Tango Series
Bar blenders
Operation Manual
Page 2
Serie Tango
Mélangeurs de bar
Manuel d’utilisation
Página 12
Serie Tango
Licuadoras para bar
Manual de uso
Página 22
840080601 |
www.commercial.hamiltonbeach.com |
Blender Safety
IMPORTANT: This operation manual should be reviewed with all equipment operators as part of your operator training program.
Your safety and the safety of others is very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages.
This is the safety alert symbol.
This symbol alerts you to hazards that can kill or hurt you and others.
All safety messages will be preceded by the safety alert symbol and the word “DANGER” or “WARNING.” These words mean:
wDANGER
wWARNING
You will be killed or seriously injured if you don’t follow instructions.
You can be killed or seriously injured if you don’t follow instructions.
All safety messages will identify the hazard, tell you how to reduce the chance of injury, and tell you what can happen if the instructions are not followed.
wWARNING
Electrical Shock Hazard Plug into a grounded outlet.
Do not remove ground. Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death, fire, or electrical shock.
wWARNING
Cut Hazard
Always place cover on jar when blending.
Do not put hands, spoons or other utensils in jar when blending.
Failure to follow these instructions can result in broken bones or cuts.
Requesting Assistance or Service
Before calling for assistance or service, please check the “Troubleshooting Guide” in this manual. If you still need help, follow the instructions below.
Whenever you call to request assistance or service, you need to know the complete model number. You can find this information on the label on the bottom of your blender.
Please also record the purchase date of your equipment and your dealer’s name, address, and telephone number.
Model Number__________________________
Purchase Date _________________________
Dealer Name ___________________________
Dealer Address _________________________
Dealer Phone___________________________
You can also order replacement parts by calling your nearest Hamilton Beach Commercial Service Center or your local dealer.
Call our Technical Service number: 866-285-1087 or 910-693-4277
8 a.m. – 5 p.m. EST Monday – Friday (www.commercial.hamiltonbeach.com)
2
Blender Safety
IMPORTANT SAFETY INSTRUCTIONS
WARNING – When using electrical appliances, basic safety precautions should be followed, including the following:
• Read all instructions. |
• Do not defeat the jar pad sensors. |
|
• Plug into a grounded outlet. |
• Do not use outdoors. |
|
• Do not touch surfaces that may be hot. |
• This appliance is intended for short periods |
|
Use handles or knobs provided. |
of operation, with a rated operating time of |
|
• Extreme caution must be used when moving an |
3 minutes. |
|
appliance containing hot oil or other hot liquids. |
• To prevent damage to blender, jar, or cutter |
|
• Do not use appliance for other than intended use. |
assembly, DO NOT move or shake blender while |
|
• To protect against electrical shock, do not |
in operation. If blending action stops during |
|
operation, turn blender OFF, remove jar from |
||
immerse cord, plug, or blender base in water |
||
base, remove jar cover, and use a thin rubber |
||
or any other liquid. |
||
spatula to push mixture towards cutters. |
||
• Close supervision is necessary when any |
||
• Do not spray the base with a high-pressure |
||
appliance is used by or near children. |
||
spray gun. |
||
• The use of accessory attachments not |
||
• Disconnect power before cleaning or servicing. |
||
recommended by Hamilton Beach may cause |
||
• To prevent burns from hot liquids splashing out of |
||
injuries. |
||
• To reduce risk of personal injury, unplug cord |
the jar, always remove the filler cap of the |
|
container cover before blending hot liquids. |
||
from outlet when not in use, and before putting on |
||
• Do not operate any appliance with a damaged |
||
or taking off parts or doing any other servicing of |
||
the blender. |
cord or plug or after the appliance malfunctions, |
|
or is dropped or damaged in any manner. |
||
• Do not let cord hang over edge of table or |
||
Return appliance to the nearest service facility |
||
counter or touch hot surfaces. |
||
for examination, repair, or electrical or |
||
• Do not place on or near a hot gas or electric |
||
mechanical adjustment. |
||
burner or in a heated oven. |
||
• If the supply cord of this appliance is damaged, |
||
• To reduce risk of personal injury and to prevent |
||
it must be replaced by the manufacturer or its |
||
damage to blender or jar and cutter assembly, |
||
service agent or a similar qualified person. |
||
DO NOT insert utensils into blender jar while |
||
IMPORTANT: If the molded plug is cut off, |
||
operating blender, or store utensils in the blender |
||
dispose of it immediately. The plug is not rewirable |
||
jar when it is not in use. |
||
and would cause a shock hazard if inserted into |
||
• Avoid contacting moving parts. |
||
a socket. |
•Blades are sharp. Handle carefully.
•Inspect jar and cutter assembly daily. Check cutter for wear, nicks, or broken blades. Replace jar and cutter assembly at least every 12 months.
–SAVE THESE INSTRUCTIONS –
Blender Operation – Quick Start Guide
1.Place the blender on a dry, level surface.
2.Make sure the power switch is in the “off” or O position. Plug the blender into a grounded electrical outlet.
3.Place the jar on the base with ingredients and jar lid in place.
4.Set the controls to your preference.
5.Move the power switch to the “on” or I position.
3
Parts and Features
The parts and features for the Tango Series Blenders are shown on this page. Become familiar with all parts and features before using your blender.
Your Tango Series blender is designed for blending and mixing beverages.
NOTE: The Blender is not designed to crush ice. Ice cubes made in most icemakers may be added to liquid ingredients in the blender to make daiquiris or similar drinks.
NOTE: Only use the Hamilton-Beach 91300 blender container (part number 6126-91300, as provided with the unit).
Removable
Filler Cap
Container
Cutter
Assembly
Blades
Model 91300
On (I)/Off (O)/
Pulse
Switch
Low/Hi
Switch
Cover
Gasket
Collar
Blender
Base
Model 91300
Removable
Filler Cap
Cover
Container
Gasket
Cutter
Assembly
Collar
Blades
Blender
Base
Model 91350
Timer Dial
On/Off
Switch
Model 91350
4
Operation
Operating the Blender–Model 91300
wWARNING
Electrical Shock Hazard Plug into a grounded outlet.
Do not remove ground. Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death, fire, or electrical shock.
wWARNING
Cut Hazard
Always place cover on jar when blending.
Do not put hands, spoons or other utensils in jar when blending.
Failure to follow these instructions can result in broken bones, cuts or other injuries.
Controls
Two separate switches on the front panel allow you to control the blender for precise blending requirements:
•The On/Off switch will turn the blender On for continuous operation or Off.
•The
Pulse position on the On/Off switch (Model 91300 only) turns on the blender only when the switch is pressed. When the switch is released, the blender will stop. This will allow you to precisely control the operation of the blender.
•The Hi/Low switch allows you to select the following speeds:
Hi – 20,000 RPM Low – 18,500 RPM
Using the blender
Before you use the blender for the first time, wash the container, cover, and cutter unit assembly. Refer to “Cleaning Instructions.” Do not put the cutter assembly in the dishwasher.
To operate the blender, proceed as follows:
1.Place the blender on a clean, dry, level surface, and set the On/Off switch to Off.
2.Place cutter unit in the threaded collar, blades up. Slip the gasket OVER the blades and onto the base of the cutter assembly. Screw the completed cutter assembly onto the container.
On (I) / |
|
|
Off (O) / |
Hi/Low |
|
Pulse |
||
Switch |
||
Switch |
||
|
Model 91300
3.Plug the blender into an electric outlet.
4.Place the ingredients to be blended into the container.
5.Place the container onto the base. Make sure it rests securely on the base.
6.Place the cover and filler cap on the container.
7.Set the Hi/Low switch to the desired speed. See “Professional Blending Techniques” for blending tips.
NOTE: If you want the blender to run for short bursts, press the
Pulse switch. While you are pressing the
Pulse switch, the blender will run at the selected speed. Release the Pulse switch to stop the blender.
5
Operation |
Operation |
|
|
Operating the Blender–Model 91350
wWARNING
Electrical Shock Hazard Plug into a grounded outlet.
Do not remove ground. Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death, fire, or electrical shock.
Controls
Two separate switches on the front panel allow you to control the blender for precise blending requirements:
•The Timer dial (Model 91350 only) allows you to select the blend time. Turn the dial clockwise to the desired setting.
•The On/Off switch will turn the blender on for continuous operation or off.
Using the blender
Before you use the blender for the first time, wash the container, cover, and cutter assembly. Refer to “Cleaning Instructions.” Do not put the cutter assembly in the dishwasher.
To operate the blender, proceed as follows:
1.Place the blender on a clean, dry, level surface, set the On/Off switch to Off, and turn the timer dial counterclockwise to the off position.
2.Place cutter in the threaded collar, blades up. Slip the gasket OVER the blades and onto the base of the cutter assembly. Screw the completed cutter assembly onto the container.
3.Plug the blender into an electric outlet.
4.Place the ingredients to be blended into the container.
wWARNING
Cut Hazard
Always place cover on jar when blending.
Do not put hands, spoons or other utensils in jar when blending.
Failure to follow these instructions can result in broken bones, cuts or other injuries.
Timer
Dial
On (I) /
Off (O)
Switch
Model 91350
5.Place the container onto the base. Make sure it rests securely on the base.
6.Place the cover and filler cap on the container.
7.Select the desired blend time.
8.Move the On/Off switch to the On position. Release the switch; blending will stop automatically after the desired time.
9.For manual operation, set the dial to “manual”. Blender will need to be turned on/off manually.
6
Operating the Blender
Professional Blending Techniques
Filling the container
When filling the container with ingredients, follow these recommendations:
•Use sufficient amount of liquid to ensure that the mixture is fluid and free-running at all times. Pour the liquid into the container FIRST.
•Cut solid ingredients into pieces that are no bigger than a 1″(2.5cm)cube.
•Add the ingredients to container in batches. Do not blend maximum volume all at once.
•Do NOT overfill the container with product. This may prevent the blender from processing the product properly. Process dense foods or thick mixtures in small batches, and remember that the volume of the product normally increases during processing.
wWARNING
Burn Hazard
Always use caution when blending hot contents.
Failure to follow these instructions can result in burns.
•Do not exceed one quart of content when blending hot product.
•Always place the cover and filler cap on the container when blending. For blending hot liquids, remove filler cap from container cover before blending.
Blending techniques
Icy drinks – Do not use blender to crush large ice cubes. The blender is not designed for this. Small ice cubes or crushed ice is recommended. Pour in liquid, then add ice. Cover. Set speed at HIGH (except model 91350) and process until desired consistency is reached. Chunks of frozen fruit can be added to milk or fruit juice to produce a sherbet or slush.
Blending hot mixtures
IMPORTANT: To minimize the possibility of scalding, the following precautions MUST be observed:
•Do not exceed 1 quart of content when blending hot product. Remember that the volume of the product normally increases during processing.
•Always place the cover on the container and remove the filler cap from container cover when blending hot liquids to prevent the build up of pressure.
•Never stand with your face directly over the container when operating the blender where steam may be released.
•Begin on LOW speed and then select a speed that produces a column of air in the center of the container (except model 91350).
Filler Cap
Use the filler cap to add liquids to the container while the unit is running.
7
Caring for the Blender
Cleaning Instructions
wWARNING
Electrical Shock Hazard
Plug into a grounded outlet.
Do not remove ground.
Do not use an adapter.
Do not use an extension cord.
Do not immerse base in water or other liquid.
Failure to follow these instructions can result in death, fire, or electrical shock.
wWARNING
Cut Hazard
Always place cover on jar when blending.
Do not put hands, spoons or other utensils in jar when blending.
Failure to follow these instructions can result in broken bones or cuts.
Sanitizing
1.Wash container as instructed in “General Cleaning.”
General cleaning
Do not allow food residue to dry on any part of the blender. Wash and rinse container, cutter unit assembly and base after each use, or whenever it will not be used again within one hour, as follows:
1.Remove the container from the base, and then remove the cover. Add cleaning solution to the container. Use a washing solution of hot water (less than 115° F/46° C) and a non-sudsing detergent. Use the recommended amount of detergent.
2.Scrub and flush out the container interior, cover and filler cap to remove food residue. Empty container.
3.Fill container 1⁄4 full with fresh washing solution and place it on the base.
4.Replace the cover on the container and run the blender on high speed (except model 91350) for 2 minutes.
5.Repeat step 3 using clean rinse water (95° F/35° C).
6.Wipe down the container, filler cap, and cover with a soft cloth or sponge, dampened with fresh washing solution.
7.Wipe the exterior of the base with a damp cloth or sponge. The base contains electrical components: do not immerse, use a high-pressure washer, or use a dishwasher
to clean the base.
2.Fill container with sanitizing solution (See “Recommended Sanitizing Solution” below) and place on base.
3.Replace cover and filler cap and run on LOW (except model 91350) speed for 2 minutes. Empty container.
4.Wipe the container exterior with a soft cloth or sponge dampened with sanitizing solution.
5.Immerse the cover and filler cap in sanitizing solution for two minutes.
6.Remove any remaining moisture from cutter assembly by replacing container on base with cover and filler cap in place. Then run blender on HiGH (except model 91350) speed for a minimum of 2 minutes.
7.To dry, place empty container on base and run on HIGH (except model 91350) speed for two seconds.
8.When ready to use, rinse with clean water.
NOTE: Do not rinse container, cover or filler cap after sanitizing.
Recommended Sanitizing Solution:
The sanitizing solution should consist of 1 tablespoon of household bleach per 1 gallon of clean, cool water (60° F, 16° C) mixed according to the instructions on the bleach. When using a sanitizing solution other than that recommended, the sanitizing solution concentration should be tested using commercially available test strips and should indicate a concentration between 100 and 200 parts per million of bleach to water.
8
|
|
|
Caring for the Blender |
|
|
|
|
|
Troubleshooting Guide |
||
|
|
|
|
|
Problem . . . |
Solution . . . |
|
|
|
|
|
|
Blender fails to start |
• Check to see if unit is securely plugged into an electric outlet. |
|
|
or stops while it is |
• Check to see if the fuse for the electric outlet has blown or if a circuit breaker |
|
|
running and cannot |
has tripped. |
|
|
be restarted |
|
|
|
|
|
|
|
Ingredients will not mix |
• Check to see if enough liquid has been added to the ingredients. Mixture should |
|
|
properly |
be fluid and free-running at all times. |
|
|
|
• Solid pieces are too large. Pieces should not exceed 1" cubes. |
|
|
|
• Container is too full. Do not fill past highest graduation marking. |
|
|
|
• Cutter unit blades are not sharp or are damaged. Inspect |
|
|
|
container and cutter assembly daily. Replace container and |
|
|
|
cutter assembly at least every 12 months or sooner if cutter assembly appears |
|
|
|
worn or damaged. |
|
|
|
• Check to see if cutter assembly is installed properly. |
|
|
|
• Select speed to create a fluid blend. |
|
|
|
|
|
|
Model 91350 fails to |
• Depress switch to the Off position, then release. Then turn blender On according |
|
|
start when switch is |
to the instructions. |
|
|
depressed. |
|
|
|
|
|
|
Maintenance
Inspect the blender and its various parts and replace as follows:
Daily |
Unplug the blender and remove the container from the base, and then inspect the |
|
container and cutter unit assembly for wear, nicks, and broken or loose blades. Replace if |
|
necessary. If the blades are loose, discontinue use immediately and replace the blades. |
|
Do not attempt to repair or tighten the cutter assembly. See “Replacement Parts” below. |
|
|
Weekly |
Unplug the blender, and then inspect the power cord insulation and power plug for cracks. |
|
Refer to “Requesting Assistance or Service” for repair or replacement. |
Yearly |
Replace the container and cutter assembly at least once a year. |
|
See “Replacement Parts” below. |
|
|
Replacement Parts
Refer to “Requesting Assistance or Service” to order parts below.
Model |
Part Description |
Part Number |
|
|
|
91300/91350 |
1 container |
6126-91300 |
91300/91350 |
Cutter assembly |
99200 |
|
|
|
9
Product Warranty
This Warranty supercedes all other Product Warranties
LIMITED WARRANTY
This product is warranted to be free from defects in material and workmanship for a period of two (2) years from the date of original purchase, except as noted below. During this period, we will repair or replace this product, at our option, at no cost to you. THE FOREGOING WARRANTY IS IN LIEU OF ANY OTHER WARRANTY, WHETHER EXPRESS OR IMPLIED, WRITTEN OR ORAL INCLUDING ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ANY LIABILITY IS EXPRESSLY LIMITED TO AN AMOUNT EQUAL TO THE PURCHASE PRICE PAID, AND ALL CLAIMS FOR SPECIAL,INCIDENTAL AND CONSEQUENTIAL DAMAGES ARE HEREBY EXCLUDED. There is no warranty with respect to the following, which may be supplied with this product: (motor brushes, container and cutter assembly, clutches, bristle brushes, funnel, stainless steel cup, agitators, carafes, etc.). This warranty extends only to the original purchaser and does not cover a defect resulting from abuse, misuse, neglect, unauthorized repair, or use not in conformity with the printed directions. Always use this product in the manner provided in the Operation Manual. This warranty gives you specific legal rights and you may also have other legal rights which vary from state to state, or province to province. Some states do not allow limitations on implied warranties or special, incidental or consequential damages, so the foregoing limitations may not apply to you.
If you have a claim under this warranty please contact our TECHNICAL SERVICE DEPARTMENT at 1-866-285-1087 or 910-693-4277. (For faster service please have model, series, and type numbers ready for operator to assist you.) Reasonable proof of date of purchase must be presented; otherwise the effective date of the warranty will be based upon the date of manufacture plus ninety (90) days.
Hamilton Beach/Proctor-Silex, Inc. |
|
Commercial Customer Service |
|
263 Yadkin Road |
|
Southern Pines, NC 28387 |
12/03 |
10
Loading...
