DS-2CD2E20F (-W)

2.0MP Recessed Mount Dome

Hikvision understands the importance of workplace aesthetics,

especially in smaller business environments where surveillance

gear can be more conspicuous. The Hikvision 2E Series

Recessed-mount IP Camera features HD resolution, on-board

storage, a Wi-Fi connection, ultra-compact design and a choice

in cover colors to blend in with your business environment,

making this camera the ideal solution for any small business or

office space. The camera is easy to install; prongs adjust to fit
any space and don't require installation tools.

 Up to 1920 x 1080 resolution
 Full HD1080p real-time video
 Efficient encoding capability
 Support SD/SDHC/SDXC card, up to 128GB
 Tool-free installation
 Support DC12V and PoE power supply
 3D Digital Noise Reduction
 Digital WDR
 Dual-streams
 Backlight Compensation
 Support EZVIZ Cloud service
 Mobile monitoring (IVMS-4500 or EZVIZ app)
 Built-in Wi-Fi optional

Specification

Camera

Image Sensor

1/3’’ Progressive Scan CMOS

Min. Illumination

0.01 Lux @ F1.2, AGC ON

Shutter Speed

1/3s ~ 1/100,000s

Lens Type

4mm fixed lens (2.8mm/6mm lens optional)

Angle of view

4mm: 85°, 2.8mm: 106°, 6mm: 52°

Lens Mount

M12

Day & Night

Electronic

DNR

3D Digital Noise Reduction

WDR

Digital WDR

Compression Standard

Video Compression

H.264 / MJPEG

H.264 Type

Baseline Profile / Main Profile

Video Bit Rate

32 Kbps – 8 Mbps

Dual streams

Support


Max. Resolution

1920 x 1080

Frame Rate

50Hz: 25fps (1920 x 1080, 1280 × 960,1280 × 720)
60Hz: 30fps (1920 x 1080, 1280 × 960,1280 × 720)

Image Setting

Rotate Mode, Saturation, Brightness, Contrast, Sharpness adjustable by client software or web browser
BLC

Support, zone configurable

ROI Codec

Support

Network

Network Storage

NAS (Support NFS,SMB/CIFS), ANR

Alarm Trigger

Motion detection, Tampering alarm, Network disconnect, IP address conflict, Storage exception

Protocols

TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP,
IGMP, 802.1X, QoS, IPv6, Bonjour

General

One-key reset, Flash-prevention, dual stream, heartbeat, mirror, password protection, privacy mask,
watermark, IP address filtering, Anonymous access

Standard

ONVIF (PROFILE S, PROFILE G), PSIA, CGI, ISAPI

D/N Switch

Auto/Schedule/Triggered by Alarm In

Interface

Communication
Interface

1 RJ45 10M/100M Ethernet port

On-board storage

Built-in Micro SD/SDHC/SDXC slot, up to 128 GB

DS-2CD2E20F (-W)

2.0MP Recessed Mount Dome
Network Camera
