Hikvision DS-2CD2H35FWD-IZS User Manual
DS-2CD2H35FWD-IZS
3 MP Ultra-Low Light Network Turret Camera
Key Features
1/2.8" Progressive Scan CMOS
2048 × 1536 resolution
Ultra-low light
H.265, H.265+
120dB WDR
IP67, IK10
BLC/3D DNR/ROI
Smart encoding: Support low bit rate, low latency
4 behavior analyses and face detection
|
|
|
|
Specifications |
|
|
|
|
|
|
Camera |
|
|
|
|
Image Sensor |
|
1/2.8" Progressive Scan CMOS |
|
|
|
|
|
|
|
Min. Illumination |
|
Color: 0.005 Lux @ (F1.2, AGC ON), 0 Lux with IR |
|
|
|
Color: 0.0089 Lux @ (F1.6, AGC ON), 0 Lux with IR |
||
|
|
|
|
|
|
|
|
|
|
|
Shutter Speed |
|
1/3 s to 1/100,000 s |
|
|
|
|
|
|
|
Slow Shutter |
|
Support |
|
|
|
|
|
|
|
Day & Night |
|
IR Cut Filter |
|
|
|
|
|
|
|
Digital Noise Reduction |
|
3D DNR |
|
|
|
|
|
|
|
WDR |
|
120dB |
|
|
|
|
|
|
|
3-Axis Adjustment |
|
Pan: 0°to 355°, tilt: 0°to 75°, rotate: 0°to 360° |
|
|
|
|
|
|
|
Lens |
|
|
|
|
Focal length |
|
2.8 to 12 mm |
|
|
|
|
|
|
|
Aperture |
|
F1.6 |
|
|
|
|
|
|
|
|
|
|
Horizontal field of view: 97°to 33° |
|
FOV |
|
Vertical field of view: 69°to 25° |
|
|
|
|
|
Diagonal field of view: 130°to 41° |
|
|
|
|
|
|
Lens Mount |
|
Φ14 |
|
|
|
|
|
|
|
IR |
|
|
|
|
|
|
|
|
|
IR Range |
|
Up to 30 m |
|
|
|
|
|
|
|
Wavelength |
|
850nm |
|
|
|
|
|
|
|
Compression Standard |
|
|
|
|
|
|
|
|
|
|
|
|
Main stream: H.265+/H.265/H.264+/H.264 |
|
Video Compression |
|
Sub stream: H.265/H.264/MJPEG |
|
|
|
|
|
Third stream: H.265/H.264 |
|
|
|
|
|
|
H.264 Type |
|
Main Profile/High Profile |
|
|
|
|
|
|
|
H.265 Type |
|
Main Profile |
|
|
|
|
|
|
|
Video Bit Rate |
|
32 Kbps to 16 Mbps |
|
|
|
|
|
|
|
Audio Compression |
|
G.711/G.722.1/G.726/MP2L2/PCM |
|
|
|
|
|
|
|
Audio Bit Rate |
|
64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2) |
|
|
|
|
|
|
|
Smart Feature-set |
|
|
|
|
|
|
|
|
|
Behavior Analysis |
|
Line crossing detection, intrusion detection, unattended baggage detection, object removal |
|
|
|
detection |
||
|
|
|
|
|
|
|
|
|
|
|
Face Detection |
|
Support |
|
|
|
|
|
|
|
Region of Interest |
|
Support 1 fixed region for main stream and sub stream |
|
|
|
|
|
|
|
Image |
|
|
|
|
Max. Resolution |
2048 × 1536 |
||
|
|
|
|
|
|
Main Stream |
|
50Hz: 25fps (2048 × 1536, 1920 × 1080, 1280 × 720) |
|
|
|
60Hz: 30fps (2048 × 1536, 1920 × 1080, 1280 × 720) |
||
|
|
|
|
|
|
|
|
|
|
|
Sub Stream |
|
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240) |
|
|
|
60Hz: 30fps (640 × 480, 640 × 360, 320 × 240) |
||
|
|
|
|
|
|
|
|
|
|
|
Third Stream |
|
50Hz: 25fps (1280 × 720, 640 × 360, 352 × 288) |
|
|
|
60Hz: 30fps (1280 × 720, 640 × 360, 352 × 240) |
||
|
|
|
|
|
|
|
|
|
|
|
Image Enhancement |
|
BLC/3D DNR |
|
|
|
|
|
|
|
Image Setting |
|
Rotate mode, saturation, brightness, contrast, sharpness adjustable by client software or web |
|
|
|
browser |
||
|
|
|
|
|
|
|
|
|
|
