:

a. Service door (see

b. Keyboard (see

c. Optical drive (

Battery on page 34).

Service door on page 35).

Keyboard on page 45)

Optical drive on page 39)

d. Top cover (see

Top cover on page 47)

Remove the card reader board:

Component replacement procedures 55

NOTE: Before you remove the card reader, make sure nothing (memory card or plastic insert) in installed.

1. Position the top cover upside-down.

2. Disconnect the cable that routes to the touchpad buttons (1).

3. Disconnect the cable that routes to the system board (2).

4. Remove the two Phillips PM2.0×2.0 broadhead screws (3) that secure the card reader board to the

computer.

5. Remove the card reader board from the top cover (4).

Reverse this procedure to install the card reader board.

56 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts

Speaker assembly

Description Spare part number

Speaker assembly 723674-001

NOTE: You must remove the left speaker to remove to function board cable.

Before removing the speaker assembly, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the

computer on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet, and

then unplugging the AC adapter from the computer.

4. Remove the battery (see

Battery on page 34).

5. Remove the following components:

a. Service door (see

b. Keyboard (see

c. Optical drive (

d. Top cover (see

Service door on page 35).

Keyboard on page 45)

Optical drive on page 39)

Top cover on page 47)

Remove the speaker assembly:

1. Position the top cover upside-down.

2. Remove the 2 Phillips PM2.5×6.0 shoulder screws (1) that secure the speakers to the computer.

3. Lift the side of each speaker opposite of the screw, and then pull each speaker out from under the tab

on the top cover (2).

4. Remove the speaker cables from the clips built into the top cover (3).

Component replacement procedures 57

5. Remove the speakers from the computer (4).

Reverse this procedure to install the speaker assembly.

58 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts

USB/audio board

Description Spare part number

USB/audio board 721542-001

Before removing the USB/audio board, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the

computer on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet, and

then unplugging the AC adapter from the computer.

4. Remove the battery (see

Battery on page 34).

5. Remove the following components:

a. Service door (see

b. Keyboard (see

c. Optical drive (

d. Top cover (see

Service door on page 35).

Keyboard on page 45)

Optical drive on page 39)

Top cover on page 47)

Remove the USB/audio board:

1. Position the top cover upside-down.

2. Disconnect the cable that routes to the system board (1).

3. Disconnect the cable that routes to the fingerprint reader board (2).

4. Remove the Phillips PM2.5×4.0 screw (3) that secures the USB/audio board to the computer.

5. Rotate the top of the board upward, pull the board away from the connectors (to remove them from top

cover holes), and then lift the board off the top cover (4).

Component replacement procedures 59

Reverse this procedure to install the USB/audio board.

System board

NOTE: All system board spare part kits include replacement thermal material.

Description Spare part number

System board for use in models without Windows 8:

1-GB of discrete graphics memory 721521-001

2-GB of discrete graphics memory 721522-001

System boards for use in Windows 8 models:

Windows 8 Standard models with 1-GB of discrete graphics memory 721521-501

Windows 8 Professional models with 1-GB of discrete graphics memory 721521-601

Windows 8 Standard models with 2-GB of discrete graphics memory 721522-501

Windows 8 Professional models with 2-GB of discrete graphics memory 721522-601

Before removing the system board, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the

computer on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet, and

then unplugging the AC adapter from the computer.

4. Remove the battery (see

Battery on page 34).

5. Remove the following components:

a. Service door (see

b. Hard drive (see

c. Optical drive (see

d. Keyboard (see

e. Top cover (see

Service door on page 35).

Hard drive on page 36)

Optical drive on page 39)

Keyboard on page 45)

Top cover on page 47)

When replacing the system board, be sure to remove the following components from the defective system
board and install on the replacement system board:

●

Memory module (see

●

WLAN/Bluetooth module (see

●

Processor (see

●

Optical drive extension board (see

●

Hard drive extension board (see

Memory modules on page 41)

WLAN/Bluetooth combo card on page 43)

Processor on page 69)

Optical drive extension board on page 65)

Hard drive extension board on page 66)

60 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts

Remove the system board:

1. Position the computer upright with the front toward you.

2. Disconnect the display cable (1) from the system board.

3. Disconnect the battery connector cable from the system board (2).

4. Remove the 2 Phillips PM2.5×4.0 screws (3) that secure the system board to the computer.

5. Remove the Phillips PM2.5×4.0 screw (3) that secures the optical drive extension board to the computer

and the Phillips PM2.5×4.0 screw (3) that secures the hard drive extension board to the computer.

6. Lift the right side of the system board up at an angle (1).

7. Pull the system board up and toward the right to remove it from the computer (2).

NOTE: The power cable connects to a connector on the bottom of the system board. When you

remove the system board, the power cable will be removed from its routing path and remain connected
to the system board.

Reverse this procedure to install the system board.

Component replacement procedures 61

Power cable

The power cable is included in the Cable Kit, spare part number 723646-001.

Before removing the power cable, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet, and

computer on, and then shut it down through the operating system.

then unplugging the AC adapter from the computer.

4. Remove the battery (see

5. Remove the following components:

a. Service door (see

b. Hard drive (see

c. Optical drive (see

d. WLAN/Bluetooth module (see

e. Keyboard (see

f. Top cover (see

g. System board (see

Remove the power cable:

1. Position the system board upside-down.

2. Disconnect the cable from the bottom of the system board.

Battery on page 34).

Service door on page 35).

Hard drive on page 36)

Optical drive on page 39)

WLAN/Bluetooth combo card on page 43)

Keyboard on page 45)

Top cover on page 47)

System board on page 60)

Reverse this procedure to install the power cable.

62 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts

Battery cable

The battery cable is included in the Cable Kit, spare part number 723646-001.

Before removing the battery cable, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the

computer on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet, and

then unplugging the AC adapter from the computer.

4. Remove the battery (see

5. Remove the following components:

a. Service door (see

b. Hard drive (see

c. Optical drive (see

d. WLAN/Bluetooth module (see

e. Keyboard (see

f. Top cover (see

g. System board (see

Remove the battery cable:

1. Position the computer upright and open as far as possible.

2. Remove the 2 Phillips PM2.5×4.0 screws that secure the battery cable to the computer (1).

3. Remove the battery cable from the computer (2).

Battery on page 34).

Service door on page 35).

Hard drive on page 36)

Optical drive on page 39)

WLAN/Bluetooth combo card on page 43)

Keyboard on page 45)

Top cover on page 47)

System board on page 60)

Reverse this procedure to install the battery cable.

Component replacement procedures 63

RTC battery

Description Spare part number

RTC battery 683601-001

Before removing the RTC battery, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet, and

computer on, and then shut it down through the operating system.

then unplugging the AC adapter from the computer.

4. Remove the battery (see

Battery on page 34).

5. Remove the following components:

a. Service door (see

b. Hard drive (see

c. Optical drive (see

d. WLAN/Bluetooth module (see

e. Keyboard (see

f. Top cover (see

g. System board (see

Service door on page 35).

Hard drive on page 36)

Optical drive on page 39)

WLAN/Bluetooth combo card on page 43)

Keyboard on page 45)

Top cover on page 47)

System board on page 60)

Remove the RTC battery:

1. Position the system board upside-down.

2. Use a thin screwdriver or similar tool to pry the battery out of the socket (1).

3. Remove the battery from the socket (2).

Reverse this procedure to install the RTC battery.

64 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts

Optical drive extension board

Description Spare part number

Optical drive extension board 723675-001

Before removing the optical drive extension board, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the

computer on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet, and

then unplugging the AC adapter from the computer.

4. Remove the battery (see

Battery on page 34).

5. Remove the following components:

a. Service door (see

b. Hard drive (see

c. Optical drive (see

d. WLAN/Bluetooth module (see

e. Keyboard (see

f. Top cover (see

g. System board (see

Service door on page 35).

Hard drive on page 36)

Optical drive on page 39)

WLAN/Bluetooth combo card on page 43)

Keyboard on page 45)

Top cover on page 47)

System board on page 60)

Remove the optical drive extension board:

▲

Pull the optical drive extension board straight away from the side of the system board.

Reverse this procedure to install the optical drive extension board.

Component replacement procedures 65

Hard drive extension board

Description Spare part number

Hard drive extension board 725891-001

Before removing the hard drive extension board, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the

computer on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet, and

then unplugging the AC adapter from the computer.

4. Remove the battery (see

Battery on page 34).

5. Remove the following components:

a. Service door (see

b. Hard drive (see

c. Optical drive (see

d. WLAN/Bluetooth module (see

e. Keyboard (see

f. Top cover (see

g. System board (see

Service door on page 35).

Hard drive on page 36)

Optical drive on page 39)

WLAN/Bluetooth combo card on page 43)

Keyboard on page 45)

Top cover on page 47)

System board on page 60)

Remove the hard drive extension board:

▲

Pull the hard drive extension board straight away from the side of the system board.

Reverse this procedure to install the hard drive extension board.

66 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts

Fan/heat sink assembly

All fan/heat sink assembly spare part kits include replacement thermal material.

Description Spare part number

Fan/heat sink assembly 721937-001

Before removing the fan/heat sink assembly, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the

computer on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet, and

then unplugging the AC adapter from the computer.

4. Remove the battery (see

Battery on page 34).

5. Remove the following components:

a. Service door (see

b. Hard drive (see

c. Optical drive (see

d. WLAN/Bluetooth module (see

e. Keyboard (see

f. Top cover (see

g. System board (see

Service door on page 35).

Hard drive on page 36)

Optical drive on page 39)

WLAN/Bluetooth combo card on page 43)

Keyboard on page 45)

Top cover on page 47)

System board on page 60)

Remove the fan/heat sink assembly:

1. Position the system board upside-down.

2. To remove the fan/heat sink assembly, in the order indicated on the heat sink, loosen the 6 captive

Phillips screws (1)-(6) that secure the heat sink to the system board.

3. Disconnect the fan cable from the system board (7).

Component replacement procedures 67

4. Lift the fan/heat sink from the system board (8).

NOTE: Thoroughly clean thermal material from the surfaces of the system board components (1)(3) and

the heat sink (2)(4) each time you remove the heat sink. All heat sink and processor spare part kits include
thermal material.

Reverse this procedure to install the fan/heat sink assembly.

68 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts

Processor

NOTE: All processor spare part kits include replacement thermal material.

Description Spare part number

Intel Core i7 processor, Quad Core

3632QM, 2.2-GHz processor with 6-MB L3 cache 701658-001

Intel Core i5 processors, Dual Core

3380M, 2.9-GHz processor with 3-MB L3 cache (includes thermal grease) 708762-001

3340M, 2.7-GHz processor with 3-MB L3 cache (includes thermal grease) 708761-001

3230M, 2.6-GHz processor with 3-MB L3 cache (includes thermal grease) 711903-001

Intel Core i3 processors, Dual Core

3130M, 2.6-GHz processor with 3-MB L3 cache (includes thermal grease) 713163-001

3120M, 2.5-GHz processor with 3-MB L3 cache (includes thermal grease) 700627-001

Intel Pentium processor, Dual Core

2020M, 2.4-GHz, with 2-MB L3 cache 700628-001

Intel Celeron processor

1000M, 1.8-GHz, with 2-MB L3 cache 713162-001

Before removing the processor, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the

computer on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet, and

then unplugging the AC adapter from the computer.

4. Remove the battery (see

Battery on page 34).

5. Remove the following components:

a. Service door (see

b. Hard drive (see

c. Optical drive (see

d. WLAN/Bluetooth module (see

e. Keyboard (see

f. Top cover (see

Service door on page 35).

Hard drive on page 36)

Optical drive on page 39)

WLAN/Bluetooth combo card on page 43)

Keyboard on page 45)

Top cover on page 47)

g. System board (see

System board on page 60)

h. Fan/heat sink assembly (see

Fan/heat sink assembly on page 67)

Component replacement procedures 69

Remove the processor:

1. Position the system board upside-down.

2. Use a flat-bladed screwdriver to turn the processor locking screw (1) one-half turn counterclockwise

until you hear a click.

3. Lift the processor (2) straight up and remove it.

NOTE: The gold triangle (3) on the processor must be aligned with the triangle embossed on the

processor slot (4) when you install the processor.

Reverse this procedure to install the processor.

70 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts

Latch assembly

NOTE: The latch kit is not spared.

Before removing the latch assembly, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the

computer on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet, and

then unplugging the AC adapter from the computer.

4. Remove the battery (see

5. Remove the following components:

a. Service door (see

b. Hard drive (see

c. Optical drive (see

d. WLAN/Bluetooth module (see

e. Keyboard (see

f. Top cover (see

g. System board (see

NOTE: The latch mechanisms include a small spring. Note the location of the spring.

Remove the latch assembly:

1. Position the computer upside-down.

2. Press on the tabs to disengage the latches from the lever (it clicks when disengaged).

Battery on page 34).

Service door on page 35).

Hard drive on page 36)

Optical drive on page 39)

WLAN/Bluetooth combo card on page 43)

Keyboard on page 45)

Top cover on page 47)

System board on page 60)

3. Push the lever toward the spring to gain access to the left side of the lever, and then pull the left end of

the lever upward (1).

Component replacement procedures 71

4. Rotate the left side of the lever upward to remove the pin on the top cover (2) from the groove in the

lever, and then lift the lever from the computer (3).

To install the latch assembly, reverse the removal procedure.

72 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts

Display assembly

All display assemblies include WLAN antenna transceivers and cables.

For a list of individual display spare parts, see

Description Spare part number

Display assembly, 43.9-cm (17.3-inch), HD+, anti-glare, with webcam 723643-001

Display components on page 19.

Before removing the display assembly, follow these steps:

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the

computer on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet, and

then unplugging the AC adapter from the computer.

4. Remove the battery (see

Battery on page 34).

5. Remove the following components:

a. Service door (see

b. WLAN/Bluetooth module (see

c. Keyboard (see

d. Top cover (see

Service door on page 35).

WLAN/Bluetooth combo card on page 43)

Keyboard on page 45)

Top cover on page 47)

Remove the display assembly:

1. Position the computer upside down.

2. Remove the WLAN antennas from the routing path on the bottom of the computer (1).

3. Pull the antennas through the hole that leads to the other side of the top cover (2).

Component replacement procedures 73

4. Place the computer upright and open as far as possible.

5. Remove the WLAN antennas from the tabs and the routing path (1) on the top of the computer.

6. Note the location that the antennas route through the chassis (2).

7. Remove the five Torx T8M2.5×4.0 screws (1) from the display hinges (3 screws in the left hinge, 2 in the

right hinge).

8. Lift the display assembly straight up and remove it (2).

CAUTION: When installing the display assembly, be sure that the wireless antenna cables are routed

and arranged properly.

Failure to properly route the antennas can result in degradation of the computer's wireless
performance.

74 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts

9. If you need to remove the hinge covers from the display hinges, squeeze and pull the covers straight up

and off the display to remove them.

If you need to remove the hinge covers from the display hinges, pinch the top and bottom of the hinges
and then pull the hinges straight up and off the display.

Display hinge covers are available in the Display Hinge Kit using spare part number 723642-001.

10. If you need to remove the display bezel, remove the 2 mylar screw covers (1) and the 2 Phillips

PM2.5×4.0 screws (2) in the bottom corners of the display bezel.

11. Flex the top (3) of the bezel, the inside edges of the left and right sides (4), and then the bottom (5) of

the bezel until it disengages from the display enclosure.

NOTE: Make sure the hinges are not bent (see hinge position in following image) when you remove the

bezel.

Component replacement procedures 75

12. Remove the display bezel (6).

The display bezel is available using spare part number 723640-001. Display bezel mylar screw covers
are available in the Rubber Kit, spare part number 723672-001.

13. If it is necessary to replace the webcam module, disconnect the cable from the module (1), and then

gently pull the module away from the double-sided tape on the display enclosure (2).

The webcam module is available using spare part number 721543-001.

14. If it is necessary to replace the display hinges, remove the 6 Phillips PM2.5×3.0 screws (1) that secure

the display hinges and panel to the display enclosure.

Display hinges are available in the Display Hinge Kit using spare part number 723642-001.

76 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts

15. Remove the display hinges and panel from the display enclosure (2).

16. Position the display panel and hinge assembly upright.

17. Remove the 3 Phillips PM1.5×2.0 screws (1) that secure each display hinge to the display panel.

18. Remove the display hinges (2).

Component replacement procedures 77

19. If it is necessary to remove the display/webcam cable assembly, disconnect the display panel cable

from the rear of the display panel by lifting the tape (1) that covers the connector, and disconnecting
the cable from the panel (2).

The display/webcam cable assembly is available in the Cable Kit, spare part number 723646-001.

20. Lift the display/webcam cable assembly straight up and off the display panel.

78 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts

21. If it is necessary to remove the antennas from the display enclosure, remove the antennas from clips on

each side of the enclosure (1), gently lift the transceivers (2) to disengage them from the double-stick
tape, and then lift the antennas from the display enclosure.

Antennas are available using spare part number 723641-001.

Reverse this procedure to reassemble and install the display assembly.

Component replacement procedures 79

7 Computer Setup (BIOS), MultiBoot, and

System Diagnostics in Windows 8

Using Computer Setup

Computer Setup, or Basic Input/Output System (BIOS), controls communication between all the input and
output devices on the system (such as disk drives, display, keyboard, mouse, and printer). Computer Setup
includes settings for the types of devices installed, the startup sequence of the computer, and the amount of
system and extended memory.

NOTE: Use extreme care when making changes in Computer Setup. Errors can prevent the computer from

operating properly.

Starting Computer Setup

NOTE: An external keyboard or mouse connected to a USB port can be used with Computer Setup only if

USB legacy support is enabled.

To start Computer Setup, follow these steps:

1. Turn on or restart the computer, and then press esc while the “Press the ESC key for Startup Menu”

message is displayed at the bottom of the screen.

2. Press f10 to enter Computer Setup.

Navigating and selecting in Computer Setup

To navigate and select in Computer Setup, follow these steps:

1. Turn on or restart the computer, and then press esc while the “Press the ESC key for Startup Menu”

message is displayed at the bottom of the screen.

●

To select a menu or a menu item, use the tab key and the keyboard arrow keys and then press

enter, or use a pointing device to click the item.

●

To scroll up and down, click the up arrow or the down arrow in the upper-right corner of the
screen, or use the up arrow key or the down arrow key on the keyboard.

●

To close open dialog boxes and return to the main Computer Setup screen, press esc, and then
follow the on-screen instructions.

NOTE: You can use either a pointing device (TouchPad, pointing stick, or USB mouse) or the keyboard

to navigate and make selections in Computer Setup.

2. Press f10 to enter Computer Setup.

80 Chapter 7 Computer Setup (BIOS), MultiBoot, and System Diagnostics in Windows 8

To exit Computer Setup menus, choose one of the following methods:

●

To exit Computer Setup menus without saving your changes:

Click the Exit icon in the lower-right corner of the screen, and then follow the on-screen instructions.

– or –

Use the tab key and the arrow keys to select File > Ignore Changes and Exit, and then press enter.

●

To save your changes and exit Computer Setup menus:

Click the Save icon in the lower-right corner of the screen, and then follow the on-screen instructions.

– or –

Use the tab key and the arrow keys to select File > Save Changes and Exit, and then press enter.

Your changes go into effect when the computer restarts.

Restoring factory settings in Computer Setup

NOTE: Restoring defaults will not change the hard drive mode.

To return all settings in Computer Setup to the values that were set at the factory, follow these steps:

1. Turn on or restart the computer, and then press esc while the “Press the ESC key for Startup Menu”

message is displayed at the bottom of the screen.

2. Press f10 to enter Computer Setup.

3. Use a pointing device or the arrow keys to select File > Restore Defaults.

4. Follow the on-screen instructions.

5. To save your changes and exit, click the Save icon in the lower-right corner of the screen, and then

follow the on-screen instructions.

– or –

Use the arrow keys to select File > Save Changes and Exit, and then press enter.

Your changes go into effect when the computer restarts.

NOTE: Your password settings and security settings are not changed when you restore the factory settings.

Updating the BIOS

Updated versions of the BIOS may be available on the HP website.

Most BIOS updates on the HP website are packaged in compressed files called SoftPaqs.

Some download packages contain a file named Readme.txt, which contains information regarding installing
and troubleshooting the file.

Determining the BIOS version

To determine whether available BIOS updates contain later BIOS versions than those currently installed on
the computer, you need to know the version of the system BIOS currently installed.

Using Computer Setup 81

BIOS version information (also known as ROM date and System BIOS) can be displayed by pressing fn+esc (if
you are already in Windows) or by using Computer Setup.

1. Start Computer Setup.

2. Use a pointing device or the arrow keys to select File > System Information.

3. To exit Computer Setup without saving your changes, click the Exit icon in the lower-right corner of the

screen, and then follow the on-screen instructions.

– or –

Use the tab key and the arrow keys to select File > Ignore Changes and Exit, and then press enter.

Downloading a BIOS update

CAUTION: To reduce the risk of damage to the computer or an unsuccessful installation, download and

install a BIOS update only when the computer is connected to reliable external power using the AC adapter.
Do not download or install a BIOS update while the computer is running on battery power, docked in an
optional docking device, or connected to an optional power source. During the download and installation,
follow these instructions:

Do not disconnect power on the computer by unplugging the power cord from the AC outlet.

Do not shut down the computer or initiate Sleep.

Do not insert, remove, connect, or disconnect any device, cable, or cord.

1. From the Start screen, select the HP Support Assistant app.

2. Select Updates and tune-ups, and then select Check for HP updates now.

3. At the download area, follow these steps:

a. Identify the most recent BIOS update and compare it to the BIOS version currently installed on

your computer. Make a note of the date, name, or other identifier. You may need this information
to locate the update later, after it has been downloaded to your hard drive.

b. Follow the on-screen instructions to download your selection to the hard drive.

If the update is more recent than your BIOS, make a note of the path to the location on your hard
drive where the BIOS update is downloaded. You will need to access this path when you are ready
to install the update.

NOTE: If you connect your computer to a network, consult the network administrator before installing

any software updates, especially system BIOS updates.

BIOS installation procedures vary. Follow any instructions that are displayed on the screen after the
download is complete. If no instructions are displayed, follow these steps:

1. From the Start screen, type e, and then click File Explorer.

2. Click your hard drive designation. The hard drive designation is typically Local Disk (C:).

3. Using the hard drive path you recorded earlier, open the folder on your hard drive that contains the

update.

4. Double-click the file that has an .exe extension (for example, filename.exe).

The BIOS installation begins.

5. Complete the installation by following the on-screen instructions.

82 Chapter 7 Computer Setup (BIOS), MultiBoot, and System Diagnostics in Windows 8

NOTE: After a message on the screen reports a successful installation, you can delete the downloaded file

from your hard drive.

Using MultiBoot

About the boot device order

As the computer starts, the system attempts to boot from enabled devices. The MultiBoot utility, which is
enabled at the factory, controls the order in which the system selects a boot device. Boot devices can include
optical drives, diskette drives, a network interface card (NIC), hard drives, and USB devices. Boot devices
contain bootable media or files that the computer needs to start and operate properly.

NOTE: Some boot devices must be enabled in Computer Setup before they can be included in the boot

order.

You can change the order in which the computer searches for a boot device by changing the boot order in
Computer Setup. You can also press esc while the “Press the ESC key for Startup Menu” message is displayed
at the bottom of the screen, and then press f9. Pressing f9 displays a menu that shows the current boot
devices and allows you to select a boot device. Or, you can use MultiBoot Express to set the computer to
prompt you for a boot location each time the computer turns on or restarts.

Choosing Multi Boot preferences

You can use MultiBoot in the following ways:

●

To set a new boot order that the computer uses each time it is turned on, by changing the boot order in
Computer Setup.

●

To dynamically choose the boot device, by pressing esc while the “Press the ESC key for Startup Menu”
message is displayed at the bottom of the screen, and then pressing f9 to enter the Boot Device Options
menu.

●

To use MultiBoot Express to set variable boot orders. This feature prompts you for a boot device each
time the computer is turned on or restarted.

Setting a new boot order in Computer Setup

To start Computer Setup and set a boot device order that the computer uses each time it is turned on or
restarted, follow these steps:

1. Turn on or restart the computer, and then press esc while the “Press the ESC key for Startup Menu”

message is displayed at the bottom of the screen.

2. Press f10 to enter Computer Setup.

3. Use a pointing device or the arrow keys to select the Legacy Boot Order list, and then press enter.

4. To move the device up in the boot order, use a pointing device to click the up arrow, or press the + key.

– or –

To move the device down in the boot order, use a pointing device to click the down arrow, or press the -
key.

5. To save your changes and exit Computer Setup, click the Save icon in the lower-left corner of the

screen, and then follow the on-screen instructions.

– or –

Use the arrow keys to select File > Save Changes and Exit, and then press enter.

Using MultiBoot 83

Dynamically choosing a boot device using the f9 prompt

To dynamically choose a boot device for the current startup sequence, follow these steps:

1. Open the Select Boot Device menu by turning on or restarting the computer, and then pressing esc while

the “Press the ESC key for Startup Menu” message is displayed at the bottom of the screen.

2. Press f9.

3. Use a pointing device or the arrow keys to select a boot device, and then press enter.

Setting a MultiBoot Express prompt

To start Computer Setup and set the computer to display the MultiBoot startup location menu each time the
computer is started or restarted, follow these steps:

1. Turn on or restart the computer, and then press esc while the “Press the ESC key for Startup Menu”

message is displayed at the bottom of the screen.

2. Press f10 to enter Computer Setup.

3. Use a pointing device or the arrow keys to select System Configuration > Boot Options, and then press

enter.

4. In the MultiBoot Express Popup Delay (Sec) field, enter the length of time in seconds that you want the

computer to display the startup location menu before it defaults to the current MultiBoot setting.
(When 0 is selected, the Express Boot startup location menu is not displayed.)

5. To save your changes and exit Computer Setup, click the Save icon in the lower-left corner of the

screen, and then follow the on-screen instructions.

– or –

Use the arrow keys to select File > Save Changes and Exit, and then press enter.

Your changes go into effect when the computer restarts.

Entering MultiBoot Express preferences

When the Express Boot menu is displayed during startup, you have the following choices:

●

To specify a boot device from the Express Boot menu, select your preference within the allotted time,
and then press enter.

●

To prevent the computer from defaulting to the current MultiBoot setting, press any key before the
allotted time expires. The computer will not start until you select a boot device and press enter.

●

To allow the computer to start according to the current MultiBoot settings, wait for the allotted time to
expire

84 Chapter 7 Computer Setup (BIOS), MultiBoot, and System Diagnostics in Windows 8

Using System Diagnostics

System Diagnostics allows you to run diagnostic tests to determine if the computer hardware is functioning
properly. The following diagnostic tests may be available in System Diagnostics:

●

System Tune-Up—This group of additional tests checks your computer to make sure that the main
components are functioning correctly. System Tune-Up runs longer and more comprehensive tests on
memory modules, hard drive SMART attributes, the hard drive surface, the battery (and battery
calibration), video memory, and the WLAN module status.

●

Start-up test—This test analyzes the main computer components that are required to start the
computer.

●

Run-in test—This test repeats the start-up test and checks for intermittent problems that the start-up
test does not detect.

●

Hard disk test—This test analyzes the physical condition of the hard drive, and then checks all data in
every sector of the hard drive. If the test detects a damaged sector, it attempts to move the data to a
good sector.

●

Memory test—This test analyzes the physical condition of the memory modules. If it reports an error,
replace the memory modules immediately.

●

Battery test—This test analyzes the condition of the battery and calibrates the battery if necessary. If
the battery fails the test, contact HP support to report the issue and purchase a replacement battery.

●

BIOS Management—You can update or rollback the version of the BIOS on the system. Do not shut
down or remove external power during the process. You will be given a confirmation screen before your
BIOS is modified. Select BIOS update, BIOS Rollback, or Back to main menu.

You can view system information and error logs or select languages in the System Diagnostics window.

To start System Diagnostics:

1. Turn on or restart the computer. While the “Press the ESC key for Startup Menu” message is displayed in

the lower-left corner of the screen, press esc. When the Startup Menu is displayed, press f2.

2. Click the diagnostic test you want to run, and then follow the on-screen instructions.

NOTE: If you need to stop a diagnostics test while it is running, press esc.

Using System Diagnostics 85

8 Setup Utility (BIOS) and System Diagnostics

in Windows 7

Using Setup Utility

Setup Utility, or Basic Input/Output System (BIOS), controls communication between all the input and output
devices on the system (such as disk drives, display, keyboard, mouse, and printer). Setup Utility includes
settings for the types of peripherals installed, the startup sequence of the computer, and the amount of
system and extended memory.

NOTE: Use extreme care when making changes in Setup Utility. Errors can prevent the computer from

operating properly.

Starting Setup Utility

NOTE: An external keyboard or mouse connected to a USB port can be used with Setup Utility only if USB

legacy support is enabled.

To start Setup Utility, follow these steps:

1. Turn on or restart the computer, and then press esc while the “Press the ESC key for Startup Menu”

message is displayed at the bottom of the screen.

2. Press f10 to enter Setup Utility.

Changing the language of Setup Utility

1. Start Setup Utility.

2. Use the arrow keys to select System Configuration > Language, and then press enter.

3. Use the arrow keys to select a language, and then press enter.

4. When a confirmation prompt with your language selected is displayed, press enter.

5. To save your change and exit Setup Utility, use the arrow keys to select Exit > Exit Saving Changes, and

then press enter.

Your change takes effect immediately.

86 Chapter 8 Setup Utility (BIOS) and System Diagnostics in Windows 7

Navigating and selecting in Setup Utility

To navigate and select in Setup Utility, follow these steps:

1. Turn on or restart the computer, and then press esc while the “Press the ESC key for Startup Menu”

message is displayed at the bottom of the screen.

●

To select a menu or a menu item, use the tab key and the keyboard arrow keys and then press

enter, or use a pointing device to click the item.

●

To scroll up and down, click the up arrow or the down arrow in the upper-right corner of the
screen, or use the up arrow key or the down arrow key.

●

To close open dialog boxes and return to the main Setup Utility screen, press esc, and then follow
the on-screen instructions.

2. Press f10 to enter Setup Utility.

To exit Setup Utility menus, choose one of the following methods:

●

To exit Setup Utility menus without saving your changes, press the esc key, and then follow the on­screen instructions.

– or –

Use the arrow keys to select Exit > Exit Discarding Changes, and then press enter.

●

To save your changes and exit Setup Utility menus, press f10, and then follow the on-screen
instructions.

– or –

Use the tab key and the arrow keys to select Exit > Exit Saving Changes, and then press enter.

Your changes go into effect when the computer restarts.

Displaying system information

1. Start Setup Utility.

2. Select the Main menu. System information such as the system time and date, and identification

information about the computer is displayed.

3. To exit Setup Utility without changing any settings, use the arrow keys to select Exit > Exit Discarding

Changes, and then press enter.

Using Setup Utility 87

Restoring factory settings in Setup Utility

NOTE: Restoring defaults will not change the hard drive mode.

To return all settings in Setup Utility to the values that were set at the factory, follow these steps:

1. Turn on or restart the computer, and then press esc while the “Press the ESC key for Startup Menu”

message is displayed at the bottom of the screen.

2. Press f10 to enter Setup Utility.

3. Use the arrow keys to select Exit > Load Setup Defaults.

4. Follow the on-screen instructions.

5. To save your changes and exit, press f10, and then follow the on-screen instructions.

– or –

Use the arrow keys to select Exit > Exit Saving Changes, and then press enter.

Your changes go into effect when the computer restarts.

NOTE: Your password settings and security settings are not changed when you restore the factory settings.

Exiting Setup Utility

●

To exit Setup Utility and save your changes from the current session:

If the Setup Utility menus are not visible, press esc to return to the menu display. Then use the arrow
keys to select Exit > Exit Saving Changes, and then press enter.

●

To exit Setup Utility without saving your changes from the current session:

If the Setup Utility menus are not visible, press esc to return to the menu display. Then use the arrow
keys to select Exit > Exit Discarding Changes, and then press enter.

Updating the BIOS

Updated versions of the BIOS may be available on the HP Web site.

Most BIOS updates on the HP Web site are packaged in compressed files called SoftPaqs.

Some download packages contain a file named Readme.txt, which contains information regarding installing
and troubleshooting the file.

88 Chapter 8 Setup Utility (BIOS) and System Diagnostics in Windows 7

Determining the BIOS version

To determine whether available BIOS updates contain later BIOS versions than those currently installed on
the computer, you need to know the version of the system BIOS currently installed.

BIOS version information (also known as ROM date and System BIOS) can be displayed by pressing fn+esc (if
you are already in Windows) or by using Setup Utility.

1. Start Setup Utility (BIOS).

2. Use the arrow keys to select Main.

3. To exit Setup Utility (BIOS) without saving your changes, use the tab key and the arrow keys to select

Exit > Exit Discarding Changes, and then press enter.

Downloading a BIOS update

CAUTION: To reduce the risk of damage to the computer or an unsuccessful installation, download and

install a BIOS update only when the computer is connected to reliable external power using the AC adapter.
Do not download or install a BIOS update while the computer is running on battery power, docked in an
optional docking device, or connected to an optional power source. During the download and installation,
follow these instructions:

Do not disconnect power from the computer by unplugging the power cord from the AC outlet.

Do not shut down the computer or initiate Sleep or Hibernation.

Do not insert, remove, connect, or disconnect any device, cable, or cord.

1. Windows 7—Select Start > Help and Support > Maintain.

Windows XP—Select Start > Help and Support, and then select the software and drivers update.

2. Follow the on-screen instructions to identify your computer and access the BIOS update you want to

download.

3. At the download area, follow these steps:

a. Identify the BIOS update that is later than the BIOS version currently installed on your computer.

Make a note of the date, name, or other identifier. You may need this information to locate the
update later, after it has been downloaded to your hard drive.

b. Follow the on-screen instructions to download your selection to the hard drive. Make a note of the

path to the location on your hard drive where the BIOS update is downloaded. You will need to
access this path when you are ready to install the update.

NOTE: If you connect your computer to a network, consult the network administrator before

installing any software updates, especially system BIOS updates.

BIOS installation procedures vary. Follow any instructions that are displayed on the screen after the
download is complete. If no instructions are displayed, follow these steps:

1. Windows 7—Open Windows Explorer by selecting Start > Computer.

Windows XP—Open Windows Explorer by selecting Start > My Computer.

2. Double-click your hard drive designation. The hard drive designation is typically Local Disk (C:).

3. Using the hard drive path you recorded earlier, open the folder on your hard drive that contains the

update.

Using Setup Utility 89

4. Double-click the file that has an .exe extension (for example, filename.exe).

The BIOS installation begins.

5. Complete the installation by following the on-screen instructions.

NOTE: After a message on the screen reports a successful installation, you can delete the downloaded file

from your hard drive.

Using System Diagnostics

System Diagnostics allows you to run diagnostic tests to determine if the computer hardware is functioning
properly. The following diagnostic tests are available in System Diagnostics:

●

Start-up test—This test analyzes the main computer components that are required to start
the computer.

●

Run-in test—This test repeats the start-up test and checks for intermittent problems that the start-up
test does not detect.

●

Hard disk test—This test analyzes the physical condition of the hard drive, and then checks all data in
every sector of the hard drive. If the test detects a damaged sector, it attempts to move the data to a
good sector.

●

Memory test—This test analyzes the physical condition of the memory modules. If it reports an error,
replace the memory modules immediately.

●

Battery test—This test analyzes the condition of the battery. If the battery fails the test, contact HP
support to report the issue and purchase a replacement battery.

You can also view system information and error logs in the System Diagnostics window.

To start System Diagnostics:

1. Turn on or restart the computer. While the “Press the ESC key for Startup Menu” message is displayed in

the lower-left corner of the screen, press esc. When the Startup Menu is displayed, press f2.

2. Click the diagnostic test you want to run, and then follow the on-screen instructions.

NOTE: If you need to stop a diagnostics test while it is running, press esc.

90 Chapter 8 Setup Utility (BIOS) and System Diagnostics in Windows 7
