User Guide
Gateway FPD Monitor
Contents
Using Your FPD Monitor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Connecting the monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Starting the monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Adjusting monitor settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
External controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
On screen display options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Software controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Video modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Power management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
ENERGY STAR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Energy declaration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
No power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
No picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Display colors are wrong . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Picture has shadows or “ghosts” . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Color is not uniform . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Image is not sized or centered correctly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
The monitor has pixels that are always dark or too bright . . . . . . . . . . . . . . . . . . . . . . 19
FPD 1530 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
FPD 1730 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
FPD 1830 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
FPD 1930 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Safety, Regulatory, and Legal Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
www.gateway.com
i
ii
www.gateway.com
Gateway
Using Your FPD Monitor
■ Connecting the monitor
■ Starting the monitor
■ Adjusting monitor settings
■ Maintenance and troubleshooting
■ Specifications
1
Connecting the monitor
To connect the monitor:
1 Position your computer and the monitor so you can easily reach the back panel of
each.
2 Set the monitor upright, then feed the power cable and the attached video cable
through the hole in the stand.
3 Lay the monitor on its back.
4 Connect the power cord to the power connector under the bottom of the screen.
2
www.gateway.com
5 If your computer supports analog video, connect the analog video cable to the analog
connector under the bottom of the screen.
- OR -
If your computer supports digital video, connect the digital video cable to the DVI
connector under the bottom of the screen (FPD 1830 and FPD 1930 only).
Important The FPD 1530 and FPD 1730 monitors have one connection. These
monitors do not support digital video.
Make sure that you only connect one video cable to the FPD 1830
and FPD 1930 monitor and computer. The only way to use both
connections it to share the monitor between two computers. Use the
SOURCE button to change between computers. For more
information, see “Adjusting monitor settings” on page 7.
6 Return the monitor to its upright position.
www.gateway.com
3
7 Make sure that your computer is turned off. 8 If your computer supports analog video, connect the analog video cable to the
matching video port on the back of your computer.
- OR -
If your computer supports digital video, connect the digital video cable (FPD 1830
and FPD 1930 only) to the matching video port on the back of your computer.
4
www.gateway.com
9 Plug the power cord into a correctly grounded electrical outlet.
www.gateway.com
5
Starting the monitor
To start the monitor:
1 Press the power button on the monitor. The power LED turns on.
Power button
and LED
2 Turn on your computer. 3 After your computer is running, the power LED on the monitor should be green. Allow
about 10 seconds for the display image to appear. If the power LED is not green or
you do not see a display image, check the connections. For more troubleshooting
information, see “Troubleshooting” on page 17.
4 Adjust the tilt of the monitor for the best viewing angle. 5 After you see the Windows desktop, press the AUTO/SET button to automatically adjust
the display image to the ideal settings.
6 Use the on-screen display (OSD) to adjust other monitor settings. For more
information, see “Adjusting monitor settings” on page 7.
Important When adjusting the monitor settings, always press the AUTO/SET
button before entering the OSD. This will automatically adjust the
display image to the ideal settings for the current screen resolution.
6
www.gateway.com
Adjusting monitor settings
Use the external controls (located on the monitor itself) and software controls (accessible
in Windows) to adjust the display image. For more information about software controls,
see “Software controls” on page 12.
External controls
These monitors feature an on-screen display (OSD) that lets you adjust and save contrast,
brightness, and other settings for the monitor. The monitor saves changes you make to
the settings, even if you turn off the monitor.
FPD 1530 and FPD 1730
OSD button
Menu selection arrows
■ OSD.
Press to open the OSD. Press again to exit.
■ Arrows.
OSD active: Press to select or adjust OSD options.
OSD inactive: Press and to adjust the contrast. Press and to adjust the
brightness.
■ AUTO/SET.
OSD active: Press to enter a selection in the OSD.
OSD inactive: Press to automatically optimize the monitor’s image position, clock, and
phase.
AUTO/SET button
www.gateway.com
7
FPD 1830 and FPD 1930
OSD button
Menu selection arrows
Up arrow also AUTO button
■ OSD.
SOURCE/SET button
Press to open the OSD. Press again to exit.
■ Arrows.
OSD active: Press to select or adjust OSD options.
OSD inactive: Press and to adjust the contrast. Press and to adjust the
brightness. If your monitor is connected to an analog video port, press the up arrow
button (
■ SOURCE/SET.
AUTO ) to automatically optimize your display's position, clock, and phase.
OSD active: Press to enter a selection in the OSD.
OSD inactive: Press to view the source signal or switch between computers if you have
two computers connected to the monitor.
8
www.gateway.com
On screen display options
To adjust the OSD settings:
1 Press the OSD button. The OSD menu opens. 2 Use the and buttons to highlight a control, then press the AUTO/SET button. 3 Use the , , and buttons to adjust the control to the desired level. 4 When you have finished making all adjustments, press the OSD button to exit the
OSD.
OSD menus
You can access any of these menus in the OSD:
OSD Menu Description
Brightness. Adjusts the amount of light in the
darkest portion of the picture. Use the lowest
brightness setting you are comfortable with to
maximize the life of the monitor backlights.
You may need to readjust brightness after the
monitor has warmed up.
Contrast. Adjusts the level of white between the
lightest and darkest portions of an image.
www.gateway.com
9
OSD Menu Description
Preset. Adjusts the color temperature.
9300K is bluish white.
6500K is reddish white.
Red, Green, Blue. Customizes the color levels.
Vertical position. Moves the display image up
and down.
Horizontal position. Moves the display image
left and right.
You can also use the Auto function to configure
the vertical and horizontal position
automatically. For more information on the Auto
function, see “External controls” on page 7.
10
Clock. Minimizes any vertical bars or stripes
visible on the screen background. The
horizontal screen size will also change.
Phase. Removes any horizontal distortion and
clears or sharpens the display image text
characters.
www.gateway.com
OSD Menu Description
FPD 1530 and FPD 1730
FPD 1830 and FPD 1930
MODE INFO ON
1280 x 1024 @60.0Hz
Language. Changes the language of the OSD
display.
OSD Position. Changes the position of the
OSD menu on the screen.
/
Language. Changes the language of the OSD
display.
OSD Position. Changes the position of the
OSD menu on the screen.
Mode Info. When changing screen resolution
settings (for example, size or number of colors),
display information is briefly shown on the
screen.
DSUB ANALOG
www.gateway.com
11
Software controls
Color depth and screen resolution are two of the most basic monitor settings you may
need to change.
Adjusting the color depth
Color depth is the number of colors your video card uses. Most images look best displayed
with the maximum number of colors available.
Windows lets you choose from several color depth settings for the monitor. We recommend
that you use the 32-bit True Color setting or the highest setting available at all times.
If the color in your images seems “false” or “jumpy,” especially after you have played a
game or run a video-intensive program, check the color depth setting and return it to 32-bit
True Color, if necessa r y.
To change the color depth:
1 In Windows XP, click Start, then click Control Panel. The Control Panel window opens.
If your Control Panel is in Category View, click
- OR -
Appearance and Themes.
In Windows 2000, click
window opens.
Start, Settings, then click Control Panel. The Control Panel
2 Click/Double-click the Display icon. The Display Properties dialog box opens.
12
www.gateway.com
3 Click the Settings tab.
4 Click the arrow button to open the Color quality or Colors list, then click the color
depth you want.
5 To save your changes in Windows XP, click OK, then click Yes.
- OR -
To save your changes in Windows 2000, click
Help and
Support
For more information about adjusting monitor settings in Windows XP, click Start, then click Help and Support.
Type the keyword changing display settings in the Search box
, then click the arrow.
OK, then click OK again
Adjusting the screen resolution
You can change the screen resolution to a size you prefer. For example, you can increase
the resolution to fit more icons on your desktop, or you can decrease the resolution to
make reading and identifying objects on the monitor easier. The higher the resolution,
the smaller individual components of the screen (such as icons and menu bars) appear.
www.gateway.com
13
To change the screen resolution:
1 In Windows XP, click Start, then click Control Panel. The Control Panel window opens.
If your Control Panel is in Category View, click
- OR -
Appearance and Themes.
In Windows 2000, click
window opens.
Start, Settings, then click Control Panel. The Control Panel
2 Click/Double-click the Display icon. The Display Properties dialog box opens. 3 Click the Settings tab.
4 Drag the Screen resolution or Screen area slider to the size you prefer. 5 To save your changes in Windows XP, click OK, then click Yes.
- OR -
14
To save your changes in Windows 2000, click
Help and
Support
For more information about adjusting screen resolution in
Windows XP, click Start, then click Help and Support.
Type the keyword changing screen resolution in the Search box
, then click the arrow.
www.gateway.com
OK, then click OK again.
Video modes
The monitor supports several video modes. Best screen resolution is:
■ FPD 1530 – 1024 × 768
■ FPD 1730 – 1280 × 1024
■ FPD 1830 – 1280 × 1024
■ FPD 1930 – 1280 × 1024
The supported video modes are:
Screen Resolution
(display mode)
1 640 × 480 31.47 kHz 60 Hz
2 640 × 480 37.5 kHz 75 Hz
3 720 × 400 31.47 kHz 70 Hz
4 800 × 600 37.88 kHz 60 Hz
5 800 × 600 46.88 kHz 75 Hz
6 1024 × 768 48.36 kHz 60 Hz
7 1024 × 768 61.12 kHz 75 Hz
8 1280 × 1024 63.98 kHz 60 Hz
Horizontal
Frequency
Vertical
Frequency
If you do not use the best mode for the monitor, the display image may look slightly
“fuzzy” or may have a black border around the edges.
www.gateway.com
15
Power management
ENERGY STAR
As an ENERGY STAR® Partner, Gateway has determined that this product meets the
ENERGY STAR guidelines for energy efficiency.
This monitor complies with the EPA's International ENERGY STAR Program, which is a
program designed to encourage manufacturers of computer equipment to build circuitry
into their products to reduce energy consumption during time of non-use.
Energy declaration
When connected to a computer that supports the VESA Display Power Management
Signaling (DPMS) Protocol, this monitor can conserve significant energy by reducing power
consumption during periods of non-use. When your computer goes into the energy saving
mode, the monitor will then enter the Active Off mode (different from total shut down).
In the Active Off mode the Power LED will still show orange.
Use these conventions and the power can be reduced to the following levels:
VESA State LED Indicator Power Consumption
On Green FPD 1530 – <35 W
FPD 1730 – <45 W
FPD 1830 – <55 W
FPD 1930 – <45 W
Active Off Orange All models – 2 W
To “wake” the monitor when it is in Active Off mode, move your mouse or press any
keyboard key.
Access the power management options in the Control Panel to change the period of time
after which the monitor enters these low power states.
16
www.gateway.com
Maintenance
To keep the monitor in optimal working order:
■ Do not block the ventilation holes.
■ Do not expose the monitor to rain or use near water.
■ Keep the monitor away from radiators or heat vents.
■ Keep the monitor out of direct sunlight.
To clean the monitor, use a soft cloth lightly moistened with water only. Wipe the cabinet,
screen, and controls.
Caution Do not use any type of abrasive pad or glass cleaner. You will
permanently scratch the screen.
Troubleshooting
If you have problems with the monitor, the information in this troubleshooting section
may help you solve them.
Important Make sure that the monitor has warmed up for approximately
30 minutes before making any judgments about the picture quality.
No power
Make sure that the power cord is connected correctly to both the back of the monitor
and the wall outlet. For more information about connecting the power cord, see
“Connecting the monitor” on page 2.
www.gateway.com
17
No picture
■ Make sure that the power cord is connected correctly to both the back of the monitor
and the wall outlet. For more information about connecting the power cord, see
“Connecting the monitor” on page 2.
■ Make sure that the video cable is connected securely to the back of the monitor and
your computer. For more information about connecting the video cable, see
“Connecting the monitor” on page 2.
■ Make sure that the monitor power button is turned on.
■ If you have two computers connected to the monitor (FPD 1830 and FPD 1930 only),
press the
computers. For more information about the
controls” on page 7.
■ If the power LED is orange:
■ Make sure that your computer is turned on.
■ Move the mouse or press any key on the keyboard to bring the monitor out of
Active Off mode.
■ Restart your computer with the monitor turned on.
■ Make sure that the video cable is not damaged.
■ Check the video port and the end of the video cable for any pins that might be
bent or pushed in.
SOURCE/SET button on the front of the monitor to switch between
SOURCE/SET button, see “External
■ Turn off the monitor and unplug the video cable from the back of your computer.
Turn the monitor back on and wait for ten seconds. If the monitor is functioning
correctly, a self-diagnostic screen appears. For more information about connecting the
video cable, see “Connecting the monitor” on page 2.
Display colors are wrong
■ Press the AUTO/SET or AUTO button, depending on the monitor model, to
automatically adjust the display image to the ideal settings. For more information,
see “External controls” on page 7.
■ Restart your computer with the monitor turned on.
■ Make sure that the video cable is connected securely to the back of the monitor and
your computer. For more information about connecting the video cable, see
“Connecting the monitor” on page 2.
■ Make sure that the video cable is not damaged.
■ Check the end of the video cable for any pins that might be bent or pushed in.
18
www.gateway.com
Picture has shadows or “ghosts”
■ Press the AUTO/SET or AUTO button, depending on the monitor model, to
automatically adjust the display image to the ideal settings. For more information,
see “External controls” on page 7.
■ Remove any extension cables or switchboxes.
■ Make sure that the video cable is connected securely to the back of the monitor and
your computer. For more information about connecting the video cable, see
“Connecting the monitor” on page 2.
■ Make sure that the video cable is not damaged.
■ Check the end of the video cable for any pins that might be bent or pushed in.
Color is not uniform
■ Make sure that the monitor warms up for at least 30 minutes before making a final
judgment about color uniformity or brightness.
■ Press the AUTO/SET or AUTO button, depending on the monitor model, to
automatically adjust the display image to the ideal settings. For more information,
see “External controls” on page 7.
Image is not sized or centered correctly
■ Press the AUTO/SET or AUTO button, depending on the monitor model, to
automatically adjust the display image to the ideal settings. For more information,
see “External controls” on page 7.
■ Use the position controls to adjust the image. For instructions on how to adjust the
display image position, see “Adjusting monitor settings” on page 7.
The monitor has pixels that are always dark or too bright
This condition is normal and inherent in the TFT technology used in active-matrix LCD
screens. Gateway’s inspection standards keep these to a minimum. If you feel these pixels
are unacceptably numerous or dense on your display, contact Gateway Technical Support
to identify whether a repair or replacement is justified based on the number of pixels
affected.
www.gateway.com
19
FPD 1530 Specifications
Specifications are subject to change without notice or obligation.
Monitor
Best screen resolution
Display colors
Power input
Power consumption
Dimensions
Power management
Certifications
Many products for Gateway and its subsidiaries are custom engineered by our suppliers
to Gateway specifications and may vary from similarly marketed products.
15-inch active-matrix TFT (Thin Film Transistor) LCD
1024 × 768
Over 16 million colors
AC 100-240 V 50/60 Hz 0.6 A
Normal operation: <35 W
Active Off operation: 2 W
14.96 × 8.07 × 14.45 inches (W × D × H)
38.0 × 20.5 × 36.7 cm) (W × D × H)
Meets EPA ENERGY STAR® and VESA DPMS requirements
UL, cUL, EPA, NOM, and FCC Class B
20
www.gateway.com
FPD 1730 Specifications
Specifications are subject to change without notice or obligation.
Monitor
Best screen resolution
Display colors
Power input
Power consumption
Dimensions
Power management
Certifications
Many products for Gateway and its subsidiaries are custom engineered by our suppliers
to Gateway specifications and may vary from similarly marketed products.
17-inch active-matrix TFT (Thin Film Transistor) LCD
1280 × 1024
Over 16 million colors
AC 100 – 240 V 50/60 Hz 1.0 A
Normal operation: <45 W
Active Off operation: 2 W
16.14 × 8.07 × 16.496 inches (W × D × H)
41.0 × 20.5 × 41.9 cm (W × D × H)
Meets EPA ENERGY STAR® and VESA DPMS requirements
UL, cUL, EPA, NOM, and FCC Class B
www.gateway.com
21
FPD 1830 Specifications
Specifications are subject to change without notice or obligation.
Monitor
Best screen resolution
Display colors
Power input
Power consumption
Dimensions
Power management
Certifications
Many products for Gateway and its subsidiaries are custom engineered by our suppliers
to Gateway specifications and may vary from similarly marketed products.
18-inch active-matrix TFT (Thin Film Transistor) LCD
1280 × 1024
Over 16 million colors
AC 100 – 240 V 50/60 Hz 1.0 A
Normal operation: <55 W
Active Off operation: <2 W at AC 115 V
17.40 × 8.07 × 16.89 inches (W × D × H)
44.2 × 20.5 × 42.9 cm (W × D × H)
Meets EPA ENERGY STAR® and VESA DPMS requirements
UL, cUL, EPA, NOM, and FCC Class B
22
www.gateway.com
FPD 1930 Specifications
Specifications are subject to change without notice or obligation.
Monitor
Best screen resolution
Display colors
Power input
Power consumption
Dimensions
Power management
Certifications
Many products for Gateway and its subsidiaries are custom engineered by our suppliers
to Gateway specifications and may vary from similarly marketed products.
19-inch active-matrix TFT (Thin Film Transistor) LCD
1280 × 1024
Over 16 million colors
AC 100 – 240 V 50/60 Hz 1.0 A
Normal operation: <45 W
Active Off operation: 2 W
18.0 × 8.0 × 17.5 inches (W × D × H)
45.72 × 20.32 × 44.45 cm (W × D × H)
Meets EPA ENERGY STAR® and VESA DPMS requirements
UL, cUL, EPA, NOM, and FCC Class B
www.gateway.com
23
24
www.gateway.com
Gateway
Safety, Regulatory, and Legal
Information
■ Safety information
■ Regulatory statements
■ Notices
25
Important safety information
Your Gateway system is designed and tested to meet the latest standards for safety of information technology
equipment. However, to ensure safe use of this product, it is important that the safety instructions marked on the
product and in the documentation are followed.
Warning Always follow these instructions to help guard against personal injury
and damage to your Gateway system.
Setting up your system
■
Read and follow all instructions marked on the product and in the documentation before you operate your
system. Retain all safety and operating instructions for future use.
■
Do not use this product near water or a heat source such as a radiator.
■
Set up the system on a stable work surface.
■
The product should only be operated from the type of power source indicated on the rating label.
■
If your product has a voltage selector switch, make sure that the switch is in the proper position for your area.
The voltage selector switch is set at the factory to the correct voltage.
■
Openings in the monitor case are provided for ventilation. Do not block or cover these openings. Make sure
you provide adequate space, at least 6 inches (15 cm), around the system for ventilation when you set up your
work area. Never insert objects of any kind into the monitor ventilation openings.
■
Some products are equipped with a three-wire power cord to make sure that the product is properly grounded
when in use. The plug on this cord will only fit into a grounding-type outlet. This is a safety feature. If you are
unable to insert the plug into an outlet, contact an electrician to install the appropriate outlet.
■
If you use an extension cord with this system, make sure that the total ampere rating on the products plugged
into the extension cord does not exceed the extension cord ampere rating.
■
If you r sy ste m is fit ted wit h a T V Tuner, c abl e, or sa tellite receiver card, make sure that the antenna or cable
system is electrically grounded to provide some protection against voltage surges and buildup of static charges.
26
www.gateway.com
Care during use
■
Do not wal k on the pow er c ord or a llo w an ythin g to res t on it .
■
Do not spill anything on the system. The best way to avoid spills is to avoid eating and drinking near your
system.
■
Do not expose the monitor to rain or use near water. If the monitor does get exposed to moisture, unplug it
and allow it to dry for 24 hours. Call Gateway Technical Support for advice on whether the monitor is safe to
turn back on.
■
When the monitor is turned off, a small amount of electrical current still flows through the monitor. To avoid
electrical shock, always unplug all power cables and modem cables from the wall outlets before cleaning the
system.
■
Unplug the system from the wall outlet and refer servicing to qualified personnel if:
■
The power cord or plug is damaged.
■
Liquid has been spilled into the system.
■
The system does not operate properly when the operating instructions are followed.
■
The system was dropped or the cabinet is damaged.
■
The system performance changes.
Warning To prevent electric shock, never remove the cover. No user
serviceable parts inside. Refer servicing to qualified service
personnel.
Replacement parts and accessories
Use only replacement parts and accessories recommended by Gateway.
Warning Do not use Gateway products in areas classified as hazardous
locations. Such areas include patient care areas of medical and
dental facilities, oxygen-laden environments, or industrial facilities.
www.gateway.com
27
Regulatory compliance statements
United States of America
Federal Communications Commission (FCC) Unintentional emitter per FCC Part 15
This device has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15
of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio or television
reception. However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause interference to radio and television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
■
Reorient or relocate the receiving antenna
■
Increase the separation between the equipment and receiver
■
Connect the equipment to an outlet on a different circuit from that to which the receiver is connected
■
Consult the dealer or an experienced radio/TV technician for help.
Compliance Accessories: The accessories associated with this equipment are: shielded video cable. These
accessories are required to be used in order to ensure compliance with FCC rules.
FCC declaration of conformity
Responsible party:
Gateway Companies, Inc.
610 Gateway Drive, North Sioux City, SD 57049
(605) 232-2000 Fax: (605) 232-2023
This device complies with Part 15 of the FCC Rules. Operation of this device is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Caution Changes or modifications not expressly approved by Gateway could
void the FCC compliance and negate your authority to operate the
product.
California Proposition 65 Warning
Warning This product contains chemicals, including lead, known to the State
of California to cause cancer, birth defects or reproductive harm.
28
www.gateway.com
Canada
Industry Canada (IC) Unintentional emitter per ICES-003
This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus as set
out in the radio interference regulations of Industry Canada.
Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicables aux
appareils numériques de Classe B prescrites dans le règlement sur le brouillage radioélectrique édicté par Industrie
Canada.
EPA ENERGY STAR
As an E NER GY S TAR® Partner, Gateway has determined that this product meets the ENERGY
STAR guidelines for energy efficiency when used with a computer equipped with a Display Power
Management System.
ENERGY STAR
www.gateway.com
29
Notices
Copyright © 2004 Gateway, Inc.
All Rights Reserved
14303 Gateway Place
Poway, CA 92064 USA
All Rights Reserved
This publication is protected by copyright and all rights are reserved. No part of it may be reproduced or transmitted by any
means or in any form, without prior consent in writing from Gateway.
The information in this manual has been carefully checked and is believed to be accurate. However, changes are made
periodically. These changes are incorporated in newer publication editions. Gateway may improve and/or change products
described in this publication at any time. Due to continuing system improvements, Gateway is not responsible for inaccurate
information which may appear in this manual. For the latest product updates, consult the Gateway Web site at
www.gateway.com
damages resulting from any defect or omission in this manual, even if advised of the possibility of such damages.
In the interest of continued product development, Gateway reserves the right to make improvements in this manual and the
products it describes at any time, without notices or obligation.
Trademark Acknowledgments
Gateway and the Black-and-White Spot Design are trademarks or registered trademarks of Gateway, Inc. in the U.S. and
other countries. SpotShop, Spotshop.com, and Your:)Ware are trademarks of Gateway, Inc. Intel, Intel Inside logo, and
Pentium are registered trademarks and MMX is a trademark of Intel Corporation. Microsoft, MS, MS-DOS, and Windows are
trademarks or registered trademarks of Microsoft Corporation. All other product names mentioned herein are used for
identification purposes only, and may be the trademarks or registered trademarks of their respective companies.
. In no event will Gateway be liable for direct, indirect, special, exemplary, incidental, or consequential
30
www.gateway.com
MAN MON FPD15/17/18/19 GDE R1 04/04
Loading...
