Homelite HL80215 User Manual
OPERATOR’S
MANUAL
MANUEL D’UTILISATION
MANUAL DEL OPERADOR
2-N-1 HI-SPEED PRESSURE WASHER
Nettoyeur haute pressioN de vitesse
rapide de 2-iN-1
LAVADORA A PRESIÓN 2 EN 1
DE ALTA VELOCIDAD
HL80215
Your pressure washer has been engineered and manufactured to our high standard for dependability, ease of operation,
and operator safety. When properly cared for, it will give you years of rugged, trouble-free performance.
WARNING: To reduce the risk of injury, the user must read and understand the operator’s manual before using
this product.
Thank you for your purchase.
SAVE THIS MANUAL FOR FUTURE REFERENCE
Ce nettoyeur haute pression a été conçu et fabriqué conformément
aux strictes normes de fiabilité, simplicité d’emploi et sécurité
d’utilisation. Correctement entretenu, il vous donnera des années
de fonctionnement robuste et sans problème.
AVERTISSEMENT :
blessures, l’utilisateur doit lire et veiller à bien comprendre
le manuel d’utilisation avant d’utiliser ce produit.
Merci de votre achat.
Pour réduire les risques de
CONSERVER CE MANUEL POUR
FUTURE RÉFÉRENCE
Su lavadora de presión ha sido diseñada y fabricada de conformidad con las estrictas normas para brindar fiabilidad, facilidad
de uso y seguridad para el operador. Con el debido cuidado, le
brindará muchos años de sólido y eficiente funcionamiento.
ADVERTENCIA: Para reducir el riesgo de lesiones,
el usuario debe leer y comprender el manual del operador antes
de usar este producto.
Le agradecemos su compra.
GUARDE ESTE MANUAL PARA
FUTURAS CONSULTAS
See this fold-out section for all of the figures referenced in the operator’s manual.
Consulter l’encart à volets afin d’examiner toutes les figures mentionnées dans le manuel d’utilisation.
Consulte esta sección desplegable para ver todas las figuras a las que se hace referencia en el manual del operador.
Fig. 1
Fig. 2
B
A
A - Test button (essayer le bouton, botón de
prueba)
B - Reset button (bouton « reset », botón de
reajuste)
Fig. 4
A - Coiled garden hose (tuyau d’arrosage en
spirale, manguera de jardín espiral)
B - Pump inlet (d’entrée de la pompe, acoplador
de la bomba)
C - Garden hose (tuyau d’arrosage, manguera
de jardín)
Fig. 5
A - Pump outlet (sortie de la pompe, tomacorriente
de la bomba)
B - Nipple (têton, conexión)
C - High pressure hose (tuyau haute pression,
manguera de alta presión)
B
A
C
A
B
C
Fig. 6
A
B
A - Trigger handle (poignée à gâchette, mango
del gatillo)
B - Spray wand (lance de pulvérisation, tubo
rociador)
Fig. 3
A
C
D
G
E
B
H
F
A - Cleaning deck (nettoyer le filtre d’arrivée d’eau, unidad
de limpieza)
B - Spray wand (lance de pulvérisation, tubo rociador)
C - Trigger with lock out (gâchette avec verrou, gatillo con
seguro)
D - Hook-and-loop strap (sangle à boucles et crochets,
correa de gancho y lazada)
E - High pressure hose (tuyau haute pression, manguera
de alta presión)
F - Coiled garden hose (tuyau d’arrosage en spirale,
manguera de jardín espiral)
G - On/Off switch (interrupteur marche/arrêt, interruptor
de encendido/apagado)
H - Electrical cord with GFCI plug (cordon électrique avec
prises GFCI, cordón del mango con tomacorriente
GFCI)
ii
Fig. 7
Fig. 10
Fig. 14
A
B
LOCK/UNLOCK PEDAL
PÉDALE DE VERROUILLAGE
ET DE DÉVERROUILLAGE
PEDAL DE BLOQUEO Y
A - On/off switch (interrupteur marche/arrêt,
A
C
interruptor de encendido)
Fig. 11
DESBLOQUEO
A
D
A - Quick-connect coupler (coupleur à ressort,
collarin acciónado por resorte)
B - Spray wand (lance de pulvérisation, tubo
rociador)
C - Deck inlet plug (prise le filtre d’arrivée d’eau,
clavija de entrada de la unidad)
D - Cleaning deck (nettoyer le filtre d’arrivée
d’eau, unidad de limpieza)
Fig. 8
A
B
A - Handle inlet coupler (coupleur d’entrée de la
poignée, acoplador de entrada del mango)
B - Nipple (têton, conexión)
C - Collar (collier, collar)
Fig. 9
C
C
B
A - Coiled garden hose (tuyau d’arrosage en
spirale, manguera de jardín que se enrolla
automáticamente)
B - Electrical cord with GFCI plug (cordon
électrique avec prises GFCI, cordón del
mango con tomacorriente GFCI)
Fig. 12
C
A
A - Trigger (gâchette, gatillo)
B - Lock out (bouton de verrouillage, botón de
seguro)
C - Slot (fente, ranura)
B
Fig. 13
B
C
Fig. 15
C
B
A
A - Spray bar (barre de pulvérisation, tubo
rociador)
B - Deck nozzle (buse de terrass, boquilla de la
unidad)
C - Holder (support, sujeción)
Fig. 16
A
B
B
A
A - Cap (capuchon, tapa)
B - Detergent (détergente, detergente)
C - Detergent tank (réservoir de détergente,
tanque de detergente)
A
C
A - Spray wand (lance de pulvérisation, tubo
rociador)
B - Nozzle (buse, boquilla)
C - Turbo nozzle (buse de turbo, boquilla de
turbo)
iii
A - High pressure filter (filtre haute pression,
filtro de alta presión)
B - Cleaning deck inlet plug (prise de nettoyer le
filtre d’arrivée d’eau, clavija de entrada de la
unidad de limpieza)
TABLE OF CONTENTS
TABLE DES MATIÈRES / ÍNDICE DE CONTENIDO
Introduction ......................................................................................................................................................................2
Introducción
Important Safety Instructions ........................................................................................................................................... 3
Instrucciones de seguridad importantes
Specific Safety Rules .....................................................................................................................................................4-5
Reglas de seguridad específicas
Symbols .........................................................................................................................................................................6-7
Símbolos
Electrical ........................................................................................................................................................................... 8
Aspectos eléctricos
Features ............................................................................................................................................................................9
Características
Assembly .....................................................................................................................................................................9-10
Armado
Operation ...................................................................................................................................................................11-12
Funcionamiento
Maintenance ................................................................................................................................................................... 13
Mantenimiento
Troubleshooting ..............................................................................................................................................................14
Solución de problemas
Warranty .........................................................................................................................................................................15
Garantía
Parts Ordering and Service ...............................................................................................................................Back Page
Pedidos de piezas y servicio ............................................................................................................................................Pág. posterior
INTRODUCTION
INTRODUCTION / INTRODUCCIÓN
This product has many features for making its use more pleasant and enjoyable. Safety, performance, and dependability
have been given top priority in the design of this product making it easy to maintain and operate.
* * *
Ce produit offre de nombreuses fonctions destinées à rendre son utilisation plus plaisante et satisfaisante. Lors de la
conception de ce produit, l’accent a été mis sur la sécurité, les performances et la fiabilité, afin d’en faire un outil facile à
utiliser et à entretenir.
* * *
Este producto ofrece numerosas características para hacer más agradable y placentero su uso. En el diseño de este producto
se ha conferido prioridad a la seguridad, el desempeño y la fiabilidad, por lo cual se facilita su manejo y mantenimiento.
Page 2 — English
IMPORTANT SAFETY INSTRUCTIONS
WARNING:
Read and understand all instructions. Failure to follow
all instructions listed below may result in electric shock,
fire, and/or serious personal injury.
WARNING:
When using this product basic precautions should always
be followed, including the following:
READ ALL INSTRUCTIONS BEFORE USING
THIS PRODUCT
To reduce the risk of injury, close supervision is neces-
sary when a product is used near children.
Be thoroughly familiar with controls. Know how to stop
the product and release pressure quickly.
SAVE THESE INSTRUCTIONS
Stay alert and exercise control. Watch what you are
doing and use common sense. Do not operate product
when you are tired. Do not rush.
Do not operate the product while under the influence
of drugs, alcohol, or any medication.
Keep the area of operation clear of all persons,
particularly small children, and pets.
Don’t overreach or stand on unstable support. Keep
proper footing and balance at all times.
Follow the maintenance instructions specified in this
manual.
This product is provided with a ground fault circuit
interrupter built into the power cord plug. If replace-
ment of the plug or cord is needed, use only identical
replacement parts.
WARNING: Risk of injection or injury – Do not direct
discharge stream at persons.
GROUND FAULT CIRCUIT INTERRUPTER
PROTECTION
This pressure washer is provided with a ground fault circuit
interrupter (GFCI) built into the plug of the power supply
cord. This device provides additional protection from the risk
of electric shock. Should replacement of the plug or cord
become necessary, use only identical replacement parts that
include GFCI protection.
SERVICING OF A DOUBLE-INSULATED
APPLIANCE
In a double-insulated product, two systems of insulation
are provided instead of grounding. No grounding means is
provided on a double-insulated product, nor should a means
for grounding be added to the product. Servicing a doubleinsulated product requires extreme care and knowledge of
the system, and should be done only by qualified service
personnel. Replacement parts for a double insulated product must be identical to the parts they replace. A doubleinsulated product is marked with the words “DOUBLE
INSULATION” or “DOUBLE INSULATED.” The symbol
may also be marked on the product.
EXTENSION CORDS
Use only extension cords that are intended for outdoor use.
These extension cords are identified by a marking “Acceptable for use with outdoor appliances; store indoors while not
in use.” Use only extension cords having an electrical rating
not less than the rating of the product. Do not use damaged
extension cords. Examine extension cord before using and
replace if damaged. Do not abuse extension cord and do
not yank on any cord to disconnect. Keep cord away from
heat and sharp edges. Always disconnect the extension
cord from the receptacle before disconnecting the product
from the extension cord.
WARNING: To reduce the risk of electrocution, keep all
connections dry and off the ground. Do not touch plug with
wet hands.
Page 3 — English
SPECIFIC SAFETY RULES
Know your product. Read the operator’s manual care-
fully. Learn the machine’s applications and limitations
as well as the specific potential hazards related to this
product.
To reduce the risk of injury, keep children and visitors
away. All visitors should wear safety glasses and be kept
a safe distance from work area.
Use right product. Don’t force product or attachment to
do a job it was not designed for. Don’t use it for a purpose
not intended.
Dress properly. Do not wear loose clothing, gloves,
neckties, or jewelry. They can get caught and draw you
into moving parts. Rubber gloves and nonskid footwear
are recommended when working outdoors. Also wear
protective hair covering to contain long hair.
Do not operate the equipment while barefoot or when
wearing sandals or similar lightweight footwear. Wear
protective footwear that will protect your feet and improve
your footing on slippery surfaces.
Exercise caution to avoid slipping or falling.
Alwaysweareyeprotectionwithsideshieldsmarked
to comply with ANSI Z87.1. Following this rule will reduce
the risk of serious personal injury.
Use only recommended accessories. The use of
improper accessories may cause risk of injury.
Check damaged parts. Before further use of the
product, a guard or other part that is damaged should
be carefully checked to determine that it will operate
properly and perform its intended function. Check for
alignment of moving parts, binding of moving parts,
breakage of parts, mounting, and any other conditions
that may affect its operation. A guard or other part that
is damaged must be properly repaired or replaced by an
authorized service center to avoid risk of personal injury.
Never leave product running unattended. Turn power
off. Don’t leave product until it comes to a complete
stop.
Keep the motor free of grass, leaves, or grease to
reduce the chance of a fire hazard.
Follow manufacturer’s recommendations for safe
loading, unloading, transport, and storage of machine.
Keep product dry, clean, and free from oil and grease.
Always use a clean cloth when cleaning. Never use
brake fluids, gasoline, petroleum-based products, or any
solvents to clean product.
Check the work area before each use. Remove all
objects such as rocks, broken glass, nails, wire, or string
which can be thrown or become entangled in the
machine.
Do not use product if switch does not turn it off. Have
defective switches replaced by an authorized service
center.
Avoid dangerous environment. Don’t expose to rain.
Keep work area well lit.
Do not abuse the cord. Never use the cord to carry the
product or to disconnect the plug from an outlet. Keep
cord away from heat, oil, sharp edges, or moving parts.
Replace damaged cords immediately. Damaged cords
increase the risk of electric shock.
Ground Fault Circuit Interrupter (GFCI) protection
should be provided on the circuit(s) or outlet(s) to be
used for the product. Receptacles are available having
built-in GFCI protection and may be used for this measure
of safety.
To reduce the risk of electric shock, this product has
a polarized plug (one blade is wider than the other)
and will require the use of a polarized extension cord.
The plug will fit into a polarized extension cord only one
way. If the plug does not fit fully into the extension cord,
reverse the plug. If the plug still does not fit, obtain a
correct polarized extension cord. A polarized extension
cord will require the use of a polarized wall outlet. This
plug will fit into the polarized wall outlet only one way.
If the plug does not fit fully into the wall outlet, reverse
the plug. If the plug still does not fit, contact a qualified
electrician to install the proper wall outlet. Do not change
the equipment plug, extension cord receptacle, or extension cord plug in any way.
Make sure your extension cord is in good condition.
When using an extension cord, be sure to use one heavy
enough to carry the current your product will draw. A wire
gauge size (A.W.G.) of at least 14 is recommended for an
extension cord 25 feet or less in length. If in doubt, use the
next heavier gauge. The smaller the gauge number, the
heavier the cord. An undersized cord will cause a drop in
line voltage resulting in loss of power and overheating.
WARNING: Use outdoor extension cords marked SW-A,
SOW-A, STW-A, STOW-A, SJW-A, SJTW-A, or SJTOWA.
These cords are rated for outdoor use and reduce the risk
of electric shock.
Inspect extension cords periodically and replace if
damaged. Keep handles dry, clean, and free from oil or
grease.
Never direct a water stream toward people or pets,
or any electrical device.
Before starting any cleaning operation, close doors
and windows. Clear the area to be cleaned of debris,
toys, outdoor furniture, or other objects that could create
a hazard.
Page 4 — English
SPECIFIC SAFETY RULES
Do not use acids, alkalines, solvents, flammable
material, bleaches, or industrial grade solutions in this
product. These products can cause physical injuries to
the operator and irreversible damage to the machine.
WARNING: High pressure jets can be dangerous if
subject to misuse. The jet must not be directed at persons,
animals, electrical devices, or the machine itself.
Keep the motor away from flammables and other
hazardous materials.
Check bolts and nuts for looseness before each use. A
loose bolt or nut may cause serious motor problems.
Before storing, allow the motor to cool.
When servicing use only identical replacement parts.
Use of any other parts may create a hazard or cause
product damage.
ONLY use cold water.
Make sure minimum clearance of 3 feet is maintained
from combustible materials.
Connect pressure washer only to an individual branch
circuit.
Hold the handle and wand securely with both hands.
Expect the trigger handle to move when the trigger is
pulled due to reaction forces. Failure to do so could cause
loss of control and injury to yourself and others.
Save these instructions. Refer to them frequently and
use them to instruct other users. If you loan someone this
product, loan them these instructions also.
Page 5 — English
SYMBOLS
The following signal words and meanings are intended to explain the levels of risk associated with this product.
SYMBOL SIGNAL MEANING
DANGER:
WARNING:
CAUTION:
CAUTION:
Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper
interpretation of these symbols will allow you to operate the product better and safer.
Indicates an imminently hazardous situation, which, if not avoided, will result
in death or serious injury.
Indicates a potentially hazardous situation, which, if not avoided, could result
in death or serious injury.
Indicates a potentially hazardous situation, which, if not avoided, may result in
minor or moderate injury.
(Without Safety Alert Symbol) Indicates a situation that may result in property
damage.
SYMBOL NAME DESIGNATION/EXPLANATION
Safety Alert Indicates a potential personal injury hazard.
Read Operator’s Manual
Eye Protection
To reduce the risk of injury, user must read and understand
operator’s manual before using this product.
Always wear eye protection with side shields marked to comply
with ANSI Z87.1.
Wet Conditions Alert Do not expose to rain or use in damp locations.
To reduce the risk of injection or injury, never direct a water stream
Risk of Injection
Kickback
Electric Shock
Chemical Burns
towards people or pets or place any body part in the stream. Leaking hoses and fittings are also capable of causing injection injury.
Do not hold hoses or fittings.
To reduce the risk of injury from kickback, hold the spray wand
securely with both hands when the machine is on.
Failure to use in dry conditions and to observe safe practices can
result in electric shock.
To reduce the risk of injury or damage, DO NOT USE ACIDS,
ALKALINES, BLEACHES, SOLVENTS, FLAMMABLE MATERIAL,
OR INDUSTRIAL GRADE SOLUTIONS in this product.
Page 6 — English
SYMBOLS
Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper
interpretation of these symbols will allow you to operate the product better and safer.
SYMBOL NAME DESIGNATION/EXPLANATION
V Volts Voltage
A Amperes Current
Hz Hertz Frequency (cycles per second)
W Watt Power
Alternating Current Type of current
n
o
.../min Per Minute Revolutions, strokes, surface speed, orbits etc., per minute
No Load Speed Rotational speed, at no load
Class II Construction Double-insulated construction
Page 7 — English
ELECTRICAL
DOUBLE INSULATION
Double insulation is a concept in safety in electric power
tools, which eliminates the need for the usual threewire grounded power cord. All exposed metal parts are
isolated from the internal metal motor components with
protecting insulation. Double insulated products do not need
to be grounded.
WARNING:
The double insulated system is intended to protect the
user from shock resulting from a break in the product’s
internal insulation. Observe all normal safety precautions
to avoid electrical shock.
NOTE: Servicing of a product with double insulation requires
extreme care and knowledge of the system and should be
performed only by a qualified service technician. For service,
we suggest you return the product to your nearest authorized
service center for repair. Always use original factory replacement parts when servicing.
ELECTRICAL CONNECTION
This product has a precision-built electric motor. It should
be connected to a power supply that is 120 volts, 60 Hz,
AC only (normal household current). Do not operate this
product on direct current (DC). A substantial voltage drop
will cause a loss of power and the motor will overheat. If
the product does not operate when plugged into an outlet,
double-check the power supply.
EXTENSION CORDS
See Figure 1.
When using a power tool at a considerable distance from
a power source, be sure to use an extension cord that has
the capacity to handle the current the product will draw. An
undersized cord will cause a drop in line voltage, resulting in
overheating and loss of power. Use the chart to determine
the minimum wire size required in an extension cord. Only
round jacketed cords listed by Underwriter’s Laboratories
(UL) should be used.
When working outdoors with a product, use an extension
cord that is designed for outside use. This type of cord is
designated with “WA” or “W” on the cord’s jacket.
Before using any extension cord, inspect it for loose or
exposed wires and cut or worn insulation.
It is possible to tie the extension cord and power cord in a
knot to prevent them from becoming disconnected during
use. Make the knot as shown in figure 1, then connect the
plug end of the power cord into the receptacle end of the
extension cord. This method can also be used to tie two
extension cords together.
**Ampere rating (on product data plate)
0-2.0 2.1-3.4 3.5-5.0 5.1-7.0 7.1-12.0 12.1-16.0
Cord Length Wire Size (A.W.G.)
25' 16 16 16 16 14 14
50' 16 16 16 14 14 12
100' 16 16 14 12 10 —
**Used on 12 gauge - 20 amp circuit.
NOTE: AWG = American Wire Gauge
WARNING:
Keep the extension cord clear of the working area.
Position the cord so that it will not get caught on
lumber, tools, or other obstructions while you are working
with a power tool. Failure to do so can result in serious
personal injury.
WARNING:
Check extension cords before each use. If damaged
replace immediately. Never use the product with a
damaged cord since touching the damaged area could
cause electrical shock resulting in serious injury.
GROUND FAULT CIRCUIT INTERRUPTER
See Figure 2.
This unit is equipped with a Ground Fault Circuit Interrupter
(GFCI), which guards against the hazards of ground fault
currents. An example of ground fault current is the current
that would flow through a person who is using an appliance
with faulty insulation and, at the same time, is in contact
with an electrical ground such as a plumbing fixture, wet
floor, or earth.
GFCI plugs do not protect against short circuits, overloads,
or shocks.
NOTE: To ensure readiness for use, press the reset button
each time you connect the pressure washer to the power
supply.
The GFCI plug can be tested with the TEST and RESET
buttons.
To test:
Depress the TEST button. This should cause the RESET
button to pop out.
To restore power, depress the RESET button.
Perform this test monthly to ensure proper operation of the
GFCI.
Page 8 — English
FEATURES
PRODUCT SPECIFICATIONS
Motor .................................................................................................................................................. 120 V, 13 Amps, 60 Hz
Maximum Pounds Per Square Inch Pressure* ......................................................................................................... 1,500 psi
Maximum Gallons Per Minute* ...................................................................................................................................1.3 gpm
Maximum Inlet Water Temperature ................................................................................................................................104˚F
*Max. rating determined by PWMA Standard 101, when tested with red nozzle
KNOW YOUR PRESSURE WASHER
See Figure 3.
The safe use of this product requires an understanding of
the information on the tool and in this operator’s manual as
well as a knowledge of the project you are attempting. Before
use of this product, familiarize yourself with all operating
features and safety rules.
CLEANING DECK
The cleaning deck can be used to clean large flat areas using
less time and energy than when using the spray wand.
DETERGENT TANK
Remove the cap from the detergent tank to add detergent
to the pressure washer.
GFCI PLUG
The pressure washer is equipped with a GFCI plug to guard
against the hazards of ground fault currents. This plug does
not protect against short circuits, overloads, or shocks.
ASSEMBLY
HIGH PRESSURE HOSE STORAGE
Once the high pressure hose is rolled, hang it on the back
of the machine using the hook-and-loop strap to secure in
place.
ON/OFF SWITCH
This switch turns the pressure washer on and off.
TRIGGER HANDLE
The trigger handle has a gripping surface that provides added
control of the spray wand and helps reduce fatigue.
TRIGGER WITH LOCK-OUT
Pulling the trigger releases a stream of water for high
pressure cleaning. The lock-out provides protection against
unauthorized use.
UNPACKING
This product requires assembly.
Carefully cut the box down the sides then remove the
product and any accessories from the box. Make sure
that all items listed in the packing list are included.
WARNING:
Do not use this product if any parts on the Packing List
are already assembled to your product when you unpack
it. Parts on this list are not assembled to the product by
the manufacturer and require customer installation. Use
of a product that may have been improperly assembled
could result in serious personal injury.
Inspect the product carefully to make sure no breakage
or damage occurred during shipping.
Do not discard the packing material until you have care-
fully inspected and satisfactorily operated the product.
If any parts are damaged or missing, please call
1-800-242-4672 for assistance.
Page 9 — English
PACKING LIST
Pressure Washer
Trigger Handle
25 ft. High Pressure Hose
Self-Coiling Garden Hose
Spray Wand
Nozzle (25°, Soap, Turbo)
Operator’s Manual
WARNING:
If any parts are damaged or missing do not operate this
product until the parts are replaced. Use of this product
with damaged or missing parts could result in serious
personal injury.
ASSEMBLY
WARNING:
Do not attempt to modify this product or create accessories not recommended for use with this product. Any
such alteration or modification is misuse and could result
in a hazardous condition leading to possible serious
personal injury.
CONNECTING THE HIGH PRESSURE HOSE TO
THE PUMP
See Figure 5.
Insert the nipple on the end of the high pressure hose
collar into the pump outlet.
Slide the collar over the outlet turning the collar clockwise
to tighten securely.
Pull on the hose to be certain it is properly secured.
WARNING:
Do not connect to power supply until assembly is complete. Failure to comply could result in accidental starting
and possible serious personal injury.
CONNECTING THE WATER SUPPLY TO THE
PRESSURE WASHER
See Figure 4.
CAUTION:
Always observe all local regulations when connnecting
hoses to the water main. Some areas have restrictions
against connecting directly to public drinking water supply to prevent the feedback of chemicals into the drinking
water supply. Direct connection through a receiver tank
or backflow preventer is usually permitted.
The water supply must come from a water main. NEVER use
hot water or water from pools, lakes, etc. For ease of use,
a self-coiling hose is provided.
NOTE: When using the self-coiling hose, be sure that the
hose does not become crimped during use as this may cause
damage to the pump.
Before connecting the garden hose to the pressure
washer:
Run water through the hose for 30 seconds to clean any
debris from the hose.
Inspect the screen in the water intake.
If the screen is damaged, do not use the machine until
the screen has been replaced.
If the screen is dirty, clean it before connecting the garden
hose to the machine.
To connect the garden hose to the machine:
Attach the self-coiling hose to the pump inlet coupler.
Straighten the garden hose.
NOTE: There must be a minimum of 10 feet of unrestricted
hose between the pressure washer intake and the hose
faucet or shut off valve (such as a “Y” shut off connector).
With the hose faucet turned completely off, attach the
end of the garden hose to the self-coiling hose. Tighten
by hand.
ASSEMBLING THE SPRAY WAND
See Figure 6.
Insert the end of the spray wand into the trigger handle
outlet coupler.
Turn the connector clockwise until it stops. This secures
the wand in place.
USING THE SPRAY WAND AS A HANDLE
See Figure 7.
When not in use, the spray wand can be stored in the cleaning
deck. In this position, the wand is then used as a handle to
push/move the pressure washer from place to place.
Attaching the spray wand to the cleaning deck:
Assemble the trigger handle and spray wand as described
previously in this manual.
Insert spray wand quick connect coupler into the clean-
ing deck inlet plug. Tilt upward until coupler clips into
position.
WARNING:
To reduce the risk of injection or injury, only use the
cleaning deck on flat, horizontal surfaces. Never lift the
cleaning deck from the cleaning surface while operating
the pressure washer.
CONNECTING HIGH PRESSURE HOSE TO
TRIGGER HANDLE
See Figure 8.
Insert the nipple on the end of the high pressure hose
collar into the handle inlet coupler.
Slide the collar over the coupler turning the collar clock-
wise to tighten securely.
Pull on the hose to be certain it is properly secured.
Page 10 — English
OPERATION
WARNING:
Do not allow familiarity with the product to make you careless. Remember that a careless fraction of a second is
sufficient to inflict serious injury.
WARNING:
Always wear eye protection with side shields marked to
comply with ANSI Z87.1. Failure to do so could result in
objects being thrown into your eyes resulting in possible
serious injury.
WARNING:
Do not use any attachments or accessories not recommended by the manufacturer of this product. The use of
attachments or accessories not recommended can result
in serious personal injury.
WARNING:
Never direct a water stream toward people or pets, or
any electrical device. Failure to heed this warning could
result in serious injury.
APPLICATIONS
You may use this product for the purposes listed below:
Using cleaning deck: removing dirt and mold from decks
and cement patios
Using spray wand: cleaning cars, boats, motorcycles,
outdoor furniture, grills, and house siding
ADDING DETERGENT TO THE PRESSURE
WASHER
See Figure 9.
Use only detergents designed for pressure washers; household detergents, acids, alkalines, bleaches, solvents, flammable material, or industrial grade solutions can damage
the pump. Many detergents may require mixing prior to use.
Prepare cleaning solution as instructed on the solution bottle.
Disconnect pressure washer from power supply.
Place pressure washer upright on a flat surface.
Remove cap from detergent tank.
Pour detergent into tank until it reaches the maximum fill
level located on the unit.
NOTE: Use a funnel, if needed, to prevent accidental
spilling of the detergent outside the tank. If any detergent
is spilled during the filling process, make sure the unit is
cleaned and dried before proceeding.
Reinstall cap.
STARTING AND STOPPING THE PRESSURE
WASHER
See Figures 10 - 11.
CAUTION:
Do not run the pump without the water supply connected
and turned on.
Connect the garden hose.
Turn the garden hose on then squeeze the high pressure
trigger to relieve air pressure. Once a steady stream of
water appears, release the trigger.
After ensuring the On/Off switch is in the OFF ( O ) posi-
tion, connect the pressure washer to the power supply.
NOTE: For ease of use during operation, you may thread
the electrical cord through the coils of the garden hose
before connecting to power supply.
Press the reset button on the pressure washer’s plug to
make sure the unit is ready for operation.
Press ON ( I ) on the switch to start the motor.
To stop the motor, release the trigger and press OFF
( O ) on the switch.
WARNING:
Hold the handle and wand securely with both hands. Expect the trigger handle to move when the trigger is pulled
due to reaction forces. Failure to do so could cause loss
of control and injury to yourself and others.
USING THE SPRAY WAND TRIGGER
See Figure 12.
For greater control and safety, keep both hands on the
trigger handle at all times.
Pull back and hold the trigger to operate the pressure
washer.
Release the trigger to stop the flow of water through the
nozzle.
To engage the lock-out:
Push up on the lock-out until it clicks into the slot.
To disengage the lock-out:
Push the lock-out down and into its original position.
For the most effective cleaning, the spray nozzle should be
between 8 in. and 24 in. from the surface to be cleaned. If
the spray is too close it can damage the cleaning surface.
Page 11 — English
OPERATION
USING THE NOZZLES
See Figure 13.
Before starting any cleaning job, determine the best nozzle
for the job. Apply detergent using the soap (black) nozzle.
The 25˚ nozzle is for general purpose or large surfaces and
the turbo nozzle gives up to 50% more cleaning power.
CAUTION:
NEVER change nozzles without locking the lock-out on
the trigger handle.
Turn off the pressure washer and shut off the water sup-
ply. Pull trigger to release water pressure.
Engage the lock-out on the trigger handle by pushing up
on the lock-out until it clicks into the slot.
Push the nozzle into the quick-connect collar until it clicks
in place and is secured properly.
To disconnect a nozzle from the trigger handle once
the cleaning job is complete:
Turn off the pressure washer and shut off the water sup-
ply. Pull trigger to release water pressure.
Engage the lock-out on the trigger handle by pushing up
on the lock-out until it clicks into the slot.
Remove the nozzle by placing hand over nozzle then
pulling back the quick-connect collar. Place nozzle in the
nozzle storage area on the top of the machine.
OPERATING THE PRESSURE WASHER
See Figures 14.
Use only detergents designed for pressure washers. Many
detergents may require mixing prior to use. Prepare cleaning
solution as instructed on the solution bottle.
To clean:
Pour detergent in the detergent tank.
Install the soap nozzle on the spray wand.
Start the pressure washer and spray the detergent on
a dry surface using long, even, overlapping strokes. To
prevent streaking, do not allow detergent to dry on the
surface.
To rinse:
Using the 25˚ nozzle, spray away from the rinsing surface
for approximately 10 seconds to allow any remaining
detergent to be flushed from the line.
Start at the top of the area to be rinsed and work down,
overlapping the strokes.
USING THE CLEANING DECK
See Figure 14.
Attach the spray wand to the cleaning deck. See Using
the Spray Wand as a Handle in the Assembly section of
this manual.
Start the pressure washer.
Step on the Lock/Unlock pedal on the back of the clean-
ing deck to release the spray wand from its upright posi-
tion.
Walk slowly behind the cleaning deck, cleaning as you
go.
NOTE: If striping or swirling occurs, slow your pace.
If problem continues, see Troubleshooting later in this
manual.
CAUTION:
Striking any raised obstacle which using with the cleaning deck will damage the unit. If contact does occur and
causes vibration when operating the pressure washer,
stop and replace the spray bar. Continuing to operate
the unit without replacing the spray bar could result in
serious injury or damage to the unit.
NOTE: See figure 15 for the location of the spray bar.
MOVING THE PRESSURE WASHER
To move the pressure washer:
Turn the pressure washer off. Point nozzle in a safe direc-
tion and pull trigger to release water pressure.
Store the spray wand in the cleaning deck.
Tilt the machine toward you until it balances on the wheels
then roll the machine to the desired position.
Page 12 — English
Loading...
