Fisher & Paykel RHV3484L PRODUCT SPECIFICATIONS

SPEC SHEET › RHV3-484-L › Dual Fuel Range, 48", 4 Burners with 4 Induction Zones, LPG

Dimensions

Depth	29	1/8"
Height	35 3/4 - 36	3/4"
Width	47	7/8"

Features & Benefits

Cook with confidence

Our touchscreen interface provides an intuitive guided cooking experience that helps deliver perfect results, whether you’ve been cooking all your life or just starting out. Cook with a favorite method, a hero ingredient, or a go-

RHV3-484-L to cooking function or recipe. The screen tilts for improved ergonomics and optimal visibility while cooking.

Dual Fuel Range, 48", 4 Burners

with 4 Induction Zones, LPG

___

Professional

This range leverages smart cooking technology to give you perfect results. Induction and gas cooktops give you the best of both heat types - Gas provides immediate response and the ability to chargrill, while Induction offers instant heat and extremely precise controls. An intuitive, high resolution touch screen makes it easy to use, and beautiful design details ensure that this range is the jewel of the kitchen.

Stainless Steel

A PEACE OF MIND SALE

24 Hours 7 Days a Week Customer Support

T 1.888.936.7872 W www.fisherpaykel.com

Generous capacity

Two independently operating cavities provide a generous total capacity of 4.8 cu. ft. in the main cavity and 2.1 cu. ft. in the secondary. Designed to spread heat evenly so you can easily create several dishes at once. The main cavity is big enough to fit full size baking sheets.

Cooking flexibility

No matter what you're cooking, you've got the right heat to get perfect results. Each of the 15 oven functions in the main cavity and 11 in the secondary have been extensively researched and carefully designed to cater to a broad range of dishes and cooking styles. The handy food probe helps you monitor your progress.

Cooktop power

On the gas side of the cooktop, Sealed dual flow burners deliver power up to 19,000 BTU, while the induction side delivers up to 2100W. This finely tuned cooktop provides instant and immediate control from the highest heat to the most gentle simmer.

Design quality

This range has craftsmanship in every detail, with real stainless steel, castiron trivets, and beautifully weighted, halo illuminated dials. Each cavity features incandescent lights and full extension telescopic racks. From the robust legs to the powerful cooktop, this range is built to last.

Date: 24.10.2019 › 1

Easy to clean

The oven features a self-cleaning function and self-clean proof side racks, which don't need to be removed when using this function. The induction zones only need a quick wipe after use to keep them clean.

Specifications

Accessories

Adjustable feet covers	•
Branded coin end cap	•
Combustible situation (Sold seperately)	BGRV3-3048H
Food probe	•
Non combustible situation (Sold seperately)	BGRV2-3048 / BGRV2-1248
Recommended hood (Sold seperately)	HCB48-12_N
Square handle option (Sold seperately)	AH-R48
Cleaning
Dishwasher proof trivets	•
Main ovenSelf cleaning	•
Secondary OvenSelf cleaning	•
Self-clean proof side racks	•

SPEC SHEET › RHV3-484-L › Dual Fuel Range, 48", 4 Burners with 4 Induction Zones, LPG

Controls

Dual control oven dials	•
High resolution touch display	•
Metal illuminated dials	•
Multi-language interface	•
Precise cooking with food probe	•
Recipe & food based functions	•
Sabbath mode	•
Tilting touch screen interface	•
Wifi connectivity	•
Cooktop features
Auto rapid heat	•
Black enamelled pan	•
Gentle heat	3 settings (111°F, 158°F, 201°F)
Heat settings	9
Induction cooking technology	•
PowerBoost	•
Sealed range top	•
SmartZone	2
Vent trim included	Flat vent trim
Zone bridging	•

Cooktop performance

Max burner power	19000 BTU
Power back left	13000 BTU
Power back right	13000 BTU
Power front left	19000 BTU
Power front right	13000 BTU
Sealed Dual Flow Burners™	4
Simmer on all burners	140 °F
Total cooktop power	58000 BTU

Gas requirements

Fitting and pipe	½ NPT, min. #" # flex line
Supply Pressure (LPG)	11" to 14" W.C

Oven features

Concealed element	•
Electronic oven control	•
Full extension telescopic sliding shelves	2
Internal light	•
Main ovenLarge broil pan	•
Secondary Oven- 3/4 extension racks	2
True Convection	•

	Date: 24.10.2019 › 2
Oven functions
Main oven functions	15
Main ovenAir Fry	•
Main ovenBake	•
Main ovenClassic Bake	•
Main ovenClean	•
Main ovenConvection Bake	•
Main ovenConvection Broil	•
Main ovenDehydrate	•
Main ovenMaxi Broil	•
Main ovenPastry Bake	•
Main ovenPizza Bake	•
Main ovenRapid Proof	•
Main ovenRoast	•
Main ovenSlow Cook	•
Main ovenTrue Convection	•
Main ovenWarm	•
Secondary OvenBake	•
Secondary OvenConvection Bake	•
Secondary OvenConvection Broil	•
Secondary oven functions	11
Secondary ovenAir Fry	•
Secondary ovenClassic Bake	•
Secondary ovenMaxi Broil	•
Secondary ovenPastry Bake	•
Secondary ovenPizza Bake	•
Secondary ovenRapid Proof	•
Secondary ovenRoast	•
