READ BEFORE USE

LIRE AVANT D’UTILISER

LEA ANTES DE USAR

Visit hamiltonbeach.com for delicious recipes, tips, and to register your product online!

Consulter hamiltonbeach.ca pour les recettes délicieuses, conseils pratiques, et pour enregistrer votre produit!

¡Visite hamiltonbeach.com.mx para recetas deliciosas, consejos, y para registrar su producto en línea!

Questions?

Please call us – our friendly associates are ready to help. USA: 1.800.851.8900

Questions?

N'hésitez pas à nous appeler – nos associés s'empresseront de vous aider.

CAN: 1.800.267.2826

¿Preguntas?

Por favor llámenos – nuestros amables representantes están listos para ayudar.

MEX: 01 800 71 16 100

Le invitamos a leer cuidadosamente este instructivo antes de usar su aparato.

BrewStation®

English ......................	2
Français ..................	12
Español ..................	23

840177100 ENnv11.qxd:Layout 1 10/28/08 2:45 PM Page 2

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always be followed to reduce the risk of fire, electric shock, and/or injury to persons, including the following:

1.Read all instructions.

2.Do not touch hot surfaces. Use handles or knobs. Care must be taken, as burns can occur from touching hot parts or from spilled, hot liquid.

3.To protect against electric shock, do not place cord, plug, or BrewStation® in water or other liquid.

4.Close supervision is necessary when any appliance is used by or near children.

5.Unplug from outlet when either the BrewStation® or clock is not in use and before cleaning. Allow to cool before putting on or taking off parts and before cleaning the appliance.

6.Scalding may occur if the lid is lifted during the brewing cycle. Do not open lid until coffeemaker has cooled completely.

7.BrewStation® must be operated on a flat surface away from the edge of counter to prevent accidental tipping.

8.Do not operate any appliance with a damaged cord or plug, or after the appliance malfunctions or is dropped or damaged in any manner. Call our toll-free customer service number for information on examination, repair, or adjustment.

9.The use of accessory attachments not recommended by the appliance manufacturer may cause injuries.

10.Do not use outdoors.

11.Do not let cord hang over edge of table or counter or touch hot surfaces, including stove.

12.The coffee tank is designed for use with this BrewStation®. It must never be used on a range top or in a microwave oven.

13.Do not place BrewStation® on or near a hot gas or electric burner or in a heated oven.

14.To disconnect BrewStation®, turn controls to OFF, then remove plug from wall outlet.

15.WARNING! To reduce the risk of fire or electric shock,

do not remove the bottom cover. No user-serviceable parts are inside. Repair should be done by authorized service personnel only.

16.Do not use appliance for other than intended use.

SAVE THESE INSTRUCTIONS!

2

840177100 ENnv11.qxd:Layout 1 10/28/08 2:45 PM Page 3

IMPORTANT

Never use coffee tank to pour hot coffee or carry hot coffee.

Handle coffee tank when it holds only cold water.

Additional Information

•If overflow occurs: Let unit, coffee, and grounds cool completely before attempting any cleanup.

•Use only brand-name, high-quality filters.

•Use only 1 tablespoon of ground coffee for each cup of water.

•Use coffeemaker cleaner to prevent hard water deposits that affect coffeemaker performance. Clean monthly.

•Do not clean coffee tank in dishwasher.

•Read instructions before using.

OTHER CONSUMER SAFETY INFORMATION

This appliance is intended for household use only.

WARNING! Shock Hazard: This appliance has a polarized plug (one wide blade) that reduces the risk of electric shock. The plug fits only one way into a polarized outlet. Do not defeat the safety purpose of the plug by modifying the plug in any way or using an adapter. If the plug does not fit, reverse the plug. If it still does not fit, have an electrician replace the outlet.

The length of the cord used on this appliance was selected to reduce the hazards of becoming tangled in, or tripping over a longer cord. If a longer cord is necessary, an approved extension

cord may be used. The electrical rating of the extension cord must be equal to or greater than the rating of the BrewStation®. Care must be taken to arrange the extension cord so that it will not drape over the countertop or tabletop where it can be pulled on by children or accidentally tripped over.

To avoid an electrical circuit overload, do not use another highwattage appliance on the same circuit with your BrewStation®.

3

840177100 ENnv11.qxd:Layout 1		10/28/08	2:45 PM	Page 4
	Parts and Features				Optional Accessories
	Filter Basket		Lid				To Order Call:
							1.800.851.8900 (U.S.)
						Coffee Scoop	1.800.267.2826 (Canada)
	Coffee						01.800.71.16.100 (Mexico)
	Tank						or visit hamiltonbeach.com
		Water Level Guide				Water Filter
		(see Fig. 1)
					Water
					Reservoir	Fig. 1
Coffee Level					Keep Warm Plate
Guide	Control Panel
	and Display
	Coffee Dispenser Bar
						Water Level Guide
	Drip Tray
4

840177100 ENnv11.qxd:Layout 1 10/28/08 2:45 PM Page 5

How To Make Coffee

Before first use: Wash coffee tank, filter basket, and drip tray in hot, soapy water. NEVER put the water reservoir in dishwasher.

BrewStation® can be programmed to automatically shut off in 0 (for Iced Coffee), 1, 2, 3, or 4 hours as desired. Default is 4 hours for automatic shutoff.

1	2
3	4

Avoid getting coffee grounds in any other areas of the BrewStation®.

wWARNING Burn Hazard.

•Never use coffee tank to pour or carry hot coffee.

•Handle coffee tank only when holding cold water for filling water reservoir and to clean tank after BrewStation® has been shut off and the coffee is cool.

•If BrewStation® overflows, unplug unit. Allow unit, coffee, and grounds to cool before cleaning unit, coffee, or grounds.

*Coffee scoop is optional feature on select models.

Water Level Guide (inside reservoir)

Normal Amount of Coffee Per Cup 1 scoop* or 1 level tablespoon per cup

Maximum Amount of Automatic Drip Coffee to Use in BrewStation®

Coffee	Scoop	Tablespoons
Regular	13	13
Decaf	12	12

5

6

Set KEEP WARM HOURS to 1, 2, 3, or 4. The 0 setting is for iced coffee. 5

840177100 ENnv11.qxd:Layout 1 10/28/08 2:45 PM Page 6

How To Make Coffee (cont.) w WARNING Burn Hazard.

• Never use coffee tank to pour or carry hot coffee.

• Handle coffee tank only when holding cold water for filling water reservoir and to clean tank after BrewStation® has been shut off and the coffee is cool.

• If BrewStation® overflows, unplug unit. Allow unit, coffee, and grounds to cool before cleaning unit, coffee, or grounds.

7

8

Brew Options

BOLD

Enhanced full/strong-flavored coffee Press Brew Mode button until BOLD is displayed

1-4 CUPS

When brewing 1–4 cups of coffee Press Brew Mode button until 1–4 CUPS is displayed

Coffeemaker will beep when brewing is complete.

NOTE: BOLD and 1–4 CUPS modes will require additional time to complete a brewing cycle. A Brew Option must be selected prior to pressing the ON button. The setting cannot be changed during/in brew mode. If a Brew Option is not selected, the coffeemaker will automatically brew on the regular/default setting.

6

840177100 ENnv11.qxd:Layout 1 10/28/08 2:46 PM Page 7

To Make Iced Coffee

*Coffee scoop is optional feature on select models.

wWARNING Burn Hazard.

•Never use coffee tank to pour or carry hot coffee.

•Handle coffee tank only when holding cold water for filling water reservoir and to clean tank after BrewStation® has been shut off and the coffee is cool.

•If BrewStation® overflows, unplug unit. Allow unit, coffee, and grounds to cool before cleaning unit, coffee, or grounds.

1

Fill coffee tank with water. Do not fill beyond the 6-cup line when making iced coffee.

5

2

6

3

Fill coffee tank with ice to the

MAX FILL ICE line.

7

Set KEEP WARM HOURS to 0. Press ON.

4

Brew double-strength coffee for iced coffee. Add 2 scoops* or 2 level tablespoons of ground

coffee per cup (up to 12 scoops).

8

7

840177100 ENnv11.qxd:Layout 1	10/28/08	2:46 PM Page 8
Programming
1	2	3	4

To set clock: Press H and then M. NOTE: Clock time must be set for programming function to work.

To program auto brew: Press and hold START TIME until clock flashes. START TIME will appear in display.

Continue holding START TIME; then press H and M until the desired brewing start time is reached.

Press and release START TIME to activate automatic brewing. A green light will signal that the unit is in program mode.

	Water Filter (optional accessory)			For better tasting coffee, use a water filter.
				Filter replacement is recommended every 60 cycles.
					Water Filter (Optional Accessory)
					If using a water filter, it should be
					replaced every 60 cycles for best
					tasting coffee.
					To Order a Water Filter Call:
					1.800.851.8900 (U.S.)
					1.800.267.2826 (Canada)
					01.800.71.16.100 (Mexico)
		15 min.			or visit
	1		2	3	hamiltonbeach.com
	8				hamiltonbeach.ca

840177100 ENnv11.qxd:Layout 1 10/28/08 2:46 PM Page 9

Cleaning with Vinegar Clean BrewStation® at least once a month (once a week for areas with hard water).

1

Remove optional water filter.

5

Run 2–3 more brew cycles with CLEAN WATER only. Allow to cool between cycles.

2

Pour 1 pint (2 cups/500 ml) vinegar into water reservoir.

DISHWASHER-SAFE

3

4

Press ON. Turn OFF after 20 seconds and wait 30 minutes. Press ON. Turn

OFF when finished. When cool, dispense several cups before emptying and rinsing reservoir. NOTE: Coffeemaker will remind you it is time for cleaning in two ways:

•Built-in cycle timer—Every 30 cycles, CLEAN will flash in display and stay illuminated for 2 cycles.

•Built-in residue sensor—CLEAN will appear in display when unit senses residue buildup and remain illuminated until the unit has been cleaned.

General Cleaning Instructions

Inside of coffeemaker: Follow steps 1–5 in “Cleaning with Vinegar.”

Filter basket: Remove the filter basket and wash by hand with warm, soapy water or in top rack of dishwasher. Clean filter basket often.

Outside of coffeemaker: Wipe outside with a soft cloth and warm, soapy water. Do not use abrasive cleaners, as they will scratch the finish of the product.

9

840177100 ENnv11.qxd:Layout 1 10/28/08 2:46 PM Page 10

Troubleshooting

PROBLEM	PROBABLE CAUSE
Coffee leaks from dispenser.	• Coffee grounds trapped in coffee tank dispensing mechanism under seal in coffee tank.
		See “Cleaning with Vinegar.”
CLEAN appears in display.	• This is a reminder to clean coffeemaker. See “Cleaning with Vinegar.”
Coffee tastes bad.	• Coffeemaker needs cleaning.
	•	Coffee ground too coarsely or too finely. Set coffee grinder to automatic drip grind.
	•	Coffee-to-water ratio unbalanced. Adjust for personal preference.
	•	Poor water quality. Use water filter or bottled water to make coffee.
Coffee not brewing or stops	• Mineral deposits have built up. Clean the coffeemaker following “Cleaning with Vinegar.”
brewing/unit will not turn on.	• Water reservoir is empty.
	• Unit is unplugged.
	• Power outage or power surge. If surge, unplug; then plug back in.
Coffee brews slowly.	• Coffeemaker needs cleaning. Clean at least every 30 days to maintain proper performance.
	• Coffeemaker is in the 1–4 CUPS or BOLD modes. Press Brew Mode button until no lights appear.
Coffee overflows basket.	• Excessive amounts of coffee grounds. See Table on page 5.
	•	Coffee ground too finely. Set coffee grinder to automatic drip grind.
	•	More than one paper filter in filter basket. Poor quality paper filter or wrong size paper filter.
Unit beeps continuously/	• No water in reservoir. Transfer water from coffee tank to reservoir.
will not brew and/or POUR
WATER appears in display.
Coffee is cold	• Selected Keep Warm Hours have elapsed and coffeemaker has automatically shut off. Brew new
when dispensed.		cycle. See “How to Make Coffee.”

840177100 ENnv11.qxd:Layout 1 10/28/08 2:46 PM Page 11

Limited Warranty

This warranty applies to products purchased in the U.S. and Canada. This is the only express warranty for this product and is in lieu of any other warranty or condition.

This product is warranted to be free from defects in material and workmanship for a period of one (1) year from the date of original purchase. During this period, your exclusive remedy is repair or replacement of this product or any component found to be defective, at our option; however, you are responsible for all costs associated with returning the product to us and our returning a product or component under this warranty to you. If the product or component is no longer available, we will replace with a similar one of equal or greater value.

This warranty does not cover glass, filters, wear from normal use, use not in conformity with the printed directions, or damage to the product resulting from accident, alteration, abuse or misuse. This warranty extends only to the original consumer purchaser or gift recipient. Keep the original sales receipt, as proof of purchase is required to make a warranty claim. This warranty is void if the product is used for other than single-family household use.

We exclude all claims for special, incidental and consequential damages caused by breach of express or implied warranty. All liability is limited to the amount of the purchase price. Every implied warranty, including any statutory warranty or condition of merchantability or fitness for a particular purpose, is disclaimed except to the extent prohibited by law, in which case such warranty or condition is limited to the duration of this written warranty. This warranty gives you specific legal rights. You may have other legal rights that vary depending on where you live. Some states or provinces do not allow limitations on implied warranties or special, incidental or consequential damages, so the foregoing limitations may not apply to you.

To make a warranty claim, do not return this appliance to the store. Please call 1.800.851.8900 in the U.S. or 1.800.267.2826 in Canada or visit hamiltonbeach.com in the U.S. or hamiltonbeach.ca in Canada. For faster service, locate the model, type, and series numbers on your appliance.

11
