READ BEFORE USE
LIRE AVANT UTILISATION LEA ANTES DE USAR
Visit www.hamiltonbeach.com for our complete line of products and Use and Care Guides – as well as delicious recipes, tips, and to register your product online!
Rendez-vous sur www.hamiltonbeach.ca pour notre liste complète de produits et de nos manuels utilisateur – ainsi que nos délicieuses recettes et nos conseils !
¡Visite www.hamiltonbeach.com (EE. UU.) o www.hamiltonbeach.com.mx (México) para ver otros productos de Hamilton Beach o para contactarnos!
Questions?
Please call us – our friendly associates are ready to help.
USA: 1.800.851.8900
Questions ?
N’hésitez pas à nous appeler – nos associés s’empresseront de vous aider.
CAN : 1.800.267.2826
¿Preguntas?
Por favor llámenos – nuestros amables representantes están listos para ayudar.
EE. UU.: 1.800.851.8900
MEX: 01 800 71 16 100
Le invitamos a leer cuidadosamente este instructivo antes de usar su aparato.
840253700 ENv07.indd 1
Hand Mixer Batteur à main Batidora
English....................... |
2 |
Français................... |
12 |
Español.................... |
15 |
|
2/27/15 1:13 PM |
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always be followed to reduce the risk of fire, electric shock, and/or injury to persons, including the following:
1.Read all instructions.
2.This appliance is not intended for use by persons (including children) with reduced physical, sensory, or mental capabilities, or lack of experience and knowledge, unless they are closely supervised and instructed concerning use of the appliance by a person responsible for their safety.
3.Close supervision is necessary when any appliance is used by or near children. Children should be supervised to ensure that they do not play with the appliance.
4.Do not touch hot surfaces. Use handles or knobs.
5.To protect against fire, electric shock, and injury to persons, do not immerse cord, plug, or the appliance in water or other liquids.
6.Unplug from outlet when not in use, before putting on or taking off parts, and before cleaning.
7.Do not operate appliance with a damaged cord or plug, or after the appliance malfunctions or has been dropped or damaged in any manner. Call our toll-free customer assistance number for information on examination, repair, or adjustment.
8.The use of accessory attachments not recommended by the appliance manufacturer may result in fire, electrical shock, or injury to persons.
9.Do not use outdoors or in a damp area.
10.Do not let cord hang over edge of table or counter or touch hot surfaces, including stove.
11.Do not place on or near a hot gas or electric burner, or in a heated oven.
12.Check that control is turned to OFF (O) before plugging cord into wall outlet. To disconnect the appliance, turn control to OFF (O); then remove plug from the wall outlet.
13.Do not use this appliance for anything other than its intended use.
14.Remove the accessories from mixer before washing.
15.Do not continuously use the mixer for longer than 5 minutes at one time.
16.Do not fill the mixing container more than 90% of its capacity.
17.When mixing liquids, use a tall container or mix small quantities at a time to reduce spillage.
18.Do not mix hot ingredients.
19.Never add ingredients to container while appliance is operating.
20.The whisk should be used without any other attachment.
21.Keep hands, hair, clothing, as well as spatulas and other utensils, away from beaters during operation to reduce the risk of injury to persons and/or damage to the mixer.
22.Avoid contacting moving parts.
SAVE THESE INSTRUCTIONS!
2
840253700 ENv07.indd 2 |
2/27/15 1:13 PM |
Other Consumer Safety Information
This appliance is intended for household use only.
w WARNING Electrical Shock Hazard: This product is provided with a polarized plug (one wide blade) to reduce the risk of electric shock. The plug fits only one way into a polarized outlet. Do not defeat the safety purpose of the plug by modifying the plug in any way or by using an adapter. If the plug does not fit fully into the outlet, reverse the plug. If it still does not fit, have an electrician replace the outlet.
The length of the cord used on this appliance was selected to reduce the hazards of becoming tangled in or tripping over a longer cord.
If a longer cord is necessary, an approved extension cord may be used. The electrical rating of the extension cord must be equal to or greater than the rating of the appliance. Care must be taken to arrange the extension cord so that it will not drape over the countertop or tabletop where it can be pulled on by children or accidentally tripped over.
w CAUTION Moving Parts Hazard:
To reduce the risk of personal injury, always unplug mixer before inserting or removing beaters.
WATTAGE/PEAK POWER INFORMATION
The marked rating of the hand mixer is determined by Underwriters Laboratories as the maximum stabilized power consumption of the hand mixer at high speed under a loaded condition.
Peak power is an average of the maximum wattage a hand mixer may consume during initial operation at high speed.
3
840253700 ENv07.indd 3 |
2/27/15 1:13 PM |
Parts and Features |
|
Handle With |
Storage Case |
|
|
|
|
|
|
*Optional Accessory on Select Models |
Speed Control/ |
Burst Button |
Soft-Grip Material |
|
|
|
|||
Eject Button |
|
|
|
|
*To order parts: |
|
|
|
|
|
|
|
|
|
US: 1.800.851.8900 |
|
|
|
|
www.hamiltonbeach.com |
|
|
|
|
Canada: 1.800.267.2826 |
|
|
Housing |
Beater |
Mexico: 01 800 71 16 100 |
|
|
|
Attachments* |
|
|
|
Power Plug |
|
|
|
|
With Power |
|
|
|
|
Cord |
|
|
|
|
Bowl Rest |
Whisk |
|
|
|
|
Attachment* |
NOTE: The mixer is equipped with |
Openings for |
|
|
|
a burst button. By pressing and |
|
Collar |
||
holding the burst button down at |
Attachments |
|
||
any speed, you can add additional |
|
|
|
Disc |
power. |
|
|
|
|
Do not use the burst button for |
|
|
|
|
more than 2 minutes at a time; |
|
Dough Hook |
|
|
otherwise the motor may overheat. |
|
|
||
When mixing is finished, set the |
|
Attachments* |
|
|
speed control back to the OFF (O) position and unplug the power plug from the wall outlet.
4
840253700 ENv07.indd 4 |
2/27/15 1:13 PM |
Before First Use
•Remove all packaging materials, labels, and/or stickers from your hand mixer.
•Check that all parts are enclosed and that the unit is not damaged.
•Clean the appliance and all accessories. See “Cleaning” section on page 9.
Use of the Attachments
Attachment |
Use |
Beaters |
• For general mixing purposes |
Dough hooks |
• Mixing heavy food like bread or pizza batters |
|
• NOTE: Only use dough hooks on speeds 3 to 6. Do not knead dough continuously for more than 5 minutes |
|
or the mixer may overheat. Do not knead more than one loaf at a time. |
Whisk |
• Whipping cream or beating egg whites |
|
|
5
840253700 ENv07.indd 5 |
2/27/15 1:13 PM |
How to Use Your Hand Mixer w CAUTION Moving Parts Hazard:
To reduce the risk of personal injury, always unplug mixer before inserting or removing beaters.
1
Make sure the hand mixer is unplugged and the speed control is set to the OFF (O) position.
2 |
3 |
Insert the desired attachment (see the table on next page for reference).
5 |
6 |
Set the speed control to a desired speed to switch on the appliance. NOTE: Start at speed 1 and gradually increase to a higher speed, as needed. Thoroughly mix the ingredients. When finished, turn speed control to OFF (O) and unplug mixer.
6
7 |
NOTE: Always unplug mixer before attempting to remove beaters.
4
Place the ingredients you want to mix into a bowl.
840253700 ENv07.indd 6 |
2/27/15 1:13 PM |
Mixing Guide
General Mixing Guide
The following mixing guide is a suggestion for selecting mixing speeds for 6-speed mixers. Begin on speed 1 and increase to desired speed depending on the recipe consistency.
SPEED |
FUNCTION |
|
|
O |
OFF (Must be OFF/O to eject beaters) |
|
|
1 |
LOW speed for folding or mixing in dry ingredients, |
|
muffins, or quick breads |
|
|
2 |
To cream butter and sugar; most cookie dough |
|
|
3 |
MEDIUM speed for most packaged cake mixes |
|
|
4 |
Frosting and mashed potatoes; kneading dough |
|
|
5 |
Beating egg whites; kneading dough |
|
|
6 |
HIGH speed for whipping cream |
|
|
Cookie Dough Mixing Guide
•Use a large mixing bowl so that the ingredients spread out for easier mixing.
•Butter and margarine should be at room temperature.
•Add flour one cup at a time, mixing thoroughly after each addition.
•Chips and nuts should be stirred by hand.
Attachment |
How to Install |
|
Beaters |
• |
Insert one beater into any of the openings. Push |
|
|
until it clicks into place. |
|
• |
Repeat the step above to insert another beater. |
Dough hooks |
• |
Insert a dough hook with a collar disc into the right- |
|
|
side opening. Push until it clicks into place. |
|
• |
Repeat the step above to insert another dough |
|
|
hook. |
Whisk |
• |
Insert the whisk into any of the openings. Push until |
|
|
it clicks into place. |
|
|
|
NOTES:
•Attachments should be used as a set (2 beaters, 2 dough hooks, or 1 whisk). Do not mix different attachments.
•You can rest the mixer on the bowl using the bowl rest during periods of nonuse; for example, when you are adding ingredients to the mixture. However, never place the mixer on the bowl rest while the appliance is switched on. Also, make sure that the bowl on which the mixer is resting will not fall over. You can also rest the mixer on its heel.
7
840253700 ENv07.indd 7 |
2/27/15 1:13 PM |
Mixing Guide
There are 6 speed settings available. The speed can be adjusted anytime by using the speed control:
|
Speed Setting |
Use |
||
|
0 |
• |
Mixer OFF (O) and/or eject attachments |
|
|
|
• |
Start mixing cake mixes |
|
|
|
• |
Slow mixing for combining and aerating |
|
|
|
|
dry ingredients without splattering |
|
|
|
• |
Add ingredients to cookie doughs or cake |
|
Low |
1 |
|
batters |
|
|
• |
Fold creams or egg whites into batters |
||
|
|
• |
Start mixing frostings |
|
|
|
• |
Stir sauces and gravies |
|
|
|
• |
Mix muffin or pancake batters |
|
|
|
• |
Cream cold butter and sugar |
|
|
2 |
• |
Mash potatoes |
|
|
|
• |
Add dry ingredients to doughs or batters |
|
|
|
• |
Add eggs to doughs or batters |
|
|
3 |
• |
Add dry ingredients with liquid ingredients |
|
|
• |
Cream softened butter and sugar |
||
|
|
|||
|
|
• |
Whip potatoes |
|
Medium |
|
• |
Whip cream (with the whisk) |
|
|
4 |
• |
Finish beating butter cream frostings |
|
|
|
• |
Finish beating cake mixes |
|
|
5 |
• |
Beat whole eggs or yolks |
|
|
• |
Mix thin batters |
||
|
|
|||
|
|
• |
Add sugar to whipped egg whites for |
|
High |
6 |
|
meringues |
|
• |
Beat egg yolks until thick and light |
|||
|
|
|||
|
|
• |
Whip egg whites |
|
8
Removing Attachments
•Set the speed control to the OFF (O) position to turn the hand mixer off. Remove the attachments from the bowl.
•Disconnect the power plug from the wall outlet.
•Hold the attachments at their stems.
•Press the eject button to release the attachments from the hand mixer.
NOTES:
•Make sure to turn the hand mixer OFF (O) before adding any ingredients.
•Never use bare hands to add ingredients into the bowl.
•Use a spoon or some other utensil to add ingredients into the bowl.
•Always turn the hand mixer OFF (O) and unplug when not in use.
840253700 ENv07.indd 8 |
2/27/15 1:13 PM |
Cleaning
w WARNING Electrical Shock Hazard.
Disconnect power before cleaning. Do not immerse mixer, cord, or plug in any liquid.
1 |
2 |
3 |
NOTES:
•Clean the hand mixer after every use. This appliance contains no user-serviceable parts and requires little maintenance. Leave any servicing or repairs to qualified personnel.
•Clean and dry all parts before storing. Store the hand mixer in its storage case or in a clean, dry place. Never wrap the power cord around the hand mixer.
DISHWASHER-SAFE |
DO NOT use the “SANI” setting when washing in the dishwasher. “SANI” cycle temperatures could damage your product.
9
840253700 ENv07.indd 9 |
2/27/15 1:13 PM |
Troubleshooting
PROBLEM |
CAUSE/SOLUTION |
|
The motor works very |
• |
Too many ingredients in the bowl. |
slowly. |
• |
The speed control is set to low speed. |
|
• |
Remove some foods and restart. |
|
• |
Set the speed control to higher speed. |
The motor does |
• |
The power plug is not connected to the wall outlet. |
not start. |
• |
The hand mixer is not switched on. |
|
• |
The motor is damaged. |
|
• |
Connect the power plug to a suitable wall outlet. |
|
• |
Set the speed control to 1–6 speed setting. |
|
• |
Contact our customer assistance number. |
|
|
|
10
