Goal Zero Venture 30 User guide [ml]

1

Table of Contents

Get To Know Your Gear 2

Charge Before Use 3

Solar Ready™ 3

Charge Your Gear 4

Smart Charge Sequence 5

Flashlight 5

Rugged Design 6

PLUG ME IN

Venture 30 is in protective shipping mode.

Plug it into a USB port before using.

BRANCHEZ-MOI: Votre Venture 30 est en mode de transport. Branchez-le sur un port USB avant de l’utiliser.

これを差 し込んで下さい Venture 30は保護モードで出荷されています。ご使用前にUSBポートに差し込んで下さい。

STECK MICH ZUERST EIN: Das Venture 30 wird im Schutzmodus geliefert. Vor dem ersten Gebrauch in einen USB-Port einstecken.

CONÉCTEME: El Venture 30 está en modo protector de envío. Conéctelo a un puerto USB antes de usarlo.

Shipping and Storage Mode 6

Restore Factory Settings 6

Troubleshooting 7

Technical Specifications 7

Français 8 - 13

日本語

Deutsch 20 - 25

Español 26 - 31

14 - 19

1

GET TO KNOW YOUR GEAR

Create custom charging
profiles. Fast.

7,800 mAh

Advanced, long-lasting
lithium internal battery.

Micro USB Cable

Charge your gear

IPX6Smart Charge

Weatherproof,
shock-proof design.

CHARGE BEFORE USE

Use the built-in cable to charge up Venture
30 from a live USB source. A new Venture
30 comes in a protective mode to prevent
self-discharge, potentially caused by long
periods of inactivity, like shipping.

The Venture 30 will not charge your gear
until it is plugged into a live USB source.

1. Unplug the USB end of the cable and
plug it into a live USB port.

2. Know it’s charging when blue indicator
lights on the top illuminate and pulse.
Each blue indicator light represents
20% battery capacity. Blue indicator

lights will flash according to how quickly
Venture 30 is charging. A slow flash

indicates a slow charge, while quicker
flashing indicates faster charging.

3. Venture 30 is full and ready to go when
all lights are pulsing together.

Venture 30 allows for pass-through power
so you can charge your gear and Venture 30
at the same time. When Venture 30’s battery
is dead, the first blue indicator light will flash
when the Battery button is pushed.

USB

5 Hrs Micro & USB Devices

Smartphone, Tablets, and more

Light | Indicator

65 lumen flashlight

& battery level indicator

2

USB Ports

Charge your gear

Charging Cable

Charge Venture 30

SOLAR READY™

Venture 30 is engineered to charge quickly
from Goal Zero Nomad

1. Unplug the USB end of the built-in cable
and plug it into the USB port on the back
of the Nomad panel.

2. Know it’s charging when blue indicator
lights illuminate and pulse. Each blue
indicator light represents 20% battery
capacity.

3. Venture 30 is full and ready to go when
all lights are pulsing together.

Blue indicator lights will flash according
to how quickly Venture 30 is charging.
A slow flash indicates a slow charge,
while quicker flashing indicates faster
charging.

When charging from solar, angle
your panel toward the sun to see
how it affects charging.

USB port on back of
Nomad 7 Solar Panel

®

Solar Panels.

Nomad 7

Solar Panel

8 Hrs

Full Sun

Micro & USB Devices

Smartphone, Tablets, and more

3

CHARGE YOUR GEAR

Venture 30 is designed to charge POV cameras, phones, tablets, and other USB-powered devices.

7”

Headlamp

1. Using your charging cable, plug into

POV Camera5xPhone

5-10x

Venture 30’s USB ports – they’ll both
work at the same time at 2.4A so you can
share power with a buddy.

2-3x

Tablet

1x

SMART CHARGE SEQUENCE

Venture 30’s advanced smart charging
feature allows you to optimize and adapt its
USB outputs to charge your gear as fast as
possible. This sequence runs independently
for both USB ports – meaning you can set
different charging profiles for each port.
Fastest profiles will be applied and saved
until reset or the sequence is run again.

1. With your gear plugged into Venture 30’s
USB port, press and hold the Battery
button for approximately 5 seconds to
activate the smart charge sequence.

2. The blue indicator lights will begin
to flash as different profiles are
automatically tested with your gear.

3. When the lights finish flashing, the
fastest profile has been selected.

Battery Button

HOW IT WORKS: You might have noticed if you plug
your device into a charger claiming a high output your
device still charges slowly. How quickly your device
charges comes down to communication between the
charger and what you plug in. Every device has its own
preference when it comes to charging, the challenge
is identifying the language used by the manufacturer
to decode that preference. Venture 30’s smart
charging feature acts as a translator, identifying your
device’s language, decoding and applying the fastest
charging profile possible, without overcharging or
overheating. This feature makes Venture 30 one of
the most compatible chargers on the market.

We recommend running the smart charge sequence
anytime you experience slow charge times or when
plugging in new gear.

Blue Indicator Lights

2. If your device charges from micro USB,
use the built-in cable.

3. The blue indicator lights will flash

according to how quickly your gear is
charging. A slow flash indicates a slow

charge, while quicker flashing indicates
faster charging. If you’re experiencing
slow charge times, run the smart charge
sequence (see next section) and ensure
Venture 30 is fully charged.

FLASHLIGHT

Venture 30 comes with a built-in 65 lumen
flashlight with three settings:

high, low, and strobe.
TURN ON/OFF

Press the Flashlight button to turn on the
65 lumen flashlight.

Flashlight

FLASHLIGHT SETTINGS

1. Press and hold the Flashlight button for
approximately 5 seconds – all the lights
will flash once indicating you’ve entered
flashlight selection mode.

2. With the Flashlight button still held
down, press the Battery button to cycle
through 5 light modes.

Whichever mode you are in when you release

the Flashlight button will become the default
mode. Avoid looking into the light when you

turn it on – it’s pretty dang bright.

Flashlight Button

54

RUGGED DESIGN

Venture 30 comes equipped with an IPX6 rating. Spray it down, take it to the beach, leave
it in the rain – and never worry about rubber plugs. It’s engineered to get out, stay out and
handle whatever Mother Nature can throw your way – even a quick drop in a puddle.

Do not submerge Venture 30.

TROUBLESHOOTING

Gear not charging?

1. Check the battery level of Venture 30 by pressing the Battery button. When Venture 30’s
battery is dead, the first blue indicator light will flash when the Battery button is pushed.

SHIPPING AND STORAGE MODE

If you won’t be using Venture 30 for long periods of time, reactivate the shipping/storage
mode to prevent self-discharge. This also resets Venture 30 to default factory settings.

1. Hold the Battery button for approximately 30 seconds, until the lights flash.

2. Release the Battery button.

3. Exit this mode by plugging Venture 30 into a live USB source.

RESTORE FACTORY SETTINGS

Used to erase all saved charging profiles and set Venture 30 to shipping/storage mode.

1. Press and hold the Battery button for approximately 30 seconds until the lights flash.
Venture 30 is now reset and in shipping/storage mode.

2. To reactivate Venture 30, plug it into a live USB port, the blue lights will flash, indicating
Venture 30 is ready for charging.

Lost charging cable? That’s OK, Venture 30 can be charged from any micro-USB cable. You
can also buy a new one from us at GoalZero.com

2. Charge up Venture 30 by using the included cable or solar.

3. Try a soft reset of Venture 30 (see below).

Soft Reset: Used to restart a frozen Venture 30, or if you’re having trouble charging gear.

1. Press and hold the Flashlight button for approximately 30 seconds. You’ll see an initial
flash of the lights, indicating you’re entering flashlight selection mode.

2. Continue holding until the lights flash twice in a row. The blue LED lights will also flash,
indicating a successful reset.

3. Press the Battery button or wait 5 seconds to resume normal operation.

TECHNICAL SPECIFICATIONS

Venture 30 Recharger

CHARGE TIMES:

GOAL ZERO Nomad 7 8-16 hrs

GOAL ZERO Nomad 13 6-12 hrs

GOAL ZERO Nomad 20 5-6 hrs

2A USB Source 5 hrs

BATTERY:

Cell chemistry Li-ion NMC

Cell type 18650 by LG chem/

Cell capacity 28Wh (3.6V, 7800mAh)

Lifecycles hundreds of cycles

Shelf-life Keep plugged in, or

Fuses none

Management system Charging and low-battery

Samsung

charge every 3-6 months

protection built-in

PORTS:

USB port (output) 5V, up to 2.4A (12W

USB-micro port (input) 5V, up to 2.1A (10.5W

GENERAL:

IP Rating IPX6

Chainable No

Weight 8.8 oz (250g)

Dimensions 4.5 x 3.25 x 1 in (11.4 x

Operating usage
temperature

Certifications CE, FCC, ROHS

Warranty 12 months

max), regulated

max)

8.25 x 2.5 cm)

-4-140F (0-40C)

Be sure to ACTIVATE YOUR WARRANTY
at goalzero.com/warranty

76

FRANÇAIS

Créer des profils de charge
personnalisés. Rapidement.

Lampe | Indicateur

Lampe 65 lumens et

indicateur de niveau de

batterie

7,800 mAh

Batterie nouvelle génération
au lithium longue durée.

Câble micro-USB

Rechargez vos appareils

Ports USB

Rechargez vos appareils

IPX6Séquence de charge intelligente

Conception étanche
et anti-choc.

Câble de charge

Chargez votre Venture 30

CHARGER AVANT PREMIÈRE UTILISATION

Utilisez le câble intégré pour charger votre
Venture 30 à partir d’un port USB d’alimentation.
Un Venture 30 neuf est vendu dans un mode
de protection pour empêcher une décharge
automatique, potentiellement causée par une
longue période d’inactivité, comme le temps de
sa livraison.

Venture 30 ne pourra recharger vos appareils
qu’une fois branché sur un port USB
d’alimentation.

1. Débranchez l’extrémité USB du câble et
branchez-le sur un port USB d’alimentation.

2. Vous savez qu’il est en mode de recharge
lorsque les voyants bleus s’allument et
clignotent. Chaque voyant bleu représente
20% de capacité de sa batterie. Les voyants
bleus clignotent selon la rapidité de recharge
du Venture 30. Un clignotement lent indique
une charge lente, tandis qu’un clignotement
rapide indique une recharge plus rapide.

SOLAR READY™

Votre Venture 30 est conçu pour se charger
rapidement depuis les panneaux solaires

®

de Goal Zero.

Nomad

1. Débranchez l’extrémité USB du câble
intégré et branchez-le sur le port USB à
l’arrière du panneau solaire Nomad.

2. Vous savez qu’il est en mode de recharge
lorsque les voyants bleus s’allument et
clignotent. Chaque voyant bleu représente
20% de capacité de sa batterie.

3. Votre Venture 30 est entièrement rechargé
lorsque tous les voyants clignotent
simultanément

Les voyants bleus clignotent selon la rapidité
de recharge du Venture 30. Un clignotement
lent indique une charge lente, tandis qu’un
rapide clignotement indique une recharge
plus rapide.

Lors d’une recharge par de l’énergie
solaire, orientez votre panneau solaire
plus ou moins directement vers le
soleil pour voir comment cela affecte la
vitesse de charge.

Port USB à l’arrière du
panneau solaire Nomad 7

3. Votre Venture 30 est entièrement rechargé
lorsque tous les voyants clignotent
simultanément.

Votre Venture 30 permet à l’énergie de le
traverser, de sorte que vous puissiez charger
vos équipements et votre Venture 30 en même
temps. Lorsque la batterie de votre Venture
30 est déchargée, seul le premier voyant bleu
clignote lorsque le bouton de batterie est pressé.

Port USB

5 Hrs Périphériques

Panneau solaire

Nomad 7

8 heures

Plein soleil

Micro-USB & USB

Téléphone, tablettes et

bien plus encore.

Périphériques

Micro-USB & USB

Téléphone, tablettes et

bien plus encore.

98

9
