IntroductIon > overvIew

IntroductIon

BlueChart® g2 is Garmin’s exclusive line of highly-detailed marine cartography. BlueChart
g2 cartography features smoother layering and better integration of map graphics for faster
redraws and more cohesive panning, scrolling, and zooming.

Overview

Blue Chart g2 features richer colors and shading for easier interpretation and improved
visibility. BlueChart g2 has all the detail of traditional BlueChart, but with additional
functions, such as an optional “mariner’s-eye view” map perspective. With BlueChart g2
preprogrammed data cards, you can access costal roads and points of interest (POIs) as well as
a growing worldwide database of high-quality navigationally signicant photos. These photos
give “real picture” detail for many harbors, ports, marinas and coastal features.

BlueChart g2 cartography features a growing database of aerial

photography to give mariners a visual overview of harbors,

marinas, waterways, and other points of reference.

BlueChart g2 User’s Guide

i

IntroductIon > IntroductIon

Additional BlueChart g2 enhancements include:

• Shaded depth contours

• Mariner’s eye view map perspective

• Port plans and navigationally signicant photos

• Improved IALA symbology

• Intertidal zones with spot soundings

• Navaids with view range and coverage

• Data on tides and currents

• Coastal roads, marinas, points of interest

• Wrecks, restricted areas, anchorages

• Shoals, spoilage, and more

Like all BlueChart cartography, BlueChart g2 cartography is styled to match the appearance
of paper charts when displayed on your Garmin chartplotter. Sharp, colorful, nely detailed
graphics let you see every cartographic contour and feature, with minimal panning and
zooming to bring the chart data into focus.

ii

BlueChart g2 User’s Guide

IntroductIon > table of contents

table of contents

Introduction ...................................................................................................... i

Overview ..................................................................................................................i

Warning ..................................................................................................................iv

Getting Started ................................................................................................ 1

Installing a BlueChart g2 Preprogrammed Data Card ........................................2

Viewing BlueChart g2 Information ................................................................ 3

Understanding BlueChart g2 Data ........................................................................3

Accessing Additional Object Information ............................................................5

Viewing Photos ................................................................................................................. 6

Accessing Paper-Chart-Specic Information ................................................................... 7

Understanding the Differences Between Electronic and Paper Charts ............8

Reporting Chart Errors .....................................................................................................8

Viewing Tide and Current Information .................................................................9

Appendix ....................................................................................................... 10

Caring for Your BlueChart g2 Data Card ............................................................10

Reading the ID Code on a BlueChart g2 Card ...................................................10

Purchasing BlueChart g2 Cards ......................................................................................10

Warranty Information ........................................................................................... 11

Product Registration ............................................................................................11

Contact Garmin ....................................................................................................11

Index .............................................................................................................. 12

BlueChart® g2 Data Card Order Form ......................................................... 13

BlueChart g2 User’s Guide

iii

IntroductIon > warnIng

Warning

Failure to avoid the following potentially hazardous situations could result in an
accident or collision resulting in death or serious injury.

When navigating, carefully compare BlueChart g2 information to all available navigation
sources, including information from visual sightings, and paper maps. For safety, always
resolve any discrepancies or questions before continuing navigation.

Use the electronic BlueChart g2 cartography only to facilitate, not to replace, the use of
authorized government charts. Ofcial government charts and notices to mariners contain all
information needed to navigate safely.

iv

BlueChart g2 User’s Guide
